Tripp%Lite%Integrated%Solutions!

Maximize the availability, manageability and efficiency
of your critical network systems with cost-effective
infrastructure solutions from a single, trusted source.

 3URYLGHUHOLDEOHHI¿FLHQWSRZHUZLWKEDWWHU\EDFNXS

 &RRORUJDQL]HVHFXUHDQGFRQQHFWFULWLFDOV\VWHPV

 0DQDJHSRZHUDQGHTXLSPHQWIURPDQ\ORFDWLRQ

CONTENTS

Introduction 2–3

APPLICATION
SCENARIOS

Remote Cabinet 4

Back Office 5

Network
Closet / IDF

Server Room 8–9

Data Center
& MDF

6–7

10–11

COMPONENTS

UPS Systems 12–13

Rack & Cooling
Solutions

Power
Distribution Units

Cables &
Connectivity

Network
Management
Tools

Service &
Support

14–15

16–17

18–19

17

20

INTEGRATED SOLUTIONS – INTRODUCTION

7KLQN%H\RQGWKH%R[

Tr ip p Lite is known for building reliable products at an affordable

price, but what really sets us apart is our willingness to work closely

with you before, during and after your purchase. Some suppliers

think a stack of cardboard boxes is a solution. You’re left to figure

out the details of making everything function with your existing

systems—which is most of the work—and you might even be

expected to scrap costly equipment and start from scratch.

When you choose Tripp Lite, our reseller partners and experienced

project engineers will help you customize a fully integrated

solution that’s individually tailored to fit your unique requirements.

Through our complimentary Solution Integration Service, we do

a lot of the hard work for you at no additional cost. We assess your

situation and provide actionable recommendations to ensure that

your solution will provide the availability, manageability, efficiency

and affordability you need to meet your goals.

Why do we give away valuable advice that other companies

charge for? Because when you compare the features and value of

a Tripp Lite integrated solution to the competition, we believe that

you’ll choose us. And after you’ve worked with us, we’re confident

that you’ll be a repeat customer.

The Solution Integration Service will help you:

s DEFINE objectives and technical requirements

s EVALUATE the installation site, including existing systems

and infrastructure

s EXAMINE systems to ensure they’re correctly powered,

protected and configured

s AUDIT power capacity requirements to right-size systems

before consolidation, virtualization and other projects

s PLAN airflow management and cooling for low-, medium- or

high-density deployments

s PREPARE for future infrastructure growth and evolving IT

requirements

s INTEGRATE components with existing systems.

We’ll provide a roadmap with detailed project requirements,

BOMs, specifications, installation considerations and ongoing

support options for your Tripp Lite integrated solution, including

preventative maintenance, extended warranties, on-site services

and rapid repair and replacement. We’ll also provide clear

alternatives that allow you to strike a balance between technical

and budgetary considerations.

Try our free

Solution Integration

Service! Our experienced

project engineers will choose

from over 3,000 products to

customize an integrated

solution for you.

Tripp Lite integrated solution benefits:

MAXIMIZE AVAILABILITY

s Combine reliable power, expandable battery backup, remote

management, robust security, built-in redundancy, hot-

swappable components and flexible cooling options to avoid

the unaffordable cost of network downtime, which averages

$70,000 per hour for midsize businesses.

SIMPLIFY MANAGEMENT

(Source: IDC, 2009.)

Manage power and equipment from any location

s Use Tripp Lite’s free PowerAlert Network Management

System and your favorite management tools through a

secure, centralized gateway.

s Manage critical systems, power, environmental sensors,

security and alarms from any location so you can spend less

time traveling and more time solving problems.

OPTIMIZE EFFICIENCY

s Reduce energy use with Economy Mode UPS operation.

s Schedule Economy Mode to provide maximum protection

during peak hours and maximum efficiency during off hours.

s Schedule automated equipment idling through remotely

switchable outlets.

+RZWR%HJLQ

Review the application scenarios in this brochure for a

sample of the thousands of Tripp Lite products and millions

of combinations available. When you’re ready to take the

next step, contact us for a custom solution tailored to

fit your unique requirements. Our experienced project

engineers are ready to assist you at no additional cost.

s Increase cooling efficiency with full support of IT best

practices like hot-aisle /cold-aisle configurations.

LOWER TCO

s Upgrade your infrastructure incrementally without scrapping

existing investments, lowering initial hardware costs.

s Lower operating costs with efficient green technology and

right-sized equipment.

s Lower service costs with reduced maintenance requirements

and self-service options.

s Increase productivity with remote management, allowing

valuable IT personnel to cover more ground in less time.

Tripp Lite Integrated Solutions are designed to work with your existing equipment, regardless of vendor.

3

INTEGRATED SOLUTIONS – APPLICATION SCENARIOS

6FHQDULR5HPRWH&DELQHW

Common Equipment Supported: Router, Switches, Wireless Access Typical Size: 1 Wall-Mount Rack Enclosure

RECOMMENDED TRIPP LITE SOLUTIONS FOR REMOTE CABINETS

UPS Systems (See pp. 12-13 for more information.)

x 1-3kVA SmartOnline™ UPS Systems

(SU1000RTXL2UA, SU1500RTXL2UA, SU2200RTXL2UA, SU3000RTXL2U)

x 1-3kVA SmartPro® Line-Interactive UPS Systems

(SMART1000RM1U, SMART1500RMXL2UA, SMART2200RM2U,

SMART3000RM2U)

Rack & Cooling Solutions (See pp. 14-15 for more information.)

x 6-26U SmartRack™ Wall-Mount Rack Enclosures

(SRW6U, SRW9U, SRW10US, SRW12US, SRW18US, SRW26US)

x 12U SmartRack Extra-Deep Wall-Mount Rack Enclosure

(SRW12US33 – Extra depth accommodates standard 1U servers.)

x 1U Blanking Panels (SR1UPANEL10 – Includes 10 x 1U panels.)

x Rolling Caster Kit

(SRCASTER – Adapts wall-mount enclosures to floor-standing applications.)

Return Air Vent
(Above Dropped Ceiling)

12U SmartRack Wall-Mount
Rack Enclosure

A sturdy hinge between the
cabinet and the wall bracket
allows you to swing the
cabinet away from the
wall for easy access
to equipment and
cabling.

