OWNER'S MANUAL

Projection Television

Introduction

your TV

Connecting

Using the

Remote Control

46H84 46H84C 51H84 51H84C 57H84 57H84C

Owner's Record

The model number and serial number are on the back of your TV. Record these numbers in the spaces below. Refer to these numbers whenever you communicate with your Toshiba dealer about this TV.

Model:

your TV

Setting up

Features

Using the TV’s

Appendix

65H84

Serial No.:

Index

23566304

Dear Customer,

Thank you for purchasing this Toshiba TV. This manual will help you use the many exciting features of your new TV.

Before operating the TV, please read this manual completely, and keep it nearby for future reference.

Safety Precautions

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

WARNING

RISK OF ELECTRIC SHOCK

DO NOT OPEN

WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning symbol in the triangle tells you that the voltage inside this product may be strong enough to cause an electric shock. DO NOT TRY TO SERVICE THIS PRODUCT YOURSELF.

The exclamation mark in the triangle tells you that important operating and maintenance instructions follow this symbol.

NOTE TO CATV INSTALLERS IN THE USA

This is a reminder to call the CATV system installer’s attention to Article 820-40 of the NEC, which provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical. For additional antenna grounding information, see items 25 and 26 on page 4.

NOTICE OF POSSIBLE TV STAND INSTABILITY

DANGER: RISK OF SERIOUS PERSONAL INJURY OR DEATH! Use this TV with the TOSHIBA TV stand

recommended in the “Specifications” section only.

Use with other stands may result in instability, causing possible injury or death.

NOTICE OF POSSIBLE ADVERSE EFFECTS

ON TV PICTURE TUBE

If a fixed (non-moving) pattern remains on the TV screen for long periods of time, the image can become permanently engrained in the picture tube. This type of damage is NOT COVERED BY YOUR WARRANTY. See item 33 on page 4.

ENERGY STAR® qualified TV. Products that earn the ENERGY STAR prevent green house gas emissions by meeting strict energy efficiency guidelines set by the U.S. Environmental Protection Agency and the U.S. Department of Energy. ENERGY STAR and the ENERGY STAR mark are registered U.S. marks.

Child Safety

It Makes A Difference Where Your TV Stands

Congratulations on your purchase! As you enjoy your new TV, keep these safety tips in mind:

The Issue

 If you are like most consumers, you have a TV in your home.

Many homes, in fact, have more than one TV.

 The home theater entertainment experience is a growing

trend, and larger TVs are popular purchases; however, they are not always supported on the proper TV stands.

 Sometimes TVs are improperly secured or inappropriately

situated on dressers, bookcases, shelves, desks, audio speakers, chests, or carts. As a result, TVs may fall over, causing unnecessary injury.

Toshiba Cares!

 The consumer electronics industry

is committed to making home

entertainment enjoyable and safe.

 The Consumer Electronics

Association formed the Home

Entertainment Support Safety

Committee, comprised of TV and consumer electronics furniture

manufacturers, to advocate

children’s safety and educate

consumers and their families about

television safety.

Tune Into Safety

 One size does NOT fit all! Use appropriate

furniture large enough to support the weight of your

TV (and other electronic components).

 Use appropriate angle braces, straps, and anchors to secure

your furniture to the wall (but never screw anything directly into the TV).

 Carefully read and understand the other enclosed

instructions for proper use of this product.

 Do not allow children to climb on or play with furniture

and TVs.

 Avoid placing any item on top of your TV (such as a VCR,

remote control, or toy) that a curious child may reach for.

 Remember that children can become excited while watching

a program and can potentially push or pull a TV over.

 Share our safety message about this hidden hazard of

home with your family and friends. Thank you!

2500 Wilson Blvd. Arlington, VA 22201 U.S.A. Tel. 703-907-7600 Fax 703-907-7690 www.CE.org

CEA is the Sponsor, Producer and Manager of the International CES

the

2 0303

Important Safety Instructions

QUALIFIED

SERVICE

TECHNICIAN

Installation, Care, and Service

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near

water.

6) Clean only with a dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

Wide plug

Installation

Follow these recommendations and precautions and heed all warnings when installing your TV:

16) Never modify this equipment. Changes or modifications may void: a) the warranty, and b) the user’s authority to operate this equipment under the rules of the Federal Communications Commission.

17) DANGER: RISK OF SERIOUS PERSONAL

INJURY, DEATH, OR EQUIPMENT DAMAGE! Never place the TV on

an unstable cart, stand, or table. The TV may fall, causing serious personal injury, death, or serious damage to the TV.

18) Never place or store the TV in direct sunlight; hot, humid areas; areas subject to excessive dust or vibration; or locations with temperatures at or below 41°F (5°C).

19) Always place the TV on the floor or a sturdy, level, stable surface that can support the weight of the unit.

10) Protect the power cord from being

walked on or pinched, particularly at plugs, convenience receptacles, and the point where it exits the apparatus.

11) Only use attachments/accessories specified by the

manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use

caution when moving the cart/apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during

lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15) CAUTION: To reduce the risk of electric shock, do not use the polarized plug with an extension cord, receptacle, or other outlet unless the blades can be inserted completely to prevent blade exposure.

20) Never place items such as vases, aquariums, or candles on top of the TV.

21) Never block or cover the slots or openings in the TV cabinet back, bottom, and sides. Never place the TV:

• on a bed, sofa, rug, or similar

surface;

• too close to drapes, curtains,

or walls; or

• in a confined space such as a

bookcase, built-in cabinet, or any other place with poor ventilation.

The slots and openings are provided to protect the TV from overheating and to help maintain reliable operation of the TV.

22) Never allow anything to rest on or roll over the power cord, and never place the TV where the power cord is subject to wear or abuse.

23) Never overload wall outlets and extension cords.

0303 3

Ground clamp

Antenna discharge unit (NEC Section 810-20)

Grounding conductors (NEC Section 810-21)

Power service grounding electrode system (NEC Art 250 Part H)

Ground clamps

Antenna lead-in wire

Electric service equipment

QUALIFIED

SERVICE

TECHNICIAN

24) Always operate this equipment from a 120 VAC, 60 Hz power source only.

30) [This item applies to projection TVs only.] If the air temperature rises suddenly (for example, when the TV is first delivered), condensation may form on the lenses. This can make the picture appear distorted or the color appear faded. If this happens, turn off the TV for 6 to 7 hours to allow the condensation to evaporate.

25) Always make sure the antenna system is properly grounded to provide adequate protection against voltage surges and built-up static charges (see Section 810 of the National Electric Code).

26) DANGER: RISK OF SERIOUS PERSONAL

INJURY OR DEATH!

• Use extreme care to make sure you are never in

a position where your body (or any item you are in contact with, such as a ladder or screwdriver) can accidentally touch overhead power lines. Never locate the antenna near overhead power lines or other electrical circuits.

• Never attempt to install any of the following during lightning activity: a) an antenna system; or b) cables, wires, or any home theater component connected to an antenna or phone system.

31) For added protection of your TV from lightning and power surges, always unplug the power cord and disconnect the antenna from the TV if you leave the TV unattended or unused for long periods of time.

32) During normal use, the TV may make occasional snapping or popping sounds. This is normal, especially when the unit is being turned on or off. If these sounds become frequent or continuous, unplug the power cord and contact a Toshiba Authorized Service Center.

33) Possible Adverse Effects on TV Picture Tube: If a fixed (non-moving) pattern remains on the TV screen for long periods of time, the image can become permanently engrained in the picture tube and cause subtle but permanent ghost images. This type of damage is NOT COVERED BY YOUR WARRANTY. Never leave your TV on for long periods of time while it is displaying the following formats or images:

• Fixed Images, such as PIP/POP windows, stock tickers,

video game patterns, TV station logos, and websites.

• Special Formats that do not use the entire screen. For

example, viewing letterbox style (16:9) media on a normal (4:3) display (gray bars at top and bottom of screen); or viewing normal style (4:3) media on a widescreen (16:9) display (gray bars on left and right sides of screen).

Care

For better performance and safer operation of your TOSHIBA TV, follow these recommendations and precautions:

27) Always sit approximately 10–25 feet away from the TV and as directly in front of it as possible. The picture can appear dull if you sit too far to the left or right of the TV, or if sunlight or room lights reflect on the screen. Turn the TV off to check for reflections on the screen, and then remove the source of reflections while viewing the TV.

28) Always unplug the TV before cleaning. Never use liquid or aerosol cleaners.

29) WARNING: RISK OF ELECTRIC SHOCK!

4 0303

Never spill liquids or push objects of any kind into the TV cabinet slots.

Service

34) WARNING: RISK OF ELECTRIC SHOCK! Never attempt to service the

TV yourself. Opening and

removing the covers may expose you to dangerous voltage or other hazards. Refer all servicing to a Toshiba Authorized Service Center.

35) If you have the TV serviced:

• Ask the service technician to use only replacement parts

specified by the manufacturer.

• Upon completion of service, ask

the service technician to perform routine safety checks to determine that the TV is in safe operating condition.

36) When the TV reaches the end of its useful life, ask a

qualified service technician to properly dispose of the TV. Improper disposal may result in a picture tube implosion and possible personal injury.

Important Safety Precautions for Split Cabinet Feature

(Models 57H84 and 65H84 only)

Toshiba TV models 57H84 and 65H84 have a split cabinet feature that allows disassembly of the cabinet into two sections during installation.

For details, please refer to the insert titled “Disassembly/ Reassembly Instructions for Split Cabinet Feature” that accompanied this owner’s manual in the accessory pack. If you do not have the insert, you can download a copy of it from our Web site (www.toshiba.com/tacp in the U.S.A. or www.toshiba.ca in Canada). If you do not have access to the Internet, call 1-800-631-3811 in the U.S.A. or 1-800268-3404 in Canada.

WARNING: If you split the cabinet for any purpose, NEVER energize the bottom section until it is completely and properly installed.

Energizing the disassembled bottom section and subjecting it to intentional misuse (for example, exposing it to a foreign object) creates the potential for an electrical shock hazard that could result in death or serious injury.

CAUTION: If you use the split cabinet feature, ALWAYS

handle and treat the top section of the TV cabinet, which contains a glass mirror, with great care. If subjected to excessive mechanical abuse (for example, if bumped or dropped), the mirror may break, creating exposed glass fragments with sharp edges. Contact with these glass fragments may result in injury.

Installation, Care, and Service

CAUTION: The split cabinet feature (models 57H84 and

65H84 only) allows disassembly of the cabinet into two sections during installation. If you use the split cabinet feature, follow these precautions while the two sections of the TV cabinet are disassembled:

1) Always handle and treat the top section of the TV cabinet (with the viewing screen), which contains a glass mirror, with great care. If subjected to excessive mechanical abuse (for example, if bumped or dropped), the mirror may break, creating exposed glass fragments with sharp edges. Contact with these glass fragments may result in injury.

2) Never temporarily locate the disassembled bottom section in an area where it may be exposed to foreign objects or abuse (for example, areas where children may be playing, where items may fall on top of the unit, or where liquids may spill into the unit). Failure to follow this instruction may result in damage to the optic components of the TV. SUCH DAMAGE IS NOT COVERED UNDER THE TOSHIBA LIMITED WARRANTY.

3) Always keep the top and bottom sections of the TV cabinet in an upright position while disassembled. Failure to follow this instruction may result in damage to the TV, including but not limited to the optic components, cabinet, bezel, and glass mirror. SUCH DAMAGE IS NOT COVERED UNDER THE TOSHIBA LIMITED WARRANTY.

4) Never energize the bottom section of the TV cabinet

while disassembled. Failure to follow this instruction could result in death or serious injury.

5) Never place anything on top of the disassembled bottom section of the TV cabinet. Failure to follow this instruction may result in damage to the optic components. SUCH DAMAGE IS NOT COVERED UNDER THE TOSHIBA LIMITED WARRANTY.

6) Never store or transport the unit while it is disassembled. Failure to follow this instruction may result in damage to the TV, including but not limited to the optic components, cabinet, bezel, and glass mirror. SUCH DAMAGE IS NOT COVERED UNDER THE TOSHIBA LIMITED WARRANTY.

0303 5

Important Safety Information............................. 2-5

Introduction................................................................ 7

Welcome to Toshiba......................................................... 7

Exploring your new TV ................................................... 7

Connecting your TV .................................................. 8

Connecting a VCR .......................................................... 9

Connecting a cable converter box .................................... 9

Connecting a cable converter box and VCR................... 10

Connecting a DVD player or satellite receiver and

a VCR............................................................................ 11

Connecting a DVD player with ColorStream

(component video) and a VCR ...................................... 12

Connecting a DTV receiver/set-top box with ColorStream

(component video) and a VCR................ 13

Connecting two VCRs ................................................... 14

Connecting a camcorder ................................................ 14

Connecting a HDMI device to the HDMI input .......... 15

Connecting a DVI device to the HDMI input ............... 16

Connecting an audio system .......................................... 16

Using the remote control ...................................... 17

Preparing the remote control for use .............................. 17

Installing the remote control batteries ............................ 17

Programming the remote control to operate a cable converter box, satellite receiver, VCR, DVD player,

or HTIB (home theater in a box) ...................................18

Remote control codes .................................................... 18

Remote control codes (cont.) ......................................... 19

Using the remote control to operate a cable converter box, satellite receiver, VCR, DVD player, or HTIB

(home theater in a box) .................................................. 20

Learning about the remote control ................................. 21

Setting up your TV .................................................. 22

Learning about the menu system ................................... 22

Changing the on-screen display language ....................... 23

Selecting the antenna input............................................ 23

Adding channels to the TV’s memory ............................ 24

Programming channels automatically...................... 24

Adding and erasing channels manually.................... 25

Changing channels ........................................................ 25

Adjusting the color convergence..................................... 26

Automatically adjusting the color convergence

using TouchFocus™ ............................................... 26

Manually adjusting the color convergence............... 26

Using the TV’s features.......................................... 28

Adjusting the channel settings........................................ 28

Switching between two channels using Channel

Return .................................................................... 28

Switching between two channels using

SurfLock™............................................................. 28

Programming your favorite channels ....................... 28

Labeling channels ................................................... 30

Viewing the wide-screen picture formats

(480i, 480p and 1080i signals only) ............................31

Selecting the picture size ......................................... 31

Scrolling the Theater Wide picture

(Theater Wide 2 and 3 only) .................................. 33

Using the AUTO ASPECT feature ......................... 34

Using the POP double-window feature .......................... 35

Switching the main and POP pictures..................... 36

Switching the speaker sound of main and

POP programs ........................................................ 36

Double-Window aspect ratio .................................. 37

Using the programmed channel search function............. 37

Using the favorite channel search function .............. 38

About the auto favorite feature................................ 38

Using the LOCKS menu ............................................... 39

Entering the PIN code ............................................39

If you cannot remember your PIN code .................. 39

Using the V-CHIP menu ............................................... 39

ENABLE BLOCKING .......................................... 40

TV RATING (Independent rating system for

broadcasters) ........................................................... 40

MPAA RATING (Independent rating system for

movies) ................................................................... 41

BLOCKING OPTION.......................................... 41

Unlocking programs temporarily ............................ 42

Locking channels ........................................................... 42

Locking the video inputs................................................ 44

Changing the PIN code ................................................. 44

Adjusting the picture ..................................................... 45

Selecting the picture mode ......................................45

Adjusting the picture quality ................................... 45

Saving new preference ............................................. 46

Selecting the color temperature ...............................46

Using the CableClear™ DNR feature .................... 47

Resetting picture adjustments ................................. 47

Selecting the display format

(for 480p signal only) ............................................. 48

Selecting the cinema mode...................................... 48

Selecting the video input source .....................................49

Labeling the video input sources .................................... 49

Using the closed caption feature..................................... 50

Setting the ON timer ..................................................... 51

Setting the sleep timer.................................................... 51

Setting the clock ............................................................ 52

Adjusting the sound ....................................................... 53

Muting the sound ................................................... 53

Selecting stereo/SAP broadcasts .............................. 53

Using the WOW™ surround sound feature ........... 54

Adjusting the sound quality .................................... 54

Resetting your audio adjustments ........................... 55

Using the StableSound

feature .............................. 55

Turning off the built-in speakers ............................. 56

Selecting the Audio OUT sound............................. 56

Selecting the background of the menu display ............... 57

Displaying on-screen information .................................. 57

Understanding the auto power off feature ...................... 57

Understanding the last mode memory feature ................ 57

Appendix................................................................... 58

Specifications ................................................................. 58

Troubleshooting .............................................................59

Limited United States Warranty .....................................60

Limited Canada Warranty .............................................. 61

Index .......................................................................... 62

Introduction

Welcome to Toshiba

Congratulations! You have purchased one of the finest projection TVs on the market. The goal of this manual is to guide you through setting up and operating your Toshiba TV as quickly as possible.

This manual applies to models 46H84, 51H84, 57H84 and 65H84. Before you start reading, check the model and serial numbers on the back of your TV. Write these numbers in the space provided on the front cover of this manual for your records.

Instructions in this manual are based on using the remote control. You also can use the controls on the TV if they have the same name as those on the remote control.

Please read all the safety and operating instructions carefully, and keep the manual for future reference.

Exploring your new TV

You can operate your TV using the buttons on the front panel or the remote control. The back panel and front panel (behind the door) provide all the terminal connections you will need to connect other equipment to your TV. See “Connecting your TV” on page 8.

Illustrations represent 57H84.

Front

Back

Remote sensor

POWER

Power

indicator

(Behind the screen)

Volume x • Channel zy

VOLUME

CHANNEL

EXITMENU

EXIT TV/VIDEO

TouchFocus™

TouchFocus

TV/VIDEO

ANT OUT

ANT-2 IN

S-VIDEO

Video/audio inputs

(behind the door)

ANT-1 IN

L/MONO

VIDEO

Video 3

Please push TouchFocus

button after setup

Convergence may drift as a result of relocating or adjusting the position of the TV. The TV automatically adjusts color convergence by using the TouchFoucas™ system. After setting up your TV, it is recommended that you set the convergence by pressing TouchFoucus on the front panel . For instructions on manually adjusting the color convergence, see page 26.

Remote control

TV / VIDEO

123

456

AUDIO

+10

100

FAVORITE

ENTER

TV CBL/SAT VCR DVD

POP DIRECT CH MUTE SLEEP

TV/VCR PAUSE

FREEZE SOURCE

SWAP POP CH

CH SCAN

REC

RECALL

INFO

FAV

DVDMENU

FAV

VOLCH

STOP

FFREW

SKIP / SEARCH

POWER

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

Introduction

your TV

Connecting

Using the

Remote Control

your TV

Setting up

Features

Using the TV’s

VIDEO 1/2

ColorStream

HD1/HD2

HDMI IN

Variable Audio OUT

Audio OUT

Appendix

Index

Connecting your TV

Note: Cables are not supplied with your TV.

