Unify OpenScape SL5, OpenScape User Manual

OpenScape DECT Phone SL5 on OpenScape Cordless Enterprise

User Manual

A31003-D1000-U105-1-7619

Our Quality and Environmental Management Systems are implemented according to the requirements of the ISO9001 and ISO14001 standards and are certified by an external certification company.



Hofmannstr. 63, 81379 Muni ch/Germany

Reference No.: A31003-D1000-U105-1- 7619

The information provided in this document contains merely general descriptions or characteristics of performance which in case of actual use do not always apply as



described or which may change as a result of further development of the products.



An obligation to provi de the respective chara cteristics shall onl y exist if expressly agreed in the terms of contract.

Availability and technical specifications are subject to change without notice.

Unify, OpenScape, OpenStage and HiPath are registered trademarks of Unify GmbH & Co. KG. All other company, brand, product and service names are trademarks or registered trademarks of their respective holders.

unify.com

Contents 3

Contents

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Using the user guide effectively . . . . . . . . . . . . . . . . . . . . . . . . . 7

Safety notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Installing the charging cradle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Connecting the charger. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Setting up the handset for use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Starting up the telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Adjusting the handset settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Connecting the headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Connecting a USB data cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Getting to know your telephone . . . . . . . . . . . . . . . . . . . . . . . . 12

Control key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Menu guidance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Entering text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Incoming calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Message lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Handset directory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Opening the directory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Directory entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

vCard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Acoustic profile. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Saving appointments to the calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Notification of appointments/anniversaries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Displaying missed (unacknowledged) appointments/anniversaries . . . . . . . . . . . . . . . . . . . . . 22

Displaying/changing/deleting stored appointments. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Alarm clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Activating/deactivating the alarm clock and setting the wake-up time . . . . . . . . . . . . . . . . . . . 22

Alarm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Switching off / repeating the alarm after an interval (snooze mode). . . . . . . . . . . . . . . . . . . . . 23

Protecting against unwanted calls . . . . . . . . . . . . . . . . . . . . . . 23

Time control for external calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Switching off the ringtone when in the charging cradle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

4 Contents

Resource Directory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Additional functions using the PC interface . . . . . . . . . . . . . . . 26

Adjusting the handset settings . . . . . . . . . . . . . . . . . . . . . . . . . 28

Display and keypad. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Activating/deactivating automatic call answering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Changing the earpiece and speaker volume. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Adjusting the microphone sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Ringtones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Activating/deactivating the vibration alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Activating/deactivating advisory tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Own area code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Resetting the handset to the default settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Extending the handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Registering a handset to multiple base stations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Network mailbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Listening to messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Entering a number for the network mailbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Questions and answers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Disclaimer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Manufacturer's advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Authorization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Protecting our environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Contact with liquid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Character charts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Display icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Menu overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Accessing system functions. . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Contents 5

Making calls to multiple parties . . . . . . . . . . . . . . . . . . . . . . . . 45

Consultation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Call waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Override . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Transferring a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Toggling (switching between calls) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

Conducting a conference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Using the second call feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Caller list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Central directories (group directory) . . . . . . . . . . . . . . . . . . . . 56

Sending and receiving an entry or list of entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Call forwarding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Using call forwarding. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Delayed call forwarding. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Forwarding calls for a different terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Mailbox. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Using the OpenScape Xpressions mailbox function (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . 70

More features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Making calls using project assignment (cost billing) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Callback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Using a different telephone in the same way as your own . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Caller ID suppression . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Activating/deactivating do not disturb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Tracing a call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Entering commands via tone dialing (DTMF suffix dialing). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Parking/activating calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

System-wide speaker call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

System appointment function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Locking the telephone line to prevent misuse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

6 Overview

Overview

1Display 2 Status bar ( S. 40)

Icons display current settings and operating status of the phone

3Display keys ( S. 12) 4 Message key ( S. 18)

Access to calls and message lists;

Flashes: new message or new call

5 End call key, On/Off key

End call; cancel function; Go back one menu level Press briefly Return to idle status Press and hold Switch the handset on/off 

(in idle status)

Press and hold

6Hash key

Toggles between upper/lowercase and digits (when inputting text):

Press briefly

Lock/unlock the keypad (in idle status)

Press and hold

7 Microphone 8R key

Consultation (flash) (during a call:)

Press briefly

Enter dial pause Press and hold

9USB port

For exchanging data between the handset and PC

10 Star key

Switch from pulse dialing to tone dialing  (for the existing connection)

Press briefly

Open table of special characters  (when inputting text):

Press briefly

Switch ion/off all ringtones Press and hold

11 Headset port

(2.5 mm jack)

12 Key 1

Dial network mailbox Press and hold

13 Talk key / Handsfree key

Accept call; dial number displayed; switch between receiver and handsfree mode

Open redial list Press briefly Start dialing Press and

hold

14 Profile key

Switch between sound profiles (in idle status)

Press briefly

Mute call (in call state

Press briefly

Switch microphone Press and hold

15 Control key/Menu key ( S. 12)

Base 1

Calls

Using the user guide effectively 7

Using the user guide effectively

Icons

Keys

Microphone key

Display keys, e.g. OK, Back, Select, Change, Save

Procedures

Example: Activating/deactivating automatic call answering

Illustration in the user guide

¤ . . . use to select Settings OK Telephony OK Auto Answer

Change ( = on)

The features described in this user guide depend on how your handset is configured and the communication platform. Deviations to the range of functions described are therefore possible.

Warnings that if not heeded can result in injury to persons or damage to devices.

Important information regarding operation and proper handling or in relation to features that may incur costs.

Prerequisite for being able to carry out the following action.

Additional useful information.

Talk key / Handsfree key End call key

Number / letter keys to Star key / Hash key

Message key Control key rim / center

Step Follow this procedure

¤ When in idle status, press the center of the control key. 

The main menu opens.

¤ ¤ OK

Use the control key to navigate to the icon.

Confirm with OK. The submenu Settings opens.

¤ Tele ph ony ¤ OK

Use the control key to select the entry Te le p ho ny .

Confirm with OK. The submenu Te le p ho n y opens.

¤ Auto Answer The function to switch auto answer on/off appears as the first menu item. ¤ Change Activate or deactivate using Change. 

Function is activated / deactivated .

Not all of the functions described in this user guide are available in all countries or for all platforms.

8 Safety notes

Safety notes

Be sure to read this user guide and the safety precautions before using your telephone.

Explain their content and the potential hazards associated with using the device to your children.

The device cannot be used in the event of a power failure. It is not possible either to make emer- gency calls.

It is not possible to call emergency numbers either when the keypad lock is activated.

Do not use the device in environments with a potential explosion hazard (e.g. paint shops).

The devices are not splash-proof. For this reason, do not install them in a damp environment such as bathrooms or shower rooms.

Use only the power adapter indicated on the device.

Use only rechargeable batteries that corre spon d to the specification (see "Technical data"), as this could otherwise result in significant health risks and personal injury. Rechargeable batteries that are noticeably damaged must be replaced.

If you give your handset to a third party, make sure you also give them the user guide.

Remove faulty devices from use or have them repaired by our Service team, as they could interfere with other wireless services.

Do not use the device if the display is cracked or broken. Broken glass or plastic can cause injury to the hands or face. Send the device to our Service department to be repaired.

Do not hold the rear of the handset to your ear when it is ringing or when speaker mode is activated. Otherwise you may seriously and permanently impair your hearing.

Your handset is compatible with the majority of digital hearing aids on the market. However, perfect function with all hearing aids cannot be guaranteed.

The telephone may cause interference in analog hearing aids (humming or whistling) or cause them to overload. If you require assistance, please contact the hearing aid supplier.

Using your telephone may affect nearby medical equipment. Be aware of the technical conditions in your particular environment, e.g. doctor's surgery. If you use a medical device (e.g. a pacemaker), pl ease contact the device manufacturer. They will be able to advise you regarding the susceptibility of the device to external sources of high frequency energy (for the specifications of your handset, see "Technical data").

Getting started 9

Getting started

Contents of the package

• One handset,

• One battery cover (rear cover of handset),

• One battery,

• One belt clip,

• One user guide.

Installing the charging cradle

The charging cradle is designed for operation in closed, dry rooms within a temperature range of +5 °C to +45

°C.

The phone's feet do not usually leave any marks on surfaces. However, due to the multitude of different varnishes and polishes used on today's furnishings, the occurrence of marks on the surfaces cannot be completely ruled out.

Connecting the charger

¤ Connect the flat plug of the AC adapter . ¤ Insert the AC adapter into the power socket .

To remove the plug from the charging cradle again:

¤ Disconnect the AC adapter from the mains power supply. ¤ Press the release button . ¤ Pull out the plug .

Setting up the handset for use

The display is protected by a plastic film. Please remove the protective film!

Inserting the battery

Never expose the telephone to the influence of heat sources, direct sunlight or other electrical devices.

Protect the telephone from moisture, dust, corrosive liquids and fumes.

Only use a rechargeable battery as this could otherwise result in significant health risks and personal injury. For example, the outer casing of the batteries could be destroyed or the battery could explode. The phone could also malfunction or be damaged as a result of using batteries that are not of the recommended type.

¤ Insert battery with the contact surface facing

down .

¤ Then press the battery downwards until it

clicks into place .

¤ Align the protrusions on the side of the

battery cover with the notches on the inside of the casing .

123

10 Getting started

Re-opening the battery cover

Charging the batteries

¤ Charge the batteries fully prior to first use in the charging

cradle or using a standard USB power supply (

S. 11).

The batteries are fully charged when the power icon disappears from the display.

Attaching the belt clip

The handset has notches on each side for attaching the belt clip.

• Attaching the belt clip: Press the belt clip onto the back of the handset

until the tabs on the clip engage in the notches.

• Removing the belt clip: Press the center of the belt clip firmly with your

thumb. Press the nail of the thumb on your other hand up between the clip and the casing. Slide the clip upwards to remove.

Starting up the telephone

Changing the display language

You can change the display language if the telephone is set to a different language than that required.

¤ Press the middle of the control key . ¤ Press the keys and slowly in succession . . . the language set-

tings display appears and the set language (e.g. English) is highlighted ( = selected).

¤ Select a different language: Press the control key until the desired

language is marked in the di splay, e.g. Francais press the key on the right directly below the display to activate the language.

¤ To revert to idle status: Press the End call key and hold

Registering the handset

A handset can be registered to up to four base stations. The registration procedure depends on the base station.

On the handset

¤ . . . use to select Settings OK Registration OK Register Handset OK

. . . use to select the base station (if the handset is already registered to one or more base

stations) OK . . . Enter the registration PIN (8-position) OK

Once the registration process has been completed successfully, the handset returns to idle status.

¤ Remove the belt clip (if attached). ¤ Insert your fingernail into the notch at the bot-

tom of the casing and pull the battery cover upwards .

¤ To change the battery, insert your fin-

gernail into the notch in the casing and pull the battery upwards .

Only place the handset in the designated charger.

The battery may heat up during charging. This is not dangerous.

After a while, the charge capacity of the battery will decrease for technical reasons.

3 h

Deutsch

English

Fran cais

Getting started 11

Setting the date and time

Set the date and time so that the date and time can be assigned correctly to incoming calls and to enable the alarm to be used.

¤ Press the display key Time

or, if the date and time have already been set:

¤ . . . use to select Settings OK Date/Time OK

The active cursor position flashes . . . use to change the cursor position . . . use to switch between cursor positions

Enter date:

¤ . . . use to enter the day, month and year in 8-digit format,

e.g. for 15/08/2015.

Enter the time.

¤ . . . use to enter hours and minutes in 4-digit format, e.g.

for 07:15.

Save setting:

¤ Press the display key Save . . . the message Saved is shown on the display

and a confirmation tone is issued

Return to idle status:

¤ Press the End call key and hold

The phone is now ready for use!

Adjusting the handset settings

You can adjust the handset to suit your requirements in the Settings menu, for example you can select a different screensaver, a different color scheme for the display or different ringtones.

¤ . . . use to select Settings OK . . . use to select the submenu, for example Dis-

play & Keypad OK . . . navigate to the required function . . . select the setting Save

¤ To set tones and signals : Audio Settings confirm with OK . . . navigate to the required

function . . . select the setting Save

Connecting the headset

¤ Connect a headset with a 2.5 mm jack to the left side of the handset .

You will find headset recommendations on the product page at wiki.unify.com/ wiki/OpenScape_DECT_Phone_SL5.

The headset volume corresponds to the setting for the earpiece volume ( S. 29).

Connecting a USB data cable

For exchanging data between the handset and PC:

¤ Connect the USB data cable with micro-USB plug into the USB

socket at the bottom of the handset .

Connect the handset directly to the PC, not via a USB hub.

Calls Time

Date/Time

Date:

8/15/2015

Time:

12:00 AM

Back Save

12 Getting to know your telephone

Getting to know your telephone

Switching the handset on/off

Locking/unlocking the keypad

The keypad lock prevents any accidental use of the telephone.

Lock/unlock the keypad: Press and hold

Keypad lock activated: The following icon appears on the display

Control key

In the description below, the side of the control key (up, down, left, right) that you have to press in the different operating situations is marked in black, for example for "press right on the control key" or for "press the center of the control key".

In idle status

In submenus, selection and entry fields

Display keys

The display keys perform a range of functions depending on the operating situation.

Display key icons S. 40.

Menu guidance

The functions of your telephone are displayed on a menu that consists of several levels.

Select/confirm functions

Switch on: ¤ When the handset is switched off, press the End call key and hold

Switch off:

¤ When the telephone is in idle status, press the End call key and hold

When a call is indicated on the handset, the keypad automatically unlocks and you can accept the call. It then locks again when the call is finished.

