Transition Networks CSEFE10XX-10X User Manual

User’s Guide

CSEFE10xx-10x

Slide-in-Module Media Converter

• Switchable Ethernet and Fast Ethernet

• 10 Mb/s Copper to Fiber

• 100 Mb/s Copper to Fiber

Transition Networks CSEFE10xx-10x series Ethernet /
Fast Ethernet media converter is designed to be
installed in a Transition Networks PointSystem™
chassis and is a 10Mbps or 100Mbps switch-selectable
media converter.

Both the copper and fiber links operate at the same speed setting via a hard set with
a dip switch, so the media converter operates at either 10 Mb/s copper to fiber or
100 Mb/s copper to fiber.

Part Number Port One - Twisted-Pair

Copper

CSEFE1012-100 RJ-45, 100 m (328 ft)* ST, 1310 nm single mode

CSEFE1014-100 RJ-45, 100 m (328 ft)* SC, 1310 nm single mode

CSEFE1015-100 RJ-45, 100 m (328 ft)* SC, 1310 nm single mode

CSEFE1022-100 RJ-45, 100 m (328 ft)* ST, 1310 nm single mode

CSEFE1029-100 RJ-45, 100 m (328 ft)* SC, 1310 mn (TX)/1550 nm (RX)

CSEFE1029-101 RJ-45, 100 m (328 ft)* SC, 1550 mn (TX)/1310 nm (RX)

The CSEFE10xx-10x media converter is designed to be installed in pairs, where
one is the local media converter and the other is the remote. For example, a local
CSEFE1011-100 converter is connected, via fiber, to a remote CSEFE1011-100
converter.

For a single fiber network, a local CSEFE1029-100 is connected, via fiber, to a
remote CSEFE1029-101 converter.

* Typical maximum cable distance.

Actual distance is dependent upon the
physical characteristics of the network.
(TX) = transmit, (RX) = receive

Port Two - Fiber Optic

duplex fiber, 20 km (12.4 miles)*

duplex fiber, 20 km (12.4 miles)*

duplex fiber, 40 km (24.8 miles)*

duplex fiber, 40 km (24.8 miles)*

single fiber, 20 km (12.4 miles)*

single fiber, 20 km (12.4 miles)*

Installation . . . . . . . . . . . . . . . . . .2

Operation . . . . . . . . . . . . . . . . . . .5

Cable Specifications . . . . . . . . . . .6

Technical Specifications . . . . . . . .8

Troubleshooting . . . . . . . . . . . . . .9

Compliance Information . . . . . . .12

CSEFE10xx-10x

k

Installation

CAUTION: Wear a grounding device and observe electrostatic discharge

precautions when setting the jumper or when installing the media converter.

Failure to observe this caution could result in damage to, and subsequent
failure of, the media converter.

Set the Hardware / Software Jumper

• The hardware/software jumper (J2) is located on
the circuit board.

• Use small needle-nose pliers to move the jumper
to the desired position.

Hardware The media converter mode is determined by

the switch settings (see below).

Software The media converter mode is determined by

the most-recently saved, on-board
microprocessor settings.

The Link Pass-Through and speed switches are located on the side of the
media converter. Use a small screwdriver to set the recessed switches.

Set Link Pass-Through (switch 1)

Link Pass-Through: up = Enable

Switch 1 sets the Link Pass-Through feature:

up = Enable Link Pass-Through.

down = Disable Link Pass-Through.

Link Pass-Through is a troubleshooting feature that allows the media converter
to monitor both the fiber and copper RX (receive) ports for loss of signal. In
the event of a loss of an RX signal on one media port, the media converter will
automatically disable the TX (transmit) signal of the other media port, thus,
“passing through” the link loss. This feature prevents the loss of valuable data
unknowingly transmitted over an invalid link.

H

hardware mode

H

software mode

Speed: up = 100 Mb/s

1 2

Installation -- Continued

Set the Speed (switch 2)

Switch 2 sets the speed for both the twisted-pair
copper and fiber links:

up = copper and fiber links are at 100Mb/s.

down = copper and fiber links are at 10 Mb/s.

