T.sonic™ 615
User’s Manual
Table of Contents
Introduction︱......................................................................................... 5
Package Contents︱............................................................................... 5
Features︱............................................................................................... 6
System Requirements︱ ........................................................................ 6
Safety Precautions︱ ............................................................................. 6
Player Controls︱ ................................................................................... 8
Music Playback Screen︱ ...................................................................... 9
Basic Operation︱ ................................................................................ 11
MUSIC Mode︱...................................................................................... 14
RADIO Mode︱...................................................................................... 15
2
RECORD Mode︱.................................................................................. 17
Settings︱.............................................................................................. 19
User EQ Customization...............................................................................................................19
Record Quality ............................................................................................................................21
VAD (Voice Activity Detection)....................................................................................................22
Set Date / Time ...........................................................................................................................24
Time Zone ...................................................................................................................................25
Daylight Saving Time (DST)........................................................................................................25
Driver Installation︱ ............................................................................. 28
Connecting to a Computer︱............................................................... 29
T.sonic™ Utility Software︱ ................................................................ 32
Log In / Log Out...............................................................................................................38
Changing your Password................................................................................................39
Forgotten Passwords ......................................................................................................40
3
Troubleshooting︱ ............................................................................... 41
Specifications︱ ................................................................................... 43
Ordering Information︱........................................................................ 43
Transcend Limited Warranty︱ ........................................................... 44
4
Introduction︱
Thank you for purchasing Transcend’s T.sonic™ 615, a next-generation MP3 Player that
combines all the advantages of lightweight portable music with the benefits of a USB flash drive,
and includes many extra features such as an FM radio, digital voice recording, karaoke-style lyrics
display, A-B repeat functions and variable track playback speeds. Your T.sonic 615 is equipped with a high-speed USB 2.0 interface to transfer data and music files to and from your computer
quickly and easily. The A-B repeat and variable track playback speed features allows you to
continuously replay specific sections of an audio file at slower or faster speeds – ideal for learning foreign languages and reviewing an important part of a song or recording. In addition, you can
make personal memos and record meetings or class lectures using the digital voice recorder with
the built-in microphone. The stylish T.sonic 615 from Transcend will change the way you think about digital music forever.
Package Contents︱
The T.sonic 615 package includes the following items:
T.sonic™ 615
Earphones
USB cable
Software CD
5
Quick Start Guide
Features︱
MP3 Player – supports MP3, WMA, WMA-DRM10 (subscription music) and WAV music formats
Recordable FM Radio with 20 station presets
Advanced Digital Voice Recorder
Karaoke-style lyrics display
Vivid dual-color OLED screen displays clear text at any angle and in any light
VAD (Voice Activity Detection) for high quality gapless audio recordings
A-B repeat function allows you to continuously replay a designated section of a track
Variable track playback speeds
Supports 13 languages including menus, song/album title, artist name and lyrics
USB flash drive capabilities for data transfer and storage
Included software can be used to lock your computer and password-protect your files
7 Equalizer effects, including a customizable USER EQ setting
Internal rechargeable Li-ion battery provides over 15 hours of continuous music playback*
High-speed mini USB 2.0 port for easy computer connectivity and fast file transfers
Real Time Clock displays local and world times
* Max. playback time achieved with screen saver set to “Blank” and “Lyrics Sync” disabled.
System Requirements︱
A desktop or notebook computer with a working USB port
One of following operating systems:
• Windows
• Windows
• Windows
• Windows Vista
• Mac
• Linux
®
Me
®
2000
®
XP
™
™
OS 10.0, or later
™
Kernel 2.4, or later
Safety Precautions︱
These usage and safety guidelines are IMPORTANT! Please follow them carefully.
General Use
• Unpack the contents of the T.sonic package carefully.
• Do not allow your T.sonic to get wet or come in contact with water or any other liquids.
6
• Do not use a damp/wet cloth to wipe the exterior case.
• Do not use or store your T.sonic in any of the following environments:
o Direct sunlight o Next to an air conditioner, electric heater or other heat sources o In a closed car that is in direct sunlight
Backing Up Data
Transcend does NOT take any responsibility for data loss or damage during operation. If
you decide to store data on your T.sonic, we strongly advise that you regularly backup the data to a computer or other storage medium.
To ensure Hi-Speed USB 2.0 data transfer rates when connecting to a computer, please ensure
the computer has the necessary USB drivers. If you are unsure how to check this, please consult your computer or motherboard’s User’s Manual for USB driver information.
Caution: Risk of Deafness
• Repeated or regular use of headphones or earphones at volume levels above 80 decibels can give a false impression that the audio level is not high enough. Users may try to
progressively increase the volume control, therefore risking a dangerous noise level for
their ears.
• To protect your health and your hearing, keep the volume of your MP3 player below 80
decibels and do not use for an extended period of time. Stop use if symptoms like
headaches, nausea, or hearing disorders occur.
• Your MP3 player is limited to a volume level of 100 decibels.
• Both the MP3 player and its accompanying earphones are compliant with the French
regulation concerning musical Walkmans (24th July 1998 Order).
• Before using any other earphones, confirm that their technical specifications are
compatible with the original set.
Reminders
• Make sure the switch is not enabled before turning on the player.
• Never use the “Quick Format” or “Full Format” functions in Windows
615.
• Follow the procedures in the “Disconnecting from a Computer” section to properly
remove your T.sonic 615 from a computer.
• Transcend occasionally releases firmware updates for certain products. We suggest you
visit http://www.transcendusa.com and download the latest firmware version for your
device.
