Owner’s Manual

4K x 2K UHD HDMI Switch

Models: B119-002-UHD (2-Port), B119-004-UHD (4-Port),

B119-005-UHD (5-Port)

Español 11 • Français 21 • Русский 31

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA

tripplite.com/support

Product Features

• Switch between multiple HDMI source devices connected to a single HDMI port on a monitor

• Switch devices via pushbutton or the included remote control

• Intelligent Auto Switching functionality will automatically switch to the next powered-on device when the power to the current device is turned off*

• Supports 4K x 2K Ultra High Deﬁnition (UHD) video resolutions up to 3840 x 2160 @ 60 Hz

• Supports up to 48-bit Deep Color (16 bits per channel)

• Supports DTS-HD, Dolby® TrueHD and

7.1 channel surround sound audio

• 3D, HDCP v2.2 and EDID compatible

• The B119-005-UHD model includes an international power supply with compatible North American, U.K., European and Australian plug adapters.

• Plug and play; no software or drivers required

Product Features

*Auto switching will not work properly if you have a device that is in sleep mode. Devices must be powered off completely for auto switch to work properly.

Package Contents

• B119-002-UHD, B119-004-UHD or B119-005-UHD

• Remote Control

• External Power Supply (Input: 100-240V, 50/60 Hz, 0.3A; Output: 5V 1A)*

• Owner’s Manual

*Includes NEMA 1-15P (North America), CEE 7/16 Schuko (Europe), BS 1363 (U.K.) and AS/NZS 3112 (Australia) plugs.

Optional Accessories

• P569-XXX-CERT Premium High-Speed HDMI with Ethernet Cables

Installation

1. Make sure the power to all devices that you

will be connecting is turned off.

2. Connect an HDMI source device to an

Input port on the switch.

Note: The length of the HDMI cable connecting

the source to the switch must not exceed 16 ft. (5 m).

3. Repeat step 2 to connect source devices to

the remaining Input ports on the switch.

4. Connect the Output port on the switch to

the HDMI input port of your display.

Note: The length of the HDMI cable connecting

the switch to the display must not exceed 16 ft. (5 m).

Installation

5. Connect the external power supply to the

switch, and then plug it into a Tripp Lite Surge Protector, Uninterruptible Power Supply (UPS), or Power Distribution Unit (PDU). The red Power LED and green Input 1 LED will illuminate to indicate that power is being received.

6. Turn on the power to the HDMI source

devices and display.

7. Switch between source devices via the

Select pushbutton on the unit or the included remote control. You can also let the Auto Switch functionality automatically switch to ports that are powered on. When multiple ports have powered on devices connected to them, the lowest numbered port will be switched to. Once the device connected to the lowest numbered port is powered off, the next powered on port in line will be switched to.

Troubleshooting

If you are unable to get an acceptable image after following the installation instructions, try the troubleshooting tips below.

1. Is the external power supply that came with the product connected and plugged into a working power source? For the

product to function properly, the switch must be connected to and receiving power from an external power supply.

2. Was the power to the connected devices turned off prior to installation? If not,

restart them.

3. What resolution are you trying to reach?

Tripp Lite’s B119-002-UHD, B119-004-UHD and B119-005-UHD are tested to support 4K x 2K Ultra High Deﬁnition (UHD) video resolutions up to 3840 x 2160 @ 60 Hz, and 48-bit Deep Color (16 bits per channel).

4. What length HDMI cable are you using?

(See the Installation section in this manual for details on the maximum cable distance). The shorter the cable being used, the higher the resolution you will be able to obtain.

(continued)

Troubleshooting

If you are not able to get an acceptable

image, try using a shorter cable, or lowering your source’s video resolution or color depth settings.

5. What type of cabling are you using? Inferior cabling can result in poor performance, so it is important that you use cables that can support the video resolution you are trying to obtain. It is recommended that you use Tripp Lite’s P569-Series High Speed HDMI cables, as they have been tested to work with the B119-002-UHD, B119-004-UHD and B119-005-UHD.

6. Test your cables to ensure they are working properly. For example, connect

your HDMI cable between a source and monitor that you know works to see if the cable is functioning.

7. Is the unit located in an area that exposes it to higher temperatures? If the

product is overheated, it will not function properly.

