Umax TS-219P PLUS, TS-419P PLUS, TS-119P PLUS User Manual

Abundant Home and SOHO Server Features

• RAID Server

• iSCSI Target

• Web Server

• File Server

• FTP Server

• MySQL Server

• Media Server

• Backup Server

• Printer Server (Max. 3 sets)

• Remote Replication (Rsync)

• Surveillance Station

• and more...

●

2.5-inch & 3.5-inch hard disk drives support

●

Hot-swappable hard disk drives with advanced RAID management

●

Online RAID capacity expansion & online RAID level migration

●

Gigabit LAN with Wake on LAN and jumbo frame settings

●

Built-in iSCSI target service & virtual disk for storage expansion

●

Smart IP filter & comprehensive log systems

●

Complete backup solution including cloud-based and Apple Time Machine backup

●

Streaming multimedia contents to iPhone or Android phones

●

Ultra low power consumption & quiet operation

512MB

DDRIII Memory

512MB

DDRIII Memory

Brand NEW

1.6GHz CPU

Brand NEW

1.6GHz CPU

for Home and SOHO Users

All-in-One NAS Server with iSCSI

1/2/4-Bay

Superior High Performance for Cross-platform Data Sharing
Energy-saving Design

TS-119P+ TS-219P+ TS-419P+

1

2

3

for Home and SOHO Users

Overview

QNAP's TS-x19P+ Series Turbo NAS servers, including the 1-drive TS-119P+,
2-drive TS-219P+ and 4-drive TS-419P+, are designed for home and soho users
who need a storage solution with large capacity to back up and share huge
amount of data, such as music, videos, photos, and documents. The new models
utilize Marvell’s new 1.6GHz embedded processor, include 512MB of DDRIII
memory, and support both 2.5-inch and 3.5-inch SATA II hard disk drives. The
models combine an attractive industrial design, outstanding performance, ultra
low power consumption, consumer-friendly features, and high system reliability.

TS-x19P+ Series Turbo NAS supports file access and system management
across Windows, Mac, Linux, and UNIX. The new models offer business-class
features such as EXT3 and EXT4 file systems, iSCSI target service, virtual disk
drive (VDD), RAID 0, 1, 5, 6, 5+spare, single and JBOD disk configurations,
online RAID capacity expansion, online RAID level migration, RAID recovery*,

policy-based IP blocking, instant email and SMS alert, CD/DVD ISO backup and
sharing, virtual host supported web server, Wake on LAN, scheduled power
on/off, and IP video surveillance.

TS-x19P+ Series supports UPnP media server to allow users to connect to a
wide range of network media players, such as Sony PS3 and Microsoft Xbox 360
gaming consoles, and NFS-supported High-Definition (HD) digital media players
for HD video playback. Users can even use their iPhone or Android phones to
stream and play the music, videos, and photos on the NAS from anywhere via
Wi-Fi or 3G network connection. The NAS also offers Download Station for
PC-less BitTorrent, FTP, and HTTP download and remote download management
over the local network or the Internet.

* The RAID features are available for 2-drive and 4-drive models only.

AII-in-One Server Features

window
window

window

All-in-One NAS Server with iSCSI

Surveillance Station

You can connect to 2-4 IP cameras via the NAS and set up an IP
surveillance system for live monitoring, video recording and playback.
QNAP NAS supports IP cameras from AXIS, D-Link, IPUX, LevelOne,
Linksys, Panasonic, and VIVOTEK.

Exclusive Windows-based Backup Utility

The automatic backup software, NetBak Replicator, is
provided for you to perform real-time synchronization or
schedule backup from multiple PCs to the Turbo NAS.

Virtual Host Supported Web Server

You can host multiple websites on Turbo NAS with the built-in web
server and virtual host feature. The NAS supports PHP, MySQL,
HTTPS connection, and SSL authentication. It is the ideal solution
for you to create your own websites, e-shops, blogs, content
management system (CMS), wiki, and so on.

Printer Server

The NAS supports network
printer sharing function
(max 3 USB printers).

X

3

X

3

Using QNAP NAS with iPhone or Android Phones

QNAP offers a free multimedia application QMobile for users of iPhone and
Android phones to carry all the multimedia files on the NAS in their pocket. You
can stream videos, watch and upload digital pictures, play music that are stored
on the NAS over the network and share your music playlists with other iPhone or
Android phones users.

