Business Cloud SDN Solution
Omada EAP - Business Wi-Fi Series:
EAP660 HD / EAP620 HD / EAP265 HD / EAP245 / EAP225 / EAP115 / EAP110 /
EAP235-Wall / EAP230-Wall / EAP225-Wall / EAP115-Wall /
EAP225-Outdoor / EAP110-Outdoor
EAP660 HD
EAP620 HD
EAP265 HD
EAP245 / EAP225
EAP115 / EAP110
EAP225-Outdoor
EAP110-Outdoor
EAP230-Wall
EAP115-Wall
Omada SDN Controller
EAP235-Wall
EAP225-Wall
Omada Solution
Software Dened Networking (SDN) with Cloud Access
Omada Software Dened Networking (SDN) platform integrates network devices, including access points,
switches and gateways, providing 100% centralized cloud management. Omada creates a highly scalable
network——all controlled from a single interface. Seamless wireless and wired connections are provided, ideal
for use in hospitality, education, retail, oces, and more.
Hassle-Free Centralized Cloud Management
100% centralized cloud management of the whole network from dierent sites——all controlled from a single
interface anywhere, anytime.
1
Zero-Touch Provisioning for Ecient Deplyment
Omada zero-touch provisioning allows remotely deployment and conguration of multi-site networks, so there's
no need to send out an engineer for on-site conguration. The Omada Cloud ensures ecient deployment with
lower costs.
1. Zero-Touch Provisioning is supported when using Omada-Cloud Based Controller
AI-Driven Technology for Stronger Performance and Easy Network Maintenance
Assign Different Management Roles
user privilege assignment is available to increase management efficiency and security. Multi-person
Multimanagement, multi-level permissions, and the ability to add admins as needed, enable exible network
operation and maintenance.
Easy and Intelligent Network Monitoring
The easy-to-use dashboard makes it easy to see your real-time network status; check network usage and
trac distribution; receive network condition logs, abnormal event warnings, and notications; or even track key
data for better business results. Network topology helps IP admins quickly see and troubleshoot connection at
a glance.
Comprehensive Protection for the Whole Network
Multiple Factors Guarantee Higher Reliability
Higher reliability of cloud service is guaranteed with 99.99% SLA availability, 24/7 automated fault detection,
geographically isolated backup servers, and reliable product quality. Your network functions even if
management trac is interrupted.
Reliable Connections Even with High-Density Clients
Equipped with enterprise chipsets, dedicated antennas, advanced RF functions, auto channel selection,
and power adjustment, Omada Wi-Fi 6 and Wi-Fi 5 APs have high concurrency capacities for remarkable
performance in high-density environments.
EAP Product Features
Easy-Mount Design
The Ceiling Mount EAP's elegant appearance and easy-mount design promote fast installation on any
wall or ceiling surface, and allow it to blend in seamlessly with most interior decorating styles. The slimline,
inconspicuous Wall Plate EAP can be easily installed into any standard EU/US wall junction box or 86 mm wall
junction box.
PoE Power Supply
With IEEE 802.3af/at PoE or Passive PoE, you can use Ethernet cables to transfer both electrical power and
network data, making deployment more exible and removing the need to install additional power cabling.
Business-Class Hardware Design
Enterprise-class chipsets oer outstanding performance and support longer running time, higher client
capacity and greater range. Dedicated high-power ampliers, specialized antennas and professionally designed
RF shields ensure excellent wireless performance.
1
Seamless Roaming
802.11k and 802.11v seamless roaming provide seamless switching to the access point with optimal signal
when moving between APs.
2
Mesh
Omada Mesh technology enables wireless connectivity between access points for extended range, making
wireless deployments more exible and convenient.
Increased Eciency with OFDMA
The Wi-Fi 6 standard uses OFDMA for more ecient channel use and reduced latency. Imagine your WiFi
connection as a series of delivery trucks delivering data packets to your devices. With 802.11ac Wi-Fi, each
delivery truck could only deliver one parcel to one device at a time. But with OFDMA, each truck can deliver
multiple parcels to multiple devices simultaneously. This vast improvement in eciency works for both uploads
and downloads.
