Umax VisionBook 12Wr Flex User Manual
EN
CZ
SK
12Wr Flex
12Wr Flex
USER MANUAL ENGLISH
en
GETTING TO KNOW YOUR COMPUTER
2 2
3
5
6
7
1
84
1. camera
2. microphone
3. touch screen
4. Windows button
5. LED indicator - power
6. LED indicator - caps lock
7. LED indicator - num lock
8. speakers
12Wr Flex
10 11 12
13 14 15 16 17
9. M.2 SATA SSD 2242
10. LED indicator - charging
11. micro HDMI
12. USB 3.0
13. power button
14. micro SD
15. USB 3.0
16. headphones+microphone jack
17. charging port
en
9
en
TURNING ON YOUR COMPUTER
Long press the power button to turn on your computer.
EXPANDING STORAGE
You can expand your storage space for saving files and
installing programs by adding M.2 SATA SSD drive.
Simply unscrew the hatch on the back side of your laptop
and insert the SSD drive. The type of the drive is M.2 SATA
SSD and size 2242 is supported.
You will need to initialize and format the drive before you
can use it.
USING THE TOUCHPAD
[1] Slide Horizontally
[2] Slide Vertically
[3] Slide Diagonally
12Wr Flex
en
[4] Tap & Double Tap
• Tap an app to select it.
• Double tap an app to launch it.
en
[5] Drag and Drop
• Double tap an item then slide the
same finger without lifting it o the
touchpad.
• To drop the item to its new location
lift your finger.
[6] Left Click
• Click an app to select it.
• Double click an app to launch it.
[7] Right Click
• Click to open the right-click menu.
[8] Two Finger Tap
• Tap two fingers to simulate the
right-click function.
[9] Two Finger Scroll (Up/Down)
• Slide two fingers up or down to
scroll.
[10] Two Finger Scroll (Left/Right)
• Slide two fingers left or right to scroll.
[11] Zoom Out
• Bring together two fingers to
zoom out.
[12] Zoom In
• Spread apart your two fingers to
zoom in.
[13] Two Finger Drag and Drop
• Select an item and then press and
hold the left button. Using your
other finger slide on the touchpad
to drag the item.
12Wr Flex
en
en
[14] Three Finger Tap
• Tap three fingers to invoke Cortana.
[15] Three Finger Swipe Left/Right
• Swipe three fingers left or right to
switch between open apps.
[16] Three Finger Swipe Up
• Swipe three fingers up to open Task
View.
[17] Three Finger Swipe Down
• Swipe three fingers down to show
desktop.
[18] Four Finger Tap
• Tap four fingers to invoke Action
Center.
USING THE KEYBOARD
12Wr Flex
en
+
+
+
+
+
+
+
+
+
+
+
Enables or disables the touchpad
Puts the laptop into Sleep mode
Turns the display on or o
Turns the speaker on or o
Turns the speaker volume down
Turns the speaker volume up
Decreases display brightness
Increases display brightness
Turns Airplane mode on or o
Skip to previous track or rewind
Play or pause
+
+
Skip to next track or fast forward
Toggles the display mode
en
WORKING WITH WINDOWS® 10
Launches the Start menu
+
+
+
+
+
+
+
+
+
+
Launches Action Center
Launches the desktop
Launches the File Explorer
Launches Settings
Launches Connect panel
Activates the Lock screen
Minimazes all currently active windows
Launches Search
Launches Project panel
Opens the Run windows
12Wr Flex
en
+
+
+
+
Opens Ease of Access Center
Opens the context menu of the Start button
Launches the magnifier icon and zooms in
your screen
Zooms out your screen
WINDOWS TIPS
The Tips app in Windows 10 is full of short-and-sweet tips that help
you get the most out of Windows 10
Select the Start button, type tips, and then select Tips at the top of
the list of results.
en
SAFETY INFORMATION
Operating temperature: 10° to 35° C, storage temperature: -25° to 45° C,
relative humidity: 0% to 90% (noncondensing).
Built-in battery. Do not attempt to replace or remove the battery yourself. You may dam-
age the battery, which could cause overheating and injury. The battery should be replaced
by an authorized service provider, and must be recycled or disposed of separately from
household waste.
Handle with care. It has sensitive electronic components inside. Place it on a stable work
surface that allows for air circulation under and around the computer. Your computer can
be damaged if dropped, burned, punctured, or crushed, or if it comes in contact with
liquids, oils, and lotions. Do not use a damaged computer as it may cause injury.
Liquid exposure. Keep your computer away from sources of liquid, such as drinks, oils,
lotions, sinks, bathtubs, shower stalls, and so on. Protect your computer from dampness,
humidity, or wet weather, such as rain, snow, and fog.
Charging. Charge only with the included power adapter. Other power adapters might
not meet safety standards, and using such power adapters could pose a risk of death or
injury. Using damaged power adapters or cables, or charging when moisture is present,
can cause fire, electric shock, injury, or damage to your computer or other property. Do
not use a power adapter in wet locations, such as near a sink, bathtub, or shower stall, or
connect or disconnect the power adapter with wet hands.
Medical device interference. It contains components and radios that emit electromagnetic fields, including magnets, which may interfere with pacemakers, defibrillators, and other
medical devices. Maintain a safe distance between your medical device and computer.
Consult your physician and medical device manufacturer for information specific to your
medical device.
Repetitive motion. When you perform repetitive activities such as typing or playing
games, you may experience discomfort in your hands, arms, wrists, shoulders, neck, or
other parts of your body. If you experience discomfort, stop using computer and consult
a physician.
Choking hazard. Some accessories may present a choking hazard to small children. Keep
these accessories away from small children.
High-consequence activities. Your computer is not intended for use where the failure of
the computer could lead to death, personal injury, or severe environmental damage.
Explosive and other atmospheric conditions. Using computer in any area with a potentially explosive atmosphere may be hazardous—particularly in areas where the air contains
high levels of flammable chemicals, vapors, or particles such as grain, dust, or metal
powders. Exposing computer to environments having high concentrations of industrial
chemicals, including evaporating liquified gases such as helium, may damage or impair its
functionality.
