TRUE PERFORMANCE 300, PERFORMANCE 100 User Manual

PERFORMANCE

100/300

TREADMILL

Model TPS100-17/TPS300-17 Version

072517

OWNER'S

MANUAL

* Assembly Guide & Warranty Card Included

PERFORMANCE 100/300 TREADMILL OWNER’S MANUAL

IMPORTANT: All Products shown are prototype. Actual product delivered may vary. Product specifications, features & software are subject to change without notice. For the most up-to-date owner's manual please visit www.truefitness.com. For documents in additional languages please visit www.truefitness.com/resources/document-library/

IMPORTANTE: Todos los productos mostrados son prototipos. La realidad el producto suministrado puede diferir. Especificaciones de productos, características y software están sujetas a cambios sin previo aviso. Para la más actualizada de este manual del propietario, por favor visite www.truefitness.com Para los documentos en otros idiomas, por favor visite www.truefitness.com/resources/document-library/

IMPORTANT: Tous les produits présentés sont prototype. Le produit réel livré peut varier. Spécifications du produit, caractéristiques et logiciels sont sujettes à modification sans préavis. Pour la plus à jour le manuel du propriétaire s’il vous plaît visitez www.truefitness.com. Pour documents dans des langues supplémentaires, veuillez www.truefitness.com/resources/document-library/ de visite

重要：显示所有产品均经过样机。交付可能会有所不同实际产品。产品规格，功能和软件如有更改，恕不另行通知。于大多数最新的用户手册，请访问对于其它语言的文档，请访问

www.truefitness.com

www

.tr

uefitnes

s.co

m/reso

urce s/documen

对

t-li

brary/

:مﺎﻫ

.ﻒﻟﺘﺨﺗ ﺪﻗ ﺎﻬﻣﻴﻟﺴﺗ ﻲﻟﻌﻔﻠا ﺞﺘﻨﻣﻠا . جذﻮﻣﻨﻠا ﻲﻫ ﺔﺿوﺮﻌﻣﻠا تﺎﺠﺘﻨﻣﻠا ﻊﻴﻣﺟ

ﺞﺘﻨﻣﻠا تﺎﻔﺻاﻮﻤ تاﺰﻴﻣﻠا و ﺞﻤاﺮﺒﻠا و ﺮﻴﻴﻐﺘﻟﻠ ﻊﻀﺨﺗ نود رﺎﻌﺷإ،

www.tr

ﻞﻟﻣﺴﺘﻧدﺎﺗ ﺐﻟﻏﺎﺗ ﺈﺿﺎﻔﻳة، يﺮ ﺠ ﯨ ﺰ ﻳار ة

WICHTIG: Alle hier gezeigten Produkte sind Prototypen. Das tatsächliche Produkt ausgeliefert wird, kann variieren. ProduktSpezifikationen, Funktionen und Software können sich ohne vorherige Ankündigung ändern. In den meisten Fällen bis zu Bedienungsanleitung Bisher besuchen Sie bitte www.truefitness.com. Für Dokumente in weiteren Sprachen finden Sie unter www.truefitness.com/resources/document-library/

BELANGRIJK: Alle getoonde producten zijn prototype. Daadwerkelijke product geleverd kan verschillen. Product specificaties, eigenschappen & software zijn onderhevig aan verandering zonder kennisgeving. Voor de meest actuele handleiding van de eigenaar kunt u terecht www.truefitness.com. Voor documenten in andere talen kunt u terecht op www.truefitness.com/resources/document-library/

