1-1. Key information

Keys

The following keys are provided with the vehicle.

Vehicles without a smart key system

Master keys

Operating the wireless remote control function (→P. 49)

Valet key Key number plate

Vehicles with a smart key system

Electronic keys

• Operating the smart key

• Operating the wireless

Mechanical keys Key number plate

system (→P. 35)

remote control function (→P. 49)

4RUNNER_U

1-1. Key information

Using the mechanical key (vehicles with a smart key system)

To take out the mechanical key, push the release button and take the key out.

After using the mechanical key, store it in the electronic key. Carry the mechanical key together with the electronic key. If the electronic key battery is depleted or the entry function does not operate properly, you will need the mechanical key. (→P. 621)

■ When required to leave the vehicle’s key with a parking attendant

Lock the glove box as circumstances demand. (→P. 442) Vehicles without a smart key system: Carry the master key for your own use

and provide the attendant with the valet key. Vehicles with a smart key system: Remove the mechanical key for your own

use and provide the attendant with the electronic key only.

■ Key number plate

Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key (without a smart key system) or mechanical key (with a smart key system) is lost, a new key can be made by your Toyota dealer using the key number plate. (→P. 619)

■ When riding in an aircraft

When bringing a key with wireless remote control function onto an aircraft, make sure you do not press any buttons on the key while inside the aircraft cabin. If you are carrying the key in your bag etc., ensure that the buttons are not likely to be pressed accidentally. Pressing a button may cause the key to emit radio waves that could interfere with the operation of the aircraft.

Before driving

4RUNNER_U

1-1. Key information

NOTICE

■ To prevent key damage

Observe the following:

● Do not drop the keys, subject them to strong shocks or bend them.

● Do not expose the keys to high temperatures for a long period of time.

● Do not get the keys wet or wash them in an ultrasonic washer etc.

● Do not attach metallic or magnetic materials to the keys or place the keys

close to such materials.

● Do not disassemble the keys.

● Do not attach a sticker or anything else to the surface of the electronic key.

● Do not place the keys near objects that produce magnetic fields, such as

TVs, audio systems, glass top ranges, or medical electrical equipment, such as low-frequency therapy equipment.

■ Carrying the electronic key on your person (vehicles with a smart key

system)

Carry the electronic key 3.9 in. (10 cm) or more away from electric appliances that are turned on.

■ In case of a smart key system malfunction or other key-related prob-

lems (vehicles with a smart key system)

Take your vehicle with all the electronic keys provided with your vehicle to your Toyota dealer.

■ When a vehicle key is lost (vehicles with a smart key system)

If the key remains lost, the risk of vehicle theft increases significantly. Visit your Toyota dealer immediately with all remaining electronic keys that was provided with your vehicle.

4RUNNER_U

1-2. Opening, closing and locking the doors

Smart key system

The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.)

Electronic key

∗

Before driving

Electronic key

Locks and unlocks the side doors (→P. 36) Locks, unlocks and opens the back door (→P. 37) Opens the back door (→P. 36) Starts the en gine (→P. 173)

CTH12AS053

∗: If equipped

4RUNNER_U

1-2. Opening, closing and locking the doors

Unlocking and locking the side doors (front door handles only)

Grip the handle to unlock the door.

Make sure to touch the sensor on the back of the handle.

The doors cannot be unlocked for 3 seconds after the doors are locked.

Touch the lock sensor (the indentation on the upper part of the door handle) to lock the doors.

Opening the back door

Press the back door opener.

The back door can be opened even if it is locked.

4RUNNER_U

1-2. Opening, closing and locking th e do o r s

Unlocking and locking the back door

Press the button to unlock the door.

Press the button to lock the door.

The back window can be opened by pressing and holding this button. (→P. 101)

The back window can be closed by pressing and holding this button. (→P. 101)

Before driving

4RUNNER_U

1-2. Opening, closing and locking the doors

Antenna location and effective range

■ Antenna location

Antennas outside the cabin Antennas inside the cabin Antenna outside the luggage

compartment

CTH12AS058

4RUNNER_U

1-2. Opening, closing and locking th e do o r s

■ Effective range (areas within which the electronic key is

detected)

When locking or unlocking the doors

The system can be operated when the electronic key is within about 2.3 ft. (0.7 m) either of the outside front door handles and back

CTH12AS051

door. (Only the doors detecting the key can be operated.)

When starting the engine or changing “ENGINE START STOP” switch modes

The system can be operated when the electronic key is inside the vehicle.

Before driving

4RUNNER_U

1-2. Opening, closing and locking the doors

■ Operation signals

A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: once; Unlocked: twice)

■ When the door cannot be locked by the lock sensor on the upper part

of the door handle

Touch both lock sensors on the upper and lower part of the door handle simultaneously.

■ Alarms and warning indicators

A combination of exterior and interior alarms as well as warning lights is used to prevent theft of the vehicle and accidents resulting from erroneous operation.

When any warning lights come on, take appropriate measures depending on which warning light comes on. (→P. 587)

4RUNNER_U

1-2. Opening, closing and locking th e do o r s

The following table describes circumstances and correction procedures when only alarms are sounded.

Alarm Situation Correction procedure

Exterior alarm sounds once for 5 seconds

Interior alarm sounds continuously

Interior alarm pings repeatedly

An attempt was made to lock the doors using the entry function while the electronic key was still inside the vehicle.

An attempt was made to lock either front door by opening a door and putting the inside lock button into the lock position, then closing the door by pulling on the outside door handle with the electronic key still inside the vehicle.

An attempt was made to lock the vehicle using the entry function while a door was open.

An attempt was made to open the door and exit the vehicle when the shift lever was not in P.

The “ENGINE START STOP” switch was turned to ACCESSORY mode while the driver's door was open (The driver's door was opened when the “ENGINE START STOP” switch was in ACCESSORY mode.)

Before driving

Retrieve the electronic key from the vehicle and lock the doors again.

Close all of the doors and lock the doors again.

Shift the shift lever to P.

Turn the “ENGINE START STOP” switch off and close the driver's door.

4RUNNER_U

1-2. Opening, closing and locking the doors

Alarm Situation Correction procedure

The “ENGINE START STOP” switch was pressed after the doors were unlocked with the mechan-

Interior alarm sounds once.

■ Security feature

If a door is not opened within approximately 60 seconds after the vehicle is unlocked, the security feature automatically locks the vehicle again.

■ Battery-saving function

In the following circumstances, the entry function is disabled in order to prevent the vehicle battery from discharging and the electronic key battery from depleting.

● When the entry function has not been used for 5 days or more

● When the electronic key has been left within approximately 6 ft. (2 m) of

the vehicle for 10 minutes or more

● If the entry function has not been used for 14 days or more, the vehicle

cannot be unlocked by a door other than the driver's door. To unlock the vehicle, grip the driver's door handle or use the wireless remote control or the mechanical key.

The system will resume operation when

● The vehicle is locked using the door handle lock switch when carrying the

electronic key on your person.

● The vehicle is locked/unlocked using the wireless remote control.

(→P. 49)

● The vehicle is locked/unlocked using the mechanical key. (→P. 621)

ical key. The “ENGINE START

STOP” switch was pressed two consecutive times without the electronic key being present.

Touch the electronic key to the “ENGINE START STOP” switch while depressing the brake pedal.

4RUNNER_U

1-2. Opening, closing and locking th e do o r s

■ Conditions affecting operation

The smart key system uses weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system, wireless remote control and immobilizer system from operating properly. (Way of coping →P. 621)

● When the electronic key battery is depleted

● Near a TV tower, electric power plant, gas station, radio station, large dis-

play, airport or other facility that generates strong radio waves or electrical noise

● When carrying a portable radio, mobile phone, cordless phone or other

wireless communication device

● When the electronic key is in contact with, or is covered by the following

metallic objects

• Cards to which aluminum foil is attached

• Cigarette boxes that have aluminum foil inside

• Metallic wallets or bags

• Coins

• Hand warmers made of metal

• Media such as CDs and DVDs

● When multiple electronic keys are in the vicinity

● When other wireless keys (that emit radio waves) are being used nearby

● When carrying the electronic key together with the following devices that

emit radio waves

• Another vehicle's electronic key or a wireless key that emits radio waves

• Personal computers or personal digital assistants (PDAs)

• Digital audio players

• Portable game systems

● If window tint with a metallic content or metallic objects are attached to

the back window

Before driving

4RUNNER_U

1-2. Opening, closing and locking the doors

■ Note for the entry function

● Even when the electronic key is within the effective range (detection

areas), the system may not operate properly in the following cases:

• The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.

• The electronic key is on the instrument panel or floor, in the glove box, or in the auxiliary box of the instrument panel.

● Do not leave the electronic key on top of the instrument panel or near the

door pockets when exiting the vehicle. Depending on the radio wave reception conditions, it may be detected by the antenna outside the cabin and the door will become lockable from the outside, possibly trapping the electronic key inside the vehicle.

● As long as the electronic key is within the effective range, the doors may

be locked or unlocked by anyone. However, only the doors detecting the electronic key can be used to unlock the vehicle.

● The doors may lock or unlock if the electronic key is within the effective

range and a large amount of water splashes on the door handle, such as in the rain or in a car wash. The doors will automatically be locked after approximately 60 seconds if a door is not opened and closed.

● If the wireless remote control is used to lock the doors when the elec-

tronic key is near the vehicle, there is a possibility that the door may not be unlocked by the entry function. (Use the wireless remote control to unlock the doors.)

■ Notes for locking the doors

● T ouching the door lock sensor while wearing gloves may delay or prevent

lock operation. Remove the gloves and touch the lock sensor again.

