TM
T
Installation and Operation Manual
RI
S
TAR MPPT
Solar System Controller
TrakStarTM Maximum Power Point Tracking Technology
MAXIMUM POWER POINT TRACKING
Solar Battery Charger
with
8 Pheasant Run
Newtown, PA 18940 USA
email: info@morningstarcorp.com
www.morningstarcorp.com
Models
TS-MPPT-60
TS-MPPT-45
Dimensions in Inches [Millimeters]
Contents
1.0 Important Safety Information 4
2.0 Getting Started 8
2.1 Overview 8
2.2 Versions and Ratings 8
2.3 Features 9
2.4 Regulatory Information 11
2.5 Optional Accessories 12
3.0 Installation 13
3.1 General Information 13
3.2 Controller Installation 15
4.0 Operation 30
4.1 TrakStarTM MPPT Technology 30
4.2 Battery Charging Information 32
4.3 Push button 40
4.4 LED Indications 41
4.5 Protections, Faults & Alarms 43
4.6 Inspection and Maintenance 46
5.0 Networking and Communication 47
5.1 Introduction 47
5.2 Morningstar MeterBus
5.3 Serial RS-232 49
5.4 EIA-485 (formerly RS-485) 51
5.5 Ethernet 52
TM
48
6.0 Troubleshooting 55
7.0 Warranty 57
8.0 Specifi cations 58
1.0 Important Safety Information
Save These Instructions
This manual contains important safety, installation and operating instructions for the
TriStar MPPT solar controller.
The following symbols are used throughout this manual to indicate potentially dangerous conditions or mark important safety instructions:
WARNING:
Indicates a potentially dangerous condition. Use extreme caution when performing
this task.
CAUTION:
!
Indicates a critical procedure for safe and proper operation of the controller.
NOTE:
Indicates a procedure or function that is important for the safe and proper operation
of the controller.
AVERTISSEMENT :
Indique une condition potentiellement dangereuse. Faites preuve d’une prudence
extrême lors de la réalisation de cette tâche.
PRUDENCE :
!
Indique une procédure critique pour l’utilisation sûre et correcte du contrôleur.
REMARQUE :
Indique une procédure ou fonction importante pour l’utilisation sûre et correcte du
contrôleur.
Safety Information
• Read all of the instructions and cautions in the manual before beginning installation.
• There are no user serviceable parts inside the TriStar MPPT. Do not disassemble or attempt to repair the controller.
• Disconnect all sources of power to the controller before installing or adjusting the
TriStar MPPT.
• There are no fuses or disconnects inside the TriStar MPPT. Do not attempt to repair.
• Install external fuses/breakers as required.
Informations de sécurité
• Lisez toutes les instructions et les avertissements fi gurant dans le manuel avant de com-
mencer l’installation.
• Le TriStar MPPT ne contient aucune pièce réparable par l’utilisateur. Ne démontez pas ni
ne tentez de réparer le contrôleur.
• Déconnectez toutes les sources d’alimentation du contrôleur avant d’installer ou de régler
le TriStar MPPT.
• Le TriStar MPPT ne contient aucun fusible ou interrupteur. Ne tentez pas de réparer.
• Installez des fusibles/coupe-circuits externes selon le besoin.
4 Important Safety Information
Installation Safety Precautions
WARNING:
This unit is not provided with a GFDI device. This charge controller must be used with an
external GFDI device as required by the Article 690 of the National Electrical Code for
the installation location.
• Mount the TriStar MPPT indoors. Prevent exposure to the elements and do not allow water to enter the controller.
• Use insulated tools when working with batteries.
• Avoid wearing jewelry during installation.
• The battery bank must be comprised of batteries of same type, make, and age.
• Do not smoke in the vicinity of the battery bank.
• Power connections must remain tight to avoid excessive heating from a loose connection.
• Use properly sized conductors and circuit interrupters.
• The grounding terminal is located in the wiring compartment and is identifi ed by the sym-
bol below.
Ground Symbol
• This charge controller is to be connected to DC circuits only. These DC connections are
identifi ed by the symbol below.
Direct Current Symbol
5TriStar MPPT Operator’s Manual
AVERTISSEMENT :
L’appareil n’est pas fourni avec un dispositif GFDI. Ce contrôleur de charge doit être
utilisé avec un dispositif GFDI externe tel que requis par l’Article 690 du Code électrique
national de l’emplacement de l’installation.
• Montez le TriStar MPPT à l’intérieur. Empêchez l’exposition aux éléments et la pénétration
d’eau dans le contrôleur.
• Utilisez des outils isolés pour travailler avec les batteries.
• Évitez le port de bijoux pendant l’installation.
• Le groupe de batteries doit être constitué de batteries du même type, fabricant et âge.
• Ne fumez pas à proximité du groupe de batteries.
• Les connexions d’alimentation doivent rester serrées pour éviter une surchauffe excessive
d’une connexion desserrée.
• Utilisez des conducteurs et des coupe-circuits de dimensions adaptées.
• La borne de mise à la terre se trouve dans le compartiment de câblage et est identifi ée
par le symbole ci-dessous.
• Ce contrôleur de charge ne doit être connecté qu’à des circuits en courant continu. Ces
connexions CC sont identifi ées par le symbole ci-dessous.
Le contrôleur TriStar MPPT doit être installé par un technicien qualifi é conformément aux règle-
mentations électriques du pays où est installé le produit.
Un moyen d’assurer la déconnexion de tous les pôles de l’alimentation doit être fourni. Cette
déconnexion doit être incorporée dans le câblage fi xe.
À l’aide de la borne de mise à la masse du TriStar MPPT (dans le compartiment de câblage), un
moyen permanent et fi able de mise à la terre doit être fourni. La fi xation de la mise à la terre doit
être fi xée contre tout desserrage accidentel.
Les ouvertures d’entrée au compartiment de câblage du TriStar MPPT doivent être protégées
avec un conduit ou une bague.
6
Important Safety Information
About this Manual
This manual provides detailed installation and usage instructions for the TriStar MPPT controller.
Only qualifi ed electricians and technicians who are familiar with solar system design and wiring
practices should install the TriStar MPPT. The usage information in this manual is intended for
the system owner/operator.
7TriStar MPPT Operator’s Manual
Getting Started2.0
2.1 Overview
Thank you for selecting the TriStar MPPT solar charge controller with TrakStarTM MPPT Technology. The TriStar MPPT (TS-MPPT) is an advanced maximum power point tracking solar battery
charger. The controller features a smart tracking algorithm that fi nds and maintains operation at
the solar array peak power point, maximizing energy harvest.
The TriStar MPPT battery charging process has been optimized for long battery life and improved system performance. Self-diagnostics and electronic error protections prevent damage
when installation mistakes or system faults occur. The controller also features eight (8) adjustable
settings switches, several communication ports, and terminals for remote battery temperature
and voltage measurement.
Please take the time to read this operator’s manual and become familiar with the controller. This
will help you make full use of the many advantages the TriStar MPPT can provide for your PV
system.
2.2 Versions and Ratings
There are two versions of TriStar MPPT controllers.
TriStar-MPPT-45
• maximum 45 amps continuous battery current
• 12, 24, 36, and 48 Volt dc systems
• maximum 150 Volt dc solar input voltage
• RS-232 and MeterBus
TriStar-MPPT-60
• maximum 60 amps continuous battery current
• 12, 24, 36, and 48 Volt dc systems
• maximum 150 Volt dc solar input voltage
• RS-232, EIA-485, MeterBus
To comply with the National Electric Code (NEC), the current rating of the controller must be
equal to or greater than 125% of the solar array’s short circuit current output (Isc). Therefore, the
maximum allowable solar array input to the TriStar MPPT controller for compliance with the NEC
is:
TS-MPPT-45: 36 amps Isc*
TS-MPPT-60: 48 amps Isc*
TM
communication ports
TM
, and Ethernet communication ports
*Solar array Isc @ STC
8TriStar MPPT Operator’s Manual
2.3 Features
The features of the TriStar MPPT are shown in Figure 2-1 below. An explanation of each feature
is provided.
Figure 2-1. TriStar MPPT features
9TriStar MPPT Operator’s Manual
1 - Heatsink
Aluminum heatsink to dissipate controller heat
2 - Mounting Hanger
Keyhole slot for mounting
3 - Settings Switches
Eight (8) settings switches to confi gure operation of the TriStar MPPT
4 - Battery Positive Terminal (red)
Power connection for Battery (+)
5 - Remote Temperature Sensor Terminals
Connection point for a Morningstar RTS (optional) to remotely monitor battery temperature
6 - LED Indicators
Three state of charge (SOC) LED indicators show charging status and controller faults
7 - MeterBusTM Port
RJ-11 socket for Morningstar MeterBusTM network connections
8 - Battery Voltage Sense Terminals
Terminals for battery voltage input provide accurate battery voltage measurement
9 - Ground Terminal
A chassis ground terminal for system grounding
10 - Ethernet Port
RJ-45 socket for LAN/internet connections (TS-MPPT-60 model only)
11 - Wiring Box with Conduit Knockouts
Termination points for wiring conduit and wire glands
12 - Wiring Box Cover
Sheet metal wiring box cover protects power connections
13 - Serial RS-232 Port
9-pin serial connector (female)
14 - EIA-485 Port
Four (4) position screw terminal for EIA-485 bus connections (TS-MPPT-60 model only)
15 - Solar Positive Terminal (yellow)
Power connection for Solar (+)
16 - Common Negative Power Terminals
Two (2) negative terminals for negative system cable termination
17 - Push-button Switch
Manually reset from an error or fault, also used to start/stop a manual equalization.
10
Getting Started
2.4 Regulatory Information
NOTE:
This section contains important information for safety and
regulatory requirements.
The TriStar MPPT controller should be installed by a qualifi ed technician according to the electri-
cal rules of the country in which the product will be installed.
TriStar MPPT controllers comply with the following EMC standards:
• Immunity: EN61000-6-2:1999
• Emissions: EN55022:1994 with A1 and A3 Class B1
• Safety: EN60335-1 and EN60335-2-29 (battery chargers)
A means shall be provided to ensure all pole disconnection from the power supply. This disconnection shall be incorporated in the fi xed wiring.
Using the TriStar MPPT grounding terminal (in the wiring compartment), a permanent and reliable means for grounding shall be provided. The clamping of the earthing shall be secured
against accidental loosening.
The entry openings to the TriStar MPPT wiring compartment shall be protected with conduit or
with a bushing.
FCC requirements:
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Changes or modifi cations not expressly approved by Morningstar for compliance could void the user’s authority to
operate the equipment.
Note:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio communication. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment on and off, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numerique de la classe B est conforme a la norme NMB-003 du Canada.
11TriStar MPPT Operator’s Manual
2.5 Optional Accessories
The following accessories are available for purchase separately from your authorized Morningstar dealer.
TriStar Digital Meter 2 / TriStar Remote Meter 2 (Models: TS-M-2 / TS-RM-2)
The TriStar Digital Meter mounts directly on the TS-MPPT controller, replacing the wiring box
cover. The TriStar Remote Meter can be fl ush mounted in a wall or into a standard duplex (2-
gang) electrical box. A 2 x 16 character display shows system operating information, error indications, and self-diagnostic information. Four (4) buttons make navigating the meter menus easy.
For systems where multiple TS-MPPT controllers are networked together, one (1) meter can
display full system information. The TriStar meters connect to the RJ- 11 MeterBusTM port on the
TriStar-MPPT.
Meter Hub (HUB-1)
A Morningstar MeterBusTM network with multiple controllers requires a Meter Hub for electrical
isolation. The HUB-1 allows communication between MeterBusTM compatible Morningstar products, including the TriStar MPPT controller. DIN rail compatible. See section 5.2 for more details.
Relay Driver (RD-1)
The Relay DriverTM accessory enables the TriStar MPPT to control external devices. Four (4)
relay control ports can be confi gured (in various combinations) to perform the following tasks:
• generator control (2-, 3-, and 4-wire confi gurations)
• dry contacts for alarms and other signals
• advanced load control
• vent fan control
• DIN rail compatible or surface mount
For more information on the Relay Driver, visit our website at www.morningstarcorp.com or inquire with your local Morningstar dealer.
EIA-485 / RS-232 Communications Adapter (RSC-1)
Connect one or more TriStar MPPT controllers to a PC or to other serial devices using the RSC-1
EIA-485 adapter. The adapter converts an RS-232 serial interface to EIA-485 compliant signals.
An LED shows network activity and errors. DIN rail compatible.
12
Getting Started
Installation3.0
3.1 General Information
The mounting location is important to the performance and operating life of the controller. The
environment must be dry and protected from water ingress. If required, the controller may be installed in a ventilated enclosure with suffi cient air fl ow. Never install the TriStar MPPT in a sealed
enclosure. The controller may be mounted in an enclosure with sealed batteries, but never
with vented/fl ooded batteries. Battery fumes from vented batteries will corrode and destroy the
TriStar MPPT circuits.
