TRENDNET TEW731BRV2 User Manual

TRENDnet User’s Guide

Cover Page

TRENDnet User’s Guide

Contents

Product Overview ........................................................................... 1

Package Contents .......................................................................................................... 1

Features ......................................................................................................................... 1

Product Hardware Features........................................................................................... 2

Application Diagram ...................................................................................................... 4

Basic Router Setup .......................................................................... 5

Creating a Home Network ............................................................................................. 5

Router Installation ......................................................................................................... 6

Connect additional wired devices to your network ..................................................... 11

Wireless Networking and Security ................................................. 12

How to choose the type of security for your wireless network .................................. 12

Secure your wireless network ..................................................................................... 13

Connect wireless devices to your router ..................................................................... 15

Connect wireless devices using WPS ........................................................................... 16

Basic wireless settings ................................................................................................. 18

Steps to improve wireless connectivity ....................................................................... 20

Advanced wireless settings .......................................................................................... 21

Access Control Filters .................................................................... 22

Access control basics ................................................................................................... 22

MAC address filters ................................................................................................. 22

Domain/URL Filters ................................................................................................. 23

Protocol/IP filters .................................................................................................... 24

Firewall rules ........................................................................................................... 25

Advanced Router Setup ................................................................. 27

Access your router management page ........................................................................ 27

Change your router login password ............................................................................ 27

Set your router date and time ..................................................................................... 28

Manually configure your Internet connection ............................................................ 28

IPv6 Internet Connection Settings ............................................................................... 29

Clone a MAC address ................................................................................................... 30

Change your router IP address .................................................................................... 31

Set up the DHCP server on your router ....................................................................... 31

Set up DHCP reservation ............................................................................................. 32

Enable/disable UPnP on your router ........................................................................... 33

Allow/deny VPN connections through your router ..................................................... 33

Allow/deny multicast streaming.................................................................................. 34

Identify your network on the Internet ........................................................................ 34

Allow remote access to your router management page ............................................. 35

Open a device on your network to the Internet .......................................................... 35

DMZ ......................................................................................................................... 35

Virtual Server .......................................................................................................... 36

Special Applications ................................................................................................ 38

Add static routes to your router .................................................................................. 39

Enable dynamic routing on your router ...................................................................... 41

Router Maintenance & Monitoring ............................................... 42

Reset your router to factory defaults .......................................................................... 42

Router Default Settings ............................................................................................... 42

Backup and restore your router configuration settings .............................................. 43

Restart your router ...................................................................................................... 45

Check connectivity using the router management page ............................................. 45

Check the router system information ......................................................................... 46

Table of Contents

TRENDnet User’s Guide

View your router log .................................................................................................... 47

Configure your router log ............................................................................................ 48

View your router packet statistics ............................................................................... 49

View wireless devices connected to your router ......................................................... 49

Capture packets using the router management page ................................................. 50

Enable SNMP on your router ....................................................................................... 50

Router Management Page Structure ............................................. 51

Technical Specifications................................................................. 52

Troubleshooting ............................................................................ 53

Appendix ...................................................................................... 54

Table of Contents

TRENDnet User’s Guide

Product Overview

Package Contents

In addition to your router, the package includes:

• Multi-Language Quick Installation Guide

• CD-ROM (User’s Guide)

• Network cable (1.5m / 5ft.)

• Power adapter (5V DC, 1A)

If any package contents are missing or damaged, please contact the retail store, online retailer, or reseller/distributor from which the product was purchased.

TEW-731BR

Features

TRENDnet’s N300 Wireless Home Router, model TEW-731BR, provides enhanced 300 Mbps wireless n speed and coverage to share files, play games, and stream video wirelessly. Advanced encryption protects your wireless network, Access Control tools help block unwanted Websites and unknown users, and embedded GREENnet technology reduces power consumption by up to 50%.

Advanced Multiple Input Multiple Output (MIMO) antenna technology reduces wireless dead spots. Wi-Fi Protected Setup (WPS) connects other WPS supported wireless adapters at the touch of a button. WMM® Quality of Service (QoS) technology prioritizes gaming, internet calls, and video streams. LEDs on the front of the router convey device status. Network wired devices to the four Fast Ethernet ports on the back of the router.