Power Distribution Units (See pp. 16-17 for more information.)

x Hot-Swap PDU (Adds hot-swap capability to <3kVA UPS.)

x Switched PDUs with Automatic Transfer Switch (ATS)

(PDUMH15ATNET, PDUMH20ATNET)

x Metered PDUs (PDUMH15, PDUMH20)

Network Management Tools (See pp. 18-19 for more information.)

x UPS Network Management Card (SNMPWEBCARD)

x Environmental Sensor

(ENVIROSENSE – Monitors temperature, humidity and dry contacts.)

x PowerAlert Network Management System (Included with UPS.)

x Compact IP Console Servers (B095-004-1E, B095-003-1E-M)

Cables & Connectivity (See p. 17 for more information.)

x Power Cables, Network Cables & Network Patch Panels

Network Cables

Compact IP

Console Server

Network

Patch Panels

Third-Party

Network Switches

Hot-Swap PDU

UPS with Network

Management Card

4

6FHQDULR%DFN2I¿FH

Common Equipment Supported: Servers, Storage, Router, Switches, Phone System Typical Size: 1-3 Rack Enclosures

RECOMMENDED TRIPP LITE SOLUTIONS FOR BACK OFFICES

UPS Systems (See pp. 12-13 for more information.)

x 5-10kVA SmartOnline Hot-Swappable UPS Systems

(SU5000RT4U, SU6000RT4UHV, SU8000RT3U, SU10KRT3U, SU10000RT3U)

x 1-5kVA SmartOnline UPS Systems

(SU1000RTXL2UA, SU1500RTXL2UA, SU2200RTXL2UA, SU3000RTXL2U,

SU5000RT4UTF)

x Additional External Battery Packs (Provide extended runtime.)

Rack & Cooling Solutions (See pp. 14-15 for more information.)

x 42U SmartRack Rack Enclosure (SR42UB)

x 25U SmartRack Rack Enclosure (SR25UB)

x 12U SmartRack Wall-Mount Rack Enclosure (SRW12US)

x 12U SmartRack Rack Enclosure (SR12UB – Similar to SRW12US,

with extra depth for 1U servers and casters for floor-standing applications.)

x 12,000 BTU Compact Air Conditioning Unit (SRCOOL12K)

x 1U Blanking Panels (SR1UPANEL10, SR1UPANEL50)

x Vertical Cable Managers

(SRCABLEDUCTVRT, SRCABLERINGVRT)

x Cable Ladder (SRCABLELADDER with SRLADDERATTACH)

Return Air Vent
(Above Dropped Ceiling)

Power Distribution Units (See pp. 16-17 for more information.)

x Switched PDUs (PDUMV20HVNET, PDUMV30HVNET)

x Hot-Swap PDU

(Adds hot-swap capability to <3kVA UPS.)

x Metered PDUs (PDUMV20HV, PDUMV30HV)

Network Management Tools (See pp. 18-19 for more information.)

x UPS Network Management Card (SNMPWEBCARD)

x Environmental Sensor

(ENVIROSENSE – Monitors temperature, humidity and dry contacts.)

x PowerAlert Network Management System (Included with UPS.)

x IP Console Server with KVM Console Ports

(B092-016)

x Compact IP Console Servers (B095-004-1E, B095-003-1E-M)

x NetDirector™ 1U Rack Consoles (B021-000-17, B021-000-19)

x NetDirector 1U Console KVM Switches with IP Access

(B020-U08-19-IP, B020-016-17-IP)

Cables & Connectivity (See p. 17 for more information.)

x Power Cables, Network Cables & Network Patch Panels

Compact Air
Conditioning Unit
Exhaust Duct

Third Party Servers

IP Console Server

Compact Air
Conditioning Unit

42U SmartRack Rack Enclosure

SmartOnline Hot-Swappable UPS
with Network Management Card
and Environmental Sensor

Additional
Battery Packs

Switched PDU

NetDirector
1U Rack Console

Rack consoles and
console KVM switches
fold and slide into a
1U rack drawer
for compact
storage
and easy
access.

Network Cables

Cable Ladder

12U SmartRack

Wall-Mount Rack

Enclosure

Compact IP

Console Server

Network

Patch Panels

Third-Party

Network Switches

Hot-Swap PDU

UPS with Network

Management Card

5

INTEGRATED SOLUTIONS – APPLICATION SCENARIOS

6FHQDULR1HWZRUN&ORVHW,'),QWHUPHGLDWH'LVWULEXWLRQ)UDPH

Common Equipment Supported: Routers, Switches, Wireless Access, Phone System Ty pi ca l Si ze : 1–3 Open Frame Racks

RECOMMENDED TRIPP LITE SOLUTIONS FOR NETWORK CLOSETS

UPS Systems (See pp. 12-13 for more information.)

x 5-20kVA SmartOnline Hot-Swappable UPS Systems

(SU5000RT4U, SU6000RT4UHV, SU8000RT3U, SU16KRT, SU20KRT)

x 1-5kVA SmartOnline UPS Systems

(SU1000RTXL2UA, SU1500RTXL2UA, SU2200RTXL2UA, SU3000RTXL2U,

SU5000RT4UTF)

x 1-5kVA SmartPro Line-Interactive UPS Systems

(SMART1000RM1U, SMART1500RM2U, SMART2200RMXL2U,

SMART3000RM2U, SMART5000XFMRXL)

x 1.5-3kVA SmartPro Shallow-Depth Line-Interactive
UPS Systems

(SMART1500CRMXL, SMART2200CRMXL, SMART3000CRMXL)

x Additional External Battery Packs (Provide extended runtime.)

Rack & Cooling Solutions (See pp. 14-15 for more information.)

x 45U SmartRack 2-Post Open Frame Rack

(SR2POST)

x 45U SmartRack 4-Post Open Frame Rack

(SR4POST)

x 42U SmartRack Heavy-Duty 4-Post Open Frame Rack

(SR42UBEXPND)

x 42U SmartRack Rack Enclosures

(SR42UB, SR42UBWD, SR42UBDP, SR42UBDPWD)

x 42U SmartRack Knockdown Rack Enclosure

(SR42UBKD – Ships partially disassembled for installation

in confined spaces.)

x SmartRack Wall-Mount Open Frame Rack

(SRWO12US – Mounting frame pivots for easy access.)

x 12,000 BTU Compact Air Conditioning Unit

(SRCOOL12K)

x High-Capacity Cable Managers

(SRCABLEVRT6, SRCABLEVRT12)

x Vert ical Cab le Managers

(SRCABLEDUCTVRT, SRCABLERINGVRT)

x Cable Ladder

(SRCABLELADDER with SRLADDERATTACH)

x Heavy-Duty 2-Post Mounting Kit

(2POSTRMKITHD)

x Heavy-Duty Mounting Ear Kit (UPSHDEARKIT)

x Rack Bolt-Down Kit (SRBOLTDOWN)

x Cantilever Rack Shelves (SRSHELF2P, SRSHELF2P1U)

Power Distribution Units (See pp. 16-17 for more information.)

x Switched PDUs

(PDUMV20HVNET, PDUMV30HVNET, PDUMH20HVNET,
PDUMH30HVNET)

x Switched PDUs with Automatic Transfer Switch (ATS)

(PDUMH15ATNET, PDUMH20ATNET)

x Monitored PDUs (PDUMNV20HV, PDUMNV30HV)

x Metered PDUs

x Hot-Swap PDUs

(PDUMV20HV, PDUMV30HV)

(Add hot-swap capability to <3kVA UPS.)

