User’s Guide
TEW-AI75O
TEW-AI75OB
Table of Contents
Français ....................................................................................
1. Avant de commencer .......................................................
2. Procéder à l'installation ...................................................
Troubleshooting ........................................................................
1
1
3
7
Version:01.04.2006
1. Avant de commencer
Contenu de l'emballage
TEW-AI75O/TEW-AI75OB
Base de fixation de l'antenne
(TEW-AI75OB uniquement)
Guide de l'utilisateur
Kit d'installation (TEW-AI75OB uniquement)
Détails du produit
L‘antenne intérieure omnidirectionnelle est équipée d'une prise
SMA femelle inversée qui peut être branchée à votre Point
d'accès ou à votre adaptateur réseau sans fil.
AVERTISSEMENT: L'antenne peut basculer de 0° à 180° et
pivoter à 360°. Le câble interne de l'antenne étant fixé, veuillez ne
pas faire pivoter l'antenne au-delà de 360°.
1
Français
Fixation murale ou sur cloison (la base de l'antenne est équipée
d'aimants)
Pour installer l'antenne, vous pouvez la fixer au mur à l'aide des
Fixations et des vis fournies ou simplement l'appliquer sur une
surface métallique.
AVERTISSEMENT: Veuillez NE PAS positionner l'antenne
horizontalement. L'antenne produit des signaux omnidirectionnels
qui son parallèles au sol lorsque l'antenne est correctement
orientée verticalement.
2
Français
2. Installation du matériel
Dispositifs recommandés pour brancher cette
antenne
AVERTISSEMENT: Veuillez vous assurer que l'antenne de
votre terminal sans fil est amovible.
Points d'accès sans fil / routeur avec antenne(s) amovible(s)
Client caméra IP ou adaptateur PCI sans fil avec antenne amovible
Recommandation:
A cause de la nature des terminaux WiFi
(émission/réception), il est recommandé d'installer des antennes
externes sur la station de base ainsi que sur le client.
3
Français
Positions d'installations recommandées
Cette antenne omnidirectionnelle reçoit et émet à 360°. Son
emplacement idéal est donc au centre de la zone couverte.
Méthodes et configuration de fixation de la station
de base
VEUILLEZ LIRE ATTENTIVEMENT LES INSTRUCTIONS
D'INSTALLATION CI-DESSOUS AVANT DE FORER DES
TROUS DANS LE MUR.
Appuyez sur l'onglet
Soulevez le
couvercle
Enlevez le
contrepoids
Après avoir enlevé le couvercle de son logement, enlevez le
contrepoids métallique des clips de fixation, révélant ainsi les
trous des vis.
Afin de diminuer le poids et d'augmenter l'adhérence
magnétique, il est fortement recommandé d'enlever la plaque
métallique avant d'installer l'antenne au plafond, sur une
cloison ou sur toute surface métallique.
4
Français
AVERTISSEMENT: Veuillez vous assurer que le dispositif
de PA / client peut atteindre la position que vous destinez à
l'antenne (le câble de l'antenne mesure 1 mètre)
Choisissez
l'endroit
Positionnez le
modèle de base
Indiquez la
position des vis
A propos des vis
Après avoir foré les trous dans la cloison/ la plaque de plâtre,
enfoncer la cheville en plastique dans le trou (utiliser un foret de 3
mm). Laissez dépasser environ de 3 à 5 mm de la vis, comme
indiqué sur le schéma ci-dessous.
3mm
5
Français
Fixation au plafond à l'aide des clips de fixation ou
des aimants
Le système spécial de fixation au plafond est surtout recommandé
lorsque votre station de base sans fil est cachée dans le plafond
ou qu'un dispositif quelconque de protection anti-vol est installé.
Comment assembler le support de l'antenne au
plafond.
Pressez l'onglet et
faites pivoter
Fixez les clips à la jointure
Retournez le couvercle pour
exposer les clips de fixation
Camouflez le routeur / PA
Remarque: Si les jointures du plafond sont en métal,
retourner le couvercle de la base de l'antenne peut ne pas être
nécessaire, parce que la base est équipée d'aimants qui peuvent
être utilisés pour fixer l'antenne à la jointure du plafond.
6
Français
Troubleshooting
Why do some of my wireless PCs receive Wi-Fi signals, and other
Q1.
PCs get a weaker signal?
The TEW-AI75O is an Omni antenna and can only send and
A1.
receive signals from a specified radius. You can adjust the position
of the Wireless Access Point, extend your TEW-AI75O to an optimal
location, or move those wireless PCs closer to the Wireless Access
Point.
My access point indicates that it is receiving power, and my laptop
Q2.
is within range of the TEW-AI75O. However, my laptop does not
receive any signals from my access point.
Make sure that you properly connect the antenna to the Wi-Fi
A2.
Access Point. (See 2. hardware Installation)
Dose the TEW-AI75O work with my IEEE 802.11a Wireless Router
Q3.
or Wireless Card?
Yes. The TEW-AI75O is compatible with IEEE 802.11a/b/g
A3.
wireless devices.
Is it necessary to use the tapping screws or the wall anchors that
Q4.
come with the TEW-AI75OB?
It is only necessary if you decide to mount the TEW-AI75OB at a
A4.
permanent location. Use discretion when attaching mounting
brackets to the TEW-AI75OB.
If you have any questions regarding the TEW-AI75O/TEW-AI75OB, please
contact TRENDnet Technical Support Department.
Certifications
This equipment has been tested and found to comply with FCC and CE Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received.
Including interference that may cause undesired operation.
Waste electrical and electronic products must not
be disposed of with household waste. Please
recycle where facilities exist. Check with you
Local Authority or Retailer for recycling advice.
