U-Line Echelon 2115WC, Echelon 2115WCOL, 2115WC Wine Captain, 2115WCOL Wine Captain Installation Manual
Installation Guide
2115WC Wine Captain
and 2115WCOL Wine Captain
®
®
with Overlay
www.U-LineService.com
Phone (414) 354-0300 • FAX (414) 354-7905
Service & Parts Tech Lines Phone (800) 779-2547 • FAX (414) 354-5696
OnlineService@U-Line.com
©2006 U-Line Corporation
06/2006
2115WC/2115WCOL Wine Captain
®
Contents
Exterior Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Cut-Out Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Product Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Door Swing/Clearances Information . . . . . . . . . . . . . . 5
Reversing the Door. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Other Site Requirements . . . . . . . . . . . . . . . . . . . . . . . . 6
Side-By-Side Installation Instructions . . . . . . . . . . . . . . 7
Wine Rack Removal/Installation . . . . . . . . . . . . . . . . . . 7
Wood Trim Finishing . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Overlay Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Checking Door Alignment . . . . . . . . . . . . . . . . . . . . . . 12
Adjusting Door Alignment . . . . . . . . . . . . . . . . . . . . . . 12
Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 13
Leveling Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Installation Tip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Anti-Tip Bracket Installation . . . . . . . . . . . . . . . . . . . . . 14
Installation Troubleshooting . . . . . . . . . . . . . . . . . . . . . 15
Initial Start-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Start-Up Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . 15
Service Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1 Follow Safety Precautions
IMPORTANT
PLEASE READ all instructions completely before
attempting to install or operate the unit.
• This unit requires connection to a grounded (threeprong), polarized receptacle that has been placed by a
qualified electrician in accordance with applicable
electrical codes.
Safety Alert Definitions
Safety items throughout this guide are labeled with a
Danger, Warning or Caution based on the risk type:
DANGER
Danger means that failure to follow this safety
statement will result in severe personal injury or
death.
WARNING
Warning means that failure to follow this safety
statement could result in serious personal injury,
or death.
CAUTION
Caution means that failure to follow this safety statement
may result in minor or moderate personal injury, property
or equipment damage.
www.U-LineService.com 2 06/2006
2115WC/2115WCOL Wine Captain
®
General Precautions
Use this appliance for its intended purpose only and
follow these general precautions along with those listed
throughout this guide:
WARNING
SHOCK HAZARD — Electrical Grounding Required.
• Keep the unit unplugged throughout installation
except during testing.
• Never remove the round grounding prong from
the plug and never use a two-prong grounding
adapter.
• Never use an extension cord to connect power to
the unit.
• Always keep your working area dry.
CAUTION
• Use care when moving and handling the unit. Use
gloves to prevent personal injury from sharp edges.
• Do not lift the unit by the door or door handle.
• Do not install the unit behind closed doors or in any
way that would obstruct airflow to the front grille,
which may cause the unit to malfunction.
2 Inspect and Plan
You have received a carton containing your 2115WC or
2115WCOL Wine Captain® with a package inside
containing a Use and Care Guide, a Product Registration
Card and an Anti-Tip Bracket Installation Kit. 2115WCOL
units are shipped with a cardboard-wrapped door and an
additional package of hardware. Complete and mail
the Product Registration Card or register online at
www.U-LineService.com. Once your unit is installed, keep
the Use and Care Guide and this Installation Guide in a
safe place for future reference.
2115WC units are Black, White or Stainless Steel. Black
and White units have a reversible door with a slightly
contoured handle across the top. Stainless Steel units are
covered with a protective coating and have been ordered
left- or right-hand hinged. The Stainless doors are not
reversible.
2115WCOL units are Black with an unattached door that
requires the construction of a 3/4-inch thick wood overlay
frame. You must determine left- or right-hand opening
before construction.
All units come with maple trim wine racks that can be
finished or stained. Please carefully follow the directions
that apply to your unit and your intended design.
Tools/Materials Required
• Screwdrivers — slotted and Phillips head
• Sandpaper; low odor, water clean up, quick drying
finish; tack cloth and, if desired, water-based wood
stain and synthetic foam brush
• 3/4-inch overlay frame material, cutting tools, drill and
bits (2115WCOL units)
Inspection
Unwrap and inspect the unit on a flat, level surface
capable of supporting its entire weight.