Network Management Tools (See pp. 18-19 for more information.)

x UPS Network Management Card (SNMPWEBCARD)

x Environmental Sensor

(ENVIROSENSE – Monitor temperature, humidity and dry contacts.)

x PowerAlert Network Management System (Included with UPS.)

x IP Console Server Management Switch

(B096-048)

x Compact IP Console Servers (B095-004-1E, B095-003-1E-M)

Cables & Connectivity (See p. 17 for more information.)

x Network Cables (Copper & Fiber-Optic)

x Network Patch Panels (Copper & Fiber-Optic)

x Power Cables

6

Tripp Lite Integrated Solutions are designed to work with your existing equipment, regardless of vendor.

Return Air Vent
(Above Dropped Ceiling)

Compact IP
Console Server

Network Patch Panels

Third-Party Modular
Network Switch

Switched PDU

Third-Party
Network
Switches

IP Console Server

Network Cables

Cable Ladder

Switched PDU

with ATS

Redundant

SmartOnline

UPS Systems

SmartOnline Hot-Swappable
Parallel UPS (N+1) with
Network Management Card

45U SmartRack 2-Post
Open Frame Rack

Switched PDU

Third-Party Network Switches

High-Capacity Cable Manager

SmartOnline

Hot-Swappable

UPS with Network

Management Card

Additional Battery Pack

12U SmartRack Wall-Mount Open Frame Rack

The mounting frame pivots and locks in place for
convenient access to equipment and cabling.

Cooling an
Enclosure

SUPPLEMENTAL COOLING OPTIONS

Cooling a
Hot Spot

Cooling a Room

The 12,000 BTU Compact Air Conditioning Unit provides three supplemental cooling options:

1. It can cool an overheating rack enclosure, spreading cold air across multiple equipment intakes.

2. It can cool a specific equipment hot spot, delivering cold air directly into the overheating device.

3. It can cool a room that is cut off from facility HVAC or overheating due to environmental conditions.

7

INTEGRATED SOLUTIONS – APPLICATION SCENARIOS

6FHQDULR6HUYHU5RRP

Common Equipment Supported: Servers, Storage, Switches, Routers Typ ic al S iz e: 1–10 Rack Enclosures

RECOMMENDED TRIPP LITE SOLUTIONS FOR SERVER ROOMS

UPS Systems (See pp. 12-13 for more information.)

x 5-20kVA SmartOnline Hot-Swappable UPS Systems

(SU5000RT4U, SU6000RT4U, SU6000RT4UHV, SU8000RT3U, SU8000RT4U,
SU10000RT3U, SU12000RT4U, SU16000RT4U, SU16KRT, SU20KRT)

x 1-5kVA SmartOnline UPS Systems

(SU1000RTXL2UA, SU1500RTXL2UA, SU2200RTXL2UA, SU3000RTXL2U,
SU3000RTXL3U, SU3000RTXR3U, SU5000RT4UTF)

x 1-5kVA SmartPro Line-Interactive UPS Systems

(SMART1000RM1U, SMART3000RM2U, SMART5000XFMRXL)

x Centralized Power Option: 20-80kVA SmartOnline 3-Phase UPS
Systems

x Redundant

x Additional External Battery Packs

(SU20K3/3, SU30K3/3, SU40K, SU60K, SU80K)

(N+1 and/or 1+1) UPS Configuration

(Provide extended runtime.)

Rack & Cooling Solutions (See pp. 14-15 for more information.)

x 42U SmartRack Rack Enclosures (SR42UB, SR42UBEXP)

x 42U SmartRack Deep, Wide or Deep & Wide Rack Enclosures

(SR42UBDP, SR42UBWD, SR42UBDPWD)

x 12,000 BTU Compact Air Conditioning Unit (SRCOOL12K)

x High-Capacity Cable Managers

(SRCABLEVRT6, SRCABLEVRT12)

x Vertical Cable Manag ers (SRCABLEDUCTVRT, SRCABLERINGVRT)

x Horizontal Cable Managers

(SRCABLEDUCT1U, SRCABLERING1U, SRCABLERING2U)

x Cable Ladder (SRCABLELADDER)

x Cable Trough with Vertical Expansion

(SRCABLETRAY with SRCABLETRAYEXP)

x Airflow Management Accessories (SRGASKET, SRSKIRT, SR1UBRUSH)

x 1U Blanking Panels (SR1UPANEL10, SR1UPANEL50)

x Heat Removal Fan Door

(SRFANDOOR)

x Heat Removal Fan Roof Panel (SRFANROOF)

x 3U Heat Removal Fan Panel

x Rack Bolt-Down Kit

(SRBOLTDOWN)

x Anti-Tip Stabilizing Plate Kit

(SRFAN3U)

(SRSTABILIZE)

Power Distribution Units (See pp. 16-17 for more information.)

x Switched PDUs

(PDUMV20HVNET, PDUMV30HVNET, PDUMH15HVNET,
PDUMH20HVNET, PDUMH30HVNET)

x Switched PDUs with Automatic Transfer Switch (ATS)

(PDUMH15ATNET, PDUMH20ATNET)

x Monitored PDUs (PDUMNV20HV, PDUMNV30HV)

x Metered PDUs (PDUMV20HV, PDUMV30HV)

x Power Distribution Center

(SUDC208V42P – Distributes 120/208V single-phase and 208V 3-phase
output from 208V 3-phase input.)

x 3-Phase Monitored and Switched PDUs

Network Management Tools (See pp. 18-19 for more information.)

x UPS Network Management Card (SNMPWEBCARD)

x Environmental Sensor

(ENVIROSENSE – Monitor temperature, humidity and dry contacts.)

x PowerAlert Network Management System (Included with UPS)

x NetDirector 1U Console KVM Switches with IP Access

(B020-016-17-IP, B020-U08-19-IP)

x IP Console Server Management Switch (B096-048)

x IP Console Server with KVM Console Ports

(B092-016)

x NetDirector 1U Rack Consoles (B021-000-17, B021-000-19)

x NetDirector 1U Console KVM Switches with Cable Kits

(B020-U16-19-K, B020-U08-19-K)

x NetDirector Multiuser Cat5 KVM Switches with IP Access

(B064-032-04-IPG, B064-032-02-IPG, B064-016-04-IPG, B064-016-02-IPG)

Cables & Connectivity (See p. 17 for more information.)

x Network Cables (Copper & Fiber-Optic)

x Network Patch Panels (Copper & Fiber-Optic)

x Power Cables

8

Tripp Lite Integrated Solutions are designed to work with your existing equipment, regardless of vendor.

