Introduction

IMPORTANTIMPORTANT

Congratulations on your purchase of a U-Line refrigerator.

For nearly five decades and three generations, U-Line continues to be the leader in innovation, quality and value in the premium built-in undercounter ice making, refrigeration and wine preservation market. U-Line has captivated those with an appreciation for the finer things with exceptional functionality, style, inspired innovation and attention to even the smallest details. We are known and respected for our unwavering dedication to product design, quality and selection.

In 1962, Henry Uihlein founded U-Line Corporation as an outgrowth of Ben-Hur Freezer Company and was the first to develop and patent an automatic stand-alone undercounter residential ice maker. His foresight and determination to develop new ideas and to succeed when there were no clear guidelines or solutions are evident today. The newest Uihlein generation continues to build upon the family’s innovative legacy at the Milwaukee, Wisconsin based business by providing continuity and vision from which new designs and technology continue to be born.

Today the complete U-Line product collection includes Ice Makers, Wine Captain® Models, Combo® Models, a Refrigerator / Freezer, Refrigerators, Drawers and Beverage Centers. The U-Line brand offers products in the 1000 Series, 2000 Series and the Modular 3000 Series. The 1000 Series offers a more targeted priced product with appropriate features, while the 2000 Series offers upscale features, advanced technology and specialized product families. U-Line’s approach to its breadth of products, multiple price points and features allows a choice and product that will fit any lifestyle.

Please Record Your Model Information

You will need your product model and serial number when you request additional information or services. You can find this information on the serial plate located on the upper right or back wall in the interior of your product. This information also appears on the warranty registration card. Please complete and mail your warranty registration card. You may also register online at www.u-line.com

Please record the model number (1), serial number (2), date of purchase, and dealer contact information for your U-Line product below:

Model Number:

________________________________________________

Serial Number:

________________________________________________

Purchase Date:

Read and save this Use and Care Guide.

READ all instructions in this guide completely before using the appliance for the first time.

For future reference, keep this guide in a safe, accessible location. If you need additional information or assistance, please contact ULine Corporation direct. Contact information appears on the back cover of this guide.

Before Calling Service. If you think your U-Line product is malfunctioning, read the OPERATION section of this guide to understand clearly the function of the control. If the problem persists, read the TROUBLESHOOTING GUIDE section of this guide to help you quickly identify common problems, and provide information on possible causes and remedies.

________________________________________________

Dealer Name:

________________________________________________

Dealer Address:

________________________________________________

Dealer Telephone:

________________________________________________

Introduction to U-Line

1 Table of Contents

U-LineCombo® Models and Ice Makers

i - Introduction .................................................................................................................................................................i

Read and save this Use and Care Guide. .........................................................................................................i

Please Record Your Model Information ...........................................................................................................i

1 - Table of Contents .....................................................................................................................................................1

3 - Safety Precautions .....................................................................................................................................................3

Safety Alert Definitions ........................................................................................................................................3

General Precautions .............................................................................................................................................3

4 - Product Features .......................................................................................................................................................4

Ice Makers Feature: ..............................................................................................................................................4

ADA15IM Model Features: .................................................................................................................................4

Combo® Models Feature: ..................................................................................................................................4

CO1175 and BI2115 Model Feature: ...............................................................................................................4

BI2115 Model Features: .......................................................................................................................................4

5 - Product Operation ...................................................................................................................................................5

Air Flow ...................................................................................................................................................................5

Initial Startup ..........................................................................................................................................................5

Control Dial ...........................................................................................................................................................5

Adjusting AirTemperature ..................................................................................................................................6

Adjusting Ice Harvest ...........................................................................................................................................6

Checking Product Temperature ........................................................................................................................6

6 - Ice Maker ....................................................................................................................................................................7

Ice Maker Adjustment ..........................................................................................................................................7

Ice Maker Operation ............................................................................................................................................7

7 - Maintenance ...............................................................................................................................................................8

Leveling ....................................................................................................................................................................8

Removing and Installing Interior Shelves .........................................................................................................8

Removing and Installing Door Shelves .............................................................................................................9

Removing and Installing Grille ............................................................................................................................9

8 - Standard Doors ...................................................................................................................................................... 10

Door Alignment and Adjustment ................................................................................................................... 10

Door Reversability ............................................................................................................................................. 10

Reversing the door ............................................................................................................................................ 10

9 - Self-Closing Doors ................................................................................................................................................ 12

Door Alignment and Adjustment ................................................................................................................... 12