3
Advanced RF Management
MU-MIMO, Airtime Fairness, Beamforming, and Band Steering Technologies guarantee optimal RF performance
for business-level applications.
Easy Centralized Management
Congure and monitor hundreds of Omada EAPs with ease using the Omada controller.
1. Only EAP660 HD, EAP620 HD, EAP265 HD, EAP245 V3, EAP225 V3, and EAP225-Outdoor support seamless roaming.
2. Only EAP265 HD, EAP245 V3, EAP225-Outdoor and EAP 225 v3 with specic rmware are available for Mesh.
3. Only EAP660 HD and EAP620 HD support OFDMA.
EAP Product List
Ceiling Mount AP
Model EAP660 HD EAP620 HD EAP265 HD EAP245 EAP225 EAP115 EAP110
Product
Speed
Ethernet Port
Power Supply
Internal Antennas
AX3600 Wireless
Dual-Band Multi-
Gigabit Ceiling
Mount Access Point
2.4 GHz: 4*4 11ax,
1148 Mbps
5 GHz: 4*4 11ax,
2402 Mbps
1 x 2.5Gbps
Ethernet Port
802.3at PoE /
12V DC
2.4 GHz: 4 x 4 dBi
5 GHz: 4 x 5 dBi
AX1800 Wireless
Dual-Band Gigabit
Ceiling Mount
Access Point
2.4 GHz: 2*2 11ax,
574 Mbps
5 GHz: 2*2 11ax,
1201 Mbps
1 x Gigabit Ethernet
Port
802.3at PoE /
12V DC
2.4 GHz: 2 x 4 dBi
5 GHz: 2 x 5 dBi
AC1750 Wireless
MU-MIMO Gigabit
Ceiling Mount
Access Point
2.4 GHz: 450Mbps
5 GHz: 1300Mbps
2 x Gigabit Ethernet
Port
802.3af PoE /
48 V Passive PoE
2.4 GHz: 3 x 3.5 dBi
5 GHz: 3 x 4 dBi
AC1750 Wireless
MU-MIMO Gigabit
Ceiling Mount
Access Point
2.4 GHz: 450Mbps
5 GHz: 1300Mbps
2 x Gigabit Ethernet
Port
802.3af PoE /
48 V Passive PoE
2.4 GHz: 3 x 3.5 dBi
5 GHz: 3 x 4 dBi
AC1350 Wireless
MU-MIMO Gigabit
Ceiling Mount
Access Point
2.4 GHz: 450Mbps
5 GHz: 867Mbps
1 x Gigabit Ethernet
Port
802.3af PoE /
24V Passive PoE
2.4 GHz: 3 x 4 dBi
5 GHz: 2 x 5 dBi
300Mbps Wireless
N Ceiling Mount
Access Point
2.4 GHz: 300Mbps 2.4 GHz: 300Mbps
1 x 10/100Mbps
Ethernet Port
802.3af PoE /
External 9 V/0.6 A
DC power supply
2 x 4 dBi 2 x 4 dBi
300Mbps Wireless
N Ceiling Mount
Access Point
1 x 10/100Mbps
Ethernet Port
24V Passive PoE
Wall Plate AP
Model EAP235-Wall EAP230-Wall EAP225-Wall EAP115-Wall
Omada AC1200 Wireless
Product
Speed
Ethernet Port
Power Supply 802.3af/at PoE 802.3af/at PoE 802.3af/at PoE 802.3af PoE
Internal Antennas
MU-MIMO Gigabit Wall Plate
Access Point
2.4 GHz: 300 Mbps
5 GHz: 867 Mbps
4 x 10/100/1000 Mbps RJ45
Ports
2.4 GHz: 2 x 4 dBi
5 GHz: 2 x 4 dBi
Omada AC1200 Wireless
MU-MIMO Gigabit Wall-
Plate Access Point
2.4 GHz: 300 Mbps
5 GHz: 867 Mbps
2 x 10/100/1000 Mbps
RJ45 Ports
2.4 GHz: 2 x 4 dBi
5 GHz: 2 x 3.6 dBi
Omada AC1200 Wireless