Supports PS3 and XBox360

All the photos, music, and videos stored on the
Turbo NAS can be played via PS3 or XBox360
on your LCD TV or stereo Hi-Fi system.

Stream your high definition
video, music and photos to
QNAP NMP-1000P network
multimedia player from the
Turbo NAS.

Detailed logs of access to Turbo NAS via SAMBA,
iSCSI, FTP, AFP, HTTP, HTTPS, Telnet, and SSH, and
networking services accessed by online users are all
recorded.

With Virtual Host support, you can host multiple websites on a NAS.

Build Your Own Audio Library

• Play all the stored music anytime and anywhere!

• Display the music info such as album art, artist, genre, and so on.

• Create your own playlists for fast access to your favorite music.

• Share handpicked audios and playlists.

Brand-new Video Entertainment Feast

• Watch the videos online!

• Most of the video formats can be transcoded on Multimedia Station directly.

Secure Access Right Management

• Manage user’s authority easily.

• Let your friends upload and share their collections with you!

Manage Photos with Perfect Ease

• Browse the photos with slide show and Cooliris 3D wall.

• Customize photo display.

• Email photos to friends.

• Publish photos to Facebook, Blogger, MySpace, Twitter, Plurk and Windows

Live Blog.

QMobile is an application dedicated to iPhone and Android phones
users. You can browse and play the multimedia files stored on the
NAS, upload photos to the NAS and publish them instantly on the
Web, or download your favorite multimedia files to your
iPhone/Android phone and play them offline. It also provides
auto-synchronization feature upon every connection.

iPhoneAndroid phones

1

2

3

1TB

1TB

1TB

1TB

Online RAID Capacity Expansion

500GB

500GB

500GB

500GB

1.5TB (RAID5) 3TB (RAID5)

Online RAID Level Migration

RAID 1 Mirroring RAID 5 (3 HDD)

a. RAID 5 (4 HDD)

b. RAID 6 (4 HDD)

c. RAID 5 + spare (4 HDD)

+

+

+

TS-219P+/419P+ supports online RAID capacity expansion for expanding the
storage capacity of the RAID configuration and online RAID level migration for
upgrading the disk configuration to higher RAID level.

With the built-in iSCSI target feature, the NAS can be an ideal solution for
backup or storage expansion. The users can easily create dedicated virtual
drives on the NAS for their PCs or existing servers. The iSCSI drives on the
NAS can be formatted as file system and used as local drives.

Backup

LUN 1

On NAS (LUN1)

On NAS (LUN2)

Local drive

E:\ drive

Local drive

C:\ drive

F:\ drive

C:\ drive

Server

PC

Volume

LUN 2

Live Audio & Video Monitoring, Recording, and Playback over the Internet

Living room

Router

Internet

Remote monitoring
over the Internet

Garage

Home

• TS-419P+

High quality video recording in
MPEG4 and Motion JPEG format

Real-time monitoring and recording
for up to 30 frames/sec per channel

Live 2-way audio supported for
monitoring and voice broadcasting

Easy installation and management
from remote locations

Advanced RAID Management
with Hot-swap Design

Flexible Built-in iSCSI Target Service

Surveillance Station

Comprehensive Event Logs

Multimedia Station

QMobile for iPhone & Android Phones

Web Server Virtual Hosting

window

sitel.mysite.com

site2.mysite.com

www.mysite2.com

Internet

window

window

• Supports hosting up to 32

websites.

• Offers a cost-effective solution

for home and SOHO users to
create and host multiple
websites quickly and easily.

Carry the Media Center in Your Pocket

View and play terabytes of photos, music and video files on the NAS by QMobile
from anywhere regardless of the actual storage size of your iPhone or Android
phone as long as the Internet access is available.

Rock Your Life with My Jukebox

You can use the built-in feature My Jukebox of QMobile to create your favorite
playlists. The app supports categorization by playlist, album, artist, song's title,
recently played (auto-cached songs), and ID3 tag.

Showcase Your Photos Instantly

You can upload photos to the Turbo NAS straightway from your iPhone or
Android phone for sharing and backup.

Save Your Favorites for Offline Playback

You can save your favorite files from the NAS to your handheld devices and play
the multimedia contents offline even when you are out of the network range.

• Mount up to 256 ISO image files.

• Browse and share disc image files over LAN/WAN via multiple network

protocols such as SMB, AFP, NFS, FTP, and WebDAV.