ВАЖНО: Все товары указаны прототипа. Фактический продукт, поставляемый могут отличаться. характеристики, особенности и программного обеспечения могут быть изменены без предварительного уведомления. Для получения самой последней на сегодняшний день руководство по эксплуатации пожалуйста, посетите www. truefitness.com .Для документов на другие языки, пожалуйста, посетите www.truefitness.com/resources/document-library/

www.truefitness.com/resources/document-library/

uefitness.com ةرايز ىجري خيرات كلاملا ليلد ىلإ لصي ام مظعم ل

Технические

Truefitness.com / 800.426.6570 / 636.272.7100

Frank Trulaske began TRUE Fitness over thirty-five years ago with the simple philosophy of delivering superior fitness products, service and support. Today, TRUE is the global leader in premium fitness equipment for the commercial and residential markets. Our goal is to be the leader in technology, innovation, performance, safety and style. TRUE has received many awards for its products over the years and remains the benchmark for the industry. Fitness facilities and consumers invest in TRUE equipment for their durable commercial platforms, used in all its products, both commercial and residential alike.

The

proud manufacturing tradition of quality and the culture of innovation at TRUE have given rise to a full line of extraordinary cardio and strength equipment. As a result, people all over the world are benefiting from the TRUE experience. Innovation across the entire product line has made TRUE successful and is a trademark of the TRUE heritage. TRUE’s patented Heart Rate Control technology is just one of the remarkable ways we deliver simple and superior performance every user can enjoy, and most importantly, use to achieve personal health and fitness goals.

At th

e heart of our success is the relentless and systematic life testing of both our products and their components. We have

dedicated employees who understand our philosophy is to deliver the best products in the world.

goal is to deliver the world’s best premium equipment for our customers’ health and fitness solutions.

Our

Truefitness.com / 800.426.6570 / 636.272.7100

PERFORMANCE 100/300 TREADMILL OWNER’S MANUAL

TABLE OF CONTENTS:

Chapter 1: Safety Instructions

Safety Instructions Space Requirements……………………………..

Use of Safety Key……………………………… 4

Grounding Instructions………………………… Power Requirements……………………………. Warning Decals……………………………… 7

Chapter 2: Assembly Guide

Safety Instructions……………………………… Pre-Assembly Checklist………………………… Treadmill Assembly Steps……………………..

Chapter 3: Product Overview

Treadmill Overview……………………………

Chapter 4: Programming & Operation

Heart Rate Monitoring………………………… Heart Rate Control………………………….. 18 Program Descriptions…………………………. Console Overview…………………………….. 20 Console Navigation……………………………. User Profiles………………………………… 26 Creating And Managing A Workout………… Utility Functions……………………………….

…………………………….. 1

5 6

8 9

28 32

Chapter 5: Care & Maintenance

Care & Maintenance…………………………… Cleaning the Equipment……………………….. Running Belt Alignment……………………….. Tensioning the Running Belt…………………... Treadmill Lubrication………………………….. Leveling the Treadmill………………………….. Other Scheduled Preventive Maintenance…… 36 Long Term Storage……………………………...

Chapter 6: Customer Service

Contacting Service……………………………... Contacting Sales……………………………….. Reporting Freight Claims or Parts Damage……. 38

Chapter 7: Additional Information

Troubleshooting Guide……………………....…39

Warranty Registration………………………….

Product Specifications………………………….

Appendix A

The Wahoo RunFit App………………………

33 33 34 35 35 35

Truefitness.com / 800.426.6570 / 636.272.7100

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE SAFETY INSTRUCTIONS

This equipment is intended for a residential setting. This owner’s manual should be accessible to all family members and guests who may use this equipment.

WARNING:

ALL EXERCISERS MUST READ ALL INSTRUCTIONS BEFORE USING THE EQUIPMENT.

WARNING:

Heart rate monitoring systems may be inaccurate for some individuals. Over-exercising may result in serious injury or death. If you feel faint, stop exercising immediately.

WARNING:

Equipment should be immediately taken out of use if it fails to work properly or when a warning is presented electronically.

TRUE STRONGLY recommends seeing a physician for a complete medical exam before undertaking an exercise program, particularly if the user has a family history of high blood pressure or heart disease, is over the age of 45, smokes, has high cholesterol, is obese or has not exercised regularly in the past year. Additionally, TRUE recommends consulting a fitness professional on the correct use of this product. If at any time while exercising the user experiences faintness, dizziness, pain or shortness of breath, he or she must stop immediately.

