TTE Technology 32D100 User Manual
Ready.
Set.
Go!
D-Series / D100
Important Information
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
Caution: To reduce the risk of electric shock, do not remove cover (or back). No user
serviceable parts inside. Refer servicing to qualied service personnel.
This symbol indicates “dangerous voltage”
inside the product that presents a risk of
electric shock or personal injury.
WARNING
To reduce the risk of re or electric shock,
donot expose this product to rain or
moisture. dripping or splashing. No
objects lled withThis product should
not be exposed to liquids, such as vases,
should be placed on the apparatus.
Warning: The batteries shall not be exposed to excessive heat such as sunshine,
re or the like.
Refer to the identication/rating label located on the back panel of your product for its
proper operating voltage.
Cable TV Installer: This reminder is provided to call your attention to Article 820-40 of
the National Electrical Code (Section 54 of the Canadian Electrical Code, Part 1) which
provides guidelines for proper grounding and, in particular, species that the cable
ground should be connected to the grounding system of the building as close to the
point of cable entry as practical.
Important: This television is a table model and is designed to sit on a rm, at surface.
Don’t place the TV on soft carpeting or similar surface because the ventilation slots on
the bottom of the unit will be blocked, resulting in reduced lifetime from overheating.
To assure adequate ventilation for this product, maintain a spacing of 4 inches from
the top and side of the TV receiver and 2 inches from the rear of the TV receiver and
other surfaces.
This symbol indicates that this product
incorporates double insulation between
hazardous main voltage and user accessible
parts. When servicing, use only identical
replacement parts.
This symbol indicates important
instructions accompanying the
product.
WARNING
The TV is unstable if it is not properly
attachedto the base or mounted to the
wall. Please follow the base or wall
mounting instructionsprovided in the
User’s Guide to ensure your safety.
Also, make sure the stand or base you use is of adequate size and strength to
prevent the TV from being accidentally tipped over, pushed o, or pulled o. This
could cause personal injury and/or damage to the TV. Refer to the Important Safety
Instructions on the next page.
The Power button (followed by the power symbol) on this TV and your remote
control puts the TV into a very low-power standby mode but will not completely turn
the power o. In order to completely shut the power o, you will need to disconnect
the power cord from the outlet. The mains plug/appliance coupler is used to
completely turn o the device. If you prefer to completely turn o the device, you
should install the TV in a manner that allows you to disconnect the power
Product Registration
Please register your TCL TV purchase on-line at www.tclusa.com. It will make it easier
to contact you should it ever be necessary. Registration is not required for warranty
coverage.
Product Information
Keep your sales receipt to obtain warranty parts and service and for proof of purchase.
Attach it here and record the serial and model numbers in case you need them. These
numbers are located on the product.
Warning: Changes or modications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
Keep the apparatus at least 20cm far sway trom the human body.
Input Signat Compatibility
Antenna/Cable 480i, 480p, 720p, l080i (NTSC, ATSC, and QAM formatal
Composite Video 480i, 576i
HDMI 480i, 480p, 720p/60Hz, 1080i/60Hz, 1080p/60Hz, 576i/p, 1080i/p/50Hz
To bring you better visual experience, please remove the energy guide label, it
available, trom TV tront panel and screen betore use.
Model No. Serial No.
Purchase Date Dealer/Address/Phone
1
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including ampliers) that produce heat.
9.
Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other . A grounding type plug
has two blades and a third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not t into your outlet, consult an
electrician for replacement of the obsolete outlet.
10.Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11.Only use attachments/accessories specied by the manufacturer.
12.Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
13.Unplug this apparatus during lightning storms or when unused for long periods of
time.
14.Refer all servicing to qualied service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped. ANSI/NFPA
15.If safety relevant, the following information should be included as far as applicable:-
minimum distances around the apparatus for sucient ventilation;- the ventilation
should not be inpeded by covering the ventilation openings with items, such as
newspapers, table-cloths, curtains, etc.;- no naked ame sources, such as lighted
candles, should be placed on the apparatus;- attention should be drawn to the
environmental aspects of battery disposal;- the use of apparatus in tropical and/or
moderate climates.
16.If an outside antenna or cable system is connected to the product, be sure the
antenna or cable system is grounded so as to provide some protection against
voltage surges and built-up static charges. Section 810 of the National Electrical
Code, ANSI/NFPA No. 70-2011 (Section 54 of Canadian Electrical Code, Part 1)
provides information with respect to proper grounding of the mast and supporting
structure, grounding of the lead in wire to an antenna-discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode. See following example:
ANTENNA LEAD IN WIRE
GROUND CLAMP
ANTENNA DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
ELECTRIC SERVICE
EQUIPMENT
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM (NEC ART
250, PARTH)
2
What’s included
What’s required
4 x Phillips screws
(ST4X20mm for 32”)
(ST4X25mm for 40”)
(M5X35mm for 49”)
TV standsTCL TV
2 x AA batteries
for remote
Power cable
(only for 49”)
TV remote
3
Phillips head screwdriver
