Tripp Lite B120-000 User Manual

NOTE: Follow these instructions to ensure proper operation and prevent damage to this device

chance to win a FREE Tripp Lite

product! www.tripplite.com/warranty

Warranty

Registration

Extender Adapter

1111 W. 35th Street, Chicago, IL 60609 USA

All trademarks are the property of their respective owners.

and its connected equipment.

(773) 869-1234 • www.tripplite.com

Tripp Lite World Headquarters

DVI Dual Link

Owner’s Manual

Model: B120-000

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR

DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING

OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF

SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as lost profits or

revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs

of substitutes, claims by third parties, or otherwise.

(RMA) number from TRIPP LITE or an authorized TRIPP LITE service center. Products

must be returned to TRIPP LITE or an authorized TRIPP LITE service center with

transportation charges prepaid and must be accompanied by a brief description of the

problem encountered and proof of date and place of purchase. This warranty does not

apply to equipment which has been damaged by accident, negligence or misapplication or

has been altered or modified in any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR

IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR

A PARTICULAR PURPOSE. Some states do not permit limitation or exclusion of implied

warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.

Connect the DC Power to the DC Jack of the B120-000 and then

connect the DC Adapter to the wall socket.

Visit www.tripplite.com/warranty today to register the warranty for

your new Tripp Lite product. You'll automatically be entered into a

drawing for a chance to win a FREE Tripp Lite product!*

TRIPP LITE warrants its products to be free from defects in materials and workmanship for

a period of one (1) year from the date of initial purchase. TRIPP LITE's obligation under this

warranty is limited to repairing or replacing (at its sole option) any such defective products.

To obtain service under this warranty, you must obtain a Returned Material Authorization

* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

1-Year Limited Warranty

Then connect the shorter DVI-D cable between the DVI Display and

the B120-000 connector marked “OUT”.

Warranty Registration

To test the power supply, use a voltmeter and measure the DC output

of the DC adapter to ensure that 5V is present. If output is 5V, the DC

adapter is functional and the B120-000 unit has failed.

Note: The positive (+) is in the middle and the ground (-) is on the exterior of the plug.

Installation

Connect the longer DVI-D cable between the DVI Source and the

B120-000 connector marked “IN”.

between the source and the display to ensure that both devices and

the cable are working properly.

Confirm that the two short cables are functional by using the above

step. Then use these cables to connect the B120-000 between the

source and display. If there is no video, either the long cable or the

B120-000 is faulty.

Troubleshooting

Direct connect a short cable (5 meters or less is recommended)