Introduction

your TV

Connecting

Using the

Remote Control

your TV

Setting up

●

Coaxial cable is the cable that comes in from your antenna, cable TV service, or cable converter box. Coaxial cable uses “F” connectors.

Standard A/V (audio/video) cables usually come in sets of three, and are typically color-coded according to use: yellow for video, red for stereo right audio, and white for stereo left (or mono) audio. On your TV’s back panel, the standard A/V inputs are color-coded in the same manner as the cables.

S-Video cable is for use with video equipment that has an S-Video input. Component video cables come in sets of three, and are for use with

video equipment that has component video inputs. (ColorStream

Toshiba’s brand of component video.) HDMI is for use with video equipment that has a HDMI type A

connector (see page 15).

NOTE REGARDING PICTURE QUALITY

When connecting video equipment to your Toshiba TV:

●

For GOOD picture quality: Use a standard yellow video cable.

●

For BETTER picture quality: input, use an S-video cable instead of a standard yellow video cable. (You still must connect the standard red and white audio cables for full system connection, but do not connect the standard yellow video cable at the same time, or the picture performance will be unacceptable.)

●

For BEST picture quality: If your equipment has component video (or HDMI) inputs, use either component video cables (or an HDMI cable) instead of a standard video or S-video cable. (You still must connect the standard red and white audio cables for full component video system connection. An HDMI connection does not require separate audio cables.)

If your equipment has an S-video

Coaxial (antenna) cable

Standard A/V cables (red/white/yellow)

S-video cable

Component video cables

HDMI cable

WARNING: RISK OF ELECTRIC SHOCK!

Do not plug in any power cords until you have finished connecting all equipment.

Features

Using the TV’s

Appendix

Index

This connection allows you to watch TV programs or basic cable channels.

From Antenna or Cable

Connecting a VCR

This connection allows you to watch local channels and video programs, play or record on the VCR while watching TV, and record from one channel while watching another channel.

You will need:

• two coaxial cables

• one set of A/V cables

From Cable Box or Antenna

Stereo VCR

IN from ANT OUT to TV CH 3

CH 4

VIDEO

OUT

AUDIO

Note:

If you have a mono VCR, connect L/Mono to VCR Audio OUT using only one audio cable.

If you have a VCR with S-video, use an Svideo cable (in the S-video jacks) instead of the standard video cable.

Do not connect a standard video cable and an S-video cable to Video-1 (or Video-2) at the same time, or the picture performance will be unacceptable.

The unauthorized recording, use, distribution, or revision of television programs, videotapes, DVDs, and other materials is prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability.

Introduction

your TV

Connecting

Using the

Remote Control

Connecting a cable converter box

This connection allows you to watch basic and premium cable channels To watch basic cable and use the TV’s features, select ANT-1. To view

premium channels, select ANT-2, tune the TV to channel 3 or 4 (whichever channel is vacant in your area), and use the converter box to change channels.

You will need:

• three coaxial cables

From Cable

INOUT

Note:

When you use a converter box with your TV, the remote control will not operate some features, such as programming your favorite channels, labeling channels, and locking channels.

your TV

Setting up

Features

Using the TV’s

Appendix

Cable converter box

Index

Connecting a cable converter box and VCR

This connection allows you to watch and record basic and premium cable channels, watch videotapes, and record one channel while

Introduction

your TV

Connecting

Using the

Remote Control

watching another channel. To watch basic cable and use the TV’s features, select ANT-1. To view premium channels or record with the VCR, select ANT-2, tune the TV and VCR to channel 3 or 4 (whichever channel is vacant in your area), and use the converter box to change channels.

You will need:

• four coaxial cables

• one set of A/V cables

From Cable

Note:

If you have a mono VCR, connect L/Mono to VCR Audio OUT using only one audio cable.

If you have a VCR with S-video, use an Svideo cable (in the S-video jacks) instead of a standard video cable. Do not connect a standard video cable and an S-video cable to Video-1 (or Video-2) at the same time, or the picture performance will be unacceptable.

When you use a converter box with your TV, the remote control will not operate some features, such as programming your favorite channels, labeling channels, and locking channels.

your TV

Setting up

Features

Using the TV’s

Appendix

IN from ANT OUT to TV CH 3

CH 4

Stereo VCR

VIDEO

OUT

AUDIO

INOUT

Cable converter box

Index

Connecting a DVD player or satellite receiver and a VCR

This connection allows you to watch DVD/satellite, VCR, and TV programs, and record one TV channel while watching another channel.

You will need:

• two (or three, if satellite receiver is used) coaxial cables

• one set of standard A/V cables (between the TV and VCR) (plus one additional set of standard A/V cables if satellite receiver is used)

• one S-video cable (between the TV and DVD player/satellite receiver)

• one pair of standard audio cables (between the TV and DVD player/satellite receiver)

Stereo VCR

OUT

AUDIO

From

Antenna

IN from ANT OUT to TV CH 3

CH 4

VIDEO

Note:

For the highest possible picture quality from a DVD player or satellite receiver without component video or HDMI, use an S-video cable. (If your DVD player has component video, see page 12. If your DVD player or satellite receiver has HDMI, see page 15.)

Do not connect both an S-video cable and a standard video cable between the TV and DVD player/satellite receiver at the same time or the picture performance will be unacceptable.

Do not connect the DVD player/satellite receiver and VCR to the same video channel on the TV. (See the illustrations, which show the DVD player/satellite receiver connected to Video-1 on the TV, and the VCR connected to Video-2 on the TV.)

Introduction

your TV

Connecting

Using the

Remote Control

your TV

Setting up

From

Satellite

Dish

IN from ANT

S-VIDEO

VIDEO

OUTOUT

VIDEO

OUTOUT

DVD Player

AUDIO

OUT

Satellite Receiver

AUDIO

OUT

Features

Using the TV’s

Appendix

Index

Connecting a DVD player with ColorStream (component video) and a VCR

This connection allows you to watch DVD, VCR, and TV programs,

Introduction

your TV

Connecting

Using the

Remote Control

your TV

Setting up

and record TV programs. Your TV has ColorStream

your TV to a DVD player with component video inputs (such as a Toshiba DVD player with ColorStream quality and realism.

– To record one TV program while watching another TV program,

– To record a TV program while watching a DVD, tune the VCR to

You will need:

(component video) inputs. Connecting

) can greatly enhance picture

tune the VCR to the channel to record, and tune the TV to the channel to watch.

the channel to record, and select ColorStream HD1 on the TV (see “Selecting the antenna input” on page 23).

• two coaxial cables

• one set of A/V cable

• one pair of audio cable

• one set of component video cables (one S-video cable for a DVD player without component video inputs; see notes at right)

From Antenna

Stereo VCR

IN from ANT OUT to TV CH 3

CH 4

VIDEO

OUT

AUDIO

Note:

For the highest possible picture quality, use component video cables (or a HDMI cable) between the TV and DVD player.

You can connect the component video cables to either set of the ColorStream jacks on the TV (HD1 or HD2).

For HDMI connection, see page 15. The ColorStream HD1/HD2 and HDMI jacks

can be used with Progressive (480p, 720p) and Interlaced (480i,1080i) scan systems; however, a 1080i signal will provide the best picture performance.

If your DVD player is not compatible with component video or HDMI, use the S-video connections (plus the standard audio connections) instead (see page 11).

Features

Using the TV’s

Appendix

Index

S-VIDEO

COMPONENT VIDEO

DVD player with component video

RPB

VIDEO

OUT

AUDIO

OUT

Connecting a DTV receiver/set-top box with

ColorStream

This connection allows you to watch DTV (digital TV), VCR, and TV programs, and record DTV and TV programs.

Your TV has ColorStream (component video) inputs. Connecting your TV to a DTV receiver with component video inputs can greatly enhance picture quality and realism.

– To record and watch a DTV program, select LINE IN on the

VCR, and select ColorStream HD2 (or VIDEO 1 for a nonColorStream connection) on the TV (see “Selecting the antenna input” on page 23).

– To record a TV program while watching a DTV program, tune the

VCR to the channel to record, and select ColorStream HD2 on the TV.

– To record and watch the same TV program, tune the VCR to the

channel to record, and select VIDEO 1 on the TV.

– To record one TV program while watching another TV program,

tune the VCR to the channel to record, and tune the TV to the channel to watch.

You will need:

• three coaxial cables

• two sets of A/V cables

• one pair of audio cables

• one set of component video cables (one S-video cable for a DTV receiver without component video; see notes at right)

From Antenna

(component video) and a VCR

Stereo VCR

Note:

For the highest possible picture quality, use component video cables (or a HDMI cable) between the TV and DTV receiver/set-top box.

You can connect component video cables to either set of ColorStream jacks on the TV (HD1 or HD2).

For HDMI connection, see page 15. The ColorStream HD1/HD2 and HDMI jacks

can be used with Progessive (480p, 720p) and Interlaced (480i, 1080i) scan systems; however, a 1080i signal will provide the best picture performance.

If your DTV receiver or set-top box is not compatible with component video or HDMI, use the S-video connections (plus the standard audio connections) instead (see page 11).

Introduction

your TV

Connecting

Using the

Remote Control

your TV

Setting up

From DTV Antenna

DTV Receiver with component video

IN from ANT OUT to TV CH 3

CH 4

Satelite IN

S-VIDEO

VIDEO

COMPONENT VIDEO

AUDIO

PRPBY

OUT

VIDEO

OUT

AUDIO

OUT

Features

Using the TV’s

Appendix

Index

Connecting two VCRs

This connection allows you to record (dub/edit) from one VCR to another VCR while watching a videotape. You can also record from

Introduction

your TV

Connecting

one TV channel while watching another TV channel. You will need:

• two coaxial cables

• two sets of A/V cables

From Antenna

VCR1

IN from ANT OUT to TV CH 3

CH 4

VIDEO

OUT

AUDIO

Note:

If you have VCRs with S-video, use S-video cables instead of standard video cables for better picture performance. Do not connect both a standard video cable and an S-video cable to Video-1 (or Video-2) at the same time, or the picture performance will be unacceptable.

Do not connect the same VCR to the output and input jacks on the TV at the same time. To dub or edit, VCR 2 must select Line IN, and the TV must select VIDEO 1 (see “Selecting the antenna input” on page 23).

* The Video OUT jack does not output the

POP picture.

** The Audio OUT jacks can output the sound

of either the Main or POP picture (see “Selecting the Audio OUT sound” on page

56).

Using the

Remote Control

your TV

Setting up

Features

Using the TV’s

VCR2

CH 3 CH 4

VIDEO AUDIO

OUT

Connecting a camcorder

This connection allows you to watch video materials recorded on a camcorder.

You will need:

• one set of A/V cables

Note:

If you have a camcorder with S-video, use an S-video cable instead of a standard video cable for better picture performance. Do not connect both a standard video cable and an S-video cable at the same time, or the picture performance will be unacceptable.

Appendix

Index

Camcorder

VIDEO

AUDIO

OUT

L/MONO

S-VIDEO

VIDEO

AUDIO

Video-3 (front panel)

Connecting a HDMI device to the HDMI input

HDMI1 (High Definition Multimedia Interface) is the first all digital consumer electronics A/V interface that supports an uncompressed standard. One jack supports both video and audio information. The HDMI input on your TV is designed to accept HDMI program material in digital form from EIA/CEA-861/861B–compliant consumer electronic devices, such as a set-top box or DVD player equipped with a HDMI or DVI output connection.

Applicable video signals

No. of dots (H

1080i 1920×1080i 59.94/60Hz 720p 1280×720p 59.94/60Hz

720×480p

480p 640×480p 59.94/60Hz 480i 720×480i 59.94/60Hz

Note: This TV is not intended for connection to and should not be used with a PC (personal computer).

××

×V) Vertical frequencies

××

You will need:

• one HDMI cable (this HDMI connecter is type A.)

Note: For proper operation, the HDMI cable length should not exceed 3m (9.8 ft). The recommended length is 2m (6.6 ft).

Notes:

HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

EIA/CEA-861/861B compliance covers the transmission of uncompressed digital video with high-bandwidth digital content protection, which is being standardized for future reception of high-definition video signals.

Consult your consumer electronics dealer for availability.

Caution:

To ensure that the HDMI device is reset properly, it is recommended that you follow these procedures:

• When turning on your electronic

components, turn on the TV first, and then the HDMI device.

• When turning off your electronic

components, turn off the HDMI device first, and then the TV.

Introduction

your TV

Connecting

Using the

Remote Control

HDMI device (for example, set top box or DVD player)

VIDEO AUDIO

OUT

HDMI OUT

your TV

Setting up

Features

Using the TV’s

Appendix

Index

Connecting a DVI device to the HDMI input

Introduction

your TV

Connecting

Using the

Remote Control

• one HDMI–DVI conversion cable

• one pair of standard audio cables

DVI device (for example, set-top box or DVD player)

VIDEO AUDIO

OUT

DVI

OUT

If the external device has DVI output only, use an HDMI–DVI conversion cable to connect to the HDMI jack on the TV. Also, connect the AUDIO OUT signal from the external device (set-top box or DVD player) to the AUDIO IN jacks next to the HDMI input.

Note:

• Some DVI or HDMI devices may not be available for this TV.

* If the AUDIO (analog) cable is connected,

the HDMI terminal does not output audio signals (digital).

your TV

Setting up

Features

Using the TV’s

Appendix

Connecting an audio system

This connection allows you to use external speakers connected to an audio amplifier and control volume levels with the TV.

To control the audio, turn on the TV and the stereo amplifier, and turn off the built-in speakers (see “Turning off the built-in speakers” on page 56).

You will need:

• one pair of audio cables

Note:

To hear sound when using an external audio amplifier, the volume of both the TV and the amplifier must be set above 0 (zero).

For example, if the volume of the TV is set to 0, you will not be able to hear any sound, even the volume of the amplifier is at its highest level.

Amplifier

LINE IN LR

Index

Using the remote control

Preparing the remote control for use

Your TV remote control can operate your TV and most cable converter boxes, satellite receivers, VCRs, DVD players, and HTIBs (home theater in a box), even if they are different brands.

If you have a Toshiba device:

Your TV remote control is preprogrammed to operate most Toshiba devices. See page 20.

If you have a non-Toshiba device or a Toshiba device that the remote control is not preprogrammed to operate:

You can program the TV remote control so it will operate the other device. See pages 18–20.

Installing the remote control batteries

1. Remove the battery cover from the back of the remote control.

Squeeze tab and lift cover.

2. Install two “AA” size batteries, making sure to match the + and – signs on the batteries to the signs on the battery compartment.

Caution:

• Dispose of batteries in a designated disposal area. Do not throw batteries into a fire.

• Attention should be drawn to the environmental aspects of battery disposal.

• Do not mix battery types or combine used batteries with new ones.

• If the remote control does not operate correctly, or if the operating range becomes reduced, replace both batteries with new ones.

• If the batteries are dead or if you will not use the remote control for a long time, remove the batteries to prevent battery acid from leaking into the battery compartment.

Introduction

your TV

Connecting

Using the

Remote Control

your TV

Setting up

3. Reinsert the battery cover in the remote control until the tab snaps.

Note:

If your Toshiba TV remote control does not operate all the features of your other device, use the original remote control for that device.

Features

Using the TV’s

Appendix

Index

Programming the remote control to operate a cable converter box, satellite receiver, VCR, DVD player, or HTIB (home theater in a box)

Introduction

your TV

Connecting

Using the

Remote Control

your TV

Setting up

Your Toshiba TV remote control is preprogrammed to operate most Toshiba devices. To program your TV remote control to operate a non-Toshiba device (or a Toshiba device that it is not preprogrammed to operate), follow the steps below. For details on using the remote control to operate the device, see page 20.

Remote control codes

In some cases you may not be able to operate your device with the TV

Features

Using the TV’s

remote control. Your other device may use a code that is not recognized by the TV remote control. If this happens, use the device’s remote control.

1. In the remote control code table (below and on the next page), find the code for your device. If more than one code is listed, try each one separately until you find one that works.

2. Set the Device Switch to the type of device you are programming the remote control to operate — CBL/SAT (for a cable converter box or satellite receiver), VCR (for a VCR or TV/VCR combo), or DVD (for a DVD player or HTIB [home theater in a box]).

3. While holding down RECALL, press the Channel Number buttons to enter the 3-digit code for your device.

4. To test the code, turn on the device, point the remote control at it, and press POWER. See notes at right.

• If the correct code was entered, the device will turn off.

• If the device does not respond, repeat steps 1 – 4 using another code.

• If the device does not respond to another code, you will need to use the remote control that came with the device.

Remember to set the Device Switch back to TV to control the TV.

6. For future reference, write down the code(s) you used:

DEVICE CODE DEVICE CODE

POWER

RECALL

TV / VIDEO

INFO

123

456

RECALL POWER

Channel

+10

100

FAVORITE

ENTER

TV CBL/SAT VCR DVD

POP DIRECT CH MUTE SLEEP

TV/VCR PAUSE

Note:

CH SCAN

• In addition to POWER, confirm that all

REC

FAV

DVDMENU

FAV

VOLCH

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

Number

Device Switch

necessary keys on the TV remote control operate your device. If some keys are not operational, repeat the device code setup using another code (if other codes are listed for your device). If, after trying all listed codes, the necessary keys do not operate your device, use the device’s original remote control.

• Every time you change the batteries, you will need to reprogram the remote control.

• Some newer VCRs respond to either of two codes. These VCRs have a switch labeled “VCR1/VCR2.” If your VCR has this kind of switch and does not respond to the codes for your VCR brand, set the switch to the other position (“VCR1” or “VCR2”) and reprogram the remote control.

