OWNER’S MANUAL

TRINITY 30" X 20" X 72” BAMBOO GARMENT RACK

- BRONZE ANTHRACITE

Model # TBFPRA-2706

Page 2

Page 3

Your TRINITY 30" x 20" x 72” Bamboo Garment Rack should include the following parts. Please inspect

box contents to ensure you have received all components.

If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY Customer Service: 800.985.5506 or [email protected]. Parts can also be requested online at www.trinityii.com (Help & More, Contact Us).

ROD (3)

FIXED SHELF (2)TOP SIDE

FRAME (2)

BOTTOM SIDE

FRAME (2)

PARTS LIST

SCREW (14) FRAME CONNECTING

SCREW (4)

FEET

LEVELER (4)

HEX KEY (1)

E F

ANTI-TIPPING

KIT (2)

Page 4

STEP 2

Screw FEET LEVELERS (G) into the bottoms of each BOTTOM SIDE FRAME (B). Turn

clockwise to screw in place.

G (4)B (2)

F (4)

H (1)

Ensure TOP SIDE FRAME (A) and BOTTOM SIDE FRAME (B) INSIDE face are facing the same direction. Side with threaded inserts for the Adjustable Shelves is the INSIDE face.

Connect TOP SIDE FRAME (A) with BOTTOM SIDE FRAME (B). Using the included HEX KEY (H), screw 1 FRAME CONNECTING SCREW (F) into each hole where BOTTOM SIDE FRAME (B) is connected with TOP SIDE FRAME (A).

Repeat for remaining FRAME CONNECTING SCREWS (F).

ASSEMBLY INSTRUCTIONS

STEP 1

B (2)

A (2)

Page 5

STEP 4

Lay SIDE FRAMES (A + B assembled in Step 2) on its side. Make sure the face with threaded inserts for the Adjustable Shelves faces INSIDE as you assembles the FIXED SHELVES (C).

Place FIXED SHELVES (C) on their sides and connect

them to SIDE FRAMES (A + B) assembled at STEP 2, fasten SCREWS (E) into frame screw holes by HEX KEY (H).

Stand the unit upright.

Place 1 ROD (D) between 2 hanger mounts on TOP SIDE FRAME (A), fasten SCEWS (E) into screw holes by HEX KEY (H).

Place other 2 RODS (D) between the Side Frames as shown, fasten

SCEWS (E) into screw holes by HEX

KEY (H).

ASSEMBLY INSTRUCTIONS

STEP 3

E (8) H (1)C (2)

E (6) H (1)D (3)

Page 6

ASSEMBLY INSTRUCTIONS

STEP 5

I (2)

To install the ANTI-TIPPING KIT (I), place

BAMBOO GARMENT RACK against the wall.

Mount bracket to the wall, next to outer TOP SIDE FRAME (A) just below the top FIXED SHELF (C).

First, fully secure ANTI-TIPPING KIT (I) to the wall.

Next, close cable loop through TOP SIDE FRAME (A) as shown.

Wall

Page 7

PRODUCT EXTRA SHELF OPTIONS

There are extra screw holes in this product for more ADJUSTABLE SHELVES. You will need 1 ADJUSTABLE SHELF (PRA-03-046-2820) and 4 ADJUSTABLE SHELF RESTS (ZBK-01-031-0620) to add one extra shelf to the product.

Extra ADJUSTABLE SHELF PACK (PRA-03-067-2820) is available for purchase. Please visit our website www.trinityii.com or contact our Customer Service (see last page of the manual) to place your order.

(4) ADJUSTABLE

SHELF REST

ZBK-01-031-0620

(1) ADJUSTABLE SHELF

PRA-03-046-2820

ADJUSTABLE

SHELF PACK

PRA-03-067-2820

Page 8

SERVICE PARTS LIST – TBFPRA-2706

TRINITY Customer Service provides the following replacement parts:

Part Number Description Part Number Description

XSV

-02-011-0007

Anti

-tipping kit 6)

XXX

-97-001-0001

Hex Key

PRA

-14-021-2036

Top Side Frame

ZBK

-01-002-0635

Screw

ZBK

-01-002-0615

Frame Connecting Screw

PRA

-13-007-2850

Rod

PRA

-14-022-2036

Bottom Side Frame

PRA

-03-045-2820

Fixed Shelf

XBK

-98-006-2525

Feet Leveler

Page 9

1. Read and understand all instructions. Failure to follow all instructions may result in injury

and/or damage.

2. Use the provided anti-tipping kits to secure the product to the wall to prevent the product from tipping over.

3. The warnings, cautions, and instructions discussed in this manual cannot cover all possible conditions or situations that may occur. The user must always be aware of their

environment and ensure that they use the product in a safe and responsible manner.

4. Do NOT modify the product in any way. Unauthorized modification may impair the

function and/or safety of the product, and may affect the life of the product.

