2 5/16"
58mm
7 7/16"
188mm
12 9/16"
319mm
357mm
14 1/16"
42 1/16"
1068mm
Color Coded Indexes
Compression Fittings
3/8" NPT x 24" Riser
for 5/8" O.D. Copper Tubing
EasyInstall
Lock Nut & Bushing
For Clarity
Items Not Shown
18" Flexible
(Remove Compression Nut
for 1/2" NPSM Male)
Stainless Steel
Supply Hoses
Mounting Surface
Quarter-Turn
Eterna Cartridges w/
Spring Checks &
Lever Handles w/
Finger Hook
2
Contractor_______________________________________
Product Specifications:
Scale:
Model No.
Item No.
T&S BRASS AND BRONZE WORKS, INC.
07/13/21JRM
Approved:
1:9
Stainless Steel Hose, 1.15 GPM Spray Valve, 6" Wall Bracket & Flexible
Travelers Rest, SC 29690
2 Saddleback Cove / P.O. Box 1088
Turn Eterna Cartridges w/ Spring Checks, Lever Handles, 44" Flexible
of
1Sheet:
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com
JHB
GEF
Date:
Stainless Steel Supply Hoses
Architect/Engineer_________________________________
B-0113-B
Pre-Rinse Unit: EasyInstall Single Hole Deck Mount Mixing Faucet, Quarter-
Checked:
Drawn:
This Space for Architect/Engineer Approval
Job Name
__________________________Date_________
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
2019 DOE PRSV - Class II
SASO (Saudi Arabia)
1.15 GPM
B-0107
Deck
[57mm]
Spray Valve
Hose w/ Spring & Spray Valve
Flange
44" Flexible Stainless Steel
Rough-In Requirement:
1 1/2" [38mm] Mounting Hole
Ø 2 1/4"
B-0109-01
6" Wall
Bracket
1 7/8"
48mm
Maximum
Thickness
Page 2
ITEM
NO.
SALES NO. DESCRIPTION
1 B-0107 1.15 GPM Spray Valve
2 010476-45 #27 Washer
3 000907-45 Spray Valve Hold Down Ring
4 002987-40 Grip Handle
5 001014-45 Washer, Hose Barrel
6 B-0044-H2A
44" Flexible Stainless Steel Hose, Less
Handle
7 000888-45 EasyInstall Overhead Spring
8 B-0109-01 6" Wall Bracket
9 000821-40 Spring Body
10 004R Finger Hook
11 000372-40 3/8" NPT x 24" Riser
12 EZ-K
EasyInstall Kit: Nut, Bushing, O-Ring &
Lock Washer
13 001065-45 O-Ring
14 014200-45 Star Washer, Anti-Rotation
15 012442-40NS
Quarter-Turn Eterna Cartridge w/
Spring Check, LTC
16 002711-40NS
Quarter-Turn Eterna Cartridge w/
Spring Check, Handle, Blue Index &
Screw, LTC
17 001638-45NS Lever Handle (New Style)
18 018506-19NS Blue Button Index, Press-in
19 002290-45 Lock Washer
20 000965-45 Lock Nut
21 012534-45 18" Flexible Supply Hose (2)
22 012443-40NS
Quarter-Turn Eterna Cartridge w/
Spring Check, RTC
23 002712-40NS
Quarter-Turn Eterna Cartridge w/
Spring Check, Handle, Red Index &
Screw, RTC
24 000925-45 Lab Handle Screw
25 001193-19NS Red Button Index, Press-in
NSF 61 - Section 9
JRM
Stainless Steel Supply Hoses
Scale:
Model No.
Item No.
2019 DOE PRSV - Class II
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com
Date: 07/13/21
2
Checked:
Travelers Rest, SC 29690
2 Saddleback Cove / P.O. Box 1088
Drawn:
B-0113-B
Sheet:NTS
SASO (Saudi Arabia)
NSF 372 (Low Lead Content)
of
T&S BRASS AND BRONZE WORKS, INC.
2JHB
GEF
Approved:
Product Compliance:
ASME A112.18.1 / CSA B125.1
Pre-Rinse Unit: EasyInstall Single Hole Deck Mount Mixing Faucet, Quarter-
Turn Eterna Cartridges w/ Spring Checks, Lever Handles, 44" Flexible
Stainless Steel Hose, 1.15 GPM Spray Valve, 6" Wall Bracket & Flexible
Product Specifications:
2
2
17
6
9
14
19
20
24
5
18
25
3
4
10
11
21
23
16
1
13
12
15
22
7
8