Appendix

Index

Cable converter box

ABC: 061, 062, 063,

082, 084, 087, 091, 092, 096, 098

Archer: 065, 092, 097,

099 Cableview: 064, 094 Century: 092 Citizen: 090, 092, 097 Contec: 083, 085, 086,

088, 093, 098 Diamond: 093 Eagle: 091 GE: 061, 062 Gemini: 069, 070, 094 General Instruments:

062, 089, 096

Hamlin: 093 Hitachi: 062, 095, 096 Jasco: 097 Jerrold: 062, 069, 071,

082, 086, 089, 091,

096 Magnavox: 072, 096 Memorex: 091, 092, 104 Multi Canal: 090 Novavision: 101 Panasonic: 081, 083, 085 Philco: 087 Philips: 066, 067, 068,

070, 072, 073, 074,

075, 091, 092 Pioneer: 076, 077 Proscan: 061, 062 Radio Shack: 092, 097,

099

RCA: 064, 081 Realistic: 065 Recoton: 102 Samsung: 077, 090 Scientific Atlanta: 063,

078, 079, 080, 088,

098, 101, 105 Sears: 095 Signature: 062 Signature 2000: 096 Sprucer: 081, 085 Starcom: 069, 082, 087,

096, 103, 104 Stargate: 069, 090 Sylvania: 095, 100 TeleView: 090 Texscan: 100 Tocom: 071, 084, 085

U. S. Electronics: 087,

096, 098 United Cable: 082 Universal: 065, 092, 097,

099, 102, 103 Wards: 096

Satellite receiver

Alphastar: 038, 059 Chaparral: 034 DISH Network: 057 Drake: 020, 040, 044,

046, 050, 053 Echostar: 018, 041, 051 Express Vu: 057 Fujitsu: 027 GE: 008, 009, 013

General Instruments:

010, 011, 012, 022,

023, 031, 049 Hitachi: 033 Hughes: 033 Hughes Network

Systems: 019 Intersat: 048 Janeil: 027 JVC: 017, 057 Kenwood: 029 Magnavox: 060 Optimus: 058 Pansat: 036, 052 Primestar: 015, 042 Proscan: 008, 009, 013 Radio Shack: 022, 023,

030

Remote control codes (cont.)

Satellite receiver (cont.)

RCA: 008, 009, 013, 016 Realistic: 030 Samsung: 059 Sony: 014, 055 Star Choice: 057 Star Trak: 025, 026, 037,

054 STS: 024 Toshiba: 000, 001, 002,

003, 004, 005, 006,

007, 020, 031, 056 Uniden: 021, 028, 030,

032, 035, 039, 043,

045, 047, 058 Zenith: 027

TV/VCR Combo

Action: 078 GE: 059, 062 Goldstar: 065 Panasonic: 065 Precision: 078 Quasar: 065 Realistic: 079 Sony: 074 Toshiba: 057 Zenith: 065

DVD/VCR Combo

Go Video:

DVD=087, VCR=081 JVC:

DVD=088, VCR=082 RCA:

DVD=089, VCR=083 Samsung:

DVD=090, VCR=084 Sanyo:

DVD=091, VCR=085 Zenith:

DVD=092, VCR=086

DVD player

Aiwa: 006, 015 Apex: 016, 017 BOSE: 097 Broksonic: 018 Clarion: 019 Classic: 020 Daewoo: 021 Denon: 022, 023, 024,

025 Emerson: 026, 027 Fisher: 028 Funai: 027 GE: 001, 029, 030 Go Video: 087 GPX: 031

Hitachi: 005, 032, 033,

034, 035

JVC: 003, 007, 036,

042, 088 Kenwood: 037 Konka: 008, 009 Magnavox: 004, 038 Memorex: 039 Mintek: 040 NAD: 026 Nakamichi: 041 Norcent: 043 Onkyo: 044 Oritron: 058 Panasonic: 010, 045,

046, 047, 048, 049,

050 Philips: 004, 051 Pioneer: 052, 053, 054,

055 Proscan: 001, 056 Qwestar: 057, 058 RCA: 001, 002, 059, 089 Sampo: 060 Samsung: 061, 062, 086,

090 Sansui: 073 Sanyo: 063, 091 Sharp: 064, 067 Sherwood: 074 Sony: 011, 012, 065,

066, 068, 069, 070 Sylvania: 027 Teac: 071 Technics: 072 Techwood: 075 Toshiba: 000, 013, 076,

077, 078 Yamaha: 079, 080, 081 Zenith: 014, 082, 092

Portable DVD player

Aiwa: 093 Audiovox: 094, 095 Panasonic: 024, 096, 099 RCA: 098

VCR

Admiral: 049 Aiko: 019 Aiwa: 018 Akai: 003, 004, 037,

038, 039, 058, 069 Audiovox: 010 Bell & Howell: 007, 068 Broksonic: 008, 017 Calix: 010 Carver: 026 CCE: 019 Citizen: 009, 010, 011,

012, 013, 014, 015,

019, 057, 073

Colortyme: 005 Craig: 009, 010, 016,

061, 065, 079

Curtis Mathes: 001, 005,

009, 012, 014, 040, 048, 053, 056, 057

Daewoo: 011, 013, 015,

017, 018, 019, 057,

078 Daytron: 078 Denon: 063 Dimensia: 001, 048 Electrohome: 010, 020,

065 Emerson: 003, 008, 010,

011, 017, 018, 020,

028, 039, 054, 057,

062, 065, 068, 072 Fisher: 007, 016, 021,

022, 023, 057, 064,

068, 070, 071, 079 Fuji: 004, 041 Funai: 018, 073 Garrard: 018 GE: 001, 002, 009, 040,

042, 048, 056 Go Video: 056, 059,

061, 081 Goldstar: 005, 010, 014,

054, 056, 065, 067 Gradiente: 018, 065 Harman Kardon: 005 Hitachi: 024, 025, 035,

037, 042, 063, 070,

080 JBL: 076 JC Penney: 005, 006,

007, 008, 009, 010,

023, 024, 025, 026,

035, 056, 061, 063,

065 Jensen: 024, 025, 037,

050 JVC: 005, 006, 007,

014, 037, 043, 050,

062, 063, 068, 082 Kenwood: 005, 006,

007, 012, 014, 037,

043, 050, 053, 068,

071 Kodak: 010 LG: 010 Lloyds: 053, 073, 079 Logik: 061 LXI: 010 Magnasonic: 061, 065,

078 Magnavox: 026, 027,

034, 044, 057, 061,

072 Marantz: 005, 006, 007,

012, 014, 026, 053,

067

Memorex: 007, 009,

010, 016, 018, 034, 049, 063, 065, 066,

068, 075, 079 MGA: 020, 028, 039 MGN: 056 Minolta: 024, 025, 035,

063 Mitsubishi: 020, 024,

025, 028, 039, 043,

065 Montgomery Ward: 049 Motorola: 049 MTC: 009, 046, 061 Multitech: 009, 012, 018 NEC: 005, 006, 007,

012, 014, 037, 043,

053, 054, 067, 070 Nikko: 010 Noblex: 009 Optimus: 010, 049, 065 Optonica: 031 Orion: 054, 057, 062,

065, 068, 072 Panasonic: 036, 045,

046, 057, 061, 072,

079 Pentax: 012, 024, 025,

035, 042, 053, 063 Pentex Research: 014 Philco: 026, 027, 063 Philips: 026, 031, 044,

057 Pioneer: 006, 024, 043,

055 Portland: 012, 013, 015 Proscan: 001, 002, 048 Proton: 061 Quasar: 045 Radio Shack: 010, 031,

065 Radio Shack/Realistic:

007, 009, 010, 016,

018, 020, 021, 022,

031, 049 Radix: 010 RCA: 001, 002, 003,

009, 024, 025, 029,

035, 040, 042, 045,

048, 055, 056, 063,

071, 083 Realistic: 007, 009, 010,

011, 016, 018, 020,

021, 022, 031, 049,

051, 056, 060, 065,

075, 079 Ricoh: 047 Runco: 034 Samsung: 009, 011, 038,

056, 073, 084 Sansui: 006, 037, 043,

061

Sanyo: 007, 009, 016,

054, 064, 068, 071, 075, 079, 085

Scott: 008, 011, 017,

028, 030, 057, 065, 072

Sears: 007, 010, 016,

021, 022, 023, 024, 025, 035, 053, 057, 063, 064, 065, 068, 071, 075, 079

Sharp: 013, 020, 031,

049, 051, 060, 066

Shintom: 004, 025, 032,

061 Signature: 049 Signature 2000: 075 Singer: 047, 061 Sony: 004, 032, 033,

041, 052, 058, 070,

074, 076, 077, 080 STS: 035 Sylvania: 018, 026, 027,

028, 044, 072 Symphonic: 018, 050,

051, 053, 073, 079 Tandy: 007 Tashiko: 010 Tatung: 037 Teac: 018, 029, 037 Technics: 036 Teknika: 010, 018, 065 Toshiba: 000, 011, 021,

023, 024, 028, 030,

039, 057, 074, 078,

079 Totevision: 009, 010,

065 Unitec: 073 Unitech: 009 Vector Research: 005,

006, 011, 012, 053 Video Concepts: 005,

006, 011, 012, 039,

053 Wards: 009, 010, 011,

016, 018, 020, 024,

025, 031, 035, 049,

051, 056, 057, 060,

065, 066, 079 White Westinghouse:

073 XR-1000: 018 Yamaha: 005, 006, 007,

014, 037, 053 Zenith: 004, 032, 034,

041, 047, 069, 086

HTIB

Lasonic: 083 Panasonic: 084 Venturer: 085

Introduction

your TV

Connecting

Using the

Remote Control

your TV

Setting up

Features

Using the TV’s

Appendix

Index

Using the remote control to operate a cable converter box, satellite receiver, VCR, DVD player, or HTIB (home theater in a box)

Introduction

your TV

Connecting

If you have a non-Toshiba device or a Toshiba device that the remote control is not preprogrammed to operate, you must first program the remote control to recognize the device (if you have not already done so). See pages 18 and 19.

To use your TV remote control to operate a:

• cable converter box or satellite receiver, set the Device Switch to

CBL/SAT.

• VCR, set the Device Switch to VCR.

• DVD player or HTIB, set the Device Switch to DVD.

Point the remote control

directly at the device.

Note:

Even after the TV remote control is programmed, it may not operate certain features on your other device. If this happens and you wish to use those features, you will need to use the device’s original remote control.

Using the

Remote Control

your TV

Setting up

Features

Using the TV’s

Appendix

Index

TV / VIDEO

+10 (DVD only)

Press to directly access

DVD chapters higher than 10.

TOP MENU (DVD only)

Accesses a DVD’s top menu.

ENTER

Required by some VCRs and cable

converter boxes to change the channel.

Device Switch

Set to “TV” to control the TV; “CBL/SAT” to

control a cable converter box or satellite

receiver; “VCR” to control a VCR; “DVD”

TV CBL/SAT VCR DVD

to control a DVD player or HTIB.

PAU SE

Press during play or record mode to

pause the picture; press again to restart.

TV/VCR PAUSE

TV/VCR (VCR only)

To view one program while recording

another, press to select TV mode.

REW

CH SCAN

REC

Rewinds the tape or DVD. (Press during play mode

to view the picture moving rapidly backward.)

REC (VCR only)

Starts tape recording.

Fast-forwards the tape or DVD.

(Press during play mode to view the

picture moving rapidly forward.)

RECALL

POWER

INFO

123

456

100

FAVORITE

ENTER

FAV

CHRTN

ENT

PIC

VOLCH

STOP

SKIP / SEARCH

+10

DVDMENU

FAV

POP DIRECT CH MUTE SLEEP

FREEZE SOURCE

FFREW

SWAP POP CH

EXIT

PLAY

SPLIT

LIGHT

POWER

Turns the selected device on and off.

INFO (CBL/SAT only)

Displays on-screen information.

Channel Numbers (0-9)

Press to directly access channels (as opposed to CH y z).

DVD MENU (DVD only)

Accesses DVD menus.

GUIDE (CBL/SAT only)

Displays channel guide.

y z x • (DVD only) Press to navigate DVD menus (may not work on some DVD players).

CLEAR (DVD only)

Press to reset the title and chapter number.

CH y z y selects the next higher channel; z selects the next lower channel.

PLAY

Begins playback of a tape or DVD.

STOP

Stops the tape or DVD.

SKIP/SEARCH

(DVD only)

Skips forward to locate later DVD chapters.

SKIP/SEARCH (DVD only)

Skips back to beginning of current DVD chapter or locates previous chapters.

Learning about the remote control

The buttons used for operating the TV only are described here.

POWER turns the TV on and off

RECALL displays screen information (page 57)

SLEEP sets the TV to turn off at a specific time (page 51)

TV/VIDEO selects video input source (page 49)

MUTE mutes the sound (page 53)

Device Switch

switches between TV, CBL/SAT, VCR, and DVD (Pages 18-20) Set to “TV” to control the TV.

CH (channel) y z cycles through programmed channels (page 25)

Channel Numbers (0-9, 100) allow direct access to channels (page 25)

VOL (volume) y z adjusts the volume level

CH RTN returns to the memorized channel (page 28)

MENU allows access to on-screen programming menus (page 22)

ENTER activates the function settings in the menu (page 22)

y z x • select or adjust programming menus (page 22)

POP CH y z

selects the POP (picture-out-picture) channel (page 35)

FAV y z cycles through favorite channels (page 29)

FAVORITE allows access to the favorite channel search function (page

38)

PIC SIZE cycles through the five picture sizes: Natural, Theater Wide

1, 2, 3, and Full (page 31)

TV / VIDEO

RECALL

INFO

123

456

100

FAVORITE

ENTER

TV CBL/SAT VCR DVD

TV/VCR PAUSE

CH SCAN

REC

+10

FAV

DVDMENU

FAV

VOLCH

POP DIRECT CH MUTE SLEEP

STOP

FREEZE SOURCE

SKIP / SEARCH

FFREW

SWAP POP CH

POWER

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

Introduction

your TV

Connecting

Using the

Remote Control

your TV

Setting up

EXIT exits programming menus (page 22)

SPLIT turns the POP feature on and off (page 35)

SOURCE selects the POP picture source (page 35)

FREEZE freezes the picture. Press again to restore the picture.

SWAP switches the main and POP pictures (page 36)

POP DIRECT CH allows direct access to POP channels (page 35)

CH SCAN

allows access to the programmed channel search function (page 37)

LIGHT illuminates the keypad for five seconds

Note:

The error message “Not Available” will appear if you press a key for a function that is not available.

Features

Using the TV’s

Appendix

Index

Setting up your TV

Learning about the menu system

Introd

your TV

Connecting

Using the

Remote Control

your TV

Setting up

Features

Using the TV’s

Appendix

After you have installed the batteries and programmed the remote control, you will need to set some preferences on the TV using the menu system. You can access the menu using the buttons on your TV or remote control.

1. Press MENU to display the menu system.

2. Press x or • to select menu.

3. Press y or z to select an item, then press ENTER.

4. Press y or z to select or adjust a setting.

MODE P I CTURE SETT I NGS D I SPLAY FORMAT C I NEMA MODE CONVERGENCE

LANGUAGE CLOCK SET 00 :0 0 ANT 1 / 2 ANT1 TV / CABLE CABLE CH PROGRAM ADD / ERASE

: ENDSELECT EX I T

P I CTURE

RESET SAVE

END::SELECT EXT

MODE CONTRAST BRI GHTNESS COLOR TINT SHARPNESS

SET UP

:SELECT

ON T I MER SLEEP T I MER CC OFF FAVOR I TE CH CH LABEL I NG V I DEO LABEL BACKGROUND

SPORTS

1080i V I DEO

P CTUREIISETT

RESET SAVE

MOVE: :SELECTENTER

ENGLISH

::ENDSELECT EX I T

NGS

ANTENNA SPORTS

100

50 50

00h00m

SHADED

LOCKS

AUDIO

0h00m

BASS TREBLE BALANCE RESET AUD I O MENU

MOVE: ADJUST:

MTS AUDIO SETTINGS WOW

SRS 3D ON

FOCUS

TruBass

SELECT::ENDEXIT

ADD

CUSTOM

V - CH I P CH LOCK V I DEO LOCK NEW P I N CODE

::ENDSELECT EXIT

STEREO

OFF H I GH

AUD I O ISETT

RESET SAVE

OFF

50 50

NGS

• Press ENTER to activate the function settings in the menus.

• The main menu display will disappear automatically if you do not make a selection within 15 seconds. If you want to close all the on-screen displays instantly, press EXIT.

TV front panel

VOLUME

CHANNEL

EXITMENU

x •zy

EXIT

(ENTER)

POWER

RECALL

TV / VIDEO

INFO

123

456

100

FAVORITE

ENTER

TV CBL/SAT VCR DVD

POP DIRECT CH MUTE SLEEP

TV/VCR PAUSE

CH SCAN

REC

+10

FAV

DVDMENU

FAV

VOLCH

STOP

FREEZE SOURCE

SKIP / SEARCH

FFREW

SWAP POP CH

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

yzx •

EXIT

ENTER

Note:

You can change the background of the menu. See page 57 for details.

TV/VIDEO

TouchFocus

Index

Changing the on-screen display language

You can choose from three different languages (English, French and Spanish) for the on-screen display of adjustment menus and messages.

To select a language:

1. Press MENU, and then press x or • until the SET UP menu appears.

2. Press y or z to highlight LANGUAGE, and then press ENTER to display the pull-down menu.

TV front panel

VOLUME

x •zy

CHANNEL

Introduction

TouchFocus

TV/VIDEO

EXITMENU

LANGUAGE CLOCK SET ANT 1 / 2 TV / CABLE CH PROGRAM ADD / ERASE

SELECT::SETENTER

SET UP

ENGLISH FRAN ESPA

AIS

3. Press y or z to highlight your desired language.

Selecting the antenna input

You can connect to two different antenna input sources (ANT 1 or ANT 2).

To select the antenna input using the menu system:

1. Press MENU, and then press x or • to highlight the SET UP menu.

2. Press y or z to highlight ANT 1/2, and then press ENTER to display the pull-down menu.

LANGUAGE CLOCK SET ANT 1 / 2 TV / CABLE CH PROGRAM ADD / ERASE

SELECT::SETENTER

SET UP

ANT1 ANT2

RECALL

TV / VIDEO

INFO

123

456

+10

100

FAV

FAVORITE

DVDMENU

ENTER

FAV

TV CBL/SAT VCR DVD

TV/VCR PAUSE

CH SCAN

REC

VOLCH

POP DIRECT CH MUTE SLEEP

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

POWER

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

TV/VIDEO

yzx •

ENTER

your TV

Connecting

Using the

Remote Control

your TV

Setting up

3. Press y or z to highlight either ANT 1 or ANT 2, depending on the antenna terminal you wish to use.

To select the antenna input using the TV/VIDEO button:

1. Press the TV/VIDEO button on the remote control or TV (see illustrations below). The current signal source displays in purple.

