T&S BRASS AND BRONZE WORKS, INC.
2 Saddleback Cove / P.O. Box 1088
Travelers Rest, SC 29690
Travelers Rest, SC: 800-476-4103
This Space for Architect/Engineer Approval
Job Name__________________________Date_________
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
Architect/Engineer_________________________________
Simi Valley, CA: 800-423-0150
Fax: 864-834-3518
REG. #A2601
ISO #9001
www.tsbrass.com
Model No.
B-0805-01
Item No.
Wrist Action Metering
Cartridge w/ 4" Wrist
Action Handle and
Blue "CW" Index
1/2" NPSM
Male Shank
2.2 GPM
Aerator
1 9/16"
(40mm)
4 5/16" (110mm)
Product Specifications:
Single Temperature Deck Mount Faucet, 1/2" NPSM Male Shank,
Wrist Action Meteri ng Cartridge w/ 4" Wrist Action Handle,
2.2 GPM Aerator
Drawn
Scale:
Rough-in: 1" Hole
Checked
GEF
1:2
Approved
JHBDMH
Date:
10/03/08
Sheet:
of
1
2
T&S BRASS AND BRONZE WORKS, INC.
Travelers Rest, SC: 800-476-4103
2 Saddleback Cove / P.O. Box 1088
Travelers Rest, SC 29690
Simi Valley, CA: 800-423-0150
ITEM
NO.
1 012449-40 Wrist Action Metering Cartridge Asm
2 000999-45 Brass Lock Washer
3 002954-45 Shank Lock Nut
4 000958-20 Coupling Nut
5 001043-45 Washer
6 044A 3/8" to Aerator Adapter
7 B-0199-01 2.2 GPM Aerator, Female
8 B-0199-02 Aerator, 2.2 GPM, 3/8" NPSM
9 B-WH4 4" Wrist Action Handle
10 000925-45 Lab Handle Screw
11 001686-45 Blue CW Index
SALES NO. DESCRIPTION
Fax: 864-834-3518
REG. #A2601
ISO #9001
www.tsbrass.com
Model No.
B-0805-01
Item No.
1
5
2
1011
9
6
7
8
3
4
Product Specifications:
Single Temperature Deck Mount Faucet, 1/2" NPSM Male Shank,
Wrist Action Meteri ng Cartridge w/ 4" Wrist Action Handle,
2.2 GPM Aerator
Drawn
DMH
Scale:
Checked
GEF
1:2
Approved
JHB
Date:
10/03/08
Sheet:
of
2
2