Removing Protective Coating
(Stainless Steel Units Only)
When inspecting/installing a Stainless Steel unit, the
protective coating covering the unit must be removed
first. Start at a corner of the unit/door and pull back the
protective coating to remove it from the unit/door.
06/2006 3 www.U-LineService.com
2115WC/2115WCOL Wine Captain
®
After all the protective coating has been removed from
the unit/door, clean all Stainless Steel surfaces with Claire
Stainless Steel Polish and Cleaner or comparable product
or a mild detergent and warm water solution and soft
cloth. Do NOT use abrasive cleaning agents.
Note: If cleaning with mild detergent and warm water
solution and soft cloth, the unit MUST be treated with
Claire Stainless Steel Polish and Cleaner or comparable
product to prevent discoloration.
Exterior Cleaning
(As Required)
Black Models:
• The door, grille and cabinet may be cleaned with a mild
detergent and warm water solution. Do not use
solvent-based or abrasive cleaners. Use a soft sponge
and rinse with clean water. Wipe with a soft, clean
towel to prevent water spotting.
Stainless Steel Models:
• Stainless steel models can discolor when exposed to
chlorine gas, pool chemicals, salt water or cleaners with
bleach.
• Keep your stainless steel unit looking new by cleaning
with a good quality all-in-one stainless steel cleaner/
polish on a monthly basis. For best results use Claire
Stainless Steel Polish and Cleaner, which can be
purchased from U-Line Corporation. (The part number
is 173348.) Comparable products are acceptable.
Frequent cleaning will remove surface contamination
that could lead to rust. Some installations may require
cleaning on a weekly basis.
• Do not clean with steel wool pads.
• Do not use cleaners that are not specifically
intended for stainless steel (this includes glass,
tile and counter cleaners).
• If any surface discolors or rusting appears, clean it
quickly with Bon-Ami or Barkeepers Friend Cleanser
and a non-abrasive cloth. Always clean in the direction
of the grain. Always finish this process with Claire
Stainless Steel Polish and Cleaner or comparable
product to prevent further problems.
• Use of abrasive pads such as Scotchbrite will
cause the graining in the stainless to become
blurred.
• Rust that is allowed to linger can penetrate into the
surface of the stainless steel and complete removal of
the rust may not be possible.
3 Prepare Site
Your U-Line product has been designed for either freestanding or built-in installation. When built-in, your unit
does not require additional air space for top, sides or rear.
However, the front grille must NOT be obstructed and
clearance is required for electrical connection in the rear.
Note: Unit can NOT be installed behind a closed cabinet
door.
Cut-Out Dimensions
34-1/4"
to
35-1/8"
7"
1"
15-3/16"
Figure 1
Follow the cut-out drawing in Figure 1. The 15-3/16"
width allows 1/4" for ease in installation and removal of
the unit. 24" is the cabinet depth in most installations.
The unit is 23-1/4" deep including the handle on Black
and White 2115WC models, 23-1/4" deep including the
wood overlay frame on 2115WCOL models and 23-1/4"
deep including the door and not the handle on Stainless
Steel models (see Figure 2).
23-1/4"
www.U-LineService.com 4 06/2006
2115WC/2115WCOL Wine Captain
®
Product Dimensions
23-1/4"
Including
Handle
34-1/8"
14-15/16"
Black Stainless Steel
23-1/4"
Including
Wood
Overlay
25-3/8"
Including
Handle
14-15/16"
34-1/8"
34-1/8"
Door Swing/Clearances Information
Black and Wood Overlay units have a zero clearance for
the door to open 90° (see Figure 3). Stainless Steel
models require a minimum of 2-1/8" door clearance to
accommodate the handle if the unit is installed next to a
wall or similar type of structure.
Wall Wall
1/4" Min.
90°
Door Swing
Black, White and Wood Overlay
Figure 3
21"
16-1/2"
2-1/8" Min.