Important: It is not possible to call emergency numbers either when the keypad lock is activated.

The control key enables you to navigate the menus and input fields and also to call up certain functions depending on the situation.

Open the directory Press briefly Open the main menu or Open the system menu Adjust the speaker volume

Confirm a function

The display keys have a function preset by default in idle status. Change the assignment: S. 32

Confirm selection using OK or press the center of the control key

Go back one level using Back

Switch to idle mode using Press and hold

Switch function on/off using Change on / off

Activate/deactivate option using Select activated / deactivated

Current display key functions

Display keys

Back Save

Getting to know your telephone 13

Main menu

In idle status: press the center of the control key . . . select the

submenu using the control key OK

The main menu functions are shown in the display as icons. The icon for the selected function is highlighted in color and the name of the associ

ated function appears in the display header.

Submenus

The functions in the submenus are displayed as lists.

To access a function: . . . use the control key to select a function OK

Return to the previous menu level:

¤ Press the display key Back

¤ Press the End call key briefly

Returning to idle status

¤ Press the End call key and hold

Entering text

Input position

¤ Use to select an input field. A field is activated when the cursor is

flashing inside it.

¤ Use to move the position of the cursor.

Correcting incorrect entries

• Delete characters to the left of the cursor: Press briefly

• Delete words to the left of the cursor: Press and hold

Entering letters/characters

Multiple letters and numbers are assigned to each key between and

and the key. As soon as a key is pressed, the possible characters are displayed at the bottom of the display. The selected character is highlighted.

• Select letters/digits: Press the key briefly several times in succession

• Switch between lowercase, uppercase and number entry mode: Press the hash key

When editing a directory entry, the first letter and each letter following a space are automatically in uppercase.

• En ter special characters: Press the star key . . . use to navigate to the desired character

Insert

If no key is pressed, the display will automatically change to idle status after around 2 minutes.

The availability of special characters depends on the character set of the handset,

Character

set tables S. 38.

Example

Audio Settings

Back OK

Settings

Date/Time

Display & Keypad

Language

Registration

Tel e ph on y

Back OK

Example

New Entry

First Name: Peter |

Surname:

Phone (Home):

Abc

‚

Save

14 Making calls

Making calls

¤ . . . use to enter a number press the Talk key briefly

¤ Press the Talk key and hold . . . use to enter a number

The connection is established using the send line configured for the handset.

Cancel dialing: Press the End call key

Dialing from the directory

¤ . . . use to open the directory . . . use to select an entry press the Talk key

If several numbers are defined for a directory entry:

¤ . . . use to view entries select number press the Talk key . . . the number is dialed

If uppercase is activated:

¤ . . . use to select a number press the Talk key . . . the number is dialed

Dialing from the redial list

The redial list contains the 20 numbers last dialed with the handset.

¤ Press the Talk key briefly or press the display key . . . the redial list opens . . . use to

select an entry press the Talk key

If a name is displayed:

¤ View . . . the number is displayed . . . use to browse numbers if required . . . when the desired

number is reached, press the Talk key

Managing entries in the redial list

¤ Press the Talk key briefly or press the display key . . . the redial list opens . . . use to

select an entry Options . . . possible options:

When the display backlight is disabled, the display lights up again the next time any key is pressed. Digit keys appear on the display for pre-dialing, other keys have no further function.

Copy an entry to the directory: Copy to Directory OK Copy the number to the display:

¤ Display number OK . . . use to amend or add numbers if necessary . . . use to save

as an entry in the directory Delete the selected entry: Delete entry OK Delete all entries: Delete all OK Set automatic line seizure:

¤ Automatic Redial . . . The selected number is automatically dialed at fixed intervals (at least

every 20 seconds). The handsfree key flashes; "open listening" is activated.

The participant answers: Press the Talk key . . . the function is terminated

The participant does not answer: The call is terminated after approx. 30 seconds. The function is ter-

minated after pressing any key or after ten unsuccessful attempts.

Making calls 15

Dialing from a call list

The call lists ( S. 18) contain the last answered, outgoing and missed calls (assuming this is configured in the telephone system, consult your administrator).

¤ . . . use to select Call Lists OK . . . use to select

the list OK . . . use to select an entry press the Talk key

Dialing in to extension systems (Delayed Extension Dialing)

When dialing in to a large corporate network (PBX systems), it is possible to dial an extension number directly after dialing the dial-up number.

¤ Ope n the directory . . . use to select an entry press the Talk

key . . . the phone dials the number before the ** . . . possible

options:

Dial a saved extension: Dial Ext. . . . the phone dials the number afte r

** Dial a different extension: . . . use to enter an extension number

. . . the phone dials the number entered

Inserting a dial pause when dialing

¤ Press the hash key and hold . . . the following letter is shown on the display P.

Incoming calls

An incoming call is indicated by ringing, by a display on the screen and by the flashing Talk key .

Accepting a call:

• Press the Talk key

• If Auto Answer is activated: Remove the handset from the charging cradle

• Accept the call on the headset

Information about the caller

The caller's phone number is displayed. If the caller's phone number is saved in the directory, the name is displayed.

The call lists can be accessed directly using the display key Calls, assuming the display key is assigned accordingly

The list of Missed calls can also be opened using the messages key .

The telephone number is saved in the directory as follows: Dial-in number, 2 stars, extension number (e.g. 1234567**128).

Changes are only saved permanently in the Profile Personal.

The caller's number is transmitted.

All calls

Frank 2/14/2015 3:40 PM

089563795

2/13/2015 3:32 PM

Susan Black

2/11/2015 1:20 PM

View Options

Example

Dial Number

1234567**128

Dial Ext. Options

16 Making calls

During calls

Handsfree mode

Activating/deactivating handsfree mode during a call and when establishing a connection:

Activating/deactivating handsfree mode during a call, when establishing a connection and when listening to the answering machine:

¤ Press the Talk/handsfree key

Placing the handset in the charging cradle during a call:

¤ Press the Talk/handsfree key to switch to handsfree mode . . . press again and hold . . .

place the handset in the charging cradle . . . hold for a further two seconds

Call volume

Applies for the current mode (handsfree, receiver or headset):

Muting the microphone

When the microphone is switched off, callers will no longer hear you.

Switch the microphone on/off during a call: press briefly.

Adjusting the microphone sensitivity

The microphone sensitivity can be adjusted in four increments in order to ensure better acoustics in loud environments and in case of echo.

¤ Press and hold the key use to adjust the microphone

sensitivity Save

¤ Press the control key . . . use to adjust the volume Save

The setting is automatically saved after around 3 seconds during a call, even if Save is not pressed.

A change made during a call without saving the setting is only valid for the current call.

Microphone

Sensitivity: < >

Back Save

Message lists 17

Message lists

Notifications of missed calls, messages on the network mailbox and missed appointments are saved in the message lists.

An advisory tone sounds as soon as a new message arrives. The message key

also flashes. Icons for the message type and the number of new mes-

sages are displayed in idle mode.

Notification available for the following message types:

on the answering machine/network mailbox

in the missed calls list

in the list of missed appointments and missed anniversaries

Displaying messages:

¤ Press the message key . . . Message lists that contain messages are

displayed. Entry highlighted in bold: new messages available. The number of new

messages is shown in brackets. Entry not highlighted in bold: no new messages. The number of old mes-

sages is shown in brackets.

¤ . . . use to select the list OK . . . the calls and/or messages are listed

Network mailbox: The number of the network mailbox is dialed (

S. 35).

7:15

INT 1 14 Oct

02 10 09 08

Calls Calendar

Example

Messages & Calls

Missed Calls:

(5)

Answer Mach.: 1

(1)

SMS: (4)

Missed Alarms: (2)

Back OK

Example

Messages & Calls

Missed Calls:

(5)

Mailbox:

(1)

Missed Alarms: (4)

Back OK

Example

18 Call lists

Call lists

The phone saves a number of different call types (missed, accepted and outgoing calls) in lists (assuming they are set up in the telephone system, consult your administrator).

Activating/deactivating the local call lists

¤ . . . then to . . .

List entry

The following information is displayed in the list entries:

• The list type (in the header)

• Icon for the entry type:

Missed calls, Accepted calls, Outgoing calls, Call on the answering machine

• Number of the caller. If the number is saved in the phonebook, the name

and number type are displayed instead ( Phone (Home), Phone (Office), Phone (Mobile)). The number of calls from this number is dis- played additionally in square brackets in the case of missed calls.

• Number of the caller

• CNIP information

• Line on which the call was incoming/outgoing

• Date and time of call (if set).

Opening the call list

Calling back a caller on the call list

¤ . . . use to select Call Lists OK . . . use to select the list OK . . . use

to select an entry press the Talk key

Additional options

¤ . . . use to select Call Lists OK . . . use to select the list OK . . . possible

options:

Other options are possible.

activate: ¤ deactivate:

Via the display key:

¤ Calls . . . use to select the list OK

Via the menu:

¤ . . . use to select Call Lists OK . . . use to select the list

Via the message key (missed calls):

¤ Press the message key Missed Calls: OK

View an entry:

¤ . . . use to select an entry View

Copy number to the phonebook:

¤ . . . use to select an entry Options Copy to Directory

Delete the entry:

¤ . . . use to select an entry Options Delete entry OK

Delete the list:

¤ Options Delete List OK Ye s

All calls

Frank

Today, 3:40 PM

[3]

089563795

5/13/2014 6:32 PM

Susan Black

5/12/2014 1:12

View Options

Example

All calls

. . . 12345678901

Smith, Frank

2/18/2011 03:40pm

View Options

Example

Handset directory 19

Handset directory

The local directory is unique to the handset.

Opening the directory

¤ Press briefly in idle status

¤ . . . use to select Directory OK

Directory entries

Creating an entry

¤ <New Entry> OK . . . use to switch between the

entry fields and enter data for the entry:.

Names / numbers:

¤ . . . use to enter first names and/or surnames, at least one number

(personal, office or mobile) and an e-mail address, if applicable

Anniversary:

¤ . . . use to activate/deactivate Anniversary . . . use to enter

the date and time . . . use to select the type of alert (Vi sual onl y or a ringtone)

Caller Melody (VIP):

¤ . . . use to select the ringtone that will indicate a call from the par-

ticipant . . . if a Caller Melody (VIP) has been assigned, the entry will appear in the directory with the icon.

Caller Picture:

¤ . . . use to selec t a picture that is to be displayed during a call from the par ticipant ( Resource

Directory).

Save entry: Save

Searching for/selecting a directory entry

¤ . . . use to browse searched names

¤ . . . use to enter initial letters (max. 8 letters) . . . the display jumps to the first name starting

with these initial letters . . .

use to continue browsing to the desired entry, if needed

Scroll through directory: Press and hold

Displaying/changing an entry

¤ . . . use to select an entry View . . . use to select the field to be changed Edit

¤ . . . use to select an entry Options Edit entry OK

Deleting entries

Delete the selected entry: . . . use to select an entry Options Delete entry OK

Delete all entries: Options Delete all OK Ye s

Setting the order of the directory entries

Directory entries can be sorted by first name or surname.

Number of entries: up to 500

Information: First name and surname, up to three telephone numbers, e-mail address, anniver-

sary with alert, VIP ringtone with VIP icon, , CLIP picture

Length of the entries: Numbers: max. 32 digits.

First name, surname: max. 16 characters E-mail address: max. 64 characters.

An entry is only valid if it contains at least one number.

Example

New Entry

First Name:

Robert

Surname: I

Phone (Home):

Abc

‚

Save

20 Handset directory

¤ Options Sort by Surname / Sort by First Name

If no name was entered, the default telephone number is shown in the surname field. These entries appear at the beginning of the list, regardless of how the entries are sorted.

The sort order is as follows:

Space | Digits (0-9) | Letters (alphabetically) | Other characters.

Displaying the number of entries available in the directory

¤ Options Available Memory OK

Copying number to the directory

Copy a numbers to the directory:

• From a list, e.g. the call list or the redial list

• When dialing a number

The number is displayed or highlighted.

¤ Press the display key or Options Copy to Directory OK . . . possible options:

Create a new entry:

¤ <New Entry> OK . . . use to select a number type OK complete entry Save

Add number to an existing entry:

¤ . . . use to select an entry OK . . . use to select a number type OK . . . the number is

entered or a prompt to overwrite an existing number is displayed . . . if required, answer the prompt with Ye s/No Save

Synchronizing the directory with the PC address book (Gigaset QuickSync)

Free to download at wiki.unify.com/wiki/OpenScape_DECT_Phone_SL5

vCard

Copying a vCard using Bluetooth

Copy directory entries in vCard format, for example to exchange entries with a mobile phone.

¤ . . . use to select an entry if needed Options Copy Entry / Copy A ll vCard via

Bluetooth

. . . the Known Devices list is displayed . . . use to select the device OK

Receiving a vCard using Bluetooth

If a device in the Known Devices list sends a vCard to your handset, a directory entry is automatically cre- ated and a message is shown on the display.

If the sending device is not in the list: . . . use to enter the PIN of the sending Bluetooth device OK . . . the copied vCard is available as a directory entry

The Gigaset QuickSync program has been installed on the computer.

The handset is connected to the computer via Bluetooth or via a USB data cable.

Bluetooth mode is activated.

The other handset/mobile phone supports Bluetooth.

Acoustic profile 21

Acoustic profile

The phone has three acoustic profiles for adapting the handset to the environmental conditions: Profile Loud, Profile Silent, Profile Personal

¤ Press the key briefly in idle mode to switch between the profiles. The profile is switched immedi-

ately without prompting.

The profiles are defined as follows in their default state:

Activate the alerting tone for incoming calls for Profile Silent: after switching to Profile Silent press the display key Beep . . . the following icon appears in the status line

Calendar

You can remind yourself of up to 30 appointments.