• 4 x 10/100Mbps Auto-MDIX LAN ports

• 1 x 10/100Mbps Auto-MDIX WAN port (internet)

• One touch wireless connection to wireless clients using the WPS button

• Wi-Fi compliant with IEEE 802.11n and IEEE 802.11b/g standards

• High-speed data rates of up to 300Mbps with IEEE 802.11n*

• GREENnet technology reduces power consumption by up to 50%

• Compatible with most popular cable / DSL internet service providers using

Dynamic / Static IP, PPPoE, PPTP and L2TP protocols

• Support for IPv6 (Internet Protocol v6) 6rd (IPv6 rapid deployment) DHCPv4,

manual and automatic configuration

• 2 fixed external antennas support high speed performance and great coverage

with MIMO technology

• Firewall features Network Address Translation (NAT)

• Virtual server and Application Level Gateway (ALG) services for special internet

applications

• Universal Plug and Play (UPnP) for auto discovery and support for device

configuration of Internet applications

• Dynamic DNS Client for dynamic Internet IP resolution

• Provides additional security with Internet Access Control (MAC Address,

Domain, and IP Filtering)

• Static and Dynamic RIP V1/2 routing support

• Easy setup via Web browser using Internet Explorer 6.0 or above, Firefox 2.0 or

above, Chrome, Opera, Safari

• Advanced wireless security of up to WPA2-RADIUS

• Wi-Fi Multimedia (WMM) Quality of Service (QoS) data prioritization

TEW-731BR

TRENDnet User’s Guide

• Indoor coverage up to 100 meters (330 ft.)* depending on the environment

• Outdoor coverage up to 300 meters (980 ft.)* depending on the environment

• 3- year limited warranty

*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary depending on interference, network traffic, building materials and other conditions.

TEW-731BR

Product Hardware Features

Rear View

• Reset Button –Use an item such as a paperclip to push and hold this button for

15 seconds and release to reset your router to its factory defaults.

• LAN Ports – Connect Network cables (also called network cables) from your

router LAN ports to your wired network devices.

• WAN Port–Connect a Network cable from your router WAN port to your

modem.

• Power Port – Connect the included power adapter from your router power

port and to an available power outlet.

Note: Use only the adapter that came with your router.

• On/Off Power Switch – Push the router On/Off push button to turn your router

“On” (Inner position) or “Off” (Outer position).

• Antennas – The antennas broadcast wireless network signals.

TRENDnet User’s Guide

Front View

TEW-731BR

• Power LED -This LED indicator is solid green when your router is powered on.

Otherwise if this LED indicator is off, there is no power to your router.

• Status LED - This LED indicator is blinking green when your router is ready and

working successfully. If this LED indicator is solid green on or off, your router is not receiving power or not working properly.

• WAN (Link/Activity) LED – This LED indicator is solid green when your router

WAN port is physically connected to the modem Network port (also called network port) successfully with a Network cable. The LED indicator will be blinking green while data is transmitted or received through the WAN port of your router.

• WLAN (Link/Activity) LED – This LED indicator is blinking green when the

wireless is “On” and functioning properly on your router. This LED indicator will be blinking green rapidly while data is transmitted or received by your wireless clients or wireless network devices connected to your router.

• LAN 1-4 (Link/Activity) LEDs – These LED indicators are solid green when the

LAN ports are successfully connected to your wired network devices (which are turned on). These LED indicators will blink green while data is transmitted or received through your router’s LAN ports.

TRENDnet User’s Guide

Side View

Application Diagram

TEW-731BR

The router is installed near the modem (supplied by your ISP “Internet Service Provider”) and physically connected to the router’s WAN port to the modem’s network

• WPS (Wi-Fi Protected Setup) –Push and hold this button for 3 seconds to

activate WPS. The button LED is blinking blue when WPS is activated.

port which connects to the Internet. Wireless signals from the router are broadcasted to wireless clients such as laptops (with wireless capability) thereby providing Internet access.

TRENDnet User’s Guide

Basic Router Setup

Creating a Home Network

What is a network?

A network is a group of computers or devices that can communicate with each other. A home network of more than one computer or device also typically includes Internet access, which requires a router.