Return Air Vent
(Above Dropped Ceiling)

Cable Ladders

Network and
Power Cables

High-Capacity

Cable Manager

Cable Trough with
Vertical Expansion

42U SmartRack Wide

Rack Enclosure

Vertical

Cable

Manager

Third-Party CRAC Unit

Heat Removal Fan Door

3-Phase UPS Output

Heat Removal Fan Panel

Horizontal
Cable Manager

Maintenance
Bypass Panel

SmartOnline 3-Phase UPS &

External Battery Cabinet

Heat Removal

Fan Roof Panel

Switched PDU

IP Console

Server

SmartOnline Hot-Swappable

UPS with Network Management

Card and Environmental Sensor

Additional Battery Pack

NetDirector 1U Console KVM Switch

42U SmartRack Rack Enclosure

SmartOnline Hot-Swappable

UPS with Network Management

Card and Environmental Sensor

120V
PDU

208V
PDU

Power
Distribution

C E N T R A L I Z E D P O W E R O P T I O N

Center

Centralized Power Option: Centralized server room power can be provided through one or more
20-80kVA SmartOnline 3-Phase UPS Systems (up to 160kVA in parallel) located in the server room
or elsewhere in the facility. The Power Distribution Center extracts single-phase 120V or 208V
power from the 3-phase 208V input and distributes it to PDUs in individual racks through output
breakers and cord sets (whips). It can also distribute 3-phase 208V power to 3-phase PDUs.

9

INTEGRATED SOLUTIONS – APPLICATION SCENARIOS

COLD
AISLE

Scenario:*Data*Center*&*MDF*(Main*Distribution*Frame)*

Common Equipment Supported: Servers, Storage, Switches, Routers Typ ic al S iz e: 10+ Rack Enclosures

RECOMMENDED TRIPP LITE SOLUTIONS FOR DATA CENTERS

UPS Systems (See pp. 12-13 for more information.)

x In-Rack Power: 6-20kVA SmartOnline Hot-Swappable UPS
Systems

(SU6000RT4UHV, SU8000RT3U, SU10000RT3U, SU16KRT, SU20KRT)

x Centralized Power: 40-80kVA SmartOnline 3-Phase UPS
Systems

(SU40K, SU60K, SU80K)

x 3-Phase Maintenance Bypass Panel

x Redundant

x Additional External Battery Packs

(N+1 and/or 1+1) UPS Configuration

(Provide extended runtime.)

Rack & Cooling Solutions (See pp. 14-15 for more information.)

x 42U & 48U SmartRack Rack Enclosures

(SR42UB, SR42UBEXP, SR48UB, SR48UBEXP)

x 42U SmartRack Thermal Duct Rack Enclosures

(SR42UBTD, SR42UBWDTD – Adjustable overhead duct routes warm
equipment exhaust to facility HVAC return air stream.)

x 42U SmartRack Deep, Wide or Deep & Wide Rack Enclosures

(SR42UBDP, SR42UBWD, SR42UBDPWD)

x 42U & 48U SmartRack Colocation Rack Enclosures

(SR42UBCL, SR48UBCL – Divided into two secure compartments.)

x 45U SmartRack 2-Post Open Frame Rack (SR2POST)

x 45U SmartRack 4-Post Open Frame Rack (SR4POST)

x 42U SmartRack Heavy-Duty 4-Post Open Frame Rack

(SR42UBEXPND)

x High-Capacity Cable Managers (SRCABLEVRT6, SRCABLEVRT12)

x Cable Ladder (SRCABLELADDER)

x Cable Trough

x Vertical Cable Manag ers

(SRCABLETRAY with SRCABLETRAYEXP)

(SRCABLEDUCTVRT, SRCABLERINGVRT)

x Horizontal Cable Managers

(SRCABLEDUCT1U, SRCABLERING1U, SRCABLERING2U)

x Heat Removal Fan Door (SRFANDOOR)

x Airflow Management Accessories (SRGASKET, SRSKIRT, SR1UBRUSH)

x 1U Blanking Panels (SR1UPANEL10, SR1UPANEL50)

Power Distribution Units (See pp. 16-17 for more information.)

x Switched PDUs

(PDUMV20HVNET, PDUMV30HVNET, PDUMH20HVNET,
PDUMH30HVNET)

x Switched PDUs with Automatic Transfer Switch (ATS)

(PDUMH15ATNET, PDUMH20ATNET)

x Monitored PDUs (PDUMNV20HV, PDUMNV30HV)

x Metered PDUs (PDUMV20HV, PDUMV30HV)

x Power Distribution Center

(SUDC208V42P – Distributes 120/208V single-phase and 208V 3-phase
output from 208V 3-phase input.)

x 3-Phase Monitored and Switched PDUs

Network Management Tools (See pp. 18-19 for more information.)

x UPS Network Management Card (SNMPWEBCARD)

x Environmental Sensor

(ENVIROSENSE – Monitors temperature, humidity and dry contacts.)

x PowerAlert Network Management System

(Included with UPS)

x NetDirector 1U Console KVM Switches with IP Access

(B020-016-17-IP, B020-U08-19-IP)

x IP Console Server Management Switches

(B096-048, B096-016)

x IP Console Server with KVM Console Ports

(B092-016)

x NetDirector 1U Rack Consoles (B021-000-17, B021-000-19)

x NetDirector 1U Console KVM Switches with Cable Kits

(B020-U16-19-K, B020-U08-19-K)

x NetDirector Multiuser Cat5 KVM Switches with IP Access

(B064-032-04-IPG, B064-032-02-IPG, B064-016-04-IPG, B064-016-02-IPG)

Cables & Connectivity (See p. 17 for more information.)

x Network Cables (Copper & Fiber-Optic)

x Network Patch Panels (Copper & Fiber-Optic)

x Power Cables

10

Tripp Lite Integrated Solutions are designed to work with your existing equipment, regardless of vendor.