WARNING:

To reduce the risk of electrical shock, always unplug this TRUE product before cleaning or attempting any maintenance activity. Do not handle the plug with wet hands.

WARNING:

To reduce the risk of burns, fire, electric shock or injury, it is imperative to connect each product to a properly grounded 110V electrical outlet. A risk of electrical shock may result from improper connection of the equipment’s grounding conductor. Check with a qualified electrician if you are unsure about proper grounding techniques. Do not modify the plug provided with this product. If it will not fit an electrical outlet, have a proper outlet installed by a qualified electrician. Your TRUE Fitness product must be properly grounded to reduce risk of shock if the equipment malfunctions. Your equipment is equipped with an electrical cord, which includes an equipment grounding conductor and a grounding plug. The plug must be inserted into an outlet that has been properly installed and grounded in accordance with all local codes and ordinances. A temporary adapter cannot be used to connect this plug to a two-pole receptacle in North America. If a properly grounded 15 amp outlet is not available, a qualified electrician must install one.

WARNING:

Do not move the equipment by lifting the console. Do not use the console as a handlebar during a workout.

WARNING:

This product contains chemicals known to the state of California to cause cancer and birth defects or other reproductive harm.

WARNING:

Keep equipment stable on flat ground.

Truefitness.com / 800.426.6570 / 636.272.7100

WARNING:

Replace warning labels that may be worn, damaged or missing.

WARNING:

Replace any non-working or damaged components; remove the unit from service until repair is performed.

WARNING:

To reduce the risk of burns, fire and electric shock or injury to persons, follow these instructions:

•

This appliance should never be left unattended when plugged in. Do not use any type of extension cord with this product. Unplug it from the outlet when not in use and before any servicing. Do not operate the equipment while being covered with a blanket, plastic, or anything that insulates or stops airflow.

WARNING:

Risk of personal injury-crushing hazard when equipment is in operation - Keep feet, hands, fingers away from moving parts.

CAUTION:

•

Health related injuries may result from incorrect or excessive use of exercise equipment.

Do not use typing or web surfing features at excessive speeds. Always stabilize yourself by holding a stationary handle

when using t yping or web surfing features (varies by console option).

Do not use the contact heart rate grips as a handlebar during a workout.

Any changes or modifications to this equipment could void the product warranty.

To disconnect, turn power OFF at the ON/OFF switch if applicable, then remove plug from electrical outlet.

Never operate a TRUE product if it has a damaged power cord or electrical plug, or if it has been dropped, damaged, or even partially immersed in water. Contact TRUE Customer Service for a replacement.

Use a TRUE AC power cord or AC/DC adapter only.

Note:

the plug configuration for the power adapter may vary by country.

Position this product so the power cord plug is accessible to the user.

Keep the power cord away from heated surfaces. Do not pull the equipment by the power cord or use the cord as a handle. Do not run the power cord along the side or under the equipment.

If the electrical supply cord is damaged it must be replaced by the manufacturer, an authorized service agent, or a similarly qualified person to avoid a hazard.

Do not use this product in areas where aerosol spray products are being used or where oxygen is being administered. Such substances create the danger of combustion and explosion.

Always follow the console instructions for proper operation.

Close supervision is necessary when used near children under the age of 15, or disabled persons.

Do not use this product outdoors, near water, while wet, or in areas of high humidity including extreme temperature changes.

Never operate a TRUE product with the air openings blocked. Keep air openings free of lint, hair or any other obstruction.

Never insert objects into any openings in this product. If an object should drop inside, turn off the power, unplug the power cord from the outlet and carefully retrieve it. If the item cannot be reached, contact TRUE Customer Service.