Speciﬁcations

Model B119-002-UHD B119-004-UHD B119-005-UHD Connectors

Input (x2) HDMI Female (x4) HDMI Female (x5) HDMI Female Output HDMI Female HDMI Female HDMI Female

Video

Maximum Resolution

Color Depth 48-bit Deep Color

Video Ampliﬁer Bandwidth

Environmental

Operating Temperature

Operating Humidity

Storage Temperature

Storage Humidity 5% to 90% RH,

Physical

Unit Dimensions (HxWxD, in.)

Unit Dimensions (HxWxD, mm)

Unit Weight (lb.) 0.23 0.33 0.33 Unit Weight (kg) 0.1062 0.15 0.15

Power Requirements

External Power Supply

Power Consumption (Max)

3840 x 2160 (60 Hz)

(16 bits per channel) 6Gbps / 600Mhz 6Gbps / 600Mhz 6Gbps / 600Mhz

32 to 104°F (0 to 40°C)

10% to 85% RH, Non-Condensing

14 to 176°F (-10 to 80°C)

Non-Condensing

0.8 x 3.1 x 2.0 0.8 x 4.8 x 2.0 0.8 x 4.8 x 2.0

20 x 80 x 51 20 x 123 x 51 20 x 123 x 51

5V/1A 5V/1A 5V/1A

2W 2W 2.5W

3840 x 2160 (60 Hz)

48-bit Deep Color (16 bits per channel)

32 to 104°F (0 to 40°C)

10% to 85% RH, Non-Condensing

14 to 176°F (-10 to 80°C)

5% to 90% RH, Non-Condensing

3840 x 2160 (60 Hz)

48-bit Deep Color (16 bits per channel)

32 to 104°F (0 to 40°C)

10% to 85% RH, Non-Condensing

14 to 176°F (-10 to 80°C)

5% to 90% RH, Non-Condensing

Warranty and Product Registration

3-YEAR LIMITED WARRANTY

TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of three (3) years from the date of initial purchase. TRIPP LITE’s obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center. Products must be returned to TRIPP LITE or an authorized TRIPP LITE service center with transportation charges prepaid and must be accompanied by a brief description of the problem encountered and proof of date and place of purchase. This warranty does not apply to equipment, which has been damaged by accident, negligence or misapplication or has been altered or modiﬁed in any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Speciﬁcally, TRIPP LITE is not liable for any costs, such as lost proﬁts or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.

Warranty and Product Registration

PRODUCT REGISTRATION

Visit tripplite.com/warranty today to register your new Tripp Lite product. You’ll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy new electrical and electronic equipment from Tripp Lite they are entitled to:

• Send old equipment for recycling on a one-for-one, like-for-like basis (this varies depending on the country)

• Send the new equipment back for recycling when this ultimately becomes waste

Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support equipment or to signiﬁcantly affect its safety or effectiveness is not recommended.

Tripp Lite has a policy of continuous improvement. Speciﬁcations are subject to change without notice.

1111 W. 35th Street, Chicago, IL 60609 USA

tripplite.com/support

19-08-201 93-37C3_RevD

Manual del Propietario

Switch HDMI de

UHD 4K x 2K

B119-002-UHD (2 Puertos), B119-004-UHD (4 Puertos), B119-005-UHD (5 Puertos)

English 1 • Français 21 • Русский 31

Modelos:

1111 W. 35th Street, Chicago, IL 60609 EE UU

tripplite.com/support

Características del Producto

• Alterna entre múltiples dispositivos fuente de HDMI conectados a un solo puerto HDMI en un monitor

• Alterna entre dispositivos mediante un botón interruptor o el control remoto incluido

• La función de Conmutación Automática inteligente cambiará automáticamente al siguiente dispositivo encendido cuando se apague la corriente del dispositivo actual*

• Soporta resoluciones de video de Ultra Alta Deﬁnición (UHD) 4K x 2K hasta 3840 x 2160 @ 60 Hz

• Soporta Color Verdadero de hasta 48 bits (16 bits por canal)

• Soporta audio DTS-HD, Dolby® TrueHD y de 7.1 canales de sonido envolvente

• Compatible con 3D, HDCP v2.2 y EDID

• El modelo B119-005-UHD incluye una fuente de alimentación internacional con adaptadores para clavijas de Norte América, Reino Unido, Europa y Australia

• Conectar y Usar—No requiere software ni controladores