The current day is outlined in white in the calendar, while numbers are highli ght ed i n co lor on d ays wit h ap poi nt men ts. When a d ay i s se lec ted , it wil l be outlined in color.

Saving appointments to the calendar

¤ . . . use to select Organiser OK Calendar OK . . . use to select the

desired day OK . . . then

Default state Profile Loud Profile Silent Profile

Perso nal

Vibration alarm On How

Profile

Perso nal

Off

Ringtone On Off On

Ringtone volume Internal 5 Off 5

External 5 Off 5

Handset volume Earpiece 5 3 3

Handsfree mode 5 3 3

Advisory tones Key click Yes No Yes

Confirmation tone

Yes No Yes

Battery tone Yes Yes Yes

Changes to the settings listed in the table

• only apply in the Loud and Silent profiles as long as the profile is not switched.

• are saved permanently for this profile in the Profile Personal .

The selected profile is retained when the handset is switched off and on again.

The date and time have been set.

Switch on/off:

¤ Activation: . . . use to select On or Off

Enter the date:

¤ Date . . . the selected date is set by default . . . use to enter a new date

Enter the time:

¤ Time . . . use to enter the hours and minutes of the appointment

Set the name:

¤ Tex t . . . use to enter a description of the appointment (e.g. evening

meal, meeting)

Set alarm tone:

¤ Signal . . . use to select the melody of the reminder alarm or deacti-

vate acoustic signaling

Enter information for the appointment:

July 2015

Mo Tu We Th Fr Sa Su

01 02 03 04 05 06

07 08 09 10 11 12 13

14 15 16 17 18 19 20

21 22 23 24 25 26 27

28 29 30 31

Back OK

22 Alarm clock

Notification of appointments/anniversaries

Anniversaries are transferred from the directory and displayed as an appointment. An appointment/anniversary is displayed in idle status and the selected ringtone plays for 60 seconds as a notification.

• Acknowledge and stop the reminder: Press the display key OFF

Displaying missed (unacknowledged) appointments/anniversaries

The following appointments and anniversaries are saved in the Missed Alarms list:

• The appointment/anniversary call was not acknowledged.

• The appointment/anniversary was notified during a call.

• The handset was switched off at the time of the appointment/anniversary.

The last 10 entries are stored. The icon and the number of new entries are shown on the display. The most recent entry appears at the top of the list.

Opening the list

¤ Press the message key Missed Alarms: OK . . . use to browse through the list of

any appointments

¤ . . . use to select Organiser OK Missed Alarms OK

Every entry is displayed with number or name, date and time. The most recent entry appears at the top of the list.

• Delete an appointment/anniversary: Delete

Displaying/changing/deleting stored appointments

¤ . . . use to select Organiser OK Calendar OK . . . use to select the

day OK . . . the appointment list is displayed . . . use to select the date . . . possible options:

Alarm clock

Activating/deactivating the alarm clock and setting the wake-up time

¤ . . . use to select Alarm Clock OK . . . then

¤ . . . use to select Date, Time, Tex t and Signal in succession . . . adjust the

value in each case with or Save

Save appointment:¤ Save

If an appointment has already been entered: <New Entry> OK . . . then enter information for the appointment.

During a call, a reminder is indicated once with an advisory tone on the handset.

Display appointment details:

¤ View . . . The appointment settings are displayed

Change appointment:

¤ View Edit

or Options Edit entry OK

Activate/deactivate appointment:

¤ Options Activate/Deactivate OK

Delete appointment:

¤ Options Delete entry OK

Delete all appointments for a day:

¤ Options Delete all Appoints. OK Ye s

The date and time have been set.

Switch on/off:

¤ Activation: . . . use to select On or Off

Set wake-up time:

¤ Time . . . use to enter hours and minutes

Protecting against unwanted calls 23

The icon and the wake-up time are displayed on the idle display when the alarm clock is activated.

Alarm

An alarm is shown on the display and indicated by the selected ringtone melody. The alarm sounds for 60 seconds. It is the n repeated after 5 minutes if no key is pressed. The alarm i s disabled for 24 hours after the second retry.

Switching off / repeating the alarm after an interval (snooze mode)

Deactivate the alarm: OFF

Repeat the alarm (snooze mode): Snooze Press or any key . . . the alarm is switched off and repeated after 5 minutes.

Protecting against unwanted calls

Time control for external calls

Enter a time period during which the handset is not to ring to indicate external calls, for example during the night.

¤ . . . use to select Audio Settings Ringtones

(Handset) OK Time Control OK . . . then

Switching off the ringtone when in the charging cradle

The handset will not ring when placed in the charging cradle. A call is only indicated on the display.

¤ Audio Settings OK Ringtones (Handset) OK Silent Charging

Change ( = Ringtone is switched off when in the charging cradle

Set days: ¤ Occurrence . . . use to switch between Monday-Friday and Daily Set volume:

¤ Volume . . . use to set the volume in 5 increments or select cre-

scendo (increasing volume)

Set alarm:

¤ Melody . . . use to select a ringtone for the alarm

Enter the wake-up details:

¤ . . . use to select Time, Occurrence, Volum e and Melody in succession

. . . adjust the value in each case with or Save

Save setting:

¤ Save

During a call, the alarm is only indicated by a short tone.

The date and time have been set.

Switch on/off:

¤ use to select On or Off

Enter the time:

¤ use to switch between Suspend ring. from

and Suspend ring. until . . . use to enter the start and end of the period in 4-digit format

Save:

¤ Save

Time control only applies to the handset for which the setting is configured.

The telephone will continue to ring for numbers that have been assigned to a VIP group in the directory.

Time Control

For external calls:

Suspend ring. from:

10:00 PM

Suspend ring. until:

7:00 AM

Back Save

Example

24 Resource Directory

Resource Directory

Sounds for ringtones and images that can be used as caller images (CLIP pictures) or as screensavers are saved in the handset's resource directory. A range of monophonic and polyphonic sounds and pictures have been pre-set but further images and sounds can be downloaded using a PC (

Gigaset QuickSync).

Media types:

If there is not enough memory available, you must first delete one or more pictures or sounds before others can be saved.

Managing CLIP images, screensavers and sounds

¤ . . . use to select Additional Features OK Resource Directory OK . . . possi-

ble options:

Checking the memory

Display the available memory for screensavers and CLIP pictures.

¤ . . . use to select Additional Features OK Resource Directory OK

Capacity OK . . . the percentage of available memory is displayed

Bluetooth

Th e han dse t is a ble to us e Bl ueto oth ™ to c ommu nic ate w irel ess ly w ith o the r dev ices tha t al so us e th is te chnology, for example for exchanging directory entries.

The following devices can be connected:

• A Bluetooth headset

It may take 5 seconds to establish a connection, whether a call is accepted using the headset or transferred to the headset, or a call is made from the headset.

• Up to 5 data devices (PCs, PDAs or mobile telephones) for the transmission of address book entries as

a vCard or for the exchange of data with the computer.

Typ e Forma t

Sound Ringtones

Monophonic Polyphonic Imported sounds

Internal Internal Internal WMA, MP3, WAV

Picture CLIP image 

Screensaver

BMP, JPG, GIF 128 x 86 pixels 128 x 160 pixels

View  screensaver:

¤ Screensavers OK . . . use to select picture View . . . the

selected picture is displayed

View CLIP picture:

¤ Caller Pictures OK . . . use to select picture View . . . the

selected picture is displayed

Play sound:

¤ Sounds OK . . . use to select sound . . . the selected sound is

played Set volume: Options Volu me OK . . . use to select the volume

Save

Rename picture/sound:

¤ Screensavers Select / Caller Pictures / Sounds OK . . . use to

select sound/image Options Rename . . . use to delete name, use

to enter a new name Save . . . the entry is saved with the new name

Delete picture/ sound:

¤ Select Caller Pictures / Sounds OK . . . use to s elec t sou nd/i mage

Options Delete entry . . . the selected entry is deleted

The relevant options are not available if a picture/sound cannot be deleted.

Bluetooth is activated and the devices have been registered to the handset.

The headset features the Headset or Handsfree Profile. If both profiles are available, the handsfree profile is used to communicate.

Bluetooth 25

To use the phone numbers, dialing codes (international and local area code) must be saved to the telephone.

Operating Bluetooth devices

User guides for devices

Activating/deactivating Bluetooth mode

¤ . . . use to select Bluetooth OK Activation Change ( = activated)

If the local area code is still not saved: . . . use to enter the local area code OK

When in idle status, the activated Bluetooth mode is indicated on the handset by the icon.

Registering Bluetooth devices

The distance between the handset in Bluetooth mode and the activated Bluetooth device (headset or data device) should be no more than 10 m.

¤ . . . use to select Bluetooth OK Search for Headset / Search Data Device

OK . . . the search starts (may take up to 30 seconds) . . . the names of found devices are displayed . . .

possible options:

Editing the list of known (trusted) devices

Opening the list

¤ . . . use to select Bluetooth OK Known Devices OK . . . the known devices

are listed, an icon indicates the type of device

If a device is connected, the corresponding icon is shown in the display header instead of .

Editing entries

¤ . . . use to select Bluetooth OK Known Devices OK . . . use to select

an entry . . . possible options:

Rejecting/accepting a non-registered Bluetooth device

If a Bluetooth device that is not registered in the list of known devices tries to connect with the handset, you will be prompted on the display to enter the PIN for the Bluetooth device (bonding).

The registration of a headset overwrites a previously registered headset.

If a headset is to be registered that is already registered with a different device, this connection must be deactivated before registering.

¤ Options Trust Device OK . . . use to enter the PIN of the Blue-

tooth device to be registered OK . . . the device is added to the list of known devices

Display information about a device:

¤ . . . use if necessary to select a device View . . . the device name and

device address are displayed

Repeat search:

¤ Options Repeat Search OK

Cancel search:

¤ Cancel

Bluetooth headset Bluetooth data device

View an entry:

¤ View . . . the device name and device address are displayed To go back,

press OK

De-register a Bluetooth device:

¤ Options Delete entry OK

Edit name:

¤ Options Edit Name OK . . . use to edit the name Save

If an active Bluetooth device is de-registered, it may try to re-connect as a "non-registered device".

Reject: ¤ Press the End call key briefly. Accept: ¤ . . . use to enter the PIN of the Bluetooth device to be accepted OK . . . wait for

PIN confirmation . . . then

Add the device to the list of known devices: Ye s

Use the device temporarily: No . . . the Bluetooth connection can be used as long as the device is located within the transmission range or until it is switched off

26 Additional functions using the PC interface

Changing the Bluetooth name of the handset

The handset is shown by this name on another Bluetooth device.

¤ . . . use to select Bluetooth OK Own Device OK . . . the name and the device

address are shown Change . . . use to change the name Save

Additional functions using the PC interface

QuickSync functions:

• Sync the handset's directory with Microsoft® Outlook®

• Upload CLIP pictures (.bmp) from the computer to the handset

• Upload pictures (.bmp) as screensavers from the computer to the handset

• Upload sounds (ringtone melodies) from the computer to the handset

• Update the firmware

• Cloud synchronization with Google™

¤ Connect the handset to the computer via Bluetooth or via a USB data cableConnect the handset to the

computer via a USB data cable.

Transferring data

¤ Launch the Gigaset QuickSync program on the computer.

The message Data transfer in progress is shown on the display while data is being transferred between the handset and PC. During this time, it is not possible to enter any data using the keypad and incoming calls are ignored.

Carrying out a firmware update

¤ Connect the telephone and PC using a USB data cable Launch Gigaset QuickSync Establish the

connection to the handset

¤ Start the firmware update in Gigaset QuickSync . . . I nformation about this can be found in the Gigaset

QuickSync help

The update process may take up to 10 minutes (not including the download time).

The data is first downloaded from the online update server. The amount of time this takes depends on the speed of the Internet connection.

The display on your phone is switched off and the Message key and the Talk key start flashing.

Once the update is complete, your phone will automatically restart.

Procedure in the event of an error

If the update procedure fails or the phone does not work properly following the update, repeat the update procedure:

¤ End the "Gigaset QuickSync" program on the PC Remove the USB data cable from the phone

Remove the battery Reinsert the battery

The Gigaset QuickSync program has been installed on the computer.

The handset is connected to the computer via Bluetooth or via a USB data cable.

Connect the handset directly to the PC, not via a USB hub.

Data transfer using Bluetooth:

• The computer has Bluetooth capability.

• A USB data cable is not plugged in. If a USB data cable is plugged in during an existing Blue-

tooth connection, the Bluetooth connection is interrupted.

Always save own pictures and sounds uploaded onto the handset on the PC also, as they may be lost during an update.

Do not interrupt the process and do not remove the USB data cable.

Additional functions using the PC interface 27

¤ Carry out the firmware update again as described above

If the update procedure fails several times or you can no longer connect to the PC, consult your administrator:

28 Adjusting the handset settings

Adjusting the handset settings

Display and keypad

Screensaver

A dialog or analog clock, Info Services and a range of pictures can be selected to be displayed as a screensaver when in idle status.

¤ . . . use to selec t Settings OK Display & Keypad OK Screensaver

Edit ( = on) . . . then

The screensaver is activated approx. 10 seconds after the display has changed to idle status.

End screensaver

¤ Press the End call key briefly . . . the idle display appears

Large font

Th e fo nt s ize of t ext and ico ns i n c all lis ts a nd i n th e directory can be increased in order to improve legibility. Only one entry is shown in the display and names are abbreviated if necessary.

¤ . . . use to select Settings OK Display & Keypad OK Large Font

Change (= on)

Color scheme

The display may appear in a range of color combinations.