MU-MIMO Wall-Plate Access
Point
2.4 GHz: 300 Mbps
5 GHz: 867 Mbps
4 x 10/100 Mbps RJ45 Ports 2 x 10/100 Mbps RJ45 Ports
2.4 GHz: 2 x 3 dBi
5 GHz: 2 x 4 dBi
300Mbps Wireless N Wall-Plate
Access Point
2.4 GHz: 300 Mbps
2 x 1.8 dBi
Outdoor AP
Model EAP225-Outdoor EAP110-Outdoor
AC1200 Wireless MU-MIMO
Product
Speed
Ethernet Port 1 Gigabit RJ45 Port
Power Supply
Internal Antennas
Gigabit Indoor/Outdoor
Access Point
2.4 GHz: 300Mbps
5 GHz: 867Mbps
802.3af PoE /
24V Passive PoE
2 Dual-Band Omni Antennas
(External Detachable)
2.4 GHz: 3 dBi; 5 GHz: 4 dBi
300Mbps Wireless N
Outdoor Access Point
2.4 GHz: 300Mbps
1 10/100Mbps
RJ45 Port
24V Passive PoE
2 Omni Antennas
(External Detachable)
2.4 GHz: 3 dBi
Specications
Ceiling Mount 802.11ax AP
Model EAP660 HD EAP620 HD
Name
Main Design
Centralized Management
Security
Wireless Function
AX3600 Wireless Dual-Band Multi-
Gigabit Ceiling Mount Access Point
LAN Interfaces 1 x 2.5Gbps Ethernet Port 1 x Gbps Ethernet Port
Wi-Fi Standards IEEE 802.11ax/ac/n/g/b/a
Maximum Data Rate
Concurrent Clients 1000+ 1000+
Antennas
Transmit Power
Omada Software Controller
Omada Hardware Controller
Omada APP
Captive Portal Authentication
Access Control
Maximum number of MAC Filter 4000
Wireless Isolation between
Clients
VLAN
Rogue AP Detection
Wireless Encryption
802.1X Support
Multiple SSIDs 16 (8 on each band)
Enable/Disable Wireless Radio
Enable/Disable SSID Broadcast
Guest Network
Automatic Channel Assignment
Transmit Power Control
QoS (WMM)
Seamless Roaming
Mesh
Beamforming
MU-MIMO
Rate Limit
Load Balance
Airtime Fairness
Band Steering
RADIUS Accounting
MAC Authentication
Reboot Schedule
Wireless Schedule
Wireless Statistics
Static IP/Dynamic IP
1148 Mbps (2.4 GHz)
+2402 Mbps (5 GHz)
2.4 GHz: 4 x 4 dBi
5 GHz: 4 x 5 dBi
CE: < 20 dBm (2.4 GHz, EIRP); < 23
dBm (5 GHz, EIRP)
FCC: < 26 dBm (2.4 GHz); < 26 dBm
(5 GHz)
•
•
•
•
•
•
•
•
WEP, WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-
Personal/Enterprise
•
•
•
•
•
Adjust transmit Power on dBm
•
•
-
•
•
Based on SSID/Client
•
•
•
•
•
•
•
•
•
AX1800 Wireless Dual-Band
Gigabit Ceiling Mount Access Point
574 Mbps (2.4 GHz)
+1201 Mbps (5 GHz)
2.4 GHz: 2 x 4 dBi
5 GHz: 2 x 5 dBi
CE: < 20 dBm (2.4 GHz, EIRP); < 23
dBm (5 GHz, EIRP)
FCC: < 25 dBm (2.4 GHz); < 25 dBm
(5 GHz)
Ceiling Mount 802.11ax AP
Model EAP660 HD EAP620 HD
Support Data Rates
Management
802.11ax
802.11ac
802.11n