90°
Door Swing
21"
16-1/2"
Stainless Steel
14-15/16"
Wood Overlay
Figure 2
Please note that the unit has adjustable feet that can add
one additional inch to height during leveling or to match
adjacent cabinets (see Figure 29 on Page 13).
Reversing the Door
(Black Units Only)
All U-Line units
(except Stainless
Steel models) may be
left- or right-hand
opening. The door
opening is easily
reversed by moving
the hinge hardware
to the opposite side.
The top hinge
hardware will be
used on the bottom
of the other side and
the bottom hinge
hardware will be
used on the top of
the other side (see
Figure 4).
To reverse the door:
1. Remove top
Figure 4
hinge screw pin
from door (Phillips screwdriver) (see Figure 5).
Remove door by tilting forward and lifting off bottom
hinge pin.
ULIN_0015_A
06/2006 5 www.U-LineService.com
2115WC/2115WCOL Wine Captain
2.
Remove plastic screw plugs (3 each, top and bottom)
from new hinge location. Do not discard (see
Figure 6
Screw Plugs
®
7. With bottom of door facing up, remove pivot plate
).
(2 screws), flip over, and remount on opposite side of
door (see
Figure 9
). Be sure angled side of plate faces
center.
Figure 6
Figure 5
ULIN_0133_A
3. Remove top hinge (3 screws), reinstall hinge screw pin,
and remount on opposite side BOTTOM (see
Figure 7
4. Remove the two door closer inserts from the existing
bottom hinge and install as shown on the new bottom
hinge (see
1
Figure 8
2
).
ULIN_0003_A
Door
Closer
Inserts
Figure 7 Figure 8
5. Remove existing bottom hinge (3 screws) and remount
on opposite side TOP. Remove hinge screw pin.
6. Remove the plastic hole plug from the top of the door
to allow the pivot pin to be inserted in the new
location. Install the plug into the vacated hole on the
opposite side.
Figure 9
ULIN_0274_A
8. Holding door upright with top of door tilted forward,
place hole of door pivot plate on bottom hinge screw
pin (see
Figure 10
).
9. Tilt top of door into
position in top hinge and
).
install top hinge screw pin.
10. Install plastic screw plugs
removed in Step 2 in old
hinge holes (3 each, top
and bottom).
Figure 10
Other Site Requirements
Power Supply
The unit requires a grounded and polarized 115 VAC,
60 Hz, 15A circuit (normal household current). See
Electrical Specifications on Page 13.
Environmental Requirements
Many U-Line models are designed to operate in harsh
outdoor/marine environments. Special considerations
include the following:
• The units are designed to operate between 50°F (10°C)
and 110°F (40°C). High ambient temperatures (110°F
[40°C] or higher) may reduce the unit’s ability to reach
low temperatures.
• For best performance, keep the unit out of direct
sunlight and away from heat generating equipment.
• In climates where high humidity and dew points are
present, condensation may appear on outside surfaces.
This is considered normal. The condensation will
disappear when the humidity drops.
• U-Line does not recommend installation of glass front
models (Wine Captain
Beverage Centers) as well as the Combo Drawer model
(Refrigerator/Freezer/Ice Maker) outdoors, or in tropical
climates where high humidity and dew point are present
on a regular basis, unless air-conditioning (typical 72°F,
75%RH) will be used.
®
wine storage models and
www.U-LineService.com 6 06/2006
2115WC/2115WCOL Wine Captain
®
Side-By-Side Installation
Instructions
For a complete refreshment center, install your 2115WC or
2115WCOL unit beside a U-Line Refrigerator, Ice Maker or
Combo Model (see Figure 11 for typical cut-out). Note
that each Side-By-Side Installation will be different.
• Cut-out width for a side-by-side installation is the total
of the widths listed under Cut-Out Dimensions in each
unit’s Installation Guide.
For example:
®
Placing a 2115 Wine Captain
would require a cut-out width of:
15-3/16" + 15-3/16" = 30-3/8"
Placing a 2115 Wine Captain
would require a cut-out width of:
15-3/16" + 24-3/16" = 39-3/8"
•
No trim kit is required. However, 1/4-inch space needs to
be maintained
between the units to ensure
unobstructed door swing.
