Tripp Lite B042, B040 User Manual

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +[phone]

E-mail: [e-mail]

Model #: B042-008

KVM Switch - 8-Port 1U Rackmount USB/PS2 KVM Switch with On-Screen Display

Highlights

USB and PS/2 Keyboard and Mouse support on both console and PC

On-Screen Display (OSD) menu functionality

2048 x 1536 Video resolution support

Rackmount Hardware Included

Description

Tripp Lite's NetController 8-port USB/PS2 KVM Switch is an affordable, highly flexible enterprise class KVM Switch. This unit gives the user a choice

of PS2 or USB inputs for the keyboard and mouse, as well as USB or PS2 attachment to the computer. A dedicated daisy-chain port offers

expandability up to 128 computers. On- Screen Display (OSD) menu functionality allows for easy switch management and port selection. Other

features include: password protection, auto-scanning, auto-logout, firmware upgradeable and video support up to 2048 x 1536 (QXGA). Mounts

easily in a standard 19" rack cabinet, and includes all necessary mounting hardware. Use only Tripp Lite P780 series USB/PS2 KVM cable kits with

this unit. Tripp Lite 1-year limited warranty.

Package Includes

B042-008 KVM Switch

AC Power Adapter ( Multi-National )and rackmount hardware kit

8-in Daisy-Chain cable - HD15M/HD15F ( for longer daisy-chain cables, see Tripp Lite P781 series cables)

Daisy Chain terminator - HD15M

Owners manual CD and Quick start guide

Features

Connect up to 128 computers by daisy-chaining up to 8 levels of B042-Series KVM Switches

Allows for easy customization of ports by daisy-chaing any combination of B042-Series KVMs

Standard 19" Rackmount size - hardware included

On-Screen Display (OSD) menu for intuitive operation and easy control

USB and PS/2 keyboard and mouse support on both console and PC/Server side

Supports video resolution up to 2048 x 1536 ( QXGA )

Password protection and Auto-logout features

Firmware upgradeable

Robust metal case design ensures best EMI/RFI shielding and video quality

Hot-swappable: disconnect and reconnect USB computers without rebooting

Supports standard 5-button Microsoft®, Logitech®, or comparable mice

Supports standard Microsoft®, Logitech®, or comparable keyboards

Supports MAC, DOS, Windows 95/98/SE/NT/2000/ME/XP/Server2003/Vista, Unix, Linux and BSD

Tripp Lite Ltd 1-Year Warranty

Specifications

OVERVIEW

# Of Users 1

AC Adapter 120-230V

Console No

Control Push-button, OSD, Hot-key

Max CPU 128

PC/Server USB, PS/2

Cat5 KVM Switch No

IP Remote Access YES WITH B050-000

PHYSICAL

Color Black

Style 1U Rackmount

Length 16.1"W x 6.5"D x 1.8"H

LCD Monitor (in.) Not Applicable

CONNECTIONS

Ports 8

Features/Specifications

BTUs 245.52

Related Items

KVM Adapters/Console Extender Kits

B013-000 KVM Switch Accessories - KVM Console Extender Kit Qty: [optional]

KVM Cable Kits

P780-006 KVM Switch Cable Kits - 6-ft. PS/2 & USB (2-in-1) KVM Cable Kit for B042-Series KVM

Switch

Qty: [optional]

P780-010 KVM Switch Cable Kits - 10-ft. PS/2 & USB (2-in-1) KVM Cable Kit for B042-Series KVM

Switch

Qty: [optional]

P780-015 KVM Switch Cable Kits - 15-ft. PS/2 & USB (2-in-1) KVM Cable Kit for B042-Series KVM

Switch

Qty: [optional]

KVM Daisy-Chain Cables

P781-003 KVM Daisy Chain Cable for the B040/B042 Series KVM Switches, 3 ft. Qty: [optional]

P781-006 KVM Daisy Chain Cable for the B040/B042 Series KVM Switches, 6 ft. Qty: [optional]

P781-010 KVM Daisy Chain Cable for the B040/B042 Series KVM Switches, 10 ft. Qty: [optional]

P781-016 KVM Daisy Chain Cable for the B040/B042 Series KVM Switches, 16 ft. Qty: [optional]

KVM Switches & Accessories

B050-000 KVM Switch Accessories - IP Remote Access Unit Qty: [optional]

B042-004 KVM Switches- 4-Port 1U Rackmount USB/PS2 KVM Switch with On-Screen Display Qty: [optional]

B042-016 KVM Switch - 16-Port 1U Rackmount USB/PS2 KVM Switch with On-Screen Display Qty: [optional]
