TRENDNET TEW623PIV3 User Manual

Regulatory notes and statements
Wireless LAN, Health and Authorization for use

Radio frequency electromagnetic energy is emitted from Wireless LAN devices.
The energy levels of these emissions however are far much less than the
electromagnetic energy emissions from wireless devices like for example mobile
phones. Wireless LAN devices are safe for use frequency safety standards and
recommendations. The use of Wireless LAN devices may be restricted in some
situations or environments for example:

·On board of airplanes, or

·In an explosive environment, or

·In case the interference risk to other devices or services is perceived or identified
as harmful

In case the policy regarding the use of Wireless LAN devices in specific
organizations or environments (e.g. airports, hospitals, chemical/oil/gas industrial
plants, private buildings etc.) is not clear, please ask for authorization to use these
devices prior to operating the equipment.

Regulatory Information/disclaimers

Installation and use of this Wireless LAN device must be in strict accordance with
the instructions included in the user documentation provided with the product. Any
changes or modifications made to this device that are not expressly approved by the
manufacturer may void the user’s authority to operate the equipment. The
Manufacturer is not responsible for any radio or television interference caused by
unauthorized modification of this device, of the substitution or attachment.
Manufacturer and its authorized resellers or distributors will assume no liability for
any damage or violation of government regulations arising from failing to comply
with these guidelines.

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:

i

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.

IMPORTANT NOTE:
FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.

This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.

The availability of some specific channels and/or operational frequency bands are
country dependent and are firmware programmed at the factory to match the
intended destination. The firmware setting is not accessible by the end user.

ii

Industry Canada statement:

This device complies with RSS-210 of the Industry Canada Rules. Operation is
subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired
operation.

IMPORTANT NOTE:
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an

uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.

This device has been designed to operate with an antenna having a maximum gain
of 2 dB. Antenna having a higher gain is strictly prohibited per regulations of
Industry Canada. The required antenna impedance is 50 ohms.

iii

Europe – EU Declaration of Conformity

This device complies with the essential requirements of the R&TTE Directive
1999/5/EC. The following test methods have been applied in order to prove
presumption of conformity with the essential requirements of the R&TTE Directive
1999/5/EC:

EN 60 950-1: 2001 +A11: 2004

Safety of Information Technology Equipment

EN 50392: 2004

Generic standard to demonstrate the compliance of electronic and electrical
apparatus with the basic restrictions related to human exposure to electromagnetic
fields (0 Hz - 300 GHz)

EN 300 328 V1.6.1 (2004-11)

Electromagnetic compatibility and Radio spectrum Matters (ERM); Wideband
transmission systems; Data transmission equipment operating in the 2,4 GHz ISM
band and using wide band modulation techniques; Harmonized EN covering
essential requirements under article 3.2 of the R&TTE Directive

EN 301 489-17 V1.6.1 (2005-08) and EN 301 489-1 V1.4.1 (2002-08)

Electromagnetic compatibility and Radio spectrum Matters (ERM);
ElectroMagnetic Compatibility (EMC) standard for radio equipment and services;
Part 17: Specific conditions for 2,4 GHz wideband transmission systems and 5 GHz
high performance RLAN equipment

This device is a 2.4 GHz wideband transmission system (transceiver), intended for
use in all EU member states and EFTA countries, except in France and Italy where
restrictive use applies.

In Italy the end-user should apply for a license at the national spectrum authorities
in order to obtain authorization to use the device for setting up outdoor radio links
and/or for supplying public access to telecommunications and/or network services.

This device may not be used for setting up outdoor radio links in France and in
some areas the RF output power may be limited to 10 mW EIRP in the frequency
range of 2454 – 2483.5 MHz. For detailed information the end-user should contact
the national spectrum authority in France.

0560

iv

[Czech]

Česky

TRENDnet tímto prohlašuje, že tento TEW-623PI je ve shodě se základními požadavky a
dalšími příslušnými ustanoveními směrnice 1999/5/ES.

Dansk

[Danish]

Deutsch

[German]

Eesti

[Estonian]

English Hereby, TRENDnet, declares that this TEW-623PI is in compliance with the essential

Español

[Spanish]

Ελληνική

[Greek]

Français

[French]

Italiano

[Italian]

Undertegnede TRENDnet erklærer herved, at følgende udstyr TEW-623PI overholder de
væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.

Hiermit erklärt TRENDnet, dass sich das Gerät TEW-623PI in Übereinstimmung mit den
grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie
1999/5/EG befindet.

Käesolevaga kinnitab TRENDnet seadme TEW-623PI vastavust direktiivi 1999/5/EÜ
põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele.

requirements and other relevant provisions of Directive 1999/5/EC.
Por medio de la presente TRENDnet declara que el TEW-623PI cumple con los requisitos

esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.

ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ TRENDnet ∆ΗΛΩΝΕΙ ΟΤΙ TEW-623PI ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ
ΤΙΣ ΟΥΣΙΩ∆ΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ∆ΙΑΤΑΞΕΙΣ ΤΗΣ Ο∆ΗΓΙΑΣ

1999/5/ΕΚ.
Par la présente TRENDnet déclare que l'appareil TEW-63PI est conforme aux exigences

essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE.
Con la presente TRENDnet dichiara che questo TEW-623PI è conforme ai requisiti essenziali ed

alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.

Latviski

[Latvian]

Lietuvių

[Lithuanian]

Nederlands

[Dutch]

Malti

[Maltese]

Magyar

[Hungarian]

Polski

[Polish]

Português

[Portuguese]

Slovensko

[Slovenian]

Slovensky

[Slovak]

Ar šo TRENDnet deklarē, ka TEW-623PI atbilst Direktīvas 1999/5/EK būtiskajām prasībām un
citiem ar to saistītajiem noteikumiem.

