TRIPPLITE B013-HU-4K Product Data Sheet

HDMI HDBaseT KVM Console Extender over Cat6

- 2 USB Ports, IR, 4K @ 30 Hz (130 ft.), 1080p (230
ft.)

MODEL NUMBER: B013-HU-4K

Controls a media player from up to 130 ft. away and extends 4K HDMI video, USB and IR signals that
same distance (230 ft. for 1080p).

Features

KVM Console Extender for Digital Signage or Extending Video in Offices or Command Centers

This extender kit includes a transmitter (local unit) and a receiver (remote unit) that work in tandem to
extend and distribute HDMI audio/video, USB and IR (infrared) remote signals. Using Cat6 cabling (sold
separately), the B013-HU-4K transmits 1080p video from a computer, Blu-ray player or other media center
to an HDMI display or interactive whiteboard located up to 230 feet away. By connecting a keyboard and
mouse to the receiver’s dual USB ports, you can also control the source device from that same distance.

Recommended for Digital Signage or Extending Video Across Offices or Command Centers

Especially useful in control or security applications, the B013-HU-4K is ideal for command centers, data
control centers, banks, governments, enterprise applications and especially any harsh environments, such
as factories and warehouses. By extending audio/video signals, you can safely store your source
computer in a cabinet or other enclosure, keeping it free of dust and blocking noise created by its fans,
while watching the display in a different room or even a warehouse or factory floor.

Transmits Both 1080p and Uncompressed 4K Video and LPCM Audio with Zero Latency

This HDBaseT kit extends 1080p video resolutions up to 230 feet, as well as 4K video (3840 x 2160 at 30
Hz) up to 130 feet with 24-bit Deep Color (8 bits per channel). It also supports uncompressed LPCM,
compressed DTS-HD and compressed Dolby TrueHD audio with no signal loss or added latency.

IR Pass-Through Technology Lets You Control the Video from the Next Room

Full bi-directional IR extension lets you control the source device with its remote (play, pause, fast
forward, etc.), while you’re standing near the receiver in another room. Video and audio will play without
stalling or delayed data transmission. Make sure the transmitter’s IR bulb is within sight of the source and
the receiver’s IR bulb is in range of the source’s remote.

Plug-and-Play Operation for Quick Setup and Immediate Use

The included transmitter and receiver units work right out of the box with no software required. Because
they connect using existing network infrastructure, you avoid the hassle and expense of running new
Cat5e/6 cables. LED indicators alert you of power and connection status of both units at a glance.

Highlights

●

Uses existing Cat5e/6 network
infrastructure, saving you the
expense of new cables

●

Delivers 4K picture quality at
Ultra HD resolutions up to 3840
x 2160 @ 30 Hz

●

Supports DTS-HD, Dolby
TrueHD and uncompressed
LPCM digital audio with no
latency

●

IR pass-through feature allows
you to control the source while
standing in another room

●

Plug-and-play operation with no
software required for easy,
immediate installation

Applications

●

Keep your video sources in a
secure or quiet location, with a
display located elsewhere for
viewing by the intended
audience

●

Extend 4K video over existing
Cat6 cabling to cut costs on
infrastructure

●

Create an easily updatable
video board communicating
dynamic information, such as a
restaurant menu or a theater
schedule

●

Display arrivals, departures and
up-to-the-minute information in
an airport or train station

●

Connect an interactive
whiteboard to use for visual aids
in your lecture or presentation

1 / 4

System Requirements

●

Source devices with HDMI
output (media server, Blu-ray
player, PC)

●

Display device with HDMI input
(HDTV, projector, whiteboard)

●

USB keyboard and mouse

Package Includes

●

Transmitter unit

●

Receiver unit

●

IR-Out cable

●

IR-In cable

●

USB 2.0 A/A cable (M/M), 4 ft.

●

(2) International power supplies
with 4 ft. cord (Input: 100–240V,
50/60 Hz, 0.3A; Output: 12V 1A)

●

(8) International plug adapters
(North America, Europe, U.K.,
Australia)

●

Owner’s manual

Specifications

OVERVIEW

UPC Code 037332241160

INPUT

Voltage Compatibility (VAC) 100; 110; 120; 125; 127; 200; 208; 220; 230; 240
External Power Supply Input Specs

(V / Hz / A)
External Power Supply Output

Specs (V / A)
External Power Supply Cord Length

(ft.)
External Power Supply Cord Length

(m.)
External Power Supply DC Barrel

Connector Specs

100-240V~50/60Hz, 0.3A

12V, 1A

3.9

1.2

OD: 5.5 x 2.1 x 10mm, Positive Pin, Negative Sleeve
