8GB USB2.0 JetFlash
™
Description
TS8GJF160 is a 8GB USB Flash Drive with 1 pcs of
8Gx8 Flash (or 2 pcs of 4Gx8) Memory assembled on a
printed circuit board.
Outline
Features
•
Color: Gray
•
USB 2.0 compatible, true Plug and Play
•
Powered directly via the USB port. No external power or
battery needed
•
LED indicates the usage status of JetFlash™
•
JetFlash elite software pack includes (Windows
2000/XP/Vista/Windows 7 only):
Favorites Function: store all your favorite website addresses on
the JetFlash™
AutoLogin Function: automatically login to websites where you
have a password
Secret-Zip Function: compress and/or password protect saved
files using 256-bit AES encryption
PC-Lock Function: makes JetFlash™ a key to your computer
E-Mail Function: use your JetFlash™ to securely send, receive
and save e-mails
DataBackup Function: backup, restore and synchronize your
data
System Requirement
Hardware: Desktop or notebook computer with USB
•
port
• Operating System: Windows® 2000 SP4, Windows® XP SP2
Windows® Vista, Windows® 7
Linux™ Kernel 2.4.2 or later
Dimensions
Side Millimeters Inches
A 61 ± 1.00 2.40 ± 0.04
B 18.6 ± 1.00 0.73 ± 0.04
C 9.8 ± 1.00 0.39 ± 0.04
and Mac™ OS 9.0 or later,
,
Transcend Information Inc.
1
T
USB Flash
Drive
Controller
USB+
/WE
S
8
S
S
8
8
G
G
G
T
T
Block Diagram
J
J
J
F
F
F
1
1
1
6
6
6
0
0
0
8GB USB2.0 JetFlash
™
D0_0~D0_7
/CE0,/CE2
Other
USB-
4Pins Connecter
D0_0~D0_7
/CE4,/CE6
D0~D7
/CE0
/CE2
/WE
/RE
D0~D7
/CE4
/CE6
/RE
Flash
Memory
8Gx8
or
Flash
Memory
4Gx8
Flash
Memory
4Gx8
Transcend Information Inc.
2
T
S
8
G
J
F
T
S
8
S
8
G
G
T
J
J
F
F
1
1
1
6
6
6
0
0
0
8GB USB2.0 JetFlash
™
Pinouts
Pin No. Pin Name
01 VCC
02 USB-
03 USB+
04 VSS
Specifications
Storage Capacity
Data Retention
Erase Cycles
Connector Durability
System Performance
Power Supply
Pin Identification
Symbol Function
USB-
USB+
VSS
VCC
8GB
10 years
>100,000 times
10,000 times
Read: 30MB/sec (max.), Write: 25MB/sec (max.)
DC 5V±10%, Max current : 200 mA
USB differential signal:
The pairs are used to transmit
Data/Address/Command
Ground
USB power input
Temperature Range
Weight
Certificates
Above technical information is based on industry standard data and tested to be reliable. However, Transcend makes no
warranty, either expressed or implied, as to its accuracy and assumes no liability in connection with the use of this product.
Transcend reserves the right to make changes in specifications at any time without prior notice.
Operation: 0-70oC, Storage: -20oC-75oC
10g
CE, FCC, BSMI
Transcend Information Inc.
