Traceable DIGI-SENSE 90205-25 Manual

SPECIFICATIONS:

Display: ¼” LCD
Range: –58.0 to 536.0°F (–50.0 to 280.0°C)
Accuracy: Cat. No. 4149— ±1°C –20 to 100°C

Cat. No. 4349— ±0.4°C –20.0 to

100.0°C at tested points, ±1° otherwise

Resolution: 0.1° above –20.0° and below 200.0°

1.0° below –20.0° and above 200.0°
Sampling

Rate: 1 second

Features: Protective sleeve with pocket clip, 8”

stain-less steel probe, 180 degree rotat­ing digital display, extra-wide tempera­ture range.

CONTROLS/INDICATORS

°F/°C button and ON/OFF button.

ULTRA™ THERMOMETER ACCURACY

Ultra™ thermometers are tested at selected test
points to be within tighter than normal tolerances to
assist in providing improved accuracy. Other points
will not necessarily fall within the same accuracy
as those found at the selected test points, but will
be within an accuracy of ±1° between –20.0 and

100.0°C.

OPERATION

1. Press the “ON/OFF” button to turn the ther­mometer on.

2. Press the “°F/°C” button to toggle between

displaying the temperature in Fahrenheit and in
Celsius.

3. Remove the thermometer from the protective
plastic sleeve and insert the probe into the
material to be measured.

4. The head of the thermometer rotates 180
degrees in order to read the display at various
angles.

5. Press the ON/OFF button to turn the unit off.

ALL OPERATIONAL DIFFICULTIES

If this unit does not function properly for any
reason, replace the battery with a new high-quality
battery (see “Battery Replacement” section). Low
battery power can occasionally cause any number

of “apparent” operational difculties. Replacing

the battery with a new fresh battery will solve most

difculties.

BATTERY REPLACEMENT

Erratic readings, a faint display, or no display are
all indicators that the battery must be replaced.
Remove the battery cap by turning ¼ turn counter
clockwise. Replace exhausted battery with a new

1.5 volt battery. Make certain that positive (+) side
is face up. Replace battery cap. Do not overtight­en the cap. Replacement battery Cat. No. 1039.

WARRANTY, SERVICE, OR RECALIBRATION

For warranty, service, or recalibration, contact:

CONTROL COMPANY

Control Company is ISO 9001:2008 Quality-Certi ied

by DNV and ISO/IEC 17025:2005 accredited as a

Calibration Laboratory by A2LA.

5 Commonwealth Ave
Woburn, MA 01801

TestEquipmentDepot.com

Control Company Cat. No. 4149 / 4349

Traceable® and Ultra™ are registered trademarks/trademarks

of Control Company.

©2016 Control Company. 92-4149-00 Rev. 5 061416

TRACEABLE

ROBO

®

™

THERMOMETER

INSTRUCTIONS