● When the lock operation is performed using the lock sensor, recognition

signals will be shown up to two consecutive times. After this, no recognition signals will be given.

● If the door handle becomes wet while the electronic key is within the

effective range, the door may lock and unlock repeatedly. Place the key in a position 6 ft. (2 m) or more separate from the vehicle while the vehicle is being washed. (Take care to ensure that the key is not stolen.)

4RUNNER_U

1-2. Opening, closing and locking th e do o r s

● If the electronic key is inside the vehicle and a door handle becomes wet

during a car wash, a buzzer will sound outside the vehicle. To turn off the alarm, lock all the doors.

● The lock sensor may not work properly if it comes into contact with ice,

snow, mud, etc. Clean the lock sensor and attempt to operate it again, or use the lock sensor on the lower part of the door handle.

● Fingernails may scrape against the door during operation of the door

handle. Be careful not to injure fingernails or damage the surface of the door.

■ Notes for the unlocking function

● Gripping the door handle when wearing a glove may not unlock the door.

● A sudden approach to the effective range or door handle may prevent the

doors from being unlocked. In this case, return the door handle to the original position and check that the doors unlock before pulling the door handle again.

● If there is another electronic key in the detection area, it may take slightly

longer to unlock the doors after the door handle is gripped.

■ When the vehicle is not driven for extended periods

To prevent theft of the vehicle, do not leave the electronic key within 6 ft. (2 m) of the vehicle.

■ To operate the system properly

Make sure to carry the electronic key when operating the system. Do not get the electronic key too close to the vehicle when operating the system from the outside of the vehicle.

Depending on the position and holding condition of the electronic key, the key may not be detected correctly and the system may not operate properly. (The alarm may go off accidentally, or the door lock prevention function may not operate.)

■ If the smart key system does not operate properly

● Locking and unlocking the doors: Use the mechanical key. (→P. 621)

● Starting the engine: →P. 622

Before driving

4RUNNER_U

1-2. Opening, closing and locking the doors

■ Electronic key battery depletion

● The standard battery life is 1 to 2 years.

● As the electronic key always receives radio waves, the battery will

become depleted even if the electronic key is not used. The following symptoms indicate that the electronic key battery may be depleted. Replace the battery when necessary. (→P. 552)

• The smart key system or the wireless remote control does not operate.

• The detection area becomes smaller.

• The LED indicator on the key surface does not turn on.

● To avoid serious deterioration, do not leave the electronic key within 3 ft.

(1 m) of the following electrical appliances that produce a magnetic field:

• TVs

• Personal computers

• Cellular phones, cordless phones and battery chargers

• Recharging cellular phones or cordless phones

• Glass top ranges

• Table lamps

■ Precautions when disconnecting the battery

● In some cases, it may not be possible to unlock the doors using the smart

key system immediately after the battery has been disconnected. Use the wireless remote control or the mechanical key to lock or unlock the doors.

● The engine may not start on the first attempt after reconnecting the bat-

tery but will start normally after the second attempt. This is not a malfunction.

● The “ENGINE START STOP” switch mode is memorized by the vehicle.

When the battery is reconnected, the system will return to the mode it was in before the battery was disconnected. Before disconnecting the battery, turn the “ENGINE START STOP” switch off.

If you are unsure what mode the “ENGINE START STOP” switch was in when the battery was disconnected, be especially careful when reconnecting the battery.

4RUNNER_U

1-2. Opening, closing and locking th e do o r s

■ When the electronic key battery is fully depleted

→P. 552

■ Customization that can be configured at Toyota dealer

Settings (e.g. smart key system) can be changed. (Customizable features →P. 660)

■ Certification for the smart key system

For vehicles sold in the U.S.A.

FCC ID: NI4TMIMB-2 FCC ID: NI4TMLF8-14 FCC ID: HYQ14ACX FCC ID: HYQ13CZD FCC ID: HYQ14ADF FCC ID: HYQ13CZE NOTE:

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

For vehicles sold in Canada

NOTE: Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

Before driving

4RUNNER_U

1-2. Opening, closing and locking the doors

CAUTION

■ Caution regarding interference with electronic devices

● People with implanted pacemakers or cardiac defibrillators should keep

away from the smart key system antennas. (→P. 38) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of emitting the radio waves. Then, consult your doctor to see if you should disable the entry function.

● Users of any electrical medical device other than implanted pacemakers

and implanted cardiac defibrillators should consult the manufacturer of the device for information about its operation under the influence of radio waves. Radio waves could have unexpected effects on the operation of such medical devices.

Ask your Toyota dealer for details on disabling the entry function.

4RUNNER_U

1-2. Opening , closing and locki ng the doors

Wireless remote control

The wireless remote control can be used to lock and unlock the vehicle.

Vehicles without a smart key system

Locks all the doors Sounds the alarm

(press and hold) (→P. 50) Unlocks all the doors

Pressing the button unlocks the driver’s door. Pressing the

CTH12AS045

button again within 3 seconds unlocks the other doors.

Opens the windows and moon roof (press and hold)*

: This setting must be custom-

ized at your Toyota dealer.

Before driving

Vehicles with a smart key system

CTH12AS046

Locks all the doors Unlocks all the doors

Pressing the button unlocks the driver’s door. Pressing the button again within 3 seconds unlocks the other doors.

Opens the windows and moon roof (press and hold)*

Sounds the alarm (press and hold) (→P. 50)

*: This setting must be custom-

ized at your Toyota dealer.

4RUNNER_U

1-2. Opening, closing and locking the doors

■ Operation signals

A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: once; Unlocked: twice)

■ Door lock buzzer

If an attempt to lock the doors is made when a door is not fully closed, a buzzer sounds continuously . Fully close the door to stop the bu zzer, and lock the vehicle once more.

■ Panic mode

Vehicles without a smart key system

When is pressed for longer than about one second, an alarm will

sound intermittently and the vehicle lights will flash to deter any person from trying to break into or damage your vehicle.

To stop the alarm, press any button on the wireless remote control.

Vehicles with a smart key system

When is pressed for longer than about one second, an alarm will

sound intermittently and the vehicle lights will flash to deter any person from trying to break into or damage your vehicle.

To stop the alarm, press any button on the electronic key.

■ Security feature

If a door is not opened within approximately 60 seconds after the vehicle is unlocked, the security feature automatically locks the vehicle again.

■ Alarm

Using the wireless remote control to lock the doors will set the alarm system. (→P. 116)

4RUNNER_U

1-2. Opening, closing and locking th e do o r s

■ Conditions affecting operation

Vehicles without a smart key system

The wireless remote control function may not operate normally in the following situations:

● Near a TV tower, radio station, electric power plant, airport or other facil-

ity that generates strong radio waves

● When carrying a portable radio, cellular phone or other wireless commu-

nication devices

● When multiple wireless keys are in the vicinity

● When the wireless key is in contact with, or is covered by, a metallic

object

● When a wireless key (that emits radio waves) is being used nearby

● When the wireless key has been left near an electrical appliance such as

a personal computer

Vehicles with a smart key system

→P. 43

■ If the wireless remote control does not operate properly (vehicles with

a smart key system)

Locking and unlocking the doors: Use the mechanical key. (→P. 621)

■ Key battery depletion

Vehicles without a smart key system

If the wireless remote control function does not operate, the battery may be depleted. Replace the battery when necessary. (→P. 552)

Vehicles with a smart key system

→P. 46

■ When the electronic key battery is fully depleted

→P. 552

■ When riding in an aircraft

When bringing a key with wireless remote control function onto an aircraft, make sure you do not press any buttons on the key while inside the aircraft cabin. If you are carrying the key in your bag etc, ensure that the buttons are not likely to be pressed accidentally. Pressing a button may cause the key to emit radio waves that could interfere with the operation of the aircraft.

Before driving

4RUNNER_U

1-2. Opening, closing and locking the doors

■ Customization that can be configured at Toyota dealer

Settings (e.g. wireless remote control system) can be changed. (Customizable features →P. 660)

■ Certification for wireless remote control

For vehicles sold in the U.S.A.

FCC ID: HYQ14ACX FCC ID: HYQ13CZD FCC ID: HYQ14ADF FCC ID: HYQ13CZE FCC ID: HYQ12BBY FCC ID: HYQ13BDC NOTE:

FCC WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

For vehicles sold in Canada

4RUNNER_U

1-2. Opening , closing and locki ng the doors

Side doors

The vehicle can be locked and unlocked using the entry function, wireless remote control, key or door lock switch.

■ Entry function (vehicles with a smart key system)

→P. 35

■ Wireless remote control

→P. 49

■ Key

Turning the key operates the doors as follows:

Vehicles without a smart key system

Locks all the doors Unlocks all the doors

Turning the key unlocks the driver's door. Turning the key again unlocks the other doors.

Vehicles with a smart key system

The doors can also be locked and unlocked with the mechanical key. (→P. 621)

Before driving

4RUNNER_U

1-2. Opening, closing and locking the doors

■ Door lock switch

CTH12AS013

■ Inside lock buttons

Locks all the doors Unlocks all the doors

Locks the door Unlocks the door

The front doors can be opened by pulling the inside handle even if the lock buttons are in the lock position.

CTH12AS014

4RUNNER_U

1-2. Opening, closing and locking th e do o r s

Locking the doors from the outside without a key

STEP

Move the inside lock button to the lock position.

STEP

Close the door.

Vehicles without a smart key system

The door cannot be locked if either of the front doors is open and the key is in the engine switch.