Multiple TriStars can be installed in parallel on the same battery bank to achieve higher charging
current. Additional parallel controllers can also be added in the future. Each TriStar MPPT must
have its own solar array.
CAUTION: Equipment Damage or Risk of Explosion
Never install the TriStar MPPT in an enclosure with vented/fl ooded batteries. Battery
!
fumes are fl ammable and will corrode and destroy the TriStar MPPT circuits.
CAUTION: Equipment Damage
When installing the TriStar MPPT in an enclosure, ensure suffi cient ventilation.
!
Installation in a sealed enclosure will lead to over-heating and a decreased product
lifetime.
PRUDENCE : Endommagement de l’équipement ou risque d’explosion
N’installez jamais le TriStar MPPT dans une enceinte avec des batteries à évent/à
!
électrolyte liquide. Les vapeurs des batteries sont infl ammables et corroderont et
détruiront les circuits du TriStar MPPT.
PRUDENCE : Endommagement de l’équipement
Assurez une ventilation suffi sante en cas d’installation du TriStar MPPT dans une
!
enceinte. L’installation dans une enceinte hermétique entraîne une surchauffe et une
réduction de la durée de vie du produit.
The installation is straightforward, but it is important each step is done correctly and safely. A
mistake can lead to dangerous voltage and current levels. Be sure to carefully follow each instruction in this section. Read all instructions fi rst before beginning installation.
The installation instructions are for installation of a negative grounded system. National Electrical
Code (NEC) requirements are noted on occasion for convenience, however the installer should
have a complete understanding of NEC and UL requirements for photovoltaic installations.
13 Installation
Recommended Tools:
• Wire strippers
• Wire cutters
• #2 & #0 Phillips screwdriver
• slotted screwdrivers
• Pliers
• Drill
• 3/32” (2.5 mm) drill bit
• Level
• hack saw (cutting conduit)
14
Installation
3.2 Controller Installation
Step 1 - Remove the wiring box cover
CAUTION: Shock Hazard
Disconnect all power sources to the controller before removing the wiring box cover. Never
!
remove the cover when voltage exists on any of the TriStar MPPT power connections.
PRUDENCE : Risque de décharge électrique
Déconnectez toutes les sources d’alimentation du contrôleur avant d’enlever le couvercle
!
du boîtier de câblage. Ne retirez jamais le couvercle en présence de tension sur une des
connexions d’alimentation du TriStar MPPT.
Use a #2 Phillips screw driver to remove the four (4) screws that secure the wiring box cover as
shown in fi gure 3-1 below.
Figure 3-1. Remove the wiring box cover.
If a TriStar Digital Meter 2 display is installed, be sure to disconnect the RJ-11 cable.
15TriStar MPPT Operator’s Manual
Step 2 - Remove the knockouts
Knockouts are provided for routing cables through conduit or wire glands. Table 3-1 below provides the knockout sizes and quantity on the TriStar MPPT wiring box. Knockout locations and
dimensions are on the inside front cover.
Quantity Trade Size Hole Dimension
8 1/2” or M20 7/8” (22.2 mm)
6 1 “ 1 - 23/64 “ (34.5 mm)
4 1 - 1/4 “ 1 - 23/32 “ (43.7 mm)
Table 3-1. Knockout sizes
CAUTION: Shock Hazard
Always use bushings, connectors, clamp connectors, or wire glands in the knockout openings to
!
protect wiring from sharp edges.
PRUDENCE : Risque de décharge électrique
Utilisez toujours des bagues, des connecteurs, des raccordements à collets ou des fouloirs dans
!
les ouvertures afi n de protéger le câblage des bords coupants.
CAUTION: Shock Hazard
!
Never route network cables in the same conduit as the power conductors.
PRUDENCE : Risque de décharge électrique
N’acheminez jamais les câbles réseau dans le même conduit que les conducteurs
!
d’alimentation.
Plan the routing of each conductor that will connect to the TriStar MPPT before removing any
knockouts. The 1/2” (M20) knockouts are ideal for routing network cables, which must be placed
in separate conduit.
16
Installation
Step 3 - Mount to a Vertical Surface
Figure 3-2. Attaching the mounting hanger
1. Attach the mounting hanger to the bottom of the TriStar MPPT with the M6 screw provided as
shown in fi gure 3-2.
2. Place the TriStar MPPT on a vertical surface protected from direct sun, high temperatures,
and water. The TriStar MPPT requires at least 6” (150 mm) of clearance above and below
and at least 1” (25 mm) on each side for proper air fl ow as shown in fi gure 3-3 below.
Figure 3-3. Required mounting clearance for air fl ow.
3. Place a mark on the mounting surface at the top of the keyhole.
4. Remove the controller and drill a 3/32” (2.5 mm) hole at the drill mark.
5. Insert a #10 screw (included) into the top pilot hole. Do not tighten the screw completely.
Leave a 1/4” (6 mm) gap between the mounting surface and screw head.
17TriStar MPPT Operator’s Manual
6. Carefully align the keyhole on the TriStar MPPT with the screw head. Slide the TriStar MPPT
down over the keyhole.
7. Check for vertical plumb with a level.
8. Mark two (2) mounting hole locations in the wiring box.
9. Remove the controller and drill 3/32” (2.5 mm) holes at the drill marks.
10. Carefully align the keyhole on the TriStar MPPT with the screw head. Slide the TriStar MPPT
down over the keyhole.
11. The pre-drilled pilot holes should align with the mounting holes in the wiring box. Secure the
controller with two (2) #10 mounting screws.
12. Tighten the keyhole screw.
Step 4 - Adjust Settings Switches
Switch 1: Reserved for Future Use
Settings switch 1 should remain in the “OFF” position.
Mode Switch 1
Solar Charging OFF
future use ON
Switches 2 & 3: System Voltage
Four (4) system voltage confi gurations are available as shown in the table below:
System Voltage Switch 2 Switch 3
Auto OFF OFF
12 OFF ON
24 ON OFF
48 ON ON
The “auto” setting allows the TriStar MPPT to detect the system voltage automatically on start up.
The test is only performed at start up and the detected system voltage will never change during
operation.
Generally, it is best to choose a specifi c system voltage. The auto detect feature should only be
used in situations where the system voltage is unknown ahead of time or in systems where the
system voltage may change periodically.
18
Installation
Switches 4, 5, & 6: Battery Charging Settings
It is important to select the battery type that matches the system battery to ensure proper charging and long battery life. Refer to the specifi cations provided by the battery manufacturer and
choose a setting that best fi ts the recommended charging profi le.
Settings
Switches
4 - 5 - 6
off-off-off 1 - Gel 14.00 13.70
off-off-on 2 - Sealed* 14.15 13.70 14.40 28
off-on-off 3 - Sealed* 14.30 13.70 14.60 28
off-on-on 4 - AGM/Flooded 14.40 13.70 15.10 28
on-off-off 5 - Flooded 14.60 13.50 15.30 28
on-off-on 6 - Flooded 14.70 13.50 15.40 28
on-on-off 7 - L-16 15.40 13.40 16.00 14
on-on-on 8 - Custom Custom Custom Custom Custom
* “Sealed” battery type includes gel and AGM batteries
Battery
Type
Absorp.
Stage
(Volts)
Float
Stage
(Volts)
Equalize
Stage
(Volts)
Equalize
Interval
(Days)
All settings are for 12 Volt nominal systems. Multiply the charge voltage settings by 2 for 24 Volt
systems or by 4 for 48 Volt systems. A description of each setting is provided below. See section 4.3 for full details on battery charging and a description of each of the settings in the battery
charging table.
Battery Type - The most common battery type associated with the specifi ed charging settings.
Absorption Stage - This stage limits input current so that the Absorption voltage is maintained.
As the battery becomes more charged, the charging current continues to taper down until the
battery is fully charged.
Float Stage - When the battery is fully charged, the charging voltage will be reduced to the Float
voltage setting.
Equalize Stage - During an equalization cycle, the charging voltage will be held constant at the
specifi ed voltage setting.
Equalize Interval - The number of days between equalization charges when the controller is confi gured for automatic equalizations (settings switch 7).
Switch 7: Battery Equalization
Choose between manual and automatic battery equalization charging. In the manual equalization setting, an equalization will only occur when manually started with the pushbutton or when
requested from the equalize menu on the TriStar meter. Automatic equalization will occur according to the battery program specifi ed by settings switches 4, 5, & 6 in the previous step.
In both settings (auto and manual), the pushbutton can be used to start and stop battery equalization. If the selected battery charging setting does not have an equalization stage an equalization will never occur, even if requested manually.
19TriStar MPPT Operator’s Manual
Equalize Switch 7
manual OFF
automatic ON
Switch 8: Ethernet Security
The Ethernet Security switch enables or disables confi guration of the TriStar MPPT settings
through the Ethernet connection. When switch eight is set to disabled, write commands to the
TriStar MPPT custom memory are not allowed. This a safety feature to prevent unintended
changes to custom settings, but it is not a replacement for proper network security.
Confi guration via TCP/IP Switch 8
disabled OFF
enabled ON
NOTE:
Adjustment of network settings and custom setpoints is always enabled via the RS-232 and EIA485 connections. The Ethernet Security switch only enables/disables remote confi guration via
TCP/IP.
CAUTION: Risk of Tampering
The Ethernet Security settings switch does not block write commands to devices bridged via EIA-
!
485.
REMARQUE :
Le réglage des paramètres de réseau et des points de consignes personnalisés est toujours
activé par les connexions RS-232 et EIA-485. Le contacteur de sécurité Ethernet n’active/
désactive que la confi guration à distance par TCP/IP.
PRUDENCE : Risque de tentative d’altération
Le contacteur des paramètres de sécurité Ethernet ne bloque pas les commandes d’écriture sur
!
les dispositifs reliés par EIA-485.
20
Installation
Step 5 - Remote Temperature Sensor
The included Remote Temperature Sensor (RTS) is recommended for effective temperature compensated charging. Connect the RTS to the 2-position terminal located between the pushbutton and the LED’s (see fi gure 2-1). The RTS is supplied with 33 ft (10 m) of 22 AWG (0.34 mm2)
cable. There is no polarity, so either wire (+ or -) can be connected to either screw terminal. The
RTS cable may be pulled through conduit along with the power wires. Tighten the connector
screws to 5 in-lb (0.56 Nm) of torque. Separate installation instructions are provided inside the
RTS bag.
CAUTION:
!
The TriStar MPPT will not temperature compensate charging parameters if the RTS is not used.
CAUTION: Equipment Damage
Never place the temperature sensor inside a battery cell. Both the RTS and the battery will be
!
damaged.
NOTE:
The RTS cable may be shortened if the full length is not needed. Be sure to reinstall the ferrite
choke on the end of the RTS if a length of cable is removed. This choke ensures compliance with
electromagnetic emissions standards.
PRUDENCE :
Le TriStar MPPT ne compense pas la température des paramètres de charges si le RTS n’est
!
pas utilisé.
PRUDENCE : Endommagement de l’équipement
Ne placez jamais la sonde de température dans un élément de batterie. Le RTS et la batterie
!
seraient endommagés.
REMARQUE :
Le câble de RTS peut être raccourci si la totalité de la longueur n’est pas nécessaire. Assurezvous de réinstaller la bobine en ferrite sur l’extrémité du RTS si une longueur de câble est
enlevée. Cette bobine assure la conformité avec les normes d’émissions électromagnétiques.
21TriStar MPPT Operator’s Manual
Step 6 - Grounding and Ground Fault Interruption
WARNING:
This unit is not provided with a GFDI device. This charge controller must be used with an
external GFDI device as required by the Article 690 of the National Electrical Code for
the installation location.
NOTE:
Conductors identifi ed by the color combination green/yellow shall only be used for earthing
conductors.
AVERTISSEMENT :
L’appareil n’est pas fourni avec un dispositif GFDI. Ce contrôleur de charge doit être
utilisé avec un dispositif GFDI externe tel que requis par l’Article 690 du Code électrique
national de la région de l’installation.
Use a copper wire to connect the grounding terminal in the wiring box to earth ground. The
grounding terminal is identifi ed by the ground symbol shown below that is stamped into the wiring
box just below the terminal:
Figure 3-4. Ground Symbol
Do not connect the system negative conductor to this terminal. NEC requires the use of an external ground fault protection device (GFPD). The TriStar MPPT does not have internal ground fault
protection. The system electrical negative should be bonded through a GFPD to earth ground at
one (and only one) location. The grounding point may be located in the solar circuit or the battery
circuit.
The minimum size of the copper grounding wire:
• TS-MPPT-45 10 AWG (6 mm2)
2
• TS-MPPT-60 8 AWG (10 mm
WARNING: Risk of Fire
DO NOT bond system electrical negative to earth ground at the controller. Per NEC
requirements, system negative must be bonded to earth ground through a GFPD at only
one point.