J2

S

NOTE: The CSEFE10xx-10x media converters are fully compliant with

10Base-T, 100Base-TX, and 100Base-FX standards and, therefore, can be
connected to any compliant 10Base-T, 100Base-TX, and 100Base-FX devices.

The CSEFE10xx-10x media converters are NOT 10Base-FL compliant and,
therefore, must be connected to another CSEFE10xx-10x media converter in a

J2

S

10Mb/s network.

Install the Slide-In-Module

CAUTION: Slots in the PointSystem™ chassis without a slide-in-module

installed MUST have a protective plate covering the empty slot for Class A
and/or Class B compliance.

To install the CSEFE10xx-10x media converter slide-in-module:

1. Locate an empty installation slot on the PointSystem™ chassis.

2. Carefully slide the slide-in-module into the installation slot, aligning the
module with the installation guides.

3. Ensure that the module is firmly seated against the back of the chassis.

4. Push in and rotate the panel fastener screw (attached to the slide-in­module) to secure the module to the chassis front.

PWR

TX

RX

LNK

R
E
S
E

I

0

I

0

T

10BASE-T

SERIAL

CPSMM120

INIT

TERM

LKS

LKM

TX

Singlemode

RX

TX

Multimode

RX

CFMFF100

PWR

Link Pass-Through: up = Enable

Speed: up = 100 Mb/s

1 2

PWR

LKS

LKM

TX

Singlemode

PWR

RX

100ACT

10

TX

SX

Multimode

TX

RX

CFMFF100

LA

RXF

RXC

10BASE-FL

10BASE-2

Link Alert

E

0

CETCF100

PWR

PWR

LKS

LNK

LKM

COL

TX

Singlemode

D

RX

TX

Multimode

50½

RX

CFMFF100

SPD

FRX

CRX

TX
100BASE-FX

RX

100BASE-TX

CFETF100

PWR

FLNK

CLNK

Near-End

Device

original fault

on the copper link

2

media converter A

disables the fiber TX link

2

1

Media

Converter A

media converter B

loses the fiber RX link

3

Media

Converter B

Far-End

Device

4

media converter B

disables the copper lin

24-Hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600

panel fastener screw

Power the Media Converter

The CSEFE10xx-10x slide-in-module is powered through the Transition
Networks PointSystem™ chassis.

[e-mail] -- Click the “Transition Now” link for a live Web chat

3

CSEFE10xx-10x

Installation -- Continued

Install the Fiber Cable

The CSEFE10xx-10x is designed to be installed in pairs over the fiber link,
where one is the local media converter and the other is the remote.

1. Locate or build fiber-optic cable with male, two-stranded TX to RX
connectors installed at both ends.

2. Connect the fiber cables to the local CSEFE10xx-10x media converter as
described:

• Connect the male TX cable connector the female TX port.

• Connect the male RX cable connector to the female RX port.

3. Connect the fiber cables to the remote CSEFE10xx-10x media converter
as described:

• Connect the male TX cable connector the female RX port.

• Connect the male RX cable connector to the female TX port.

Connect the fiber cable
to the local media
converter as shown.

RX

TX

Install the Copper Cable

NOTE: The MDI (straight-through) or MDI-X (crossover) cable connection is

configured automatically, according to the network conditions.

1. Locate or build 10/100Base-TX copper cables with male, RJ-45
connectors installed at both ends.

2. Connect the RJ-45 connector at one end of the cable to the RJ-45 port on
the CSEFE10xx-10x media converter.

3. Connect the RJ-45 connector at the other end of the cable to the RJ-45
port on the other device (switch, workstation, etc.).

Connect the fiber cable

to the remote media

converter as shown

RX

TX

Operation

Status LEDs

Use the status LEDs to monitor the CSEFE10xx-10x media
converter operation in the network.

PWR Power On = Connection to the external AC

or DC power.

F-ACT Fiber Activity Blinking = Data reception on the fiber

link.

F-100 Fiber Speed On = Fiber link at 100 Mb/s.

F-10 Fiber Speed On = Fiber link at 10 Mb/s.

TP-ACT Copper Activity Blinking = Data reception on the

twisted-pair copper link.

TP-100 Copper Speed On = Copper link at 100 Mb/s.