Vehicles with a smart key system

The door cannot be locked if the “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode, or the electronic key is left inside the vehicle.

The key may not be detected correctly and the door may be locked.

Rear door child-protector lock

The door cannot be opened from inside the vehicle when the lock is set.

Before driving

CTH12AS015

These locks can be set to prevent children from opening the rear doors. Push down on each rear door switch to lock both rear doors.

4RUNNER_U

1-2. Opening, closing and locking the doors

Automatic door locking and unlocking systems

The following functions can be set or canceled:

Function Operation

Shift position linked door locking function

Shift position linked door unlocking function

Speed linked door locking function

Driver's door linked door unlocking function (

vehicles without a

smart key system Driver's door linked door

unlocking function

vehicles with a smart

( key system

)

Shifting the shift lever out of P locks all the doors.

Shifting the shift lever to P unlocks all the doors.

All

the

doors are locked when the vehicle speed is approximately 12 mph (20 km/h) or higher.

All

the

doors are unlocked when the driver's door is opened within 10 seconds after turning the engine switch to “ACC” or “LOCK”.

All

the

doors are unlocked when the driver's door is opened within 10 seconds after turning the “ENGINE START STOP” switch off.

■ Setting and canceling the functions

To switch between setting and canceling, follow the procedure below:

STEP

Vehicles without a smart key system

Close all the doors and turn the engine switch to the “ON” position. (Perform step 2 within 20 seconds.)

Vehicles with a smart key system

Close all the doors and turn the “ENGINE START STOP” switch to IGNITION ON mode. (Perform step 2 within 20 seconds.)

4RUNNER_U

1-2. Opening, closing and locking th e do o r s

STEP

Function

Shift position linked door locking function

Shift position linked door unlocking function

Speed linked door lo cking function

Driver's door linked door unlocking function

CTH12AS016

Shift the shift lever to P or N, and press and hold the driver's door lock switch (

or ) for

approximately 5 seconds and then release.

The shift lever and switch positions corresponding to the desired function to be set are shown in the following table.

Use the same procedure to cancel the function.

Shift lever

position

Driver’s door lock

switch position

Before driving

When the setting or canceling operation is complete, all the doors are locked and then unlocked.

■ Using the mechanical key (vehicles with a smart key system)

The doors can also be locked and unlocked with the mechanical key. (→P. 621)

■ Customization that can be configured at Toyota dealer

Settings (e.g. door unlocking function) can be changed. (Customizable features →P. 660)

4RUNNER_U

1-2. Opening, closing and locking the doors

CAUTION

■ To prevent an accident

Observe the following precautions while driving the vehicle. Failure to do so may result in a door opening and an occupant falling out, resulting in death or serious injury.

● Always use a seat belt.

● Always lock all the doors.

● Ensure that all doors are properly closed.

● Do not pull the inside handle of the doors while driving.

The doors may be opened and the passengers are thrown out of the vehicle and it may result in serious injury or death.

Be especially careful for the front doors, as the doors may be opened even if the inside lock buttons are in locked position.

● Set the rear door child-protector locks when children are seated in the rear

seats.

4RUNNER_U

1-2. Opening , closing and locki ng the doors

Automatic running boards

The Automatic running boards are linked to the side door operations, extending and retracting when a side door is opened and closed. When a door is opened or closed, the board on the same side extends or retracts.

∗

Opening a door: The appropriate board extends Closing a door: The appropriate board retracts

Before driving

CTH12AS059

4RUNNER_U

∗: If equipped

1-2. Opening, closing and locking the doors

Turning off the Automatic running boards system

Press “OFF” on the Automatic running boards switch to turn off the Automatic running boards system.

On (Automatic mode) Off

The orange line at the top of the switch illuminates to indicate that the Automatic running boards system is on.

When extension of the boards is

CTH12AS056

not necessary, or extension of a board is not desirable due to an obstacle, turn the Automatic running boards switch off before opening the side door.

■ Jam protection function

During Automatic running boards operation: If a board contacts an obstacle when extending, it will retract. If an obstacle

gets caught between a board and the vehicle when retracting, the board will extend.

If an obstacle is detected 3 times in a row during Automatic running boards operation, the board will stop at the position it contacts the obstacle. When a side door on the same side as the board is opened and closed one more time, the board will extend and retract, or retract and extend. After this, the board will resume normal operation.

4RUNNER_U

1-2. Opening, closing and locking th e do o r s

■ Automatic retraction function

The boards will be automatically retracted, for safety, under the following conditions:

● A board is not completely retracted

● Vehicle speed is approximately 5 mph (8 km/h) or higher

The boards will not automatically extend again when vehicle speed returns to less than 5 mph (8 km/h).

■ If the Automatic running boards indicator comes on when driving first

commences

A board has not completely retracted. Check that no obstacles are caught between a board and the vehicle.

■ If the Automatic running boards indicator light flashes

There may be a malfunction in the Automatic running boards system. Have the vehicle inspected by your Toyota dealer immediately.

■ When snow or mud is attached to the board or the board is frozen

The Automatic running boards may not operate correctly. Before stepping on a board, check that it is completely extended. If the Automatic running boards are not operating correctly, turn the Automatic running boards switch off and refrain from use.

When removing snow or mud, turn the Automatic running boards switch off.

■ After recharging/reconnecting the battery

If the Automatic running boards have not completely extended or retracted, the boards may not move in the intended direction the first time they are operated. However, from the second time onwards, the boards will resume normal operation.

■ When getting in and out of the vehicle

Take care because clothes and shoes may become dirty due to contact with the lower part of the vehicle body.

Before driving

4RUNNER_U

1-2. Opening, closing and locking the doors

CAUTION

■ Jam protection function

Observe the following precautions. Failure to do so may cause serious injury.

Never use any part of your body to intentionally activate the jam protection function.

The jam protection function may not work depending on the shape of the object that is caught. Be careful not to get fingers or other body parts caught.

■ Cautions regarding the Automatic running boards

Observe the following precautions. Failure to do so may cause serious injury.

● Check to make sure that all passengers and people in the vehicle’s sur-

rounding area do not have a hand on a board or any part of their body in a position where it could be caught between a board and the vehicle when an Automatic running board is being operated.

● Confirm that the boards have completely extended or retracted before get-

ting in or out of the vehicle. If someone gets in or out of the vehicle during Automatic running board operation, the boards may stop extending or retracting.

● Drive the vehicle after confirming that the boards have completely

retracted. Driving with a board extended is dangerous because it may hit other people or objects.

● Take care when pressing the Automatic running boards switch. The board

will extend or retract and may hit other people or objects.

● Always check that the Automatic running boards switch is turned off when

cleaning a board.

● Do not allow children to operate the Automatic running boards.

Operating Automatic running boards in a manner so that a board contacts someone can cause serious injury, and in some instances, even death.

4RUNNER_U

1-2. Opening , closing and locki ng the doors

Back door

The back door can be locked/unlocked and opened by the following procedures:

■ Locking and unlocking the back door

Entry function (vehicles with a smart key system)

→P. 36

Wireless remote control

→P. 49

Door lock switch

→P. 54

Keys (vehicles without a smart key system)

Unlocks all the doors Opens the back window

(turn and hold) (→P. 101) Locks all the doors Closes the back window

(turn and hold) (→P. 101)

Before driving

CTH12AS018

■ Opening the back door from outside the vehicle

Back door opener

Raise the back door while pushing up the back door opener switch.

CTH12AS038

4RUNNER_U

1-2. Opening, closing and locking the doors

Rear step bumper

CTH12AS019

■ When closing the back door

Lower the back door using the back door handle, and make sure to push the back door down from the outside to close it.

The rear step bumper is intended for rear end protection and easier step-up loading.

CTH12AS029

■ Luggage compartment lights

Each luggage compartment light has the following 3 positions:

Turns the light off Turns the light on Turns the light on/off linked to back

door position

CTH12AS054

If the luggage compartment lights remain on when the back door is not fully closed and the luggage compartment light switch is in the “DOOR” position, the lights will go off automatically after 20 minutes.

■ If the back door opener is inoperative or the battery is discharged

→P. 620

4RUNNER_U

1-2. Opening, closing and locking th e do o r s

CAUTION

■ Caution while driving

● Keep the back door closed.

If the back door is left open, it may hit nearby objects while driving or luggage may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a serious health hazard. Make sure to close the back door before driving.

● Before driving the vehicle, make sure that the back door is fully closed. If

the back door is not fully closed, it may open unexpectedly while driving, causing an accident.

● Never let anyone sit in the luggage compartment. In the event of sudden

braking or a collision, they are susceptible to death or serious injury.

● Do not get on the rear step bumper.

■ When children are in the vehicle

Observe the following precautions. Failure to do so may result in death or serious injury.

● Do not leave children alone in the luggage compartment.

If a child is accidentally locked in the luggage compartment, they could have heat exhaustion.

● Do not allow a child to open or close the back door.

Doing so may cause the back door to move unexpectedly, or cause the child’s hands, head, or neck to be caught by the closing back door, which may result in death or serious injury of the child.

■ Operating the back door

Observe the following precautions. Failure to do so may cause parts of the body to be caught, resulting in death or serious injury.

● Remove any heavy loads, such as snow and ice, from the back door

before opening it. Failure to do so may cause the back door to fall closed again after it is opened.

Before driving

4RUNNER_U

1-2. Opening, closing and locking the doors

CAUTION

● When opening or closing the back door, thoroughly check to make sure

the surrounding area is safe.

● If anyone is in the vicinity, make sure they are safe and let them know that

the back door is about to open or close.