• Units must operate from separate, properly grounded
electrical receptacles placed according to each unit’s
Electrical Specifications.
next to a 2115 series unit
®
next to a 2175 series unit
4 Prepare Racks and Door Frame
The U-Line Wine Captain® is equipped with woodtrimmed wine racks that are coated at the factory with a
clear vinyl sealer, which will adequately protect the wood
in normal usage. A final finish coat was not applied so
that the wood trim could be stained to match décor or
overlay frame. The trim on the racks may be coated with a
final finish or stained.
2115WCOL Models are designed for, and require
installation of, an Overlay Frame.
If none of these treatments are to be included in this
installation, go on to 5 Adjust Door.
CAUTION
To prevent permanent damage to the inner liner of the
Wine Captain®, the wine rack wood trim MUST be
removed from the unit for staining and/or finishing.
Allow stain/finish to dry thoroughly (at least 24 hours per
coat) in accordance with the stain/finish manufacturer’s
instructions prior to re-installing the wood trim inside the
cabinet of the Wine Captain
the inner liner of the unit to have a permanent odor,
which is not covered by the warranty.
®
. Failure to do so may cause
Typical Side-By-Side Cut-Out
34-1/4"
to
35-1/8"
1/4" Space
Between Appliances
Figure 11
Wine Rack Removal/Installation
To remove a rack from the cabinet:
1. Grasp the end of the rack, and gently slide it out until
it stops.
2. Remove any bottles stored on the rack.
23-1/4"
7"
1"
Figure 12
3. Press the left rack release lever
(Figure 12)
at the same time, lift the corresponding right rack
release lever up, and pull the rack out until it is free of
the tracks and the cabinet.
ULIN_0207_A
down, and
06/2006 7 www.U-LineService.com
IMPORTANT
Do not remove the track side rails from the cabinet.
2115WC/2115WCOL Wine Captain
®
To insert a rack in the cabinet:
1. Align the left and right rack channels with the tracks
in the cabinet, and ensuring an even track
engagement on both sides, gently push the rack into
the cabinet until it stops.
2. Before reloading the rack, ensure proper operation of
the travel stops in the left and right track rails by
pulling the rack out gently until it completely stops.
Wood Trim Finishing
Interior components of your U-Line unit are equipped
with a natural wood trim for appearance and durability.
Although this wood trim has been coated with a clear
sealer at the factory, it is recommended that the trim be
stained (if desired), and receive a final finish coating prior
to the unit going into full-time service.
WARNING
To prevent permanent damage to the inner liner
of your unit, the wood trim MUST be removed
from the unit for staining and/or finishing. Allow
stain/finish to dry thoroughly (at least 24 hours
per coat) in accordance with the product
manufacturer’s instructions prior to
reinstallation. Failure to do so may cause the
inner liner of the unit to have a permanent odor,
which is not covered by the warranty.
If staining the trim is desired, it must be done before the
application of any type of final finish. Review the
following staining/final finish and final finish-only
guidelines when staining/ and or sealing the wood to
ensure proper adhesion and durability of the finish.
NOTE: Glass in door is tinted. Stain may look darker
when door is closed.
Staining and final finish application:
1. Remove all screws securing wood trim to interior
components, and remove the trim from the cabinet
interior.
NOTE: Your model will contain an electronic display panel
in the lowest level trim piece. After removing the trim
screws, and gently pulling the trim from its location, a
wiring harness connector will become visible. Unplug the
connector, and remove the trim from the interior.
2. Apply Minwax® Water-Based Wood Stain to wood with
a synthetic bristle brush or a foam applicator. Allow
stain to penetrate approximately three minutes. Before
the stain is dry, take a stain dampened rag and remove
any excess stain remaining. Wipe in the direction of the
grain with medium pressure to achieve the desired stain
color.
3. After two hours, repeat step 2. This will even out the
color of the wood.
4. Allow stain to dry for a minimum of three hours before
applying the final finish.
5. If desired, sand the wood with very fine sandpaper to
smooth the surface after the staining process.