TP-10 Copper Speed On = Copper link at 10 Mb/s.

AutoCross™

The AutoCross feature allows either straight-through (MDI) or crossover (MDI-X)
cables to be used when connecting to devices, such as hubs, transceivers, or
network interface cards (NICs). AutoCross determines the characteristics of the
cable connection and automatically configures the unit to link up, regardless of
the cable configuration.

NOTE: The CSEFE10xx-10x series media converter does NOT support rate
conversion between 10Mb/s and 100Mb/s network devices.

100ACT

F

TP

TX

CSEFE100

10

PWR

4

RJ-45 port

on the media

converter

24-Hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600

RJ-45 port

on the other device

(switch, work station, etc.)

[e-mail] -- Click the “Transition Now” link for a live Web chat

5

CSEFE10xx-10x

Operation -- Continued

SNMP

Use SNMP at an attached terminal or at a remote location to monitor the
media converter by monitoring:

• Media converter power

• Copper link status

• Fiber link status

• Copper receive status

• Fiber receive status

• Link Pass-Through status

• Media converter speed

Also, use SNMP to enter network commands that:

• Enable/disable Link Pass-Through

• Set the speed to 100 Mb/s or 10 Mb/s

• Power down the media converter

See the on-line documentation that comes with Transition Networks
FocalPoint™ software for applicable commands and usage.

Cable Specifications

Copper Cable

Category 3: (Minimum requirement for 10 Mb/s operation)

Gauge 24 to 22 AWG
Attenuation 11.5 dB/100m @ 5-10 MHz

Category 5: (Minimum requirement for 100 Mb/s operation)

Gauge 24 to 22 AWG
Attenuation 22.0 dB /100m @ 100 MHz

• Straight-through or crossover copper cable may be used.

• Shielded (STP) or unshielded (UTP) twisted-pair cable may be used.

• Pins 1&2 and 3&6 are the two active pairs in an Ethernet network .

• RJ-45 Pin-out: Pin 1 = TD+, Pin 2 = TD-, Pin 3 = RD+, Pin 6 = RD-

• Use only dedicated wire pairs for the active pins:

(e.g., blue/white & white/blue, orange/white & white/orange, etc.)

• Do not use flat or silver satin wire.

Crossover Cable

1
2

3

6

Twisted Pair #1

Twisted Pair #2

Straight-Through Cable

1
2

3
6

1
2

3
6

Twisted Pair #1

Twisted Pair #2

Cable Specifications

The physical characteristics must meet or exceed IEEE 802.3™ specifications.

Fiber Cable

Bit Error Rate: <10
Single mode: 9 µm

CSEFE1012-100 1310 nm single mode
Fiber-optic Transmitter Power: min: -15.0 dBm max: -8.0 dBm
Fiber-optic Receiver Sensitivity: min: -32.0 dBm max: -5.0 dBm
Link Budget: 17.0 dB

CSEFE1014-100 1310 nm single mode
Fiber-optic Transmitter Power: min: -15.0 dBm max: -8.0 dBm
Fiber-optic Receiver Sensitivity: min: -32.0 dBm max: -5.0 dBm
Link Budget: 17.0 dB

CSEFE1015-100 1310 nm single mode
Fiber Optic Transmitter Power: min: -8.0 dBm max: -2.0 dBm
Fiber Optic Receiver Sensitivity: min: -34.0 dBm max: -5.0 dBm
Link Budget: 26.0 dB

CSEFE1022-100 1310 nm single mode
Fiber Optic Transmitter Power: min: -8.0 dBm max: -2.0 dBm
Fiber Optic Receiver Sensitivity: min: -34.0 dBm max: -5.0 dBm
Link Budget: 26.0 dB

CSEFE1029-100 1310 nm (TX)/1550 nm (RX) simplex
Fiber-optic Transmitter Power: min: -14.0 dBm max: -8.0 dBm
Fiber-optic Receiver Sensitivity: min: -33.0 dBm max: -3.0 dBm
Link Budget: 19.0 dB

CSEFE1029-101 1550 nm (TX)/1310 nm (RX) simplex
Fiber-optic Transmitter Power: min: -14.0 dBm max: -8.0 dBm
Fiber-optic Receiver Sensitivity: min: -33.0 dBm max: -3.0 dBm
Link Budget: 19.0 dB

The fiber optic transmitters on this device meet Class I Laser safety
requirements per IEC-825/CDRH standards and comply with 21
CFR1040.10 and 21CFR1040.11.