ISO

A

B

A

C

TM

LAN

Internet

Office 2007

Photoshop

Drivers/Utilities

B

Policy-based Unauthorized IP Blocking:
You can allow, deny or auto block specified IP address or network domain
which attempts to connect to the Turbo NAS via
SSH/Telnet/HTTP(S)/FTP/samba/AFP.

Remote Login:

Turbo NAS supports remote login by SSH (secure shell) or Telnet connection.

SSL Security (HTTPS):

Turbo NAS can be accessed and configured by the web browser securely.
You can also upload a secure certificate and RSA private key in X.509PEM
format issued by a trusted provider for the users to access the NAS by
secure SSL login.

Secure FTP:

The NAS data can be transmitted with SSL/TLS (explicit) encryption. Passive
FTP port range setup is also supported.

Encrypted Remote Replication by Rsync:

The data on Turbo NAS can be backed up to or from another Turbo NAS or
Rsync server over the network securely.

Share Folder Management:

For the security of Windows network environment, you can choose to hide or
show the network share folders on the NAS.

User Authority Management:

You can create multiple user ID and password, and define the authority and
quota for each user.

Cloud Storage (Amazon S3)

Remote

Replication

NetBak
Replicator

3rd Party

Backup

Software

Ready

Router

Router

Time Machine

External Storage

Router

USB
OTB

QNAP NAS

Hard Disk Standby: You can configure the hard disks to enter standby mode
if there is no disk access within the specified period.

Scheduled Power on/off: The flexible scheduled power on/off feature enables you
to manage the NAS server's up time accordin

g to the working hours. You can set the

time for automatic system power on, power off, or restart on any days of the week.

Power Recovery Settings: The Turbo NAS can be configured to be turned on
or off when the AC power resumes after a power loss.

UPS Support & Advanced Standby Settings: The Turbo NAS supports the
majority of USB UPS devices (usbhid-ups supported). You can also set the
time for the server to enter standby mode when an abnormal AC power
supply is detected. When the power resumes, the server resumes to the
operation status before the power outage.

Wake on LAN: Enable this option to power on the NAS remotely by Wake on
LAN. Wake on LAN helps you manage your NAS conveniently.

• Client PC: Intel® Core™ 2 Quad 2.50GHz CPU, 4GB DDR2/800 RAM, Intel Dual Port

Server 82571 Networking Controller, Windows 7 Enterprise 32bit

• Testing Method: Connect the TS-419P+ and PC to switch, upload/download 3GB file,

FTP program: FileZilla 3.3.4

FTP

SAMBA

(MB/Sec)

25 50 75 100 1250

Read

TS-419P

Write

TS-419P+

UPUP

40%

UPUP

40%

UPUP

30%30%

40%

40%

UPUP

40%40%

Low Power Consumption

PC server

TS-419P+ (Sleep mode)
TS-419P+ (In operation)

13W

31W

350W

Ultra-high Speed Performance Secure Data Access

Efficient Power Management

ISO File Archiving and Sharing

Software Expansion via QPKG

Turbo NAS supports mounting ISO images of CD and DVD discs as network
shares for data archiving, storage, and sharing.

Complete Backup Solution

The NAS offers complete backup solution for data protection, including
cloud-based storage backup (Amazon S3), Apple Time Machine
support, encrypted remote replication, third party software backup,
one-touch-copy backup and QNAP exclusive Windows-based utility
NetBak Replicator.

Rsync Server

XDove named after XMail & Dovecot the 2 open source offerings
that are combined to provide a complete set of Email server
functionalities which is one-click installable on your QNAP NAS.
XDove not only provides SMTP, POP3 and IMAP services, it also
comes with a variety of features like multiple virtual domains and
accounts, AJAX webmail with extended functionalities including
personal folders, address book, calendar and real-time chat
among users under the same mail domain.

QNAP NAS

QPKG Software Platform

Joomla!

MLDonkey

Optware

IPKG

More...

You can maximize the usage of
Turbo NAS by installing additional
QPKG software packages
developed by the users and
community worldwide.

MLDonkey is a door to the "donkey" world, a multi-network,
multi-platform open source P2P application used to exchange big
files on the Internet and present most features of the basic
Windows donkey client and additionally supports overnet, fasttrack,
BitTorrent, and gnutella protocols (and more)! The core works best
with Sancho the premier graphical user interface for MLDonkey.

WordPress is a free, open-source personal publishing system
that allows you to easily create a complex blog, or web log, on
your site. Written in PHP and supported by a MySQL database,
WordPress offers intuitive administrative tools and sophisticated
design features that make it easy to develop and integrate a
personal or professional blog on your site.

