Tripp Lite DWF1323M Specifications

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +[phone]

E-mail: [e-mail]

Model #: DWF1323M

Fixed Wall Mount for 13" to 27" Flat-Screen Displays

Highlights

Low-profile mounting keeps unit out of sight for sleek, professional appearance

Fits most flat-panel displays from 13” to 27”

Supports up to 88 lbs.

5-year warranty

Description

Tripp Lite’s VESA-compliant DWF1323M Fixed Flat-Screen Wall Mount’s low-profile design stays hidden behind your display for a sleek,
professional appearance. Its durable, all-metal frame with scratch-resistant, powder-coat finish supports weights of up to 88 lbs. and fits most 13- to
27-inch flat-panel displays. It comes preassembled for quick and easy installation. For peace of mind, the DWF1323M comes backed by a 5-year
warranty.

Package Includes

DWF1323M Fixed Flat-Screen Wall Mount

Mounting Hardware

Owner’s Manual

Specifications

OVERVIEW

Display Mount Type Standard

Mounting Location Wall

PHYSICAL

Unit weight (lbs) 1.43

Unit weight (kg) .64

Color Black

Display Size (in.) 13 - 27

Display Size (cm) 33.02 - 68.58

VESA Pattern (mm) 50x50; 75x75; 100x100

Motion Fixed

Min/Max Arm Extension (in.) N/A

Min/Max Arm Extension (cm) N/A

Maximum Weight Capacity
(lbs)

88

Maximum Weight Capacity
(kg)

39

FEATURES/SPECIFICATIONS

Tools Necessary Yes

Cord Management No

WARRANTY

Product Warranty Period
(U.S. & Canada)

5-year limited warranty

Related Items

Optional Products

Related Model Description Qty.

TLP31SAT 3 outlet - 2 fixed outlets, 1 rotating power outlet and rotating coax, Direct plug-in, 1080

Joules, 1-line gold coaxial - Surge Suppressor

1

P502-006 6-ft. SVGA/VGA Monitor Gold Cable with RGB Coax (HD15 M/M) 1

P560-006 6-ft. DVI Dual Link TMDS Cable (DVI-D M/M) 1

P568-006-RA2 6-ft. High Speed HDMI Gold Cable with Right-Angle Connectors 1

P568-006-SW 6-ft. High Speed HDMI Gold Cable with Swivel Connectors 1

N042-001-WH White Keystone Faceplate - dual outlet 1

B125-101-60-WP HDMI over Dual Cat6 60Hz Wallplate Extender Kit 1

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=5541.
