Quick Installation Guide
TK-804R
TK-1604R
Technical Specifications
Management:
Console Port Connectors:
Daisy-Chain Port Connectors:
PC Port Connectors:
(all female)
VGA Resolution:
Daisy-Chain Levels:
Maximum Number of PC
Connections:
Port Selection:
LED Segment:
Keyboard State: Saved and restored
Auto-Scan Intervals:
Power:
Size (19" Rack mount):
Dimensions:
Weight:
Humidity:
TK-804R: 8 computers
TK-1604R: 16 computers
1 x USB keyboard Type A
1 x USB mouse Type A
1 x PS/2 keyboard 6-pin mini din female
1 x PS/2 mouse 6-pin mini din female
1 x VGA HDB 15-pin female
1 x VGA HDB 15-pin male (Daisy-Chain IN)
1 x VGA HDB 15-pin female (Daisy-Chain OUT)
TK-803R: 8 x VGA HDB 15-pin
TK-1603R: 16 x VGA HDB 15-pin
2048 x 1536
8 Levels
TK-804R: 64 Computers
TK-1604R: 128 Computers
Push Button, OSD and Hot-Key Commands
Per Port : PC Link (Green) ; PC Active (Red)
10 ~ 100 seconds
PS/2 Interface Power
USB Interface Power
External AC Power Adapter : 9V DC, 1A
1RU
407 x 164 x 45 mm (16 x 6.5 x 1.8 in)
TK-803R : 1.70 kg (4.15 lbs)
TK-1603R : 2.06 kg (4.55 lbs)
0ºC ~ 40ºC (32ºF ~104ºF)Operating Temperature:
-20ºC ~ 60ºC (-4ºF ~ 140ºF)Storage Temperature:
0%~90%, Non-Condensing
FCC and CECertifications:
12
Troubleshooting
Do I need to use the included external AC adapter?
Q1:
Q2:
What should I do?
Q3:
Q4:
Q5:
Q6:
TK-207K/TK-407K with the TK-804R/TK-1604R?
It is recommended that you use the included external AC adapter with the
A1:
TK-804R/TK-1604R KVM switch.
I have the KVM switch connected properly, but my keyboard and mouse don't work.
First, make sure the power adapter is plugged into your KVM switch. Second, make
A2:
sure your PS/2/USB ports are working properly by connecting your mouse and keyboard
directly to the PS/2 or USB port computer. Third, once you confirm that the PS/2 or USB
ports are functional, please reboot your computers, and try to use the KVM switch again.
Fourth, if your computer is running Windows 98SE, you may need to download and install
the USB hot fix. Please go to this link for download and installation instructions:
http://support.microsoft.com/kb/q240075
instructions in Section 2.
Can I connect or disconnect the KVM cables while the computers are turned on?
Yes, you can connect or disconnect the KVM cables while the computers are
A3:
turned on, because the interface is Hot-Pluggable.
Will the KVM switch restore the keyboard settings when switching between computers?
Yes, the KVM switch will restore the keyboard settings when switching
A4:
between computers. (i.e.: Caps Lock, Num Lock, etc.)
How do I switch from one computer to another with the KVM switch?
A5:
You can switch computers by pressing the Push Buttons on the KVM switch or using the
Hot Key commands. Go to Section 3 Operation for more information.
I already have the TK-207K/TK-407K. Can I use the KVM cables that come with the
A6
: You can not use the KVM cables that come with the TK-207K/TK-407K. The pin layout
for the TK-804R/TK-1604R is different from the TK-207K/TK-407K. You must use the
TK-CU06/TK-CU10/TK-CU15.
. Once the hot fix is installed, follow the installation
Q7:
Does the keyboard and mouse have to be the same type (e.g. USB or PS/2)?
A7:
One device can be USB while the other device is PS/2.
If you still encounter problems or have any questions regarding the TK-804R/TK-1604R, please
contact TRENDnet's Technical Support Department.
13
Limited Warranty
TRENDnet warrants its products against defects in material and
workmanship, under normal use and service, for the following lengths of
time from the date of purchase.
TK-804R/TK-1604R - 2-Year Warranty
If a product does not operate as warranted above during the applicable
warranty period, TRENDnet shall, at its option and expense, repair the
defective product or part, deliver to customer an equivalent product or
part to replace the defective item, or refund to customer the purchase
price paid for the defective product. All products that are replaced will
become the property of TRENDnet. Replacement products may be new
or reconditioned.