®
to format your T.sonic
7
Player Controls︱
Figure 1. T.sonic 615
A Hi-Speed mini USB 2.0 Connector B Microphone C Dual-Color OLED Display D E
F G H
I
Play / Pause / Power Volume Up Previous / Rewind Volume Down Next / Fast-Forward Headphone Jack
J Lanyard Attachment Loop K
L
M
N
O
Hold Switch Record Menu Button A-B Repeat Reset Button
8
Music Playback Screen︱
Figure 2. OLED Display
ICON INDICATION
A Record Source
Built-in Microphone
FM Radio
B VAD Indicates Voice Activity Detection is enabled C Record Quality
Low Quality Medium Quality High Quality
D
Sleep Indicates the Sleep Timer is enabled
E EQ Mode
(Blank)
Normal Pop Rock Classical Jazz Bass
(Blank)
F Repeat Mode
Normal
G Play Speed H
Graphic EQ Displays real-time graphic equalizer visualization during playback.
I
Lock Indicates the Hold switch is enabled (controls are locked)
J
Battery Indicates the battery power level
K
Album / Artist / Lyrics Displays album title, artist name, or lyrics
(Blank)
1.00x 1.33x
Repeat
One
Repeat
All
Shuffle
Normal in
Folder
Repeat in
Folder
Shuffle in
1.14x
0.80x 0.67x
Folder
USER
A-B
Repeat
L
Song Title / Lyrics Displays song title, file name, or lyrics
M
Date Displays today’s date and day of the week
N
Time Displays the current time
O
Track Info Indicates current track number and playtime statistics
P Play Status
Play Pause Stop Rewind Fast-Forward Record
9
Q Text Display Mode
Album Title Artist Name Song Lyrics
10
Basic Operation︱
The T.sonic 615 needs to be charged for at least 12 hours before first use.
Charging the Battery
Plug the small end of the USB cable into the Mini USB port on the T.sonic, and plug the large end of
the cable into an available USB port on your desktop or notebook computer. The T.sonic 615’s internal Li-ion battery will begin charging.
Figure 3. Connecting to a Computer
Power ON
Press and hold the button to turn on the player. An animated Transcend logo will appear on
the screen. After the startup screen disappears, the Main Menu will appear. You can now start using the T.sonic 615. The Main Menu will appear.
• It takes a few seconds for the T.sonic to power up.
• If the Lock icon
the
power on the player.
appears on the display while powering on the T.sonic, this means that
switch is enabled. You must switch off the Hold mode before you can
Power OFF
Press and hold the button to turn off the T.sonic 615.
• It takes a few seconds to completely power down.
• The power OFF animation will be displayed:
11
Pla y a Song
Press to play the currently selected MP3, WMA, or WAV track.
Pause a Song
Press to pause and un-pause a track during playback.
Next Track
Press to skip to the next available song.
Previous Track
Press
to go back to the previous song.
Fast Forward
Press and hold the button to fast-forward.
Rewind
Press and hold the
button to rewind.
Increase Volume
Press once or press and hold the
button until you reach the desired volume level.
Decrease Volume
Press once or press and hold the
button until you reach the desired volume level.
Main Menu
Press in any mode to bring up the Main Menu. The Main Menu gives you access to the
MUSIC, RADIO, RECORD modes and the SETTINGS menu.
Voice Recording
The T.sonic 615 records using its built-in microphone located near the
1. Press and hold the
mode) to activate the T.sonic 615’s built-in microphone and begin recording.
button for 2 seconds in any mode (except the FM Radio
12
button.
2. Press and hold
3. Recorded audio files can be found in the Record mode.
for 2 seconds again to finish the recording.
A-B Repeat
1. While listening to a song or recording in the Music or Record modes, press the
button once to mark the beginning of the portion you wish to repeat.
2. Press the
3. The marked section of the track will playback the marked A-B section in a continuous loop.
4. Press the
button again to mark the end of the section you wish to repeat.
button once more to stop the A-B repeat function.
Hold
When the switch is enabled, all of the T.sonic 615’s buttons will be disabled, and
cannot accidentally be pressed while in your pocket.
Reset
If the T.sonic is not functioning properly, you can reboot by pressing
for 3 to 5 seconds.
13
MUSIC Mode︱
Before buying DRM (Digital Rights Management) protected music online, please be advised that the T.sonic 615 only supports WMA-DRM10 file
Playing MP3, WMA, or WMA-DRM10 Music
1. Press and hold the
¾ If the T.sonic is already on, press the
button to power ON the T.sonic. The Main Menu will appear.
button to enter the Main Menu.
2. Use the and buttons to select the “MP3” icon and press to confirm.
The player will automatically find available music files.
3. Select the song you want to listen to with the Navigator.
¾ If T.sonic cannot find any MP3, WMA, or DRM10 files, a “No Music Files” message
will appear.
¾ WAV files can only be played in the Record mode.
and buttons or use the File
4. Press the button to play the music file.
¾ T.sonic 615 supports Mpeg I Layer 3 and WMA files compressed at between
32Kbps – 320Kbps.
File Navigator
The File Navigator is a fast and convenient way of moving between tracks, files and folders.
1. In the MUSIC mode, press and hold the
button to enter the File Navigator.
2. A list of files or folders will appear. Use the and buttons to move up and down the
list.
3. Press
4. Press
5. To exit, press and hold
or to play the highlighted song or to enter the selected folder.
select the
or
icon and press to move up one folder level.
.
Deleting Music Files
1. In the MUSIC mode, press and hold
to enter the File Navigator.
14
Loading...
+ 30 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