2. Continue pressing the TV/VIDEO button to select ANT 1 or ANT 2.

SELECT ION

SOURCE

ANT 1

VIDEO 1

VIDEO 2

IDEO

Color Stream

HDM I

ANT 2

7 TO SELECT:

HD1 HD2

Pressing TV/VIDEO on the remote control displays the current signal source (press TV/VIDEO again or 0-7 to change)

TV / V I DEO : TO SELECT

Pressing TV/VIDEO on the TV changes the current signal source

SOURCE

SELECT ION

ANT 1 VIDEO 1 VIDEO 2

IDEO

Color Stream Color Stream

HDM I ANT 2

HD1 HD2

TV front panel

VOLUME

CHANNEL

EXITMENU

TV/VIDEO

TouchFocus

TV/VIDEO

Please note the following regarding the HDMI source selection:

This TV is not intended for connection to and should not be used with a PC (personal computer). See “Connecting a device to the HDMI input” on page 15 for details.

Features

Using the TV’s

Appendix

Index

Adding channels to the TV’s memory

When you press Channel y or z, your TV will stop only on the channels stored in the TV’s channel memory.

Follow the steps below and on the next page to program all active

Introd

your TV

Connecting

Using the

Remote Control

your TV

Setting up

channels into the TV’s memory.

Programming channels automatically

Your TV can automatically detect all active channels in your area and store them in its memory. After the channels are stored automatically, you can manually add or erase individual channels (see page 25).

To program channels automatically:

1. Press MENU, and then press x or • until the SET UP menu appears.

2. Press y or z until the TV/CABLE is highlighted, and then press ENTER to display the pull-down menu.

3. Press y or z to highlight either TV or CABLE, depending on which you use. If you use an antenna, highlight TV; if you use cable, highlight CABLE.

LANGUAGE CLOCK SET ANT 1 / 2 TV / CABLE CH PROGRAM ADD / ERASE

SELECT::SETENTER

SET UP

CABLE

4. Press ENTER.

5. Press z to select CH PROGRAM.

Note:

To tune the TV to a channel not programmed in the channel memory, you must use the Channel Number buttons on the remote control.

POWER

RECALL

TV / VIDEO

INFO

123

456

100

FAVORITE

ENTER

TV CBL/SAT VCR DVD

POP DIRECT CH MUTE SLEEP

TV/VCR PAUSE

CH SCAN

REC

+10

FAV

DVDMENU

FAV

VOLCH

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

yzx •

ENTER Channel yz

Features

Using the TV’s

Appendix

Index

LANGUAGE CLOCK SET ANT 1 / 2 ANT1 TV / CABLE CABLE CH PROGRAM ADD / ERASE

MOVE::STARTENTER

SET UP

ENGLISH

00:00

ADD

6. Press ENTER to start channel programming. The TV will automatically cycle through all the TV or Cable channels (depending on which you selected), and store all active channels in the channel memory.

While the TV is cycling through the channels, the message “Programming Now—Please Wait” appears.

7. When channel programming is complete,the message “Completed” appears.

8. Press Channel y or z to view the programmed channels.

Adding and erasing channels manually

After you have programmed the channels automatically, you can manually add or erase specific channels.

To add or erase channels:

1. Select the channel you want to add or erase. If you are adding a channel, you must select the channel using the Channel Number buttons.

2. Press MENU, and then press x or • until the SET UP menu appears.

3. Press y or z to highlight ADD/ERASE, and then press ENTER to display the pull-down menu.

LANGUAGE CLOCK SET ANT 1 / 2 TV / CABLE CH PROGRAM ADD / ERASE

SELECT::SETENTER

SET UP

ADD

ERASE

4. Press y or z to select ADD or ERASE, depending on the function you want to perform.

5. Repeat steps 1-4 for other channels you want to add or erase.

Changing channels

To change to a specific channel (programmed or unprogrammed):

Press the Channel Number buttons (0–9 and 100). For channels 100 and higher, press the 100 button, and then the next two numbers. For example, to select channel 125, press 100, 2, 5.

To change to the next programmed channel:

Press Channel y or z on the TV or remote control.

TV front panel

TV / VIDEO

123

456

+10

100

FAVORITE

ENTER

TV CBL/SAT VCR DVD

POP DIRECT CH MUTE SLEEP

TV/VCR PAUSE

CH SCAN

REC

VOLUME

x •zy

RECALL

INFO

FAV

DVDMENU

FAV

VOLCH

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

POWER

CHRTN

ENT

PIC SIZE

CHANNEL

EXIT

PLAY

SPLIT

LIGHT

TouchFocus

TV/VIDEO

EXITMENU

Channel Number

yzx •

ENTER Channel yz

Introduction

your TV

Connecting

Using the

Remote Control

your TV

Setting up

Features

Using the TV’s

Appendix

Index

Adjusting the color convergence

This projection TV uses three separate TV tubes: red, green, and blue. The red, green, and blue images are projected onto the screen where they converge to form a full-color picture. You can see a clear picture only when the three images converge correctly. Convergence may drift

Introd

your TV

Connecting

over time or if you move the TV. If you can see clear images on your TV screen, skip this procedure.

It is recommended that the adjustment is made only after the TV has been on for at least 30 minutes.

Automatically adjusting the color convergence using TouchFocus™

Press TouchFocus on the TV once. The TV will enter autoconvergence mode, and adjust convergence automatically.

TV front panel

Using the

Remote Control

your TV

Setting up

Features

Using the TV’s

TOUCH FOCUS

When the adjustment is complete, the normal picture appears.

You can adjust the convergence manually described as follows for more detailed convergence adjustment than by TouchFocus.

Manually adjusting the color convergence

You can use the CONVERGENCE in the PICTURE menu to perform continual auto-convergence (TouchFocus) and manual convergence adjustments.

1. Press MENU, and then press x or • until the PICTURE menu appears.

2. Press y or z to highlight CONVERGENCE, and then press ENTER to display the pull-down menu.

3. Press y or z to highlight ADJUST, and then press ENTER. The TV will perform TouchFocus. When the adjustment is complete, the TV will enter 56-point static convergence mode automatically.

MODE P I CTURE SETT I NGS D I SPLAY FORMAT C I NEMA MODE CONVERGENCE

SELECT: ENTER

P I CTURE

RESET SAVE

:START

ADJUST RESET

ENTER : TO ADJUST CONVERGENCE EX I T : TO F I N I SH ADJUSTMENT

: TO SELECT POS I T I ON

cursor

VOLUME

x •zy

RECALL

TV / VIDEO

INFO

123

456

+10

100

FAV

FAVORITE

DVDMENU

ENTER

FAV

TV CBL/SAT VCR DVD

VOLCH

POWER

CHRTN

ENT

PIC SIZE

CHANNEL

EXIT

Touch Focus

TV/VIDEO

EXITMENU

TouchFocus™

MENU yzx •

ENTER

Appendix

Index

If you see separate red, blue, or green crossed lines (or red or blue shadows next to white lines), you need to adjust the convergence.

4. Press yzx • to move the cursor to the position you want to adjust.

5. Press ENTER repeatedly to select RED or BLUE adjusting mode (red crossed lines or blue crossed lines), depending on which color needs adjusting.

(continued on next page)

6. Press y (up), z (down), x (left), or • (right) on the remote control to converge the red or blue line into the white line.

: TO ADJUST RED

ENTER : TO CHANGE COLOR

EX I T : TO F I N I SH ADJUSTMENT

: TO ADJUST BLUE

ENTER : TO SELECT POS I T I ON

EX I T : TO F I N I SH ADJUSTMENT

7. If both red and blue need adjusting, you will need to perfrom steps 5 and 6 twice.

8. Press ENTER to display the cursor.

9. Repeat steps 4 to 8 to adjust another position.

10. Press EXIT to close the Convergence menu.

RECALL

TV / VIDEO

INFO

123

456

+10

100

FAV

FAVORITE

DVDMENU

ENTER

FAV

TV CBL/SAT VCR DVD

TV/VCR PAUSE

CH SCAN

REC

VOLCH

POP DIRECT CH MUTE SLEEP

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

POWER

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

Introduction

yzx •

EXIT

your TV

Connecting

ENTER

Using the

Remote Control

To reset your adjustments:

1. Select RESET in step 3 on page 26, and then press ENTER. The message “WARNING: RESETS USER ADJUSTMENT TO FACTORY SETTINGS” will appear.

2. Press y or z to highlight START, and then press ENTER. Your convergence settings have been reset.

RESET ADJUSTMENT

WARN I NG : RESETS USER ADJUSTMENT

SELECT::STARTENTER

CONVERGENCE

TO FACTORY SETT I NGS

RESET SAVE

CANCEL

START

your TV

Setting up

Features

Using the TV’s

Appendix

Index

Using the TV’s features

Introduction

Adjusting the channel settings

Switching between two channels using Channel Return

The Channel Return feature allows you to switch between two channels without entering an actual channel number each time.

your TV

Connecting

Each time you press CH RTN, the TV will switch back and forth between the last two channels that were selected.

Switching between two channels using SurfLock™

The SurfLock™ feature temporarily “memorizes” one channel in the CH RTN button, so you can return to that channel quickly from any other channel by pressing CH RTN.

Using the

To memorize a channel in the CH RTN button:

Remote Control

your TV

Setting up

The TV will return to the memorized channel one time only. Once you press CH RTN and then change channels again, the CH RTN button memory will be cleared and the button will function as Channel Return, by switching back and forth between the last two channels that were selected.

Features

Using the TV’s

Programming your favorite channels

You can preset up to 12 of your favorite channels using the Favorite Channel Programming feature. Because this feature scans through only your favorite channels, it allows you to skip other channels you do not normally watch.

To program your favorite channels:

Appendix

1. Select the first channel (or video mode) you want to view.

2. Select a second channel using the Channel Number buttons (0–9, 100).

3. Press CH RTN. The previous channel will display.

1. Select the channel you want to program into the CH RTN button.

2. Press and hold CH RTN for about 2 seconds until the message “Channel Memorized” appears on

CHANNEL MEMOR I ZED

CABLE

ANT 1

the screen. The channel has been programmed into the CH RTN button.

3. Continue to change channels until your desired channel is selected.

4. Press CH RTN. The memorized channel will be selected.

1. Press MENU, and then press x or • until the CUSTOM menu appears.

2. Press y or z to highlight FAVORITE CH.

RECALL

TV / VIDEO

INFO

123

456

+10

100

FAV

FAVORITE

DVDMENU

ENTER

FAV

TV CBL/SAT VCR DVD

TV/VCR PAUSE

CH SCAN

REC

TV / VIDEO

VOLCH

POP DIRECT CH MUTE SLEEP

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

RECALL

INFO

123

456

+10

100

FAV

FAVORITE

DVDMENU

ENTER

FAV

TV CBL/SAT VCR DVD

TV/VCR PAUSE

CH SCAN

REC

VOLCH

POP DIRECT CH MUTE SLEEP

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

POWER

CHRTN

ENT

PIC SIZE

POWER

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

EXIT

PLAY

SPLIT

LIGHT

TV/VIDEO

Channel Number

CH RTN

yzx •

Index

ON T I MER SLEEP T I MER CC OFF FAVOR I TE CH CH LABEL I NG V I DEO LABEL BACKGROUND

::STARTMOVE ENTER

CUSTOM

00h00m

0h00m

SHADED

(continued on next page)

3. Press ENTER to display the FAVORITE CH menu. CH INPUT will be highlighted.

CH I NPUT

CLEAR ALL CUSTOM MENU

0–9

FAVOR I TE CH

– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – –

SELECT: :SETENTER

– – –

TV CABLE

4. Press the Channel Number buttons to enter one of your favorite channels.

5. Press ENTER.

6. Repeat steps 4 and 5 for other channels.

To select your favorite channels:

Press FAV z or y.

To quickly scan through your favorite channels in a twelve-picture multi-window:

Press FAVORITE (see page 38 for detail).

To clear a favorite channel:

1. Press MENU, and then press x or • until the CUSTOM menu appears.

2. Press y or z to highlight FAVORITE CH.

3. Press ENTER to display the FAVORITE CH menu.

CH I NPUT

CLEAR ALL CUSTOM MENU

0–9

FAVOR I TE CH

2345 6789

10 11 12 13

SELECT: :SETENTER

– – –

TV CABLE

4. Press yzx • to highlight the channel you want to clear, then press ENTER.

CH I NPUT

CLEAR ALL CUSTOM MENU

FAVOR I TE CH

345

6789

10 11 12 13

SELECT: :CLEARENTER

– – –

TV CABLE

Notes:

• The FAV

zy buttons operate as

MENU zy buttons when a menu is onscreen.

• The favorite channel feature is not available in ANT2 mode.

POWER

RECALL

TV / VIDEO

INFO

123

456

+10

100

FAV

FAVORITE

DVDMENU

ENTER

FAV

TV CBL/SAT VCR DVD

TV/VCR PAUSE

CH SCAN

REC

VOLCH

POP DIRECT CH MUTE SLEEP

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

Channel Number

FAVORITE

yzx •

FAV zy

ENTER

Introduction

your TV

Connecting

Using the

Remote Control

your TV

Setting up

Features

Using the TV’s

5. Repeat step 4 for other channels.

To clear all favorite channels at once:

Press y or z to highlight CLEAR ALL in step 4 above, and then press ENTER to clear all favorite channels at once.

CH I NPUT

CLEAR ALL CUSTOM MENU

: : STARTENTER

FAVOR I TE CH

– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – –

MOVE

– – –

TV CABLE

Appendix

Index

Labeling channels

Channel labels appear above the on-screen channel number display each time you turn on the TV, change a channel, or press RECALL.

Introduction

You can choose any four characters to identify a channel. To create channel labels:

your TV

Connecting

Using the

Remote Control

1. Press MENU, and then press x or • until the CUSTOM menu appears.

2. Press y or z to highlight CH LABELING.

3. Press ENTER to display the CH LABELING menu. CH INPUT will be highlighted.

CH I NPUT LABEL CLEAR CUSTOM MENU

0–9

SELECT: :SETENTER

CH LABEL I NG

– – – – – – – –

4. Press the Channel Number buttons to select a channel you want to label.

5. Press z to highlight LABEL.

6. Press x or • repeatedly to select a character for the first space, and then press ENTER.

RECALL

TV / VIDEO

INFO

123

456

+10

100

FAV

FAVORITE

DVDMENU

ENTER

FAV

TV CBL/SAT VCR DVD

TV/VCR PAUSE

CH SCAN

REC

VOLCH

POP DIRECT CH MUTE SLEEP

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

POWER

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

RECALL

Channel Number

yzx •

ENTER

your TV

Setting up

Features

Using the TV’s

Appendix

CH I NPUT LABEL CLEAR CUSTOM MENU

0–9

SELECT: : SETENTER

CH LABEL I NG

– – – –

CH I NPUT LABEL CLEAR CUSTOM MENU

CH LABEL I NG

SELECT: : SETENTER

A – – –

0 6

7. Repeat step 6 to enter the rest of the characters. If you would like a blank space in the label name, you must

choose an empty space from the list of characters. Otherwise, a dash “–” will appear in that space.

8. Repeat steps 4–7 for other channels. You can assign labels to a maximum of 32 channels.

To erase channel labels:

1. Press MENU, and then press x or • until the CUSTOM menu appears.

2. Press y or z to highlight CH LABELING.

3. Press ENTER to display the CH LABELING menu.

4. CH INPUT will be highlighted. Select the channel you want to clear with the Channel Number buttons.

5. Press z or y to highlight CLEAR.

6. Press ENTER to erase the channel label.

CH I NPUT LABEL CLEAR CUSTOM MENU

CH LABEL I NG

A B C D

0 6

7. Repeat steps 4–6 to erase other channel labels.

MOVE::STARTENTER

Index

Viewing the wide-screen picture formats (480i, 480p and 1080i signals only)

You can view 480i and 480p format programs in a variety of picture sizes—Natural, Theater Wide 1, Theater Wide 2, Theater Wide 3, and Full. (The Full picture size is not selectable for 1080i format program.)

The way the image displays in any of the picture sizes will vary depending on the format of the program you are viewing. Select the picture size that displays the current program the way that looks best to you. See “Notice of possible adverse effects on TV picture tube,”

below right.

Selecting the picture size

1. Press PIC SIZE on the remote control.

2. Press the corresponding number button (0-4) to select the desired picture size, as described below and on the next page.

P I CTURE S I ZE

0 : NATURAL 1 : THEATER W I DE 1 2 : THEATER W I DE 2 3 : THEATER W I DE 3 4 : FULL

0 4 : TO SELECT –

POWER

RECALL

TV / VIDEO

INFO

123

Number

456

+10

100

FAVORITE

ENTER

TV CBL/SAT VCR DVD

POP DIRECT CH MUTE SLEEP

TV/VCR PAUSE

Note:

CH SCAN

You also can change the picture size by

REC

selecting PICTURE SIZE in the PICTURE

FAV

DVDMENU

FAV

VOLCH

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

CHRTN

ENT

IC SIZE

EXIT

PLAY

SPLIT

LIGHT

PIC SIZE MENU

yzx •

ENTER

menu.

Introduction

your TV

Connecting

Using the

Remote Control

Natural picture size

• The image is displayed close to its originally formatted proportion. Some program formats will display with side bars and/or bars at the top and bottom (see examples below).

Natural picture size examples: The way the image displays will vary depending on the format of the program you are currently watching.

See “Notice of possible adverse effects on TV picture tube” at right.

RESET

P I CTURE

OFF

SAVE

P I CTURE S I ZE AUTO ASPECT P I CTURE SCROLL

MOVE::STARTENTER

NOTICE OF POSSIBLE ADVERSE

EFFECTS ON TV PICTURE TUBE

Avoid displaying stationary images on your TV screen for extended periods of time. Fixed (non-moving) images (such as still PIP/POP windows or black/gray bars in wide-screen picture or PIP/POP formats) can become permanently engrained in the picture tube. This type

of damage is NOT COVERED BY YOUR WARRANTY because it is the

result of misuse. See item 33 on page 4.

your TV

Setting up

Features

Using the TV’s

Appendix

(continued on next page)

Index

Theater Wide 1 picture size (For 4:3 format program)

Introduction

your TV

Connecting

Theater Wide 2 picture size (For 16:9 Letter box program)

Using the

Remote Control

Theater Wide 3 picture size (For 16:9 Letter box program with subtitles)

your TV

Setting up

Features

Using the TV’s

• The picture is non-uniformly enlarged—the center of the picture remains close to its original proportion, but the left and right edges are stretched wider to fill the screen.

• A small part of the picture at the top and bottom is hidden; however, this mode cannot be scrolled.

• The entire picture is uniformly enlarged—it is stretched the same amount both wider and taller (retains its original proportion).

