airMAX® ac BaseStation
with airPrism® Technology

Model: R2AC

Worldwide, Full-Band 2.4 GHz Coverage

airMAX ac Technology for up to 330+ Mbps Throughput

Revolutionary airPrism Active RF Filtering Technology

Overview

Ubiquiti Networks has designed

Application Example

airMAX ac radios with high
performance and ease of installation
in mind. The Rocket®2AC Prism

RocketDish with

Rocket 2AC Prism

features both airMAX ac and airPrism
technologies for maximum wireless
performance in high‑density areas.

Pair the Rocket 2AC Prism with airMAX

Datasheet

antennas for optimal performance:

• Point-to-Point (PtP)

backhaul RocketDish

™

Antenna

Internet

Backbone

ISP

Network

• Point-to-MultiPoint (PtMP)

PtP Backhaul Link

airMAX Sector with

Rocket 2AC Prism

RocketDish with

Rocket 2AC Prism

links airMAXSector Antenna

2.4 GHz Coverage

PtMP airMAX Links

Deploy the Rocket 2AC Prism
anywhere in the world. It delivers
complete coverage of the 2.4 GHz
spectrum with a single radio. The

Rocket 2AC Prism allows for exibility
in conguring channel bandwidths

(subject to local country regulations).

Software

Corporate Building

Residence

Internet Cafe Small Business

Outdoor Hotspot

The Rocket 2AC Prism used for a PtP backhaul and a PtMP link in an airMAX network.

airOS® v8 is the revolutionary

operating system for Ubiquiti®

airMAXac products.

Powerful Wireless Features

• Access Point PtMP airMAX Mixed

Mode

• airMAX ac Protocol Support

• Long‑Range Point‑to‑Point (PtP)

Link Mode

• Selectable Channel Width

• PtP: 10/20/40 MHz

• PtMP: 10/20/40 MHz

• Automatic Channel Selection

• Transmit Power Control:

Automatic/Manual

• Automatic Distance Selection

(ACK Timing)

• Strongest WPA2 Security

Usability Enhancements

• airMagic® Channel Selection Tool

• Dynamic Conguration Changes

• Instant Input Validation

• Redesigned User Interface

• HTML5 Technology

• Optimization for Mobile Devices

• Detailed Device Statistics

• Diagnostic Tools, including Ethernet

Cabling Test, RF Diagnostics, and

airView® Spectrum Analyzer

Dashboard

2

Advanced RF Analytics

airMAX ac devices feature a
multi‑radio architecture to power a
revolutionary RF analytics engine.

An independent processor on the
PCBA powers a second, dedicated
radio, which persistently analyzes
the full 2.4 GHz spectrum and every
received symbol to provide you with
the most advanced RF analytics in the
industry.

Real-Time Reporting

airOS 8 displays the following RF

information:

• Persistent RF Error Vector

Magnitude (EVM) constellation
diagrams

• Signal, Noise, and Interference (SNI)

diagrams

• Carrier to Interference‑plus‑Noise

Ratio (CINR) histograms

Multi-Radio Architecture

Datasheet

Constellation Diagrams

Spectral Analysis

airView allows you to identify noise
signatures and plan your networks to
minimize noise interference. airView
performs the following functions:

• Constantly monitors environmental

noise

• Collects energy data points in

real‑time spectral views

• Helps optimize channel selection,

network design, and wireless
performance

airView runs in the background
without disabling the wireless link, so
there is no disruption to the network.

In airView, there are three spectral
views, each of which represents
different data: waveform, waterfall,
and ambient noise level.

airView provides powerful spectrum
analyzer functionality, eliminating the
need to rent or purchase additional
equipment for conducting site
surveys.

UNMS App

SNI Diagram and CINR Histogram

Dedicated Spectral Analysis

UNMS Conguration Screen

The Rocket 2AC Prism integrates a

separate Wi-Fi radio for fast and easy

setup using your mobile device.

Accessing airOS via Wi-Fi

The UNMS™ app provides instant
accessibility to the airOS conguration

interface and can be downloaded

from the AppStore (iOS) or Google

™

Play

(Android). UNMS allows you to

set up, congure, and manage the

Rocket 2AC Prism and offers various

conguration options once you’re

connected or logged in.

