Page 1
H-2594
H-2595
PORTABLE BLOWER
SERVICE INFORMATION
NOTE: Save these instructions.
These instructions serve as a guide to routine
maintenance. If additional service is required, contact
Uline repairs.
IMPORTANT SAFEGUARDS
When using an electrical appliance, basic precautions
should always be followed, including the following:
WARNING! Read all instructions before using
this portable blower.
To reduce the risk of fire, electric shock, or injury:
• Do not use machine while placed in standing water.
• Use machine only as described in this manual. Do
not use in ways it was not intended.
• Turn off all switches and unplug the electrical cord
when not in use and before servicing.
• Do not allow to be used by untrained personnel.
Close attention is necessary when used near
children.
• If the machine is not working as it should, has been
dropped, damaged, or left outdoors, call Uline
repairs before using.
• Avoid electrical shock; do not handle the plug or
machine with wet hands. To unplug the cord, grasp
the plug. Do not pull on the cord.
• Do not use extension cords or outlets with inadequate
current carrying capacity. Do not use with a
damaged cord or plug. Connect the machine only
to a properly grounded outlet (refer to GROUNDING
INSTRUCTIONS). Avoid damaging cord (closing doors
on cord, pulling around sharp edges or corners, hot
surfaces, or running machine over cord).
• This machine creates suction and contains a
revolving fan. Keep hair, loose clothing, fingers, and
all other parts of the body away from openings and
moving parts. Do not insert any object into any of
the openings in the machine.
• Do not use in areas where flammable and/or
explosive vapor or dust is present to avoid the
possibility of fire or explosion. Some cleaning fluids
can produce such vapors.
• Do not allow air inlet openings on either side of the
machine to be obstructed; this could cause the
motor to overheat.
• Do not allow debris near front air exhaust opening
which could be thrown by the air stream.
• This unit is thermally protected.
• Use only on GFCI protected receptacles.
• Use indoors only. Do not use outdoors or expose
to rain.
• Do not use an extension cord with this blower.
0311 IH-2594PAGE 1 OF 3
Page 2
GROUNDING INSTRUCTIONS
Grounded Outlet Box
Grounded Outlet Box
This appliance must be grounded. If it should malfunction
or breakdown, grounding provides a path of least
resistance for electric current to reduce the risk of electric
shock. This appliance is equipped with a cord having an
equipment-grounding conductor and grounding plug.
The plug must be plugged into an appropriate outlet that
is properly installed and grounded in accordance with
all local codes and ordinances.
DANGER
Improper connection of an equipment-grounding
conductor can result in risk of electric shock. Check
with a qualified electrician or service person if you are
in doubt as to whether the outlet is properly grounded.
Do not modify the plug provided with the appliance. If
it will not fit the outlet, have proper outlet installed by a
qualified technician.
This appliance is for use on a nominal 120 volt circuit
and has a grounding plug that looks like the plug
illustrated in Figure A. A temporary adapter which looks
like the adapter illustrated in Figure B may be used to
connect this plug to a two-pole receptacle, as shown,
if a properly grounded outlet is not available. The
temporary adapter should be used only until a properly
grounded outlet, Figure A, can be installed by a
qualified electrician. The green colored rigid ear, lug, or
the like extending from the adapter must be connected
to a permanent ground such as a properly grounded
outlet box cover. Whenever the adapter is used, it must
be held in place by a metal screw.
NOTE: In Canada, the use of a temporary
adapter is not permitted by the Canadian
Electrical Code.
Figure A
Grounding blade
is longest of the
three blades
Figure B
Adapter
Metal Screw
Grounding Tab
OPERATING INSTRUCTIONS
WARNING! To reduce the risk of fire, electric
shock or injury; only use dryer as described in
this manual.
1. Plug in to a standard outlet with the correct voltage
and amperage for the unit.
2. Place the dryer in the desired operating position.
3. Set the switch at the desired speed: low, medium or
high. (See Figure 1)
Figure 1
OFF
LOW
HIGH
MED
4. Check for proper operation before leaving the unit
unattended. Do not move or carry the dryer when it
is running.
5. Unwrap cord before using. (See Figure 2)
Figure 2
0311 IH-2594PAGE 2 OF 3
Page 3
OPERATING INSTRUCTIONS CONTINUED
Telescoping handle and wheels available on H-2595
model. (See Figure 3)
To use handle, push in release button, pull handle up until
it locks into place. Tilt the unit back onto the wheels and
roll to desired location.
Figure 3
WARNING! Do not stack dryers more than two
units high without tie-downs
OFF
OFF
LOW
LOW
HIGH
HIGH
MED
MED
OFF
OFF
LOW
LOW
HIGH
HIGH
MED
MED
MAINTENANCE/TROUBLESHOOTING
WARNING! To reduce the risk of fire, electric
shock or injury; DO NOT attempt to service the
unit while appliance is plugged in.
PERIODIC MAINTENANCE
1. Check power cord for any breaks, separations
or cuts.
2. Make sure the ground pin or grounding prong is
intact or the machine will be unsafe to operate.
TROUBLESHOOTING (IF THE DRYER WILL NOT RUN)
1. Check electrical cord; is it firmly seated in wall outlet.
2. Check GFCI and reset if tripped.
3. Check to see if building circuit breaker is tripped.
If circuit is overloaded, move cord to different GFCI
outlet.
4. If using an extension cord, make sure it is in good
condition, proper gauge and firmly connected.
5. Motor overheated and tripped thermal protection;
turn off and unplug. Wait 30 minutes to let cool
before running.
0311 IH-2594PAGE 3 OF 3