6. Remove all dust from the wood, and apply one coat of
Minwax
®
Polycrylic® Protective Finish using a synthetic
bristle brush to the wood. This finish should be applied
in a thin coat following the direction of the grain.
Apply the finish to the back and sides of the wood first,
and allow it to dry for two hours. Apply the finish to the
front side of the wood next, and allow it to dry for two
hours. Sand with very fine 220 grit sandpaper. Apply
two addition coats of the finish in the same manner, but
do not sand the trim after the final third coat is applied.
7. Allow the final coat to dry for 24 hours before
reinstalling the trim to the cabinet interior components.
Final finish-only application:
1. Remove all screws securing wood trim to interior
components, and remove the trim.
2. Lightly scruff sand the wood trim with 280 or finer grit
sandpaper.
3. Remove sanding dust with a clean, dry cloth.
4. The factory-applied seal is compatible with virtually all
finishes. A low odor, water clean up, quick-drying finish
such as Minwax
®
Polycrylic® Protective Finish is
recommended (Minwax® Polycrylic® is an ultra fastdrying water-based finish). Apply a thin coat of a clear,
protective finish, following the container label
directions.
5. Lightly sand and reapply if desired.
6. Allow the final coat to dry for 24 hours before
reinstalling the trim to the cabinet interior components.
IMPORTANT
DO NOT use oil-based stains on wood trim. Vapors from
oil-based stains will permanently penetrate the liner and
will not dissipate over time.
www.U-LineService.com 8 06/2006
2115WC/2115WCOL Wine Captain
®
Overlay Frame
(2115WCOL Units Only)
Frame Preparation
An overlay frame covers the door frame to give a built-in
appearance. Appropriate hardware and a copy of these
instructions will be included in the unit.
IMPORTANT
The thickness of the wood overlay frame must be 3/4".
The door frame must not weigh more than 20 lbs.
1. Create an overlay frame to the dimensions shown in
Figure 13.
13/16"
1/8"
Relief Notch
for Pivot Plate
(Right Hand Hinge Shown)
3/4"
1/8"
Rear View
of
Wood Frame
27-3/4"
30"
2. Typical routing dimensions
are shown in
Figure 14
.
3/4"
3/8"
1-1/8"
11/16"
(Ref.)
7/16"
(Ref.)
5/32"
1-13/16"
2-1/4"
Figure 14
3. Create a relief for pivot plate by cutting notch in top
corner and coinciding back corner of overlay frame.
Refer to
3/8"
13/32"
13/16"
Figure 15
0.177" Dia. (#16 Drill)
x
11/16" Deep
Top View
for exact specifications.
3/8"
Door Bottom:
5/16" Dia. x 1/4" Deep
Chamfer 1/32" x 45°
Bottom View
13/32"
12-1/2"
14-3/4"
Figure 13
IMPORTANT
Rear View of wood frame for right-hand hinge shown.
Use mirror image for left-hand hinges.
1/8"
1-17/32"
5/16" Dia.
x
13/16"
7/16"
1/2" Deep
1/8"
Back View
13/16"
13/32"
1/8"
1/32" R
1/8" R
3/4"
Side View
Figure 15
Route notch in top corner of overlay frame as shown (see
Top and Side Views). Top of notch is entire depth of
frame, front to back.
Width: 13/16"
Depth: 1/8"
Route notch in backside of top corner of overlay frame
(see Back and Side Views).
Width: 13/16"
Depth: 1/8"
06/2006 9 www.U-LineService.com
2115WC/2115WCOL Wine Captain
®
Height: 1-17/32" from top edge of frame (less 1/8" for
depth of notch on top of frame)
Radius of corner notch: 1/8" (see Back View)
4. Drill holes for pivot plate mounts (see
Figure 15
, Back
View).
5/16" diameter x 1/2" deep, from the routed surface
CAUTION
Be careful not to drill too deep! Drilling holes too deep
may destroy your door frame.
5. Drill hole for upper door hinge (top of frame) (see
Figure 15
, Top View).
0.177" diameter
(#16 drill) x 11/16" deep
6. Drill hole for lower door hinge (see
Figure 15
, Bottom
View).