AVERTISSEMENT : Risque d’incendie
NE LIEZ PAS le côté négatif du système à la mise à la terre au niveau du contrôleur.
Selon les exigences du CNE, le côté négatif du système doit être mis à la terre par un
GFPD à un seul point.
)
22
Installation
Step 7 - Battery Voltage Sense
The voltage at the battery connection on the TriStar MPPT may differ slightly from the voltage di-
rectly at the battery bank terminals due to connection and cable resistance. The Battery Voltage
Sense connection enables the TriStar MPPT to measure the battery terminal voltage precisely
with small gauge wires that carry very little current, and thus have no voltage drop. Both battery
voltage sense wires are connected to the TriStar at the 2-position terminal located between the
pushbutton and the positive (+) terminal lug (see fi gure 2-1).
A battery voltage sense connection is not required to operate your TriStar MPPT controller, but it
is recommended for best performance. If a TriStar meter will be added to the controller, the battery voltage sense will ensure that the voltage and diagnostic displays are very accurate.
The voltage sense wires should be cut to length as required to connect the battery to the voltage
sense terminal. The wire size can range from 16 to 24 AWG (1.0 to 0.25 mm2). A twisted pair
cable is recommended but not required. Use UL rated 300 Volt conductors. The voltage sense
wires may be pulled through conduit with the power conductors. Tighten the connector screws to
5 in-lb (0.56 Nm) of torque.
The maximum length allowed for each battery voltage sense wire is 98 ft (30 m).
Be careful to connect the battery positive (+) terminal to the voltage sense positive (+) terminal.
No damage will occur if the polarity is reversed, but the controller cannot read a reversed sense
voltage. Connecting the voltage sense wires to the RTS terminal will cause an alarm.
If a TriStar meter is installed, check the “TriStar Settings” to confi rm the Voltage Sense and the
RTS (if installed) are both present and detected by the controller. MSViewTM PC software can
also be used to confi rm the voltage sense is working correctly.
Step 8 - Network Connections
Network connections allow the TriStar MPPT to communicate with other controller or computers.
A network can be as simple as one controller and one PC, or as complex as dozens of controllers monitored via the internet. Review section 5.0 for more information about networking and the
connection(s) required for your system.
WARNING: Shock Hazard
Never route network cables in the same conduit as the power conductors.
WARNING: Shock Hazard
Only use 300 Volt UL rated communication cable.
AVERTISSEMENT : Risque de décharge électrique
N’acheminez jamais les câbles réseau dans le même conduit que les conducteurs
d’alimentation.
23TriStar MPPT Operator’s Manual
AVERTISSEMENT : Risque de décharge électrique
N’utilisez qu’un câble de communication 300 V homologué UL.
Connect the appropriate network cables to the TriStar MPPT at this time. Access to the network
ports is easier before the power cables are attached. The ports are located inside the conduit wiring box on the lower circuit board as shown in fi gure 3-5.
Figure 3-5. TriStar MPPT network port locations
EIA-485 Connection
The four (4) position EIA-485 connector on the TriStar MPPT must be removed to access the
terminal screws. Remove the socket connector by fi rmly grasping the connector body and pulling
away from the circuit board as shown in fi gure 3-6.
Figure 3-6. Removing the RS-485 socket connector
24
Installation
RS-232 Connection
The serial RS-232 port is a standard 9-pin (DB9) female connector. A low-profi le serial connector
is recommended to save room in the wiring box.
NOTE:
The RS-232 and EIA-485 ports share hardware. Both ports cannot be used simultaneously.
REMARQUE :
Les ports RS-232 et EIA-485 partagent le matériel. Ils ne peuvent pas être utilisés simultanément.
Ethernet Connection
The RJ-45 Ethernet jack features two (2) indicator LEDs for connection status and network traffi c. Use CAT-5 or CAT-5e twisted pair cable and RJ-45 plugs. If possible, pull the network cable
through conduit before crimping on the RJ-45 connectors. If using pre-assembled cables, take
care not to damage the plugs when the cables are pulled through conduit.
MeterBus
MeterBus
TM
Connection
TM
networks use standard 4-wire or 6-wire RJ-11 telephone cables. If possible, pull the
telephone cable through conduit before crimping on the RJ-11 connectors. If using pre-assembled cables, take care not to damage the plugs when the cables are pulled through conduit.
25TriStar MPPT Operator’s Manual
Step 9 - Power Connections
NOTE:
To comply with the NEC, the TriStar MPPT must be installed using wiring methods in accordance
with the latest edition of the National Electric Code, NFPA 70.
CAUTION: Risk of Fire and Shock
Connect battery terminals prior to the connection of array terminals. The battery positive (+)
!
terminal has a red cover, the solar positive (+) terminal has a yellow cover.
REMARQUE :
Pour la conformité CNE, le TriStar MPPT doit être installé selon des méthodes de câblage
conformes à la dernière édition du Code électrique national, NFPA 70.
PRUDENCE : Risque d’incendie et de décharge électrique
Branchez les bornes de la batterie avant la connexion des bornes de réseau. La borne positive
!
(+) de la batterie a un capuchon rouge, la borne positive (+) solaire a un capuchon jaune.
Wire Size
The four large power terminals are sized for 14 - 2 AWG (2.5 - 35 mm
rated for copper and aluminum conductors. Use UL-listed Class B 300 Volt stranded wire only.
Good system design generally requires large conductor wires for the solar and battery connections that limit voltage drop losses to 2% or less. The wire tables in the appendix on pages
51-54 provide wire sizing information for connecting the solar array and battery bank to the
TriStar MPPT with a maximum of 2% voltage drop.
2
) wire. The terminals are
Minimum Wire Size
The NEC requires that the wires carrying the system current never exceed 80% of the conductors current rating. The table below provides the minimum size of copper wire allowed by NEC
for both TriStar MPPT models when the current equals the full nameplate rating (45 Amps or 60
Amps). Wire types rated for 75°C and 90°C are included.
Minimum wire sizes for ambient temperatures to 45°C are provided in table 3-2 below:
Model Wire Type 75°C Wire 90°C Wire
TS-MPPT-45 Copper 6 AWG (16 mm
TS-MPPT-45 Aluminum 4 AWG (25 mm2) 6 AWG (16 mm2)
TS-MPPT-60 Copper 4 AWG (25 mm2) 6 AWG (16 mm2)
TS-MPPT-60 Aluminum 2 AWG (35 mm2) 4 AWG (25 mm2)
Table 3-2 Minimum wire sizes
2
) 8 AWG (10 mm2)
26
Installation
Overcurrent Protection and Disconnects
WARNING: Shock Hazard
Fuses, circuit breakers, and disconnect switches should never
open grounded system conductors. Only GFDI devices are
permitted to disconnect grounded conductors.
AVERTISSEMENT : Risque de décharge électrique
Les fusibles, coupe-circuits et interrupteurs ne doivent jamais
ouvrir les conducteurs du système mis à la terre. Seuls les
dispositifs GFDI sont autorisés à déconnecter les conducteurs
reliés mis à la terre.
Circuit breakers or fuses must be installed in both the battery and solar circuits. The protection
device ratings and installation methods must conform to NEC requirements.
The battery circuit fuse or circuit breaker must be rated to 125% of the maximum current or more.
The minimum fuse/breaker rating allowed for use with each TriStar MPPT model is listed in table
3-3.
Model Minimum battery circuit fuse/breaker rating
TS-MPPT-45 1.25 x 45 Amps = 56.3 Amps
TS-MPPT-60 1.25 x 60 Amps = 75.0 Amps
Table 3-3 Minimum battery circuit fuse/breaker ratings per NEC requirements
A disconnect is required for the battery and solar circuits to provide a means for removing power
from the TriStar MPPT. Double pole switches or breakers are convenient for disconnecting both
solar and battery conductors simultaneously.
Connect the Power Wires
WARNING: Shock Hazard
The solar PV array can produce open-circuit voltages in excess of 100 Vdc when
in sunlight. Verify that the solar input breaker or disconnect has been opened
(disconnected) before installing the system wires.
AVERTISSEMENT : Risque de décharge électrique
Le réseau PV solaire peut produire des tensions de circuit ouvert supérieures à 100 V cc
à la lumière du soleil. Vérifi ez que le coupe-circuit ou l’interrupteur d’entrée solaire a été
ouvert (déconnexion) avant d’installer les câbles du système.
27TriStar MPPT Operator’s Manual
Figure 3-7. Power terminal locations
Connect the four (4) power conductors shown in fi gure 3-7 above in the following steps:
1. Confi rm that the system input and output disconnect switches are both turned off before
connecting the power wires to the controller. There are no disconnect switches inside the
TriStar MPPT.
2. Provide for strain relief if the bottom knockouts are used and conduit is not used.
3. Pull the wires into the wiring box. The Remote Temperature Sensor and Battery Sense wires
can be inside the conduit with the power conductors. It is easier to pull the RTS and Sense
wires before the power cables.
WARNING: Risk of Damage
Be very certain that the battery connection is made with correct polarity. Turn on the battery
breaker/disconnect and measure the voltage on the open battery wires BEFORE connecting to
the TriStar MPPT. Disconnect the battery breaker/disconnect before wiring to the controller.
AVERTISSEMENT : Risque d’endommagement
Assurez-vous que la connexion a la batterie est effectuée avec la polarité correcte. Activez le
coupe-circuit/interrupteur de la batterie et mesure la tension sur les câbles ouverts AVANT la
connexion au TriStar MPPT. Déconnectez le coupe-circuit/interrupteur de la batterie avant le
câblage sur le contrôleur.
4. Connect the Battery + (positive) wire to the Battery + terminal on the TriStar MPPT. The Bat-
tery + terminal has a red cover.
5. Connect the Battery - (negative) wire to one of the Common Negative terminals on the
TriStar MPPT.
WARNING: Risk of Damage
Be very certain that the solar connection is made with correct polarity. Turn on the solar array
breaker/disconnect and measure the voltage on the open wires BEFORE connecting to the
TriStar MPPT. Disconnect the solar breaker/disconnect before wiring to the controller.
28
Installation
AVERTISSEMENT : Risque d’endommagement
Assurez-vous que la connexion solaire est effectuée avec la polarité correcte. Activez le coupecircuit/interrupteur de réseau solaire et mesure la tension sur les câbles ouverts AVANT la
connexion au TriStar MPPT. Déconnectez le coupe-circuit/interrupteur solaire avant le câblage
sur le contrôleur.
6. Connect the Solar + (positive) wire to the Solar + terminal on the TriStar MPPT. The Solar +
terminal has a yellow cover.
7. Connect the Solar - (negative) wire to one of the Common Negative terminals on the
TriStar MPPT.
Torque all four (4) power terminals to 50 in-lbs (5.65 Nm)
Power-Up
WARNING: Risk of Damage
Connecting the solar array to the battery terminal will permanently damage the TriStar MPPT.
WARNING: Risk of Damage
Connecting the solar array or battery connection with reverse polarity will permanently damage
the TriStar MPPT.
AVERTISSEMENT : Risque d’endommagement
La connexion du réseau solaire sur la borne de la batterie endommagera le TriStar MPPT de
façon permanente.
AVERTISSEMENT : Risque d’endommagement
La connexion du réseau solaire ou la connexion de la batterie avec une polarité inversée
endommagera le TriStar MPPT de façon permanente.
• Confi rm that the Solar and Battery polarities are correct.
• Turn the battery disconnect switch on fi rst. Observe that the LED’s indicate a successful
start-up. (LED’s blink Green - Yellow - Red in one cycle)
• Note that a battery must be connected to the TriStar MPPT to start and operate the controller. The controller will not operate only from solar input.
• Turn the solar disconnect on. If the solar array is in full sunlight, the TriStar MPPT will
begin charging. If an optional TriStar Meter is installed, charging current will be reported
along with charging state.
29TriStar MPPT Operator’s Manual
Operation4.0
The TriStar MPPT operation is fully automatic. After installation is completed, there are few operator tasks to perform. However, the operator should be familiar with the operation and care of
the TriStar MPPT as described in this section.
4.1 TrakStarTM MPPT Technology
The TriStar MPPT utilizes Morningstar’s TrakStarTM Maximum Power Point Tracking technology
to extract maximum power from the solar array. The tracking algorithm is fully automatic and
does not require user adjustment. TrakStar
as it varies with weather conditions, ensuring that maximum power is harvested from the array
through the course of the day.
Current Boost
Under most conditions, TrakStar
TM
MPPT technology will “boost” the solar charge current. For
example, a system may have 36 Amps of solar current fl owing into the TS-MPPT and 44 Amps
of charge current fl owing out to the battery. The TriStar MPPT does not create current! Rest as-
sured that the power into the TriStar MPPT is the same as the power out of the TriStar MPPT.