Door Reversability ............................................................................................................................................. 12

Reversing the door ............................................................................................................................................ 12

10 - Cleaning ................................................................................................................................................................. 14

Exterior Cleaning ............................................................................................................................................... 14

Interior Cleaning ................................................................................................................................................ 14

Defrosting ............................................................................................................................................................ 14

Condensor Cleaning .......................................................................................................................................... 15

Storage, Vacation and Moving ......................................................................................................................... 15

Product Disposal ................................................................................................................................................ 15

11 - Service .................................................................................................................................................................... 16

Normal Operating Sounds ............................................................................................................................... 16

Troubleshooting Guide ..................................................................................................................................... 16

Before Calling for Service ................................................................................................................................ 16

If Service is Required ......................................................................................................................................... 16

Replacement Parts ............................................................................................................................................. 16

12 - U-Line Corporation Limited Warranty .......................................................................................................... 17

U-Line Use and Care Table of Contents 1

IMPORTANTIMPORTANT

DANGER

WARNING

CAUTION

1 Safety Precautions

DANGER

WARNING

CAUTION

IMPORTANTIMPORTANT

• PLEASE READ all instructions before installing, operating, or servicing the appliance.

General Precautions

Use this appliance for its intended purpose only. Follow these general precautions with those listed throughout this guide:

• Proper installation procedures must be followed when completing an installation or relocation of a unit. Consult the installation guide before any installation begins. U-Line contact information appears on the rear cover of this guide.

• This unit requires connection to a dedicated 15 Amp grounded (three-prong), polarized receptacle, installed by a qualified electrician, compliant with applicable electrical codes.

Safety Alert Definitions

Throughout this guide are safety items labeled with a Danger, Warning or Caution based on the risk type:

Danger means that failure to follow this safety statement will result in severe personal injury or death.

Warning means that failure to follow this safety statement could result in serious personal injury, property or equipment damage.

RISK OF CHILD ENTRAPMENT. Before you throw away your old refrigerator or freezer, take off the doors and leave shelves in place so children may not easily climb inside.

SHOCK HAZARD - Electrical Grounding Required.

• Never attempt to repair or perform maintenance on the unit until the electricity has been disconnected.

• Never remove the round grounding prong from the plug and never use a two-prong grounding adaptor.

• Altering, cutting of power cord, removal of power cord, removal of power plug, or direct wiring can cause serious injury, fire and or loss of property and or life, and will void the warranty.

• Never use an extension cord to connect power to the unit.

• Always keep your working area dry.

Install provided Anti-Tip kit. Serious personal injury could occur.

• Use care when moving and handling the unit. Use gloves to prevent personal injury from sharp edges.

• If your model requires defrosting, DO NOT use an ice pick or other sharp instrument to help speed up defrosting. These instruments can puncture the inner lining or damage the cooling unit. DO NOT use any type of heater to defrost. Using a heater to speed up defrosting can cause personal injury and damage to the inner lining.

Caution means that failure to follow this safety statement may result in minor or moderate personal injury, property or equipment damage.

1 Precautions

• Do not lift unit by door handle.

• Never install or operate the unit behind closed doors.

• Failure to clean the condenser every six months can

• Allow unit temperature to stabilize for 24 hours before

• Do not Block any internal Fans

Use only genuine U-Line replacement parts. Imitation parts can damage the unit, affect its operation or performance and may void the warranty.

Be sure front grille is free of obstruction. Obstructing free airflow can cause the unit to malfunction and will void the warranty.

cause the unit to malfunction. This could void the warranty.

use.

4 Product Features

Ice Makers Feature:

High ice production and storage. ADA15IM, BI2115 and BI98

models produce up to 25 pounds of ice per day and store 25 pounds. BI95 and SP18 models produce up to 23 pounds of ice per day and store 12 pounds. Combo pounds of ice per day and store 13 pounds and provide both ice production and refrigeration in one. CO1175 has 4.2 cubic feet and CO29 has 2.1 cubic feet refrigeration storage.

No drain required. Easy and inexpensive to install. Only requires a 1/4" outside diameter water line.

Conserves on water. Uses under 3 gallons of water to produce 22 pounds of ice or 2-1/4 gallons for 18 pounds.

Built-in or freestanding. Provides custom look when built-in with no additional venting clearance needed on sides, top or rear. Do not obstruct the grille.

Vinyl-clad cabinet. Textured, rich appearance. More resistant to scratching, peeling and flaking.