¤ . . . use to select Settings OK Display & Keypad OK Colour

Schemes OK . . . use to select the desired color scheme Select ( = selected)

Switch on/off:

¤ Activation: . . . use to select On or Off

Select screensaver:

¤ Selection . . . use to select a screensaver (Digital Clock / Analog

Clock / Info Services / <Pictures> / Slideshow)

View screensaver: ¤ View Save selection:

¤ Save

All pictures from the Screensaver folder of the Resource Directory are available for selection.

Adjusting the handset settings 29

Display backlight

The display backlight always illuminates when the handset is taken out of the base station/charging cradle or a key is pressed. Any digit keys that are pressed appear on the display for pre-dialing.

Switch the display backlight on/off when in idle status:

¤ . . . use to select Settings OK Display & Keypad OK Display

Backlight OK . . . then

Switching the keypad illumination on/off

¤ . . . use to select Settings OK Display & Keypad OK Key

Illumination Change . . . use to set the brightness in 5 levels.

Activating/deactivating automatic keypad lock

Automatically lock the keypad when the handset has been in idle status for around 15 seconds.

¤ . . . use to select Settings OK Display & Keypad OK Auto

Keypadlock Change (= on)

Activating/deactivating automatic call answering

When set to auto answer, the handset accepts an incoming call as soon as it is removed from the charging cradle.

¤ . . . use to select Settings OK Te le p ho n y OK Auto Answer Change

( = on)

Regardless of the Auto Answer setting, the connection ends as soon as you place the handset back in the charging cradle. Exception: Press and hold the Talk key

for a fur ther 2 seconds while placing the hand-

set in the charging cradle.

Changing the earpiece and speaker volume

You can set the volume of the earpiece and speaker at 5 levels independently of each other.

During a call

¤ Handset Volume . . . use to select the volume Save . . . the setting is saved

In idle status

¤ Audio Settings OK Handset Volume OK . . . then

Backlight in the charging cradle:

¤ In Charger: . . . use to select On or Off

Backlight when not in the charging cradle:

¤ Out of Charger . . . use to select On or Off

Save selection:

¤ Save

The handset's standby time may be significantly reduced if the display backlight is activated.

The setting will be saved automatically after approx. 3 seconds without saving.

For the earpiece:

¤ Earpiece: . . . use to set the volume

For the speaker:

¤ Speaker . . . use to set the volume

Save setting:

¤ Save

Changes are only saved permanently in the Profile Personal.

30 Adjusting the handset settings

Adjusting the microphone sensitivity

The microphone sensitivity can be adjusted in four increments in order to ensure better acoustics in loud environments and in case of echo.

¤ Press and hold the key use to adjust the microphone

sensitivity Save

Ringtones

Ringtone volume

¤ Audio Settings OK Ringtones (Handset) OK

Volume OK . . . use to select For internal calls and alarms or

External Calls . . . use to set the volume in 5 increments or select

crescendo (increasing volume) Save

Ringtone melody

Set a variety of ringtones for internal and external calls on all of the phone's available receiving lines (Landline, IP1, Gigaset.net) or the same ringtone for All calls.

¤ Audio Settings OK Ringtones (Handset) OK Melodies OK . . . use

to select the connection . . . use to select the ringtone/melody in each case Save

Activating/deactivating the ringtone

Deactivating the ringtone permanently

¤ Use the key to set the Profile Silent . . . the following icon appears in the status bar

Activating the ringtone permanently

¤ Use the key to set the Profile Loud or Profile Personal

Activating/deactivating the alerting tone (beep)

Activate an alerting tone (beep) instead of the ringtone:

¤ Press the asterisk key and hold within three seconds press Beep . . . the following icon

appears in the status bar

Deactivate the alerting tone again: Press the asterisk key and hold

Activating/deactivating the vibration alarm

Incoming calls and other messages are indicated by a vibration.

¤ . . . use Audio Settings OK Silent Alert Change ( = on)

Activating/deactivating advisory tones

The handset notifies acoustically about different activities and statuses. These advisory tones can be activated/deactivated independently of each other.

¤ Audio Settings OK Advisory Tones OK . . . then

Tone when keys are pressed:

¤ Key Tones: . . . use to select On or Off

Microphone

Sensitivity: < >

Back Save

Volu me

For internal calls and alarms:

< >

External Calls:

Back Save

Example

Adjusting the handset settings 31

Confirmation/error tone after making entries, advisory tone when a new message has been received:

¤ Confirmation . . . use to select On or Off

Warning tone when there are fewer than 10 minutes of talktime remaining (every 60 seconds):

¤ Battery . . . use to select On or Off

Warning tone when the handset is moved out of range of the base station:

¤ Out of Range: . . . use to select On or Off

Save setting:

¤ Save

32 Adjusting the handset settings

Fast access to numbers and functions

Number keys: The keys to can each be assigned a number from the directory.

Display keys: The left and right display keys have a function preset by default, but the keys can be re-

assigned.

The number is then dialed or the function started by simply pressing a key.

Assigning a number to digit keys (quick dial)

¤ Press and hold the digit key

¤ Press the digit key briefly press the display key Quick Dial

The directory opens.

¤ . . . use to select an entry OK . . . use to select a nu mber if required OK . . . the entry is

saved to the digit key

Dialing a number

¤ Press and hold the digit key . . . the number is dialed immediately

¤ Press the digit key briefly . . . the number/name (possibly in abbreviated form) is shown on the left

display key . . . press the display key . . . the number is dialed

Changing the digit key assignment

¤ Press the digit key briefly Change . . . the directory is opened . . . possible options:

Assigning display keys, changing assignments

¤ Press and hold the left or right display key in idle status . . . the list of possible key assignments is

opened . . . use to select a function OK . . . possible options:

Starting a function

With the telephone in idle status: Press the display key briefly . . . the assigned function is executed

You have to assign a number to the digit key.

If the entry is subsequently deleted in the directory, this will not affect the assignment to the number key.

Change the assignment:

¤ . . . use to select an entry OK . . . select a number if required OK

Delete the assignment:

¤ Clear Key

Call Lists Show the call list INT Open the internal menu Quick Dial Assign a number from the directory to the display key Alarm Clock Set and activate/deactivate the alarm clock Calendar Open the calendar Bluetooth Open the Bluetooth menu Redial Show the redial list

Adjusting the handset settings 33

Changing the handset PIN

The handset is PIN-protected to prevent unauthorized use (default setting: 0000). The PIN is requested each time you turn on the handset, assuming it has been changed and does not correspond to the default state 0000.

Change the handset's 4-digit PIN (default setting: 0000):

¤ . . . use to select Settings OK System OK Handset PIN OK . . .

use to enter the current handset PIN OK . . . use to enter the new handset PIN OK

Own area code

The area code (international and local area code) must be saved on the phone in order to transfer phone numbers (e.g. in vCards)

Some of these numbers are already preset.

¤ . . . use to select Settings OK Telephony

OK Area Codes OK Check (pre-)set area code

Edit the number:

¤ . . . use to select/switch entry field . . . use to change entry

position . . . delete digit if appropriate . . . use to enter

digit Save

Resetting the handset to the default settings

Reset any individual settings and changes that you have made.

¤ . . . use to select Settings OK System OK Handset Reset OK Yes

. . . the handset's settings are reset

The following settings are not affected by the reset:

• Registration of the handset to the base station

• Date and time

• Directory entries and call lists

Area Codes

International code:

00 - 49

Local area code:

0 - [8 ]

Save

Example

34 Extending the handset

Extending the handset

Registering a handset to multiple base stations

The handset can be registered to up to four base stations. The active base station is the base station to which the handset was last registered. The other base stations remain saved in the list of available base sta

tions.

¤ . . . use to select Settings OK Registration OK Select Base OK . . . pos-

sible options:

Change active base station:

¤ . . . use to select the base station or Best Base Select ( = selected)

Best Base: The handset chooses the base station with the best reception as

soon as it loses connection to the current base station.

Change name of a base station:

¤ . . . use to select a base station Select ( = selected) Name

change name Save

Network mailbox 35

Network mailbox

Activating and deactivating the network mailbox

Every handset can manage the network mailboxes belonging to one of its receiving lines.

¤ . . . use to select the Answer Machine OK Network Mailbox OK . . . use

if appropriate to select the connection OK . . . then

For fixed network connection

¤ . . . use to enter or change the number of the network mailbox Save

Listening to messages

¤ Press and hold the key

Listen to announcement aloud: Press the handsfree key

Entering a number for the network mailbox

If a number is not yet saved for the network mailbox:

¤ . . . enter the number of the network mailbox with Save press and hold the End call

(idle status)

The network mailbox is assigned to Key 1. If not,instructions regarding input will follow.

36 Questions and answers

Questions and answers

Troubleshooting steps

Disclaimer

Your handset display is made up of pixels. Each pixel consists of three sub-pixels (red, green, blue). It may happen that a sub-pixel fails or a color deviation occurs. A warranty case exists only if the maximum number of permitted pixel errors is exceeded.

Manufacturer's advice

Authorization

We, Unify GmbH & Co. KG, declare that this device meets the essential requirements and other relevant regulations laid down in Directive 1999/5/EC.

The EU declaration of conformity under 1999/5/EC can be found at: wiki.unify.com/wiki/Declarations_of_Conformity#Cordless_Phones.

The display is blank.

• The handset is not switched on. Press and hold

• The battery is empty. Charge the battery or replace it ( S. 9)

"No Base" flashes on the display.

• The handset is outside the range of the base. Reduce the distance between the handset and the

base.

Your settings are not transferred.

• An incorrect profile is selected. Profile Personal should be selected . . . and then the device settings

changed.

The handset does not ring.

• The ringtone is deactivated. Activate the ringtone ( S. 30)

The other party cannot hear you.

• The handset is "muted". Reactivate the microphone ( S. 16)

You hear an error tone when keying in (descending tone sequence).

• Action has failed/invalid input. Repeat the process. Read the display and refer to the user guide if

necessary.

No time is specified for a message in the call list.

• The date/time are not set. Set the date and time.

Registration or connection problems with a Bluetooth headset.

¤ Reset the Bluetooth headset (see the user guide for the headset). ¤ Delete the registration data on the handset by de-registering the device. ¤ Repeat the registration process.

Answering machine ( S. 35):

No time is specified for a message in the call list.

• The date/time are not set.

Description Max. number of permitted pixel errors

Color illuminated sub-pixels 1

Dark sub-pixels 1

Total number of colored and dark sub-pixels 1



Traces of usage on the display and housing are excluded from the warranty.

Manufacturer's advice 37

Protecting our environment

Disposal

Batteries should not be disposed of in general household waste. Observe the local waste disposal regulations, details of which can be obtained from your local authority. Dispose of batteries in the green boxes designated as "common collec

tion system for batteries" at specialist retailers. All electrical and electronic products should be disposed of separately from the municipal waste stream via designated

collection facilities appointed by the government or the local authorities.

This crossed-out wheeled bin symbol on the product means the product is covered by the European Directive 2002/96/EC. The correct disposal and separate collection of your old appliance will help prevent potential negative consequences for the environment and human health. It is a precondition for reuse and recycling of used electrical

and electronic equipment. For more detailed information about disposal of your old appliance, please contact your local authority refuse center or waste disposal service.

Care

Always use a damp or antistatic cloth to clean the device. Do not use solvents or microfiber cloths. Never use a dry cloth as this can cause a static charge.

In rare cases, contact with chemical substances can cause changes to the device's exterior. Not all substances have been tested due to the wide variety of chemical products available on the market.

Impairments to high-gloss finishes can be carefully removed using display polishes for mobile phones.

Contact with liquid

If the device comes into contact with liquid:

1. Disconnect it from the power supply.

2. Remove the batteries and leave the battery compartment open.

3. Allow the liquid to drain from the device.

4. Dab all components dry.

5. Place the handset in a dry, warm place for at least 72 hours with the battery compartment open and keypad (if applicable) facing down (not in a microwave, oven, etc...).

6. Do not switch on the device again until it is completely dry.

When it has fully dried out, you will usually be able to use it again.

38 Technical data

Technical data

Batteries

Handset operating times/charging times

The operating time of your handset depends on the capacity and age of the battery and the way it is used. (All times are maximum possible times).

General specifications

Bluetooth

Character charts

Technology: Lithium ion (Li-Ion)

Voltage: 3.7 V

Capacity: 750 mAh

Standby time (hours) * 250

Tal kti me ( hours) 12

Charging time in charging cradle (hours) 2.5

* Without display backlight in idle mode (Setting the display backlight S. 29)

The operating times of the phone can be extended by using a more powerful battery.

DECT standard Supported

GAP standard Supported

No. of channels 60 duplex channels

Radio frequency range 1880-1900 MHz

Duplex mode Time division multiplexing, 10 ms frame length

Pulse repetition rate 100 Hz

Pulse transmission length 370 µs

Channel grid 1728 kHz

Bit rate 1152 kbit/s

Modulation GFSK

Language code 32 kbit/s

Transmission power 10 mW, average power per channel, 250 mW pulse power

Range Up to 50 m indoors, up to 300 m outdoors

Base station power supply 230 V ~/50 Hz

Environmental conditions for operation

+5 °C to +45 °C; 20 % to 75 % relative humidity

Dialing mode DTMF (tone dialing)/ PD (pulse dialing)

Radio frequency range 2402-2480 MHz

Transmission power 4 mW pulse power

Standard characters

Press the relevant key the indicated number of times.

1) Space

2) Line break

1x 2x 3x 4x 5x 6x 7x 8x 9x 10x

1 abc2дбавгз def 3лйик gh i4ïíìî

jkl5 mno6цсутфх pq r s7Я

tuv8üúùû wx y z 9ÿ ýæøå

.,?! 0

Technical data 39

Central Europe

Press the relevant key the indicated number of times.