802.11g 6, 9, 12, 18, 24, 36, 48 ,54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11a 6, 9, 12, 18, 24, 36, 48 ,54 Mbps
LED ON/OFF Control
Management MAC Access Control
Web-based Management
Telenet
SNMP
SSH
Restore & Backup
Firmware update via Web
NTP
System Log
Email Alerts
Power Supply
8 Mbps to 2402 Mbps (MCS0-
MCS11, NSS = 1 to 4 HE20/40/80)
6.5 Mbps to 2166.7 Mbps
(MCS0-MCS11, NSS = 1 to 4
VHT20/40/80)
6.5 Mbps to 600 Mbps(MSC0-
MCS31, HT20/40)
•
•
•
•
v1, v2c, v3
•
•
•
•
•
•
802.3at PoE or external 12V/2A DC
power supply
8 Mbps to 1201 Mbps (MCS0-
MCS11, NSS = 1 to 2 HE20/40/80)
6.5 Mbps to 1083.3 Mbps (MCS0-
MCS11, NSS = 1 to 2 VHT20/40/80)
6.5 Mbps to 300 Mbps (MCS0-
MCS15, HT20/40)
802.3at PoE or external 12V/1A DC
power supply
Physical & Environment
Others
Maximum Power Consumption
Reset
Mounting Ceiling / Wall mouting (Kits included)
Certications CE, FCC, RoHS
Dimensions (W x D x H) 243 x 243 x 64 mm
Environment
EU: 18.5 W (For PoE); 15 W (for DC)
US: 22.5 W (For PoE); 18 W (for DC)
•
Operating Temperature: 0 °C–40 °C (32 °F–104 °F);
Storage Temperature: -40 °C–70 °C (-40 °F–158 °F);
Operating Humidity: 10%–90% non-condensing;
Storage Humidity: 5%–90% non-condensing;
EU: 12.5 W (For PoE); 10 W (for DC)
US: 14W (For PoE); 11.5 W (for DC)
Ceiling Mount 802.11n/ac AP
Model EAP265 HD EAP245 EAP225 EAP115 EAP110
Name
Main Design
Centralized Management
Security
Wireless Function
AC1750 Wireless
MU-MIMO Gigabit
Ceiling Mount
Access Point
LAN Interfaces 2 10/100/1000 Mbps Ethernet Ports
Wi-Fi Standards IEEE 802.11a/b/g/n/ac IEEE 802.11a/b/g/n
Maximum Data Rate 450 Mbps (2.4 GHz) +1300 Mbps (5 GHz)
Concurrent Clients 500+ 220+ 220+ 100
Antennas
Transmit Power
Omada Software Controller
Omada Hardware Controller
Omada APP
Captive Portal Authentication
Access Control
Maximum number of MAC
Filter
Wireless Isolation between
Clients
VLAN
Rogue AP Detection
Wireless Encryption WEP, WPA-Personal/Enterprise, WPA2-Personal/Enterprise
802.1X Support
Multiple SSIDs 16 (8 on each band) 8
Enable/Disable Wireless Radio
Enable/Disable SSID
Broadcast
Guest Network
Automatic Channel
Assignment
Transmit Power Control
QoS (WMM)
Seamless Roaming
Mesh
Beamforming
MU-MIMO
Rate Limit
Load Balance
Airtime Fairness
Band Steering
RADIUS Accounting
MAC Authentication
Reboot Schedule
Wireless Schedule
Wireless Statistics
Static IP/Dynamic IP
2.4G: 3 x 3.5 dBi
5GHz: 3 x 4 dBi
CE: < 20 dBm (2.4
GHz, EIRP); < 23 dBm
(5 GHz, EIRP)
FCC: < 24 dBm (2.4
GHz); < 24 dBm (5
GHz)
•
•
•
•
•
4000
•