• Part of the picture at the top and bottom is hidden. To view the hidden areas, see “Scrolling the Theater Wide picture” on page 33.

• The picture is non-uniformly enlarged—it is stretched wider to fill the width of the screen, but only slightly stretched taller.

• A small part of the picture at the top and bottom is hidden. To view the hidden areas (such as subtitles or captions), see “Scrolling the Theater Wide picture” on page 33.

Theater Wide 1 picture size example

Theater Wide 2 picture size example

Theater Wide 3 picture size example

Note:

• To select the picture size, press PIC SIZE on the remote control or select PICTURE SIZE in the PICTURE menu.

• The PICTURE SIZE feature is not available for some program formats (such as 1080i or 720p). Such formats will display in Natural picture size (see page 31).

• If you select Theater Wide 2 or 3, the top and bottom edges of the picture may be hidden. To see the hidden edges, either scroll the picture (see page 33) or try viewing the program in Full picture size.

NOTICE OF POSSIBLE ADVERSE

EFFECTS ON TV PICTURE TUBE

of damage is NOT COVERED BY YOUR WARRANTY because it is the

result of misuse. See item 33 on page 4.

Note:

Using these functions to change the picture size (i.e., changing the height/ width ratio) for any purpose other than your private viewing may be prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability.

Appendix

Index

Full picture size (For 16:9 source squeezed (4:3) program)

• The picture is non-uniformly enlarged—it is stretched wider to fill the width of the screen, but not stretched taller.

• None of the picture is hidden.

Full picture size example

Scrolling the Theater Wide picture (Theater Wide 2 and 3 only)

1. Press PIC SIZE to select the Theater Wide 2 or 3 mode.

2. Press MENU, and then press x or • until PICTURE menu appears.

3. Press y or z to highlight PICTURE SCROLL.

RESET

P I CTURE

OFF

SAVE

P I CTURE S I ZE AUTO ASPECT P I CTURE SCROLL

MOVE::STARTENTER

4. Press ENTER to display the Scroll Adjustment mode.

SCROLL ADJ USTMENT 0

TO ADJUST

5. Press y or z to adjust the vertical position of the picture.

• Normal (center) position

POWER

RECALL

TV / VIDEO

INFO

123

456

+10

100

FAVORITE

ENTER

TV CBL/SAT VCR DVD

POP DIRECT CH MUTE SLEEP

TV/VCR PAUSE

Note:

CH SCAN

You can scroll the picture in Theater Wide 2

REC

and Theater Wide 3 only. The scroll amounts

FAV

DVDMENU

FAV

VOLCH

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

CHRTN

ENT

IC SIZE

EXIT

PLAY

SPLIT

LIGHT

PIC SIZE

yzx •

ENTER

are as follows:

• 480i/480p/1080i signal source: Wide 1 : Not adjustable

Wide 2 : -10 to +20 Wide 3 : -10 to +20

Introduction

your TV

Connecting

Using the

Remote Control

SCROLL ADJ USTMENT 0

TO ADJUST

• To raise the picture, press y .

SCROLL ADJ USTMENT +20

TO ADJUST

• To lower the picture, press z.

SCROLL ADJ USTMENT –10

TO ADJUST

NOTICE OF POSSIBLE ADVERSE

EFFECTS ON TV PICTURE TUBE

of damage is NOT COVERED BY YOUR WARRANTY because it is the

result of misuse. See item 33 on page 4.

your TV

Setting up

Features

Using the TV’s

Appendix

Index

Using the AUTO ASPECT feature

When the AUTO ASPECT feature is set to ON and the TV receives a 480i signal (other than HDMI imput source), the picture size is

Introduction

automatically selected (as described in the following table).

your TV

Connecting

If the signal does not include aspect information, the picture size you selected on pages 31–32 is displayed.

To turn on the AUTO ASPECT feature:

Using the

Remote Control

your TV

Setting up

Features

Using the TV’s

Automatic aspect size

Aspect ratio of signal source

(automatically selected

when AUTO ASPECT is ON)

4:3 Normal

16:9 Full

4:3 Letter box

Not defined (no ID-1 data)

Natural

Full

Theater wide 2 User-set mode

1. Press MENU, and then press x or • until the PICTURE menu appears.

MODE P I CTURE SETT I NGS D I SPLAY FORMAT C I NEMA MODE CONVERGENCE

P I CTURE

RESET SAVE

END::SELECT EX I T

SPORTS

1080i

V I DEO

2. Press y or z to highlight AUTO ASPECT, and then press ENTER.

P I CTURE S I ZE AUTO ASPECT P I CTURE SCROLL

RESET

: SELECT

P I CTURE

:SETENTER

SAVE

OFF

3. Press y or z to select ON, and then press ENTER.

Note:

• The AUTO ASPECT is also available when viewing HDMI input source of 480i or other format.

• The AUTO ASPECT operates according to aspect information indicated in the digital signal of HDMI (not ID-1 signal).

POWER

RECALL

TV / VIDEO

INFO

123

456

+10

100

FAVORITE

ENTER

TV CBL/SAT VCR DVD

POP DIRECT CH MUTE SLEEP

TV/VCR PAUSE

CH SCAN

NOTICE OF POSSIBLE ADVERSE

REC

EFFECTS ON TV PICTURE TUBE

FAV

DVDMENU

FAV

VOLCH

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

CHRTN

ENT

C SIZE

EXIT

PLAY

SPLIT

LIGHT

yzx •

ENTER

of damage is NOT COVERED BY YOUR WARRANTY because it is the

result of misuse. See item 33 on page 4.

Appendix

Index

Using the POP double-window feature

The POP (picture-out-picture) feature splits the screen into a double window that allows you to watch two programs at the same time. The POP program can come from a TV broadcast or an external source, such as a VCR.

To display a TV broadcast in the POP window:

1. Press SPLIT to display the POP window.

Main window

(480i only)

ANT 1

MAIN

POP

2. Select channels of the POP window in the following two ways:

• To change to a specific channels, press POP DIRECT CH. While “POP” is on the screen, press the Channel Number buttons (0-9 and 100).

• To change the next programmed channels, press POP CH zy.

If the V-CHIP feature is active and you try to watch a TV program that exceeds your set rating limits, the program will be blocked (see “Using the V-CHIP menu” on page 39).

POP window

Note:

• The SPLIT buttons on the remote control operate the TV’s POP features.

• You cannot display the signal other than 480i format program in the Main window. Only the audio signal is output.

• You cannot display the ANT-2 signal source in the POP window.

• You can choose to output the sound of either the main or POP program (see “Selecting the Audio OUT sound” on page

56).

• You can choose to hear the speaker sound of either the main or POP program (See “Switching the speaker sound of main and POP programs” on page 36).

• HDMI, 720p ColorStream, 480p ColorStream, and 1080i ColorStream signals will only display in the POP (right) window. These signals will not display in the main (left) window when the TV is in double-window mode.

• If an HDMI or ColorStream source is being viewed when you open the POP doublewindow feature, the HDMI or ColorStream source will default to the POP (right) window.

Introduction

your TV

Connecting

Using the

Remote Control

POP

BLOCKED

To display a picture from an external source in the POP window:

1. Connect the external source equipment (see “Connecting your TV” on page 8).

2. Select the TV program you want to watch in the main window.

3. Press SPLIT to display the POP window.

4. Repeatedly press SOURCE to select the input source for the POP window (VIDEO 1, VIDEO 2, VIDEO 3, ColorStream HD1, ColorStream HD2 or HDMI). The current source will display in purple.

5. You can play a tape as the POP picture, or select a channel for the POP window using the VCR’s channel keys.

POP SOURCE SELECT I ON

0 : TV 2 :

3 : 4 : Color Stream HD1 5 : Color Stream HD2 6 : HDM I

0 - 6 : TO SELECT

V1 :

IDEO

VIDEO

1 2 3

While the above menu is on the screen, you can select the desired signal input source by pressing the corresponding number button (0-6).

To close the POP window:

Press SPLIT again or EXIT.

123

456

+10

100

FAV

VORITE

DVDMENU

ENTER

FAV

TV CBL/SAT VCR DVD

TV/VCR PAUSE

CH SCAN

REC

VOLCH

POP DIRECT CH MUTE SLEEP

STOP

FREEZE SOURCE

SKIP / SEARCH

FFREW

SWAP POP CH

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

Channel Numbers

EXIT

POP DIRECT CH SPLIT

SOURCE

POP CH zy

NOTICE OF POSSIBLE ADVERSE

EFFECTS ON TV PICTURE TUBE

of damage is NOT COVERED BY YOUR WARRANTY because it is the

result of misuse. See item 33 on page 4.

your TV

Setting up

Features

Using the TV’s

Appendix

Index

Switching the main and POP pictures

Press SWAP while you are using the POP feature to switch the main and POP pictures.

Introduction

your TV

Connecting

Switching the speaker sound of main and POP programs

Press x or • while you are using the POP feature to switch the sound (main or POP) from the speakers. The POP sound is monaural only.

The selected input source indicator is displayed in purple.

Using the

Remote Control

Example: Press x Example: Press •

MAIN

POP

MAIN

purple

POP

purple

Note:

• The SAP channel will not be decoded when the speaker source is switched to POP. Even if SAP is selected in the menu (see page 53), the main audio channel will be heard when the speaker sound is switched to POP.

• The VARIABLE AUDIO OUT jacks will switch with the speaker sound.

However, the source of the regular AUDIO OUT jacks is determined by the AUDIO OUT menu setting (page 56). The regular AUDIO OUT jacks do not switch with the speaker sound.

FAV

DVDMENU

FAV

VOLCH

STOP

SKIP / SEARCH

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

x •

SWAP

FAVORITE

ENTER

TV CBL/SAT VCR DVD

POP DIRECT CH MUTE SLEEP

TV/VCR PAUSE

FREEZE SOURCE

FFREW

SWAP POP CH

CH SCAN

REC

your TV

Setting up

Features

Using the TV’s

Appendix

NOTICE OF POSSIBLE ADVERSE

EFFECTS ON TV PICTURE TUBE

of damage is NOT COVERED BY YOUR WARRANTY because it is the

result of misuse. See item 33 on page 4.

Index

Double-Window aspect ratio

The Double-Window feature displays each picture according to its input signal aspect ratio, as illustrated below.

480i 480i

480p-720p480i

Using the programmed channel search function

You can use the programmed channel search function to quickly scan the channels you programmed into the TV’s memory (page 24).

1. Press CH SCAN. The TV automatically enters multi-window mode, and begins a twelve-picture scan of your programmed channels. (Press CH SCAN again to return to a normal picture.)

234

678

10 11 12

Note:

• The AUTO ASPECT feature (page 34) does not operate in double-window mode.

• Aspect ratio is the ratio of width to height

TV / VIDEO

of the picture.

123

456

100

FAVORITE

ENTER

TV CBL/SAT VCR DVD

POP DIRECT CH MUTE SLEEP

TV/VCR PAUSE

CH SCAN

REC

RECALL

INFO

+10

FAV

DVDMENU

FAV

STOP

FREEZE SOURCE

FFREW

SWAP POP CH

POWER

CHRTN

ENT

PIC SIZE

EXIT

VOLCH

PLAY

SPLIT

SKIP / SEARCH

LIGHT

Channel Number

Channel yz

CH SCAN

Introduction

your TV

Connecting

Using the

Remote Control

2. Press the Channel Number buttons to select one of the twelve pictures.

234

678

10 11 12

NOTICE OF POSSIBLE ADVERSE

EFFECTS ON TV PICTURE TUBE

of damage is NOT COVERED BY YOUR WARRANTY because it is the

result of misuse. See item 33 on page 4.

your TV

Setting up

Features

Using the TV’s

Appendix

Index

Using the favorite channel search function

You can use the favorite channel search function to quickly scan your favorite channels (see “Programming your favorite channels” on page

Introduction

28).

your TV

Connecting

Using the

Remote Control

1. Press FAVORITE. The TV automatically enters multi-window mode, and begins a twelve- picture scan of your favorite channels. (Press FAVORITE again to return to a normal picture.)

Moving picture

purple

234

678

10 11 12

2. Press yzx • to select one of the twelve pictures (becomes a moving picture). The selected channel number is in purple and the monaural sound of the selected channel is output.

3. Press ENTER to display the channel you selected in step 2 as a normal picture.

234

POWER

RECALL

TV / VIDEO

INFO

123

456

+10

100

FAVORITE

ENTER

TV CBL/SAT VCR DVD

POP DIRECT CH MUTE SLEEP

TV/VCR PAUSE

CH SCAN

REC

FAV

DVDMENU

FAV

VOLCH

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

FAVORITE

yzx •

ENTER

your TV

Setting up

Features

Using the TV’s

Appendix

678

10 11 12

purple

Moving picture

About the auto favorite feature

If your TV is in the program lock mode, after 4 seconds, the TV starts the auto favorite channel search function. See page 42 for details.

234

81011

9 X

NOTICE OF POSSIBLE ADVERSE

EFFECTS ON TV PICTURE TUBE

of damage is NOT COVERED BY YOUR WARRANTY because it is the

result of misuse. See item 33 on page 4.

Index

Using the LOCKS menu

The LOCKS menu includes the V-Chip, CH Lock, Video Lock, and New PIN Code functions. You can use these functions after entering the correct PIN code.

Entering the PIN code

1. Press MENU, and then press x or • until the LOCKS menu appears.

V - CH I P CH LOCK V I DEO LOCK NEW P I N CODE

::ENDSELECT EXIT

2. Press y or z to display the PIN code entering mode.

• Blocking Reset status: Set your 4-digit code by pressing the Number buttons (0–9).

BLOCK I NG RESET P I N CODE

0–9

LOCKS

SELECT: : SETENTER

1110

OFF

• When the PIN code is already stored: Press the Number buttons (0-9) to enter the 4-digit PIN code used for blocking channels.

BLOCK I NG ACT I VE P I N CODE

LOCKS

0–9

SELECT: : SETENTER

1234

Note:

The V-Chip function is available only for the U.S. V-Chip system. The Canadian V-Chip system is not supported.

POWER

RECALL

TV / VIDEO

INFO

123

456

+10

100

FAV

FAVORITE

DVDMENU

ENTER

FAV

TV CBL/SAT VCR DVD

TV/VCR PAUSE

CH SCAN

REC

VOLCH

POP DIRECT CH MUTE SLEEP

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

RECALL

Number

yzx •

ENTER

Introduction

your TV

Connecting

Using the

Remote Control

If the wrong PIN code is entered, the message “Incorrect” appears. Enter the code again, and then press ENTER.

If you cannot remember your PIN code

1. While the PIN code entering screen is displayed, press RECALL four times within five seconds. The PIN code will be released (Blocking Reset status restored).

2. Set new 4-digit code, and then press ENTER. The LOCKS menu appears.

V - CH I P CH LOCK V I DEO LOCK NEW P I N CODE

: MOVE

LOCKS

OFF

:STARTENTER

Continue to set each item following the steps.

Using the V-CHIP menu

Some TV programs and movies include signals that classify the content of the program (violence, sex, dialog, language). The V-CHIP conrol feature in this TV detects the signals and blocks the programs according to your selections. To use this feature, perform the following setup.

your TV

Setting up

Features

Using the TV’s

Appendix

Index

(continued on next page)

Introduction

ENABLE BLOCKING

1. From the LOCKS menu, press z or y to highlight V-CHIP, and then press ENTER.

The V-CHIP menu appears.

2. Press z or y to highlight ENABLE BLOCKING, and then press ENTER.

ENABLE BLOCK I NG TV RAT I NG MPAA RAT I NG BLOCK I NG OPT I ON LOCKS MENU

V – CH I P

ON OFF

V - CH I P CH LOCK V I DEO LOCK NEW P I N CODE

: MOVE

LOCKS menu

LOCKS

OFF

:STARTENTER

your TV

Connecting

3. Press y or z to select ON or OFF.

TV RATING (Independent rating system for broadcasters)

Using the

Remote Control

your TV

Setting up

The TV age-based ratings and content themes you can lock are listed in the table below.

Features

Using the TV’s

Appendix

Index

SELECT:

: SETENTER

ON : To enable your setting (Lock) OFF: To release your setting (Unlock)

Note: The CH LOCK function is not affected with this selection.

1. From the V-CHIP menu, press z or y to highlight TV RATING, and then press ENTER.

The TV RATING menu appears.

2. Press z or y to select item.

3. Press • to lock (display “X” ) Press x to unlock (display “✓ ”)

4. Repeat steps 2 and 3 to set the next item.

TV RAT I NG GPG14MA

D I ALOG LANGUAGE SEX V I OLENCE NO DLSV

YOUTH TV RAT I NG V – CH I P MENU

MOVE::SELECT

XX XX XX XX

Y7FV Y7 Y

Ratings Description and Content themes

MA Mature Audience Only (This program is specifically

designed to be viewed by adults and therefore may be unsuitable for children under 17.)

L) Crude or indecent language S) Explicit sexual activity V) Graphic violence

14 Parents Strongly Cautioned (This program contains some

material that many parents would find unsuitable for children under 14 years of age.)

D) Intensely suggestive dialog L) Strong, coarse language S) Intense sexual situations V) Intense violence

PG Parental Guidances Suggested (This program contains

material that parents may find unsuitable for younger children.)

D) Some suggestive dialog L) Infrequent coarse language S) Some sexual situations V) Moderate violence

G General Audience (Most parents would find this program

suitable for all ages.)

Y7, Directed to Older Children (This program is designed for

Y7FV children age 7 and above. Note: Programs in which fantasy

violence may be more intense or more combative than other programs in this category are designated Y7FV.)

Y All Children (This program is designed to be appropriate for

all children.)

POWER

RECALL

TV / VIDEO

INFO

123

456

+10

100

FAVORITE

ENTER

TV CBL/SAT VCR DVD

POP DIRECT CH MUTE SLEEP

TV/VCR PAUSE

CH SCAN

REC

FAV

DVDMENU

FAV

VOLCH

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

yzx •

ENTER

Press RECALL to display the rating of the TV program you are currently watching.

STEREO SAP TV L VPG–

ANT

FULL

CABLECLOCK 9 : 2 5

33 34 35

MPAA RATING (Independent rating system for movies)

1. From the V-CHIP menu, press z or y to highlight MPAA RATING, and then press ENTER. MPAA RATING menu appears.

2. Press y or z to highlight MPAA RATING.

3. Press • to lock (“X”) or

MPAA RAT I NG V – CH I P MENU

MPAA RAT I NG

X NC17 PG13 PG GR

XXX

press x to unlock (“✓”).