Šiuo TRENDnet deklaruoja, kad šis TEW-623PI atitinka esminius reikalavimus ir kitas
1999/5/EB Direktyvos nuostatas.

Hierbij verklaart TRENDnet dat het toestel TEW-623PI in overeenstemming is met de essentiële
eisen en de andere relevante bepalingen van richtlijn 1999/5/EG.

Hawnhekk, TRENDnet jiddikjara li dan TEW-623PI jikkonforma mal-ħtiġijiet essenzjali u ma
provvedimenti oħrajn relevanti li hemm fid-Dirrettiva 1999/5/EC.

Alulírott, TRENDnet nyilatkozom, hogy TEW-623PI megfelel a vonatkozó alapvetõ
követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak.

Niniejszym TRENDnet oświadcza, że TEW-623PI jest zgodny z zasadniczymi wymogami oraz
pozostałymi stosownymi postanowieniami Dyrektywy 1999/5/EC.

TRENDnet declara que este TEW-623PI está conforme com os requisitos essenciais e outras
disposições da Directiva 1999/5/CE.

TRENDnet izjavlja, da je ta TEW-623PI v skladu z bistvenimi zahtevami in ostalimi
relevantnimi določili direktive 1999/5/ES.

TRENDnet týmto vyhlasuje, že TEW-623PI spĺňa základné požiadavky a všetky príslušné
ustanovenia Smernice 1999/5/ES.

Suomi

[Finnish]

Svenska

[Swedish]

TRENDnet vakuuttaa täten että TEW-623PI tyyppinen laite on direktiivin 1999/5/EY oleellisten
vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen.

Härmed intygar TRENDnet att denna TEW-623PI står I överensstämmelse med de väsentliga
egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG.

Export restrictions

v

This product or software contains encryption code that may not be exported or
transferred from the US of Canada without an approved US Department of
Commerce export license.

Safety Information

Your device contains a low power transmitter. When device is transmitted it sends
out radio frequency (RF) signal.

CAUTION: To maintain compliance with FCC’s RF exposure guidelines, this
equipment should be installed and operated with minimum distance 20cm between
the radiator and your body. Use on the supplied antenna. Unauthorized antenna,
modification, or attachments could damage the transmitter and may violate FCC
regulations.

The antenna(s) used for this transmitter must be installed to provide a separation
distance of at least 20 cm from all persons and must not be co-located or operating
in conjunction with any other antenna or transmitter.

CE Mark Warning

This is a Class B product. In a domestic environment, this product may cause radio
interference, in which case the user may be required to take adequate measures.

Protection requirements for health and safety – Article 3.1a

Testing for electric safety according to EN 60950 has been conducted. These are
considered relevant and sufficient.

Protection requirements for electromagnetic compatibility – Article

3.1b

Testing for electromagnetic compatibility according to EN 301 489-1, EN 301 489­17 and EN 55024 has been conducted. These are considered relevant and sufficient.

Effective use of the radio spectrum – Article 3.2

Testing for radio test suites according to EN 300 328-2 has been conducted. These
are considered relevant and sufficient.

CE in which Countries where the product may be used freely:

Germany, UK, Italy, Spain, Belgium, Netherlands, Portugal, Greece, Ireland,
Denmark, Luxembourg, Austria, Finland, Sweden, Norway and Iceland.

France: except the channel 10 through 13, law prohibits the use of other channels.

vi

TABLE OF CONTENT

Introduction................................................................................................1

Overview of this User’s Guide .................................................................................1

Unpacking and Setup .................................................................................2

Unpacking.................................................................................................................2

Setup..........................................................................................................................2

Hardware Installation.................................................................................3

LED Indicator for CardBus.......................................................................................3

LED Indicator for PCI ..............................................................................................3

Check the installation................................................................................................3

Software Installation ..................................................................................4

Windows 2000/XP/Vista Utility and Driver Installation .........................................4

Windows Wireless Utility Setting ............................................................................5

Technical Specifications.........................................................................................17

vii

INTRODUCTION

Congratulations on your purchase of this 300Mbps 802.11n Wireless LAN Adapter.
This manual contains detailed instructions regarding the operation of this product.

Please keep this manual for future reference.
With the 300Mbps 802.11n Wireless LAN Adapter, a desktop or laptop computer

can communicate with another computer wirelessly. An easy-to-use utility is
bundled with the 300Mbps 802.11n Wireless LAN Adapter for configuration,
monitoring, and diagnostic purposes.

The 300Mbps 802.11n Wireless LAN Adapter can wirelessly transmit and receive
data, at a speed of up to 300 megabits per second.

The 300Mbps 802.11n Wireless LAN Adapter provides users with access to real­time information anywhere in their organization. The mobility of the 300Mbps

802.11n Wireless LAN Adapter provides productivity and service, which are not
available under wired networks. The 300Mbps 802.11n Wireless LAN Adapter can
easily adapt from peer-to-peer networks, suitable for a small number of users, to
full infrastructure networks of thousands of users that allow roaming around a
broad area.

Overview of this User’s Guide

Introduction. Describes the 300Mbps 802.11n Wireless LAN Adapter and its

features.
Unpacking and Setup. Helps you get started with the basic installation of the

300Mbps 802.11n Wireless LAN Adapter.

Hardware Installation. Describes the LED indicator on the Adapter.
Software Installation. Describes how to setup the driver and the utility setting.
Technical Specifications. Lists the technical (general, physical and environmental)

specifications of the 300Mbps 802.11n Wireless LAN Adapter.

1