5/16" diameter x 1/4" deep
CAUTION
It is important to ensure that all drilled holes are drilled to
the correct depth in order to avoid splits in the wood
when hardware is installed.
Installation Instructions
Preparing Door
Note: Door is not attached. It
is in a separate box inside the
unit box and taped to the
unit.
1. Lay door on a clean, flat
surface with the gasket
facing up.
2. Pull gasket completely out
of the groove. Start in the
Door
Figure 16
middle and pull outward,
moving toward the edge
(see
Figure 16
). This may take some force.
Note: Lay gasket flat on a clean surface to avoid
disturbing interior magnet.
Checking Overlay Fit
Gasket
2. Visually check for gap between frame and glass. If there
is an objectionable gap, follow steps under Applying
Foam Tape to Overlay Frame. If there is little or no gap,
continue to Attaching the Overlay Frame.
Applying Foam Tape to Overlay Frame (If required)
Inside Edge
Incorrect Correct
Figure 18
1. Cut foam tape into four pieces, two pieces the width
of the overlay frame and two pieces the height of the
overlay frame.
2. Remove the adhesive protection strip from one piece of
the foam tape and align to the edge of the overlay
frame as shown in
Figure 18
, adhering the foam tape
to the overlay frame.
3. Trim each piece of tape immediately after application.
Do not allow any overlapping of the foam tape.
Damage to the overlay frame can occur if the foam tape
is not trimmed properly.
Typical Wood
Frame
#6 X 5/8"
Flat Head Screw
Top Pivot
8 mm Plug Insert
Two Required
Two Required
Plate
Figure 19
Not Fully Seated Little or No Gap Objectional Gap
Figure 17
1. Turn door over and lay overlay frame on front side of
door. Make sure frame is fully seated on all four sides.
See Figure 17.
www.U-LineService.com 10 06/2006
Attaching the Overlay Frame
1. Tap nylon inserts into the top holes drilled in the
overlay frame. Use two #6 screws to attach top pivot
bracket to the overlay frame (see Figure 19).
2. If a user-supplied cabinet handle will be used, attach its
hardware to the overlay frame at this time.
2115WC/2115WCOL Wine Captain
®
IMPORTANT
User-supplied cabinet handle MUST be counter bored to
make sure mounting hardware is below surface of overlay
frame. Failure to do so can cause damage to overlay
frame and/or door. Overlay frame will not sit flush to door
if mounting hardware is not counter bored.
Tape
Figure 20
Door
Frame
Overlay
Frame
Note: The door frame is designed with a slight amount of
“play” to square it to the overlay frame.
6. Remove all traces of tape securing overlay frame to
door frame.
7. Starting at the corners and working toward the center,
push the door gasket back into place. Make sure gasket
is seated on all four sides.
Installing the Door
IMPORTANT
Pivot posts must be clean. Closers must also be clean and
greased to ensure proper operation.
1. Insert pivot post into bottom hinge, making sure to
tighten only until post is level with outside of hinge.
2. Install door closer. See Figure 26 on Page 12. Be sure
that bosses on closers align with holes in hinge.
Pivot Post
Backing plate for hinge
must be in place behind
each hinge
3. Secure the front of the door to the back of the overlay
frame using tape on all four corners, as shown in
Figure 20
. Make sure all four edges are aligned.
Rear View
of
Door and
Overlay Frame
Punch Pilot Holes
with #
6 x 1" Pan-head
Screws
–
10 Places
for use
Figure 21
4. Place door and overlay frame on a flat, clean protective
surface. Use the door frame holes as a guide to lightly
punch pilot holes for the #6 x 1" pan-head screws. See
Figure 21
.
5. Attach the door to the overlay frame using the #6 x 1"
wood screws.
Flush mount screws
in bracket so you can
see head only
Top Pivot Plate
Figure 22
3. Holding door upright with top of door tilted forward,
place hole of pivot plate onto bottom hinge screw pin.
Be sure that bosses on closers align with holes in pivot
plate.
4. Tilt top of door into position and install top hinge screw
pin. See
Figure 22
. Tighten only until post is level with
top of hinge.
5. Go on to
5 Adjust Door
.