Cyrillic

Press the relevant key the indicated number of times.

Greek

Press the relevant key the indicated number of times.

Tur kis h

Press the relevant key the indicated number of times.

Arabic

Press the relevant key the indicated number of times.

1) Space

1x 2x 3x 4x 5x 6x 7x 8x 9x 10x

1$¤ abc2ąäáâćç def 3ďęëéě gh i 4 í î

jkl5ł mno6ńňóöőô pq r s7 řß ś š

tuv8t'űüúů wx y z 9ý ź ż ž

-.0

1) Space

2) Line break

1x 2x 3x 4x 5x 6x 7x 8x 9x 10x

1 a 2abc ë3def 4gh i 5 j k l 6mno

yx7pqrs 8 t uv l     9 w x y z

.,?! 0

1) Space

2) Line break

1x 2x 3x 4x 5x 6x 7x 8x 9x 10x 11x 12x

1 αβά2abc δεφέ3def

γηιήίϊΐ4ghi κλ5j kl νοωόώ6mno πρ σψ7pqr s θτ8tuv

ζξυχύϋΰ9wxy z

.,?! 0

1) Space

2) Line break

1x 2x 3x 4x 5x 6x 7x 8x 9x 10x

1 abcз2дбавг def 3лйик gğh ıi4ïíìî

jkl5 mnoц6сутфх prs ş7qЯ

tuüv8úùû

yz9wxÿæøå

.,?! 0

1) Space

2) Line break

1x 2x 3x 4x 5x 6x 7x 8x 9x 10x 11x

1 abc2 de f 3 gh i 4

jkl5 mn o 6 pq r s

tuv

wx y z

., ! 0

40 Display icons

Display icons

The following icons are displayed dependent on the settings and the operating status of your telephone.

Icons in the status bar

Display key icons

Display icons to indicate ... . . .

Other display icons

Signal strength 1 % -100 %

white if Maximum Range is on; green if Maximum Range is off

Red: no connection to the base station

white if Maximum Range is on; green if Maximum Range is off

Profile Silent activated (ringtone switched off )

"Beep" ringtone activated

Keypad lock activated

Battery charge status (white): between 11% and 100% charged

Red: less than 11% charged

Flashing: battery almost empty (approx. 5 minutes of talktime remaining)

Battery is charging (current charge status): 0% - 100%

Last number redial

Delete text

Open the directory

Copy number to the directory

Î Back, cancel

Establishing a call (outgoing call)

Connection established

No connection established/connection terminated

Call

Reminder for anniversary

Reminder for appointment

Wake -up call

Alarm clock is on, display with alarm time

Display icons 41

Action complete (green)

Action failed (red)

Information

(Confirmation) prompt

Please wait...

42 Menu overview

Menu overview

Open the main menu: press this key when the handset is in idle mode

Not all of the functions described in this user guide are available in all countries or from all network providers.

Audio Settings

Handset Volume p. 29

Advisory Tones p. 30

Silent Alert p. 30

Ringtones (Handset) Volume p. 30

Melodies p. 30

Time Control p. 23

Silent Charging p. 23

Bluetooth

Activation p. 25

Search for Headset p. 25

Search Data Device p. 25

Known Devices p. 25

Own Device p. 26

Additional Features

Resource Directory Screensavers p. 24

Caller Pictures

Sounds

Capacity

Call Lists

p. 18

All calls

Outgoing calls

Accepted calls

Missed calls

Alarm Clock

p. 22

Answer Machine

Play Messages p. 35

Network Mailbox p. 35

Organiser

Calendar p. 21

Missed Alarms p. 22

Directory

p. 19

Menu overview 43

Settings

Date/Time p. 11

Display & Keypad Screensaver p. 28

Large Font p. 28

Colour Schemes p. 28

Display Backlight p. 29

Key Illumination p. 29

Auto Keypadlock p. 29

Language p. 10

Registration Register Handset p. 34

Select Base p. 34

Telephony Auto Answer p. 29

Area Codes p. 33

System Handset Reset p. 33

Handset PIN

p. 33

Base Reset

44 Accessing system functions

Accessing system functions

The system functions can be accessed via the Service menu.

Structure of the Service menu

Using the Service menu

The Service menu can be used both by means of the control key and the display keys.

Operation using the control key is shown below.

Example: Selecting the "second call" feature

u Open the Service menu.

s t w Select and confirm the basic service. The Service menu is displayed.

s t w Select the menu item and confirm (example). s t w Select the menu item and confirm (example).

Note:

Not all menu options are displayed depending on the system configuration.

Control key Function Alternative usage

Open Service menu or  One level higher

Left display key

One level lower During a call: Adjust call volume and open local phonebook

Right display key

Scroll Previous -

Scroll Next -

Confirm your selection -

Destinations

Control relays

Appointment

More features

Set up call forwarding

Camp-on on/off Do not disturb on/off Spk. call protect on/off Forwarding on/off Call forwarding display on/off

Variable call forwarding Fixed call forwarding Forwarding for intnl Forwarding for extnl Forwarding on busy Call forwarding no reply Forwarding on busy after timeout

BASIC SERVICE ...

Feature settings

Camp-on

Making calls to multiple parties 45

Making calls to multiple parties

Consultation

You interrupt your call to consult with a user (including external users) and then resume the original call.

p You are conducting a call.

Activating and conducting an inquiry/consultation call

s t w Activate inquiry. The current call is placed "on hold", so that the first user waits.

o Enter the phone number for the consultation call.

p The number is dialed. The station answers. The consultation starts.

The second user is busy or does not answer

During the consultation you can:

• Book a callback  page 72,

• Activate call waiting

 page 46 or

• Busy override

 page 47.

Ending a consultation call and returning to the waiting call

Either:

s t w If the consultation call/inquiry function was activated but a number was not yet

entered: Select the menu item and confirm.

s t w Select the menu item and confirm.

You are reconnected with the first party. The second call party hears the busy tone and hangs up.

s t w

The second u s e r h angs up. B y p r essing "TO WAIT. C A L L ", you are reconnected with the first party again.

You can also:

• Toggle between the partners  page 49,

• Set up a conference

 page 50 or

• Transfer the waiting partner to the second partner

 page 48.

CONSULT

TO WAIT. CALL

RETURN

TO WAIT. CALL

46 Making calls to multiple parties

Call waiting

You need to speak to a user in your communications system urgently, even though this user's line is busy. You can send a call waiting signal during the call to let the user know you want to talk to him or her. The user either answers im

mediately or you will be automatically connected when he or she has finished his call.

This function is only available if it has been configured by the service engineer.

The user is busy. You want to use call waiting.

s t w Select the menu item, confirm and wait briefly.

You receive a call waiting signal (second call)

You are still available to other callers, even though you are on the telephone. The call waiting signal informs you of the second call while you are conducting a call. You can answer this call without ending the first call.

p You are on a call and hear a call waiting signal.

If you want to answer the second call, you can either place the first call on hold (the first caller waits) or end the first call.

Placing the first call on hold and answering the second call

w Confirm to accept the second call.

Talk to the second caller. The first caller waits. His or her call is on hold. You can now:

• Toggle between the two callers  page 49 or

• Set up a conference

 page 50.

Ending the second call

a Press the End call key. Your handset rings.

Press the Talk key to talk to the first caller again.

Ending the first call

a Press the End call key. The first call is ended. Your phone rings.

Press the Talk key and answer the second call.

CAMP-ON

Note:

To camp on, you must have the appropriate class of service.

Camp-on is not possible if the called party is protected by the camp-on security function.

Pickup

Making calls to multiple parties 47

Override

You need to speak to an internal user urgently, even though his or her line is busy. The "Override" function allows you to interrupt the ongoing call to pass on a message.

p The user is busy.

s t w Select the menu item and confirm.

Both your colleague and their call partner hear a warning tone.

You can now start talking.

OVERRIDE

Note:

To override, you must have the appropriate class of service.

Override is not possible if the called party is protected by the Privacy function.

48 Making calls to multiple parties

Transferring a call

If the person you are speaking to wishes to be forwarded to one of your colleagues, you can transfer the call.

Transferring the call with prior announcement:

s t w Select the menu item and confirm.

o Enter the number of the party to whom you want to transfer the call.

Announce the call partner.

a Press the End call key. The person you were speaking to is now connected to

the desired party.

Transferring the call without prior announcement:

s t w Select the menu item and confirm.

o Enter the number of the party to whom you want to transfer the call.

a Press the End call key.

CONSULT

START TRANSFER

Note:

If a connection is not set up between the other two parties within 40 seconds, you will be called again. You are reconnected with the first party.

Making calls to multiple parties 49

Toggling (switching between calls)

The Toggle function allows you to switch between two users without allowing them to speak to each other directly. The two users can be either external or in

ternal users. You can also start a conference.

p You are conducting a call.

s t w Press the display key. The current call is placed "on hold", the user waits.

o Enter the phone number of the second user.

p The second user answers.

Switching to the caller on hold

s t w Press the display key to switch between the two calls.

Ending the present call – returning to the other call

s t w Select the menu item and confirm.

Setting up a three-way conference

s t w Select the menu item and confirm.

An alerting tone advises you that a conference call is now in progress between all three parties.

CONSULT

TOGGLE

RETURN

CONFERENCE

50 Making calls to multiple parties

Conducting a conference

In a system-assisted conference you can include up to 8 internal and external users. Users with system telephones can perform or use all the following func

tions simultaneously. ISDN telephones and external stations are passive users – they can only be included in an existing conference.

You can include parties and conferences from a remote system in your conference. The remote parties can set up a conference of their own and extend it. The members of this conference are included in your current conference – but they cannot perform or use the following functions.

The following functions are supported for all conference participants with a system telephone:

• Setting up a conference when calling a user or receiving a call or making a

consultation call or receiving a second call.

• Accepting a waiting call and including the caller in the conference.

• Toggling between the conference and a consultation call or second call.

• Conducting a consultation call during a conference and connecting it to the

conference.

• Interconnecting conference members from two independent conferences via

a remote network.

• Putting the conference on hold if line keys are installed.

• Obtaining an overview of all conference participants.

• Transferring a conference to a new party.

The functions listed can be performed by all conference participants at the same time.

Setting up a conference

You can set up a conference from any of the following types of connection:

• Single call

• Consultation call

• Second call

Initiating a conference from a single call

You want to set up a conference.

p You are conducting a call.

s t w Select the menu item and confirm.

o Call another user. 

Announce that a conference is to be set up.

s t w Select the menu item and confirm. You will briefly see the message: "1 is your

position".

Setting up a conference from a consultation call

p You are connected to one user and you call a second user.

w Confirm the option shown.

START CONF.

CONFERENCE

Conf. EXPAND CONF.

CONSULT

Making calls to multiple parties 51

o Call another user. The second user answers, you announce the conference.

s t w Select the menu item and confirm. You will briefly see the message: "1 is your

position".

Setting up a conference from a second call

p You are connected to one user and receive a second call, which is signaled by

an alerting tone.

s t w Select and confirm the option shown. You are connected to the second caller.

The other party is placed on hold.

s t w Select the menu item and confirm. You will briefly see the message: "1 is your

position". All members are connected in a conference call.

Expanding a conference

Any member of the system conference can expand the conference by:

• calling another user and adding this person to the conference,

• connecting a party from a consultation call to the conference, or

• accepting a second call and adding the caller to the conference.

Calling another specific party and connecting them

You intend calling another party and connecting them to the conference.

s t w Select the menu item and confirm.

o Call the new party. 

Announce that a conference is to be set up.

w Confirm the option shown.

The party is added to the conference.

If the new user does not answer:

w Confirm the option shown.

CONFERENCE

Pickup

CONFERENCE

EXPAND CONF.

CONFERENCE

TO CONFERENCE

52 Making calls to multiple parties

Expanding the conference from a consultation call

You wish to make a consultation call during the conference.

s t w Select the menu item and confirm. The conference is placed on hold.

o Call a party. Make the consultation call.

Either:

s t w Select the menu item and confirm to add the user from the consultation call to

the conference.

Or:

s t w Toggle between the conference and the consultation call.

Or:

s t w Select the menu item and confirm to release the consultation call and return to

the conference.

Accepting a second call and adding it to the conference

If you receive a second call during the conference (the second call function is activated), you can add this user to the conference.

You hear an alerting tone.

s t w Select and confirm the option shown. You are connected to the second caller.

The conference is placed on hold.

Either:

s t w Select and confirm to add the second caller to the conference.

Or:

s t w Toggle between the conference and the second call.

Or:

s t w Select and confirm to release the second call and return to the conference.

Transferring the conference

Any party can transfer the conference to a third party whom he or she has called by using the consultation or "expand conference" function. This party is not yet a participant in the conference. The conference cannot be transferred to a sec

ond call.

You are taking part in a conference

Either:

s t w Select and confirm the option shown. The conference is placed on hold.

o Call a party.

Or:

w Select and confirm the option shown.

o Call a party.

CONSULT

CONFERENCE

TOGGLE

RETURN

Pickup

CONFERENCE

TOGGLE

RETURN

CONSULT

EXPAND CONF.

Making calls to multiple parties 53

Announce that you are transferring the conference

s t w Select and confirm the option shown.

You are disconnected from the conference.

a Press the End call key.

During the conference

You are taking part in a conference with 3 to 8 members and you wish to know about the other members or to disconnect a certain member or to disconnect the last member added to the conference.

Viewing member information and disconnecting members

s t w Select and confirm the option shown.

The display shows the phone number and possibly the name of the conference member with the lowest member number.

Either:

w Confirm to display the next member.

Or:

s t w Select and confirm to end the display.

Or:

s t w Select and confirm to disconnect this party from the conference. If there were

only three members, the conference is now ended.

