Quick Installation Guide
TEW-AMBA
Table of Contents
Table of Contents
English ......................................................................................................
1. Before You Start
2. Hardware Installation .........................................................................
3. Related Products ...............................................................................
Troubleshooting ......................................................................................................
................................................................................
1
1
2
4
5
Version 04.19.2006
Version 04.19.2006
1. Before You Start
System Requirements
2.4GHz 802.11b/g or 5.8GHz 802.11a access point, wireless router or
wireless PCI adapter with a RP-TNC male connector
Antenna with a RP-SMA female connector
Application
Package Contents
TEW-AMBA
Quick Installation Guide
Indoo r Antenna
TEW-AI86D
Wireless PCI Adapter
Wireless Router / AP
TEW-AI75O
Devices wit h RP-TNC
Male Connec tor
Antenna Stands
Indoo r Antenna
with Base
TEW-AI86DB
TEW-AI75OB
1
English
Surge Arrestor
(TEW-ASAK)
LMR200 Cable
(TEW-L202 /
TEW-L208)
+
LMR400 Cable
+
Indoo r / Outd oor
(TEW-L406 /
TEW-L412)
Indoor / Outdoor
Antenna
(TEW-AO09D)
Antenn a
+
Outdoor Antenna
(TEW-AO19D)
2. Hardware Installation
Note: For outdoor applications, the TEW-ASAK surge arrestor must be used
with outdoor antenna cables such as the TEW-L406 or TEW-L412.
Antenna
TEW-AI75O / TEW-AI86D
1. Take the RP-SMA male end of the
adapter and screw it securely into
an antenna with a RP-SMA female
connector.
Mounting Base for:
TEW-AI75O / TEW-AI86D
Indoor Antenna Cable
TEW-L202 / TEW-L208
Surge Arrestor Cable
TEW-ASAK
Surge Arrestor
TEW-ASAK
Outdoor Antenna Cable
TEW-L406 / L412
2
English
Note: Before proceeding to step 2, unscrew the detachable antenna from your
access point, wireless router or wireless PCI adapter.
2. Take the RP-TNC female end of
the adapter and screw it securely
into an access point, wireless
router or wireless PCI adapter with
a RP-TNC male connector.
Your Installation is completed.
Access Point/
Wireless router
Wireless PCI adapter
3
English
3. Related products
Connector
Type
Connector
Type
TEW-AI75O
RP-SMA
Female
TEW-AO08O
N-Type
Female
TEW-AI75OB
RP-SMA
Female
TEW-AO10O
N-Type
Female
TEW-AI86D
RP-SMA
Female
TEW-ASAK
Arrestor:
N-Type Male to
N-Type Female
Cable:
N-Type Male to
RP-SMA Female
TEW-AI86DB
RP-SMA
Female
TEW-L202
N-Type Male
to
RP-SMA
Female
TEW-AO09D
N-Type
Female
TEW-L208
N-Type Male
to
RP-SMA
Female
TEW-AO14D
N-Type
Female
TEW-L406
N-Type Male
to
N-Type
Female
TEW-AO19D
N-Type
Female
TEW-L412
N-Type Male
to
N-Type
Female
4
English
Troubleshooting
When I tried to screw in the TEW-AMBA, it will not tighten. What should I do?
Q1:
First, double check that your wireless device meets the minimum
A1:
requirements as listed in Section 1. Verify with the manufacturer of the wireless
device if you are not sure. Second, make sure that you are turning the correct
screw when you are trying to tighten the adapter. Please reference the
instructions and diagrams in Section 2.
Can I connect the TEW-AMBA to an outdoor antenna?
Q2:
The TEW-AMBA can be used for indoor or outdoor applications. For outdoor
A2:
applications, the TEW-AMBA must be used with the TEW-ASAK Surge Arrestor.
How much attenuation (signal loss) will my wireless network experience with
Q3:
the TEW-AMBA?
0.2dB Max.
A3:
Will the TEW-AMBA work with my wireless device?
Q4:
It will work with any access point, antenna, antenna cable, mounting base,
A4:
wireless router or wireless PCI adapter that meets the minimum requirements as
listed in Section 1.
If you still encounter problems or have any questions regarding the TEW-AMBA, please
contact TRENDnet's Technical Support Department.
Certifications
This equipment has been tested and found to comply with FCC and CE Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received. Including interference that may
cause undesired operation.
Waste electrical and electronic products must not
be disposed of with household waste. Please
recycle where facilities exist. Check with you Local
Authority or Retailer for recycling advice.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO
OPERATE THE EQUIPMENT.
5
Limited Warranty
TRENDnet warrants its products against defects in material and workmanship, under
normal use and service, for the following lengths of time from the date of purchase.
TEW-AMBA
If a product does not operate as warranted above during the applicable warranty period,
TRENDnet shall, at its option and expense, repair the defective product or deliver to
customer an equivalent product to replace the defective item. All products that are
replaced will become the property of TRENDnet. Replacement products may be new or
reconditioned.
TRENDnet shall not be responsible for any software, firmware, information, or memory
data of customer contained in, stored on, or integrated with any products returned to
TRENDnet pursuant to any warranty.
There are no user serviceable parts inside the product. Do not remove or attempt to
service the product through any unauthorized service center. This warranty is voided if
(i) the product has been modified or repaired by any unauthorized service center, (ii) the
product was subject to accident, abuse, or improper use (iii) the product was subject to
conditions more severe than those specified in the manual.
Warranty service may be obtained by contacting TRENDnet office within the applicable
warranty period for a Return Material Authorization (RMA) number, accompanied by a
copy of the dated proof of the purchase. Products returned to TRENDnet must be preauthorized by TRENDnet with RMA number marked on the outside of the package, and
sent prepaid, insured and packaged appropriately for safe shipment.
- 3-Year Warranty
6
WARRANTIES EXCLUSIVE: IF THE TRENDNET PRODUCT DOES NOT OPERATE
AS WARRANTED ABOVE, THE CUSTOMER’S SOLE REMEDY SHALL BE, AT
TRENDNET’S OPTION, REPAIR OR REPLACEMENT. THE FOREGOING
WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER
WARRANTIES, EXPRESSED OR IMPLIED, EITHER IN FACT OR BY OPERATION OF
LAW, STATUTORY OR OTHERWISE, INCLUDING WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. TRENDNET
NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT
ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION,
MAINTENANCE OR USE OF TRENDNET’S PRODUCTS.
TRENDNET SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND
EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES
NOT EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S
MISUSE, NEGLECT, IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED
ATTEMPTS TO REPAIR OR MODIFY, OR ANY OTHER CAUSE BEYOND THE
RANGE OF THE INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING, OR OTHER
HAZARD.
LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW TRENDNET
ALSO EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY LIABILITY, WHETHER
BASED IN CONTRACT OR TORT (INCLUDING NEGLIGENCE), FOR INCIDENTAL,
CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND,
OR FOR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF
INFORMATION OR DATE, OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN
CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE, USE,
PERFORMANCE, FAILURE, OR INTERRUPTION OF THE POSSIBILITY OF SUCH
DAMAGES, AND LIMITS ITS LIABILITY TO REPAIR, REPLACEMENT, OR REFUND
OF THE PURCHASE PRICE PAID, AT TRENDNET’S OPTION. THIS DISCLAIMER OF
LIABILITY FOR DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED
HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE.
Governing Law: This Limited Warranty shall be governed by the laws of the state of
California.
Note: AC/DC Power Adapter, Cooling Fan, and Power Supply carry 1-Year Warranty