COLD
AISLE

Cable Trough

Horizontal Cable Manager

Third-Party CRAC Unit

Return Air Vent (Above Dropped Ceiling)

SmartOnline 3-Phase UPS with External Battery Cabinet

Maintenance Bypass Panel

Network and Power Cables

Cable Ladder

Raised Floor

High-Capacity Cable Manager

45U SmartRack 2-Post Open Frame Rack

42U SmartRack Enclosure

Cold
Aisle

NetDirector Console

KVM Switch

SmartOnline Hot-Swappable Parallel UPS (N+1) with

Network Management Card & Environmental Sensor

Switched PDU

Hot-Aisle / Cold-Aisle Configuration

COLD
AISLE

The data center can be powered by in-rack

single-phase UPS systems, centralized 3-phase

UPS systems or a combination of both (as shown).

42U SmartRack Thermal

Duct Rack Enclosure

HOT

AISLE

COLD
AISLE

HOT

AISLE

Hot-aisle / cold-aisle configurations increase data center
cooling efficiency, reducing energy use by up to 20%.

TDI Data Centers.)

Cold air passes through special floor tiles in

(Source:

the cold aisle, where it is drawn to equipment air intakes
through the perforated front door of each rack enclosure.
Hot exhaust air passes through the perforated rear doors of
each rack enclosure to the hot aisle and vents overhead.
Heat Removal Fan Doors and Thermal Duct Rack Enclosures
isolate and remove hot air for even greater cooling efficiency.

Economy Mode Operation

In Economy Mode, SmartOnline UPS
Systems save energy, eliminate heat and
reduce operating costs by implementing
dynamic double conversion. As long as
input power quality is satisfactory, the UPS system suspends
double conversion and operates with maximum efficiency. If
input power falls outside the satisfactory range, the UPS
system resumes double conversion until input power quality
improves. Replacing 160kVA of legacy on-line UPS capacity
with SmartOnline UPS Systems operating in Economy Mode
can save more than $20,000 per year.

Hot

IP Console Server

Vertical Cable Manager

Cold
Aisle

Power Distribution Center

Heat Removal Fan Door

Ideal Power for Critical Systems

SmartOnline UPS Systems provide ideal power for critical
network systems, isolating equipment from blackouts,
brownouts, overvoltages, surges, line noise, harmonic
distortion, electrical impulses and frequency variations. True
on-line double conversion delivers pure sine wave output
24x7 and complies with worldwide standards for voltage­and frequency-independent operation. No matter what your
power line throws at you—rolling blackouts, industrial power
fluctuations, dangerous transient voltages—your equipment
will continue to receive reliable power and your critical
network systems will stay up and running around the clock.

MANUAL
BYPASS

AC OUTPUT

AC SOURCE

BATTERY

AUTO

BYPASS

INVERTERRECTIFIER

MAXIMIZE SYSTEM
AVAILABILITY

with SmartOnline UPS Systems

UPS systems are crucial to maintaining system availability,
but the wrong UPS system can actually cause downtime.
Traditional UPS systems typically require you to power
down and disconnect your equipment during a UPS repair.
Before you can restore productivity, you’ll need a repair
technician to install the new UPS system and you’ll need to
reconnect, power up and test all your equipment.
SmartOnline Hot-Swappable UPS Systems eliminate these
shortcomings.

Estimated Repair Time Line for 5kVA+ UPS

All SmartOnline UPS Systems include hot-swappable
batteries and an automatic bypass that keeps your
equipment powered by utility power in the event of an
internal fault or overload. SmartOnline Hot-Swappable
UPS Systems also have one or more hot-swappable power
modules and a detachable PDU with a manual bypass
switch. After you turn the bypass switch, you can completely
remove and replace the power module while the
detachable PDU keeps your critical systems up and
running, effectively reducing mean time to repair (MTTR)
to zero. A SmartOnline Hot-Swappable UPS System can

eliminate 60 minutes of downtime during a single
repair, saving average midsize businesses up to $70,000
per incident.

(Source: IDC, 2009.)

Traditional UPS System

Schedule Downtime

(Typically After Hours) Hours to Days

Wait for UPS Repair Technician 4-24 hours

Shut Down & Disconnect Equipment 10+ minutes

Disconnect & Remove Old UPS 15 minutes

Install New UPS in Rack and Power Up 20 minutes

Plug In, Start Up & Test Equipment 15+ minutes

Total Repair Time 5-25+ hours

Total Downtime of Critical Systems 60+ minutes

Critical Systems

Traditional UPS

SmartOnline Hot-Swappable UPS System

Schedule Downtime Not Required

Wait for UPS Repair Technician Not Required

Turn Bypass Switch & Detach PDU 1 minute

Remove Old Power Module 1.5 minutes

Install New Power Module 1.5 minutes

Reattach PDU & Turn Bypass Switch 1 minute

Total Repair Time 5 minutes

Total Downtime of Critical Systems Zero

Critical Systems

Hot-Swappable
UPS Power Module

s #RITICAL 3YSTEMS
s #RITICAL 3YSTEMS !RE 5NPLUGGED
s !# )NPUT .EEDS 2EWIRING

During repair, critical systems are dead in the water while the
traditional UPS system is disconnected, replaced and rewired by
one or more costly service specialists – 60+ minutes of downtime
per incident, plus additional time scheduling the service outage
and waiting for the repair technician to arrive.

11 12

Are Still Plugged In

s !# )NPUT $OESNT

Need Rewiring

During repair, critical systems remain fully operational on bypass
power while the hot-swappable power module is disconnected,
replaced and reconnected by an IT staffer – zero downtime per
incident, with no waiting to schedule service outages and no
need to contract a costly repair technician.

Detachable PDU

Hot-Swappable Battery Pack

INTEGRATED SOLUTIONS – UPS SYSTEMS

UPS SYSTEMS

Core Function: Provide Reliable, Efficient Power with Expandable Battery Backup

s Keep critical network systems operating 24x7 through blackouts and other power problems.
s Reduce energy usage, heat production and electricity costs through Economy Mode operation.
s Provide remote power management via SNMP, Web or telnet, including free PowerAlert software.

