TRENDnet TK-208K User Manual

User’s Guide

TK-208K

Table of Contents

Table of Contents

English ......................................................................................................

1. Before You Start

2. How to Connect .................................................................................

3. Using the KVM Switch .......................................................................

Specifications ............................................................................................

Troubleshooting ........................................................................................

.................................................................................

1

1
2
4

6
7

Version 10.31.05

1. Before You Start

System Requirements

VGA or SVGA Compatible Monitor
6-pin Mini-Din PS/2 Keyboard
6-pin Mini-Din PS/2 Mouse
Speakers
Microphone

Application

Package Content

TK-208K
Multi-Language User’s Guide
2 Sets of KVM & Audio Cables

PC 1

LCD Monitor

Keyboard Mouse

PC 2

2-Port PS/2 Audio

KVM Switch

(TK-208K)

Speakers

Microphone

1

English

2. How to Connect

1. Connect the Monitor to your
Switch's Console Port.

2. Connect the Keyboard, Mouse,
Microphone and Speakers to the
Switch's Console Port.

3. Use the provided KVM cables to
connect your PC to your KVM
switch.

2

English

4. Connect the other end of the cable
to the Switch's PC Port.

5. Connect the other end of the Audio
cable to the Switch's Audio Port.

6. Turn on all connected PC’s.

Your installation is now complete.

3

English

3. Using the KVM Switch

To alternate between computers, you use hot-key commands.

Hot-Key Commands

A keyboard hot-key command consists of three keystrokes:

Hot-Key command = ScrLk + ScrLk + Command key(s)

After pressing the ScrLk key, you have 2 seconds to press the ScrLk key again.
You then have another 2 seconds to press a command key. If you do not press
a key within 2 seconds, the switch will exit hot-key mode.

NOTE

1. Hotkey command works on top row numbers keys only.

2. When the binding of PC & Audio/Mic port switching is enabled by the hotkey
sequence, any PC and Audio/Mic switching are bound together.

3. For non-PnP OS(Linux, Windows NT 4.0), please use the following

commands to reset the mouse setting:

4. Mac User must note: Standard PC Keyboard mapping to MAC
Keyboard:

Hot-Key convention: The hotkey notation ,denotes that you should hit the
individual key consecutively one at a time, not simultaneously.

4

English

Command

Select PC

Select Audio/Mic
Channel

Quick Reference Sheet for TK-208K

Hot-Keys

ScrLk ScrLk X

+ +

x = 1 ~ 2 for PC channel number

ScrLk ScrLk

+ +

(Fx is a function key) x = 1 ~ 2 for Audio mic
channel number

FX

Select the active PC channel.

Select the active Audio/Mic channel

Description

Bind PC & Audio/Mic
Switching

UnBind PC & Audio/
Mic Switching

Next higher PC
channel

Next lower PC
channel

Console Mouse/
Keyboard Reset

Autoscan

Stop Autoscan

ScrLk ScrLk

+ +

ScrLk ScrLk

+ +

ScrLk ScrLk

+ +

ScrLk ScrLk

+ +

ScrLk ScrLk

+ +

ScrLk ScrLk

+ +

Press any key on keyboard

(Arrow down)

Q

W

(Arrow up)

End

S

Enable the binding of PC port and Audio/Mic port
switching.

Disable the binding of PC port and Audio/Mic port
switching.

Select the next higher available computer

Select the next lower available computer

Reset mouse/keyboard on the console side. (works on
non-PnP OS only)

Autoscan through every connected channel for
quick screen browsing of each channel (scan delay
= 10 seconds).

Terminate Autoscan activity.

5

English

Specifications

Computer Connections:

KVM Cable:

Cable Connectors:

Console Port Connectors:

Port Selection:

Auto-Scan Intervals:

Keyboard State:

Power Type:

Dimensions:

Weight:

Humidity:

2
2 Sets of 1.2M (4ft) KVM & Audio Cables

KVM

To Console: 1 x 15-pin HDB type VGA (Male)
To PC: • 1 x PS/2 Keyboard 6-pin Mini Din (Male)

• 1 x PS/2 Mouse 6-pin Mini Din (Male)

• 1 X VGA HDB 15-pin (Male)

Audio

To Console: 2 x USB (Type Mini B)
To PC: • 1 x 3.5mm audio in/out jack

• 1 x 3.5mm microphone in/out jack
Keyboard: PS/2 Keyboard 6-pin Mini Din (Female)

Mouse: PS/2 Keyboard 6-pin Mini Din (Female)
Monitor: VGA HDB 15-pin (Female)
Speaker: 3.5mm audio in/out jack
Microphone: 3.5mm microphone in/out jack

Push Button and Hot-Key Commands
10 seconds
Saved and Restored
PS/2 Interface Power

95 x 65 x 30 mm (3.7 x 2.6 x 1.2 in.)
99 g (3.5 oz)
0º ~ 40ºC (32º ~104º F)Operating Temperature:

-20º ~ 60ºC (-4º ~ 140º F)Storage Temperature:
0%~90%, Non-Condensing
FCC and CECertifications:

6

Troubleshooting

Where is the power supply? I did not find one in the box.

Q1:

The TK-208K does not require a power supply. It draws power from

A1:

your computer's PS/2 connections. As long as your KVM switch is connected to
the PS/2 port, it will receive the necessary power to function.

I have the KVM switch connected properly, but my keyboard and mouse don't

Q2:

work.

Please make sure your PS/2 port is working properly by testing it with your

A2:

other PS/2 devices. Once you confirm that the PS/2 port is functional, please
reboot your computers, and try to use the KVM switch again.

Can I connect and disconnect the PS/2 cables while the computers are turned

Q3:

on?

Yes, you can connect or disconnect the PS/2 cables while the computers are

A3:

turned on because the PS/2 interface is Plug-and-Play and Hot-Pluggable.

Will the KVM switch remember the keyboard settings between computers?

Q4:

Yes, the KVM switch will remember the keyboard settings when switching

A4:

between your computers. (i.e.: Cap lock, Num key, etc.)

How do I switch from one computer to another with the KVM switch?

Q5:

You may switch between PCs by pressing the Push button on the KVM switch

A5:

or by using the Hot-Key commands.

If you have further questions, please contact TRENDnet’s Technical Support
Department.