V-CHIP menu

ENABLE BLOCK I NG TV RAT I NG MPAA RAT I NG BLOCK I NG OPT I ON LOCKS MENU

V – CH I P

Introduction

MOVE::SELECT

The movie ratings you can lock are described as follows:

X : X-rated (For adults only) NC17: Not intended for anyone 17 and under R : Restricted (Under 17 requires accompanying parent or adult

guardian.)

PG13 : Parents Strongly Cautioned (Some material may be

inappropriate for children under 13)

PG : Parental Guidance Suggested (Some material may not be

suitable for children)

G : General Audience (Appropriate for all ages)

BLOCKING OPTION

1. From the V-CHIP menu, press z or y to highlight BLOCKING OPTION, and then press ENTER.

BLOCKING OPTION menu appears.

2. Press y or z to select item.

MPAA UNRATED:

1. Highlight MPAA UNRATED, and then press ENTER.

2. Press y or z to select ON (Lock) or OFF (Unlock) for unrated programs in the MPAA rating system, then press ENTER.

ENABLE BLOCK I NG TV RAT I NG MPAA RAT I NG BLOCK I NG OPT I ON LOCKS MENU

MOVE::STARTENTER

V – CH I P

MPAA UNRATED TV NONE RAT I NG V – CH I P MENU

SELECT:

BLOCK I NG OPT I ON

SETENTER

ON OFF

TV NONE RATING

1. Highlight TV NONE RATING, and then press ENTER.

2. Press y or z to select ON (Lock) or OFF (Unlock) for programs rated NONE in the TV PARENTAL GUIDELINES, then press ENTER.

MOVE::STARTENTER

POWER

RECALL

TV / VIDEO

INFO

123

456

+10

100

FAVORITE

ENTER

TV CBL/SAT VCR DVD

POP DIRECT CH MUTE SLEEP

TV/VCR PAUSE

Caution

CH SCAN

Be aware that setting the TV None Rating to

REC

FAV

DVDMENU

FAV

VOLCH

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

yzx •

ENTER

ON may block the broadcast of emergency information.The menu will display the note, “Enabling this option may block emergency messages” to warn you of this possibility.

your TV

Connecting

Using the

Remote Control

your TV

Setting up

Features

Using the TV’s

Appendix

MPAA UNRATED TV NONE RAT I NG V – CH I P MENU

NOTE : ENABL I NG TH I S OPT I ON

BLOCK I NG OPT I ON

MAY BLOCK EMERGENCY MESSAGES

SELECT:

ON OFF

SETENTER

V-CHIP MENU:

Highlight V-CHIP menu, then press ENTER to return to the V-CHIP menu.

Index

Unlocking programs temporarily

Introduction

your TV

Connecting

Using the

Remote Control

your TV

Setting up

Locking channels

With the CH LOCK feature, you can lock specific channels. The TV will not be able to tune locked channels with the Channel y z buttons or Channel Number buttons, unless you clear the setting.

Features

Using the TV’s

Appendix

You can lock a maximum of nine channels. To lock channels:

1. If you try to watch a TV program that exceeds the rating limits you set, the TV enters program lock mode. After 4 seconds, the TV starts the auto favorite channel search function (see page 38). You can either unlock the program temporarily (see steps 2-4) or select a non-locked program to watch.

After 4 seconds

234

THI S PROGRAM HAS BEEN BLOCKED!

PG L V–

EXCEEDS

SET L I M I TS

PUSH MUTE TO ENTER

INP

CABLE

10 11 12

2. To temporarily unlock the program, press MUTE while the message is on the screen.

3. Press the Number buttons (0-9) to enter your 4-digit PIN code.

BLOCK ACT

ING IVE

ENTER

CODEP

TO TEMPORAR

0– 9 TO SELECT ENTER: TO SET:

UN–BLOCKLY

––––

4. Press ENTER. If the correct code is entered, the program lock mode is released

and the normal picture appears. All locking is disabled until the TV is turned off, and will be

enabled when the TV is turned on again.

1. Make sure the POP is not tuned to a channel you want to lock.

2. From the LOCKS menu, press y or z to highlight CH LOCK, and then press ENTER.

CH LOCK menu appears, and CH INPUT will be highlighted.

3. Press the Channel Number buttons to enter the channel you want to lock.

4. Press ENTER.

CH I NPUT

– – – – – – – – – – – – – – – – – – – – – – – – – – –

CLEAR ALL LOCKS MENU

0–9

SELECT: : SETENTER

CH LOCK

TV CABLE

CH I NPUT

CLEAR ALL LOCKS MENU

0–9

CH LOCK

– – – – – – – – –– – – – – –

– – – – – – – – –

SELECT: : SETENTER

– – –

TV CABLE

9 X

POWER

RECALL

TV / VIDEO

INFO

123

456

+10

100

FAVORITE

ENTER

TV CBL/SAT VCR DVD

POP DIRECT CH MUTE SLEEP

TV/VCR PAUSE

CH SCAN

REC

FAV

DVDMENU

FAV

VOLCH

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

LOCKS menu

V - CH I P CH LOCK V I DEO LOCK NEW P I N CODE

::STARTMOVE ENTER

Note

After programming CH LOCK, change the channel before turning off the TV.

LOCKS

Channel Number

yzx •

ENTER

MUTE

OFF

Index

5. Repeat steps 3 and 4 for other channels.

To unlock individual channels:

1. From the LOCKS menu, press y or z to highlight CH LOCK, then press ENTER.

CH LOCK menu appears.

2. Press yzx • to highlight the channel you want to unlock, then press ENTER.

CH I NPUT

12 18 33

– – – – – – – – –

CLEAR ALL

LOCKS MENU

SELECT::CLEARENTER

CH LOCK

– – – – – –

TV CABLE

– – –

CH I NPUT

CLEAR ALL

LOCKS MENU

CH LOCK

12 18

– – –– – – – – –

– – – – – – – – –

SELECT::CLEARENTER

TV CABLE

– – –

3. Repeat step 2 for other channels.

To unlock all locked channels at once:

Press y or z to highlight CLEAR ALL, and then press ENTER.

CH I NPUT

– – – – – – – – –

CLEAR ALL LOCKS MENU

MOVE::STARTENTER

CH LOCK

– – –– – – – – – – – –– – – – – –

– – –

TV CABLE

RECALL

TV / VIDEO

INFO

123

456

+10

100

FAV

FAVORITE

DVDMENU

ENTER

FAV

TV CBL/SAT VCR DVD

TV/VCR PAUSE

CH SCAN

REC

VOLCH

POP DIRECT CH MUTE SLEEP

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

POWER

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

Introduction

your TV

Connecting

yzx •

ENTER

Using the

Remote Control

your TV

Setting up

Features

Using the TV’s

Appendix

Index

Locking the video inputs

With the VIDEO LOCK feature, you can lock out the input sources (Video 1, Video 2, Video 3, ColorStream HD1, ColorStream HD2,

Introduction

your TV

Connecting

Using the

Remote Control

HDMI) and channels 3 and 4. You will not be able to select the input sources with the TV/VIDEO

button or Channel buttons unless you clear the setting. To set up the video lock:

1. From the LOCKS menu, press y or z to highlight VIDEO LOCK, then press ENTER.

2. Press y or z to highlight the level of video locking you want (Video, Video+, or Off), as follows:

VIDEO : Locks Video 1, Video 2, Video 3, ColorStream HD1,

HD2 and HDMI.

VIDEO+ : Locks Video 1, Video 2, Video 3, ColorStream,

HD1/HD2, HDMI and channels 3 and 4. This option should be used if you use the antenna terminal to play a video tape.

Note: Make sure the main and POP windows are not currently tuned to channel 3 or 4 or one of the video modes.

OFF : Unlocks all video input sources.

V - CH I P CH LOCK V I DEO LOCK NEW P I N CODE

LOCKS

V I DEO V I DEO+

OFF

RECALL

TV / VIDEO

INFO

123

456

+10

100

FAV

FAVORITE

DVDMENU

ENTER

FAV

TV CBL/SAT VCR DVD

TV/VCR PAUSE

CH SCAN

REC

VOLCH

POP DIRECT CH MUTE SLEEP

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

POWER

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

ENTER

your TV

Setting up

Features

Using the TV’s

Appendix

::SETENTER

SELECT:

3. Press ENTER.

Changing the PIN code

1. From the LOCKS menu, press y or z to highlight NEW PIN CODE.

2. Press the Number buttons (0-9) to enter a 4-digit code. The numbers you enter will replace the dashes in the display.

V - CH I P CH LOCK V I DEO LOCK NEW P I N CODE

0–9

3. Press ENTER. The new PIN code is now active.

LOCKS

SELECT: :SETENTER

V I DEO

2562

RECALL

TV / VIDEO

INFO

123

456

+10

100

FAV

FAVORITE

DVDMENU

ENTER

FAV

TV CBL/SAT VCR DVD

TV/VCR PAUSE

CH SCAN

REC

VOLCH

POP DIRECT CH MUTE SLEEP

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

POWER

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

Number

yzx •

ENTER

Index

Adjusting the picture

Selecting the picture mode

You can select your desired picture type from four picture modes: Sports, Standard, Movie, and Preference.

Mode Picture Quality

Sports Bright and dynamic picture (factory setting) Standard Standard picture setting (factory setting) Movie Movie-like picture setting (factory setting) Preference Your personal preference*

*(see “Saving new preference” on page 46.)

To select the picture mode:

1. Press MENU, and then press x or • until the PICTURE menu appears.

2. Press z or y to highlight MODE, and then press ENTER.

3. Press z or y to select the mode you prefer, then press ENTER.

MODE P I CTURE SETT I NGS D I SPLAY FORMAT C I NEMA MODE CONVERGENCE

P I CTURE

RESET SAVE

SELECT::SETENTER

SPORTS

STANDARD

MOV I E

PREFERENCE

Adjusting the picture quality

You can adjust the picture quality to your personal preferences, including the contrast, brightness, color, tint, sharpness, and color temperature.

Note:

If you select one of the factory-set picture modes (SPORTS, STANDARDS, or MOVIE) and then change a picture quality setting (for example, increase the contrast), the picture mode automatically changes to PREFERENCE in the Picture menu.

To save your new picture quality settings, you must select SAVE (see page 46) before closing the Picture menu or the TV will return to the previous picture mode.

TV front panel

VOLUME

CHANNEL

EXITMENU

TV/VIDEO

TouchFocus

x •zy

Introduction

your TV

Connecting

Using the

Remote Control

Selection x Pressing •

contrast lower higher brightness darker lighter color paler deeper tint reddish greenish sharpness softer sharper color temperature cool medium warm

To adjust the picture quality:

1. Press MENU, and then press x or • until the PICTURE menu appears.

2. Press z or y to highlight PICTURE SETTINGS, then press ENTER. PICTURE SETTINGS menu appears.

3. Press y or z until the item you want to adjust is highlighted, then press ENTER.

P CTUREIISETT MODE CONTRAST BRI GHTNESS

COLOR TINT SHARPNESS

RESET SAVE

MOVE::SELECTENTER

NGS ANTENNA

PREFERENCE

100

50 50

4. Press x or • to adjust the level.

CONTRAST 75

The PICTURE qualities you adjusted can be saved in the TV’s memory (see page 46). You can keep these settings or choose factory set options, as described under “Selecting the picture mode” above.

RECALL

TV / VIDEO

INFO

123

456

+10

100

FAV

FAVORITE

DVDMENU

ENTER

FAV

TV CBL/SAT VCR DVD

TV/VCR PAUSE

CH SCAN

REC

VOLCH

POP DIRECT CH MUTE SLEEP

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

POWER

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

your TV

Setting up

yzx •

Features

Using the TV’s

ENTER

Appendix

Index

Saving new preference

You can save the PICTURE qualities (contrast, brightness, color, tint, sharpness, color temperature and CableClear DNR) you adjusted in

Introduction

the picture preference mode. To save your new preferences:

your TV

Connecting

Using the

Remote Control

The picture mode automatically changes to PREFERENCE (see “Selecting the picture mode” on page 45).

Selecting the color temperature

You can change the quality of the picture by selecting from three preset color temperatures: cool, medium, and warm.

To select the color temperature:

your TV

Setting up

1. Press MENU, and then press x or • until the PICTURE menu appears.

2. Press y or z to highlight PICTURE SETTINGS, and then press ENTER.

PICTURE SETTINGS menu appears.

3. Press yzx • to highlight SAVE, and then press ENTER. When complete, SAVE changes to “DONE”.

P CTUREIISETT MODE COLOR TEMPERATURE CableClear DNR P I CTURE MENU

RESET DONE

MOVE::SELECTENTER

NGS

ANTENNA SPORTS

COOL

OFF

1. Press MENU, and then press x or • until the PICTURE menu appears.

2. Press y or z to highlight PICTURE SETTINGS, and then press ENTER.

PICTURE SETTINGS menu appears.

3. Press y or z to highlight COLOR TEMPERATURE, and then press ENTER.

RECALL

TV / VIDEO

INFO

123

456

+10

100

FAV

FAVORITE

DVDMENU

ENTER

FAV

TV CBL/SAT VCR DVD

TV/VCR PAUSE

CH SCAN

REC

VOLCH

POP DIRECT CH MUTE SLEEP

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

POWER

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

yzx •

ENTER

Features

Using the TV’s

Appendix

Index

P CTUREIISETT MODE COLOR TEMPERATURE CableClear DNR P I CTURE MENU

RESET SAVE

MOVE::SELECTENTER

NGS ANTENNA

SPORTS

COOL

OFF

4. Press x or • to select the mode you prefer.

Mode Picture Quality

cool bluish medium neutral warm reddish

Using the CableClear™ DNR feature

CableClear™ DNR reduces visible interference in your TV picture. This is useful when receiving a broadcast with a weak signal (especially a Cable channel) or playing a video cassette or disc damaged by repeated use.

To turn on CableClear™ DNR:

1. Press MENU, and then press x or • until the PICTURE menu appears.

2. Press y or z to highlight PICTURE SETTINGS, and then press ENTER.

PICTURE SETTINGS menu appears.

3. Press y or z to highlight CableClear DNR, and then press ENTER.

P CTUREIISETT MODE COLOR TEMPERATURE

CableClear DNR

P I CTURE MENU

RESET SAVE

MOVE::SELECTENTER

NGS

ANTENNA

SPORTS

COOL OFF

4. Press x or • to select AUTO.

To turn off CableClear DNR:

Select OFF in step 4 above.

POWER

RECALL

TV / VIDEO

INFO

123

456

+10

100

FAVORITE

ENTER

TV CBL/SAT VCR DVD

POP DIRECT CH MUTE SLEEP

TV/VCR PAUSE

Note:

CH SCAN

When in ColorStream or HDMI mode,

REC

“CableClear DNR” display will change to

FAV

DVDMENU

FAV

VOLCH

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

yzx •

ENTER

“DNR”. DNR is not selectable in the HDMI mode.

Introduction

your TV

Connecting

Using the

Remote Control

Resetting picture adjustments

The RESET function adjusts the picture qualities to the following factory settings:

Mode ........................... sports

Contrast ................ max (100)

Brightness ............ center (50)

Color ................... center (50)

Tint ....................... center (0)

Sharpness ............. center (50)

Color temperature........... cool

CableClear DNR ........... auto

To reset the picture adjustments:

1. Press MENU, and then press x or • until the PICTURE menu appears.

2. Press y or z to highlight PICTURE SETTINGS, and then press ENTER. PICTURE SETTINGS menu appears.

3. Press y or z to highlight RESET.

4. Press ENTER until the RESET changes to “DONE”.

P CTUREIISETT MODE COLOR TEMPERATURE

CableClear DNR

P I CTURE MENU

MOVE::STARTENTER

NGS

RESETDONE

ANTENNA SPORTS

COOL

AUTO

your TV

Setting up

Features

Using the TV’s

Appendix

Index

Selecting the display format (for 480p signal only)

This feature is to convert the input signal 480p to 540p or 1080i. To select the display format:

Introduction

your TV

Connecting

Selecting the cinema mode

When you view a DVD movie (3:2 pulldown processed or interlaced mode) from a DVD player connected to the ColorStream (component video) inputs on the TV, smoother and more natural motion can be obtained by setting the CINEMA MODE to FILM (auto).

Using the

To set the CINEMA MODE to FILM (auto):

Remote Control

your TV

Setting up

1. Press MENU, and then press x or • until the PICTURE menu appears.

2. Press y or z to highlight DISPLAY FORMAT, and then press ENTER.

3. Press y or z to select 540p or 1080i as you desire.

MODE P I CTURE SETT I NGS D I SPLAY FORMAT C I NEMA MODE CONVERGENCE

SELECT::SETENTER

P I CTURE

RESET SAVE

1080 i

540p

1. Press MENU, and then press x or • until the PICTURE menu appears.

2. Press y or z to highlight CINEMA MODE, and then press ENTER.

3. Press y or z to select FILM (auto).

MODE P I CTURE SETT I NGS D I SPLAY FORMAT C I NEMA MODE CONVERGENCE

SELECT::SETENTER

P I CTURE

RESET SAVE

F I LM

V I DEO

RECALL

TV / VIDEO

INFO

123

456

+10

100

FAV

FAVORITE

DVDMENU

ENTER

FAV

TV CBL/SAT VCR DVD

TV/VCR PAUSE

CH SCAN

REC

VOLCH

POP DIRECT CH MUTE SLEEP

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

POWER

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

yzx •

ENTER

Features

Using the TV’s

Appendix

Index

To set the CINEMA MODE to VIDEO (off):

Press y or z to select VIDEO in step 3 above.

Selecting the video input source

Press the TV/VIDEO on the remote control or the TV to view a signal from another device connected to your TV, such as a VCR or DVD player (see illustrations below). You can select ANT 1, VIDEO 1, VIDEO 2, VIDEO 3, ColorStream HD1, ColorStream HD2, HDMI, or ANT 2 depending on which input jacks are used for connecting the devices (see “Connecting your TV” on page 8).

SELECT ION

SOURCE

ANT 1

VIDEO 1

VIDEO 2

IDEO

Color Stream

HDM I

ANT 2

7 TO SELECT:

HD1 HD2

Pressing TV/VIDEO on the remote control displays the current signal source (press TV/VIDEO again or 0-7 to change)

TV / V I DEO : TO SELECT

Pressing TV/VIDEO on the TV changes the current signal source

SOURCE

SELECT ION

ANT 1 VIDEO 1 VIDEO 2

IDEO

Color Stream Color Stream

HDM I ANT 2

HD1 HD2

Labeling the video input sources

Note:

• When ColorStream HD 1 or HD 2 is selected, the VIDEO OUT jack does not output a signal. To receive a VIDEO OUT signal, use a standard video or S-video IN connection instead of the ColorStream connection.