Since power is the product of voltage and current (Volts x Amps), the following is true*:
TM
technology tracks the array maximum power point
(1) Power Into the TriStar MPPT = Power Out of the TriStar MPPT
(2) Volts In x Amps In = Volts Out x Amps Out
* assuming 100% efficiency. Losses in wiring and conversion exist.
If the solar module’s maximum power voltage (V
) is greater than the battery voltage, it follows
mp
that the battery current must be proportionally greater than the solar input current so that input
and output power are balanced. The greater the difference between the Vmp and battery voltage,
the greater the current boost. Current boost can be substantial in systems where the solar array
is of a higher nominal voltage than the battery as described in the next section.
High Voltage Strings and Grid-tie Modules
Another benefi t of TrakStar
TM
MPPT technology is the ability to charge batteries with solar arrays
of higher nominal voltages. For example, a 12 Volt battery bank may be charged with a 12-, 24-,
36-, or 48-Volt nominal off-grid solar array. Grid-tie solar modules may also be used as long as
the solar array open circuit voltage (V
) rating will not exceed the TriStar MPPT 150 Volt maxi-
oc
mum input voltage rating at worst-case (coldest) module temperature. The solar module documentation should provide Voc vs. temperature data.
Higher solar input voltage results in lower solar input current for a given input power. High voltage
solar input strings allow for smaller gauge solar wiring. This is especially helpful and economical
for systems with long wiring runs between the controller and the solar array.
30 Operation
An Advantage Over Traditional Controllers
Traditional controllers connect the solar module directly to the battery when recharging. This requires that the solar module operate in a voltage range that is usually below the module’s V
a 12 Volt system for example, the battery voltage may range from 10 - 15 Vdc, but the module’s
is typically around 16 or 17 Volts. Figure 4-1 shows typical current vs. voltage and power
V
mp
output curves for a nominal 12 Volt off-grid module.
12 Volt Module
Current vs. Voltage
Typical Battery
Voltage Range
CURRENT
Maximum
Power
Point
POWER
12 Volt Module
Output Power
Traditional
Controller
Operating Range
TrackStar
Maximum
Power
Point
mp
. In
10 15 17
Figure 4-1. Nominal 12 Volt Solar Module I-V curve and output power graph.
VOLTAG E
10 15 17
VOLTAG E
The array Vmp is the voltage where the product of output current and voltage (Amps x Volts) is
greatest, which falls on the “knee” of the solar module I-V curve as shown on the left in Figure
4-1.
Because traditional controllers do not always operate at the Vmp of the solar array, energy is
wasted that could otherwise be used to charge the battery and power system loads. The greater
the difference between battery voltage and the Vmp of the module, the more energy is wasted.
TrakStarTM MPPT technology will always operate at the maximum power point resulting in less
wasted energy compared to traditional controllers.
Conditions That Limit the Effectiveness of MPPT
The V
weather, the V
of a solar module decreases as the temperature of the module increases. In very hot
mp
may be close or even less than battery voltage. In this situation, there will be
mp
very little or no MPPT gain compared to traditional controllers. However, systems with modules of
higher nominal voltage than the battery bank will always have an array V
greater than battery
mp
voltage. Additionally, the savings in wiring due to reduced solar current make MPPT worthwhile
even in hot climates.
31TriStar MPPT Operator’s Manual
4.2 Battery Charging Information
4-Stage Charging
The TriStar MPPT has a 4-stage battery charging algorithm for rapid, effi cient, and safe battery
charging. Figure 4-2 shows the sequence of the stages.
EQUALIZE
VOLTAGE
BULK
NIGHT NIGHT
Figure 4-2. TriStar MPPT charging algorithm
CHARGE
ABSORPTION
TIME
FLOAT
Bulk Charge Stage
In Bulk charging stage, the battery is not at 100% state of charge and battery voltage has not
yet charged to the Absorption voltage setpoint. The controller will deliver 100% of available solar
power to recharge the battery.
Absorption Stage
When the battery has recharged to the Absorption voltage setpoint, constant-voltage regulation is
used to maintain battery voltage at the Absorption setpoint. This prevents heating and excessive
battery gassing. The battery is allowed to come to full state of charge at the Absorption voltage
setpoint. The green SOC LED will blink once per second during Absorption charging.
The battery must remain in the Absorption charging stage for a cumulative 120 - 150 minutes,
depending on battery type, before transition to the Float stage will occur. However, Absorption
time will be extended by 30 minutes if the battery discharges below 12.5 Volts (25 Volts @24 V,
50 Volts @48 V) the previous night.
The Absorption setpoint is temperature compensated if the RTS is connected.
32
Operation
Float Stage
After the battery is fully charged in the Absorption stage, the TriStar MPPT reduces the battery
voltage to the Float voltage setpoint. When the battery is fully recharged, there can be no more
chemical reactions and all the charging current is turned into heat and gassing. The fl oat stage
provides a very low rate of maintenance charging while reducing the heating and gassing of a
fully charged battery. The purpose of fl oat is to protect the battery from long-term overcharge.
The green SOC LED will blink once every two (2) seconds during Float charging.
Once in Float stage, loads can continue to draw power from the battery. In the event that the
system load(s) exceed the solar charge current, the controller will no longer be able to maintain
the battery at the Float setpoint. Should the battery voltage remain below the Float setpoint for a
cumulative 30 minute period, the controller will exit Float stage and return to Bulk charging.
The Float setpoint is temperature compensated if the RTS is connected.
Equalize Stage
WARNING: Risk of Explosion
Equalizing vented batteries produces explosive gases. The battery bank must be properly
ventilated.
CAUTION: Equipment Damage
Equalization increases the battery voltage to levels that may damage sensitive DC loads. Verify
!
all system loads are rated for the temperature compensated Equalize voltage before beginning
an Equalization charge.
CAUTION: Equipment Damage
Excessive overcharging and gassing too vigorously can damage the battery plates and cause
!
shedding of active material from the plates. An equalization that is too high or for too long can
be damaging. Review the requirements for the particular battery being used in your system.
AVERTISSEMENT : Risque d’explosion
Les batteries à évent et compensation produisent des gaz explosifs. Le groupe de batteries doit
être correctement ventilé.
PRUDENCE : Endommagement de l’équipement
La compensation augmente la tension des batteries à des niveaux pouvant endommager les
!
charges sensibles en CC. Vérifi ez que toutes les charges du système sont conçues pour la
tension de compensation par température avant de commencer une charge de compensation.
PRUDENCE : Endommagement de l’équipement
Une surcharge excessive et un dégagement gazeux trop vigoureux peuvent endommager les
!
plaques de batteries et provoquer l’élimination du matériau actif des plaques. Une compensation
trop élevée ou trop longue peut provoquer des dégâts. Examinez les exigences pour la batterie
particulière utilisée dans votre système.
Certain battery types benefi t from a periodic boost charge to stir the electrolyte, level the cell volt-
ages, and complete the chemical reactions. Equalize charging raises the battery voltage above
the standard absorption voltage so that the electrolyte gasses. The green SOC LED will blink
33TriStar MPPT Operator’s Manual
rapidly two (2) times per second during equalization charging.
The duration of the equalize charge is determined by the selected battery type. See table 4-1
in this section for more details. The Equalization Time is defi ned as time spent at the equalize
setpoint. If there is insuffi cient charge current to reach the equalization voltage, the equalization
will terminate after an additional 60 minutes to avoid over gassing or heating the battery. If the
battery requires more time in equalization, an equalize can be requested using the TriStar Meter
or pushbutton to continue for one or more additional equalization cycles.
The Equalize setpoint is temperature compensated if the RTS is connected.
When to Equalize
The ideal frequency of equalizations depends on the battery type (lead-calcium, lead-antimony,
etc.), the depth of discharging, battery age, temperature, and other factors. One very broad
guide is to equalize fl ooded batteries every 1 to 3 months or every 5 to 10 deep discharges.
Some batteries, such as the L-16 group, will need more frequent equalizations.
The difference between the highest cell and lowest cell in a battery can also indicate the need
for an equalization. Either the specifi c gravity or the cell voltage can be measured. The battery
manufacturer can recommend the specifi c gravity or voltage values for your particular battery.
Why Equalize?
Routine equalization cycles are often vital to the performance and life of a battery - particularly in
a solar system. During battery discharge, sulfuric acid is consumed and soft lead sulfate crystals form on the plates. If the battery remains in a partially discharged condition, the soft crystals
will turn into hard crystals over time. This process, called “lead sulfation,” causes the crystals to
become harder over time and more diffi cult to convert back to soft active materials.
Sulfation from chronic undercharging of the battery is the leading cause of battery failures in
solar systems. In addition to reducing the battery capacity, sulfate build-up is the most common
cause of buckling plates and cracked grids. Deep cycle batteries are particularly susceptible to
lead sulfation.
Normal charging of the battery can convert the sulfate back to the soft active material if the battery is fully recharged. However, a solar battery is seldom completely recharged, so the soft lead
sulfate crystals harden over a period of time. Only a long controlled overcharge, or equalization,
at a higher voltage can reverse the hardening of sulfate crystals.
Preparation for Equalization
First, confi rm that all of the system loads are rated for the equalization voltage. Consider that at
0°C (32°F) the equalization voltage will reach 16.75 Volts for 12 Volt L-16 batteries (67.0 Volts for
48 Volt systems) with a temperature sensor installed. Disconnect any loads at risk of damage
due to the high input voltage.
34
Operation
If Hydrocaps are used, be sure to remove them before starting an equalization. Replace the
Hydrocaps with standard battery cell caps. The Hydrocaps can get very hot during an equalization. Also, if Hydrocaps are used, the equalization should be set for manual only (DIP switch #7
is Off).
After the equalization is fi nished, add distilled water to each cell to replace gassing losses.
Check that the battery plates are covered.
Equalize a Sealed Battery?
The Battery Charging Settings table (see table 4-1 in this section) shows one sealed battery
setting with an Equalization cycle. This is only a 0.1 Volt (12V battery) boost cycle to level individual cells. This is not an equalization, and will not vent gas from sealed batteries that require
up to 14.4V charging (12V battery). Many VRLA batteries, including AGM and gel, have charging
requirements up to 14.4V (12V battery). This “boost” charge for sealed cells can be disabled by
setting the equalize setting switch to manual if required.
35TriStar MPPT Operator’s Manual
Battery Charging Settings
The details of the TriStar MPPT battery charging settings are shown in tables 4-1 and 4-2 below.
All voltage settings listed are for nominal 12 Volt batteries. Multiply the voltage settings by two (2)
for 24 Volt batteries or by four (4) for 48 Volt systems.
Settings
Switches
4 - 5 - 6
off-off-off 1 - Gel 14.00 13.70 150
off-off-on 2 - Sealed* 14.15 13.70 14.40 150 60 28
off-on-off 3 - Sealed* 14.30 13.70 14.60 150 60 28
off-on-on 4 - AGM/Flooded 14.40 13.70 15.10 180 120 28
on-off-off 5 - Flooded 14.60 13.50 15.30 180 120 28
on-off-on 6 - Flooded 14.70 13.50 15.40 180 180 28
on-on-off 7 - L-16 15.40 13.40 16.00 180 180 14
on-on-on 8 - Custom Custom Custom Custom Custom Custom Custom
* “Sealed” battery type includes gel and AGM batteries
Table 4-1. Battery charging settings for each selectable battery type
Absorption Extension Voltage 12.50 Volts
Absorption Extension Time Absorption Time + 30 minutes
Float Exit Timeout 30 minutes
Float Cancel Voltage 11.50 Volts
Equalize Timeout Equalize Time + 60 minutes
Temperature Compensation Coeffi cient* - 5
* 25°C reference
Table 4-2. Battery settings that are shared between all battery types
Battery
Type
Shared Settings Value Units
Absorp.
Stage
(Volts)
Float
Stage
(Volts)
Equalize
Stage
(Volts)
Absorp.
Time
(Minutes)
millivolts /
Equalize
(Minutes)
Time
°C / cell
Equalize
Interval
(Days)
The TriStar MPPT provides seven (7) standard battery charging settings that are selected with
the settings switches (see X-X in Installation). These standard charging settings are suitable for
lead-acid batteries ranging from sealed (gel, AGM, maintenance-free) to Flooded and L-16 cells.
In addition, an 8th charging setting provides for custom setpoints using MSViewTM PC software.
Table 4-1 above summarizes the major parameters of the standard charging settings.
The shared settings in table 4-2 are common to all battery types. The following charging profi les
graphically explain the shared settings.
36
Operation
Absorption Extension
Figure 4-3. Absorption extension charging profi le.
If battery voltage discharges below 12.50 Volts (25.00 Volts @ 24 V, 50 Volts @ 48 V) the previous night, Absorption charging will be extended on the next charge cycle as shown in fi gure 4-3
above. 30 minutes will be added to the normal Absorption duration.