1
2

3
6

-9

6

24-Hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600

[e-mail] -- Click the “Transition Now” link for a live Web chat

7

CSEFE10xx-10x

Technical Specifications

For use with Transition Networks Model CSEFE10xx-10x or equivalent.

Standards: IEEE 802.3™, 10Base-T, 100Base-TX, 100Base-FX

Data Rate: 10 Mb/s, 100 Mb/s

Dimensions: 3.4" x 0.87" x 5" (86 mm x 22 mm x 182 mm)

Weight: 3 oz (91 g) (approximate)

Power Consumption: 3.6 watts

Environment: Tmra*: 0° to 50°C (32° to 122°F)

Storage Temperature: -20° to 85°C (-4° to 185°F)
Humidity: 5 to 95%, non condensing
Altitude: 0 to 10,000 feet

Warranty: Lifetime

*Manufacturer’s rated ambient temperature: Tmra range for this slide-in-module
depends on the physical characteristics and the installation configuration of the
Transition Networks PointSystem™ chassis in which this slide-in-module will be
installed.

NOTE: The information in this user’s guide is subject to change. For the most
up-to-date information on the CSEFE10xx-10x media converter, view the user’s
guide on-line at: www.transition.com.

The stand alone version of the media converter is the SSEFE10xx-10x model. For
more information, see the SSEFE10xx-10x user’s guide on-line at:
www.transition.com.

Product is certified by the manufacturer to comply with DHHS Rule 21/CFR,
Subchapter J applicable at the date of manufacture.

CAUTION: Visible and invisible laser radiation when open. Do not stare into
beam or view directly with optical instruments.

CAUTION: Use of controls, adjustments or the performance of procedures other
than those specified herein may result in hazardous radiation exposure.

Troubleshooting

1. Is the PWR LED on the media converter illuminated?
NO

• Is the media converter inserted properly into the chassis?

• Is the power cord properly installed in the chassis and in the

grounded AC outlet?

• Does the grounded AC outlet provide power?

• Contact Tech Support: 1-800-260-1312, Int’l: 00-1-952-941-7600.

YES

• Go to step 2.

2. Is the F-ACT LED illuminated?
NO

• Check the fiber cables for proper connection.

• Verify that the TX and RX cables on the media converter are

connected to the RX and TX ports, respectively, on the other media
converter.

• Contact Tech Support: 1-800-260-1312, Int’l: 00-1-952-941-7600.

YES

• Go to step 3.

3. Is the F-ACT LED blinking?
NO

• If there is no activity on the fiber port, go to step 4.

• If there is activity on the fiber port, disconnect and reconnect the

fiber cable to restart the initialization process.

• Restart the workstation to restart the initialization process.

• Contact Tech Support: 1-800-260-1312, Int’l: 00-1-952-941-7600.

YES

• Go to step 4.

4. Are the F-100 and/or the TP-100 LEDs illuminated?
YES

• The media converter is set to 100Mb/s for both the copper fiber links.

If this is not the correct speed, carefully remove the media converter
from the chassis and set switch 1 to “down” (speed = 10 Mb/s).

• Contact Tech Support: 1-800-260-1312, Int’l: 00-1-952-941-7600.

NO

• Go to step 5.

5. Are the F-10 and/or the TP-10 LEDs illuminated?
YES

• The media converter is set to 10 Mb/s for the copper and fiber links.

If this is not the correct speed, carefully remove the media converter
from the chassis and set switch 2 to “up” (speed = 100 Mb/s).

• Contact Tech Support: 1-800-260-1312, Int’l: 00-1-952-941-7600.

NO

• Go to step 6.

8

24-Hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600

[e-mail] -- Click the “Transition Now” link for a live Web chat

9

CSEFE10xx-10x

Troubleshooting -- Continued

6. Is the TP-ACT LED illuminated?
NO

• Check the twisted-pair copper cables for proper connection.