• In POP double-window mode, the main window will display 480i signals only. If you select ColorStream HD1 or ColorStream HD2 while the POP picture is active, the message “Not Available” will display.

Note the following regarding the HDMI source selection:

This TV is not intended for connection to and should not be used with a PC (personal computer). See “Connecting a device to the HDMI input” on page 15 for details.

Introduction

your TV

Connecting

The video label feature allows you to label each input source for your TV from the following preset list of labels:

– – – : Uses the default label name VCR : Video cassette recorder DVD : DVD video DTV : Digital TV set-top box SAT : Satellite box CBL : Cable box

To label the video input sources:

1. Press MENU, and then press x or • until the CUSTOM menu appears.

2. Press y or z to highlight VIDEO LABEL.

ON T I MER SLEEP T I MER CC OFF FAVOR I TE CH CH LABEL I NG V I DEO LABEL BACKGROUND

MOVE::STARTENTER

CUSTOM

00h00m

0h00m

SHADED

3. Press ENTER to display the VIDEO LABEL menu.

4. Press y or z to highlight the video source you want to label and then press ENTER.

5. Press y or z to select the desired label for that input source.

V I DEO1 V I DEO2 V I DEO3 ColorStream

ColorStream HDM I CUSTOM MENU

SELECT::SETENTER

V I DEO LABEL

HD1 HD2

– – – VCR DVD DTV SAT CBL

6. Finish labeling the other video sources as desired. To return to the previous menu, press y or z to highlight CUSTOM MENU, and then press ENTER.

7. To exit the menu, press EXIT.

TV front panel

VOLUME

RECALL

TV / VIDEO

INFO

123

456

+10

100

FAV

FAVORITE

DVDMENU

ENTER

FAV

TV CBL/SAT VCR DVD

VOLCH

POWER

CHRTN

ENT

PIC SIZE

CHANNEL

EXIT

TV/VIDEO

EXITMENU

TV/VIDEO

yzx •

EXIT ENTER

TouchFocus

Using the

Remote Control

your TV

Setting up

Features

Using the TV’s

Appendix

Index

Using the closed caption feature

The closed caption feature has two options:

Introduction

To view captions or text:

your TV

Connecting

Using the

Remote Control

your TV

Setting up

• Captions—An on-screen display of the dialogue, narration, and sound effects of TV programs and videos that are closed captioned (usually marked as “CC” in TV listings).

• Text—An on-screen display of information not related to the current program, such as weather or stock data (when provided by individual stations).

1. Tune the TV to the desired program.

2. Press MENU, and then press x or • to display CUSTOM menu.

3. Press y or z to highlight CC, and then press ENTER.

ON T I MER SLEEP T I MER CC FAVOR I TE CH CH LABEL I NG V I DEO LABEL BACKGROUND

SELECT::SETENTER

CUSTOM

OFF

CAPT I ON

TEXT

4. Press y or z to highlight CAPTION or TEXT, and then press ENTER.

ON T I MER SLEEP T I MER CC FAVOR I TE CH CH LABEL I NG V I DEO LABEL BACKGROUND

SELECT::SETENTER

CUSTOM

C1 C2 C3 C4

• To view captions, highlight CAPTION in step 4 above, and then highlight C1, C2, C3, or C4 (C1 displays translation of the primary language in your area).

Note: If the program or video you selected is not closed captioned, no

captions will display on the screen.

POWER

RECALL

TV / VIDEO

INFO

123

456

TV/VCR PAUSE

CH SCAN

Note:

ENTER

TV CBL/SAT VCR DVD

REC

+10

100

FAVORITE

POP DIRECT CH MUTE SLEEP

FAV

DVDMENU

FAV

VOLCH

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

yzx •

ENTER

A closed caption signal may not display in the following situations:

• when a videotape has been dubbed

• when the signal reception is weak

• when the signal reception is nonstandard

Features

Using the TV’s

Appendix

Index

Giant pandas eat leaves.

• To view text, highlight TEXT in step 4 above, and then highlight T1, T2, T3, or T4.

Note: If text is not available in your area, a black rectangle may appear on

your screen. If this happens, turn the Closed Caption feature OFF.

WORLD WEATHER

Temps Current F C Weather LONDON 51 11 MOSCOW PARIS ROME TOKYO

57 14 53 12 66 19 65 18

Clear Cloudy Clear Cloudy Rain

To turn off the Closed Caption feature:

Highlight OFF in step 4.

Setting the ON timer

To set the ON timer to turn the TV on automatically:

1. Press MENU, and then press x or • until the CUSTOM menu appears.

2. Press y or z to highlight ON TIMER, and then press ENTER.

3. Press the Number buttons (0-9) to enter the length of time until the TV turns on automatically. You can set the ON timer in 10 minute increments, up to 12h00m.

4. Press ENTER to start the timer.

ON T I MER SLEEP T I MER CC FAVOR I TE CH CH LABEL I NG V I DEO LABEL BACKGROUND

0–9

SELECT: :SETENTER

CUSTOM

10h30m

5. Press POWER to turn off the TV. The TV will turn on automatically after the length of time you set in the ON Timer.

Setting the sleep timer

To set the sleep timer to turn the TV off automatically:

1. Press SLEEP to set the length of time until the TV turns off.

TV / VIDEO

INFO

POWER

RECALL

123

456

+10

100

FAV

FAVORITE

DVDMENU

ENTER

FAV

TV CBL/SAT VCR DVD

POP DIRECT CH MUTE SLEEP

TV/VCR PAUSE

FREEZE SOURCE

FFREW

SWAP POP CH

CH SCAN

REC

CHRTN

ENT

PIC SIZE

VOLCH

STOP

SKIP / SEARCH

EXIT

PLAY

SPLIT

LIGHT

Number

yzx •

ENTER

SLEEP

Note :

• When an instant power failure occurs, the ON timer and sleep timer settings may be cleared.

• To display the amount of time left until the TV turns on or off automatically, press RECALL.

Introduction

your TV

Connecting

Using the

Remote Control

your TV

Setting up

T I MER

h00m

Every time you press the button, the time display will increase by 10 minutes, up to 3 hours.

0h00m → 0h10m → 0h20m 2h50m → 3h00m → 0h00m

To cancel the sleep timer:

Press SLEEP until it is set to 0h00m.

The timer can also be set using the on-screen menu:

1. Press MENU, and then press x or • until the CUSTOM menu appears.

2. Press y or z to highlight SLEEP TIMER, and then press ENTER.

3. Press the Number buttons (0-9) to enter the length of time until the TV turns off automatically.

4. Press ENTER to start the timer.

ON T I MER SLEEP T I MER CC FAVOR I TE CH CH LABEL I NG V I DEO LABEL BACKGROUND

0–9

SELECT: :SETENTER

CUSTOM

2h00m

Features

Using the TV’s

Appendix

Index

Setting the clock

To set the clock:

Introduction

your TV

Connecting

To display the time on-screen:

Using the

Remote Control

1. Press MENU, and then press x or • until the SET UP menu appears.

2. Press y or z to highlight CLOCK SET, and then press ENTER.

3. Press the Number buttons (0-9) to enter the correct time. The clock operates on a 24-hour cycle.

4. Press ENTER to start the clock.

LANGUAGE CLOCK SET ANT 1 / 2 TV / CABLE CH PROGRAM ADD / ERASE

0–9

SELECT: :SETENTER

SET UP

09:25

Press RECALL.

Note :

If the TV’s power source is interrupted (the power cord is unplugged or a power failure occurs), the clock must be reset.

POWER

RECALL

TV / VIDEO

INFO

123

456

+10

100

FAV

FAVORITE

DVDMENU

FAV

TV CBL/SAT VCR DVD

TV/VCR PAUSE

CH SCAN

REC

VOLCH

POP DIRECT CH MUTE SLEEP

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

RECALL

Number

yzx •

ENTER

your TV

Setting up

Features

Using the TV’s

Appendix

Index

Adjusting the sound

Muting the sound

Press MUTE to temporarily reduce (1/2 MUTE) or turn off (MUTE) the sound. While the sound is off, the screen will display “1/2 MUTE” or “MUTE” in the lower right corner. Every time you press the button, the mute mode will change in the following order.

→ Normal → 1/2 MUTE → MUTE

When you select “MUTE” mode, the closed caption feature is automatically activated. To deactivate this feature, deactivate MUTE. This feature works only when the closed caption mode is set to OFF. See “Using the closed caption feature” on page 50 for more information.

Selecting stereo/SAP broadcasts

The multi-channel TV sound (MTS) feature allows you to listen to high-fidelity stereo sound while watching TV. MTS can also transmit a second audio program (SAP) containing a second language, music, or other audio information (when provided by individual stations).

When the TV receives a stereo or SAP broadcast, the word STEREO or SAP appears on-screen every time the TV is turned on, the channel is changed, or the RECALL button is pressed.

The MTS feature is not available when the TV is in VIDEO mode. To listen to stereo sound:

1. Press MENU, and then press x or • until the AUDIO menu appears.

2. Press y or z to highlight MTS, and then press ENTER.

3. Press y or z to highlight STEREO, and then press ENTER.

TV / VIDEO

123

456

100

FAVORITE

ENTER

TV CBL/SAT VCR DVD

POP DIRECT CH MUTE SLEEP

TV/VCR PAUSE

CH SCAN

REC

TV front panel

RECALL

INFO

+10

FAV

DVDMENU

FAV

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

VOLUME

x •zy

VOLCH

POWER

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

CHANNEL

RECALL

yzx •

ENTER

MUTE

TV/VIDEO

EXITMENU

TouchFocus

Introduction

your TV

Connecting

Using the

Remote Control

your TV

Setting up

MTS AUDIO SETTINGS WOW

SRS 3D FOCUS TruBass

SELECT::SETENTER

AUDIO

STEREO

SAP MONO

You can leave your TV in STEREO mode because it will automatically output the type of sound being broadcast (stereo or monaural). The word “STEREO” or “SAP” displays in yellow in the menu when the TV receives the signal.

If the stereo sound is noisy, select MONO to reduce the noise.

To listen to SAP (if available):

1. Press MENU, and then press x or • until the AUDIO menu appears.

2. Press y or z to highlight MTS, and then press ENTER.

3. Press y or z to highlight SAP, and then press ENTER. You will hear the station’s second audio program (if available) from the speakers, while viewing the original program’s picture (see note at right).

Note :

A second audio program (SAP) can be heard only on those TV stations that offer it.

For example, a station might broadcast music as a second audio program. If you have SAP on, you will see the current program on the screen but hear music instead of the program’s normal audio.

However, if you have SAP on, and the station you are watching is not currently broadcasting a second audio program, the station’s normal audio will be output; however, occasionally there is no sound at all in SAP mode. If this happens, set the MTS feature to STEREO mode.

Features

Using the TV’s

Appendix

Index

Using the WOW™ surround sound feature

WOW is a special combination of SRS Labs audio technologies that creates a thrilling surround sound experience with deep, rich bass

Introduction

from stereo sound sources. Your TV’s audio will sound fuller, richer, and wider.

To adjust the WOW feature:

your TV

Connecting

Using the

Remote Control

Adjusting the sound quality

your TV

Setting up

You can change the quality of your TV’s sound by adjusting the bass, treble, and balance.

To adjust the sound quality:

1. Select STEREO mode (See “Selecting stereo/SAP broadcasts” on page 53).

2. Press MENU, and then press x or • until the AUDIO menu appears.

3. Press y or z to highlight the desired WOW feature you want to adjust, then press ENTER.

• SRS 3D — To turn on or off the surround sound effect.

• FOCUS — To turn on or off the vocal enphasis effect.

• TruBass — To select your desired bass expansion level (HIGH,

LOW or OFF).

MTS AUDIO SETTINGS WOW

SRS 3D FOCUS TruBass

SELECT::SETENTER

AUDIO

OFF

4. Press y or z to adjust the item, then press ENTER.

1. Press MENU, and then press x or • until the AUDIO menu appears.

2. Press y or z to highlight AUDIO SETTINGS, and then press ENTER.

AUDIO SETTINGS menu appears.

Note:

If the broadcast is monaural, the WOW SRS 3D surround sound effect will not work.

POWER

RECALL

TV / VIDEO

INFO

123

456

+10

100

FAVORITE

ENTER

TV CBL/SAT VCR DVD

POP DIRECT CH MUTE SLEEP

TV/VCR PAUSE

CH SCAN

REC

FAV

DVDMENU

FAV

VOLCH

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

yzx •

ENTER

Features

Using the TV’s

Appendix

Index

BASS TREBLE BALANCE RESET AUD I O MENU

RESET SAVE

MOVE::ADJUST

AUD I O ISETT

NGS 70 50

3. Press y or z to highlight the item you want to adjust.

4. Press x or • to adjust the level.

• x makes the sound quality weaker or decreases the balance in the right channel, depending on the item selected.

• • makes the sound quality stronger or decreases the balance in the left channel, depending on the item selected.

SRS WOW, SRS and symbol are trademarks of SRS Labs, Inc. SRS WOW technology is incorporated under license from SRS Labs, Inc.

Resetting your audio adjustments

The RESET function returns the audio adjustments to the following factory settings:

Bass.................. center (50)

Treble ............... center (50)

Balance ............ center (0)

To reset the audio adjustments:

1. Press MENU, and then press x or • until the AUDIO menu appears.

2. Press y or z to highlight AUDIO SETTINGS, and then press ENTER. AUDIO SETTINGS menu appears.

3. Press y or z to highlight RESET, and then press ENTER.

BASS TREBLE BALANCE RESET AUD I O MENU

RESET SAVE

MOVE::ADJUST

AUD I O ISETT

NGS 50 50

Using the StableSound® feature

When the signal source is changed, the StableSound feature limits the highest volume level to prevent extreme changes in volume (for example, to prevent the sudden increase in volume that often happens when a TV program switches to a commercial).

To turn on the StableSound feature:

1. Press MENU, and then press x or • until the AUDIO menu appears.

2. Press y or z to highlight STABLE SOUND, and then press ENTER.

3. Press y or z to select ON, and then press ENTER.

STABLE SOUND SPEAKERS AUD I O OUT

::SETSELECT ENTER

AUDIO

ON OFF

To turn off the StableSound feature:

Select OFF in step 3 above.

RECALL

TV / VIDEO

INFO

123

456

+10

100

FAV

FAVORITE

DVDMENU

ENTER

FAV

TV CBL/SAT VCR DVD

TV/VCR PAUSE

CH SCAN

REC

TV / VIDEO

VOLCH

POP DIRECT CH MUTE SLEEP

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

RECALL

INFO

123

456

+10

100

FAV

FAVORITE

DVDMENU

ENTER

FAV

TV CBL/SAT VCR DVD

TV/VCR PAUSE

CH SCAN

REC

VOLCH

POP DIRECT CH MUTE SLEEP

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

POWER

CHRTN

ENT

PIC SIZE

POWER

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

EXIT

PLAY

SPLIT

LIGHT

Introduction

yzx •

ENTER

your TV

Connecting

Using the

Remote Control

your TV

Setting up

yzx •

ENTER

Features

Using the TV’s

Appendix

Index

Turning off the built-in speakers

Use this feature to turn the TV speakers off when you connect an audio system (See “Connecting an audio system” on page 16).

Introduction

To turn off the built-in speakers:

your TV

Connecting

To turn on the built-in speakers:

Selecting the Audio OUT sound

Using the

Remote Control

This feature allows you to select the sound source (MAIN or POP) that is output from the Audio OUT terminals (for example, see “Connecting two VCRs” on page 14).

This is useful when amplifying or recording the POP sound with external equipment while listening to the sound of the main picture through the built-in speakers.

To select the Audio OUT sound:

your TV

Setting up

1. Press MENU, then press x or • until AUDIO menu appears.

2. Press y or z to highlight SPEAKERS, and then press ENTER.

3. Press y or z to select OFF, and then press ENTER.

STABLE SOUND SPEAKERS AUD I O OUT

::SETSELECT ENTER

AUDIO

ON OFF

Select ON in step 3 above.

1. Press MENU, and then press x or • until the AUDIO menu appears.

2. Press y or z to highlight AUDIO OUT, and then press ENTER.

3. Press y or z to select MAIN or POP, and then press ENTER.

Note:

Make sure the volume control of your audio amplifier is set to a moderate listening level.

POWER

RECALL

TV / VIDEO

INFO

123

456

+10

100

FAVORITE

ENTER

TV CBL/SAT VCR DVD

POP DIRECT CH MUTE SLEEP

TV/VCR PAUSE

Note:

CH SCAN

• When the POP window is closed, the sound

REC

FAV

DVDMENU

FAV

VOLCH

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

yzx •

ENTER

of the main program is output through the AUDIO OUT terminals, even if POP is selected in the AUDIO OUT menu.

• The sound of the main program is always output through the TV speakers, regardless of the AUDIO OUT setting.

Features

Using the TV’s

Appendix

Index

STABLE SOUND SPEAKERS AUD I O OUT

::SETSELECT ENTER

AUDIO

MA I N POP

• MAIN : Outputs the sound of the main (left window) program.

• POP : Outputs the sound of the POP (right window) program.

Selecting the background of the menu display

You can change the background of the menu display by selecting from two preset types: shaded and solid (gray).

To select the background:

1. Press MENU, and then press x or • until the CUSTOM menu appears.

2. Press y or z to highlight BACKGROUND, and then press ENTER.

3. Press y or z to select either a SHADED or SOLID background, and then press ENTER.

ON T I MER SLEEP T I MER CC FAVOR I TE CH CH LABEL I NG V I DEO LABEL BACKGROUND

::SETSEL ECT ENTER

CUSTOM

SHADED

SOL I D

Displaying on-screen information

Press RECALL to display the following information on-screen:

• Antenna mode (when in TV mode)

• Channel number or VIDEO mode selected

• Time (if set)

• Remaining time of ON/SLEEP timer (if set)

• Channel label (if set)

• Video label (when in video mode)

• Stereo or SAP audio status

• V-CHIP rating status

• Picture size

STEREO SAP

DL SVPG–

MER

ON T SLEEP T I MER

12h34m

1h23m

33 34 35

1 2 3 4

TV D L S VPG–

MER

CLOCK

12h34m

1h23m

ColorStream12: 3

ON T

SLEEP T I MER

7 8 9 10 11 12 13 14

ANT

15 16

ABCDFULL

THEATER W I DE 1

CABLECLOCK 9 : 2 5

33 34 35

DVD HD1

33 34 35

POWER

RECALL

TV / VIDEO

INFO

RECALL

Introduction

123

456

+10

100

FAVORITE

ENTER

TV CBL/SAT VCR DVD

POP DIRECT CH MUTE SLEEP

TV/VCR PAUSE

CH SCAN

REC

FAV

DVDMENU

FAV

VOLCH

STOP

FREEZE SOURCE

FFREW

SKIP / SEARCH

SWAP POP CH

CHRTN

ENT

PIC SIZE

EXIT

PLAY

SPLIT

LIGHT

yzx •

ENTER

your TV

Connecting

Using the

Remote Control

your TV

Setting up

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18

Features

Using the TV’s

Understanding the auto power off feature

The TV will automatically turn itself off after approximately 15 minutes if it is tuned to a vacant channel or a station that completes its broadcast for the day. This feature does not work in VIDEO mode.