Float Timeout
Figure 4-4. Float exit timeout charging profi le
After entering Float stage, the controller will only exit Float if the battery voltage remains below
Float voltage for 30 cumulative minutes. In fi gure 4-4, a system load turns on at 4:30 hrs when
the controller is in Float stage, runs for 1/2 hour, and turns off at 5:00 hrs. The load current draw
is larger than the charge current, causing battery voltage to drop below Float voltage for 30 minutes. After the load turns off, the controller returns to Bulk charging and then Absorption stage
once again. In this example, a load runs continuously for 30 min. However, because the Float
exit timer is cumulative, multiple momentary load events that pull the battery voltage below Float
voltage for a combined 30 minutes duration will also force an exit from Float stage.
37TriStar MPPT Operator’s Manual
Float Cancel Voltage
Figure 4-5. Float cancelled charging profi le
If the battery bank discharges below 11.50 Volts (23.00 Volts @ 24 V, 46.00 Volts @ 48 V) the
previous night, Float charging stage will be cancelled for the next charge cycle. Figure 4-5 above
illustrates this concept. At 0:00 hrs (dawn), battery voltage is below the Float Cancel threshold
voltage. The diagram shows where Float stage would have occurred if Float was not cancelled.
Equalize Timeout
Figure 4-6. Equalize timeout charging profi le
The charging profi le in fi gure 4-6 shows an Equalize Timeout event. The timeout timer begins as
soon as battery voltage exceeds the Absorption voltage setpoint. If there is insuffi cient charging
current or system loads are too large, the battery voltage may not reach the Equalize setpoint.
Equalize Timeout is a safety feature that prevents high battery voltage for extended periods of
time which may damage the battery.
38
Operation
Temperature Compensation
All charging settings are based on 25°C (77°F). If the battery temperature varies by 5°C, the
charging setting will change by 0.15 Volts for a 12 Volt battery. This is a substantial change in
the charging of the battery, and the use of the Remote Temperature Sensor (RTS) is recommended to adjust charging to the actual battery temperature.
The need for temperature compensation depends on the temperature variations, battery type,
how the system is used, and other factors. If the battery appears to be gassing too much or not
charging enough, the RTS can be added at any time after the system has been installed. See
Section 2.3 - Step 4 for installation instructions.
Battery Sense
Voltage drops are unavoidable in power cables that carry current, including the TriStar MPPT
battery cables. If Battery Sense wires are not used, the controller must use the voltage reading
at the battery power terminals for regulation. Due to voltage drops in the battery cables, the battery power connection voltage will be higher than the actual battery bank voltage while charging
the battery.
Two sense wires, sized from 1.0 to 0.25 mm2 (16 to 24 AWG), can be used for battery voltage
sense. Because these wires carry no current, the voltage at the TriStar will be identical to the
battery voltage. A 2-position terminal is used for the battery sense connection.
Generally accepted wiring practice is to limit voltage drops between the charger and the battery
to 2%. Even properly sized wiring with 2% drop can result in a 0.29 Volt drop for 14.4V charging (or 1.15 Volt for a 48 Volt nominal system). Voltage drops will cause some undercharging of
the battery. The controller will begin Absorption or limit equalization at a lower battery voltage
because the controller measures a higher voltage at the controller’s terminals than is the actual
battery voltage. For example, if the controller is programmed to start Absorption at 14.4V, when
the controller “sees” 14.4V at its battery terminals, the true battery voltage would only be 14.1V if
there is a 0.3V drop between the controller and battery.
Note that the battery sense wires will not power the controller, and the sense wires will not compensate for losses in the power wires between the controller and the battery. The battery sense
wires are used to improve the accuracy of the battery charging.
See Section 3.2 - Step 7 for instructions on how to connect the battery sense wires.
39TriStar MPPT Operator’s Manual
4.3 Push button
The following functions can be enabled with the pushbutton (located on the front cover):
PUSH
• Reset from an error or fault.
• Reset the battery service indication if this has been activated in custom settings. A new
service period will be started, and the fl ashing LED’s will stop blinking. If the battery ser-
vice is performed before the LED’s begin blinking, the pushbutton must be pushed at the
time when the LED’s are blinking to reset the service interval and stop the blinking.
PUSH AND HOLD 5 SECONDS
• Request battery equalization manually. The TriStar MPPT will begin equalization in either
the manual or automatic equalization mode. Equalization will begin when there is suffi cient
solar power to charge the battery up to the equalization voltage. The LEDs will blink the
sequence defi ned in table 4-3 below to confi rm that an equalize has been requested. The
equalization request will automatically stop per the battery type selected (see Section 4.4).
Equalization will only occur if the selected battery type has an equalization stage.
• Stop an equalization that is in progress. This will be effective in either the manual or automatic mode. The equalization will be terminated. The LEDs will blink to confi rm the equal-
ize has been cancelled as shown in table 4-3 below.
Pushbutton Action SOC LED Indication
Manual Equalization Started Green+Yellow+Red / Green+Yellow+Red / Green / Green
Stop Equalization Green+Yellow+Red / Green+Yellow+Red / Red / Red
Table 4-3. Manual equalization LED indications
NOTE:
For multiple TriStar MPPT controllers on a MeterBusTM network, initialize a battery equalization
using the TriStar meter so that all controllers are synchronized.
REMARQUE :
Avec plusieurs contrôleurs TriStar MPPT sur un réseau MeterBusTM, initialisez une
compensation de batteries à l’aide de l’outil de mesure TriStar afi n de synchroniser tous les
contrôleurs.
Note that if two or more TriStar MPPT controllers are charging in parallel, each controller may
attempt to equalize on a different day. Systems with multiple controllers should only equalize
manually to ensure synchronization between controllers.
40
Operation
4.4 LED Indications
Valuable information can be provided by the three LED’s visible through the front cover. Although
there are many different LED indications, they have similar patterns to make it easier to interpret
each LED display. Consider as three groups of indications: General Transitions // Battery Status
// Faults & Alarms.
LED Display Explanation
G = green LED is lit
Y / R = yellow LED is lit, then red LED is lit
G+Y = Green and Yellow are both lit at the same time
G+Y / R = Green & Yellow both lit, then Red is lit alone
Sequencing LED patterns (faults) repeat until the fault is cleared
General Transitions
• Controller start-up G / Y / R (one cycle)
• Equalize request start G+Y+R / G+Y+R / G / G
• Equalize cancelled G+Y+R / G+Y+R / R / R
• Battery service is required* all 3 LED’s blinking until service is reset
*battery service notifi cation is only enabled in custom settings
Battery Status
• General state-of-charge see battery SOC indications below
• Absorption state G blinking (½ second on / ½ second off)
• Equalization state G fast blink (2 to 3 times per second)
• Float state G slow blink (1 second on / 1 second off)
Faults & Alarms
• Over-temperature Y / R sequencing
• High voltage disconnect G / R sequencing
• DIP switch fault R / Y / G sequencing
• Self-test faults R / Y / G sequencing
• Remote Temperature Sensor (RTS) G+Y / Y+R sequencing
• Battery voltage sense G+Y / Y+R sequencing
41TriStar MPPT Operator’s Manual
Battery State-of-Charge LED Indications
G 80% to 95% SOC
G+Y 60% to 80% SOC
Y 35% to 60% SOC
Y+R 0% to 35% SOC
R battery is discharging
Refer to the Specifi cations (Section 8.0) for the State-of-Charge voltages.
Note that because these State-of-Charge LED displays are for all battery types and system designs, they are only approximate indications of the battery charge state.
Ethernet Jack Indications
In addition to the SOC LEDs, two (2) small LEDs can be found on the Ethernet RJ-45 jack inside
the wiring box. These LEDs indicate the LAN/WAN network link and activity status as follows:
Condition Green LED Yellow LED
Network Connection OK ON OFF
Network Activity ON Blinking
Error OFF ON
42
Operation
4.5 Protections, Faults & Alarms
The TriStar MPPT protections and automatic recovery are important features that ensure the
safe operation of the system. Additionally, the TriStar MPPT features real-time self diagnostics
that report Fault and Alarm conditions as they occur.
Faults are events or conditions that require the TriStar MPPT to cease operation. A Fault usually
occurs when a limit such as voltage, current, or temperature has been surpassed. Fault conditions are indicated with unique LED sequences and are also displayed on the TriStar Meter.
Alarms are events or conditions that may require the TriStar MPPT to modify operation. Alarms
are commonly used to alert the user that the controller is nearing a specifi c voltage, current, or
temperature limit. Alarm conditions are only displayed on the TriStar Meter.
Some basic fault conditions are reviewed below:
Protections
Solar Overload
The TriStar MPPT will limit battery current to the Maximum Battery Current rating. An over-sized
solar array will not operate at peak power. The solar array should be less than the TriStar MPPT
Nominal Maximum Input Power rating for optimal performance. See section 8.0 for more informa-
tion.
Solar Short Circuit
The TriStar MPPT will disconnect the solar input if a short circuit is detected in the solar wiring.
Charging automatically resumes when the short is cleared. No LED indication.
Solar High Input Voltage
Solar input current will be limited as the array open circuit voltage approaches the 150 Volt maximum input voltage limit.
Very Low Battery Voltage
If battery discharges below ~7 Volts the controller will go into brownout and shut down. When
the battery voltage rises above the 8 Volt minimum operating voltage, the controller will restart.
Faults
Remote Temperature Sensor Failure (R+Y / G+Y)
If a fault in the RTS (such as a short circuit, open circuit, loose terminal) occurs after the RTS has
been working, the LED’s will indicate a failure. However, if the controller is restarted with a failed
RTS, the controller may not detect that the RTS is connected, and the LED’s will not indicate a
problem. A TriStar meter or the PC software can be used to determine if an RTS is detected and
working properly.
43TriStar MPPT Operator’s Manual
Battery Voltage Sense Failure (R+Y / G+Y)
If a fault in the battery sense connection (such as a short circuit, open circuit or loose terminal)
occurs after the battery sense has been working, the LED’s will indicate a failure. If the controller is restarted with the failure still present, the controller may not detect that the battery sense is
connected and the LED’s will not indicate a fault. A TriStar meter or the PC software can be used
to determine if the battery sense is working properly.
Settings (DIP) Switch Changed (R / Y / G sequencing)
If a settings switch is changed while there is power to the controller, the LED’s will begin sequencing and the solar input will disconnect. The controller must be restarted to clear the fault
and begin operation with the new settings.
Battery High Voltage Disconnect (G / R sequencing)
This fault is set when battery voltage is above normal operating limits. The controller will disconnect the solar input and set a High Voltage Disconnect fault. This fault is commonly caused by
other charging sources in the system charging the battery above the TriStar MPPT regulation
voltage. When the battery voltage returns to normal levels, the fault will automatically clear.
Custom Settings Edit (G+Y+R fl ashing)
A value has been modifi ed in custom settings memory. The controller will stop charging and
indicate a fault condition. After all settings have been modifi ed, the controller must be reset by
removing and then restoring power to the controller. The new programmed settings will be used
after the power reset.
Firmware Update Failure (Y / R)
The fi rmware update was not successfully programmed. The controller will not indicate the full
power-up LED sequence of G / Y / R when power to the controller is reset. Instead, the controller
will display green and then stop on yellow. The yellow LED will continue to be lit and the controller will not complete start up or begin charging. Retry the fi rmware update. The fi rmware must be
successfully loaded before the controller will start up.
Alarms
High Temperature Current Limit
The TriStar MPPT will limit the solar input current if the heatsink temperature exceeds safe limits.
Solar charge current will be tapered back (to 0 amps if needed) to reduce the heatsink temperature. The TriStar MPPT is designed to operate at full rated current at the maximum ambient temperature. This alarm indicates that there is insuffi cient airfl ow and that the heatsink temperature
is approaching unsafe limits. If the controller frequently reports this alarm condition, corrective
action must be taken to provide better air fl ow or to relocate the controller to a cooler spot.
High Input Voltage Current Limit
The TriStar MPPT will limit the solar input current as the solar array Voc approaches the maximum input voltage rating. The array Voc should never exceed the 150 Volt maximum input voltage. See the array voltage derating graph in Section 8.0.
44
Operation
Current Limit
The array power exceeds the rating of the controller. This alarm indicates that the TriStar MPPT
is limiting battery current to the maximum current rating.
RTS Open
The Remote Temperature Sensor is not connected to the controller. Use of the RTS is recommended for proper battery charging.
Heatsink Temperature Sensor Open / Shorted
The heatsink temperature sensor is damaged. Return the controller to an authorized Morningstar
dealer for service.
Battery Sense Out of Range / Disconnected
A battery sense wire is disconnected. Inspect the battery sense connections. This alarm is set
when the voltage at the battery sense voltage differs by more than 5 volts from the voltage at the
battery terminals.