● Use caution when opening or closing the back door in windy weather as it

may move abruptly in strong wind.

● The back door may fall if it is not

opened fully. It is more difficult to open or close the back door on an incline than on a level surface, so beware of the back door unexpectedly opening or closing by itself. Make sure that the

CTH12AS035

CTH12AS037

back door is fully open and secure before using the luggage compartment.

● When closing the back door, take extra

care to prevent your fingers etc. from being caught.

● When closing the back door, make sure

to press it lightly on its outer surface. If the back door handle is used to fully close the back door, it may result in hands or arms being caught.

● Do not pull on the back door damper stay to close the back door, and do

not hang on the back door damper stay. Doing so may cause hands to be caught or the back door damper stay to break, causing an accident.

● If a bicycle carrier or similar heavy object is attached to the back door, it

may fall closed again after being opened, causing someone’s hands, head or neck to be caught and injured. When installing an accessory part to the back door, using a genuine Toyota part is recommended.

4RUNNER_U

1-2. Opening, closing and locking th e do o r s

NOTICE

■ To prevent damage to the back door components

Do not allow more than one person to get on the rear step bumper at a time.

■ Back door damper stays

The back door is equipped with damper stays that hold the back door in place.

Observe the following precautions. Failure to do so may cause damage to the back door damper stay, resulting in malfunction.

● Do not attach any foreign objects, such

as stickers, plastic sheets, or adhesives to the damper stay rod.

● Do not touch the damper stay rod with

gloves or other fabric items.

CTH12AS036

● Do not attach any accessories other

than genuine Toyota parts to the back door.

● Do not place your hand on the damper

stay or apply lateral forces to it.

Before driving

4RUNNER_U

1-3. Adjustable components (seats, mirrors, steering w heel)

Front seats

Manual seat

Seat position adjustment lever

Vertical height adjustment lever (driver’s side only)

Seatback angle adjustment lever

Lumber support adjustment switch (driver’s side only)

CTH13AS055

4RUNNER_U

Power seat

1-3. Adjustable components (seats, mirrors, steering wheel)

Seat position adjustment switch

Seatback angle adjustment switch

Seat cushion (front) angle adjustment switch (driver’s side only)

Vertical height adjustment switch (driver’s side only)

Lumber support adjustment switch (driver’s side only)

CTH13AS010

Before driving

Active head restraints

When the occupant’s lower back presses against the seatback during a rear-end collision, the head restraint moves slightly forward and upward to help reduce the risk of whiplash to the seat occupant.

CTH13AS011

4RUNNER_U

1-3. Adjustable components (seats, mirrors, steering wheel)

■ The auto away function for exiting the driver seat

If the seat is already close to the rearmost position, the auto away function may not operate when the driver exits the vehicle.

■ Active head restraints

Even small forces applied to the seatback may cause the head restraint to move. Pushing up a locked head restraint forcibly may appear the head restraint inner structure. These do not indicate problems.

During rear-end collision

Inner structure

4RUNNER_U

CTH13AS012

1-3. Adjustable components (seats, mirrors, steering wheel)

CAUTION

■ Seat adjustment

● To reduce the risk of sliding under the lap belt during a collision, do not

recline the seat more than necessary. If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces directly to the abdomen, or your neck may contact the shoulder belt, increasing the risk of death or serious injury in the event of an accident. Adjustments should not be made while driving as the seat may unexpectedly move and cause the driver to lose control of the vehicle.

● After adjusting the seat, make sure that the seat is locked in position.

Before driving

4RUNNER_U

1-3. Adjustable components (seats, mirro rs, steering w heel)

Rear seats

Vehicles without third row seats

■ Rear seat

Pull up the seatback angle adjustment lever until the lock is released.

CTH13AS081

4RUNNER_U

1-3. Adjustable components (seats, mirrors, steering wheel)

Vehicles with third row seats

■ Second row seats

Seat position adjustment lever

Seatback angle adjustment lever

CTH13AS053

■ Third row seats

The third row seats do not have a seat adjustment function.

Before driving

4RUNNER_U

1-3. Adjustable components (seats, mirrors, steering wheel)

Folding down the rear seats (vehicles without third row seats)

■ Before folding down the rear seats

STEP

Adjust the head restraints to the downmost position.

Fold down the head restraints.

When returning the head restraints to their original positions, make sure they are locked securely.

Stow the rear seat belt buckles.

4RUNNER_U

1-3. Adjustable components (seats, mirrors, steering wheel)

■ Folding down the rear seats

STEP

Swing the bottom cushions up by pulling the lock release strap.

When returning the rear seat cushions to their original positions, make sure they are locked securely.

STEP

Push the lock release button and fold down the seatbacks.

To return the rear seatbacks to their original positions, lift them up until they lock.

■ Folding down rear center seatback only

Pull the center seatback angle lever behind the seatback and fold the seatback down.

Before driving

4RUNNER_U

To return the rear center seatback to its original position, lift it up until it locks.

1-3. Adjustable components (seats, mirrors, steering wheel)

Folding down the second row seats (vehicles with third row seats)

■ Before folding down the second row seats

STEP

Adjust the head restraints to the downmost position.

CTH13AS045

Stow the second row seat belt buckles.

CTH13AS071

4RUNNER_U

1-3. Adjustable components (seats, mirrors, steering wheel)

■ Folding down the second row seats

Pull the seatback lock release lever and fold the seatback down.

To return the second row seatbacks to their original positions, lift them up until they lock.

CTH13AS051

■ Folding down the second row center seatback only

Pull the center seatback angle lever behind the seatback and fold the seatback down.

To return the second row center seatback to its original position, lift it up until it locks.

Before driving

CTH13AS052

4RUNNER_U

1-3. Adjustable components (seats, mirrors, steering wheel)

Moving a second row seat for access to the third row seats (vehicles with third row seats)

■ Getting in the vehicle (right side only)

Pull up the lever and fold down the seatback. The seat will slide forward.

Move the seat to the front-most position.

CTH13AS057

■ Getting out of the vehicle (right side only)

Lift the lever on the back of the seatback and fold down the seatback. The seat will slide forward.

Move the seat to the front-most position.

CTH13AS058

■ After passengers have entered/exited the vehicle

Lift up the seatback and slide the seat backward until it locks.

4RUNNER_U

1-3. Adjustable components (seats, mirrors, steering wheel)

Folding down the third row seats (vehicles with third row seats)

■ Before folding down the third row seats

Pass the seat belts through the seat belt hangers and secure the seat belt plates.

CTH13AS072

■ Folding down the third row seats

From inside

STEP

Pull the strap to fold down the head restraint.

CTH13AS025

STEP

Pull the lever up.

Before driving

This prevents the shoulder belts from being damaged.

Make sure that the seat belts are removed from the hangers before using them.

4RUNNER_U

The seat cushion will slide backward.

CTH13AS026

1-3. Adjustable components (seats, mirrors, steering wheel)

STEP

From outside

STEP

Pull the lever to unlock the seatback and then fold the seatback down.

CTH13AS027

Pull the strap to fold down the head restraint.

CTH13AS028

Pull the lever up.

The seat cushion will slide backward and the seatback will be unlocked.

STEP

4RUNNER_U

CTH13AS029

CTH13AS064

Fold the seatback down.

1-3. Adjustable components (seats, mirrors, steering wheel)

■ Returning the third row seats

As the seat cushions cannot be pulled forward from outside, this operation can only be performed from inside.

STEP

Raise the seatbacks to their orig-

inal positions.

Make sure they are locked securely.

CTH13AS061

CTH13AS062

Pull the seat cushions forward.

Raise the head restraints.

Before driving

4RUNNER_U

CTH13AS063

1-3. Adjustable components (seats, mirrors, steering wheel)

CAUTION

■ When folding the rear seatbacks down

Observe the following precautions. Failure to do so may result in death or serious injury.

● Do not fold the seatbacks down while driving.

● Stop the vehicle on level ground, set the parking brake and shift the shift

lever to P.

● Do not allow anyone to sit on a folded seatback or in the luggage compart-

ment while driving.

● Do not allow children to enter the luggage compartment.

■ Seat adjustment

To reduce the risk of sliding under the lap belt during a collision, do not recline the seat more than necessary. If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces directly to the abdomen, or your neck may contact the shoulder belt, increasing the risk of death or serious injury in the event of an accident. Adjustments should not be made while driving as the seat may unexpectedly move and cause the driver to lose control of the vehicle.

■ After returning the rear seatback to the upright position

Observe the following precautions. Failure to do so may result in death or serious injury.

● Make sure the seatback is securely locked by pushing it forward and rear-

ward on the top.

● Check that the seat belts are not twisted or caught in the seatback.

NOTICE

■ Stowing the seat belts

The seat belts and the buckles must be stowed before you fold down the rear seatbacks.

4RUNNER_U

1-3. Adjustable components (seats, mirro rs, steering w heel)

Head restraints

Head restraints are provided for all seats.

■ Adjusting the head restraints

Front and second seats

Pull the head restraints up.

Down

Lock release button

CTH13AS031

■ Folding the head restraints

Second seats (vehicles without third row seats)

Push the head restraint down while pushing the lock release button.

To use To fold

Before driving

Third seats (vehicles with third row seats)

4RUNNER_U

CTH13AS082

To use To fold

CTH13AS034

1-3. Adjustable components (seats, mirrors, steering wheel)

■ Removing the head restraints (except third row seats)

Pull the head restraint up while pressing the lock release button.

CTH13AS036

■ Installing the head restraints (except third row seats)

Align the head restraint with the installation holes and push it down to the lock position.

