TBAS1PDBLK
RRP AUS $4,900.00 AUS $4,900.00
Transtherm 'Wine Vault' 267 Bottle Single Zone Bastide
TBAS1PDBLK - Transtherm 'Wine Vault' 267 Bottle Single Zone Bastide
Transtherm
Product Details
TBAS1PDBLK - Transtherm 'Wine Vault' 267 Bottle Single Zone Bastide
Transtherm
Specifications
WINE CELLARS
Domestic Warranty 2
Installation Type Both
Door Style Solid black laminate
door
Door Type Solid door
Door Construction N/A
Handle D shaped handle
Refrigerant No
Easy Capacity (Bottles) 238
Maximum Capacity
(Bottles)
267
Main Function Cellaring Reds & Whites
Alternate Function None
No of Zones 1
Temperature Range Zone
1 (deg)
8-18
Height (mm) 1810
Width (mm) 680
Depth(mm) 680
Depth Door Open (mm) 1140
Air space at sides (mm) 10
Air space above cabinet
(mm)
10
Joinery cut out dimensionminimum height (mm)
1860
Joinery cut out
dimension- minimum width
(mm)
700
Joinery cut out dimensionminimum depth (mm)
730
TBAS1PDBLK - Transtherm 'Wine Vault' 267 Bottle Single Zone Bastide
Transtherm
Specifications
Weight Unloaded 86
Power Supply 240V / 10AMP
Electricity Consumption
(kWh/Day)
0.68
Ambient Temperature
(deg)
0-35
Display Panel LED Digital Display
Castors and Feet 4 ADJUSTABLE FEET
Lock Yes
Alarm None
Lighting No Light
Number of Shelves 4
Shelving Material Wood
Shelving Type 4 adjustable
Shipping Weight (Kg) 102
Pack Dimensions Height
(mm)
1950
Pack Dimension Width
(mm)
760
Pack Dimension Depth
(mm)
730
TBAS1PDBLK - Transtherm 'Wine Vault' 267 Bottle Single Zone Bastide
Transtherm
ELECTROLUX HOME PRODUCTS AUSTRALIA
telephone: 1300 363 640
fax: 1800 350 067
email: customercare@electrolux.com.au
web: www.electrolux.com.au
ELECTROLUX HOME PRODUCTS NEW ZEALAND
telephone: 09 573 2230
fax: 09 573 2221
email: customercare@electrolux.co.nz
web: www.electrolux.co.nz
Terms and Conditions
IMPORTANT
This is a guide of product dimensions only. For complete installation instructions, refer to the manual provided with product.
PRODUCT INFORMATION
The descriptors and illustrations in this publication apply to the specific products and models described as at the date of issue. Under our policy of continuous
productdevelopment, product specifications may change without notice. Prospective purchasers should therefore check with their retailer to ensure this
publication correctly describes theproducts that are being offered for sale. All information supplied is to be used for general reference purposes only and is on the
understanding that Electrolux Home Products PtyLtd (Australia) and Electrolux (NZ) Ltd (New Zealand) will not be liable for any loss, liability or damage of whatever
kind arising as a result of reliance on such information. Colours ofproducts illustrated are as close as printing limitations allow. Electrolux will at all times comply
with its obligations pursuant to law including Trade Practices (Australian Consumer Law) Act and Regulations.
WARRANTY
This warranty only applies to Appliances purchased and used in Australia or New Zealand and used in normal domestic applications and is in addition to (and does
not exclude, restrict, or modify in any way) any non-excludable statutory warranties in Australia or New Zealand. All warranties are subject to the conditions set out in
the warranty card accompanying the product when purchased.