Disconnecting the last member added

You wish to disconnect the last party added to the conference.

s t w Select and confirm the option shown. The last member added is disconnected.

If there were only three members, the conference is now ended.

CONF. TRANSFER

VIEW MEMBERS?

Phone no. Party 1

NEXT CONF PTY?

STOP VIEWING?

RELEASE PARTY?

REM LAST PTY?

54 Making calls to multiple parties

Using the second call feature

If you are expecting an important call, you should activate the camp-on function. A second call will then be signaled while a call is in progress. You can accept or ignore the second call.

Activating and deactivating second call

u Open the system menu.

s t w Select and confirm the basic service.

Either:

2  Enter the service code.

Or:

s t w Select the menu item and confirm. s t w Select the menu item and confirm.

then: Activating or deactivating

w Confirm one of the two displays.

Accepting a second call

Prerequisite: You are making a call. The camp-on function is activated.

You will hear an alerting tone. The caller hears the ring tone as if you were "free".

s t w Select and confirm the option shown. You are connected to the second caller.

The first party is placed on hold.

Ending the second call, resuming the first call:

a Replace the handset and lift it again.

Note:

A second call is not signaled on the Bluetooth headset.

BASIC SERVICE

Feature settings

Camp-on

Activate

Deactivate

Pickup

Caller list 55

Caller list

Callers who have tried to reach you during your absence are saved in the "Caller list". Callback requests

 page 72 are also recorded here.

Retrieving the caller list

An advisory message appears and the message key flashes when one or more information messages or voicemails have been received for you.

Either:

f Press the message key.

Or:

u Open the system menu.

s t w Select the menu item and confirm.

The phone number or associated names are displayed. Phone numbers that have been viewed are ticked.

s t Press to view the list of phone numbers (names). Phone numbers (names) that

have already been viewed are ticked.

Calling back a caller on the list

s t Press to select the required phone number (name).

s t w Select and confirm the option shown. 

The station will be called.

Deleting a caller from the list

s t Press to select the required phone number (name).

s t w Select and confirm the option shown. The entry is deleted and the missed calls

list is displayed again.

Exiting the missed calls list

Î Press to move up to the next or a higher level of the menu

Or:

a Press the End call key to return to the idle menu.

Note:

If the "local call list" was allocated to the handset in the system, then please use the description on Seite 17.

QUERY NO.

46068 34101



DIAL

DELETE

56 Central directories (group directory)

Central directories (group directory)

You can save your private phonebook that is saved on your handset to a central server and add group phonebooks that are saved on this server to your private phonebook.

To protect phone numbers in your private phonebook from being modified when a group phonebook is added, we recommend first saving your private phone

book using the function "Send List"  page 57.

If the number of group directory entries exceeds the volume of memory available in your private phonebook, the transfer operation terminates as soon as the memory capacity limit is reached.

u Open the system menu.

s t w Select and confirm the phonebook.

Either: Deleting the private phonebook

s t w Select the menu item and confirm.

The following message appears:  PHONEBOOK DELETED

Or: Loading the private phonebook

s t w Select the menu item and confirm.

Or: Loading the group directory

s t w Select the menu item and confirm.

s t w Select and confirm the group directory.

a Press the End call key to end the operation.

Directory

Delete priv.

Load priv.

Load group

ABC Directory EFG Directory

Central directories (group directory) 57

Sending and receiving an entry or list of entries

You can send either an individual entry or the entire list to the communications system. This list can be received by the communications system and returned. Furthermore, it is also possible to load group directories.

Restrictions when copying using the communications system

The entries in the handset's phonebook are stored in vCard format . The communications system, however, uses another format. This can cause loss of phonebook entry information. The phone numbers are not affected.

Sending a list/entry

s Open the phonebook.

s t Select the entry you want.

Press the display key.

Either:

s t w Select the menu item and confirm.

Or:

s t w Select the menu item and confirm.

o Enter phone number 00 and confirm.

For "Copy Entry":

if nec. Select this option for additional entries.

Loading a list from the communications system

Prerequisite: You sent an entry or list to the communications system by dialing the phone number 00.

u Press the INT key.

s t w Select the menu item and confirm.

s t w Select the menu item and confirm.

a Press the End call key once. You will receive a call from the system and the

transfer starts once you answer this call.

Deleting a list in the communications system

Prerequisite: A currently unused list or entry is saved on the communications system.

Options

Copy All

Copy Entry

to Internal

Yes

Directory

Load priv.

Load group

58 Central directories (group directory)

If the handset with phone number 00 was used to send the list or entry to the communications system, any handset can be used to delete this list or entry.

u Press the INT key.

s t w Select the menu item and confirm.

s t w Select the menu item and confirm. The handset starts to delete the list/entry.

a Press the End call key to end the operation.

Loading the group directory

A group directory has to be created in the communications system by the service engineer and assigned to the authorized users.

u Press the INT key.

s t w Select the menu item and confirm.

s t w Select and confirm the group directory.

a Press the End call key to end the operation.

Directory

Delete priv.

Directory

Load group

ABC Directory EFG Directory

Call forwarding 59

Call forwarding

Using call forwarding

You can program two types of call forwarding:

• Fixed call forwarding and

• Variable call forwarding.

For fixed call forwarding, you program a forwarding destination that will remain valid until you change or delete it. You can activate and deactivate this forward

ing function.

For variable call forwarding, you can choose between six different forwarding types:

• Variable forwarding (unconditional forwarding)

• Forwarding for internal

• Forwarding for external

• Forwarding on busy

• Call forwarding no reply

• Forwarding on busy/after timeout

Call forwarding is activated when a forwarding destination is programmed.

When the phone is idle, active forwarding instructions are shown on the display, for instance Forwarding: 47110 to 47200.

You can use codes to activate and deactivate call forwarding  page 65.

Note:

The function must be approved for your communications system.

47110 --> 47200

60 Call forwarding

Fixed forwarding

If you have programmed a forwarding destination for fixed forwarding, you can activate and deactivate the forwarding facility in the Service menu. The pro

grammed forwarding destination remains valid until you change or delete it.

Programming and activating a forwarding destination

u Open the system menu.

s t w Select and confirm the basic service. s t w Select the menu item and confirm.

w Confirm the option shown. "Variable forwarding" is displayed.

w Confirm the option shown. "Fixed forwarding" is displayed. If call forwarding has

already been programmed, the forwarding destination is displayed.

s t w Select and confirm the option shown.

o Enter the phone number for the forwarding destination. Any destination previ-

ously saved will be overwritten.

w Confirm when the complete number has been entered. Call forwarding to the

programmed destination is active.



Activating and deactivating fixed forwarding

You can only activate and deactivate fixed forwarding if a destination number has been programmed.

u Open the system menu.

s t w Select and confirm the basic service. s t w Select the menu item and confirm.

w Confirm the option shown. "Variable forwarding" is displayed.

w Confirm the option shown.

Deactivating

The display shows "Fixed forwarding". .

s t w Select the menu item and confirm. Fixed forwarding is deactivated.

Activating

The display shows "Fixed forwarding".

s t w Select the menu item and confirm. Fixed forwarding is activated.

BASIC SERVICE

DESTINATIONS

FORWARD

ENTER DESTIN.:

SAVE

BASIC SERVICE

DESTINATIONS

FORWARD

FWD-FIXED off Deactivate

FWD-FIXED off

Activate

Call forwarding 61

Deleting the destination for fixed forwarding

You can delete the destination for fixed forwarding.

u Open the system menu.

s t w Select and confirm the basic service. s t w Select the menu item and confirm.

w Confirm the option shown. "Variable forwarding" is displayed.

w Confirm the option shown. The display shows "Fixed forwarding" and the for-

warding destination.

The display shows "Fixed forwarding" and the forwarding destination when forwarding is activated.

s t w Select and confirm the option shown. The forwarding destination is deleted. If

fixed forwarding was activated it is now deactivated.

BASIC SERVICE

DESTINATIONS

FORWARD

FWD-FIXED off

DELETE

62 Call forwarding

Variable forwarding

For variable forwarding you can choose between six different call forwarding types:

• Variable forwarding (unconditional forwarding)

• Forwarding for internal

• Forwarding for external

• Forwarding on busy

• Call forwarding no reply

• Forwarding on busy/after timeout

Remark: The various forwarding types must be configured for the user.

The forwarding types are mutually exclusive except for "forwarding for internal" and "forwarding for external". You can program a forwarding destination for each of the two exceptions and activate them both.

Example: You have activated variable forwarding. If you now program and thus activate forwarding after timeout, variable forwarding will be automatically deactivated and its forwarding destination will be deleted.

Selecting a variable forwarding type

Select Destinations and Forwarding in the Service menu.

u Open the system menu.

s t w Select and confirm the basic service. s t w Select the menu item and confirm.

w Confirm the option shown.

Variable forwarding is offered first.

Output on first line.

s t w Confirm to select the next forwarding type.

Output on first line.

s t w Confirm to select the next forwarding type.

Output on first line.

s t w Confirm to select the next variable forwarding type.

Output on first line.

s t w Confirm to select the next variable forwarding type.

s t To edit the current variable forwarding type, select the required command.

BASIC SERVICE

DESTINATIONS

FORWARD

FWD-VAR-ALL-

FWD-FIXED off

FWD-VAR-ALL-INT

FWD-VAR-ALL-

Call forwarding 63

Programming a forwarding destination

u Open the System Menu.

s t w Select and confirm the basic service. s t w Select the menu item and confirm.

w Confirm the option shown. "Variable forwarding" is displayed.

w Confirm the option shown. "Fixed forwarding" is displayed.

w Confirm the option shown. The display shows "Forwarding for internal".

s t w Select and confirm the option shown.

o Enter the phone number for the forwarding destination. Any destination previ-

ously programmed will be overwritten.

w Confirm when the complete number has been entered.

To select a different forwarding type, proceed as described on  page 62.

If variable forwarding was previously programmed and activated, it is deactivated and the forwarding destination is deleted (for exception, see  page 62). Fixed forwarding is deactivated.

Deleting a forwarding destination

A variable forwarding destination is automatically deleted when the forwarding type is deactivated.

Activating variable forwarding

Variable forwarding is automatically activated when the forwarding destination is programmed.

Deactivating variable forwarding

You can deactivate all variable forwarding types in the Service menu (Basic Service).

u Open the system menu.

s t w Select and confirm the basic service. s t w Select the menu item and confirm.

w Confirm the option shown. "Variable forwarding" is displayed.

w Confirm the option shown. "Fixed forwarding" is displayed. w Confirm the option shown. The display shows "Forwarding for internal".

s t w Select and confirm the option shown. Variable forwarding is deactivated and the

forwarding destination is deleted.

To select a different variable forwarding type, proceed as described on

 page 62.

BASIC SERVICE

DESTINATIONS

FORWARD

ENTER DESTIN.:

SAVE

BASIC SERVICE

DESTINATIONS

FORWARD

Deactivate

64 Call forwarding

Checking forwarding

To check the status of the forwarding types, proceed as described on

 page 62. The forwarding destination is shown in the second line if this vari-

able forwarding type is activated.

Activating and deactivating forwarding by means of an option

If a forwarding destination has been programmed for fixed forwarding, you can use the option to activate and deactivate the forwarding facility. If variable for

warding is activated, it can only be deactivated with this option.

u Open the system menu.

s t w Select and confirm the basic service. s t w Select and confirm the option shown. s t w Select and confirm the option shown.

s t w Select the menu item and confirm. The call forwarding function is activated. s t w Select the menu item and confirm. Call forwarding is deactivated. This deletes

any destination number programmed for variable forwarding.

Forwarding calls automatically

Forwarding of internal and external calls in the system can be configured and activated for your line by your administrator. Calls can be forwarded:

• unconditionally

• when the line is busy

• when the call is not answered

Unconditional call forwarding should only be used if the line is for outgoing calls only (for example in an elevator).

If you have set up fixed or variable forwarding and if the manually programmed forwarding destinations are not obtainable (for example because they are busy), then calls are automatically forwarded to the system forwarding destinations.

BASIC SERVICE

Feature settings

FORWARD

Activate

Deactivate

Call forwarding 65

Call forwarding with codes

You can use codes to set up the following forwarding types:

The display messages for activating and deactivating call forwarding can be found on

 page 59.

Note:

The codes are dependent on the configuration in your communication system. Please consult your administrator.

Forwarding type Code

(example)

Program and activate fixed forwarding

* 51

Activate fixed forwarding

* 41

Delete (and deactivate) fixed forwarding

# 51

Deactivate fixed forwarding

# 41

Program and activate unconditional variable forwarding

* 42

Program and activate variable forwarding for internal calls

* 44

Program and activate variable forwarding for external calls

* 43

Program and activate variable forwarding on busy

* 45

Program and activate variable forwarding after timeout

* 46

Program and activate variable forwarding on busy / after timeout

* 47

Deactivate variable and fixed forwarding

# 41

Deactivate variable forwarding for internal calls

# 44

Deactivate variable forwarding for external calls

# 43

Activate system call forwarding

* 90

Deactivate system call forwarding

# 90

66 Call forwarding

Programming and activating call forwarding

Hold down the Talk key.

o Enter the code, for example *51 (ask your administrator). You will hear the dial

tone.

o Enter the destination number.

# Enter the termination character. You will hear a confirmation beep and call for-

warding is activated.

a Press the End call key.

Activating fixed forwarding

Hold down the Talk key.

o Enter the code, for example *41 (ask your administrator). You hear a confirma-

tion tone.

a Press the End call key.

Deactivating call forwarding

Hold down the Talk key.

o Enter the code, for example #41 (ask your administrator). You hear a confirma-

tion tone.

a Press the End call key.