A typical home network may include multiple computers, a media player/server, a printer, a modem, and a router. A large home network may also have a switch, additional routers, access points, and many Internet-capable media devices such as TVs, game consoles, and Internet cameras.

• Modem – Connects a computer or router to the Internet or ISP (Internet

Service Provider).

• Router – Connects multiple devices to the Internet.

• Switch –Connect several wired network devices to your home network. Your

router has a built-in network switch (the LAN port 1-4). If you have more wired network devices than available Network ports on your router, you will need an additional switch to add more wired connections.

How to set up a home network

1. For a network that includes Internet access, you’ll need:

• Computers/devices with a Network port or wireless networking capabilities.

• A modem and Internet service to your home, provided by your ISP (modem

typically supplied by your ISP).

• A router to connect multiple devices to the Internet.

2. Make sure that your modem is working properly. Your modem is provided by your Internet Service Provider (ISP) when you sign up for Internet service. If your modem is not working contact your ISP to verify functionality.

3. Set up your router. See “How to setup your router” below.

4. To connect additional wired computers or wired network devices to your network, see “Connect additional wired devices to your network” on page 11.

5. To set up wireless networking on your router, see “Wireless Networking and Security” on page 12.

How to setup your router

Refer to the Quick Installation Guide or continue to the next section “Router Installation” on page 6 for more detailed installation instructions.

Where to find more help

In addition to this User’s Guide, you can find help below:

• http://www.trendnet.com/support

(documents, downloads, and FAQs are available from this Web page))

TEW-731BR

TRENDnet User’s Guide

Router Installation

Before you Install

Many Internet Service Providers (ISPs) allow your router to connect to the Internet without verifying the information fields listed below. Skip this section for now and if your router cannot connect to the Internet using the standard installation process, come back to this page and contact your ISP to verify required ISP specification fields listed below.

1. Obtain IP Address Automatically (DHCP)

Host Name (Optional) Clone Mac Address (Optional)

2. Fixed IP address

WAN IP Address: _____. _____._____._____ (e.g. 215.24.24.129) WAN Subnet Mask: _____. _____._____._____ WAN Gateway IP Address: _____. _____._____._____ DNS Server Address 1: _____. _____._____._____ DNS Server Address 2: _____. _____._____._____

3. PPPoE to obtain IP automatically

User Name: _________ Password: ________________ Verify Password: ________________

4. PPPoE with a fixed IP address

User Name: _________ Password: ________________ Verify Password: ________________ IP Address: ____. _____._____._____ (e.g. 215.24.24.129)

5. PPTP or Russian PPTP

Type (Dynamic IP or Static IP) My IP Address: _____. _____._____._____ (e.g. 215.24.24.129) Subnet Mask:_____. _____._____._____ Gateway:_____. _____._____._____ Server IP: _____. _____._____._____ PPTP Account: ________________ PPTP Password: ________________ Retype Password: ________________

6. L2TP or Russia L2TP

Type (Dynamic IP or Static IP) My IP Address: _____. _____._____._____ (e.g. 215.24.24.129) Subnet Mask:_____. _____._____._____ Gateway:_____. _____._____._____ Server IP: _____. _____._____._____ L2TP Account: ________________ L2TP Password: ________________ Retype Password: ________________

7. Russia PPPoE

Type (Dynamic IP or Static IP) User Name: _________ Password: ________________ Verify Password: ________________

IP Address: ____. _____._____._____ (e.g. 215.24.24.129)

TEW-731BR

TRENDnet User’s Guide

Hardware Installation

1. Verify that you have an Internet connection when connecting your computer directly to your modem.

2. Turn off your modem.

3. Disconnect the Network cable from your computer to your modem.

4. Using a Network cable, connect your computer to one of the four LAN ports on the router.

5. Using another Network cable, connect the WAN port on the router to your modem.

6. Plug in the power adapter, connect it to the router’s power port, and then push the On/Off Power Switch to the “On” position (pushed in).

7. Turn on your modem.

8. Verify that the following front panel LED indicators on your router: Power (Solid Green), Status (Blinking Green), LAN 1, 2, 3, or 4 (Solid/Blinking Green for ports for which devices are connected), WAN (Solid/Blinking Green), and WLAN (Blinking Green).

