True T-24-GC Specifications

TRUE FOOD SERVICE

EQUIPMENT, INC.

St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366

[phone] • FAX [phone] • [phone] • www.truemfg.com

Parts Dept. (800)424-TRUE • Parts Dept. FAX# [phone]

Project Name:

Location:

Item #: Qty:

Model #:

AIA #

SIS #

Model:

T-24-GC

Glass and Plate Chiller/Froster:

Solid Lid

T-24-GC

True’s glass and plate chiller/frosters
are designed with enduring quality
and value. Our commitment to
using the highest quality materials
and oversized refrigeration assures
colder product temperatures and
years of trouble free service.

Large storage capacity to meet the
supply and demand requirements
during peak hours.

Oversized, factory balanced,
refrigeration system holds 0°F
(-17.7°C) and below.

Forced-air cooling, positively guided
airfl ow provide effi cient balanced
temperatures throughout the
cabinet. This unique design insures
fast frosting of dry glasses and
plates.

Exterior - heavy duty, wear resistant
laminated black vinyl front and
sides, matching black aluminum
back. All stainless steel countertop
and lid.

Interior - long lasting, heavy duty
galvanized steel.

Evaporator - epoxy coated at the
time of manufacture to eliminate
the potential of corrosion.

Entire cabinet structure and lids are
foamed-in-place using high density,
CFC free, polyurethane insulation.

Heavy duty, 10 mil thick pure grade
PVC coated adjustable shelves.

ROUGH-IN DATA

Capacity

8"

(204 mm)

Model Lids

Mugs

T-24-GC 1 90 85 2 24

†

Depth does not include 1" (26 mm) for rear bumpers. ▲ Plug type varies by country.

T

RUE

R

EFRIGERATION

TM

MADE IN

U.S.A.

SINCE 1945

12/05

10 oz.
Steins

Printed in U.S.A.

Shelves

R

Chart dimensions rounded up to the nearest

Cabinet Dimensions

(inches)

(mm)

LD†H

3

/4

265/8

629

APPROVALS:

677

333/8

848

Specifi cations subject to change without notice.

1

/8" (millimeters rounded up to next whole number).

HP Voltage Amps

1

/4

1

/3

115/60/1

230-240/50/1

5.8

2.7

AVAILABLE AT:

NEMA

Confi g.

5-15P

▲

Cord

Length

(total ft.)

(total m)

9

2.74

Crated

Weight

(lbs.)

(kg)

180

82

Model:

T-24-GC

Glass & Plate Chiller/Froster:

Solid Lid

STANDARD FEATURES

DESIGN

• True’s glass and plate chiller/frosters
are designed with enduring quality and
value. Our commitment to using the
highest quality materials and oversized
refrigeration assures colder product
temperatures and years of trouble free
service.

REFRIGERATION SYSTEM

• Factory engineered, self-contained,
capillary tube system using
environmentally friendly (CFC free) 404A
refrigerant.

• Extra large evaporator coil balanced
with higher horsepower compressor
and large condenser; maintains cabinet
temperatures of 0°F (-17.7°C) and below.

• Sealed, cast iron, self-lubricating
evaporator fan motor and larger fan
blades give True chiller/frosters a more
effi cient low velocity, high volume airfl ow
design. This unique design insures fast
frosting of dry glasses and plates.

• Automatic defrost system time-initiated,
time-terminated.

• Condensing unit accessed from behind
front grill, slides out for easy maintenance.

• Forced-air cooling, positively guided
airfl ow provide effi cient balanced
temperatures throughout the cabinet.

CABINET CONSTRUCTION

• Exterior - heavy duty, wear resistant
laminated black vinyl front and sides,
matching black aluminum back. All
stainless steel countertop and lids.

• Interior - long lasting, heavy duty
galvanized steel.

• Insulation - entire cabinet structure is
foamed-in-place using high density, CFC
free, polyurethane insulation.

• Welded, heavy duty galvanized frame rail
dipped in rust inhibiting enamel paint for
corrosion protection inside and out.

SHELVING

• Two (2) adjustable, heavy duty PVC coated
wire shelves 10

1

/4"L x 195/16"D (261 mm
x 491 mm). Split shelf design allows for
effective rotation of chilled smallware,
working with already chilled plates and
glasses on one side while chilling dry
product on other side.

MODEL FEATURES

• Evaporator is epoxy coated to eliminate
the potential of corrosion.

• Listed under NSF-7 for the storage and/or
display of packaged or bottled product.

ELECTRICAL

• Unit completely pre-wired at factory and
ready for fi nal connection to a 115/60/1
phase - 15 amp dedicated outlet. Cord
and plug set included.

115/60/1
NEMA-5-15R

OPTIONAL FEATURES/ACCESSORIES

Upcharge and lead times may apply.

❒

230-240V / 50 Hz.

❒

6" (153 mm) standard legs.

❒

6" (153 mm) seismic/fl anged legs.

❒

21/2" (64 mm) diameter castors.

❒

3" (77 mm) diameter castors.

❒

Ratchet lock.

❒

Floor racks.

❒

Additional shelves.

❒

Remote cabinets (condensing unit
supplied by others; system comes standard
with 404A expansion valve and requires
R404A refrigerant), consult factory
technical service department for BTU
information.

PLAN VIEW

23/4"

(70 mm)

279/16"

(701 mm)

31/16"

(78 mm)

One year warranty on all parts

and labor and an additional 4
year warranty on compressor.

St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • FAX [phone] • [phone] • www.truemfg.com

243/4"

(629 mm)

ELEVATION

WARRANTY

(U.S.A. only)

333/8"

(848 mm)

RIGHT VIEW

METRIC DIMENSIONS ROUNDED UP TO THE

NEAREST WHOLE MILLIMETER

SPECIFICATIONS SUBJECT TO CHANGE

WITHOUT NOTICE

TRUE FOOD SERVICE EQUIPMENT

269/16"

(675 mm)

KCL

1"

(26 mm)

279/16"

(701 mm)

PLAN VIEW

Model Elevation Right Plan 3D

T-24-GC TFLY03E TFLY01S TFLY03P TFLY033