Canceling fixed forwarding

Hold down the Talk key.

o Enter the code, for example #51 (ask your administrator). You will hear a con-

firmation beep and call forwarding is canceled.

a Press the End call key.

Call forwarding 67

Delayed call forwarding

Prerequisite: The second call function must be activated  page 54.

If "Forwarding on busy / after timeout" or "Forwarding after timeout" is activated on your handset

 page 62 and a second call comes in, you will automatically

hear the call waiting tone and see the details of the caller on the display. You then have the option of accepting this call before call forwarding is activated (you may be urgently awaiting this call for instance).

The caller hears the ringing tone and is not forwarded to another extension until after a certain timeout.

Forwarding calls for a different terminal

You can save, activate, check and deactivate call forwarding for another telephone, fax machine or PC from your own handset. To do so, you need to know the PIN for the other station or have the "Call forwarding for other stations" class of service. Your administrator can help you in both cases.

Storing a destination for another telephone/activating call forwarding

u Open the system menu.

s t w Select and confirm the basic service. s t w Select the menu item and confirm. s t w Select the menu item and confirm.

w Confirm the option shown.

o Enter the number of the other telephone.

w Confirm the option shown.

o Enter the PIN

(only if your own station does not have the "Call forwarding for remote terminal" class of service).

w Confirm the option shown.

o Enter the destination number.

w Confirm the option shown.

Call forwarding is activated immediately.

Note:

This is configured for the entire system by your administrator.

BASIC SERVICE

Feature settings

FORWARD NUM-

VAR Y FORWARD

FINISHED?

SAVE

68 Call forwarding

Deactivating/checking call forwarding for another telephone

u Open the system menu.

s t w Select and confirm the basic service. s t w Select the menu item and confirm. s t w Select the menu item and confirm.

w Confirm the option shown.

o Enter the number of the other telephone.

w Confirm the option shown.

o Enter the PIN

(only if your own station does not have the "Call forwarding for remote terminal" class of service).

w Confirm the option shown.

Deactivating or checking:

w Confirm or:

s t w Select the menu item and confirm.

Sample display: Calls for station 3428 are redirected to station 8968.

Changing call forwarding for a different terminal

Proceed in the same way as for saving/activating:  page 67.

BASIC SERVICE

Feature settings

FORWARD NUM-

VAR Y FORWARD

FINISHED?

Deactivate

INTERROGATE?

3428----------->8968

Mailbox 69

Mailbox

Callers who have tried to reach you during your absence can leave a callback request in your mailbox.



In the mailbox you will also find voice or fax messages from the mail server (if this has been set up).

Viewing the mailbox/selecting a mailbox entry

An advisory message appears and the message key flashes when one or more information messages or voicemails have been received for you.

u Open the system menu.

s t w Select the menu item and confirm.

w The first entry is displayed on the screen.

s t Press to display the menu selection.

s t w Select the menu item and confirm to select the next callback request.

Making a requested callback

The callback request is displayed.

s t Press to display the menu selection.

s t w Select and confirm the option shown. 

The station will be called.

Deleting mailbox entries

Select the required entry  page 69.

The required entry appears.

s t Press to display the menu selection.

s t w Select and confirm to delete the entry.

Ending mailbox viewing

s t Press to display the menu selection.

s t w Select and confirm the option shown. Mailbox entries that have not been deleted

remain saved.

MAILBOX

MUELLER MOBILE TH 06.02 09:23

Output

MUELLER MOBILE TH 06.02 09:23

DELETE

Note:

You cannot delete (new) voice messages that you have not yet listened to in ful l . To ma r k a mes s age as " list e ned to " , jum p to the e nd of t h e me s s age by pressing 66 for example (depends on the system). Callback requests must also be deleted from the missed calls list

 page 55.

CANCEL

70 Mailbox

Using the OpenScape Xpressions mailbox function (optional)

Users with a mailbox (OpenScape Xpressions) can dial the messaging phone number to use this system's features and thus configure call forwarding types or listen to available messages. User voice prompts explain how to obtain all the available functions. If call forwarding to the mailbox is activated, the messaging phone number is shown on the display

 page 59.

More features 71

More features

Making calls using project assignment (cost billing)

You can assign external calls to certain projects.

Prerequisite: Project numbers (from 1 to 5) have been configured for certain projects and you have an account code (ACCT) for the project.

u Open the system menu.

s t w Select and confirm the basic service.

Either:

o Enter a service code between 61 (for project number 1) and 65 (for project num-

ber 5).

o Enter the PIN

Or:

s t w Select the menu item and confirm. s t w Select the required PIN and confirm.

then:

o Enter the external phone number.

Then make your phone call as usual  page 14.

Note:

The function must be approved for your communications system.

BASIC SERVICE

PIN / COS?

PIN 1? ...

A time limit is applied to project assignment. It is automatically deactivated if you have not used your handset for a period of more than five minutes, for instance.

72 More features

Callback

This function enables you to call a user who does not answer or whose line is busy. The Callback function enables you to contact this user as soon as he or she hangs up or re-uses his or her telephone. Please note that a line is signaled as busy when it is being called by another user. You can continue to use your handset without restriction when a callback has been booked.

Booking a callback

p The number is dialed. You hear the busy tone or the user does not answer.

w Save the callback request.

a Press the End call key to end the operation.

You receive a callback

You are then called back:

• as soon as the selected user terminates his or her call, or

• the first time the user uses his or her handset

, or

• as soon as the other party checks his or her mailbox and responds to your call-

back request

 page 72.

Press the Talk key briefly. The connection is set up.

Deleting a callback request

u Open the system menu.

s t w Select the menu item and confirm. s t w The oldest entry is displayed first.

s t Select the required command.

Displaying the next entry:

s t w Select and confirm the command to view the next entry.

Deleting an entry that is displayed:

s t w Select and confirm the command.

You receive confirmation: "Callback deleted".

Terminating callback display:

s t w Select and confirm the command.

a Press the End call key to end the operation.

CALLBACK

1. Depending on the configuration of your communications platform.

Note:

Callbacks are repeated until a connection is established or until the callback is deleted. A handset can initiate up to five callbacks and can be the destination for up to five callback requests. If these conditions are met, any further callbacks are rejected.

CALLBACK

MUELLER MOBILE TH 06.02 09:23

DELETE

Callback deleted.

CANCEL

More features 73

Using a different telephone in the same way as your own

You can log on to another telephone belonging to the HiPath 4000 system using a personal identification number (PIN). This also applies to telephones in net

worked HiPath 4000 systems, for example at other company locations. At the other telephone you can then

• make calls and assign the charges to cost centers,

• make calls and assign the charges to specific projects,

• check your mailbox,

• enter appointments.

Using an internal PIN, you can have your calls diverted to a telephone in the office or department where you will be for a temporary period (call forwarding - "follow me").

Prerequisite: You have been assigned a PIN by your administrator. You require an internal PIN for calls within your own HiPath

4000 system, while for calls involving other HiPath 4000 systems in the integrated network you require a network-wide PIN.

u Open the system menu.

s t w Select and confirm the basic service.

Either:

L  Enter the service code 

(61 for PIN 1, 62 for PIN 2, etc.).

Or:

s t w Select the menu item and confirm. s t w Select the menu item and confirm.

If you have several PINs and wish to use another one, select the other PIN.

then:

You are prompted to enter the PIN by the message "Enter station no." or "Enter ID" on the display.

The following applies within your own HiPath 4000 system:

o Enter your internal PIN.

The following applies within your own and anothersystem within the integrated networkHiPath 4000:

o Enter the 2-digit node ID of your own HiPath 4000 system (consult your admin-

istrator).

o # Enter your own number and press the hash key.

o # Enter the network-wide PIN and press the hash key.

Dialing after (successful) identification:

You will hear the dial tone. The following appears on the display:  "Please dial".

Note:

The function must be approved for your communications system.

BASIC SERVICE

PIN / COS?

PIN 1?

74 More features

o Enter a phone number.

More features 75

Call forwarding - follow me after successful identification:

s t w Select the menu item and confirm.

w Confirm the option shown. Call forwarding is activated immediately.

Caller ID suppression

The caller ID display can only be suppressed for one subsequent call and the setting is not saved if the number is redialed.

u Open the system menu.

s t w Select and confirm the basic service.

Either:

N 2 Enter the service code.

Or:

s t w Select the menu item and confirm. s t w Select the menu item and confirm.

then:

o Enter the phone number of the user. If the called party accepts the call, your

phone number will not be displayed.

VAR Y FORWARD

SAVE

Note:

The function must be approved for your communications system.

BASIC SERVICE

OTHER FUNCT.

DISPLAY SUPPR

76 More features

Activating/deactivating do not disturb

If you do not wish to take calls, you can activate do not disturb. Internal callers will hear the ringing tone and the announcement "Do Not Disturb"; external calls will be diverted to the attendant. Your administrator can also set up call forward

ing destinations for the "Do not disturb" function, to which you can forward your internal and external calls.

Prerequisite: The administrator has enabled the Do Not Disturb function for all extensions.

u Open the system menu.

s t w Select and confirm the basic service.

Either:

2 2 Enter the service code.

Or:

s t w Select the menu item and confirm. s t w Select the menu item and confirm. The display indicates whether "Do not dis-

turb" is activated or not.

then:

w Confirm the display if "Do Not Disturb" should be activated. w Confirm the display if "Do Not Disturb" should be deactivated.

BASIC SERVICE

Feature settings

DO NOT DISTURB

Activate

Deactivate

Note:

A tone reminds you that Do Not Disturb is activated when you seize the trunk.

The attendant can circumvent the Do Not Disturb function and reach you anyway.

If the administrator has locked the Do Not Disturb function for all users, the item "Do Not Disturb" will not appear in the Service menu.

More features 77

Tracing a call

You can identify malicious external callers. You can record the caller's phone number during a call or for up to 30 seconds after a call. You should not hang up in the process.

p During the call.

u Open the system menu.

s t w Select and confirm the basic service.

Either:

N 3 Enter the service code.

Or:

s t w Select the menu item and confirm. s t w Select the menu item and confirm.

Note:

The function must be approved for your communications system.

BASIC SERVICE

OTHER FUNCT.

CALL TRACING

Note:

If the trace is successful, the transmitted data is stored by your network operator. Consult your administrator.

78 More features

Entering commands via tone dialing (DTMF suffix dialing)

After dialing a phone number, you can activate DTMF tone dialing (dual-tone multifrequency signaling) in order to operate devices, such as answering ma

chines or automatic directory inquiry or switching systems, by means of command inputs.

p You are connected.

u Open the system menu.

s t w Select and confirm the basic service.

Either:

N  Enter the service code.

Or:

s t w Select the menu item and confirm. s t w Select the menu item and confirm.

You can now enter commands with the keys 0 to 9, the star key and the hash key.

BASIC SERVICE

OTHER FUNCT.

DTMF DIALING

Note:

Ending the call also deactivates DTMF suffix dialing.

Depending on the system configuration, "DTMF DIALING" may be displayed immediately after the number has been entered. In this case, you can enter commands immediately after dialing a phone number.

More features 79

Parking/activating calls

You can park up to 10 internal and/or external calls and resume them at another telephone.

Calls cannot be parked if:

• All parking positions are busy.

• The parking position you have selected is busy.

• The user is the attendant console.

• The call is a consultation call.

• The call is part of a conference.

Parking and resuming a call

You can park a call to your handset in a free parking position and resume it on your own telephone or on another one. This function can also be performed on telephones that do not have a display.

p You are conducting a call.

o Enter the system parking code (consult your administrator if you need assis-

tance).

1 ... 9 Enter and note a parking position number between 1 and 9.

The call is parked.

a Press the End call key.

Retrieving a parked call

The handset is not in the charging cradle. Hold down the Talk key.

o Enter the system parking code (consult your administrator if you need assis-

tance).

1 ... 9 Enter the parking position number between 1 and 9 that you have noted and

continue your call.

Parking is not possible

If the selected parking position or all parking positions are busy or if call parking is not available for some other reason, you will receive both an acoustic and a visual message.

If the selected parking position is occupied, you will receive a display message and hear the busy tone.

Either:

w Confirm and continue the call.

Or:

a Press the End call key. You receive a recall for the call on hold.

TO WAIT. CALL

80 More features

System-wide speaker call

You can place a speaker call to an internal party on HiPath 4000 using the loudspeaker on their telephone to establish a connection. You can also initiate a speaker call from a consultation call.

To cancel a speaker call, replace the handset or - during an inquiry - resume the call that was in progress.

From your handset, you can directly call any internal user whose telephone has the speakerphone function or a loudspeaker.

A destination party is contacted via his or her internal phone number.

Speaker call

The handset is not in the charging cradle. Press and hold down the Talk key.

o Enter the code for "Speaker call" and

o the user's phone number.

A connection to that user's loudspeaker will immediately be established if:

• the station is not busy,

• the handset has not been lifted and

• speaker call protect is not activated.

The caller hears a confirmation tone when the connection has been established and can start speaking.

The called party can accept the call by lifting the handset.

Note:

Please ensure for all functions that "Speaker call protect" is deactivated on the relevant phones

 page 81.

If a speaker call is placed to a party and "Speaker call protect" is activated, the speaker call will be ignored and a normal call will be placed.

Privacy:

You can place a speaker call to a called subscriber but will not hear the other party unless they have pressed the Talk key.

Note:

The number of possible speaker calls and normal calls is the same.

More features 81

Activating/deactivating "Speaker call protect"

You can protect yourself against being addressed directly with a speaker call. Attempts to address you directly over the speakerphone will then become normal calls.

u Open the system menu.

s t w Select and confirm the basic service. s t w Select the menu item and confirm.

s t w Select the menu item and confirm.

then:

Activating or deactivating

w Confirm the menu item displayed.