Uncalibrated
The controller was not factory calibrated. Return the controller to an authorized Morningstar
dealer for service.
45TriStar MPPT Operator’s Manual
4.6 Inspection and Maintenance
The following inspections are recommended two times per year for best long-term performance.
System Inspection
• Confi rm the controller is securely mounted in a clean and dry environment.
• Confi rm that the air fl ow around the controller is not blocked. Clean the heat sink of any
dirt or debris.
• Inspect all exposed conductors for insulation damage due to sun damage, rubbing on
nearby objects, dry rot, insects, or rodents. Repair or replace conductors as necessary.
• Tighten all power connections per the manufacturer’s recommendations.
• Verify the LED indications are consistent with the equipment operation. Note any fault or
error indications. Take corrective action if necessary.
• Inspect the battery bank. Look for cracked or bulging cases and corroded terminals.
For wet cell fl ooded batteries, make sure the water level is correct. Wet cell water levels
should also be checked frequently according to the manufacturer’s recommendations.
• Inspect the system earth grounding for all components. Verify all grounding conductors
are appropriately secured to earth ground.
Inside the TriStar MPPT Wiring Box
CAUTION: Shock Hazard
Disconnect all power sources to the controller before removing the wiring box cover.
!
Never remove the cover when voltage exists on the TriStar MPPT power connections.
PRUDENCE : Risque de décharge électrique
Déconnectez toutes les sources d’alimentation du contrôleur avant d’enlever le couvercle
!
du boîtier de câblage. Ne retirez jamais le couvercle en présence de tension sur une des
connexions d’alimentation du TriStar MPPT.
• Check all wire terminals. Inspect connections for corrosion, damaged insulation, signs of
high temperature or burning/discoloration. Tighten the terminal screws to the recommended torque.
• Inspect for dirt, nesting insects, and corrosion. Clean as required.
46
Operation
5.0 Networking and Communication
5.1 Introduction
The TriStar MPPT provides several communication options. The TriStar MPPT uses a proprietary
protocol for the MeterBusTM network and the non-proprietary open standard MODBUSTM and
MODBUS TCP/IPTM protocols for RS-232, EIA-485, and ethernet networks. Additionally, HTTP,
SMTP, and SNMP are supported for web page, email, and network message support.
Morningstar’s MSViewTM PC software provides system monitoring and logging capabilities via
RS-232, EIA-485, and ethernet. MSViewTM PC software is available for free on our website at:
http://www.morningstarcorp.com.
Further, hardware and third party software that supports the MODBUSTM protocol can also be
used to communicate with a TriStar MPPT.
Multiple communication ports can be used simultaneously. For example, a TriStar MPPT may
be connected to a MeterBusTM network for on-site system metering, connected to the internet for
remote monitoring, and connected to an EIA-485 network to bridge data from other controllers in
the system to an internet connection. Note that the RS-232 and EIA-485 connections share hardware and therefore cannot be used simultaneously.
Table 5-1 below provides a summary of supported features for each communication interface.
Display system/network data on a TriStar meter
Connect a TSMPPT to a Relay Driver or other MS Accessory
Connect multiple TSMPPT together in a network
View and log data with MSViewTM PC Software
View logged data stored in the TriStar MPPT internal memory
Update TriStar MPPT fi rmware
Program custom settings
View data in a web browser
Email notifi cation
Text Message Alerts
SNMP Alerts
Table 5-1. Communication summary
MeterBus
RS-232
●
●
●
●
●
●
●
●
EIA-485
●
●
●
●
Ethernet
●
●
●
●
●
●
●
●
47TriStar MPPT Operator’s Manual
5.2 Morningstar MeterBus
TM
Morningstar’s proprietary MeterBusTM protocol allows communication between compatible Morningstar products. Use a MeterBusTM network to:
• display net system data for multiple TriStar / TriStar MPPT systems**
• communicate with a TriStar Digital Meter 2 or TriStar Remote Meter 2
• communicate with a Relay Driver or other compatible Morningstar accessories (see section 2.5 for more details)
**A Morningstar MeterBus Hub (HUB-1) and either a TriStar Digital Meter 2 (TS-M-2) or TriStar Remote Meter 2 (TS-RM-2) are
required, not included.
A MeterBus Hub (model: HUB-1) is required for MeterBus networks containing multiple
TriStar MPPT controllers. The ports on the hub are electrically isolated to prevent damage in the
event of broken grounds or voltage differences between controllers. Figure 5-1 below shows an
TM
example MeterBus
network with two (2) TriStar MPPT controllers and a TriStar Remote Meter 2
(TS-RM2).
Figure 5-1. An example MeterBus network.
Up to fi ve (5) controllers can be networked together with a single hub. Multiple hubs can be
daisy-chained together to allow networks of up to 14 controllers and a meter.
Refer to the HUB-1 and TriStar Meter manuals for more information about Morningstar MeterBusTM networking.
48
Networking and Communication
5.3 Serial RS-232
The serial port connection on the TriStar MPPT is a standard 9-pin isolated RS-232 port. See fi g-
ure 3-5 for the port location.The TriStar MPPT communicates through the serial port via the open
standard MODBUS
Connect the TriStar MPPT to the serial port on a PC to:
TM
protocol.
• program custom charge settings with MSView
TM
PC software
• view real-time data with MSViewTM PC software
• log real-time data with MSViewTM PC software
• confi gure ethernet settings
• update controller fi rmware with MSLoadTM fi rmware utility
NOTE:
The RS-232 and EIA-485 ports share hardware. Both ports cannot be used simultaneously.
NOTE:
If your PC does not have a serial port, a USB to Serial cable can be purchased at your local
electronics retailer.
The serial connection is ideal for confi guring custom settings or monitoring a single TriStar MPPT
controller. Figure 5-2 shows a serial connection between the controller and a PC with MSViewTM
PC software.
Figure 5-2. A serial connection between a PC and the TriStar MPPT
49TriStar MPPT Operator’s Manual
Serial Port Settings
Adjust the serial port settings as follows:
• 9600 BAUD
• 8 data bits
• 1 or 2 stop bits
• no parity
The serial RS-232 connection provides a direct connection between a TriStar MPPT and a PC
(or other serial device). Firmware updates can only be programmed through the RS-232
connection. The serial connection is not typically used for multi-controller networking. However,
networking is possible using a USB hub and USB-Serial cables. For more information, refer to
the “Morningstar Communications Document” on our website at:
HTTP://www.morningstarcorp.com/
50
Networking and Communication
5.4 EIA-485 (formerly RS-485)
NOTE:
The EIA-485 connection is only available on the TS-MPPT-60 model.
NOTE:
The RS-232 and EIA-485 ports share hardware. Both ports cannot be used simultaneously.
EIA-485 is a networking standard for serial communication between multiple devices on a bus.
The TriStar MPPT communicates over an EIA-485 network via the open standard MODBUSTM
protocol. Use EIA-485 networking to:
• connect multiple TriStar MPPT controllers on a network to log and view real-time data using MSViewTM PC software
• program each controller on the network with custom charge settings using MSViewTM PC
software
• connect the TriStar MPPT to other Morningstar controllers with the RSC-1 Serial to EIA485 Adapter (sold separately)
• bridge an Ethernet connection through a TriStar MPPT to an EIA-485 network
The EIA-485 port has four (4) connections: Power, Data A, Data B, and Ground. Data A & B are
differentially driven data lines that carry the network data. Power and Ground connections provide power to the network. The TriStar MPPT does not supply power to the EIA-485 network,
therefore an external power source is required. The source voltage must be between 8-16 Vdc.
For 12 Volt systems, the network can be powered directly from the system battery. Use a DC-DC
converter for 24, 36, and 48 Volt systems.
CAUTION: Equipment Damage
Tapping power off of individual batteries in a series string of batteries can cause a voltage imbalance.
!
Damage to the batteries may result. Always use a DC-DC converter to power the EIA-485 network if the
nominal system voltage is greater than 12 volts.
PRUDENCE : Endommagement de l’équipement
L’arrêt progressif de batteries individuelles dans une série de batteries peut provoquer un déséquilibre
!
de tension. Les batteries peuvent être endommagées. Utilisez toujours un convertisseur CC-CC pour
convertir l’alimentation au réseau EIA-485 si la tension nominale du système est supérieure à 12 V.
For more information on EIA-485 networking, refer to the “Morningstar Communications Document” on our website at:
HTTP://www.morningstarcorp.com/
51TriStar MPPT Operator’s Manual
5.5 Ethernet
NOTE:
Ethernet is only available on the TS-MPPT-60 model.
CAUTION: Risk of Tampering
The TS-MPPT does not feature built-in network security. It is the responsibility of the user or network
!
administrator to place the TS-MPPT behind a network fi rewall to prevent unauthorized access.
PRUDENCE : Risque de tentative d’altération
Le TS-MPPT ne comporte pas de sécurité réseau intégrée. Il incombe à l’utilisateur ou à l’administrateur
!
du réseau de placer le TS-MPPT derrière un pare-feu réseau afi n d’empêcher l’accès non autorisé.
The Ethernet port supports HTTP, MODBUS TCP/IPTM, SMTP, and SNMP protocols to provide a
fully web-enabled interface between the TriStar MPPT and a LAN/WAN network or the internet.
Some of the many features the Ethernet connection provides include:
• program custom settings with MSViewTM PC software
• monitor the controller from a web browser
• modify controller settings from a web browser
• log and monitor the system with MSViewTM PC software anywhere on the internet
• create custom web pages to show system data
• send an email or text message if a fault, alarm, or user-defi ned event occurs
• monitor and receive messages on an SNMP network
This section provides a summary of each of the features. For detailed information about Ethernet
connectivity and networking, refer to the “Morningstar Communications Document” on our website at:
HTTP://www.morningstarcorp.com/
Network Information
Connect to the TriStar MPPT via an Ethernet network (LAN/WAN) or connect the controller
directly to a PC using an ethernet cross-over cable. Use CAT-5 or CAT-5e twisted pair Ethernet
cables with RJ-45 connectors. A network diagram for both scenarios is shown in fi gure 5-3 below.
Figure 5-3. Ethernet network diagrams.
52
Networking and Communication
Factory Default Network Settings
DHCP enabled
Live View Web Address http://tsmppt + serial number **
IP 192.168.1.253 (if DHCP is not enabled)
Subnet Mask 255.255.255.0
Gateway 192.168.1.1
Primary DNS Server 169.254.1.1
MODBUS TCP/IP
** The Live View web address is unique to each controller. If the TriStar MPPT serial number is 09501234, then the Live View address is: http://tsmppt09501234. The Live View address is printed on the serial label on the side of the unit for reference.
TM
Port 502
The controller’s MAC Address is located on the serial label on the side of the controller.
Two (2) LED’s on the Ethernet jack indicate link and activity status.
Condition Green LED Yellow LED
Network Connection OK ON OFF
Network Activity ON Blinking
Error OFF ON
Web Pages
Connect the TriStar MPPT controller to the network using an Ethernet cable. Wait 5 to 10 minutes for the controller to connect to the network. Open a web browser on any PC on the network.
Enter the Live View web address in the address bar of the web browser. The TriStar MPPT main
Live View webpage will load. Links are provided to real-time data, history, and network settings
adjustment pages.
Pages served by the TriStar MPPT are ideal for retrieving quick information about the charge
controller and making adjustments to network settings. However, there is no ability to customize the layout or data displayed. Also, information from multiple controllers cannot be displayed
on the same webpage. Custom web pages can be created to format and display data exactly as
needed. Custom web pages can be served from a webserver. Further, websites can be created
to display data from multiple controllers. Examples and sample code are available on our website.
Custom Settings
The TriStar MPPT Setup Wizard in MSView
eters. Morningstar’s MSViewTM PC software can connect to any TriStar MPPT on the Ethernet
network or through a RS-232 serial connection. Refer to the help documentation included with
MSViewTM for more information.
TM
provides an interface to adjust all operating param-
53TriStar MPPT Operator’s Manual
Email & SMS Alerts
The email and SMS alerts feature sends notifi cation to an email address or mobile phone if one
of the following occurs:
• TriStar MPPT self diagnostics fault condition
• TriStar MPPT self diagnostics alarm condition
• User-defi ned event (e.g. battery voltage is less than 46 Volts)
Up to four email and SMS alerts can be confi gured from the network settings web page in the
MSView TriStar MPPT wizard.
View logged data
The TriStar MPPT logs up to 200 days* of daily data. The controller always logs the standard values listed below. Using MSView, the controller can be confi gured to log additional optional values
each day. The maximum number of days that can be stored decreases as the number of logged
values increases.
