AC1350
High Power Wireless
Dual Band Router
Higher Power,
Greater Coverage,
Faster Streaming
Archer C58HP
450Mbps + 867Mbps
Dual Band Wi-Fi
9
dBi
9dBi Antennas
Maximum Range

Highlights
Superior Coverage Wall-Breaking Wi-Fi
An array of high-powered features provides wireless coverage for areas of up
to 10,000 square feet.
The supercharged wireless signal cuts through walls and other physical
barriers, eliminating dead zones for a worry-free Wi-Fi network.
TP-Link AC1350 High Power Wireless Dual Band Router
Archer C58HP

Highlights
High-Gain Stability Tap into Multi-Mode
Three 9dBi antennas make stable connections for reliable Wi-Fi to all your
devices.
The RE Button lets you eortlessly switch between router and extender modes.
Access point mode is also available from the web utility or Tether app.
Router Mode
Extender Mode
TP-Link AC1350 High Power Wireless Dual Band Router
Archer C58HP

Features
Reliability
· Ultimate Wireless Speed – Combined wireless speeds up to
450Mbps over 2.4GHz and 867Mbps over 5GHz
· Support 802.11ac – Provides a data transfer rate 3 times faster
than 802.11n for each stream
· Easy Bandwidth Management– QoS allocates necessary speed
of each connected device to ensure quality of multimedia
streaming
Ease of Use
· Intuitive Web UI – Ensures quick and simple Installation without
hassle
· Fast Encryption – One-touch WPA wireless security encryption
with the WPS button
· Hassle-free Management with Tether App – Network
management is made easy with the TP-Link Tether App,
available on any Android and iOS device
Security
· Guest Network – Keeps your main network secure by creating a
separate network for friends and visitors
· Access Control – Establishes a whitelist or blacklist to allow or
restrict certain devices to access the internet
· Parental Controls – Restricts internet access time and contents
for children devices
· Encryptions for Secure Network – WPA-PSK and WPA2-PSK
encryptions provide active protection against security threats
TP-Link AC1350 High Power Wireless Dual Band Router
Archer C58HP

Specications
Hardware
· Ethernet Ports: 4 10/100Mbps LAN Ports, 1 10/100Mbps WAN Port
· Buttons: Power On/O Button, Wi-Fi On/O Button, Reset Button,
WPS Button, RE Button
· Antennas: Three 9dBi Detachable Antennas
· External Power Supply: 12V/1.5A
· Dimensions (W x D x H): 9.0× 7.5×1.9 in. (228×190×48mm)
Wireless
· Wireless Standards: IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz
· Frequency: 2.4GHz, 5GHz
· Signal Rate: 867Mbps at 5GHz, 450Mbps at 2.4GHz
· Transmit Power: CE: < 20dBm, FCC: <30dBm
· Reception Sensitivity:
5GHz:
866M:-61dBm@10%PER
400M:-63dBm@10%PER
173M:-68dBm@10%PER
54M:-76dBm@10%PER
Power
On/Off
Wi-Fi
On/Off
2.4GHz:
450M:-69dBm@10%PER
216M:-72dBm@10%PER
54M:-75dBm@10%PER
11M:-89dBm@8%PER
· Wireless Function: Enable/Disable Wireless Radio, WDS Bridge, WMM,
Wireless Statistics
InternetPower Reset
LAN PortsWPS
· Wireless Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
encryptions
TP-Link AC1350 High Power Wireless Dual Band Router
Archer C58HP

Specications
OthersSoftware
· Quality of Service: WMM, Bandwidth Control
· WAN Type: Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual
Access)/BigPond
· Management: Access Control, Local Management, Remote Management
· DHCP: Server, DHCP Client List, Address Reservation
· Port Forwarding: Virtual Server, Port Triggering, UPnP, DMZ
· Dynamic DNS: DynDns, NO-IP
· Access Control: Parental Controls, Local Management Control, Host List, White
List, Black List
· Firewall Security: DoS, SPI Firewall, IP and MAC Address Binding
· Protocols: IPv4, IPv6
· Guest Network: 2.4GHz and 5GHz guest networks
· Certication:
CE, FCC, RoHS
· System Requirements:
Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS,
NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
Java-enabled browser
· Environment:
Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
· Package Contents
AC1350 High Power Wireless Dual Band Router Archer C58HP
Power Supply Unit
Ethernet Cable
Quick Installation Guide
For more information, please visit
http://www.tp-link.com/en/products/details/Archer C58HP.html
or scan the QR code left
Attention: This device may only be used indoors in all EU member states and EFTA countries.
Specications are subject to change without notice. TP-Link is a registered trademark of TP-Link Technologies Co., Ltd. Other brands and product names are trademarks or registered trademarks of their respective holders. Copyright ©2017 TP-Link Technologies Co., Ltd. All rights reserved.
*Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network
conditions, including local interference, volume and density of trac, product location, network complexity, and network overhead, and 3) client limitations, including rated performance, location, connection, quality, and client condition.
TP-Link Technologies Co., Ltd. No.5 Keyuan Road, Nanshan, Shenzhen, 518057, PRC
www.tp-link.com