Press and hold the lock release button when lowering the head restraint.

CTH13AS037

■ Adjusting the height of the head restraints

Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears.

CTH13AS035

■ Adjusting the second center seat head restraint

Always raise the head restraint one level from the stowed position when using.

4RUNNER_U

1-3. Adjustable components (seats, mirrors, steering wheel)

CAUTION

■ Head restraint precautions

Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury.

● Use the head restraints designed for each respective seat.

● Adjust the head restraints to the correct position at all times.

● After adjusting the head restraints, push down on them and make sure

they are locked in position.

● Do not drive with the head restraints removed.

Before driving

4RUNNER_U

1-3. Adjustable components (seats, mirro rs, steering w heel)

Seat belts

Make sure that all occupants are wearing their seat belts before driving the vehicle.

■ Correct use of the seat belts

● Extend the shoulder belt so

that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.

CTH13AS038

● Position the lap belt as low as possible over the hips.

● Adjust the position of the seatback. Sit up straight and well back in the seat.

● Do not twist the seat belt.

■ Fastening and releasing the seat belt

To fasten the seat belt, push the plate into the buckle until a click sound is heard.

To release the seat belt, press the release button.

Release button

CTH13AS083

4RUNNER_U

1-3. Adjustable components (seats, mirrors, steering wheel)

■ Adjusting the seat belt shoulder anchor height (front seats)

Push the seat belt shoulder anchor down while pressing the release button.

Push the seat belt shoulder anchor up.

Move the height adjuster up

CTH13AS084

and down as needed until you hear a click.

Seat belt pretensioners (front seats)

The pretensioner helps the seat belt to quickly restrain the occupant by retracting the seat belt when the vehicle is subjected to certain types of severe frontal and side collision or a vehicle rollover.

CTH13AS041

The pretensioner may not activate in the event of a minor frontal or side impact or a rear impact.

Before driving

4RUNNER_U

1-3. Adjustable components (seats, mirrors, steering wheel)

■ Emergency locking retractor (ELR)

The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.

■ Automatic locking retractor (ALR)

When a passenger's shoulder belt is completely extended and then retracted even slightly, the belt is locked in that position and cannot be extended. This feature is used to hold the child restraint system (CRS) firmly . To free the belt again, fully retract the belt and then pull the belt out once more. (→P. 146)

■ Pregnant women

Obtain medical advice and wear the seat belt in the proper way. (→P. 86)

Women who are pregnant should position the lap belt as low as possible over the hips in the same manner as other occupants. Extend the shoulder belt completely over the shoulder and position the belt across the chest. Avoid belt contact over the rounding of the abdominal area.

If the seat belt is not worn properly, not only the pregnant woman, but also the fetus could suffer death or serious injury

CTH13AS085

as a result of sudden braking or a collision.

■ People suffering illness

Obtain medical advice and wear the seat belt in the proper way. (→P. 86)

4RUNNER_U

1-3. Adjustable components (seats, mirrors, steering wheel)

■ Child seat belt usage

The seat belts of your vehicle were principally designed for persons of adult size.

● Use a child restraint system appropriate for the child, until the child

becomes large enough to properly wear the vehicle’s seat belt. (→P. 142)

● When the child becomes large enough to properly wear the vehicle’s

seat belt, follow the instructions on P. 86 regarding seat belt usage.

■ Replacing the belt after the pretensioner has been activated

If the vehicle is involved in multiple collisions, the pretensioner will activate for the first collision, but will not activate for the second or subsequent collisions.

■ Seat belt extender

If your seat belts cannot be fastened securely because they are not long enough, a personalized seat belt extender is available from your Toyota dealer free of charge.

Before driving

CTH13AS044

4RUNNER_U

1-3. Adjustable components (seats, mirrors, steering wheel)

CAUTION

Observe the following precautions to reduce the risk of injury in the event of sudden braking, sudden swerving or an accident. Failure to do so may cause death or serious injury.

■ Wearing a seat belt

● Ensure that all passengers wear a seat belt.

● Always wear a seat belt properly.

● Each seat belt should be used by one person only. Do not use a seat belt

for more than one person at once, including children.

● Toyota recommends that children be seated in the rear seat and always

use a seat belt and/or an appropriate child restraint system.

● To achieve a proper seating position, do not recline the seat more than

necessary. The seat belt is most effective when the occupants are sitting up straight and well back in the seats.

● Do not wear the shoulder belt under your arm.

● Always wear your seat belt low and snug across your hips.

■ When children are in the vehicle

Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious injuries that could result in death. If this occurs and the buckle cannot be unfastened, scissors should be used to cut the belt.

■ Seat belt pretensioners

● Do not place anything, such as a cushion, on the front passenger's seat.

Doing so will disperse the passenger's weight, which prevents the sensor from detecting the passenger's weight properly. As a result, the seat belt pretensioner for the front passenger's seat may not activate in the event of a collision.

● If the pretensioner has activated, the SRS warning light will come on. In

that case, the seat belt cannot be used again and must be replaced at your Toyota dealer.

4RUNNER_U

1-3. Adjustable components (seats, mirrors, steering wheel)

CAUTION

■ Adjustable shoulder anchor

Always make sure the shoulder belt is positioned across the center of your shoulder. The belt should be kept away from your neck, but not falling off your shoulder. Failure to do so could reduce the amount of protection in an accident and cause death or serious injuries in the event of a sudden stop, sudden swerve or accident. (→P. 87)

■ Seat belt damage and wear

● Do not damage the seat belts by allowing the belt, plate, or buckle to be

jammed in the door.

● Inspect the seat belt system periodically. Check for cuts, fraying, and loose

parts. Do not use a damaged seat belt until it is replaced. Damaged seat belts cannot protect an occupant from death or serious injury.

● Ensure that the belt and plate are locked and the belt is not twisted.

If the seat belt does not function correctly, immediately contact your Toyota dealer.

● Replace the seat assembly, including the belts, if your vehicle has been

involved in a serious accident, even if there’s no obvious damage.

● Do not attempt to install, remove, modify, disassemble or dispose of the

seat belts. Have any necessary repairs carried out by your Toyota dealer. Inappropriate handling of the pretensioner may prevent it from operating properly, resulting in death or serious injury.

■ Using a seat belt extender

● Do not wear the seat belt extender if you can fasten the seat belt without

the extender.

● Do not use the seat belt extender when installing a child restraint system

because the belt will not securely hold the child restraint system, increasing the risk of death or serious injury in the event of an accident.

● The personalized extender may not be safe on another vehicle, when

used by another person, or at a different seating position other than the one originally intended.

Before driving

4RUNNER_U

1-3. Adjustable components (seats, mirrors, steering wheel)

NOTICE

■ When using a seat belt extender

When releasing the seat belt, press on the buckle release button on the extender, not on the seat belt. This helps prevent damage to the vehicle interior and the extender itself.

4RUNNER_U

1-3. Adjustable components (seats, mirro rs, steering w heel)

Steering w heel

The steering wheel can be adjusted to a comfortable position.

STEP

Hold the steering wheel and push the lever down.

CTH13AS007

STEP

Adjust to the ideal position by moving the steering wheel horizontally and vertically.

After adjustment, pull the lever up to secure the steering wheel.

CTH13AS008

CAUTION

■ Caution while driving

Do not adjust the steering wheel while driving. Doing so may cause the driver to mishandle the vehicle and cause an accident, resulting in death or serious injury.

■ After adjusting the steering wheel

Make sure that the steering wheel is securely locked. Otherwise, the steering wheel may move suddenly, possibly causing an accident, and resulting in death or serious injury.

Before driving

4RUNNER_U

1-3. Adjustable components (seats, mirro rs, steering w heel)

Inside rear view mirror

Glare from the headlights of vehicles behind can be reduced by using the following functions:

Manual anti-glare inside rear view mirror (if equipped)

Normal position Anti-glare position

CTH13AS001

Auto anti-glare inside rear view mirror (if equipped)

In automatic mode, sensors are used to detect the headlights of vehicles behind and the reflected light is automatically reduced.

Turns automatic mode on/off

CTH13AS054

The indicator comes on when automatic mode is turned on.

Vehicles without a smart key system

The mirror will revert to the automatic mode each time the engine switch is turned to the “ON” position.

Vehicles with a smart key system

The mirror will revert to the automatic mode each time the “ENGINE START STOP” switch is turned to IGNITION ON mode.

4RUNNER_U

1-3. Adjustable components (seats, mirrors, steering wheel)

Adjusting the height of rear view mirror

Adjust the height of the rear view mirror by moving it up and down.

CTH13AS074

■ To prevent sensor error (vehicles with auto anti-glare inside rear view

mirror)

To ensure that the sensors operate properly, do not touch or cover them.

Before driving

CTH13AS088

CAUTION

■ Caution while driving

Do not adjust the position of the mirror while driving. Doing so may lead to mishandling of the vehicle and cause an accident, resulting in death or serious injury.

4RUNNER_U

1-3. Adjustable components (seats, mirro rs, steering w heel)

Outside rear view mirrors

Mirror angle can be adjusted using the switch.

STEP

Folding the mirrors

To select a mirror to adjust, press the switch.

Left Right

CTH13AS004

To adjust the mirror, press the switch.

Up Right Down Left

CTH13AS005

Push the mirror back in the direction of the vehicle's rear.

4RUNNER_U

CTH13AS006CTH13AS066

1-3. Adjustable components (seats, mirrors, steering wheel)

■ Mirror angle can be adjusted when

Vehicles without a smart key system

The engine switch is in the “ACC” or “ON” position.