TEW-731BR

TRENDnet User’s Guide

Setup Wizard

1. Open your web browser (e.g. Internet Explorer, Firefox, Safari, Chrome, or Opera) and go to http://192.168.10.1

2. Next to Language, click the drop-down list to select your preferred language. Enter the default user name and password and then click Login.

Default User Name: admin Default Password: admin

. Your router will prompt you for a user name and password.

3. The Setup Wizard will automatically appear. Click Next.

Note: If the Setup Wizard does not automatically appear, click Wizard (the bottom button on the left tab).

4. Enter a new login password for your router and enter it again next to “Verify Password” to confirm. This will change the password required to log into your router. Click Next.

Note: This is the password to enter your router’s management interface and NOT to connect to the router wirelessly. Once you change the login password, it will be required every time you log into your router. Store your router password in a location that you can reference at a future time.

TEW-731BR

TRENDnet User’s Guide

5. Select the Time Zone for your router and click Next.

6. Click Next at the Set LAN connection and DHCP Server window.

Note: If you are an advanced user, you can make LAN IP address interface and DHCP IP address range changes here.

7. This section determines what method the router will use to interface with your ISP service. Most ISP services allow your router to obtain an IP address automatically. Do not change the default setting of Obtain IP Automatically and click next to proceed.

Note: If you know that your ISP requires a configuration other than Obtain IP Automatically or if are having difficulty completing the router installation, please contact your ISP to verify all required settings for one of the options listed on page 6. The options listed on page 6 match the settings options available to choose from.

TEW-731BR

8. Wireless LAN: Select Enable for Wireless LAN.

Note: Selecting Disable will disable the wireless functionality of the router and will not allow wireless clients to connect.

TRENDnet User’s Guide

9. SSID: Enter a unique SSID (Wireless Network Name). Choose something that you would easily identify when searching for available wireless networks (using laptops, smart phones, etc.) Click Next.

Note:

1. To protect your network from unauthorized access, it is recommended to enable wireless encryption. See “Secure your wireless network” on page 13 for information on configuring wireless security.

2. Once wireless security is enabled on your router, each wireless device connecting to your router must be configured with the same wireless security type and key.

10. Click Restart and wait for your router to reboot.

11. Wait for your router to reboot.

12. Verify you have an Internet connection by opening a Web browser on your computer.

Note: If you cannot access the Internet, power down your modem and router again. Occasionally certain modems need to be power cycled to adopt new router settings.

TEW-731BR

TRENDnet User’s Guide

Connect additional wired devices to your network

You can connect additional computers or other network enabled devices to your network by using Network cables. Connect them to one of the available LAN ports labeled 1,2,3,4 on your router. Check the status of the LED indicators (1, 2, 3, or 4) on the front panel of your router to ensure the physical cable connection from your computer or device.

Note: If you encounter issues connecting to your network, there may be a problem with your computer or device network settings. Please ensure that your computer or device network settings (also called TCP/IP settings) are configured to obtain IP address settings automatically (also called dynamic IP address or DHCP) and to Obtain DNS Server address settings automatically.

TEW-731BR

TRENDnet User’s Guide

Wireless Networking and Security

How to choose the type of security for your wireless network

Setting up wireless security is very important. Leaving your wireless network open and unsecure could expose your entire network and personal files to outsiders. TRENDnet recommends reading through this entire section and setting up wireless security on your new router.

There are a few different wireless security types supported in wireless networking each

having its own characteristics which may be more suitable for your wireless network

taking into consideration compatibility, performance, as well as the security strength

along with using older wireless networking hardware (also called legacy hardware).

It is strongly recommended to enable wireless security to prevent unwanted users from

accessing your network and network resources (personal documents, media, etc.).

In general, it is recommended that you choose the security type with the highest

strength and performance supported by the wireless computers and devices in your

network. Please review the security types to determine which one you should use for

your network.

Wireless Encryption Types

cards(wireless clients), you may have to set your router to WEP to allow the old

adapters to connect to the router. Note: This encryption standard will limit

connection speeds to 54Mbps.

• WPA: This encryption is significantly more robust than the WEP technology.

Much of the older 802.11g hardware was been upgraded (with firmware/driver

upgrades) to support this encryption standard. Total wireless speeds under

this encryption type however are limited to 54Mbps.