Joomla! is a free, open source content management system for
publishing content on the world wide web and intranets. The system
includes features such as page caching to improve performance,
RSS feeds, printable versions of pages, news flashes, blogs, polls,
website searching, and language internationalization.

Squeezebox Server is the server software from Squeezebox (formerly
Slim Device) that manages common digital audio formats (.mp3, .flac,
.ogg, etc.) and streams them to its players. This Squeezebox Server
QPKG is a combination of SSOTS (made by flipflip) and Squeezbox
server. It gives you a one-click install solution, without the need to
download and install Squeezebox server yourself.

Ipkg, or the Itsy Package Management System, is a lightweight
package management system designed for embedded devices. It is
used in the Unslung operating system for the Linksys NSLU2, in
OpenWRT, OpenMoko, Gumstix, iPAQ and now on QNAP NAS too.

1

2

3

4

5

Operating System

Embedded Linux

Protocols

CIFS/SMB, AFP (3.2), NFS(v3), FTP, FTPS, HTTP,
HTTPS, Telnet, SSH, iSCSI, SNMP, SMTP, SMSC

Platforms

• Microsoft Windows 2000, XP, Vista (32/64-bit),
Windows 7 (32/64-bit), Windows Server 2003/2008

• Apple Mac OS X

• Linux & UNIX

File System

• Internal: EXT3, EXT4

• External: EXT3, EXT4, NTFS, FAT32, HFS+

Networking

• TCP/IP IPv4 & IPv6 Dual Stack

• Dual Gigabit Ethernet with Jumbo Frame *

• Port Trunking/NIC Teaming (Modes: Balance-rr, Active
Backup, Balance XOR, Broadcast, IEEE 802.3ad/Link
Aggregation, Balance-tlb, and Balance-alb) *

• Load Balancing, Failover, Multi-IP Settings *

• DHCP Client, DHCP Server

• UPnP & Bonjour Discovery

Security

• IP Filter

• Network Access Protection with IP Auto-blocking

• HTTPS Connection

• FTP with SSL/TLS (Explicit)

• Encrypted Remote Replication (Rsync over SSH)

• Importable SSL Certificate

• E-mail and SMS Alerts

Disk Management

• Single Disk, JBOD, RAID 0/1/5/6/5+Hot Spare ***

• Online RAID Capacity Expansion **

• Online RAID Level Migration **

• HDD S.M.A.R.T.

• Bad Block Scan

• RAID Recovery **

• Bitmap **

• ISO Mounting: Max 256 (via Web File Manager)

iSCSI

• iSCSI Target

- Multi-LUNs per Target

- Up to 256 LUNs

- LUN Mapping & LUN Masking

- SPC-3 Persistent Reservation

- MPIO & MC/S

• Virtual Disk Drive (via iSCSI Initiator)

- Stack Chaining Master

- Virtual Disk Drives: Max 8

Power Management

• Wake on LAN

• Scheduled Power on/off (Max 15 Settings)

• Automatic Power on after Power Recovery

• Network UPS with SNMP Management

• HDD Standby Mode

Access Right Management

• User Accounts: Max 4,096 *

• Groups: Max 512 *

• Shares: Max 512 *

• Batch User Creation

• Import User List

• User Quota Management

• Supports Active Directory Authentication

- Domain Users Login via CIFS/SMB, AFP,
FTP, and Web File Manager

- NTLMv2 Authentication

• Smart Fan Control

• Dynamic DNS (DDNS)

• SNMP Traps (v2 & v3)

• UPS Support with SNMP & USB

• Resource Monitor

• Network Recycle Bin for File Deletion via CIFS/SMB
and AFP

• Comprehensive Logs (Event & Connection)

• Real-time Online User List

• Syslog Client

• Firmware Live Update

• System Settings Backup and Restore

• Restore to Factory Default

Multilingual Support

English, Finnish, French, German, Italian, Japanese,

• Chinese (Traditional & Simplified), Czech, Danish Dutch,

Korean, Norwegian, Polish, Russian, Spanish, Swedish

Browser Support

• Internet Explorer 7 & 8 or Later

• Firefox 3 or Later

• Safari 3 & 4 or Later

• Google Chrome

File Server

• Protocols: CIFS/SMB (Plus DFS Support), AFP, NFS,
FTP/FTPS, HTTP/HTTPS (Web File Manager), WebDAV