Vehicles with a smart key system

The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode.

■ When the mirrors are fogged up

Turn on the mirror defoggers to defog the mirrors. (→P. 328)

CAUTION

■ When driving the vehicle

Observe the following precautions while driving. Failure to do so may result in loss of control of the vehicle and cause an accident, resulting in death or serious injury.

● Do not adjust the mirrors while driving.

● Do not drive with the mirrors folded.

● Both the driver and passenger side mirrors must be extended and properly

adjusted before driving.

■ When a mirror is moving

To avoid personal injury and mirror malfunction, be careful not to get your hand caught by the moving mirror.

■ When the mirror defoggers are operating

Do not touch the rear view mirror surfaces, as they can become very hot and burn you.

Before driving

4RUNNER_U

1-4. Opening and closing the window s and moon roof

Power windows

The power windows can be opened and closed using the switches.

Operating the switch moves the windows as follows:

Closing One-touch closing* Opening One-touch opening*

*: Pushing the switch in the

opposite direction will stop

CTH14AS010

Window lock switch

window travel partway.

Press the switch down to lock the passenger window switches and back window switch.

Use this switch to prevent children from accidentally opening or closing a passenger window and back window.

CTH14AS002

■ The power windows can be operated when

Vehicles without a smart key system

The engine switch is in the “ON” position.

Vehicles with a smart key system

The “ENGINE START STOP” switch is in IGNITION ON mode.

4RUNNER_U

1-4. Opening and closing the windows and moon roof

■ Operating the power windows after turning the engine off

Vehicles without a smart key system

The power windows can be operated for approximately 45 seconds even after the engine switch is turned to the “ACC” or “LOCK” position. They cannot, however, be operated once either front door is opened.

Vehicles with a smart key system

The power windows can be operated for approximately 45 seconds even after the “ENGINE START STOP” switch is turned to ACCESSORY mode or turned off. They cannot, however, be operated once either front door is opened.

■ Jam protection function

If an object becomes caught between the window and the window frame, window travel is stopped and the window is opened slightly.

■ When the power window does not close normally

If the jam protection function is operating abnormally and a window cannot be closed, perform the following operations using the power window switch on the relevant door.

● After stopping the vehicle, the window can be closed by holding the

power window switch in the one-touch closing position while the engine switch is turned to the “ON” position (vehicles without a smart key system) or the “ENGINE START STOP” switch is turned to IGNITION ON mode (vehicles with a smart key system).

● If the window still cannot be closed even by carrying out the operation

explained above, initialize the function by performing the following procedure.

STEP

Hold the power window switch in the one-touch closing position. Continue holding the switch for a further 6 seconds after the window has closed.

STEP

Hold the power window switch in the one-touch opening position. Continue holding the switch for a further 2 seconds after the window has opened completely.

Before driving

4RUNNER_U

1-4. Opening and closing the windows and moon roof

STEP

Hold the power window switch in the one-touch closing position once again. Continue holding the switch for a further 2 seconds after the window has closed.

If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after performing the above procedure correctly, have the vehicle inspected by your Toyota dealer.

■ Customization that can be configured at Toyota dealer

Settings (e.g. linked door lock operation) can be changed. (Customizable features →P. 660)

CAUTION

■ Closing the windows

Observe the following precautions. Failure to do so may result in death or serious injury.

● Check to make sure that all passengers do not have any part of their body

in a position where it could be caught when a window is being operated.

● Do not allow children to operate the power windows.

Closing a power window on someone can cause serious injury, and in some instances, even death.

■ Jam protection function

● Never use any part of your body to intentionally activate the jam protection

function.

● The jam protection function may not work if something gets caught just

before the window fully closes.

100

4RUNNER_U

1-4. Opening and closing the w indows and moon roof

Power back w indow

The power back window can be opened and closed using the switch or key.

From inside the vehicle

Closing One-touch closing* Opening One-touch opening*

*: Pressing the switch in the

opposite direction will stop window travel partway.

Before driving

CTH14AS019

From outside the vehicle (vehicles without a smart key system)

Opening Closing

Turn the key fully and hold it.

CTH14AS012

101

4RUNNER_U

1-4. Opening and closing the windows and moon roof

From outside the vehicle (vehicles with a smart key system)

Opening (push and hold) Closing (push and hold)

This operation can only be performed when the electronic key is within the detection range.

CTH14AS018

■ The power back window can be operated from inside the vehicle when

Vehicles without a smart key system

The engine switch is in the “ON” position.

Vehicles with a smart key system

The “ENGINE START STOP” switch is in IGNITION ON mode.

● The power back window can be opened when the rear window wiper is

working, but the wiper stops working until the window is closed again. If the power back window is not fully closed, the rear window wiper, washer, and defogger will not work.

● If the back door is not fully closed, the power back window cannot be

opened using the switch located in the cabin. (It is still possible to close the window.)

● If the back door is opened while the power back window is opening or

closing, window operation will stop.

■ The power back window can be operated from outside the vehicle

when (vehicles with a smart key system)

● The “ENGINE START STOP” switch is off.

● The back door is closed.

102

4RUNNER_U

1-4. Opening and closing the windows and moon roof

■ Operating the power back window from inside the vehicle after turning

the engine off Vehicles without a smart key system

The power back window can be operated for approximately 45 seconds even after the engine switch is turned to the “ACC” or “LOCK” position. It cannot, however, be operated once either front door is opened.

Vehicles with a smart key system

The power back window can be operated for approximately 45 seconds even after the “ENGINE START STOP” switch is turned to ACCESSORY mode or turned off. It cannot, however, be operated once either front door is opened.

■ Jam protection function

If an object becomes caught between the window and the window frame, window travel is stopped and the window is opened slightly.

■ When the power back window does not close normally

If the jam protection function is operating abnormally and a window cannot be closed, perform the following operations using the power back window switch.

● After stopping the vehicle, the window can be closed by holding the

power back window switch in the one-touch closing position while the engine switch is turned to the “ON” position (vehicles without a smart key system) or the “ENGINE ST AR T ST OP” switch is turned to IGNITION ON mode (vehicles with a smart key system).

● If the window still cannot be closed even by carrying out the operation

explained above, initialize the function by performing the following procedure.

STEP

Hold the power back window switch in the one-touch closing position. Continue holding the switch for a further 6 seconds after the window has closed.

STEP

Hold the power back window switch in the one-touch opening position. Continue holding the switch for a further 2 seconds after the window has opened completely.

STEP

Hold the power back window switch in the one-touch closing position once again. Continue holding the switch for a further 2 seconds after the window has closed.

Before driving

4RUNNER_U

103

1-4. Opening and closing the windows and moon roof

■ Customization that can be configured at Toyota dealer

Settings (e.g. linked operation) can be changed. (Customizable features →P. 660)

CAUTION

■ Caution while driving

Keep the back door and back window closed while driving. If the back door or the back window is left open, the back door may hit nearby objects while driving or luggage may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a serious health hazard. Make sure to close the back door and back window before driving.

■ Closing the power back window

Observe the following precautions. Failure to do so may result in death or serious injury.

● Check to make sure that all passengers do not have any part of their body

in a position where it could be caught when a window is being operated.

● Do not allow children to operate the power back window.

Closing a power back window on someone can cause serious injury, and in some instances, even death.

■ Jam protection function

● Never use any part of your body to intentionally activate the jam protection

function.

● The jam protection function may not work if something gets caught just

before the window fully closes.

104

4RUNNER_U

1-4. Opening and closing the w indows and moon roof

Moon roof

Use the overhead switches to open and close the moon roof and tilt it up and down.

∗

■ Opening and closing

Opens

the moon roof

■ Tilting up and down

CTH14AS020

CTH14AS008

The moon roof stops slightly before the fully open position to reduce wind noise.

Press the switch again to fully open the moon roof.

Closes

the moon roof

*: Lightly press the switch in

either direction to stop the moon roof partway.

Tilts the moon roof up* Tilts the moon roof down*

: Lightly press either of the

moon roof switches to stop the moon roof partway.

Before driving

4RUNNER_U

∗: If equipped

105

1-4. Opening and closing the windows and moon roof

■ The moon roof can be operated when

Vehicles without a smart key system

The engine switch is in the “ON” position.

Vehicles with a smart key system

The “ENGINE START STOP” switch is in IGNITION ON mode.

■ Operating the moon roof after turning the engine off

Vehicles without a smart key system

The moon roof can be operated for approximately 45 seconds even after the engine switch is turned to the “ACC” or “LOCK” position. It cannot, however, be operated once either front door is opened.

Vehicles with a smart key system

The moon roof can be operated for approximately 45 seconds even after the “ENGINE START STOP” switch is turned to ACCESSORY mode or turned off. It cannot, however, be operated once either front door is opened.

■ Jam protection function

If an object is detected between the moon roof and the frame while the moon roof is closing or tilting down, travel is stopped and the moon roof opens slightly.

■ To reduce moon roof wind noise

When the moon roof is opened automatically, it will stop slightly before the fully open position. Driving with the moon roof in this position can help reduce wind noise.

■ Sunshade

The sunshade can be opened and closed manually. However, the sunshade will open automatically when the moon roof is opened.

106

4RUNNER_U

1-4. Opening and closing the windows and moon roof

■ When the moon roof does not close normally

Perform the following procedure:

● If the moon roof closes but then re-opens slightly

STEP

Stop the vehicle.

STEP

Press and hold the “SLIDE (open/close)” switch in the close posi-

tion.* The moon roof will close, reopen and pause for approximately 10 seconds.*2 Then it will close again, tilt up and pause for approximately 1 second. Finally, it will tilt down, open and close.