•
•
•
•
•
•
•
Adjust transmit Power on dBm
•
• -
• -
• -
• -
Based on SSID/Client
•
• -
• -
•
•
•
•
•
•
AC1750 Wireless
MU-MIMO Gigabit
Ceiling Mount
Access Point
2.4 GHz: 3 x 3.5 dBi,
5 GHz: 3 x 4 dBi
CE: < 20 dBm (2.4
GHz, EIRP); < 28
dBm (5 GHz, EIRP)
FCC: < 24 dBm (2.4
GHz); < 24 dBm (5
GHz)
AC1350 Wireless
MU-MIMO Gigabit
Ceiling Mount
Access Point
1 10/100/1000
Mbps Ethernet Port
450 Mbps (2.4 GHz)
+876 Mbps (5 GHz)
2.4 GHz: 3 x 4 dBi,
5 GHz: 2 x 5 dBi
CE: < 20 dBm (2.4
GHz, EIRP); < 27
dBm (5 GHz, EIRP)
FCC: < 24 dBm (2.4
GHz); < 22 dBm (5
GHz)
300 Mbps
Wireless N
Access Point
1 10/100 Mbps Ethernet Port
300 Mbps (2.4 GHz)
2 x 4 dBi
CE: < 19 dBm (EIRP), FCC: < 21 dBm
300 Mbps
Wireless N Access
Point
Ceiling Mount 802.11n/ac AP
Model EAP265 HD EAP245 EAP225 EAP115 EAP110
6.5 Mbps to 867
Support Data Rates
Management
Physical & Environment
Others
802.11ac
802.11n 6.5 Mbps to 450 Mbps (MCS0-MCS23, HT20/40)
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
LED ON/OFF Control
Management MAC Access
Control
Web-based Management
Telenet
SNMP
SSH
Restore & Backup
Firmware update via Web
NTP
System Log
Email Alerts
Power Supply
Maximum Power
Consumption
Reset
Mounting
Certications
Dimensions (W x D x H) 205.4 x 181.6 x 37.4 mm 189.4 x172.3 x 29.5 mm
6.5 Mbps to 1300 Mbps (MCS0-MCS9,
NSS = 1 to 3 VHT20/40/80)
•
•
•
•
v1, v2c
•
•
•
•
•
•
802.3af PoE or 48
V Passive PoE (+4,5
pins; -7,8 pins. PoE
Adapter Included)
10.36 W 12.3 W 12.6 W 3.1 W 2.8 W
802.3af PoE or 48
V Passive PoE (+4,5
pins; -7,8 pins. PoE
Adapter Included)
•
Ceiling/Wall mounting (Kits included)
CE, FCC, RoHS
Operating Temperature: 0 °C–40 °C (32 °F–104 °F)
Environment
Storage Temperature: -40 °C–70 °C (-40 °F–158 °F)
Operating Humidity: 10%–90% non-condensing
Storage Humidity: 5%–90% non-condensing
Mbps (MCS0-
MCS9, NSS = 1 to
2 VHT20/40/80)
802.3af PoE or 24
V Passive PoE (+4,5
pins; -7,8 pins. PoE
Adapter Included)
-
6.5 Mbps to 300 Mbps (MCS0-
MCS15, HT20/40)
-
802.3af PoE or
external 9 V/0.6 A
DC power supply
24 V Passive PoE
(+4,5 pins; -7,8
pins. PoE Adapter
Included)
Wall Plate AP
Model EAP235-Wall EAP230-Wall EAP225-Wall E AP115-Wall
Name
Main Design
Centralized Management
Security
Wireless Function
AC1200 Wireless
MU-MIMO Gigabit
Wall Plate Access Point
Uplink: 1 10/100/1000
Mbps Ethernet Port
LAN Interfaces
Wi-Fi Standards IEEE 802.11a/b/g/n/ac IEEE 802.11a/b/g/n
Maximum Data Rate 300 Mbps (2.4 GHz) + 867 Mbps (5 GHz) 300 Mbps (2.4 GHz)