BASIC SERVICE

Feature settings

CALL PROTECT

Activate

Deactivate

82 More features

System appointment function

You can arrange for the communications system to remind you of an appointment. For this to happen, you need to save the times at which you wish to be reminded. This is possible for a period of up to 24 hours in advance.

Saving an appointment

u Open the system menu.

s t w Select and confirm the basic service.

Either:

M Enter the service code.

Or:

s t w Select and confirm the option shown.

The display indicates whether an appointment reminder has already been saved.

s t w Select the menu item and confirm.

then:

o Enter the time as 3 or 4 digits, for example 845 for 8.45a.m. or 1500 for 3p.m.

w Confirm the option shown.

Deleting a saved appointment

u Open the System Menu.

s t w Select and confirm the basic service.

Either:

M Enter the service code.

Or:

s t w Select and confirm the option shown. A saved reminder is displayed. s t w Confirm if you have saved several reminders.

then:

s t w Select the menu item and confirm.

a Press the End call key.

Using timed reminders

Prerequisite: You have saved a reminder. The saved time arrives.

The handset starts ringing.

Press the Talk key. The appointment time is displayed.

a Press the End call key.

BASIC SERVICE

REMINDER

NEW REMINDER

SAVE

BASIC SERVICE

REMINDER

DELETE

Reminder

If you do not accept the reminder, the handset will ring a few more times and "Appoint." will be displayed before the reminder is deleted.

More features 83

Locking the telephone line to prevent misuse

You can prevent unauthorized persons from using your telephone (and the system directory) during your absence.

Prerequisite: You have been assigned a personal identification number (PIN) by the administrator responsible for your communications system.

Locking the telephone line to prevent unauthorized dialing

u Open the system menu.

s t w Select and confirm the basic service.

Either:

L M Enter the service code.

Or:

s t w Select the menu item and confirm. s t w Select the menu item and confirm.

then:

o Enter the PIN (code no.).

w Press this key. If the PIN is correct, it will be confirmed with: "carried out" on the

display.

Enabling the telephone again:

u Open the system menu.

s t w Select and confirm the basic service.

Either:

L M Enter the service code.

Or:

s t w Select the menu item and confirm. s t w Select the menu item and confirm.

then:

o Enter the PIN (code no.).

w Press this key. If the PIN is correct, it will be confirmed with:

"carried out" on the display.

Note:

As an alternative, however, you can lock your handset against misuse (see local functions). Neither of these two locks may be active if you want to place a call. The PINs for locking the telephone line and for the handset are not identical.

BASIC SERVICE

PIN / COS?

CHANGE COS

BASIC SERVICE

PIN / COS?

CHANGE COS

84 Index

Index

Acoustic profile ......................................................... 21

Advisory tones ......................................................... 30

Alarm ........................................................................ 23

Alarm clock .............................................................. 22

switching on/off ..................................................... 22

Alerting tone (beep) ...........................................21, 30

Anniversary, see Appointment Answering machine

listening to messages ........................................... 35

Appointment

displaying missed .................................................. 22

missed ................................................................... 22

notification ............................................................. 22

setting ................................................................... 21

Appointments

~ in system ............................................................ 82

confirming ............................................................. 82

deactivating ........................................................... 82

saving .................................................................... 82

Assigning number key .............................................. 32

Authorization ............................................................ 36

Automatic

answer .................................................................. 29

redial ..................................................................... 14

Automatic call forwarding ......................................... 64

Base station

changing ............................................................... 34

changing the name ............................................... 34

Battery

charging ................................................................ 10

inserting .................................................................. 9

Beep (alerting tone) ...........................................21, 30

Best Base ................................................................. 34

Bluetooth .................................................................. 24

activating ............................................................... 25

changing device name .......................................... 26

copying directory (vCard) ......................................20

de-registering devices ........................................... 25

list of known devices ............................................. 25

registering devices ................................................ 25

Calendar .................................................................. 21

Call

accepting .............................................................. 15

anonymous ~ ........................................................ 75

external ................................................................. 14

holding .................................................................. 45

parking .................................................................. 79

Transferring .......................................................... 48

Call answering ......................................................... 29

Call charge assignment ........................................... 71

Call forwarding ......................................................... 59

via codes ............................................................... 65

Call list

calling back a caller .............................................. 18

copying the number to the phonebook ................. 18

deleting ................................................................. 18

deleting an entry ................................................... 18

dialing from the ..................................................... 15

entry ...................................................................... 18

opening ................................................................. 18

Call lists ................................................................... 18

Call number

suppression .......................................................... 75

Call waiting .............................................................. 46

Callback ................................................................... 72

Callback request ...................................................... 69

Caller list .................................................................. 55

Caller Melody (VIP) .................................................. 19

Calling

external ................................................................. 14

Caring for your device .............................................. 37

Changing

display language ................................................... 28

earpiece volume ................................................... 29

handset PIN .......................................................... 33

speaker volume .................................................... 29

Changing device names (Bluetooth) ........................ 26

Character charts ...................................................... 38

Charging cradle (handset)

connecting .............................................................. 9

installing .................................................................. 9

CLIP picture

viewing in resource directory ................................ 24

CLIP picture, in directory .......................................... 19

Color scheme ........................................................... 28

Conference

adding a party ....................................................... 51

ending ................................................................... 53

initiating ................................................................. 53

setting up .............................................................. 50

transferring ............................................................ 52

viewing .................................................................. 53

Connect with base station ........................................ 34

Connecting a USB data cable .................................. 11

Consultation (second connection) ............................ 45

Contact with liquid .................................................... 37

Index 85

Control key ........................................................... 6, 12

Copying

all .......................................................................... 57

entry ...................................................................... 57

Copying all ............................................................... 57

Copying entry ........................................................... 57

Copying the directory ............................................... 57

Correcting incorrect entries ...................................... 13

Delayed call forwarding ............................................ 67

Delayed extension dialing ........................................ 15

De-registering devices (Bluetooth) ........................... 25

Dialing

from a call list ........................................................ 15

from the directory .................................................. 14

from the redial list .................................................. 14

using quick dial ..................................................... 32

Different telephone ................................................... 73

Directory ................................................................... 19

copying numbers ................................................... 20

copying vCard (Bluetooth) .................................... 20

creating an entry ................................................... 19

dialing numbers ..................................................... 14

entry ...................................................................... 19

memory ................................................................. 20

opening ................................................................. 19

order of entries ...................................................... 19

searching .............................................................. 19

selecting an entry .................................................. 19

Directory, copying .................................................... 57

Disclaimer ................................................................ 36

Display

backlight .......................................................... 28, 29

changing display language ................................... 28

color scheme ......................................................... 28

memory in the directory ........................................20

missed appointment/anniversary .......................... 22

screensaver .......................................................... 28

setting ................................................................... 28

Display icons ............................................................ 40

Display keys ......................................................... 6, 12

assigning ............................................................... 32

icons ...................................................................... 40

Displaying new messages ....................................... 17

Do not disturb ........................................................... 76

switching off ringtone when in charging cradle ..... 23

time control ........................................................... 23

DTMF suffix dialing .................................................. 78

Earpiece volume ...................................................... 16

End call key .......................................................... 6, 14

Entering numbers .................................................... 13

Entering special characters ...................................... 13

Entering special letters ............................................. 13

Entering text ............................................................. 13

Entering umlauts ...................................................... 13

Environment ............................................................. 37

Extension systems, dialing in

(delayed extension dialing) ...................................... 15

Fast access .............................................................. 32

Fax messages ......................................................... 69

Firmware update ...................................................... 26

Fixed forwarding ...................................................... 60

Forwarding

activating/deactivating .......................................... 64

automatic .............................................................. 64

changing for other station .....................................68

fixed ...................................................................... 60

for other station ..................................................... 67

variable ................................................................. 62

viewing for other station ........................................ 68

Functions ................................................................. 44

Getting started ........................................................... 9

Gigaset QuickSync .................................................. 20

Handset

automatic keypad lock ..........................................29

changing the PIN .................................................. 33

changing to a different base station ...................... 34

changing to best reception .................................... 34

color scheme ........................................................ 28

connecting the charging cradle ............................... 9

display backlight ............................................. 28, 29

display language ................................................... 28

earpiece volume ............................................. 16, 29

idle status .............................................................. 13

keypad illumination ............................................... 29

large font ............................................................... 28

muting ................................................................... 16

overview .................................................................. 6

registering ............................................................. 10

registering to another base station ....................... 34

restoring to default setting .................................... 33

setting up for use .................................................... 9

speaker volume .............................................. 16, 29

switching on/off ..................................................... 12

86 Index

Handset charging time ............................................. 38

Handset operating time ............................................ 38

Handsfree key .......................................................... 16

Handsfree mode ...................................................... 16

Hash key .................................................................... 6

Headset (Bluetooth) ................................................. 24

Headset port .................................................. 6, 10, 11

Hearing aids ............................................................... 8

Help .......................................................................... 36

Holding ..................................................................... 45

Icons

alarm clock ............................................................ 23

displaying new messages ..................................... 17

indications ............................................................. 40

on display keys ..................................................... 40

status bar .............................................................. 40

Identification number ................................................ 73

Idle status

returning to ............................................................ 13

Illumination, keypad ................................................. 29

Indications, icons ..................................................... 40

Information message, viewing ................................. 69

Key 1 (fast access) .................................................... 6

Key, assigning .......................................................... 32

Keypad illumination .................................................. 29

Keypad lock, automatic ............................................ 29

Keys

control key ......................................................... 6, 12

display keys ...................................................... 6, 12

end call key ....................................................... 6, 14

fast access .............................................................. 6

handsfree key ....................................................... 16

hash key .................................................................. 6

menu ..................................................................... 12

message key ........................................................... 6

on/off key ................................................................ 6

profile .................................................................... 21

profile key ................................................................ 6

R key ....................................................................... 6

star key ................................................................... 6

talk key .................................................................... 6

Language, display .................................................... 10

Large font ................................................................. 28

Liquids ..................................................................... 37

List

known devices (Bluetooth) .................................... 25

Locking/unlocking

system .................................................................. 83

Locking/unlocking the keypad .................................. 12

Lower/uppercase ..................................................... 13

Mailbox ........................................................69, 70, 73

deleting entries ..................................................... 69

viewing .................................................................. 69

Making anonymous calls .......................................... 75

Making calls

accepting a call ..................................................... 15

external ................................................................. 14

Medical equipment ..................................................... 8

Melody

ringtone for internal/external calls ......................... 30

Memory in the directory ........................................... 20

Memory, resource directory .....................................24

Menu key ................................................................. 12

Message key .............................................................. 6

Message lists ........................................................... 17

Message, viewing .................................................... 69

Microphone

switching on/off ..................................................... 16

Missed appointments/anniversaries ......................... 22

Muting the handset .................................................. 16

Network mailbox ...................................................... 35

activating/deactivating .......................................... 35

entering number .................................................... 35

Network MB, see Network mailbox Number

copying to the directory ......................................... 20

entering the number of the network mailbox ......... 35

saving in the directory ........................................... 19

On/off key .................................................................. 6

Override ................................................................... 47

Overview

handset ................................................................... 6

Index 87

Package contents ...................................................... 9

Parking a call ........................................................... 79

PC interface ............................................................. 26


as CLIP image ...................................................... 24

as screensaver ...................................................... 24

deleting ................................................................. 24

formats .................................................................. 24

renaming ............................................................... 24

Power adapter ............................................................ 8

Profile ....................................................................... 21

Profile key ............................................................ 6, 21

Project assignment .................................................. 71

Questions and answers ........................................... 36

QuickSync .......................................................... 20, 26

R key .......................................................................... 6

Redial list ................................................................. 14

Registering (handset) ............................................... 10

Registering devices (Bluetooth) ............................... 25

Resource directory ................................................... 24

memory ................................................................. 24

viewing CLIP picture ............................................. 24

Ringtone

changing ............................................................... 30

melody for internal/external calls .......................... 30

switching off when in charging cradle ................... 23

time control ........................................................... 23

volume .................................................................. 30

Ringtones ................................................................. 30

Safety notes ............................................................... 8

Screensaver ............................................................. 28

Searching in directory .............................................. 19

Second call .............................................................. 54

Second connection (consultation) ............................ 45

Setting the date .................................................. 11, 43

Setting the time .................................................. 11, 43

Setting up for use, handset ........................................ 9

Signal strength ......................................................... 40

Snooze mode (alarm clock) ..................................... 23

Sound

deleting ................................................................. 24

format .................................................................... 24

playback ................................................................ 24

renaming ............................................................... 24

Sounds for ringtones ................................................ 24

Speaker ................................................................... 16

Speaker call ............................................................. 80

Speaker calling ........................................................ 81

Speaker volume ....................................................... 16

Star key ...................................................................... 6

Status bar .................................................................. 6

icons ..................................................................... 40

Switching between calling partners .......................... 49

System functions ..................................................... 44

Talk key ..................................................................... 6

Technical data ......................................................... 38

Time control for external calls .................................. 23

Toggle/connect ........................................................ 49

Tone dialing ............................................................. 78

Tracing a call ........................................................... 77

Transferring ............................................................. 48

Transferring (call) ..................................................... 48

Troubleshooting

general .................................................................. 36

Update ..................................................................... 26

Upper/lowercase ...................................................... 13

USB port .................................................................... 6

Variable forwarding .................................................. 62

Vibration alarm ......................................................... 30

Viewing a message .................................................. 69

VIP group, classify directory entry ........................... 19

VIP ringtone ............................................................. 19

Voicemail ................................................................. 69

Volume

earpiece ................................................................ 29

handset speaker volume ....................................... 29

handset speaker/earpiece volume ........................ 16

speaker ................................................................. 29

Unify OpenScape SL5, OpenScape User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