5. Check for damaged parts. Before using this product, carefully check that all parts are in

good condition, and that the product will operate properly and perform its intended function. Check for damaged parts and any other conditions that may affect the operation of this product. Replace damaged or worn parts, and never use this product with a damaged part.

6. Do NOT overload the product.

7. Do NOT allow children to climb or play around the product.

WARNINGS

CARE AND MAINTENANCE

Weight capacity of Hanging Rod (evenly distributed) 50 lb

Weight capacity per shelf (evenly distributed) 75 lb

• Bamboo can be maintained with mineral oil for best results.

• Avoid harsh, abrasive cleaners, and other corrosive chemicals.

• The product is designed for indoor use. Wipe dry and keep out of direct sunlight.

Page 10

Thank you for purchasing a TRINITY 30" x 20" x 72” Bamboo Garment Rack. In order to register your product and receive streamlined customer service, please fill out the following Product Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at www.trinityii.com or (3) scan and email the form to [email protected]. Include a copy of your original receipt with your submission.

First Name: Last Name: Address: City: State: Zip Code: Email Address: Phone: Product Model #: TBFPRA-2706 Purchase Date: / / Location of Purchase:

Please rate the importance of each feature (1=least important; 10=most important) Quality Price Size/Capacity Appearance Other

How did you hear about our product?

Magazine Ad Catalog Salesperson Word of Mouth Internet Store Display Other

Marital Status: Single Married Household Income: Below $50,000 $50,000-$150,000 $150,000+ Education: High School College Graduate School Primary Residence: Own Rent Comments/Suggestions:

PRODUCT REGISTRATION

Page 11

TRINITY 30" x 20" x 72” Bamboo Garment Rack

Model # TBFPRA-2706

Trinity International Industries (“Trinity”) warrants to the original consumer purchaser (“Purchaser”) of the Trinity 30" x 20" x 72” Bamboo Garment Rack (“Product”) that each Product shall be free from defects in workmanship and materials for a period of 1 year from the date of original purchase. Trinity’s obligation

under this warranty shall be limited to repair or replacement of, or adequate compensation for the Product which shall not be greater than the amount of the purchase price of the Product, at the option of Trinity, during the warranty period. All replaced parts and Products become the property of Trinity and must be returned to Trinity.

This warranty excludes normal wear and tear of the Product and its parts or components, and damage arising

from any of the following: negligent use or misuse of the Product, use contrary to this User’s Manual, or

alteration by anyone other than Trinity. The warranty period of 1 year shall not be extended or renewed by the repair or replacement of, or compensation for, the Product. Any warranty implied by applicable law is limited in duration to one year from the date of purchase and is subject to the same conditions and limitations as is provided for our express warranty.

Except as set forth herein, and to the extent of applicable there are no warranties on this Product either express or implied, and Trinity disclaims all warranties including, but not limited to, any implied warranties of merchantability, infringement or fitness for a particular purpose. No warranty or guarantee given by any person, firm, or corporation with respect to this product shall be binding on Trinity.

If your Product is defective or otherwise requires service or parts, please call TRINITY Customer Service tollfree at (800) 985-5506, between 5:00 a.m. and 5:00 p.m., PST. Please tell us which model you purchased, the

date of the purchase, and the problem with your Product. A copy of your original purchase receipt must

accompany your service request.

LIMITATION OF REMEDIES AND LIABILITY

Trinity (and its employees, officers, members, managers, affiliates an assigns) shall not be liable for any incidental, consequential, special, indirect, remote, special or punitive damages for breach of any warranty, express or implied, including, but not limited to, lost profits, lost savings, loss of anticipated benefits and

attorneys’ fees, which arise out of the purchase, use or inability to use the Product, whether arising out of

contract, negligence, strict tort, product liability, or any other legal theory on which a claim is based. As noted above, to the extent damages are allowed by our express warranty or by applicable law, those

damages may not exceed the purchase price paid for the Product. Without limiting the foregoing Purchaser

assumes all risk and liability for loss, damage or injury to Purchaser and Purchaser’s property and to others

and their property arising out of the use, misuse, or inability to use this Product. This limited warranty shall not extend to anyone other than the original purchaser of this product, is nontransferable and states your exclusive remedy.

Some states do not allow the exclusion or limitation of incidental, consequential, special, or punitive damages, so the above limitation or exclusion may not apply to you. The above warranty gives you specific legal rights, and you may have other rights which vary from state to state.

1 YEAR LIMITED WARRANTY

Page 12

TRINITY Customer Service

TEL: 800.985.5506

FAX: 310.347.4134

EMAIL: [email protected]

Monday through Friday

5:00 AM – 5:00 PM (PST)

www.trinityii.com

QUESTIONS? NEED PARTS?

WE ARE HERE TO HELP!

Please feel free to contact us. There are no questions too small, or

any problems too big. We’re committed to providing our customers

with the highest level of service.