Concurrent Clients 200 200 200 100
Antennas
Transmit Power
Omada Software Controller
Omada Hardware Controller
Omada APP
Captive Portal Authentication
Access Control
Maximum number of MAC
Filter
Wireless Isolation between
Clients
VLAN
Rogue AP Detection
Wireless Encryption
802.1X Support
Multiple SSIDs 16 (8 on each band) 8
Enable/Disable Wireless Radio
Enable/Disable SSID
Broadcast
Guest Network
Automatic Channel
Assignment
Transmit Power Control Adjust transmit Power on dBm
QoS (WMM)
Seamless Roaming
Mesh
Beamforming
MU-MIMO
Rate Limit Based on SSID/Client
Load Balance
Airtime Fairness
Band Steering
RADIUS Accounting
MAC Authentication
Reboot Schedule
Wireless Schedule
Wireless Statistics
Static IP/Dynamic IP
Downlink: 3 10/100/1000
Mbps Ethernet Ports (one
supports PoE Out)
2.4 GHz: 2 x 4 dBi
5 GHz: 2 x 4 dBi
FCC: < 21 dBm (2.4 GHz);
< 21 dBm (5 GHz)
•
•
•
•
•
4000
•
•
•
WEP, WPA-Personal/Enterprise, WPA2-Personal/Enterprise
•
•
•
•
•
•
-
-
•
•
•
-
• -
•
•
•
•
•
•
AC1200 Wireless
MU-MIMO Gigabit
Wall Plate Access Point
Uplink: 1 10/100/1000
Mbps Ethernet Port
Downlink: 1
10/100/1000 Mbps
Ethernet Port
2.4 GHz: 2 x 4 dBi
5 GHz: 2 x 3.6 dBi
CE: < 20 dBm (2.4 GHz,
EIRP); < 23 dBm (5 GHz,
EIRP)
AC1200 Wireless
MU-MIMO Wall Plate
Access Point
Uplink: 1 10/100 Mbps
Ethernet Port
Downlink: 3 10/100 Mbps
Ethernet Ports (one
supports PoE Out)
2.4 GHz: 2 x 3 dBi
5 GHz: 2 x 4 dBi
CE: < 20 dBm (2.4 GHz,
EIRP); < 23 dBm (5 GHz,
EIRP)
FCC: < 21 dBm (2.4 GHz);
< 21 dBm (5 GHz)
300 Mbps Wireless N
Wall Plate Access Point
Uplink: 1 10/100 Mbps
Ethernet Port
Downlink: 1 10/100
Mbps Ethernet Port
2 x 1.8 dBi
CE: < 20 dBm
-
-
Wall Plate AP
Model EAP235-Wall EAP230-Wall EAP225-Wall E AP115-Wall
Support Data Rates
Management
Physical & Environment
Others
802.11ac 6.5 Mbps to 867 Mbps (MCS0-MCS9, NSS = 1 to 2 VHT20/40/80)
802.11n 6.5 Mbps to 300 Mbps (MCS0-MCS15, HT20/40)
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
LED ON/OFF Control
Management MAC Access
Control
Web-based Management
Telenet
SNMP
SSH
Restore & Backup
Firmware update via Web
NTP
System Log
Email Alerts
Power Supply 802.3af/at PoE 802.3af PoE
Maximum Power
Consumption
Reset
Mounting Wall Plate Mouting (Kits included)
Certications FCC, RoHS CE, RoHS CE, FCC, RoHS CE, RoHS
Dimensions (W x D x H) 143 x 86 x 20 mm 86.8 × 86.8 × 30.2 mm 143 x 86 x 20 mm 86.8 × 86.8 × 30.2 mm
Environment
•
•
•
•
v1, v2c
•
•
•
•
•
•
9.8 W (Without PoE Out) 7 W 9.8 W (Without PoE Out) 2.8 W