STEP

Check to make sure that the moon roof is completely closed and then release the switch.

● If the moon roof tilts down but then tilts back up

STEP

Stop the vehicle.

STEP

Press and hold the “UP” switch*1 until the moon roof moves into the tilt up position and stops.

STEP

Release the “UP” switch once and then press and hold the “UP” switch again.*

The moon roof will pause for approximately 10 seconds in the tilt up position.*2 Then it will adjust slightly and pause for approximately 1 second. Finally, it will tilt down, open and close.

STEP

Check to make sure that the moon roof is completely closed and then release the switch.

*1: If the switch is released at the incorrect time, the procedure will have to

be performed again from the beginning.

: If the switch is released after the above mentioned 10 second pause,

automatic operation will be disabled. In that case, press and hold the “UP” or “DOWN” switch, and the moon roof will tilt up and pause for approximately 1 second. Then it will tilt down, open and close. Check to make sure that the moon roof is completely closed and then release the switch.

If the moon roof does not fully close even after performing the above procedure correctly, have the vehicle ins pected by your Toyota dealer.

Before driving

4RUNNER_U

107

1-4. Opening and closing the windows and moon roof

■ Moon roof open reminder function

Vehicles without a smart key system

An alarm will sound when the driver’s door is opened with the moon roof not fully closed and the engine switch off.

Vehicles with a smart key system

An alarm will sound when the driver’s door is opened with the moon roof not fully closed and the “ENGINE START STOP” switch off.

■ Customization that can be configured at Toyota dealer

Settings (e.g. linked door lock operation) can be changed. (Customizable features →P. 660)

CAUTION

■ Opening the moon roof

Observe the following precautions. Failure to do so may cause death or serious injury.

● Do not allow any passengers to put their hands or heads outside the vehi-

cle while it is moving.

● Do not sit on top of the moon roof.

■ Closing the moon roof

Observe the following precautions. Failure to do so may result in death or serious injury.

● Check to make sure that all passengers do not have any part of their body

in a position where it could be caught when the moon roof is being operated.

● Do not allow children to operate the moon roof.

Closing the moon roof on someone can cause death or serious injury.

■ Jam protection function

● Never use any part of your body to intentionally activate the jam protection

function.

● The jam protection function may not work if something gets caught just

before the moon roof fully closes.

108

4RUNNER_U

1-5. Refuel ing

Opening the fuel tank cap

Perform the following steps to open the fuel tank cap:

■ Before refueling the vehicle

Vehicles without a smart key system

Turn the engine switch off and ensure that all the doors and windows are closed.

Vehicles with a smart key system

Turn the “ENGINE START STOP” switch off and ensure that all the doors and windows are closed.

■ Opening the fuel tank cap

Before driving

STEP

CTH15AS001

Open the fuel filler door.

Turn the fuel tank cap slowly to open.

CTH15AS002

4RUNNER_U

109

1-5. Refueling

STEP

Closing the fuel tank cap

Hang the fuel tank cap on the back of the fuel filler door.

CTH15AS003

After refueling, turn the fuel tank cap until you hear a click. Once the cap is released, it will turn slightly in the opposite direction.

CTH15AS004

110

4RUNNER_U

1-5. Refueling

CAUTION

■ When refueling the vehicle

Observe the following precautions while refueling the vehicle. Failure to do so may result in death or serious injury.

● After exiting the vehicle and before opening the fuel door, touch an

unpainted metal surface to discharge any static electricity. It is important to discharge static electricity before refueling because sparks resulting from static electricity can cause fuel vapors to ignite while refueling.

● Always hold the grips on the fuel tank cap and turn it slowly to remove it.

A whooshing sound may be heard when the fuel tank cap is loosened. Wait until the sound cannot be heard before fully removing the cap. In hot weather, pressurized fuel may spray out the filler neck and cause injury.

● Do not allow anyone that has not discharged static electricity from their

body to come close to an open fuel tank.

● Do not inhale vaporized fuel.

Fuel contains substances that are harmful if inhaled.

● Do not smoke while refueling the vehicle.

Doing so may cause the fuel to ignite and cause a fire.

● Do not return to the vehicle or touch any person or object that is statically

charged. This may cause static electricity to build up, resulting in a possible ignition hazard.

■ When refueling

Securely insert the fuel nozzle into the fuel filler neck. If fuel is added with the nozzle slightly lifted away from the fuel filler neck, the automatic shut off function may not operate, resulting in fuel overflowing from the tank.

■ When replacing the fuel cap

Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.

Before driving

4RUNNER_U

111

1-5. Refueling

NOTICE

■ Refueling

Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the emission control system to operate abnormally or damaging fuel system components or the vehicle's painted surface.

112

4RUNNER_U

1-6. Theft deterrent system

Engine immobilizer system

The vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously registered in the vehicle’s on-board computer.

Never leave the keys inside the vehicle when you leave the vehicle.

CTH16AS004

Vehicles without a smart key system

The indicator light flashes after the key has been removed from the engine switch to indicate that the system is operating.

The indicator light stops flashing after the registered key has been inserted into the engine switch to indicate that the system has been canceled.

Vehicles with a smart key system

The indicator light flashes after the “ENGINE START STOP” switch has been turned off to indicate that the system is operating.

Before driving

4RUNNER_U

The indicator light stops flashing after the “ENGINE START STOP” switch has been turned to ACCESSORY or IGNITION ON mode to indicate that the system has been canceled.

113

1-6. Theft deterrent system

■ System maintenance

The vehicle has a maintenance-free type engine immobilizer system.

■ Conditions that may cause the system to malfunction

● If the grip portion of the key is in contact with a metallic object

● If the key is in close proximity to or touching a key to the security system

(key with a built-in transponder chip) of another vehicle

■ Certifications for the engine immobilizer system (vehicles without a

smart key system)

● For vehicles sold in the U.S.A.

FCC ID: MOZRI-33BTY This device complies with Part 15 of the FCC Rules. Operation is subject to

the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

● For vehicles sold in Canada

Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

114

4RUNNER_U

1-6. Theft deterrent system

CAUTION

■ Certifications for the immobilizer system

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

NOTICE

■ To ensure the system operates correctly

Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed.

Before driving

4RUNNER_U

115

1-6. Theft deterrent system

Alarm

The system sounds the alarm and flashes the lights when forced entry is detected.

∗

■ Triggering of the alarm

The alarm is triggered in the following situations when the alarm is set:

● A locked door is unlocked or opened in any way other than using the entry function, wireless remote control or mechanical key. (The doors will lock again automatically.)

● The hood is opened.

■ Setting the alarm system

Close the doors and hood, and lock all the doors. The system will be set automatically after 30 seconds.

The indicator light changes from being on to flashing when the system is set.

CTH16AS004

■ Deactivating or stopping the alarm

Do one of the following to deactivate or stop the alarms:

● Unlock the doors.

● Start the engine. (The alarm will be deactivated or stopped

after a few seconds.)

116

∗: If equipped

4RUNNER_U

1-6. Theft deterrent system

■ System maintenance

The vehicle has a maintenance-free type alarm system.

■ Items to check before locking the vehicle

To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following:

● Nobody is in the vehicle.

● The windows and moon roof are closed before the alarm is set.

● No valuables or other personal items are left in the vehicle.

■ Triggering of the alarm

The alarm may be triggered in the following situations: (Stopping the alarm deactivates the alarm system.)

● A person inside the vehicle opens a

door or the hood.

Before driving

CTH16AS006

● The battery is recharged or replaced

when the vehicle is locked.

CTH16AS007

■ Alarm-operated door lock

● When the alarm is operating, the doors are locked automatically to pre-

vent intruders.

● Do not leave the key inside the vehicle when the alarm is operating, and

make sure the key is not inside the vehicle when recharging or replacing the battery.

117

4RUNNER_U

1-6. Theft deterrent system

NOTICE

■ To ensure the system operates correctly

Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed.

118

4RUNNER_U

1-7. Safety information

Correct driving posture

Drive with a good posture as follows:

Sit upright and well back in the seat. (→P. 68)

Adjust the position of the seat forward or backward to ensure the pedals can be reached and easily depressed to the extent required. (→P. 68)

Adjust the seatback so that the controls are easily operable.

Adjust the tilt and telescopic positions of the steering wheel downward so the airbag is facing your chest. (→P. 93)

Lock the head restraint in place with the center of the head restraint closest to the top of your ears. (→P. 83)

Wear the seat belt correctly. (→P. 86)

Before driving

4RUNNER_U

119

1-7. Safety information

CAUTION

■ While driving

● Do not adjust the position of the driver’s seat.

Doing so could cause the driver to lose control of the vehicle.

● Do not place a cushion between the driver or passenger and the seatback.

A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.

● Do not place anything under the front seats.

Objects placed under the front seats may become jammed in the seat tracks and stop the seat from locking in place. This may lead to an accident, resulting in death or serious injury. The adjustment mechanism may also be damaged.

■ Adjusting the seat position

● Take care when adjusting the seat position to ensure that other passen-

gers are not injured by the moving seat.

● Do not put your hands under the seat or near the moving parts to avoid

injury. Fingers or hands may become jammed in the seat mechanism.

120

4RUNNER_U

1-7. Safety information

SRS airbags

The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury.