SmartOnline True On-Line UPS Systems

Available in capacities from 750VA to 20kVA, SmartOnline UPS

Systems provide the best protection for critical network systems.

s 4RUE ONLINE DOUBLECONVERSION OPERATION DELIVERS PRECISION

regulated output continuously, isolating equipment from
power problems, including blackouts, brownouts,
overvoltages, surges, line noise, harmonic distortions,
electrical impulses and frequency variations.

s 2ELIABLE BATTERY BACKUP KEEPS EQUIPMENT OPERATING
through power failures.

s !N AUTOMATIC INTERNAL BYPASS KEEPS CONNECTED EQUIPMENT
powered if there’s an overload or internal fault.

SmartOnline UPS Systems Provide Maximum

Availability for Critical Network Systems

Remove the hot-swappable power module

for maintenance or repair...

s 0URE SINE WAVE OUTPUT AND ZERO TRANSFER TIME TO BATTERY

ensure compatibility with sensitive network equipment.

s %CONOMY -ODE OPERATION LOWERS OPERATING COSTS

s /PTIONAL 503 .ETWORK -ANAGEMENT #ARDS ENABLE

stand-alone remote monitoring and control via SNMP, Web
or telnet, including centralized power management via free
PowerAlert Network Management System.

s /PTIONAL EXTERNAL BATTERY PACKS PROVIDE UNLIMITED SCALABILITY

to meet any runtime requirement.

s )NTERNAL AND EXTERNAL BATTERIES ARE HOTSWAPPABLE

s 3MART/NLINE (OT3WAPPABLE 503 3YSTEMS INCLUDE A HOT

swappable power module and detachable PDU to allow UPS
maintenance, repair or replacement without interrupting
power and causing critical system downtime.

Tripp Lite Integrated Solutions are designed to work with your existing equipment, regardless of vendor.

...and the detachable PDU keeps your equipment

operating without an interruption.

“We chose Tripp Lite for two reasons: their

reputation as a leading UPS manufacturer

and the attractive price. Since the Tripp Lite

UPS was installed, we haven’t experienced

any equipment damage or downtime.”

Benny Chang, Systems Analyst
for Columbia Business School

SmartOnline 3-Phase UPS Systems

SmartPro Line-Interactive UPS Systems

Available in capacities up to 80kVA (160kVA in parallel),

SmartOnline 3-Phase UPS Systems employ 3-phase input and

output to provide higher capacity with fewer circuits in less space

per kVA than single-phase units.

s !DVANCED )'"4 RECTIFIER TECHNOLOGY PRODUCES LOW INPUT
total harmonic distortion to eliminate costly over-sizing
requirements.

s %CONOMY -ODE OPERATION PROVIDES INCREASED EFFICIENCY

which can reduce data center power and cooling costs by
more than $20,000 per year for each 160kVA load.

(Estimate assumes 96% vs. 86% efficiency and 24x7 duty cycle.)

s (OTSWAPPABLE K6! POWER MODULES PROVIDE INTERNAL .

redundancy and parallel configurations provide 1+1
redundancy or double output capacity.

s )F SERVICE OR REPAIR REQUIRES SHUTDOWN A MANUAL BYPASS

breaker and automatic bypass function maintain system
availability by passing through AC power until the system
returns to service.

s )NTERNAL AND EXTERNAL BATTERIES ARE HOTSWAPPABLE

SmartPro UPS Systems are available in capacities from 500VA to
5kVA. Line-interactive operation—also known as automatic
voltage regulation (AVR)—automatically adjusts abnormal input
voltages to safe levels.

s 2ELIABLE BATTERY BACKUP KEEPS EQUIPMENT OPERATING

through power failures.

s 0URE SINE WAVE OUTPUT MOST MODELS ENSURES COMPATIBILITY

with sensitive network equipment.

s /PTIONAL 503 .ETWORK -ANAGEMENT #ARDS ENABLE

stand-alone remote monitoring and control via SNMP, Web
or telnet, including centralized power management via
free PowerAlert Network Management System.

s /PTIONAL EXTERNAL BATTERY PACKS PROVIDE INCREASED BATTERY

backup runtime (select models).

s )NTERNAL AND EXTERNAL BATTERIES ARE HOTSWAPPABLE

s 3HALLOWDEPTH MODELS ARE OPTIMIZED FOR POST RACKS AND

network closets.

External Battery Packs & Battery Cabinets

External battery packs & battery cabinets increase battery
runtime. Expandable models allow daisy-chaining of multiple
units for unlimited runtime scalability. Tripp Lite also offers a full
line of replacement batteries to keep UPS systems in operation
when batteries eventually require replacement.

13

INTEGRATED SOLUTIONS – RACK & COOLING SOLUTIONS

RACK & COOLING SOLUTIONS

Core Function: Secure, Organize and Cool Equipment

s Provide air conditioning and heat removal for high-density installations.
s Organize equipment and cabling, providing security wherever required.
s Support hot-aisle / cold-aisle installations for efficient data center cooling.

SmartRack Premium Rack Enclosures

Available with or without side panels in sizes from 12U to 48U,
SmartRack Enclosures organize and secure standard 19-inch rack
equipment, regardless of vendor.

s (EAVYDUTY  LB LOAD RATING SUPPORTS HIGHDENSITY

installations.

s &EATURES LIKE QUICKADJUST VERTICAL RAILS EASYVIEW DEPTH

indexing, integrated baying hardware and toolless mounting
for vertical PDUs and cable managers make installation and
configuration tasks quicker and easier.

s -ASSIVE FRONTTOREAR AIRFLOW EXCEEDS SERVER MANUFACTURER
requirements and fully supports hot-aisle / cold-aisle
configurations for efficient data center cooling.

s +NOCKDOWN MODELS SHIP PARTIALLY

disassembled into several major
sections for easy transport and
quick reassembly in tight spaces.

s #OLOCATION MODELS ARE DIVIDED

into two secure compartments
(upper and lower) for multi-tenant
applications.

s $EEP WIDE AND DEEP  WIDE MODELS ARE AVAILABLE TO

accommodate deeper equipment cabinets and
facilitate high-density cable management.

SmartRack Thermal Duct Rack Enclosures

SmartRack Thermal Duct Rack
Enclosures keep equipment cooler
without using electricity or
generating additional heat. An
adjustable overhead duct and
sealed rear doors route warm
exhaust air directly to your facility’s
HVAC return air stream. The
negative pressure of the return air
duct pulls heat from the enclosure,
increasing cooling capacity and
efficiency.