3

Technology

0 50 100 150 200 250 300 350

airMAX ac TDMA Technology

Unlike standard Wi-Fi protocol,
Ubiquiti’s Time Division Multiple

Access (TDMA) airMAX ac protocol
allows each client to send and receive
data using pre‑designated time
slots scheduled by an intelligent AP

Datasheet

controller.

This time slot method eliminates
hidden node collisions and maximizes

airtime efciency, so airMAX ac

technology provides performance
improvements in latency, noise
immunity, scalability, and throughput
compared to other outdoor systems in
its class.

Intelligent QoS Priority assigned to
voice/video for seamless streaming.

Scalability High capacity and
scalability.

Long Distance Capable of
high‑speed, carrier‑class links.

Timeline

Time Slot 1

Time Slots

Packet Prioritization

Time Slot 2

Time Slot 3

Time Slot 4

Data

VOIP

VOIP

VOIP

Up to 100 airMAX ac stations can be connected to an airMAX ac Sector;

four airMAXac stations are shown to illustrate the general concept.

airMAX ac Network Scalability

Superior Performance

The next-generation airMAXac

technology boosts the advantages of
our proprietary TDMA protocol.

Ubiquiti’s airMAX engine with custom

IC dramatically improves TDMA
latency and network scalability. The
custom silicon provides hardware
acceleration capabilities to the airMAX
scheduler, to support the high data
rates and dense modulation used in
airMAX ac technology.

Throughput Breakthrough

airMAX ac supports high data rates,
which require dense modulation:

256QAM – a signicant increase from

64QAM, which is used in airMAX.

With their use of proprietary
airMAXac technology, airMAX ac
products supports up to 330+Mbps

(maximum 40 MHz channel width)
real TCP/IP throughput – up to triple
the throughput of standard airMAX
products.

U-AME-G1-BR4A
NKC966.001B
1412
TAIWAN

Superior Throughput Performance

150+ Mbps

150+ Mbps

330+ Mbps

4

Technology

To enhance airMAX ac performance,
Ubiquiti Networks introduces our
patented airPrism technology, which
is featured on the Rocket 2AC Prism,

model R2AC-PRISM.

Improves SNR

High data rates require a high

Signal-to-Noise Ratio (SNR), which is

challenging to achieve, especially in
noisy, high‑density areas.

Integrated into Ubiquiti’s custom

silicon, airPrism technology creates a

high SNR by isolating signals within

the operating channel and rejecting
interference using specialized circuitry,

the High-Selectivity Receiver(HSR).

Removes Interference

Depending on the product model and
operating mode, available channel
widths may include 10, 20, or 40 MHz.

Theoretically APs operate on different
channels; however, because of the
wider channel bandwidths, there can
be overlap in spectrum usage.

airPrism technology removes up to an

additional 30+dB of adjacent channel

interference through the active

ltering design, so an airMAXac AP

with airPrism technology can provide

signicantly greater performance than

a typical AP.

Active Radio Frequency Filtering

Facilitates AP Co-Location

Co‑location is vital in many scenarios.

For example, a WISP may have limited

tower space, so it must co‑locate all
APs within that allotted footprint.

Shielding and other means can lessen

interference but may be impractical.

By deploying airMAX ac APs with
airPrism technology, you can
co‑locate APs and enhance the overall
performance of your wireless network.