•

Never place liquids of any type directly on the unit except in the accessory tray or bottle holders. Containers with lids

are recommended

Truefitness.com / 800.426.6570 / 636.272.7100

CAUTION

•

Wear shoes with rubber or high traction soles. Do not use shoes with heels, leather soles, cleats or spikes. Make sure no stones are embedded in the soles. Do not use this product in bare feet. Keep all loose clothing, shoelaces and towels away from moving parts. Do not reach into or underneath the unit, or tip it on its side during operation. Use correct ergonomic positioning while running on equipment. Do not allow animals on or near the equipment while in operation. Use the side handrails whenever additional stability is required. In case of emergency, such as tripping, the side handrails should be grabbed and the user should place his/her feet on the side platforms. The front handle bars should be used to grasp the heart rate sensors or to rest the hand on while operating the activity zone keys, but not for stability, emergency, or continuous use. Do not exceed maximum user weight of 350 lbs (159 kg). Do not use if you have a cold or fever. When using this exercise machine, basic precautions should always be followed. Use this equipment only for its intended use as described in this manual. Do not use attachments not recommended by the manufacturer. Allow only trained personnel to service this equipment. Avoid the possibility of bystanders being struck or caught between moving parts by making sure they are out of reach of the equipment while it is in motion. This appliance can be used by children aged from 8 years and above and by persons with reduced physical, sensory or mental capabilities or by those who lack experience and knowledge of it's operation, if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. Allow only one person at a time on the equipment while it is operating. It is the sole responsibility of the owner/operator to ensure regular and scheduled maintenance is performed. To avoid injury stand on the side rails before starting the equipment. Avoid exiting equipment while leaving the tread belt in motion. Never walk or jog backwards on the equipment. Do not change the incline of the equipment by placing objects under it. To avoid serious injury, do not touch the incline rack while the equipment is in use. To avoid serious injury, do not touch the belt while the equipment is in use. Do not operate under blanket or pillow. Excessive heating can occur and cause fire, electric shock, or injury to persons. See Grounding Instructions (page 5). On the machine power switch, the “1” means that the machine power is switched “ON” and the “0” means the machine power is switched “ OFF”.

(CONTINUED)

CAUTION:

The Safety Key must be in place on the treadmill console, and should be attached to the user’s clothing. The treadmill will not operate if the safety key is not attached to the console.

Truefitness.com / 800.426.6570 / 636.272.7100

SPACE REQUIREMENTS:

1 Clothing

2 Clip 3

Console

TRUE’s recommendation is to leave a minimum of 20” (0.5m) on each side of the treadmill and a 79” (2 m) safety zone at the rear of the treadmill. (See Fig 1)

Fig. 1

USE OF SAFETY KEY (E-STOP):

•

Attach the safety clip to your clothing before each workout and when treadmill is in use. (See Fig. 2) Attach the magnetic key to the treadmill.

Fig. 2

Truefitness.com / 800.426.6570 / 636.272.7100

GROUNDING INSTRUCTIONS:

This product must be grounded, if it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped with a grounded cord having an equipmentgrounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.

DANGER:

•

Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check with a qualified electrician or serviceman if you are in doubt as to whether the product is properly grounded. Do not modify the plug provided with the product. If it will not fit the outlet, have a proper outlet installed by a qualified electrician. Do not remove the motor cover or you may risk injury due to electric shock. The 120-V model is for use on a nominal 120-V circuit and has a grounding plug that looks like the plug illustrated in figure A. Make sure the product is connected to an outlet having the same configuration as the plug. No adapter should be used with this product.

Truefitness.com / 800.426.6570 / 636.272.7100

WARNING DECALS:

WARNING:

Replace warning labels that may be worn, damaged or missing.

To replace any worn or missing warning decals contact TRUE Fitness by visiting www.truefitness.com or contact Customer Service at 800.883.8783 or email service@truefitness.com.