SmartRack Wall-Mount
Rack Enclosures

Ideal for locations with limited floor space, SmartRack
Wall-Mount Rack Enclosures are available in sizes from 6U to
26U. Most models include a hinged wall bracket that allows the
enclosure to swing away from the wall for easy access to

equipment and cabling. An optional caster kit is
available for floor-standing and roll-away applications.
For applications that do not require a secure cabinet,
SmartRack Wall-Mount Open Frame Racks from 2U to
22U are also available.

14

SmartRack Open Frame Racks

SmartRack Open Frame Racks provide economical
equipment organization and cable management for
applications that do not require a secure enclosure.
2-post racks are available in 25U and 45U sizes. 4-post
racks are available in 13U, 25U and 45U sizes, as well
as a 42U heavy-duty model.

Compact Air Conditioning Unit

The portable, maintenance-free Compact Air Conditioning Unit
provides 12,000 BTU (up to 3.4kW) of supplemental cooling
capacity. It’s ideal for cooling overheated rack enclosures,
IT equipment hot spots and network closets without access to
facility air conditioning. You can focus cool air through its flexible
cooling duct or cool an entire room through its louvered vent.
The unit also filters and dehumidifies air. Condensate is
re-evaporated for drip-free operation, so you won’t waste time
emptying water collection tanks. Installation does not require
plumbing or special circuits. Eco-friendly R410a refrigerant meets
environmental standards worldwide.

Heat Removal Fan Panels

The 3U Horizontal Fan Panel removes warm air from enclosure
hot spots with three high-performance fans. The Roof Fan Panel
replaces the standard SmartRack Enclosure roof panel and
includes six high-performance fans.

Airflow Management Accessories

Airflow management accessories facilitate front-to-rear airflow
for increased cooling efficiency, especially for SmartRack
Enclosures arranged in a hot-aisle /cold-aisle configuration. They
prevent warm exhaust air from recirculating and contaminating
cool intake air. Accessories include 1U Blanking Panels, Cable
Pass-Through Panels and Rack Enclosure Skirts.

Rack Shelves

Fixed and sliding rack shelves with capacities up to 250 lb are
available for SmartRack Rack Enclosures and Open Frame Racks.

Internal Cable Managers

A variety of ring-type and duct-type vertical and horizontal
Internal Cable Managers are available. Vertical Cable Managers
include toolless mounting.

External Cable Managers

Cable Ladders and Cable Troughs
route cables between racks and
across aisles. They also separate
power and data cables to reduce
interference and maintain optimal
data transmission speeds.

Heat Removal Fan Door

The Heat Removal Fan Door connects
to a standard-width 42U or 48U
SmartRack Enclosure in place of the
rear doors. Four powerful centrifugal
fans supercharge front-to-rear airflow
to remove heat through overhead
ducts, which connect to a drop ceiling
or your facility’s HVAC return air
stream. Digital thermometers display
intake and exhaust temperature.

High-Capacity Cable Managers

With double-sided cable channels
and flexible fingers at 1U increments,
High-Capacity Cable Managers
organize and secure large quantities
of patch cables in high-density data
centers and network closets. High­Capacity Cable Managers are
available in 6-inch and 12-inch widths.

15

INTEGRATED SOLUTIONS – POWER DISTRIBUTION UNITS

POWER DISTRIBUTION UNITS (PDUs)

Core Function: Provide Reliable, Manageable Power Distribution

s Distribute power from a UPS system, generator or wall outlet to multiple devices.
s Right-size equipment and infrastructure to reduce up-front costs and increase operational efficiency.
s Reboot unresponsive devices from any distance, eliminating time-consuming trips to remote sites.

Network-Grade Power
Distribution Units

Tripp Lite single-phase PDUs are available in four
varieties: Basic, Metered, Monitored and Switched.

Feature Benefit Basic Metered Monitored Switched

Multiple
Outlets

High­Current
Input
and Low­Current
Outlets

Toolless
Mounting
Buttons

Load
Meter(s)

Auto­matic
Transfer
Switch
(ATS)

Network
Interface

Remote
Individual
Outlet
Control

Provide
reliable power
distribution from
a UPS system,
generator or
utility source to
multiple devices.

Convert a single
high-amperage
outlet into
multiple low­amperage
outlets.

Provide quick,
convenient 0U
mounting.

Display the
connected
equipment load
to prevent
overloads and
safely optimize
load levels.

Provides
redundant
power sources
for single-cord
devices.

Provides remote
monitoring
and condition
reporting to
prevent
overloads and
downtime.

Eliminates costly
service calls by
rebooting
locked devices
from any location.

Yes Ye s Yes Yes

Select

Models

Vertical
Models

PDU Type

Select

Models

Vertical
Models

Select

Models

Select

Models

Vertical
Models

Yes Yes Yes

Yes Ye s

Select

Models

Vertical
Models

Select

Models

Yes

3-Phase Power Distribution Units

3-Phase PDUs are available in two varieties: Monitored
and Switched. They’re similar to standard PDUs, but
they accept 3-phase input power and provide single­phase output power. Switched 3-Phase PDUs can also
measure and display the connected equipment load of
individual outlets.

Hot-Swap Power Distribution Units

Hot-Swap PDUs pass through utility power to connected
equipment during UPS system maintenance, repair or
replacement, preventing downtime. They add hot-swap
capability to UPS systems up to 3kVA.

16

Tripp Lite Integrated Solutions are designed to work with your existing equipment, regardless of vendor.

17

Power Distribution Centers

Power Distribution Centers organize and simplify power
distribution for multiple racks. They accept 3-phase input power
from SmartOnline 3-Phase UPS Systems and distribute single-
phase and/or 3-phase output power to PDUs. Power distribution
through individual output breakers and corresponding output
cord sets (whips) maximizes flexibility, balances critical loads and
provides branch circuit over-current protection. Select models
include an integrated bypass panel to allow UPS maintenance
without requiring connected equipment downtime.

CABLES & CONNECTIVITY

Core Function:

Connect Equipment
& Infrastructure

Cables

s Cat5/5e/6/6a,
Cat3, T1 &
CX4 Patch
Cables

s Singlemode,
Multimode & Mode Conditioning Fiber-Optic Cables

s VGA, DVI & HDMI Display Cables

s Easy Pull Display Cables

(Ideal for Conduit)

s AC Power Cables

s Audio/Video Cables

s USB & FireWire

®

Cables

s Storage Cables

Patch Panels

s Cat5e & Cat6 Network Patch Panels

s Fiber-Optic Patch Panels

s Up to 48 Ports per 1U

Adapters, Extenders, Splitters
& Switches

s VGA, DVI & HDMI Extenders, Splitters & Switches

s Component Video, VGA, DVI & HDMI Over Cat5

Extenders

s Fiber-Optic Converters, Adapters & Couplers

“Tripp Lite has always delivered excellent products and support. That’s why I chose them to

protect Cisco’s flagship product line. We will be recommending Tripp Lite power protection to all

our Cisco TelePresence customers.”

