Instruction Manual

Ionizing Air Gun

Model BFNG10

Contents

1 Description

BFNG10 1

Safety 2
Specifications 2

2 Operation and Use

Environmental Conditions 2

Set-up and Placement 2
Mounting 3
Power and Gas Connection 3

3 Maintenance

Periodic Maintenance 4
Cleaning Emitter Points 4
Emitter Point Replacement 5
Service 6
Troubleshooting 6

4 Specifications 7
5 Assembly and

Mounting Instructions 8

6 Service and Warranty 12

7 BFNG10 Line Drawing 13

Description

Ionizing Air Gun Model BFNG10

The BFNG10 is a high performance ESD ionizing gun perfect for a
wide variety of industrial applications. The BFNG10 ionizing gun com­bines portability, fast static decay rates, excellent balance and low com­pressed air consumption to efficiently remove static and contaminates in
the Semiconductor, Electronic Assembly, Medical Device, Optics, Auto-

motive and Pharmaceutical markets.

About BFN Technology

Dependable, Balanced and Fast. BFN® AC ionizers, from Transforming
Technologies, are built to last. Reliable AC ionization technology is com­bined with superior mechanical design to assure years of optimal static

neutralizing performance.

• A full 1 year warranty.

• High Frequency AC (68KHz) Ion Emission

• Titanium alloy emitter points for long life.

All BFN series AC ionizing blowers are designed for safe operation un-

der normal use.

Safety:

• Do not use BFN ionizers in flammable or explosive environments.

• Do not insert foreign objects into the air inlet or outlet.

• Make certain the BFN ionizer is properly grounded before operation.

• Do not open or attempt to repair any BFN series product. Breaking

the manufacturing seal will void warranty.

• Do not allow water to enter the gun. Do not operated in high humidi-

ty, or wet areas. This can cause damage to the internal circuits of

the ionizer

• Power off unit before maintenance and cleaning. Wait until fully dry

to power on again if using alcohol to clean.

1