TRENDnet shall not be responsible for any software, firmware,
information, or memory data of customer contained in, stored on, or
integrated with any products returned to TRENDnet pursuant to any
warranty.
There are no user serviceable parts inside the product. Do not remove
or attempt to service the product by any unauthorized service center.
This warranty is voided if (i) the product has been modified or repaired
by any unauthorized service center, (ii) the product was subject to
accident, abuse, or improper use (iii) the product was subject to
conditions more severe than those specified in the manual.
Warranty service may be obtained by contacting TRENDnet office within
the applicable warranty period for a Return Material Authorization (RMA)
number, accompanied by a copy of the dated proof of the purchase.
Products returned to TRENDnet must be pre-authorized by TRENDnet
with RMA number marked on the outside of the package, and sent
prepaid, insured and packaged appropriately for safe shipment.
14
WARRANTIES EXCLUSIVE: IF THE TRENDnet PRODUCT DOES NOT
OPERATE AS WARRANTED ABOVE, THE CUSTOMER'S SOLE
REMEDY SHALL BE, AT TRENDnet'S OPTION, REPAIR OR
REPLACEMENT. THE FOREGOING WARRANTIES AND REMEDIES
ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER WARRANTIES,
EXPRESSED OR IMPLIED, EITHER IN FACT OR BY OPERATION OF
LAW, STATUTORY OR OTHERWISE, INCLUDING WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
TRENDnet NEITHER ASSUMES NOR AUTHORIZES ANY OTHER
PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN
CONNECTION WITH THE SALE, INSTALLATION MAINTENANCE OR
USE OF TRENDnet'S PRODUCTS.
TRENDnet SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS
TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED
DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY
CUSTOMER'S OR ANY THIRD PERSON'S MISUSE, NEGLECT,
IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED
ATTEMPTS TO REPAIR OR MODIFY, OR ANY OTHER CAUSE
BEYOND THE RANGE OF THE INTENDED USE, OR BY ACCIDENT,
FIRE, LIGHTNING, OR OTHER HAZARD.
LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW
TRENDnet ALSO EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY
LIABILITY, WHETHER BASED IN CONTRACT OR TORT (INCLUDING
NEGLIGENCE), FOR INCIDENTAL, CONSEQUENTIAL, INDIRECT,
SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND, OR FOR LOSS OF
REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF
INFORMATION OR DATE, OR OTHER FINANCIAL LOSS ARISING OUT
OF OR IN CONNECTION WITH THE SALE, INSTALLATION,
MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION
OF THE POSSIBILITY OF SUCH DAMAGES, AND LIMITS ITS LIABILITY
TO REPAIR, REPLACEMENT, OR REFUND OF THE PURCHASE PRICE
PAID, AT TRENDnet’S OPTION. THIS DISCLAIMER OF LIABILITY FOR
DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED
HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE.
Governing Law: This Limited Warranty shall be governed by the laws of
the state of California.
AC/DC Power Adapter, Cooling Fan, Cables and Power Supply carry a 1
Year Warranty
15
Certifications
This equipment has been tested and found to comply with FCC and CE Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received. Including interference that may
cause undesired operation.
Waste electrical and electronic products must not
be disposed of with household waste. Please
recycle where facilities exist. Check with you Local
Authority or Retailer for recycling advice.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO
OPERATE THE EQUIPMENT.
ADVERTENCIA
En todos nuestros equipos se mencionan claramente las caracteristicas del adaptador de
alimentacón necesario para su funcionamiento. El uso de un adaptador distinto al
mencionado puede producir daños fisicos y/o daños al equipo conectado. El adaptador
de alimentación debe operar con voltaje y frecuencia de la energia electrica domiciliaria
existente en el pais o zona de instalación.
TRENDnet Technical Support
.
US Canada
Toll Free Telephone: 1(866) 845-3673
24/7 Tech Support
Europe (Germany France Italy Spain Switzerland UK)
Toll Free Telephone: +00800 60 76 76 67
English/Espanol - 24/7
Francais/Deutsch - 11am-8pm, Monday - Friday MET
. . . . .
Worldwide
Telephone: +(31) (0) 20 504 05 35
English/Espanol - 24/7
Francais/Deutsch - 11am-8pm, Monday - Friday MET