• Platforms: Windows, Mac OS, Linux/UNIX

• Web File Manager:

- File Management by Web Browser

- Smart File & Folder Search

FTP Server

• FTP over SSL/TLS (Explicit)

• Concurrent Connections: Max 256

• Passive FTP Port Range Control

• FTP Bandwidth & Connection Control

• Supports FXP & Unicode

Backup Server

• Apple Time Machine Support with Backup Management

• QNAP NetBak Replicator Backup Software

(Windows Client)

• Backup to Cloud Storage (Amazon S3)

• Backup to External Storage Devices

• USB One Touch Backup (Import/Export)

• Block-level Remote Replication:

- Work as Both Rsync Server & Client

- Encrypted Replication to/from QNAP NAS Servers

• Third Party Backup Software Support: Acronis
True Image, CA BrightStor, ARCserve Backup, EMC
Retrospect, Symantec Backup Exec, LaCie
SilverKeeper

Web Server

• HTTP/HTTPS Connections

• Built-in MySQL Server

• Web-based Management via phpMyAdmin (QPKG)

• Virtual Hosts: Max 32

Media Server

Multimedia Station

•

Photo Viewing, Audio & Video Playback

•

Image Slideshow and Rotation

•

Automatic & Scheduled Thumbnail Generation for
Easy Browsing

• Display Photo Details from EXIF: Date, Exposure Time,
Aperture, etc.

• Display Audio Details from ID3 Tag: Album Cover, Title,
Artist, Album, etc.

• Access Authority Management

• Multimedia (Video & Audio) Streaming

• Cooliris 3D Wall Display

• Web Publishing (Facebook, MySpace, MSN Live,
Twitter, Plurk, and Blogger)

• E-mail Publishing

• Supported Formats:

-

Photo: JPG/JPEG, GIF, PNG

-

Audio: MP3

• Video:

- Playback: FLV, MPEG-4 Video (H.264 + AAC)

- Transcode: AVI, M4V, MPG/MPEG, RM/RMVB, WMV

iTunes Server

• Audio and Video Sharing

• Smart Playlist for iTunes Client (Windows & Mac)

Mobile App

• QMobile for iPhone

- Compatible with iPhone, iPod Touch, and iPad

- iPhone OS 3.0 or Later Required

• QMobile for Android

- Compatible with Android OS 1.5, 1.6, and 2.1

UPnP Media Server

• Real-time & Background Photo Transcoding

• Media Player

- Game Consoles: PlayStation 3, PSP, and Xbox 360
Digital Media Adapter/Player

- Mobile Devices (e.g. iPhone, iPod Touch)

• Supported Formats:

- Photo: JPG, JPE, JPEG, TIFF, TIF, GIF, PNG, BMP

Download Station

• PC-less BitTorrent/FTP/HTTP Download (Max 500 Tasks)

• BitTorrent Download

- TCP/UDP Tracker Protocol

- Scheduled Download

- Configurable Port Range

- Configurable File Saving Directory

- Bandwidth Control

- UPnP NAT Port Forwarding

• HTTP/FTP Download

- Bulk Download with Wildcard Settings

- RapidShare Download

• QNAP Download Management Software: QGet

- For Windows & Mac OS

- Remote Download Tasks Management of Multiple

NAS over LAN or WAN

Printer Server

• Network Printer Sharing (USB)

• Printers: Max 3

Surveillance Station

• Supports IP Cameras: Max 4 * (Optional Purchase)

• Network Surveillance: Remote Monitoring, Video
Recording, and Playback

QPKG

• Web Applications

- Joomla!

- phpMyAdmin

- WordPress

- AjaXplorer

- VtigerCRM

- eyeOS

- Magento

- GPLI

• P2P Applications

- MLDonkey (eMule)

- SABnzbd+

- NzBGet

• Media Server

- Squeezebox Server

- IceStation

• Server application

- Asterisk

- XDove(Mail Server)

- Open LDAP

• Misc.

- Optware IPKG

- Python

- iStat

• …and more

* For TS-419P+
** For TS-219P+ / TS-419P+
*** The RAID configurations available vary according to the product models and the number of hard disk drives installed.

