CRT/MK3
CRT/MK3 - SPARE PARTS DIAGRAM v1.0 03/2011
17
16
35
18
19
20
21
31
22
34
23
30
24
25
37
26
32
33
15
14
13
3
4
2
36
50
12
11
41
9
8
58
1
28
29
CRT
65
MK3
43
64
45
63
10
59
57
7
51
44
27
40
42
56
48
46
47
52
53
38
54
39
55
5
6
62
61
60
49
Please use only Trend original spare parts.
CRT/MK3
CRT/MK3 - SPARE PARTS LIST
v1.0 03/2011
No. Qty. Desc. Ref.
1 1 Table Top WP-CRTMK3/01
2 1 Insert Plate WP-CRTMK3/02
3 1 Back Fence WP-CRTMK3/03
4 2 Fence Cheek WP-CRTMK3/04
5 4 Leg WP-CRTMK3/05
6 2 Leg Rail Short WP-CRTMK3/06
7 2 Leg Rail Long WP-CRTMK3/07
8 2 Edge Planing Rod WP-CRTMK3/08
9 2 T-Nut for Edge Planing Knob WP-CRTMK3/09
10 1 No Volt Release Switch 240V NVRS/2/240V
11 2 Spring for Edge Planing Knob WP-CRTMK3/11
12 2 Knob for Edge Planing Assembly WP-CRTMK3/12
13 4 Knob UNC 1/4 - 20 x 3/4” Male for Fence Cheek WP-CRTMK3/13
14 2 Washer 8mm x 23mm x 2mm for Back Fence Knob WP-CRTMK3/14
15 2 Back Fence Knob UNC 5/16 Female WP-CRTMK3/15
16 1 Dust Spout WP-CRTMK3/16
17 2 Machine Screw M4 x 8mm Pozi for Dust Spout WP-CRTMK3/17
18 2 T Bolt UNC 1/4 - 20 x 1- 3/4” for Top Guard WP-CRTMK3/18
19 2 Washer for T Bolt WP-CRTMK3/19
20 1 Top Pressure WP-CRTMK3/20
21 1 Top Guard WP-CRTMK3/21
22 2 Washer Plastic for Top Guard WP-CRTMK3/22
23 2 Knob UNC 1/4 - 20 Female for Plastic Guard WP-CRTMK3/23
24 2 Knob for Side Pressure WP-CRTMK3/24
25 2 Washer 8mm x 23mm x 2mm for Side Pressure Bolt WP-CRTMK3/25
26 1 Side Pressure WP-CRTMK3/26
27 2 Machine Screw for Pushstick Park WP-CRTMK3/27
28 2 Plate for Side Pressure Bolt WP-CRTMK3/28
29 2 Machine Screw Csk 1/4” x 1 9/16” Phillips WP-CRTMK3/29
30 7 Set Screw M6 x 6mm for Fixing Plate WP-CRTMK3/30
31 3 Machine Screw Csk M6 x 15mm Phillips WP-CRTMK3/31
32 1 Insert Ring 31.8mm ID WP-CRTMK3/32
33 1 Insert Ring 67.5mm ID WP-CRTMK3/33
34 4 Machine Screw Csk M5 x 16mm Skt WP-CRTMK3/34
35 1 Lead-on Pin WP-CRTMK3/35
36 7 Magnet 8mm x 5mm WP-CRTMK3/36
37 5 Self Tapping Screw for Mitre Fence Extrusion WP-CRTMK3/37
38 1 Mitre Fence Extrusion WP-CRTMK3/38
39 2 Coach Bolt UNC 5/16 x 2” Male for Back Fence WP-CRTMK3/39
40 2 Switch Bracket WP-CRTMK3/40
CRT/MK3
CRT/MK3 - SPARE PARTS LIST
v1.0 03/2011
No. Qty. Desc. Ref.
41 2 Washer for Edge Planing Assembly WP-CRTMK3/41
42 4 Self Tapping Screw Pan 4mm x 16mm Phillips WP-CRTMK3/42
43 16 Machine Screw Carriage M6 x 10mm for Leg Frame WP-CRTMK3/43
44 16 Nut Hex Flanged M6 for Leg Frame WP-CRTMK3/44
45 8 Self Tapping Screw Pan 4mm x 19mm Phillips WP-CRTMK3/45
46 4 Bench Mounting Bracket WP-CRTMK3/46
47 4 Foot WP-CRTMK3/47
48 4 Self Tapping Screw Pan 4.8mm x 16mm Phillips WP-CRTMK3/48
49 2 Nut for Pushstick Park WP-CRTMK3/49
50 2 Scale Label WP-CRTMK3/50
51 1 Spanner Pressed Steel 10mm A/F WP-CRTMK3/51
52 1 Mitre Fence Knob WP-CRTMK3/52
53 1 Washer for Mitre Fence WP-CRTMK3/53
54 1 Mitre Fence Body WP-CRTMK3/54
55 1 Mitre Fence Rail and Index Head WP-CRTMK3/55
56 2 Cable Management Clip WP-CRTMK3/56
57 4 Self Tapping Screw Pan 4mm x 12mm Phillips WP-CRTMK3/57
58 1 Back Fence Scale WP-CRTMK3/58
59 2 Machine Screw Pan M6 x 16mm Phillips WP-CRTMK3/59
60 1 Mitre Fence Location Pin WP-CRTMK3/60
61 1 Mitre Fence Location Pin Spring WP-CRTMK3/61
62 1 Pushstick PUSHSTICK/1
63 1 Hex Key 3mm A/F WP-AP/03
64 1 Router Screw Fixing Pack Csk FIX/KIT/2
65 1 Manual MANU/CRTMK3