IMPORTANT
If you decide to drill pilot holes, remove the door and do
not use a drill bit larger than 7/64". Do not drill deeper
than 3/8". Door frame and overlay frame must be aligned
properly or the door will not operate correctly.
06/2006 11 www.U-LineService.com
5 Adjust Door
2115WC/2115WCOL Wine Captain
®
Checking Door Alignment
The unit’s door is aligned at the factory before shipment.
However, its alignment could have been disturbed during
shipment or during overlay frame installation.
IMPORTANT
Properly aligned, the door should be 1/8" below the top of
the unit’s cabinet, NOT flush with the top (see
1/8"
Figure 23
1. Compare the top edge of the door to the top edge of
the cabinet.
2. If the door edge is 1/8" below and parallel to the top of
the cabinet, go on to
6 Prepare Power Supply
not, note whether the side opposite the hinge needs to
be moved UP or DOWN, and use the following
procedure.
Figure 23
. If it is
).
Adjusting Door Alignment
1. Remove top hinge screw
pin (Phillips screwdriver,
Figure 24). Remove
see
door by tilting forward
and lifting off bottom
hinge pin.
Slotted
Mounting
Holes
Raise
Outside
Door Edge
Angled Edge
Towards Center
of Door
Lower
Outside
Door Edge
Figure 25
3. See
Figure 25
. If the top far edge of the door needs to
move UP, move the hinge plate toward the outside of
the door and retighten screws. If the top far edge of the
door needs to move DOWN, move the hinge plate
toward the inside of the door and retighten screws.
4. Mount the door to recheck alignment and repeat
Steps 2 and 3 if further adjustment is necessary.
5. When top edge of door is parallel to top edge of
cabinet, remove the door and ensure the two screws
are secure.
6. Remove the door closers from the bottom hinge, clean
thoroughly and lubricate the mating surfaces with
petroleum jelly.
7. Reinstall the closers, lining
up the bosses with holes in
hinge and hinge plate (see
Figure 26
8. Mount the door, install top
hinge pivot pin and go on
6 Prepare Power
to
Supply
).
Door
Closer
Inserts
.
2. With door upside-down,
loosen but do not remove
the two screws on the
door’s bottom hinge plate.
Figure 24
www.U-LineService.com 12 06/2006
Boss
Figure 26
ULIN_0133_A
2115WC/2115WCOL Wine Captain
®
6 Prepare Power Supply
Electrical Specifications
CAUTION
Electrical installation must observe all state and local
codes. This unit requires connection to a grounded (threeprong), polarized receptacle that has been placed by a
qualified electrician.
The unit requires a grounded and polarized 115 VAC,
60 Hz, 15A power supply (normal household current).
An individual, properly grounded branch circuit or circuit
breaker is recommended. GFCI (ground fault circuit
interrupter) is usually not required for fixed location
appliances and is not recommended for your unit because
a GFCI could be prone to nuisance tripping. However, be
sure to consult your local codes.
See Figure 27 for recommended receptacle location.
7 Level the Unit
Leveling Information
Note: It is recommended that the unit is level.
1. Use a level to
check the
levelness of the
Wine Captain
from front to
back and from
side to side. Level
should be placed
along top edge
and side edge as
shown (see
Figure 28).
2. If the
Wine Captain® is not level, adjust the feet on the
corners of the unit as necessary (see
®
Figure 28
Figure 29
ULIN_0206_A
).
23-1/4"
7"
1"
Figure 27
WARNING
SHOCK HAZARD — Electrical Grounding Required.
• Never remove the round grounding prong from
the plug and never use a two-prong grounding
adapter.
• Never use an extension cord to connect power to
the unit.
Go on to 7 Level the Unit.
Turn Foot to Adjust
Figure 29
3. Check the levelness after each adjustment and repeat
the previous steps until the unit is level. Go on to
8 Install the Unit
.
Installation Tip
If the room floor is higher than the floor in the cut-out
opening, adjust the rear feet to achieve a total unit rear
"
height of 1/8
the unit height in the front by adjusting the front feet.
This allows the unit to be gently tipped into the opening.