Software Specif ications

Administration

• AJAX-based User Interface

• HTTP/HTTPS Connections

• Email & SMS Alerts

Audio: MP3, MP4, M4A, M4B, 3GP, APL, AC3,
M1V, M4V, MOV, AAC, AMR, AWB, WAV,
PCM, LPCM, MP1, MP2, AIF, AIFF, AIFC,
SND, WMA, OGG, FLAC
Video: WMV, ASF, VDR, AVI, XVID, DIVX, FLV,
MPG, MPE, MTS, MT2S, M2T, MPEG,
SPTS, M2P, M2V, MP2T, MP2P, MPG2,
DVR-MS, VOB

512MB

DDRIII Memory

512MB

DDRIII Memory

++

QNAP

®

is a registered trademark of QNAP Systems, Inc. All other brands and product names referred to are trademarks of their respective holders.

Designs and specifications are subject to change without notice.

For more detailed information, please visit QNAP website: http://www.qnap.com/

©

Copyright 2010. QNAP Systems, Inc. All Rights Reserved.

2010/11(A)P/N: 51000-022941-RS

TS-119P+

TS-219P+

TS-419P+

CPU

Memory

Flash

Internal 2.5’’/3.5’’ HDD

Max. Internal Capacity
(Using 2TB Hard Drives)

Gigabit LAN

eSATA

Power Consumption *
(Sleep / Operation)

Dimensions

Weight

Power Supply

Smart FAN

Disk Management

Access Right Management

IP Cameras Support

LCD Panel

* Actual power consumption may be different depending on your operation environment.

Environmental
Compliance

USB 2.0

Marvell® 1.6 GHz

512 MB DDR III

16 MB

1

2 TB

1

1

5W / 12W

AC Input Power Voltage: 100V-240V. Power Frequency: 50Hz-60Hz

External Power Adapter, 36W

1 (5cm, 12V DC)

Single Disk, Q-RAID1

●

Max. No. of User Accounts: 2048

●

Max. No. of User Groups: 256

●

Max. No. of Share Folders: 256

●

Max. No. of Concurrent Connections: 256

2

No

●

Temperature: 0

°

C-40°C

●

Relative Humidity: 0%-95%

●

Certificate: CE, FCC, VCCI, BSMI, RoHS

3 (Front: 1, Back: 2)

●

150.2(H) x 67(W) x 216(D) mm

5.91(H) x 2.64(W) x 8.54(D) inch

●

●

Net Weight: 1.06kg/ 2.34 lb
Gross Weight: 1.86kg/ 4.10 lb

Marvell® 1.6 GHz

512 MB DDR III

16 MB

2

4 TB

1

2

7W / 19W

External Power Adapter, 60W

1 (7cm, 12V DC)

Single Disk, JBOD, RAID 0/1

2

No

3 (Front: 1, Back: 2)

●

150.2(H) x 102(W) x 216(D) mm

5.91(H) x 4.02(W) x 8.5(D) inch

●

●

Net Weight: 1.74kg/ 3.84 lb
Gross Weight: 2.92kg/ 6.44 lb

Marvell® 1.6 GHz

512 MB DDR III

16 MB

4

8 TB

2

2

13W / 31W

External Power Adapter, 120W

1 (9cm, 12V DC)

Single Disk, JBOD, RAID 0/1/5/6/5+Hot Spare

●

Max. No. of User Accounts: 4096

●

Max. No. of User Groups: 512

●

Max. No. of Share Folders: 512

●

Max. No. of Concurrent Connections: 256

4

Yes

4 (Front: 1, Back: 3)

●

● ● ●

177(H) x 180(W) x 235(D) mm

6.97(H) x 7.09(W) x 9.25(D) inch

●

●

Net Weight: 3kg/ 6.61 lb
Gross Weight: 4.6kg/ 10.14 lb

Comparison List

USB 2.0

Power Button

Power Connector

Password & Network
Settings Reset Button

Gigabit LAN x 2

USB 2.0 x 3

eSATA x 2

K-Lock Security Slot

One Touch Copy Button

LED Indicators:
HDD1-4

LED Indicators: Status,
LAN, USB, eSATA

Enter Button

Select Button

QNAP Taiwan (Headquarters)

21 F, No. 77, Sec. 1, Xintai 5th Rd, Xizhi City, Taipei County, 221, Taiwan
TEL: [phone] FAX: [phone]

QNAP US Office

166 University Parkway, Pomona, CA 91768
TEL: [phone] FAX: [phone]

Front & Rear (Example: TS-419P+)

QNAP Awards and Recognitions:

512MB

DDRIII Memory

512MB

DDRIII Memory
