Controls and Indicators

Warning!

Troubleshooting

EAB C

1 Antenna 2 Belt Clip 3 PTT (Push to Talk) Key 4 Light/Lock Key 5 Squelch Knob 6 Volume/Power Knob 7 LCD Display 8 Scan button ( 9 Memory button (

10 WX Mode/Weather

Alert button

WX ALERT

( 11 Speaker 12 Channel Up

button (s) 13 Channel Down

button (t) 14 16/9 – Triple Watch

button (

16/9/TRI

3 4

SCAN

MEM

)

KJIHG

HH985 MARINE RADIO

W ATERTIGHT

8 9

10 13

15 USA/International/

Canadian button (

16 TX Power button

(

1W/5W

17 Microphone 18 Battery

A Key Lock Indicator B TX Power Indicator

)

C Channel Number

Display

)

D Battery Indicator E USA/International/

Canadian (

) Indicator

CND

F T riple W atch Indicator G Memory Indicator H Weather Mode

Indicator

I Weather Alert Indicator J Scan Indicator K Transmit Indicator

5 6

7 14

15 16 17

U/I/C

)/Invert Display

USA/INT/

+ The HH985 is watertight only when both

the antenna and the battery are properly attached.

+ Do not operate the transmitter of any radio

equipment unless all the Radio Frequency (RF) connectors are secure and any open connectors are properly terminated.

+ Do not operate the transmitter of any radio

equipment near electrical blasting caps or in an explosive atmosphere.

+ Do not let children operate any

transmitter-equipped radio equipment without proper supervision.

+ Have your radio equipment serviced by a

qualified technician.

+ Do not operate the transmitter of any radio

! Not enough range

Cause: Line of sight blocked

" Increase antenna height.

! Will not transmit on 5 watt range but will

transmit on the 1 watt range.

Cause: Low voltage " Recharge or replace the batteries.

(Use high quality alkaline batteries)

! Will not transmit while on the charger.

Cause: Low voltage " The unit is not designed to transmit

while on the charger. The charger does not supply enough power for

transmitting. equipment with the antenna touching or close to the eyes, face, or exposed body parts.

Nickel-Cadmium Battery Pack Warning

)

+ This equipment contains a Nickel-

Cadmium Battery Pack.

+ Cadmium is a chemical known to the State

of California to cause cancer.

+ The Nickel-Cadmium Battery Pack

contained in this equipment may explode if disposed of in a fire.

+ Do not short-circuit the Battery Pack. + Do not charge the Nickel-Cadmium

! Battery will not charge.

Cause: Charger inoperative " Replace charger. Damage to the

charger can be a result of keying up

the radio while on the charger.

! Battery will not hold a charge

Cause: Battery has developed a

memory

" Periodically, drain the ni-cad battery

before recharging. (This can be done

by listening to the weather channel

until the battery drains). Battery Pack used in this equipment in any

charger other than the one designed to charge this Battery Pack. Using another charger may damage the Battery Pack or cause the Battery Pack to explode.

+ Nickel-Cadmium batteries must be

disposed of properly.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

Contents

Introduction ................................................ 2

Features .................................................2

Technical Support and Service..............3

Maritime Radio Services Operation.......3

Parts and Accessories ..............................4

Getting Started...........................................5

Mounting the Drop-in Charger ...............5

Attaching the Antenna ...........................5

Attaching the Battery Pack ....................6

Charging the Battery Pack.....................7

Operation .................................................... 8

Turning on the Unit

and Setting Squelch...............................8

Selecting a Channel...............................9

One-touch Channel 16/9........................9

Monitoring Weather Channels .............10

T riple W atch..........................................11

Weather Alert .......................................12

NWR-SAME Alert ................................13

Registering FIPS Code ........................14

USA, International

and Canadian Channels ...................... 15

Programming a Channel into Memory .. 15

Deleting a Channel from Memory........15

Scanning ..............................................16

Transmitting ..........................................16

Lighted Keys and Display.....................17

Battery Indicator...................................17

Reversible Channel Display ................. 17

Key Lock...............................................18

Marine Channels - USA ........................... 19

Marine Channels - International.............20

Marine Channels - Canada .....................21

NWR-SAME Alert Level ...........................22

Parts and Accessories ............................23

Specifications ..........................................24

Introduction

The HH985 is a watertight, portable two-way VHF transceiver. It is compact, lightweight, rugged and fits easily in your hand. This handheld VHF marine radio will give you consistent, outstanding performance in virtually all conditions and situations.

To ensure that you get the most from the HH985's features, please read this operating guide carefully before using the unit.

Features

n Watertight n Triple W atch Mode n Priority Channel Startup (Channel 16) n Programmable Memory n One-Touch Channel 16/9 n 10 Weather Channels n Weather Alert n NWR-SAME Alert n Programmable FIPS Code n Memory Scan n USA, International and Canadian Channels n Table-Top Drop-In Charger

(can also be wall-mounted)

n Rechargeable Nickel-Cadmium Battery Pack n Alkaline Battery Pack n Battery Save Operation n Key Lock n Back-Lit Keys and Display n Reversible Channel Display n Belt Clip n Wrist Strap n TX Power 1W/5W

Technical Support and Service

Your Uniden dealer can provide you with sales assistance and information. If your marine radio does not perform properly, follow the troubleshooting tips in the back of this reference guide. For technical support contact Uniden Repair/Service department at 1-800-235-3874. The radio contains no userserviceable parts.

Unauthorized adjustment will void the warranty and may cause illegal radio operation. Be sure that a qualified technician services your radio equipment.

Caution: Changes or modifications to this

product not expressly approved by Uniden, or operation of this product in any way other than as detailed by this Operating Guide, can void your authority to operate this product.

Maritime Radio Services Operation

This transmitter will operate on channels/ frequencies that have restricted use in the United States. The channel assignments include frequencies assigned for exclusive use of the U.S. Coast Guard, use in Canada, and use in international waters. Operation in these frequencies without proper authorization is strictly forbidden. For frequencies/channels that are currently for use in the world see page 19~22. Please contact the FCC Call Center at 1-888-CALL-FCC for any additional channel information.

Parts and Accessories

HH985 MARINE RADIO

SCAN

WATERTIGHT

HH985

Antenna

(HH9408)

Alkaline Battery Holder

(GHDZ34956Z)

Drop-in Charger

(GCAS346933Z)

AC Adapter

(BYYY0603001)

Wrist Strap

(RETC484647Z)

Ni-cad Battery

(BP-985)

Mounting Screws (SSCW8840165)

Reference Guide

Printed Material

If any of these items are missing from the box, contact your Uniden Dealer.

Getting Started

Mounting the Drop-in Charger

1. Mount the drop-in charger to either a counter or wall.

2. Plug one end of the AC adapter into the wall outlet and the other end into the dropin charger.

Attaching the Antenna

Attach the antenna to the HH985. Be sure the antenna is firmly seated.

Attaching the Battery Pack

1. Slide the battery pack onto the bottom of the radio.

HH985 MA RINE RADIO

WATERTIGHT

2. Use a coin or screwdriver to turn the screw that connects the battery pack to the HH985. Be sure the battery pack fits tightly against the HH985's body.
