Trendnet TEW-603PI Quick Installation Guide
TEW-603PI
Quick Installation Guide
Version 09.15.2005
Copyright ©2005. All Rights Reserved. TRENDnet.
Table of Contents
English .................................................................................
1. Prepare for Installation ..................................................
2. Install Wireless Configuration Utility .............................
3. Install Hardware ............................................................
4. Install Drivers ................................................................
5. Wireless Configuration ..................................................
Româna ...............................................................................
1. Pregatiti-va de instalare ................................................
2. Instalarea programului Wireless Configuration Utility ...
3. Instalare fizica ...............................................................
4. Instalare drivere ............................................................
5. Configurarea Wireless ..................................................
Troubleshooting......................................................................
1
1
2
5
6
11
12
12
13
16
17
22
23
English
1. Prepare for Installation
Thank you for purchasing the TEW-603PI. Your new wireless network adapter
will allow you to share the Internet, files, or other resources by connecting you
to an 802.11g or 802.11b wireless network. This guide will help you setup and
configure your wireless card. Following the installation instructions should be
quick and easy. If you run into problems, please refer to the Troubleshooting
section or the more detailed installation procedures on the User's Guide CDROM. If you need further technical support, please visit www.TRENDNET.com
or call by phone.
Verify Package Contents
Please make sure you have everything in the box:
TEW-603PI
Quick Installation Guide
Version 09.15.2005
Copyright ©2005. All Rights Reserved. TRENDnet.
TEW-603PI
User’s Guide CD-ROM
Verify Equipment
Before installing this PCI Adapter, you should have a:
1. Pentium class desktop computers with at least one available PCI slot
2. Microsoft Windows 2000 or XP
3. CD-ROM drive
Quick Installation Guide
Important! DO NOT install the PCI adapter in the computer until instructed to
do so. Please follow the instructions in Section 2 before installing the adapter
into your computer.
1
English
2. Install Wireless Configuration Utility
Windows 2000/XP
1. Insert the TEW-603PI CD-ROM into your computer's CD-ROM
drive; the installation menu will appear automatically. If the window does not
appear automatically, click Start, click Run, and type E:\Autorun.exe in the
text-field. Click OK to start the installation.
NOTE: Replace “E” in “E:\Autorun.exe” with whichever letter is assigned
to your CD-ROM drive.
2. On the Installation Menu, click Install Utility.
3. Click Next.
2
English
4. Click Next.
5. Click Install.
3
English
6. A warning message will tell you that the device you're installing has not yet
been certified for Windows XP compatibility. Click Continue Anyway. For
Windows 2000, click Yes.
7. Click Finish.
4
English
3. Install Hardware
If you are installing the TEW-603PI Wireless PCI Card:
Proceed only if you have already completed the steps in Section 2
1. Shut down your computer.
2. Open your computer case to reveal the motherboard and expansion slots.
(Please refer to your computer's user manual if you need help opening the
case)
3. Insert the wireless card into one of the motherboard's free PCI slots. Press
down firmly and evenly on the card until it snaps into place.
4. Screw the PCI Card's metal bracket into your case with a standard bracket
screw. Attach the included antenna to the connector on the back of your
card.
5. Close your computer case, and reboot your computer.
5
English
4. Install Drivers
Windows 2000
1. Click Next.
2. Select Search for a suitable driver for my device (recommended) and
click Next.
6
English