Readjust the front feet to level the unit after it is correctly
positioned in the opening.
less than the opening’s rear height. Shorten
06/2006 13 www.U-LineService.com
2115WC/2115WCOL Wine Captain
8 Install the Unit
Anti-Tip Bracket Installation
1. Locate two Anti-Tip Brackets included inside the unit.
2. Place the unit into the area where it will be installed.
Check the door, sides and top for a proper fit. Also test
to make sure the door opens and closes freely.
3. Remove grill and place a mark on the floor at the front
of the unit. Also place a mark on the floor in the center
of the unit. See
Figure 30
.
®
Front
of Unit
Back
Wall
Line Marks
Back
of Unit
20-1/4"
Figure 30
Marks on floor
4. Remove the unit. Using a square, extend a centerline
20-1/4" toward the back wall. See
Figure 31
. At the
back of the centerline, mark a line that measures
6-9/16" to the left and right. This line serves as the back
edge for the Anti-Tip Brackets and its furthest points
mark the outer edge of each bracket.
Note: Instructions are shown for built-in installation. Use
same dimensions for free-standing installation.
Marks
on Floor
6-9/16" 6-9/16"
Centerline
Figure 31
5. Place the Anti-Tip Brackets on the floor against the line
drawn for the outer edge. Mark spots for the screw
holes. See
Figure 32
.
Drill Holes and
Mount Anti-Tip
Brackets to Floor
Back
of Unit
Front
of Unit
Back
Wall
Figure 32
6. Use a 1/8" drill to make two starter holes and fasten the
Anti-Tip Brackets to the floor using the screws provided.
CAUTION
Other hardware is required for floors made of materials
other than wood.
7. Place the unit back into position, making sure the feet
engage the Anti-Tip Brackets properly. Check the
alignment of the lines made on the floor in Step 3 with
the position of the front feet to ensure proper
positioning.
www.U-LineService.com 14 06/2006
2115WC/2115WCOL Wine Captain
®
Installation Troubleshooting
Problem
Q:
The door remains open unless it is pushed closed.
Solution
A:
The hinges should be self-closing when the door is open
"
approximately 8
closers (at the bottom of the hinge pin) are clean, greased
and installed correctly. Also, re-check leveling from front
to back of the unit and readjust if necessary. Make sure
that pivot plate is installed correctly.
. If this is not the case, make sure the
9 Start-Up for the First Time
Initial Start-Up
The unit is shipped with the control preset. No adjustments
should be necessary at this time. For information about
Adjusting the Temperature Control, see the Use and Care
Guide.
Start-Up Troubleshooting
Problem
Q:
Unit does not appear to turn on when plugged in.
Solution
A:
Make sure outlet has power (circuit breaker has not
tripped). Check to see that control is turned on.
Problem
Q:
Light is on with door closed.
Solution
A:
Touch the LIGHT icon on the display panel. This will cancel
out the light function and just allow the light to turn on
and off with the door opening and closing.
The Wine Captain
when the door is opened. The light can be left on while
the door is closed by pressing the LIGHT icon. This will
turn interior light on for 4 hours, then it will turn off.
®
has an interior light that is illuminated
IMPORTANT
See the Use and Care Guide’s Troubleshooting Guide for
more solutions.
06/2006 15 www.U-LineService.com
Who to Call
Service Information
If the need for service arises, call the U-Line Customer
Care Center directly @ 800-779-2547. To ensure accurate
assistance, please have your Model Number and Serial
Number and an explanation of the problem. The Model
and Serial Number plate is located inside unit at upper
right hand corner.
If you need to locate a service company, you can go online
at www.U-LineService.com and search for a service
company by zip code.
For more than four decades, U-Line has distinguished itself as the leader in built-in
undercounter ice making, refrigeration and wine storage appliances.
U-Line Corporation, located in Milwaukee, WI, is a family operated manufacturer of built-in
undercounter icemakers, Combo
refrigerators, refrigerated drawers and refrigerator/freezers.
©2006 U-Line Corporation
Publication No. 30142E
06/2006 Rev. A
®
icemaker/refrigerators, Wine Captain® wine storage units,
Loading...