• Contact Tech Support: 1-800-260-1312, Int’l: 00-1-952-941-7600.

YES

• Go to step 7.

7. Is the TP-ACT LED blinking?
NO

• If there is activity on the copper port, disconnect and reconnect the

copper cable to restart the initialization process.

• Restart the workstation to restart the initialization process.

• Contact Tech Support: 1-800-260-1312, Int’l: 00-1-952-941-7600.

Contact Us

Technical Support

Technical support is available 24 hours a day.
US and Canada: 1-800-260-1312
International: 00-1-952-941-7600

Transition Now

Chat live via the Web with Transition Networks Technical Support.
Log onto www.transition.com and click the Transition Now link.

Web-Based Seminars

Transition Networks provides seminars via live web-based training.
Log onto www.transition.com and click the Learning Center link.

E-Mail

Ask a question anytime by sending an e-mail to our technical support staff.

[e-mail]

Address

Transition Networks
6475 City West Parkway
Minneapolis, MN 55344, USA
telephone: [phone]
toll free: 800-526-9267
fax: [phone]

10

24-Hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600

Declaration of Conformity

Name of Mfg: Transition Networks

Model: CSEFE10xx-10x Series Media Converters
Part Number(s): CSEFE1012-100, CSEFE1014-100, CSEFE1015-100,

Regulation: EMC Directive 89/336/EEC

Purpose: To declare that the

conformity with the following standards.

CISPR 22: 1993; EN55022:1998 Class A ; FCCPart 15 Subpart B; EN 55024:1998;

EN 61000-3-2: 1995; EN 61000-3-3:1995; 21 CFR Subpart J

I, the undersigned, hereby declare that the equipment specified above conforms to the above

Directive(s) and Standard(s).

Stephen Anderson, Vice-President of Engineering Date

[e-mail] -- Click the “Transition Now” link for a live Web chat

6475 City West Parkway, Minneapolis MN 55344 USA

CSEFE1022-100, CSEFE1029-100, CSEFE1029-101

CSEFE10xx-10x

to which this declaration refers is in

_December 6, 2004_____

11

Compliance Information

CISPR22/EN55022 Class A + EN55024
CE Mark

FCC Regulations

This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference, in which case the user will be required to correct the
interference at the user's own expense.

Canadian Regulations

This digital apparatus does not exceed the Class A limits for radio noise for digital apparatus
set out on the radio interference regulations of the Canadian Department of Communications.
Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites
applicables aux appareils numériques de la Class A prescrites dans le Règlement sur le
brouillage radioélectrique édicté par le ministère des Communications du Canada.

European Regulations

Warning This is a Class A product. In a domestic environment this product may cause radio

interference in which case the user may be required to take adequate measures.

Achtung! Dieses ist ein Gerät der Funkstörgrenzwertklasse A. In Wohnbereichen können
bei Betrieb dieses Gerätes Rundfunkstörungen auftreten. In diesem Fäll ist der Benutzer für
Gegenmaßnahmen verantwortlich.

Attention! Ceci est un produit de Classe A. Dans un environment domestique, ce produit
risque de créer des interférences radioélectriques, il appartiendra alors à l'utilsateur de
prende les measures spécifiques appropriées.

CAUTION: RJ connectors are NOT INTENDED FOR CONNECTION TO THE
PUBLIC TELEPHONE NETWORK. Failure to observe this caution could result in
damage to the public telephone network.

Der Anschluss dieses Gerätes an ein öffentlickes Telekommunikationsnetz in den EG­Mitgliedstaaten verstösst gegen die jeweligen einzelstaatlichen Gesetze zur Anwendung der
Richtlinie 91/263/EWG zur Angleichung der Rechtsvorschriften der Mitgliedstaaten über
Telekommunikationsendeinrichtungen einschliesslich der gegenseitigen Anerkennung ihrer
Konformität.

Trademark Notice

All trademarks and registered trademarks are the property of their respective owners.

Copyright Restrictions

© 2005 Transition Networks.
All rights reserved. No part of this work may be reproduced or used in any form or by any
means - graphic, electronic, or mechanical - without written permission from Transition
Networks.

Printed in the U.S.A.

33317.A