Before driving

SRS front airbags

SRS driver airbag/front passenger airbag Can help protect the head and chest of the driver a nd front passenger from impact with interior components

SRS knee airbags Can help provide driver and front passenger protection

SRS side and curtain shield airbags

SRS side airbags Can help protect the torso of the front seat occupants

SRS curtain shield airbags Can help protect primarily the head of occupants in the outer seats

CTH17AS103

121

4RUNNER_U

1-7. Safety information

SRS airbag system components

Side airbags “AIR BAG ON” and “AIR BAG

OFF” indicator lights Curtain shield airbags Front passenger airbag Knee airbags Side and curtain shield airbag

sensors Front airbag sensors Airbag sensor assembly Front passenger’s seat belt

buckle switch

CTH17AS100

Occupant detection system (ECU and sensors)

Curtain shield airbag sensors SRS warning light and

“RSCA OFF” indicator light Roll sensing of curtain shield

airbags off switch Floor sensor Driver airbag Driver’s seat belt buckle

switch

122

4RUNNER_U

1-7. Safety information

Your vehicle is equipped with ADVANCED AIRBAGS designed based on the US motor vehicle safety standards (FMVSS208). The airbag system controls airbag deployment power for the driver and front passenger. The driver airbag system consists of the driver’s seat belt buckle switch etc. The front passenger’s airbag system consists of the front passenger occupant classification sensor etc.

The main SRS airbag system components are shown above. The SRS airbag system is controlled by the airbag sensor assembly. The airbag sensor assembly consists of a safing sensor and an airbag sensor.

In certain types of severe frontal or side impacts, the SRS airbag system triggers the airbag inflators. A chemical reaction in the inflators quickly fills the airbags with non-toxic gas to help restrain the motion of the occupants.

■ If the SRS airbags deploy (inflate)

● Bruising and slight abrasions may result from contact with a deploying

(inflating) SRS airbag.

● A loud noise and white powder will be emitted.

● Parts of the airbag module (steering wheel hub, airbag cover and inflator)

as well as the front seats, parts of the front and rear pillars, and roof side rails, may be hot for several minutes. The airbag itself may also be hot.

● The windshield may crack.

● For Safety Connect subscribers, if the SRS airbags deploy or in the event

of a severe rear-end collision, the system is designed to send an emergency call to the response center, notifying them of the vehicle’s location (without needing to push the “SOS” button) and an agent will attempt to speak with the occupants to ascertain the level of emergency and assistance required. If the occupants are unable to communicate, the agent automatically treats the call as an emergency and helps to dispatch the necessary emergency services. (→P. 493)

Before driving

4RUNNER_U

123

1-7. Safety information

■ SRS airbag deployment conditions (SRS front airbags)

● The SRS front airbags will deploy in the event of an impact that exceeds

the set threshold level (the level of force corresponding to an approximately 12 - 18 mph [20 - 30 km/h] frontal collision with a fixed wall that does not move or deform).

However, this threshold velocity will be considerably higher if the vehicle strikes an object, such as a parked vehicle and sign pole, which can move or deform on impact, or if the vehicle is involved in an underride collision (e.g. a collision in which the front of the vehicle “underrides”, or goes under, the bed of a truck etc.).

● It is possible that in some collisions where the forward deceleration of the

vehicle is very close to the designed threshold level, the SRS front airbags and the seat belt pretensioners may not activate together.

● The SRS front passenger airbag will not activate if there is no passenger

sitting in the front passenger seat. However, the front passenger airbag may deploy, if luggage is put in the seat, even if the seat is unoccupied.

■ SRS airbag deployment conditions (SRS side airbags)

The SRS side airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to the impact force produced by an approximately 3300 lb. [1500 kg] vehicle colliding with the vehicle cabin from a direction perpendicular to the vehicle orientation at an approximate speed of 12 - 18 mph [20 - 30 km/h]).

■ SRS airbag deployment conditions (SRS curtain shield airbags)

The SRS curtain shield airbags will deploy in the event of vehicle rollover or an impact that exceeds the set threshold level (the level of force corresponding to the impact force produced by an approximately 3300 lb. [1500 kg] vehicle colliding with the vehicle cabin from a direction perpendicular to the vehicle orientation at an approximate speed of 12 - 18 mph [20 - 30 km/h]).

124

4RUNNER_U

1-7. Safety information

■ Conditions under which the SRS airbags may deploy (inflate), other

than a collision

The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration.

● Hitting a curb, edge of pavement or

hard surface

● Falling into or jumping over a deep hole

● Landing hard or falling

CTH17AS150

The SRS curtain shield airbags may also deploy under the situations shown in the illustration.

● The angle of vehicle tip-up is marginal.

● The vehicle skids and hits a curb stone.

Before driving

■ Types of collisions that may not deploy the SRS airbags (SRS front air-

bags)

The SRS front airbags are generally not designed to inflate if the vehicle is involved in a side or rear collision, if it rolls over, or if it is involved in a lowspeed frontal collision. But, whenever a collision of any type causes sufficient forward deceleration of the vehicle, deployment of the SRS front airbags may occur.

● Collision from the side

● Collision from the rear

● Vehicle rollover

CTH17AS151

125

4RUNNER_U

1-7. Safety information

■ Types of collisions that may not deploy the SRS airbags

(SRS side airbags and curtain shield airbags)

The SRS side airbag and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.

● Collision from the side to the vehicle

body other than the passenger compartment

● Collision from the side at an angle

The SRS side airbags are not generally designed to inflate if the vehicle is involved in a frontal or rear collision, if it rolls over, or if it is involved in a lowspeed side collision.

● Collision from the front

● Collision from the rear

● Vehicle rollover

CTH17AS147

The SRS curtain shield airbags are not generally designed to inflate if the vehicle is involved in a frontal or rear collision, if it pitches end over end, or if it is involved in a low-speed side collision.

● Collision from the front

● Collision from the rear

● Pitching end over end

CTH17AS148

126

4RUNNER_U

1-7. Safety information

■ When to contact your Toyota dealer

In the following cases, contact your Toyota dealer as soon as possible.

● Any of the SRS airbags have been inflated.

CTH17AS078

CTH17AS149

● The front of the vehicle is damaged or

deformed, or was involved in an accident that was not severe enough to cause the SRS airbags to inflate.

● A portion of a door is damaged or

deformed, or the vehicle was involved in an accident that was not severe enough to cause the SRS side airbags and curtain shield airbags to inflate.

● The pad section of the steering wheel,

dashboard near the front passenger airbag or lower portion of the instrument panel is scratched, cracked, or otherwise damaged.

● The surface of the seats with the side

airbag is scratched, cracked, or otherwise damaged.

● The portion of the front and rear pillar

garnish, or roof interior containing the curtain shield airbags inside is scratched, cracked or otherwise damaged.

Before driving

4RUNNER_U

127

1-7. Safety information

CAUTION

■ SRS airbag precautions

Observe the following precautions regarding the SRS airbags. Failure to do so may cause death or serious injury.

● The driver and all passengers in the vehicle must wear their seat belts

properly. The SRS airbags are supplemental devices to be used with the seat belts.

● The SRS driver airbag deploys with considerable force, and can cause

death or serious injury especially if the driver is very close to the airbag. The National Highway Traffic Safety Administration (NHTSA) advises:

Since the risk zone for the driver’s airbag is the first 2 - 3 in. (50 - 75 mm) of inflation, placing yourself 10 in. (250 mm) from your driver airbag provides you with a clear margin of safety . This dist ance is measured from the center of the steering wheel to your breastbone. If you sit less than 10 in. (250 mm) away now, you can change your driving position in several ways:

• Move your seat to the rear as far as you can while still reaching the pedals comfortably.

• Slightly recline the back of the seat. Although vehicle designs vary, many drivers can achieve the 10 in. (250 mm) distance, even with the driver seat all the way forward, simply by reclining the back of the seat somewhat. If reclining the back of your seat makes it hard to see the road, raise yourself by using a firm, non-slippery cushion, or raise the seat if your vehicle has that feature.

• If your steering wheel is adjustable, tilt it downward. This points the airbag toward your chest instead of your head and neck.

The seat should be adjusted as recommended by NHTSA above, while still maintaining control of the foot pedals, steering wheel, and your view of the instrument panel controls.

128

4RUNNER_U

CAUTION

■ SRS airbag precautions

1-7. Safety information

● If the seat belt extender has been con-

nected to the driver's seat belt buckle but the seat belt extender has not also been fastened to the latch plate of the driver's seat belt, the SRS driver airbag system will judge that the driver is

CTH17AS014

wearing the seat belt even though the seat belt has not been connected. In this case, the SRS driver airbag may not activate correctly in a collision, resulting in death or serious injury in the event of a collision. Be sure to wear the seat belt with the seat belt extender.

● The SRS front passenger airbag also deploys with considerable force, and

can cause death or serious injury especially if the front passenger is very close to the airbag. The front passenger seat should be as far from the airbag as possible with the seatback adjusted, so the front passenger sits upright.

● Improperly seated and/or restrained infants and children can be killed or

seriously injured by a deploying airbag. An infant or child who is too small to use a seat belt should be properly secured using a child restraint system. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat. (→P. 142)

Before driving

4RUNNER_U

129

1-7. Safety information

CAUTION

■ SRS airbag precautions

● Do not sit on the edge of the seat or

lean against the dashboard.

CTH17AS015

● Do not allow a child to stand in front of

the SRS front passenger airbag unit or sit on the knees of a front passenger.

● Do not allow the front seat occupants to

hold items on their knees.

CTH17AS016

● Do not lean against the door, the roof

side rail or the front and rear pillars.

130

4RUNNER_U

CTH17AS137

● Do not allow anyone to kneel on the

passenger seat toward the door or put their head or hands outside the vehicle.

CTH17AS018

Toyota 4Runner 2012 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