Rick Santina, Technical Marketing Engineer for Cisco TelePresence Exchange Business Unit

INTEGRATED SOLUTIONS – NETWORK MANAGEMENT TOOLS

NETWORK MANAGEMENT TOOLS

Core Function: Manage Power and IT Devices from Any Location

s Provide secure access and control for all devices.
s Allow valuable IT personnel to cover more ground in less time.
s Detect problems sooner and fix them faster—before downtime hurts your bottom line.

KVM Switches, Console KVM Switches &
Rack Consoles

KVM Switches are available with or without built-in LCD consoles,
Cat5 cabling, IP remote access and support for multiple
concurrent users. KVM Switches contain up to 32 ports per 1U
and can expand to control thousands of servers by connecting
additional units.

IP Console Servers

IP Console Servers provide remote access to all your serial- and
network-connected devices, including servers, switches, routers,
UPS systems and PDUs. If your primary IP network connection
goes down due to an outage or device malfunction, you can still
access connected equipment through alternative, out-of-band
connections such as dial-up modems and serial ports.

s Secure tunneling to all devices
s Up to 48 Cisco
s 1,000+ devices per IP address
s Up to 48 concurrent users
s Embedded Linux
s Built-in management tools, including service processor tools
s Ability to add your favorite management tools
s Flash memory for logs and configurations
s Integrated or plug-in temperature sensors

Compact IP Console Servers include an embedded temperature
sensor, 3 or 4 serial ports and a modem port or built-in modem.
They’re perfect for branch offices and smaller installations. The
IP Console Server with KVM Console Ports includes an
embedded thin client and embedded PowerAlert NMS. It
provides convenient rack-side access and can also add IP

®

-compatible RJ45 serial ports in 1U

®

with shell access

access to your existing KVM
infrastructure. IP Console Server
Management Switches have
redundant power supplies and
dual Ethernet ports. They can
host a separate management
LAN for increased security and
high-speed out-of-band access.

PowerAlert Network Management
System (NMS)

Tripp Lite’s free PowerAlert
software allows you to
monitor and control
hundreds of UPS systems,
Monitored PDUs and
Switched PDUs over the
network through a single
interface.

UPS Network Management Cards

UPS Network Management Cards
allow compatible UPS systems to
connect to the network for remote
monitoring and control via SNMP,
Web or telnet, including centralized
management through free PowerAlert
NMS software.

Environmental Sensors

Environmental Sensors connect to
UPS Network Management Cards and
Monitored/Switched PDUs, providing
remote monitoring of temperature,
humidity and dry contacts.

18

INTEGRATED POWER & DEVICE MANAGEMENT

Network

Manager(s)

Critical
Network
Systems

PowerAlert

NMS

Web Browser

Access

PowerMan &

PowerAlert

Consoles

Nagios

Monitoring

Serial-over-LAN

NUT

Use your favorite management tools to manage your devices.

IP Console Server IP KVM

IP KVM

Management

LAN

Critical
Network
Systems

LAN, WAN,

Internet

Service

Processor

Access

Command

Line Access

Remote GUI

Access

Server with

PowerAlert Software

PDU (Monitored or Switched)

UPS with Network

Management Card

Rack with Local IP Console Server Rack without Local IP Console Server

IP Console Servers allow you to access all your serial- and network-connected devices from any location through secure tunnels, regardless of which management
tool or protocol you’re using, including Tripp Lite’s free PowerAlert NMS network power management software. Out-of-band connections (including dial-up, serial
and management LAN) ensure that you can access and troubleshoot managed devices from any location 24x7, even when in-band (primary IP network) connections
are unavailable due to network outages, device malfunctions or security restrictions.

UPS without Network

Management Card

In-Band Access (Primary IP Network)

Out-of-Band Access (Management LAN)

Out-of-Band Access (Dial-Up, Serial, etc.)

KVM or USB/Serial Access

Power

Managed UPS Systems

Managed PDUs

IP Console Servers & KVMs

IT Devices (Servers, Storage, Switches, etc.)

Environmental Sensors

UPS with Network

Management Card

PDU (Monitored or Switched)

19

INTEGRATED SOLUTIONS – SERVICE & SUPPORT

SERVICE & SUPPORT

Core Function: Provide Superior Customer Service

Before, During and After Project Implementation

When you choose Tripp Lite, our experienced project engineers

will help you customize a solution tailored to fit your unique

requirements. Through our Solution Integration Service, we do a

lot of the hard work for you at no additional cost. We assess your

situation and provide actionable recommendations to ensure that

your solution will provide the availability, manageability, efficiency

and affordability you need to meet your goals.

We’ll provide a roadmap with detailed project requirements,

BOMs, specifications, installation considerations and ongoing

support options, including preventative maintenance, extended

warranties, on-site services and rapid repair and replacement.

We’ll also provide clear alternatives that allow you to strike a

balance between technical and budgetary considerations.

Our Solution Integration Service will help you:

s DEFINE objectives and technical requirements

s EVALUATE the installation site, including existing systems

and infrastructure

s EXAMINE systems to ensure they’re correctly powered,

protected and configured

s AUDIT power capacity requirements and right-size systems

before consolidation, virtualization and other projects

s PLAN airflow management and cooling for low-, medium- or

high-density deployments

s PREPARE for future infrastructure growth and evolving IT

requirements

s INTEGRATE components with existing systems.

AWARD-WINNING TRIPP LITE RELIABILITY

Tech Awards Circle

A Single, Trusted Source

With a long history of providing superior customer service and thousands of
vendor-neutral IT infrastructure solutions, Tripp Lite is uniquely positioned to
help you maximize the availability, manageability and efficiency of your critical
network systems. Whether you’re starting from scratch, upgrading or expanding,
Tripp Lite delivers practical, proven, cost-effective solutions, with single-source
convenience for planning, ordering, implementation, service and support.

Distributed By:

Tripp Lite has been a trusted manufacturer of

innovative solutions for over 85 years!

Copyright © 2011 Tripp Lite. All trademarks are the sole property of their respective owners. Photos and illustrations may differ slightly from actual products.
Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.

201205225 95-3065
