Totally wicked Touch User Manual

USER MANUAL

CONGRATULATIONS
ON PURCHASING YOUR

TOTALLY WICKED
TOUCH
ELECTRONIC
CIGARETTE KIT

THE TOTALLY WICKED TOUCH

Mouthpiece

Sliding top
Filling hole

Atomizer head

Tank base

Touch battery

Power button

Touchscreen

Reset button

3

QUICK START GUIDE USING YOUR TOTALLY WICKED TOUCH

If you are familiar with using e-cigarettes, follow the quick start guide
below to be vaping in minutes:

• Prime the atomizer head.

• Fill the tank.

• Switch the Totally Wicked Touch on (5 clicks of the power button).

• Set the power to 12 watts

• Press and hold the power button and inhale

• Charge the battery (possibly not shipped with a full charge).

Detailed descriptions of these steps and more are given on the following pages.

PRIMING

It is important to “prime” a
new atomizer head before

rst use. Failure to do so

can cause the atomizer
coil to overheat, resulting
in a burnt taste and
sometimes irreversible
damage to the atomizer
head requiring early

replacement.

Unscrew and remove the
tank from the battery and

invert. Unscrew the base

of the tank and prime the
atomizer head by dripping
a few drops of e-liquid
into the central hole of

the atomizer head. After

priming the atomizer head,
screw the base back onto
the tank, and screw the

tank back onto the battery.

4 5

USING YOUR TOTALLY WICKED TOUCH USING YOUR TOTALLY WICKED TOUCH

FILLING

Slide the top cap open by pushing rmly in the

direction indicated by the arrow on the top cap to

expose the ll hole. Insert the lling nozzle into the
ll hole and ll the tank, being careful to leave an air
gap of approximately 2mm. Slide the top cap shut
after lling.

Note: After priming a new atomizer head and

lling the tank with e-liquid, it is recommended
to wait 5 minutes to ensure the atomizer head is
fully saturated with e-liquid.

SWITCHING ON AND OFF

Switch the Totally Wicked Touch on by

quickly pressing the power button ve

times, the screen will illuminate, indicating
the Totally Wicked Touch has been

switched on. Quickly press the power
button ve times to switch the Totally
Wicked Touch o.

CHARGING THE BATTERY

The Totally Wicked Touch is charged by
connecting the charge port on the battery
to a USB port or suitable wall adaptor with

the supplied charging lead. The battery
icon will begin to ash onscreen. The

temperature at charging will be displayed

on screen. Once the device reaches
100%, the charging icon will stop ashing.

6 7

USING YOUR TOTALLY WICKED TOUCH USING YOUR TOTALLY WICKED TOUCH

SETTING THE WATTAGE

The Totally Wicked Touch has
adjustable wattage that can

be set from 1 – 80 watts. To

adjust the wattage, press the
power button 3 times, this
will unlock the left and right
touch sensitive adjustment

buttons. Tap or hold the left

or right adjustment button
to decrease/increase the

wattage respectively.

RESETTING THE DEVICE

If the Totally Wicked Touch
becomes unresponsive,
the reset button is located

below the power button.

To reset the Totally Wicked
Touch, use a small pin to
press the reset button,

the screen will ash

-

momentarily and normal

vaping will resume.

+

Reset

VAPING

Press and hold the power button as you
inhale the vapour, the screen will display

a pu timer.

ADJUSTING AIRFLOW

If you nd the air ow too airy or too tight
while vaping, rotate the airow control
ring located on the tank base. Experiment
by rotating the air ow control ring to nd
your preferred setting.

E-LIQUID LEVEL

To prevent the atomizer head from
becoming dry and burning prematurely,
ensure the amount of e-liquid inside the

Totally Wicked Touch EX tank does not

drop below the feed holes located on the

sides of the atomizer head.

8 9

USING YOUR TOTALLY WICKED TOUCH USING YOUR TOTALLY WICKED TOUCH

ATOMIZER HEAD LIFESPAN

Atomizer heads do not last forever and

need to be periodically replaced. The

lifespan of an atomizer head can vary from

several days up to several weeks.

Factors aecting lifespan include wattage,
vaping style, avour and type of e-liquid.

Indicators that the atomizer head may
require replacement include a slight burnt
taste, general loss of vapour production

or a reduction in avour intensity.

REPLACING THE ATOMIZER HEAD

To install a new atomizer head follow the
process shown in the “PRIMING” section
of the manual, and uncscrew and replace

the atomizer head.

Reminder: After priming a new atomizer

head and lling the tank with e-liquid,
it is recommended to wait 5 minutes
to ensure the atomizer head is fully
saturated with e-liquid.

CLEANING AND MAINTENANCE

The Totally Wicked Touch battery can be
cleaned by wiping down with tissue or a

dry cloth. The Totally Wicked Touch EX

tank can be cleaned by removing it from
the battery, unscrewing the tank base
from the glass section of the tank then

removing the atomizer head.

The entire Totally Wicked Touch EX tank

and base can now be cleaned under hot

running water. Allow the tank to fully dry
before retting the atomizer head into the
tank base. Reassemble the tank.

Note: Do not attempt to clean the
atomizer head with water. Do not
submerge the Totally Wicked Touch
battery unit in water or allow it to get
wet.

10 11

SPECIFICATIONS KIT CONTENTS

Totally Wicked Touch battery

Dimensions: 83mm (height) x 42mm
(width) x 28mm (depth)

Weight: 147.5g

Battery Capacity: 4400mAh
Wattage Range: 1 – 80W

Voltage Range: 0.5 – 9V
Maximum Charge Current: 2.0A

Maximum Tank Diameter: 25mm
Thread Type: 510 connection

Atomizer Resistance Compatibility: 0.1
– 3.0ohm

Totally Wicked Touch EX tank

Dimensions: 22mm (diameter) x 43.5mm

(height)
Weight: 42g
Tank Capacity: 2ml

Atomizer Type: EX atomizer heads

Thread Type: 510 connection

Atomizer Head Resistance: 1.2ohm tted,

0.5ohm available as accessory
Airow Type: Bottom adjustable
Maximum Rell Nozzle Diameter: 3.5mm

Additional product information

1 x Totally Wicked Touch battery

1 x Totally Wicked Touch EX tank
1 x EX 1.2ohm atomizer head (tted)
1 x EX 1.2ohm atomizer head (spare)

1 x USB-C cable
1 x User manual
Spare parts

12 13

PRODUCT STORAGE AND BATTERY PRECAUTIONS WARRANTY

• Store the Totally Wicked Touch e-cigarette and its accessories away from children whilst

not in use.

• Please only use the charging cable provided.

• Please dispose of dead batteries in accordance with your country’s appropriate

legislation.

• Do not charge the battery in a damp environment, or in temperatures under 0°C or

above 45°C.

• Do not use the device in temperatures under -10°C or above 60°C.

• Do not carry batteries in a pocket or bag with other metallic objects.

• Do not attempt to repair a faulty Totally Wicked Touch battery as these are sealed units

with no serviceable parts. Attempted repairs will void the warranty.

Totally Wicked Touch components have a 28-day parts warranty with the exception of
atomizer heads which are consumable items and are covered by our ‘Dead on Arrival’

warranty only. The USB cable supplied has a 12-month warranty. If any parts are found to

be faulty within this time please contact our customer service team, whose details are on

the back page of this booklet and we will arrange for a replacement. We may require the
goods to be returned for further investigation.

ADDITIONAL PRODUCT INFORMATION

There are no reported medical side eects with this product. If you believe you experience
a side eect, please contact the manufacturer.

14 15