•
Operating Temperature: 0 °C–40 °C (32 °F–104 °F);
Storage Temperature: -40 °C–70 °C (-40 °F–158 °F);
Operating Humidity: 10%–90% non-condensing;
Storage Humidity: 5%–90% non-condensing;
-
-
Outdoor AP
Model EAP225-Outdoor EAP110-Outdoor
Name
Main Design
Centralized Management
Security
Wireless Function
Support Data Rates
AC1200 Wireless MU-MIMO Gigabit Indoor/Outdoor
Access Point
LAN Interfaces 1 10/100/1000 Mbps Ethernet Port 1 10/100 Mbps Ethernet Port
Wi-Fi Standards IEEE 802.11b/g/n/ac IEEE 802.11b/g/n
Maximum Data Rate
Concurrent Clients 220+ 100
Antennas
Transmit Power
Omada Software Controller
Omada Hardware Controller
Omada APP
Captive Portal Authentication
Access Control
Maximum number of MAC Filter 4000
Wireless Isolation between
Clients
VLAN
Rogue AP Detection
Wireless Encryption WEP, WPA-Personal/Enterprise, WPA2-Personal/Enterprise
802.1X Support
Multiple SSIDs 16 (8 for each band) 8
Enable/Disable Wireless Radio
Enable/Disable SSID Broadcast
Guest Network
Automatic Channel Assignment
Transmit Power Control Adjust transmit Power on dBm
QoS (WMM)
Seamless Roaming
Mesh
Beamforming
MU-MIMO
Rate Limit Based on SSID/Client
Load Balance
Airtime Fairness
Band Steering
RADIUS Accounting
MAC Authentication
Reboot Schedule
Wireless Schedule
Wireless Statistics
Static IP/Dynamic IP
802.11ac
802.11n 6.5 Mbps to 300 Mbps (MCS0-MCS15, HT20/40)
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
300 Mbps (2.4 GHz)
+ 867 Mbps (5 GHz)
2 Dual-Band Omni Antennas (External Detachable) 2.4
GHz: 3 dBi;
5 GHz: 4 dBi
CE: < 20 dBm (2.4 GHz, EIRP), < 26 dBm (5 GHz, EIRP);
FCC: < 23 dBm (2.4 GHz), < 22 dBm (5 GHz)
•
•
•
•
•
•
•
•
•
•
•
•
•
•
• -
• -
• -
• -
•
• -
• -
•
•
•
•
•
•
6.5 Mbps to 867 Mbps (MCS0-MCS9, NSS=1 to 2
VHT20/40/80)
300 Mbps Wireless N Outdoor Access Point
300 Mbps (2.4 GHz)
2 Omni Antennas (External Detachable) 2.4 GHz: 3
dBi
CE: < 20 dBm (EIRP), FCC: < 22 dBm
-
-
Outdoor AP
Model EAP225-Outdoor EAP110-Outdoor
Management
Physical & Environment
Others
LED ON/OFF Control
Management MAC Access
Control
Web-based Management
Telenet
SNMP v1, v2c
SSH
Restore & Backup
Firmware update via Web
NTP
System Log
Email Alerts
Power Supply
Maximum Power Consumption 10.5W 3.1 W
Reset
Mounting Pole/Wall mouting (Kits included)
Certications CE, FCC, RoHS
Dimensions (W x D x H) 214.9 x 46 x 26.7 mm 216 x 46 x 27 mm
Environment
•
•
•
•
•
•
•
•
•
•
802.3af PoE or 24 V Passive PoE (+4,5 pins; -7,8 pins.