Standard Values
• Minimum Battery Voltage
• Maximum Battery Voltage
• Daily Events (Equalize triggered, Entered Float, Alarm/Fault occurred, Controller Reset)
• Faults / Alarms - recorded only if a fault or alarm occurs that day
Optional Values
• Maximum Array Voltage
• Maximum Power Output
• Charge Amp-hours
• Charge Watt-hours
• Minimum/Maximum Battery Temperature
• Charge stage regulation timers for Absorption, Float, Equalize
* logging only standard values
SNMP
For telecom and industrial applications that require SNMP monitoring of deployed systems, the
TriStar MPPT will behave as an SNMP agent and supports the following commands:
TRAP
GET
GETNEXT
A link to the agent Management Information Base fi le (*.MIB) is available on the TriStar MPPT
Live View Network Settings page.
54
Networking and Communication
Troubleshooting6.0
Battery Charging and Performance Issues
Problem:
No LED indications, controller does not appear to be powered
Solution:
With a multi-meter, check the voltage at the battery terminals on the TriStar MPPT. Battery voltage must be 8 Vdc or greater. If the voltage on the battery terminals of the controller is between
8 and 72 Vdc and no LEDs are lit, contact your authorized Morningstar dealer for service. If no
voltage is measured, check wiring connections, fuses, and breakers.
Problem:
The TriStar MPPT is not charging the battery.
Solution:
Check the three (3) battery SOC LEDs. If they are fl ashing a sequence, see Section 4.4 Faults &
Alarms of this manual to determine the issue. If a TriStar Meter 2 is connected, the diagnostics
menu will display reported faults and alarms.
If the LED indications are normal, check the fuses, breakers, and wiring connections in the solar
array wiring. With a multi-meter, check the array voltage directly at the TriStar MPPT solar input
terminals. Input voltage must be greater than battery voltage before charging will begin.
NOTE:
For more in-depth testing and diagnosis, download the TriStar MPPT Testing Document from the
Support section on our website: www.morningstarcorp.com/
Network and Communication Issues
Problem:
Cannot connect to the controller via RS-232
Solution:
Check the following:
• The RS-232 cable is straight-through, not a Null Modem (cross-over)
• If using a serial-USB adapter, verify that the adapter software is installed and a serial COM
port has been mapped. Check the activity light on the USB adapter if it has one. If there is
no activity, the wrong COM port has been chosen or there is a confi guration issue with the
adapter.
• The default MODBUS ID of the TriStar MPPT is 1. Verify that the PC software is confi g-
ured to communicate using the correct ID.
55TriStar MPPT Operator’s Manual
Problem:
Cannot connect to the controller via EIA-485
Solution:
Check the following:
• The RS-232 port is not in use. The EIA-485 and RS-232 ports cannot be used simultaneously. Only one port can be used at a time.
• The RSC-1 adapter used to connect the PC to the EIA-485 network shows a green LED
and pulses red when a connection is attempted. See the RSC-1 documentation for more
information.
• Each controller or device on the EIA-485 network has been programmed with a unique
MODBUS ID.
• A serial cross-over (Null Modem) cable is used for the connection between the PC and the
Morningstar RSC-1 485 Adapter. A straight-through serial cable will not work.
• Power is supplied to the 4-wire bus on the Power/Ground lines. The bus requires voltage
in the range: 8 - 16 Vdc.
• All bus connections are secure and each terminal is wired in parallel: line A to line A, line B
to line B, etc.
Problem:
Cannot connect to the controller via Ethernet
Solution:
see the TriStar MPPT Networking Companion Document, available on our website.
56
Troubleshooting
Warranty7.0
The TriStar MPPT charge controller is warranted to be free from defects in material and workmanship for a period of FIVE (5) years from the date of shipment to the original end user. Morningstar will, at its option, repair or replace any such defective products.
CLAIM PROCEDURE
Before requesting warranty service, check the Operator’s Manual to be certain that there is a
problem with the controller. Return the defective product to your authorized Morningstar distributor with shipping charges prepaid. Provide proof of date and place of purchase.
To obtain service under this warranty, the returned products must include the model, serial number and detailed reason for the failure, the module type, array size, type of batteries and system
loads. This information is critical to a rapid disposition of your warranty claim.
Morningstar will pay the return shipping charges if the repairs are covered by the warranty.
WARRANTY EXCLUSIONS AND LIMITATIONS
This warranty does not apply under the following conditions:
• Damage by accident, negligence, abuse or improper use.
• PV or load currents exceeding the ratings of the product.
• Unauthorized product modifi cation or attempted repair.
• Damage occurring during shipment.
THE WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE AND IN LIEU OF
ALL OTHERS, EXPRESS OR IMPLIED. MORNINGSTAR SPECIFICALLY DISCLAIMS ANY
AND ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. No Morningstar distributor, agent or employee is authorized to make any modifi cation or extension to this warranty.
MORNINGSTAR IS NOT RESPONSIBLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES
OF ANY KIND, INCLUDING BUT NOT LIMITED TO LOST PROFITS, DOWNTIME, GOODWILL
OR DAMAGE TO EQUIPMENT OR PROPERTY.
8 Pheasant Run
Newtown, PA 18940 USA
Email: info@morningstarcorp.com
Website: www.morningstarcorp.com
57TriStar MPPT Operator’s Manual
8.0 Specifi cations
Electrical
TS-MPPT-45 TS-MPPT-60
Nominal System Voltage 12, 24, 36, or 48 Volts dc
Maximum Battery Current 45 Amps 60 Amps
Maximum Solar Input Voltage 150 Volts dc
Battery Operating Voltage Range 8 - 72 Volts dc
Nominal Maximum Input Power:
12 Volt 600 Watts 800 Watts
24 Volt 1200 Watts 1600 Watts
48 Volt 2400 Watts 3200 Watts
Voltage Accuracy 12 / 24 V: ≤ 0.1 % ± 50 mV
48 V: ≤ 0.1 % ± 100 mV
Self consumption (tare loss) 1.3 - 2.7 Watts
Transient Surge Protection 4500 Watts / port
Battery Charging
Charging algorithm 4 - stage
Charging stages Bulk, Absorption, Float, Equalize
Temperature compensation coeffi cient -5 mV / °C / cell (25 °C ref.)
Temperature compensation range -30 °C to +80 °C
Temperature compensated setpoints Absorption, Float, Equalize, HVD
Charging Setpoints:
Settings
Switches
sw: 4-5-6 Volts Volts Volts Minutes Minutes Minutes Days
off-off-off 1 - Sealed* 14.00 13.70 150
off-off-on 2 - Sealed* 14.15 13.70 14.40 150 60 120 28
off-on-off 3 - Sealed* 14.30 13.70 14.60 150 60 120 28
off-on-on 4 - AGM/Flooded 14.40 13.70 15.10 180 120 180 28
on-off-off 5 - Flooded 14.60 13.50 15.30 180 120 180 28
on-off-on 6 - Flooded 14.70 13.50 15.40 180 180 240 28
on-on-off 7 - L-16 15.40 13.40 16.00 180 180 240 14
on-on-on 8 - Custom Custom Custom Custom Custom Custom Custom Custom
* “Sealed” battery type includes gel and AGM batteries
See section X.X for more information
Battery
Type
Absorp.
Stage
Float
Stage
Equalize
Stage
Absorp.
Time
Equalize
Time
Equalize
Timeout
Equalize
Interval
NOTE:
All charging voltage setpoints listed are for 12 Volt systems.
Multiply 2X for 24 Volt systems, 4X for 48 Volt systems.
58 Specifi cations
Battery Charging Status LEDs
LED Indication Battery Charging Status
Green Flashing (fast) - 2 to 3 times per second Equalize charging stage
Green Flashing - 1/2 sec on, 1/2 sec off Absorption charging stage
Green Flashing (slow) - 1 sec on, 1 sec off Float charging stage
Green 13.3 Volts ≤ Vbattery
Green & Yellow 13.0 Volts ≤ Vbattery < 13.3 Volts
Yellow 12.7 Volts ≤ Vbattery < 13.0 Volts
Yellow & Red 12.0 Volts ≤ Vbattery < 12.7 Volts
Red Vbattery < 12.0 Volts
Mechanical
Dimensions (H) 291 mm / 11.44”
(W) 130 mm / 5.12”
(D) 142 mm / 5.58”
Product Weight 4.14 kg / 9 lbs 2 oz
Shipping Weight (2 pcs/carton) 11.6 kg / 25 lbs 9oz
Power terminals:
Minimum wire size 2.5 mm2 / 14 AWG
Maximum wire size 35 mm2 / 2 AWG
Recommended torque 5.65 Nm / 50 in-lb
RTS / Sense terminals:
Minimum wire size 0.25 mm2 / 24 AWG
Maximum wire size 1.0 mm2 / 16 AWG
Recommended torque 0.40 Nm / 3.5 in-lb
Knockouts (trade sizes) M20 & 1/2”, 1”, 1 - 1/4”
Mounting Vertical surface
Environmental
Ambient Temperature Range -40 °C to +45 °C
Storage Temperature -55 °C to +100 °C
Humidity 100% N.C.
Enclosure IP20
Type 1 (indoor & vented)
Protections
Solar high voltage disconnect
Solar high voltage reconnect
Battery high voltage disconnect
Battery high voltage reconnect
High temperature disconnect
High temperature reconnect
59TriStar MPPT Operator’s Manual
Deratings
Figure 8-7. Battery Current vs. Array Voltage
Figure 8-8. Battery Current vs. Heatsink Temperature
60
Specifi cations
E ciency
98
TriStar MPPT 12 Volt Efficiency
97
96
95
94
93
92
efficiency (%)
91
90
89
88
50 100 150 200 250 300 350 400 450 500 550 600 650 700 750
0
output power (Watts)
Battery @ 12.8 V, 25 C ambient, fi rmware ver. 08 or later
13 Vmp
16.5 Vmp
66 Vmp
98 Vmp
TriStar MPPT 24 Volt Efficiency
99
98
97
96
95
94
93
efficiency (%)
92
91
90
89
100 200 300 400 500 600 700 800 900 1000 1100 1200 1300 1400 1500
0
output power (Watts)
Battery @ 25.6 V, 25 C ambient, fi rmware ver. 08 or later
26 Vmp
33 Vmp
66 Vmp
98 Vmp
61TriStar MPPT Operator’s Manual
100
TriStar MPPT 48 Volt Efficiency
99
98
97
96
95
94
efficiency (%)
93
92
91
90
200 400 600 800 1000 1200 1400 1600 1800 2000 2200 2400 2600 2800 30000
output power (Watts)
Battery @ 51.2 V, 25 C ambient, fi rmware ver. 08 or later
52 Vmp
66 Vmp
83 Vmp
98 Vmp
62
Specifi cations
Certi cations
UL1741 INVERTERS, CONVERTERS, AND
CONTROLLERS AND INTERCONNECTION SYSTEM
EQUIPMENT FOR USE WITH DISTRIBUTED ENERGY
SOURCES, FIRST EDITION, REVISION THROUGH AND
INCLUDING NOV 7, 2005
3094762
CSA C22.2 No. 107.1-01
EMC Directives
• Immunity: EN61000-6-2:1999
• Emissions: EN55022:1994 with A1 and A3 Class B1
• Safety: EN60335-1 and EN60335-2-29 (battery chargers)
RoHS
Compliant
2002/95/EC
63TriStar MPPT Operator’s Manual
2% Voltage Drop Charts for 75°C Stranded Copper Wire
1-Way Wire Distance (feet), 12 Volt System
Wire Size
(AWG)
2/0 ** 22.4 24.4 26.9 29.9 33.6 38.4 44.8 53.8 67.2 89.6
1/0 ** 17.8 19.4 21.3 23.7 26.6 30.4 35.5 42.6 53.3 71.0
2 11.2 12.2 13.4 14.9 16.8 19.1 22.3 26.8 33.5 44.7
4 7.0 7.7 8.4 9.4 10.6 12.1 14.1 16.9 21.1 28.1
6 4.4 4.8 5.3 5.9 6.6 7.6 8.8 10.6 13.2 17.7
8 2.8 3.0 3.3 3.7 4.2 4.8 5.6 6.7 8.4 11.1
10 1.7 1.9 2.1 2.3 2.6 3.0 3.5 4.2 5.2 7.0
12 1.1 1.2 1.3 1.5 1.6 1.9 2.2 2.6 3.3 4.4
14 0.7 0.8 0.8 0.9 1.0 1.2 1.4 1.7 2.1 2.8
Table 8-1. Maximum 1-way wire distance for 12 Volt systems, stranded copper, 2% voltage drop
Wire Size
(mm2)
70 ** 6.83 7.45 8.20 9.11 10.24 11.71 13.66 16.39 20.49 27.32
50 ** 5.41 5.91 6.50 7.22 8.12 9.28 10.83 12.99 16.24 21.65
35 3.40 3.71 4.08 4.54 5.11 5.84 6.81 8.17 10.21 13.62
25 2.14 2.34 2.57 2.86 3.22 3.68 4.29 5.15 6.43 8.58
16 1.35 1.47 1.61 1.79 2.02 2.31 2.69 3.23 4.04 5.38
10 0.85 0.93 1.02 1.13 1.27 1.46 1.70 2.04 2.55 3.40
6 0.53 0.58 0.64 0.71 0.80 0.91 1.07 1.28 1.60 2.13
4 0.33 0.36 0.40 0.44 0.50 0.57 0.67 0.80 1.00 1.33
2.5 0.21 0.23 0.25 0.28 0.32 0.36 0.42 0.50 0.63 0.84
Table 8-2. Maximum 1-way wire distance for 12 Volt systems, solid copper, 2% voltage drop
60
Amps55Amps50Amps45Amps40Amps35Amps30Amps25Amps20Amps15Amps
1-Way Wire Distance (meters), 12 Volt System
60
Amps55Amps50Amps45Amps40Amps35Amps30Amps25Amps20Amps15Amps
** Wires sizes larger than 2 AWG (35 mm2) must be terminated at a splicer block located outside of the TriStar MPPT wiring box.