• WPA-Auto: This setting provides the router with the ability to detect wireless

devices using either WPA or WPA2 encryption. Your wireless network will

automatically change the encryption setting based on the first wireless device

connected. For example, if the first wireless client that connects to your

wireless network uses WPA encryption your wireless network will use WPA

encryption. Only when all wireless clients disconnect to the network and a

wireless client with WPA2 encryption connects your wireless network will then

change to WPA2 encryption. NOTE: WPA2 encryption supports 802.11n speeds

and WPA encryption will limit your connection speeds to 54Mbps

• WPA2: This is the most secure wireless encryption available today, similar to

WPA encryption but more robust. This encryption standard also supports the

highest connection speeds. TRENDnet recommends setting your router to this

encryption standard. If you find that one of your wireless network devices does

not support WPA2 encryption, then set your router to either WPA or WPA-Auto

encryption.

TEW-731BR

• WEP: Legacy encryption method supported by older 802.11b/g hardware. This

is the oldest and least secure type of wireless encryption. It is generally not

recommended to use this encryption standard, however if you have old 802.11

b or 802.11g wireless adapters or computers with old embedded wireless

Note: Check the specifications of your wireless network adapters and wireless appliances

to verify the highest level of encryption supported.

Security Standard

WEP

WPA

WPA2

Standards

IEEE 802.11a/b/g/n

802.11g speeds)

IEEE 802.11a/b/g/n

802.11g speeds)

IEEE 802.11a/b/g/n

Highest

Setting

Up to 54Mbps

Up to 450Mbps*

Encryption Strength

Low

Medium

High

Open System or

Different key sizes

TKIP

8-63 characters

AES

8-63 characters

300Mbps, or 450Mbps)

TRENDnet User’s Guide

Below is brief comparison chart of the wireless security types and the recommended

configuration depending on which type you choose for your wireless network.

Compatible Wireless

Performance Under This

Additional Options

(802.11n devices will operate at

Shared Key, HEX or ASCII,

(802.11n devices will operate at

TKIP or AES, Preshared Key or RADIUS

Secure your wireless network

Wireless > Security

After you have determined which security type to use for your wireless network (see “How to choose the security type for your wireless network” on page 12), you can set up wireless security.

1. Log into your router management page (see “Access your router management page” on page 27

2. Click on Wireless, and click on Security.

3. Click on the Authentication Type drop-down list to select your wireless security type.

TEW-731BR

Recommended Configuration

*Dependent on the maximum 802.11n data rate supported by the device (150Mbps,

Open System ASCII 13 characters

Preshared Key

TRENDnet User’s Guide

Selecting WEP:

If selecting WEP (Wired Equivalent Privacy), please review the WEP settings to configure and click Apply to save the changes.

• WEP– Choose Open System or Shared Key.

Note: It is recommended to use Open System because it is known to be more secure than Shared Key.

• Mode – Choose HEX or ASCII.

Note: It is recommended to use ASCII because of the much larger character set that can be used to create the key.

• WEP Key – Choose the key length 64-bit or 128-bit.

Note: It is recommended to use 128-bit because it is more secure to use a key that consists of more characters.

• Key 1-4

o This is where you enter the password or key needed for a computer to

connect to the router wirelessly

o You can define up to 4 passwords or 4 keys. Only one key can be active

at a given time. Most users simply define one key.

o Choose a key index 1, 2, 3, or 4 and enter the key. o When connecting to the router, the client must match both the

password and the Key number. (e.g. if you have activated Key 2 with a

password of 12345, then the client must select: Key 2 (entering Key 1, 3, or 4 will block the ability to connect) and enter password 12345)

Selecting WPA, WPA-Auto, or WPA2 (WPA2 recommended):

First, from the Authentication Type row, select WPA, WPA-Auto, or WPA2.

Then from the PSK/EAP row, select either PSK or EAP

• PSK stands for Preshared Key

• EAP stands for Extensive Authentication Protocol, also called Remote

Authentication Dial-In User Service or RADIUS).

Note: EAP requires an external RADIUS server, PSK only requires you to create a passphrase.

The following section outlines options when selecting PSK (Preshared Key Protocol),

WEP Key Format

Character set 0-9 & A-F, a-f only Alphanumeric (a,b,C,?,*, /,1,2, etc.)