Number of APs Channel Width

1 40 MHz

3 20 MHz

6 10 MHz

2.4 GHz with airPrism2.4 GHz Environment

Datasheet

What the Radio Sees

Improved Latency and Noise Immunity

H
V

5

Specications

R2AC

Dimensions 88 x 40 x 230 mm (3.47 x 1.58 x 9.06")

Weight 440 g (15.52 oz)

Networking Interface (1) 10/100/1000 Ethernet Port

RF Connectors (2) RP-SMA (Waterproof ), (1) GPS* (Waterproof)

LEDs (4) Signal Strength, GPS*, LAN, Power

Enclosure Die-Cast Aluminum with White Powder Coating

Max. Power Consumption 8.5W

Datasheet

Power Supply 24V, 0.5A Gigabit PoE Adapter (Included)

Power Method Passive PoE (Pairs 4, 5+; 7, 8 Return)

Processor Specs Atheros MIPS 74Kc, 720 MHz

Memory 128 MB DDR2 SDRAM, 16 MB NOR Flash

Supported Voltage Range 18-26VDC

Signal Strength LEDs Software-Adjustable to Correspond to Custom RSSI Levels

Channel Sizes 10/20/40 MHz

ESD/EMP Protection ± 24 kV Contact / Air for Ethernet

Operating Temperature -40 to 70° C (-40 to 158° F)

Operating Humidity 5 to 95% Noncondensing

RoHS Compliance Yes

Shock and Vibration ETSI300-019-1.4

Modes Access Point, Station

Services Web Server, SNMP, SSH Server, Telnet , Ping Watchdog, DHCP, NAT, Bridging, Routing

Utilities airMagic, airView, Antenna Alignment Tool, Discovery Utility, Site Survey, Ping, Traceroute, Speed Test

Distance Adjustment Dynamic Ack and Ackless Mode

Power Adjustment Software Adjustable UI or CLI

Security WPA2 AES Only

QoS Supports Packet Level Classication WMM and User Customer Level: High/Medium/Low

Statistical Reporting Up Time, Packet Errors, Data Rates, Wireless Distance, Ethernet Link Rate

Other Remote Reset Support, Software Enabled/Disabled,

VLAN Support, 256QAM, GPS*, TX Filter

Ubiquiti Specic Features 10 MHz Channels, airMAX ac Mode, Trafc Shaping with Burst Support,

Discovery Protocol, Frequency Band Offset, Ackless Mode

Certications CE, FCC, IC

* GPS sync support available in airOS rmware v8.5.0 and newer.

Operating Frequency (MHz)

Worldwide 2412 - 2472

USA 2412 ‑ 2462

Management Radio (MHz)

Worldwide 5150 ‑ 5250

USA U-NII-3: 5725 - 5850

R2AC Output Power: 27 dBm

TX Power Specications RX Power Specications

Modulation Data Rate Avg. TX Tolerance Modulation Data Rate Sensitivity Tolerance

airMAX ac

1x BPSK (½) 27 dBm ± 2 dB

2x QPSK (½) 27 dBm ± 2 dB 2x QPSK (½) -95 dBm ± 2 dB

2x QPSK (¾) 27 dBm ± 2 dB 2x QPSK (¾) -92 dBm ± 2 dB

4x 16QAM (½) 26 dBm ± 2 dB 4x 16QAM (½) -90 dBm ± 2 dB

4x 16QAM (¾) 26 dBm ± 2 dB 4x 16QAM (¾) -86 dBm ± 2 dB

6x 64QAM (⁄) 25 dBm ± 2 dB 6x 64QAM (⁄) -83 dBm ± 2 dB

6x 64QAM (¾) 25 dBm ± 2 dB 6x 64QAM (¾) -77 dBm ± 2 dB

6x 64QAM (⁄) 24 dBm ± 2 dB 6x 64QAM (⁄) -74 dBm ± 2 dB

8x 256QAM (¾) 23 dBm ± 2 dB 8x 256QAM (¾) -69 dBm ± 2 dB

8x 256QAM (⁄) 22 dBm ± 2 dB 8x 256QAM (⁄) ‑65 dBm ± 2 dB

airMAX ac

1x BPSK (½) -96 dBm ± 2 dB

6

Plug and Play Integration

Frequency Band

Rocket radios and airMAX antennas have been designed to seamlessly work together. Every airMAX antenna has a built‑in
Rocket mount, so installation requires no special tools.

Antenna
Compatibility

Rocket 2AC Prism

2.4 GHz

AMO-2G10

AMO-2G13

Omni

AM-2G15-120

Datasheet

AM-2G16-90

AM-V2G-Ti

Sector

RD-2G24

Rocket Dish