Use 2 AWG (35 mm2) or smaller wire to connect to the TriStar MPPT to the splicer block.
Notes:
• The specifi ed wire length is for a pair of conductors from the solar or battery source to the
controller (1-way distance)
• For 24 volt systems, multiply the 1-way length in the table by 2.
• For 48 volt systems, multiply the 1-way length in the table by 4.
• Shaded cells in the table indicate that the current exceeds the ampacity of the wire for a
given ambient temperature as defi ned in the following table:
Wire Ampacity* Key
Exceeds wire ampacity at 60°C ambient temperature
Exceeds wire ampacity at 50°C ambient temperature
64
Exceeds wire ampacity at 40°C ambient temperature
Exceeds wire ampacity at 30°C ambient temperature
Specifi cations
*Ampacity for not more than three current-carrying conductors in a raceway, cable, or earth
(buried).
2% Voltage Drop Charts for 75°C Solid Copper Wire
1-Way Wire Distance (feet), 12 Volt System
Wire Size
(AWG)
2/0 ** 27.8 30.3 33.4 37.1 41.7 47.7 55.6 66.7 83.4 111.2
1/0 ** 22.0 24.1 26.5 29.4 33.1 37.8 44.1 52.9 66.1 88.2
2 13.9 15.1 16.6 18.5 20.8 23.8 27.7 33.3 41.6 55.4
4 8.7 9.5 10.5 11.6 13.1 14.9 17.4 20.9 26.2 34.9
6 5.5 6.0 6.6 7.3 8.2 9.4 11.0 13.2 16.5 21.9
8 3.4 3.8 4.1 4.6 5.2 5.9 6.9 8.3 10.3 13.8
10 2.2 2.4 2.6 2.9 3.3 3.7 4.3 5.2 6.5 8.7
12 1.4 1.5 1.6 1.8 2.0 2.3 2.7 3.3 4.1 5.5
14 0.9 0.9 1.0 1.1 1.3 1.5 1.7 2.1 2.6 3.4
Table 8-3. Maximum 1-way wire distance for 12 Volt systems, solid copper, 2% voltage drop
Wire Size
(mm2)
70 ** 8.47 9.24 10.17 11.30 12.71 14.53 16.95 20.34 25.42 33.90
50 ** 6.72 7.33 8.06 8.96 10.08 11.52 13.44 16.13 20.16 26.88
35 4.23 4.61 5.07 5.63 6.34 7.24 8.45 10.14 12.68 16.90
25 2.66 2.90 3.19 3.54 3.99 4.56 5.32 6.38 7.97 10.63
16 1.67 1.82 2.01 2.23 2.51 2.87 3.34 4.01 5.01 6.69
10 1.05 1.15 1.26 1.40 1.58 1.80 2.10 2.52 3.15 4.21
6 0.66 0.72 0.79 0.88 0.99 1.13 1.32 1.59 1.98 2.64
4 0.42 0.45 0.50 0.55 0.62 0.71 0.83 1.00 1.25 1.66
2.5 0.26 0.29 0.31 0.35 0.39 0.45 0.52 0.63 0.78 1.05
Table 8-4. Maximum 1-way wire distance for 12 Volt systems, solid copper, 2% voltage drop
60
Amps55Amps50Amps45Amps40Amps35Amps30Amps25Amps20Amps15Amps
1-Way Wire Distance (meters), 12 Volt System
60
Amps55Amps50Amps45Amps40Amps35Amps30Amps25Amps20Amps15Amps
** Wires sizes larger than 2 AWG (35 mm2) must be terminated at a splicer block located outside of the TriStar MPPT wiring box.
Use 2 AWG (35 mm2) or smaller wire to connect to the TriStar MPPT to the splicer block.
Notes:
• The specifi ed wire length is for a pair of conductors from the solar or battery source to the
controller (1-way distance)
• For 24 volt systems, multiply the 1-way length in the table by 2.
• For 48 volt systems, multiply the 1-way length in the table by 4.
• Shaded cells in the table indicate that the current exceeds the ampacity of the wire for a
given ambient temperature as defi ned in the following table:
Wire Ampacity* Key
Exceeds wire ampacity at 60°C ambient temperature
Exceeds wire ampacity at 50°C ambient temperature
Exceeds wire ampacity at 40°C ambient temperature
Exceeds wire ampacity at 30°C ambient temperature
*Ampacity for not more than three current-carrying conductors in a raceway, cable, or earth
(buried).
65TriStar MPPT Operator’s Manual
2% Voltage Drop Charts for 90°C Stranded Copper Wire
1-Way Wire Distance (feet), 12 Volt System
Wire Size
(AWG)
2/0 ** 22.4 24.4 26.9 29.9 33.6 38.4 44.8 53.8 67.2 89.6
1/0 ** 17.8 19.4 21.3 23.7 26.6 30.4 35.5 42.6 53.3 71.0
2 11.2 12.2 13.4 14.9 16.8 19.1 22.3 26.8 33.5 44.7
4 7.0 7.7 8.4 9.4 10.6 12.1 14.1 16.9 21.1 28.1
6 4.4 4.8 5.3 5.9 6.6 7.6 8.8 10.6 13.2 17.7
8 2.8 3.0 3.3 3.7 4.2 4.8 5.6 6.7 8.4 11.1
10 1.7 1.9 2.1 2.3 2.6 3.0 3.5 4.2 5.2 7.0
12 1.1 1.2 1.3 1.5 1.6 1.9 2.2 2.6 3.3 4.4
14 0.7 0.8 0.8 0.9 1.0 1.2 1.4 1.7 2.1 2.8
Table 8-5. Maximum 1-way wire distance for 12 Volt systems, stranded copper, 2% voltage drop
Wire Size
(mm2)
70 ** 6.83 7.45 8.20 9.11 10.24 11.71 13.66 16.39 20.49 27.32
50 ** 5.41 5.91 6.50 7.22 8.12 9.28 10.83 12.99 16.24 21.65
35 3.40 3.71 4.08 4.54 5.11 5.84 6.81 8.17 10.21 13.62
25 2.14 2.34 2.57 2.86 3.22 3.68 4.29 5.15 6.43 8.58
16 1.35 1.47 1.61 1.79 2.02 2.31 2.69 3.23 4.04 5.38
10 0.85 0.93 1.02 1.13 1.27 1.46 1.70 2.04 2.55 3.40
6 0.53 0.58 0.64 0.71 0.80 0.91 1.07 1.28 1.60 2.13
4 0.33 0.36 0.40 0.44 0.50 0.57 0.67 0.80 1.00 1.33
2.5 0.21 0.23 0.25 0.28 0.32 0.36 0.42 0.50 0.63 0.84
Table 8-6. Maximum 1-way wire distance for 12 Volt systems, stranded copper, 2% voltage drop
60
Amps55Amps50Amps45Amps40Amps35Amps30Amps25Amps20Amps15Amps
1-Way Wire Distance (meters), 12 Volt System
60
Amps55Amps50Amps45Amps40Amps35Amps30Amps25Amps20Amps15Amps
** Wires sizes larger than 2 AWG (35 mm2) must be terminated at a splicer block located outside of the TriStar MPPT wiring box.
Use 2 AWG (35 mm2) or smaller wire to connect to the TriStar MPPT to the splicer block.
Notes:
• The specifi ed wire length is for a pair of conductors from the solar or battery source to the
controller (1-way distance)
• For 24 volt systems, multiply the 1-way length in the table by 2.
• For 48 volt systems, multiply the 1-way length in the table by 4.
• Shaded cells in the table indicate that the current exceeds the ampacity of the wire for a
given ambient temperature as defi ned in the following table:
Wire Ampacity* Key
Exceeds wire ampacity at 60°C ambient temperature
Exceeds wire ampacity at 50°C ambient temperature
66
Exceeds wire ampacity at 40°C ambient temperature
Exceeds wire ampacity at 30°C ambient temperature
Specifi cations
*Ampacity for not more than three current-carrying conductors in a raceway, cable, or earth
(buried).
2% Voltage Drop Charts for 90°C Solid Copper Wire
1-Way Wire Distance (feet), 12 Volt System
Wire Size
(AWG)
2/0 ** 27.8 30.3 33.4 37.1 41.7 47.7 55.6 66.7 83.4 111.2
1/0 ** 22.0 24.1 26.5 29.4 33.1 37.8 44.1 52.9 66.1 88.2
2 13.9 15.1 16.6 18.5 20.8 23.8 27.7 33.3 41.6 55.4
4 8.7 9.5 10.5 11.6 13.1 14.9 17.4 20.9 26.2 34.9
6 5.5 6.0 6.6 7.3 8.2 9.4 11.0 13.2 16.5 21.9
8 3.4 3.8 4.1 4.6 5.2 5.9 6.9 8.3 10.3 13.8
10 2.2 2.4 2.6 2.9 3.3 3.7 4.3 5.2 6.5 8.7
12 1.4 1.5 1.6 1.8 2.0 2.3 2.7 3.3 4.1 5.5
14 0.9 0.9 1.0 1.1 1.3 1.5 1.7 2.1 2.6 3.4
Table 8-7. Maximum 1-way wire distance for 12 Volt systems, solid copper, 2% voltage drop
Wire Size
(mm2)
70 ** 8.47 9.24 10.17 11.30 12.71 14.53 16.95 20.34 25.42 33.90
50 ** 6.72 7.33 8.06 8.96 10.08 11.52 13.44 16.13 20.16 26.88
35 4.23 4.61 5.07 5.63 6.34 7.24 8.45 10.14 12.68 16.90
25 2.66 2.90 3.19 3.54 3.99 4.56 5.32 6.38 7.97 10.63
16 1.67 1.82 2.01 2.23 2.51 2.87 3.34 4.01 5.01 6.69
10 1.05 1.15 1.26 1.40 1.58 1.80 2.10 2.52 3.15 4.21
6 0.66 0.72 0.79 0.88 0.99 1.13 1.32 1.59 1.98 2.64
4 0.42 0.45 0.50 0.55 0.62 0.71 0.83 1.00 1.25 1.66
2.5 0.26 0.29 0.31 0.35 0.39 0.45 0.52 0.63 0.78 1.05
Table 8-8. Maximum 1-way wire distance for 12 Volt systems, solid copper, 2% voltage drop
60
Amps55Amps50Amps45Amps40Amps35Amps30Amps25Amps20Amps15Amps
1-Way Wire Distance (meters), 12 Volt System
60
Amps55Amps50Amps45Amps40Amps35Amps30Amps25Amps20Amps15Amps
** Wires sizes larger than 2 AWG (35 mm2) must be terminated at a splicer block located outside of the TriStar MPPT wiring box.
Use 2 AWG (35 mm2) or smaller wire to connect to the TriStar MPPT to the splicer block.
Notes:
• The specifi ed wire length is for a pair of conductors from the solar or battery source to the
controller (1-way distance)
• For 24 volt systems, multiply the 1-way length in the table by 2.
• For 48 volt systems, multiply the 1-way length in the table by 4.
• Shaded cells in the table indicate that the current exceeds the ampacity of the wire for a
given ambient temperature as defi ned in the following table:
Wire Ampacity* Key
Exceeds wire ampacity at 60°C ambient temperature
Exceeds wire ampacity at 50°C ambient temperature
Exceeds wire ampacity at 40°C ambient temperature
Exceeds wire ampacity at 30°C ambient temperature
*Ampacity for not more than three current-carrying conductors in a raceway, cable, or earth
(buried).
67TriStar MPPT Operator’s Manual
TriStarTM, TriStar MPPTTM, MeterBus
MODBUSTM and MODBUS TCP/IPTM are trademarks of Modbus IDA. www.modbus-ida.org
TM
are trademarks of Morningstar Corporation
RoHS
© 2010 Morningstar Corporation. All rights reserved.
MS-ZMAN-TSMPPT-01
v04
03/2010
Loading...