64-bit key length 10 characters 5 characters

128-bit key length 26 characters 13 characters

o Select a Cipher Type. When selecting WPA security, it is recommended

to use TKIP.

o When selecting WPA-Auto security, it is recommended to use AES. o When selecting WPA2 security, it is recommended to use AES.

HEX ASCII

TEW-731BR

TRENDnet User’s Guide

Create your Wireless security Passphrase (password or key):

• Passphrase – Enter the passphrase.

o This is the password or key that is used to connect your computer to

this router wirelessly

• Confirmed Passphrase – Re-enter the passphrase.

Note: 8-63 alphanumeric characters (a,b,C,?,*, /,1,2, etc.)

The following section outlines options when selecting EAP (Extensive Authentication Protocol),

EAP (Extensible Authentication Protocol) is also called Remote Authentication Dial-In User Service or RADIUS.

Select a Cipher Type

o When selecting WPA security, it is recommended to use TKIP. o When selecting WPA-Auto security, it is recommended to use AES. o When selecting WPA2 security, it is recommended to use AES.

• RADIUS Server 1/2 - Configure the RADIUS server settings.

Note: RADIUS Server 2 is optional and can be configured as a backup if there are any issues with RADIUS Server 1.

o IP – Enter the IP address of the RADIUS server. (e.g. 192.168.10.250) o Port – Enter the port your RADIUS server is configured to use for

RADIUS authentication.

Note: It is recommended to use port 1812.

o Shared Secret – Enter the shared secret used to authorize your router

with your RADIUS server.

Connect wireless devices to your router

A variety of wireless network devices can connect to your wireless network such as:

• Gaming Consoles

• Internet enabled TVs

TEW-731BR

• Network media players

• Smart Phones

• Wireless Laptop computers

• Wireless IP cameras

Each device may have its own software utility for searching and connecting to available wireless networks, therefore, you must refer to the User’s Manual/Guide of your wireless client device to determine how to search and connect to this router’s wireless network.

•

See the “Appendix” on page 54 network.

for general information on connecting to a wireless

TRENDnet User’s Guide

Connect wireless devices using WPS

WPS (Wi-Fi Protected Setup) is a feature that makes it easy to connect devices to your wireless network. If your wireless devices support WPS, you can use this feature to easily add wireless devices to your network.

Note: You will not be able to use WPS if you set the SSID Broadcast setting to Disabled.

There are two methods the WPS feature can easily connect your wireless devices to your network.

• Push Button Configuration (PBC) method o RECOMMENDED Hardware Push Button method–with an external

button located physically on your router and on your client device

o WPS Software/Virtual Push Button - located in router management

page

• PIN (Personal Identification Number) Method - located in router management

page

Note: Refer to your wireless device documentation for details on the operation of WPS.

Recommended Hardware Push Button (PBC) Method

• Note it is recommended that a wireless key (passphrase or password) is created

before connecting clients using the PBC method. If no wireless key is defined when connecting via PBC, the router will automatically create an encryption key that is 64 characters long. This 64 character key will then have to be used if one has to connect computers to the router using the traditional connection method.

To add a wireless device to your network, simply push the WPS button on the wireless device you are connecting(consult client device User’s Guide for length of time), then push and hold the WPS button located on your router for 3 seconds and release it. A blue LED on your router WPS button will flash indicating that the WPS setup process has been activated on your router. (See “Product Hardware Features” on page 2

For connecting additional WPS supported devices, repeat this process for each additional device.

PBC (Software/Virtual Push Button)

Wireless >WiFi Protected Setup

In addition to the hardware push button located physically on your router, the router management page also has push button which is a software or virtual push button you can click to activate WPS on your router.

1. Log into your router management page (see “Access your router management page” on page 27

2. Click on Wireless, and click on WPS.

3. To add a wireless device to your network, simply the push the WPS button on the wireless device (consult wireless device’s User’s Guide for length of time), you are connecting, then in your router management page next to Push Button Configuration, click Start PBC.

4. You will receive a message counting down indicating the WPS process is activated on your router.

5. You will receive a success message indicate that the wireless device successfully connected using WPS.

)

TEW-731BR

+ 43 hidden pages
