TRENDnet TPE-224WS, Utility CD-ROM User Manual
Quick Installation Guide
TPE-224WS
Table of Contents
Table of Contents
English ......................................................................................................
1. Before You Start
2. Hardware Installation ........................................................................
3. Web Management Utility ....................................................................
Troubleshooting ........................................................................................
................................................................................
1
1
2
3
6
Version 03.13.2006
1. Before You Start
Package Content
TPE-224WS
Quick Installation Guide
Utility CD-ROM
2 mounting brackets with screws
AC Power Cord
System Requirements
Web Browser: Internet Explorer (5.0 or above), Netscape (6.0 or above)
Computer with Network adapter installed
Application
Advanced Wireless Pan & Tilt
Internet Camera Server
(TV-IP400W)
Advanced Day/Night
Internet Camera Server
(TV-IP300)
108Mbps 802.11g
Wireless Access Point
(TEW-450APB)
Power over Ethernet
(PoE) Splitter
(TPE-102S)
Power over Ethernet
(PoE) Splitter
(TPE-102S)
Power over Ethernet
(PoE) Splitter
(TPE-102S)
Power + Ethernet Data
26-Port 10/100/1000Mbps
Gigabit Web Smart
PoE Switch
(TPE-224WS)
Power over Ethernet
(PoE) Splitter
(TPE-102S)
1
English
108Mbps 802.11g
Hot-Spot Access Point
(TEW-453APB)
108Mbps 802.11g
Hot-Spot Access Point
(TEW-453APB)
Advanced Wireless Day/Night
Internet Camera Server)
(TV-IP300W)
2. Hardware Installation
1. Connect the Power Cord to the
rear of the TPE-224WS and then to
a power outlet.
2. Connect a CAT-5 network
cable from the computer to an
available Ethernet port of the
TPE-224WS.
2
English