Door will accept a 1/4" panel. Ability to match surrounding décor and cabinets. Black and white models only.

Integrated handle. Does not add depth to the cabinet when built in. Black and white models only.

Field-reversible doors. Flexible installation options. All models with black and white doors are field-reversible. Stainless steel models must be order right- or left-hand hinged.

® Models produce up to 18

ADA15IM Model Features:

Factory installed door locks. Provides security and safety.

Stainless steel models. Offers a bold stainless steel habdle,

stainless steel wrap door. Stainless steel models must be ordered right or left-hand hinged

Combo® Models Feature:

Mechanical Temperature Control. Provides ability to set the

temperature.

Adjustable tempered glass shelves. Sleek, streamlined interior. Allows flexible shelf locations to meet varying food and beverage storage needs. Three in 75, Two in 29.

In-door storage shelves. Two adjustable on 75 model and 3 on 29 model. Easiest access storage area right where you need it. Adjustable to allow flexible storage options

CO1175 and BI2115 Model Feature:

Adjustable leveling legs. Achieve a more precise under counter

fit. Durable, strong legs will not bend when unit is installed.

Stainless steel model. Offers a bold stainless steel handle, stainless steel wrap door. BI2115 has full wrap. CO1175 has black "cap" on top and bottom of the door. Stainless steel models must be order right- or left-hand hinged.

Flat recessed grille. Blends with the other models and integrates with surrounding cabinetry.

Defrost Type: Manual Defrost

For indoor use only.

BI2115 Model Features:

Optional 3/4" full overlay door panel kit. Provides a fully

integrated appearance with surrounding décor while maintaining zero door clearance. Easy to install. Black and white models only. Must order kit number U-OL2115.

Self-closing door. Engages when the door is open 8-10". Ensures a positive door seal and prevents door bounceback.

Contemporary grille design. Integrates seamlessly with surrounding cabinetry.

4 U-Line Combo Model and Ice MakerProduct Features

OFF

1 Product Operation

IMPORTANTIMPORTANT

Air Flow

The unit requires proper air flow to perform at its highest efficiency. Do not block the front grille or internal fans at any time, or the unit will not perform as expected. Do not install the unit behind a door.

Initial Startup

All U-Line controls are preset at the factory. Initial startup requires no adjustments.

U-Line recommends allowing the unit to run overnight before loading refrigerator or freezer with product.

On ice maker equipped units, it is possible that dirt or scale will dislodge in the water line. Always throw away all ice cubes made during the first two to three hours of operation.

To turn the unit on or off:

Press the rocker switch located below the temperature control dial in the center of the grille(2), inside the door on the front panel, or behind the grille.

Control Dial

Combo Models provide two temperature zones within the cabinet to satisfy the specific storage requirements.

The control dial sets a single continuous temperature. This setpoint temperature is a base setting used by the controller to maintain the temperature zone in the unit. The factory default MID setting, number 3 or 4 set-point for Beverage Center and Refrigerator models is 38°F. The factory default set-point Wine

U-Line Product Operation 5

Adjusting AirTemperature

IMPORTANTIMPORTANT

Combo Models

• Adjust the set point temperature in single increments, and wait 24 hours for the temperature to stabilize before rechecking.

• Factory recommended set-point is MID setting on dial control.

To adjust the set point temperature:

Adjust the temperature by turning the numbered dial (1) in small increments.

Adjusting Ice Harvest

Checking Product Temperature

To check the actual product temperature in the unit.

1. Partially fill a plastic (nonbreakable) bottle with water.

2. Insert an accurate thermometer.

3. Tighten the bottle cap securely.

4. Place the bottle in the desired area for 24 hours.

BI Models

1. Remove the front grille (see MAINTENANCE).

2. Turn the adjusting screw (3) using a flat tip screwdriver in a

small increment clockwise for a COLDER setting (slower ice production) or counterclockwise for a WARMER setting (faster ice production).

3. Replace the front grille (two screws).

5. Avoid opening the unit during the testing period.

6. After 24 hours, check the temperature of the water. If required, adjust the temperature control in a small increment (See ADJUSTING TEMPERATURE).

Causes which affect the internal temperatures of the cabinet include:

• Temperature setting.

• Ambient temperature where installed.

• Installation in direct sunlight or near a heat source.

• The number of door openings and the time the door is open.

• The time the internal light is illuminated. (This mainly affects

product on the top rack or shelf.)

• The front grille or condenser are obstructed.

6 U-Line Product Operation
