Model B-0865-04 includes 4” Wrist Action
handles (B-WH4). Model B-0865 includes
6” Wrist Action handles (B-WH6).
B-0865, B-0865-04
Commercial Faucet Assembly
1 Screw, Handle 000925-45 12 Washer 000981-45
2 Index, Snap-In, Blue/Cold 001686-45 13 Nut, Coupling 000958-20
Index, Snap-In, Red/Hot 001194-45 14 Nipple 000342-20
3 Handle, Wrist Action, 6" (B-0865) B-WH6 15 Locknut 002954-45
Handle, Wrist Action, 4" (B-0865-04) B-WH4 16 O-Ring, Knuckle Joint 001060-45
4 Escutcheon 001257-40 17 Locknut, Yoke 000956-45
5 Asm, Side Body - Cold 161A 18 Center Body 000136-40
Asm, Side Body - Hot 162A 19 Washer 000999-45
6 Asm, Spindle, Eterna - RH/Cold006478-40 20 Washer, Swivel Yoke, Top 000994-45
Asm, Spindle, Eterna - LH/Hot 006477-40 21 O-Ring, Swivel Yoke, Center 001068-45
7 Locknut, Body Top 000959-20 22 Washer, Swivel Yoke, Bottom 000993-45
8Washer, Body 002290-45 23 Washer, Yoke Star 000982-45
9Washer, Nipple 001006-45 24 Asm, Nozzle Gooseneck 120X
10 Locknut, Body Bottom 000960-20 25 Asm, Spray Head, Rosespray B-0103
11 Washer, Beveled 001091-45
T&S Brass and Bronze Works, Inc. • Travelers Rest, South Carolina • 1-800-476-4103
