FDNL-CSG88-W
This station provides 8 inputs and 8 outputs. The input and output circuits are combined in
one connector. The unit is specifically designed to work I/O devices that have both an input
and output. Examples include part verification arrays and push buttons. The station also
accepts 3-wire PNP sensors or simple outputs alone.
Each eurofast
to the attached sensor, is short-circuit protected and monitored as a group. The V- is the
sensor and output ground. The input will work with a PNP type sensor or dry contact. The
outputs are short-circuit protected, but monitored as a group.
Each connector has both input LED and output LED associated with it. The LED turns green
if the I/O point is on. Inputs are monitored for short-circuit protection as a group.
The node address can be set using the rotary switches located under the cover or through
software. The unit automatically detects the communication rate.
Polled, change of state, and cyclic I/O messages are supported.
Recommended Cordsets:
Bus line: RSM RKM 579-*M
Inputs: VB2-RS 4.4T-*/2RK 4.4T-*/*/S651 or RK 4.4T-*-RS4.4T
Bus T: RSM 2RKM 57/C1125
®
connector provides V+, V-, Input, and Output. The V+ provides power
FDNL-CSG88-W Dimensions
Advanced DeviceNet™ station•
8 combined input and output points•
Applications
For use with pushbuttons•
For use with 3-wire sensors•
For use with discrete actuators•
Features
PNP short-circuit protected inputs•
0.5 amp short-circuit protected outputs•
Rotary address switches•
Automatic detection of network •
communication rate
TURCK Inc. 10240193 Rev 1.05 3/08
FDNL-CSG88-W
Connectors
5-pin Male
DeviceNet™ minifast
Input / Output Connector
I/O Data Mapping
Item Number F0128
Product Type / Code: 7/2049
1 = Shield
2 = V +
3 = V –
4 = CAN_H
5 = CAN_L
®
Abbreviations
I = Input Data (0=OFF, 1=ON)
IGS = Input Group Status (0=Working, 1=Fault)
O = OutputData (0=OFF, 1=ON)
OGS = Output Group Status (0=Working, 1=Fault)
Input
Data
Output
Data
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 I-7 I-6 I-5 I-4 I-3 I-2 I-1 I-0
1 IGS OGS - - - - - -
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 O-7 O-6 O-5 O-4 O-3 O-2 O-1 O-0
Module Specifications
Supply Voltage
Bus Power 11-26 VDC, powers communication, inputs and outputs
Internal Current Consumption <100 mA plus sum of sensor and output currents
Input Circuits (8) PNP 3-wire sensors or dry contacts
Input Voltage (V+) 13-26 VDC (from bus power)
Input Short-Circuit (V+) 700 mA - 2.0A (total)
Input Signal Current (I) OFF <2 mA
ON 3.0-3.4 mA at 24 VDC
Input Delay 2.5 ms
TURCK Inc. 10240193 Rev 1.05 3/08
FDNL-CSG88-W
Output Circuits (8) DC actuators or indicators
Output Voltage 18-26 VDC (from bus power)
Output Load Current 0.5 A per output (from bus power)
Maximum Switching Frequency 100 Hz
I/O LED Indications
Off = Not active
Green = Active
Module Status LED
Off = Power off
Green = Operating
Flashing Green = Autobaud
Flashing Red = I/O short
Network Status LED
Off = No connection
Green = Established connection
Flashing green = Ready for connection
Flashing red = Connection time-out
Red = Connection not possible
Address via rotary switch
0-63
Address from internal EEPROM (rotary switch must be in PGM position)
Housing 197 x 60 x 40 (H x W x D)
Material Glass-filled nylon, nickel plated brass connectors
Mounting 4 through-holes, 5.3 mm diameter
Enclosure NEMA 1, 3, 4, 6, 6P, 12, 13 and IEC IP 67, 68, and 69K
Operating Temperature -40° to +70°C (-40° to 158° F)
TURCK Inc. 10240193 Rev 1.05 3/08