COMPLIANCES:

This equipment complies with all applicable codes and regulations. For a complete list of compliances, please visit www.truefitness.com

Truefitness.com / 800.426.6570 / 636.272.7100

CHAPTER 2: ASSEMBLY GUIDE

IMPORTANT SAFETY INSTRUCTIONS

Basic Guidelines for Setting up the Treadmill:

After removing the treadmill from the packaging, place your treadmill on a clean, level surface. Make sure the electrical cord easily reaches a grounded three-pronged outlet and has enough slack to allow the deck to incline without tightening the cord. Do not allow the treadmill assembly to rest on the cord.

Important Electrical Requirements – 115V:

Your TRUE treadmill requires a dedicated 115 to 120 volt, alternating current (AC), 15 amp grounded outlet circuit. This means nothing else can be plugged into the same circuit. Most power circuits are rated for this 115 to 120V AC 15 amp requirement. You must ensure the treadmill does not share the circuit with anything else.

DANGER:

Do not use an extension cord or ungrounded outlet:

The ground helps prevent electrical damage to your treadmill and enhances your safety by helping prevent shock. Check with a qualified electrician or serviceman if you are in doubt as to whether the treadmill is properly grounded. Do not modify the plug provided with the treadmill if it will not fit the outlet. Have a proper outlet installed by a qualified electrician.

Truefitness.com / 800.426.6570 / 636.272.7100

CHAPTER 2: ASSEMBLY GUIDE

PRE-ASSEMBLY CHECKLIST:

Item Description QTY:

Base

Console Assembly

Pedestal Upright (L)

Pedestal Upright (R)

Sport Bottle

Tablet Holder

Bolt Cover

Cable Cover

Hardware Pack

CAUTION:

• Use caution when assembling treadmill. Unpacking and assembling of this trea

Truefitness.com / 800.426.6570 / 636.272.7100

dmill is a two person task.

Chapter 2: Assembly Guide

Truefitness.com / 800.426.6570 / 636.272.7100

CHAPTER 2: ASSEMBLY GUIDE

TREADMILL ASSEMBLY STEPS:

STEP 1 Remove Motor Cover:

Remove the nine (9) screws securing the motor cover to the treadmill frame.

Remove the motor cover and set to the side.

STEP 2 Install Pedestal Uprights:

Slide the left and right pedestal uprights into place.

*DO NOT PINCH THE CABLES

Install four (4) bolts and washers into e

ach pedestal, but do not fully tighten .

Truefitness.com / 800.426.6570 / 636.272.7100

CHAPTER 2: ASSEMBLY GUIDE

TREADMILL ASSEMBLY STEPS (CONTINUED):

STEP 3 Lower Data Cable:

) Connect the data cable coming from the bottom

of the left pedestal upright to the lower control board as shown.

STEP 4 Console Assembly:

Place the console assembly on the pedestal uprights and secure with four (4) bolts.

Attach the left and right bolt covers by snapping them into place.

Truefitness.com / 800.426.6570 / 636.272.7100

CHAPTER 2: ASSEMBLY GUIDE

TREADMILL ASSEMBLY STEPS (CONTINUED):

STEP 5 Data Cable & Cable Cover:

Connect the lower control wire coming out of left upright with the upper control wire attached in the console.

Install the wire cover with two (2) bolts to the upper console cover.

STEP 6 Secure Pedestal Uprights:

Fully tighten the eight (8) bolts from Step 2.

b) Tighten the hex head bolt on the front of each pedestal

upright and then tighten the nut.

Truefitness.com / 800.426.6570 / 636.272.7100

CHAPTER 2: ASSEMBLY GUIDE

TREADMILL ASSEMBLY STEPS (CONTINUED):

STEP 7 Re-Install Motor Cover:

) Re-install the motor cover as shown.

STEP 8 Tablet Holder:

Slide the tablet holder into the slots on the back of

the console assembly.

b) Secure the tablet holder with two (2) screws.

Truefitness.com / 800.426.6570 / 636.272.7100