PoE Adapter
Included)
•
Operating Temperature: -30 °C–70 °C (-22 °F–158 °F);
Storage Temperature: -40 °C–70 °C (-40 °F–158 °F);
Operating Humidity: 10%–90% non-condensing;
Storage Humidity: 5%–90% non-condensing;
24 V Passive PoE (+4,5 pins; -7,8 pins. PoE Adapter
Included)
Operating Temperature: -30 °C–65 °C (-22 °F–149 °F);
Storage Temperature: -40 °C–70 °C (-40 °F–158 °F);
Operating Humidity: 10%–90% non-condensing;
Storage Humidity: 5%–90% non-condensing;
Antenna Radiation Patterns
Ceiling Mount AP
Elevation-0° Elevation-90° Azimuth Mapped 3D
2.45 GHz
5.25 GHz
EAP660 HD
5.5 GHz
5.75 GHz
Ceiling Mount AP
2.45 GHz
5.25 GHz
EAP620 HD
Elevation-0° Elevation-90° Azimuth Mapped 3D
5.5 GHz
5.75 GHz
Ceiling Mount AP
2.45 GHz
5.25 GHz
EAP265 HD
Elevation-0° Elevation-90° Azimuth Mapped 3D
5.5 GHz
5.75 GHz
Ceiling Mount AP
2.45 GHz
5.25 GHz
EAP245
Elevation-0° Elevation-90° Azimuth Mapped 3D
5.5 GHz
5.75 GHz
Ceiling Mount AP
2.45 GHz
5.25 GHz
EAP225
Elevation-0° Elevation-90° Azimuth Mapped 3D
5.5 GHz
5.75 GHz
Ceiling Mount AP
2.45 GHz
Ceiling Mount AP
EAP115
Elevation-0° Elevation-90° Azimuth Mapped 3D
EAP110
Elevation-0° Elevation-90° Azimuth Mapped 3D
2.45 GHz
Wall Plate AP
2.45 GHz
5.25 GHz
EAP235-wall
Elevation-0° Elevation-90° Azimuth Mapped 3D
5.5 GHz
5.75 GHz
Wall Plate AP
2.45 GHz
5.25 GHz
EAP230-wall
Elevation-0° Elevation-90° Azimuth Mapped 3D
5.5 GHz
5.75 GHz
Wall Plate AP
2.45 GHz
5.25 GHz
EAP225-wall
Elevation-0° Elevation-90° Azimuth Mapped 3D
5.5 GHz
5.75 GHz
Wall Plate AP
EAP115-wall
Elevation-0° Elevation-90° Azimuth Mapped 3D
2.45 GHz
Outdoor AP
2.45 GHz
5.25 GHz
EAP225-outdoor
Elevation-0° Elevation-90° Azimuth Mapped 3D
5.5 GHz
5.75 GHz
Outdoor AP
EAP110-outdoor
Elevation-0° Elevation-90° Azimuth Mapped 3D
2.45 GHz
Disclaimers
Wireless Speed, Range and Concurrent Devices Disclaimer
Maximum wireless transmission rates are the physical rates derived from IEEE Standard 802.11 specications.
Range and coverage specications along with the number of connected devices were dened according to test
results under normal usage conditions. Actual wireless transmission rate, wireless coverage, and concurrent
devices are not guaranteed, and will vary as a result of 1) environmental factors, including building
materials, physical objects and obstacles, 2) network conditions, including local interference, volume and
density of trac, product location, network complexity, and network overhead and 3) client limitations, including
rated performance, location, connection quality, and client condition.
MU-MIMO Disclaimer
(for EAP265 HD / EAP245 / EAP225 / EAP225-Outdoor / EAP235-Wall / EAP230-Wall / EAP225-Wall)
MU-MIMO capability requires client devices that also support MU-MIMO.
Seamless Roaming Disclaimer
(for EAP265 HD / EAP245 / EAP225 / EAP225-Outdoor)
Seamless roaming requires both the access point and client devices to support 802.11k and 802.11v
protocols.
Lightning and Electro-Static Discharge Protection Disclaimer
(for EAP225-Outdoor / EAP110-Outdoor)
Protection against lightning and electro-static discharge may be achieved through proper product setup,
grounding and cable shielding. Refer to the instruction manual and consult an IT professional to assist with
setting up this product.
PoE Disclaimer
PoE budget calculations are based on laboratory testing. Actual PoE power budget is not guaranteed and will
vary as a result of client limitations and environmental factors.
Some models featured in this guide may be unavailable in your country or region. Visit TP-Link website for local sales
information: www.tp-link.com. Specications are subject to change without notice.
© 2020 TP-Link
Loading...