Understanding the last mode memory feature

If the power is cut off while you are viewing the TV, the Last Mode Memory feature turns the TV on automatically when the power is resupplied.

If the power is going to be off for a long time and you are going to be away from your TV, unplug the power cord to prevent the TV from turning on in your absence.

Appendix

Index

Appendix

Introduction

Specifications

• Design and specifications are subject to change without notice.

Television System

your TV

Connecting

Channel Coverage

Using the

Power Source

Remote Control

Power Consumption

Audio Power

your TV

Setting up

Speaker Type

Video/Audio Terminals

Features

Using the TV’s

Appendix

Index

WARNING: RISK OF ELECTRIC SHOCK !

Never attempt to service the TV yourself. Opening and removing the covers may expose you to dangerous voltage

or other hazards. Refer all servicing to a Toshiba Authorized Service Center.

NTSC standard

VHF: 2 through 13 UHF: 14 through 69 Cable TV: Mid band (A-8 through A-1, A through I)

Super band (J through W) Hyper band (AA through ZZ, AAA, BBB) Ultra band (65 through 94, 100 through 125)

120 V AC, 60 Hz

185 W (average)

15 W + 15 W

46H84: Two 4-3/4 inches (12 cm) round 51H84: Two 6-5/16 inches (16 cm) round 57H84: Two 6-5/16 inches (16 cm) round 65H84: Two 6-5/16 inches (16 cm) round

S-VIDEO INPUT

Y : 1 V(p-p), 75 ohms, negative sync. C : 0.286 V(p-p) (burst signal), 75 ohms

VIDEO/AUDIO INPUT

VIDEO: 1 V(p-p), 75 ohms, negative sync. AUDIO: 150 mV(rms) (30% modulation equivalent,

22 k ohms or more)

ColorStream

Y : 1V(p-p), 75 ohms P P AUDIO: 150 mV(rms), 22 k ohms or more

VIDEO/AUDIO OUTPUT

VIDEO: 1 V(p-p), 75 ohms, negative sync. AUDIO: 150 mV(rms) (30% modulation equivalent,

VARIABLE AUDIO OUTPUT

0–300 mV(rms) (30% modulation equivalent,

2.2 k ohms or less)

HDMI INPUT

HDMI type A Suggested scan rates: 1080i, 720p, 480p, 480i

(component video) INPUT

R: 0.7 V(p-p), 75 ohms B: 0.7 V(p-p), 75 ohms

2.2 k ohms or less)

Dimensions

46H84: Width 43-3/8 inches (1,100 mm)

Height 40-1/2 inches (1,026 mm) Depth 21-7/8 inches (555 mm)

51H84: Width 47-9/16 inches (1,206 mm)

Height 50-1/2 inches (1,280 mm) Depth 22-1/2 inches (570 mm)

57H84: Width 52-3/4 inches (1,340 mm)

Height 55-3/4 inches (1,415 mm) Depth 23-7/8 inches (606 mm)

65H84: Width 59-7/8 inches (1,521mm)

Height 59-7/8 inches (1,521mm) Depth 26-1/4 inches (665 mm)

Mass

46H84: 143 lbs (65.0 kg) 51H84: 169 lbs (76.0 kg) 57H84: 204 lbs (92.0 kg) 65H84: 240 lbs (108 kg)

Supplied Accessories

Remote Control with 2 size “AA” alkaline batteries

Optional TV Stand

46H84: ST4663

Troubleshooting

Before calling a service technician, please check the following table for a possible cause of the symptom and some solutions.

Symptom Solution

TV will not turn on • Make sure the power cord is plugged in, then press POWER.

• The remote control batteries may be dead. Replace the batteries.

No picture, no sound • Check the antenna/cable connections.

Introduction

No sound, picture OK • The sound may be muted. Press VOLUME.

• The station may have broadcast difficulties. Try another channel.

• Make sure the SPEAKERS function in AUDIO menu is set properly.

• Make sure “STEREO” is selected (page 53).

Poor picture, sound OK • Check the antenna connections.

• The station may have broadcast difficulties. Try another channel.

• Adjust the PICTURE menu.

Poor reception of broadcast channels • The station may have broadcast difficulties. Try another channel.

• Check the antenna connections.

• If you are using a VCR, make sure the TV/VCR button is set correctly.

Cannot receive above channel 13 • Make sure the TV/CABLE switch is set to the mode that

corresponds with the signal source type (cable company or outside antenna).

Black box appears on the screen • The closed caption feature may be set to one of the Text modes (T1,

T2, T3, or T4). Turn closed captioning OFF.

Unable to select a certain channel • The channel may be locked out with the CH LOCK feature, or

erased with the ADD/ERASE feature.

your TV

Connecting

Using the

Remote Control

your TV

Setting up

Multiple images • The station may have broadcast difficulties. Try another channel.

• Antenna reception may be poor. Use a highly directional outdoor antenna.

Poor color or no color • The station may have broadcast difficulties. Try another channel.

• Adjust the TINT and/or COLOR in the PICTURE menu.

No stereo or SAP sound from a • Make sure the MTS feature is set properly. known MTS broadcast

The remote control does not operate • Check whether the appropriate device mode is selected.

• Remove all obstructions between the remote control and the remote control sensor in the TV.

• The remote control batteries may be dead. Replace the batteries.

Cannot access signal input sources • Check the VIDEO LOCK feature. (Video1, Video2, Video3, ColorStream HD1/HD2, HDMI) and/or Channels 3 and 4.

Features

Using the TV’s

Appendix

Index

Limited United States Warranty

for 27'' FST PURE® and All Larger Television Models

Introduction

your TV

Connecting

Using the

Remote Control

your TV

Setting up

Features

Using the TV’s

Appendix

Index

Toshiba America Consumer Products, L.L.C. (“TACP”) makes the following limited warranties to original consumers in the United States.

THESE LIMITED WARRANTIES EXTEND TO THE ORIGINAL CONSUMER PURCHASER OR ANY PERSON RECEIVING THIS TELEVISION AS A GIFT FROM THE ORIGINAL CONSUMER PURCHASER AND TO NO OTHER PURCHASER OR TRANSFEREE.

PRODUCTS PURCHASED IN THE U.S.A. AND USED IN CANADA ARE NOT COVERED BY THESE WARRANTIES.

PRODUCTS PURCHASED IN CANADA AND USED IN THE U.S.A. ARE NOT COVERED BY THESE WARRANTIES.

Limited One (1) Year Warranty on Parts and Labor*

TACP warrants this television and its parts against defects in materials or workmanship for a period of one (1) year after the date of original retail purchase. DURING THIS PERIOD, TACP

WILL, AT TACP’S OPTION, REPAIR OR REPLACE A DEFECTIVE PART WITH A NEW OR REFURBISHED PART WITHOUT CHARGE TO YOU FOR PARTS OR LABOR. TA CP

Authorized Service Station personnel will come to your home when warranty service is required. Depending on the type of repair required, either the service will be performed in your home or the set will be taken to the TACP Authorized Service Station for repair and returned to your home at no cost to you.

Limited Two (2) Year Warranty on Picture Tube*

TACP warrants the picture tube in this television against defects in materials or workmanship for a period of two (2) years after the date of original retail purchase. DURING THIS PERIOD,

TACP WILL, AT TACP’S OPTION, REPAIR OR REPLACE A DEFECTIVE PICTURE TUBE WITH A NEW OR REFURBISHED PICTURE TUBE WITHOUT CHARGE TO YOU. LABOR CHARGES FOR PICTURE TUBE REPLACEMENT ARE NOT COVERED UNDER THIS WARRANTY AFTER ONE (1) YEAR FROM THE DATE OF THE ORIGINAL RETAIL PURCHASE.

TACP Authorized Service Station personnel will come to your home when warranty service is required. Depending on the type of repair required, either the service will be performed in your home or the set will be taken to the TACP Authorized Service Station for repair and returned to your home at no cost to you.

Rental Units

The warranty for rental units begins with the date of first rental or thirty (30) days from the date of shipment to the rental firm, whichever comes first.

*Limited Warranty for Commercial Units

TACP warrants televisions sold and used for commercial purposes as follows: all parts are warranted against defects in materials or workmanship for a period of ninety (90) days after the date of original retail purchase. DURING THIS PERIOD,

TACP WILL, AT TACP’S OPTION, REPAIR OR REPLACE A DEFECTIVE PART WITH A NEW OR REFURBISHED PART WITHOUT CHARGE TO YOU.

Owner’s Manual and Product Registration Card

Read this owner’s manual thoroughly before operating this television.

Complete and mail the enclosed product registration card or register your product online at as soon as possible. By registering your product you will enable TACP to provide you with better customer service and improved product support. Failure to register your product will not affect your rights under this warranty.

www.tacp.toshiba.com/service

Your Responsibility

THE ABOVE WARRANTIES ARE SUBJECT TO THE FOLLOWING CONDITIONS:

(1) You must provide your bill of sale or other proof of purchase. (2) All warranty servicing of this television must be performed by

an Authorized TACP Service Station. These warranties from TACP are effective only if the television is

(3)

purchased and operated in the U.S.A. or Puerto Rico.

(4) Labor charges for installation, setup, adjustment of customer

controls, and installation or repair of antenna systems are not covered by these warranties. Reception problems caused by inadequate antenna systems are your responsibility.

(5) Warranties extend only to defects in materials or

workmanship as limited above, and do not extend to any television or parts that have been lost or discarded by you or to damage to the television or parts caused by fires, misuse, accident, Acts of God (such as lightning or fluctuations in electric power), improper installation, improper maintenance, use in violation of instructions furnished by TACP, or misuse or malfunction through simultaneous use of this product and connected equipment; or to units that have been modified or had the serial number removed, altered, defaced, or rendered illegible.

How to Obtain Warranty Services

If, after following all of the operating instructions in this manual and checking the “Troubleshooting” section, you find that service is needed:

(1) To find the nearest TACP Authorized Service Station, visit

TACP’s web site at www.tacp.toshiba.com/service or call toll free 1-800-631-3811.

(2) Present your bill of sale or other proof of purchase to the

Authorized Service Station.

For additional information, visit TACP’s web site:

ALL WARRANTIES IMPLIED BY THE LAW OF ANY STATE OF THE U.S.A., INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE EXPRESSLY LIMITED TO THE DURATION OF THE LIMITED WARRANTIES SET FORTH ABOVE. WITH THE EXCEPTION OF ANY WARRANTIES IMPLIED BY THE LAW OF ANY STATE OF THE U.S.A. AS HEREBY LIMITED, THE FOREGOING WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, GUARANTEES, AGREEMENTS, AND SIMILAR OBLIGATIONS OF TACP WITH RESPECT TO THE REPAIR OR REPLACEMENT OF ANY PARTS. IN NO EVENT SHALL TACP BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES.

No person, agent, distributor, dealer, or company is authorized to change, modify, or extend the terms of these warranties in any manner whatsoever. The time within which action must be commenced to enforce any obligation of TACP arising under this warranty or under any law of the United States or of any state thereof is hereby limited to 90 days from the date you discover, or should have discovered, the defect. This limitation does not apply to implied warranties arising under the law of any state of the U.S.A.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH MAY VARY FROM STATE TO STATE IN THE U.S.A. SOME STATES OF THE U.S.A. DO NOT ALLOW LIMITATIONS ON THE DURATION OF AN IMPLIED WARRANTY, LIMITATIONS ON THE TIME WITHIN WHICH AN ACTION MAY BE BROUGHT, OR THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES; THEREFORE, THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU UNDER SUCH CIRCUMSTANCES.

FST PURE® is a registered trademark of Toshiba America Consumer Products, L.L.C.

www.tacp.toshiba.com

041504

Limited Canada Warranty

for 32'' and Larger Television Models

Toshiba of Canada Limited (“TCL”) makes the following limited warranties to original consumers in Canada.

THESE LIMITED WARRANTIES EXTEND TO THE ORIGINAL CONSUMER PURCHASER OR ANY PERSON RECEIVING THIS TELEVISION AS A GIFT FROM THE ORIGINAL CONSUMER PURCHASER AND TO NO OTHER PURCHASER OR TRANSFEREE.

PRODUCTS PURCHASED IN THE U.S.A. AND USED IN CANADA ARE NOT COVERED BY THESE WARRANTIES.

PRODUCTS PURCHASED IN CANADA AND USED IN THE U.S.A. ARE NOT COVERED BY THESE WARRANTIES.

Limited One (1) Year Warranty on Parts and Labor*

TCL warrants this television and its parts against defects in materials or workmanship for a period of one (1) year after the date of original retail purchase. DURING THIS PERIOD, TCL

WILL, AT TCL’S OPTION, REPAIR OR REPLACE A DEFECTIVE PART WITH A NEW OR REFURBISHED PART WITHOUT CHARGE TO YOU FOR PARTS OR LABOR. TCL Authorized

Service Depot personnel will come to your home when warranty service is required. Depending on the type of repair required, either the service will be performed in your home or the set will be taken to the TCL Authorized Service Depot for repair and returned to your home at no cost to you. IN-HOME SERVICE

ONLY APPLIES WITHIN 100 KILOMETERS OF AN AUTHORIZED TCL SERVICE DEPOT.

Limited Two (2) Year Warranty on Picture Tube*

TCL warrants the picture tube in this television against defects in materials or workmanship for a period of two (2) years after the date of original retail purchase. DURING THIS PERIOD, TCL

WILL, AT TCL’S OPTION, REPAIR OR REPLACE A DEFECTIVE PICTURE TUBE WITH A NEW OR REFURBISHED PICTURE TUBE WITHOUT CHARGE TO YOU. LABOR CHARGES FOR PICTURE TUBE REPLACEMENT ARE NOT COVERED UNDER THIS WARRANTY AFTER ONE (1) YEAR FROM THE DATE OF THE ORIGINAL RETAIL PURCHASE. TCL Authorized Service

Depot personnel will come to your home when warranty service is required. Depending on the type of repair required, either the service will be performed in your home or the set will be taken to the TCL Authorized Service Depot for repair and returned to your home at no cost to you. IN-HOME SERVICE ONLY APPLIES

WITHIN 100 KILOMETERS OF AN AUTHORIZED TCL SERVICE DEPOT.

Rental Units

The warranty for rental units begins with the date of first rental or thirty (30) days from the date of shipment to the rental firm, whichever comes first.

*Limited Warranty for Commercial Units

TCL warrants televisions sold and used for commercial purposes as follows: all parts are warranted against defects in materials or workmanship for a period of ninety (90) days after the date of original retail purchase. DURING THIS PERIOD, TCL WILL, AT

TCL’S OPTION, REPAIR OR REPLACE A DEFECTIVE PART WITH A NEW OR REFURBISHED PART WITHOUT CHARGE TO YOU.

Owner’s Manual and Product Registration

Read this owner’s manual thoroughly before operating this television.

Register your product online at possible. By registering your product you will enable TCL to provide you with better customer service and improved product support. Failure to register your product will not affect your rights under this warranty.

www.toshiba.ca

as soon as

Your Responsibility

THE ABOVE WARRANTIES ARE SUBJECT TO THE FOLLOWING CONDITIONS:

(1) You must provide your bill of sale or other proof of purchase. (2) All warranty servicing of this television must be performed by

an Authorized TCL Service Depot.

(3) These warranties from TCL are effective only if the television

is purchased in Canada from an authorized TCL dealer and operated in Canada.

(4) Labor charges for installation, setup, adjustment of customer

controls, and installation or repair of antenna systems are not covered by these warranties. Reception problems caused by inadequate antenna systems are your responsibility.

(5) Warranties extend only to defects in materials or

workmanship as limited above, and do not extend to any television or parts that have been lost or discarded by you or to damage to the television or parts caused by fires, misuse, accident, Acts of God (such as lightning or fluctuations in electric power), improper installation, improper maintenance, use in violation of instructions furnished by TCL, or misuse or malfunction through simultaneous use of this product and connected equipment; or to units that have been modified or had the serial number removed, altered, defaced, or rendered illegible.

How to Obtain Warranty Services

If, after following all of the operating instructions in this manual and checking the “Troubleshooting” section, you find that service is needed:

(1) To find the nearest TCL Authorized Service Depot, visit TCL’s

web site at www.toshiba.ca.

(2) Present your bill of sale or other proof of purchase to the

Authorized Service Depot.

For additional information, visit TCL’s web site:

ALL WARRANTIES IMPLIED BY THE LAW OF ANY PROVINCE OF CANADA, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE EXPRESSLY LIMITED TO THE DURATION OF THE LIMITED WARRANTIES SET FORTH ABOVE. WITH THE EXCEPTION OF ANY WARRANTIES IMPLIED BY THE LAW OF ANY PROVINCE OF CANADA AS HEREBY LIMITED, THE FOREGOING WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, GUARANTEES, AGREEMENTS, AND SIMILAR OBLIGATIONS OF TCL WITH RESPECT TO THE REPAIR OR REPLACEMENT OF ANY PARTS. IN NO EVENT SHALL TCL BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES.

No person, agent, distributor, dealer, or company is authorized to change, modify, or extend the terms of these warranties in any manner whatsoever. The time within which action must be commenced to enforce any obligation of TCL arising under this warranty or under any law of Canada or of any province thereof is hereby limited to 90 days from the date you discover, or should have discovered, the defect. This limitation does not apply to implied warranties arising under the law of any province of Canada.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH MAY VARY FROM PROVINCE TO PROVINCE IN CANADA. SOME PROVINCES OF CANADA DO NOT ALLOW LIMITATIONS ON THE DURATION OF AN IMPLIED WARRANTY, LIMITATIONS ON THE TIME WITHIN WHICH AN ACTION MAY BE BROUGHT, OR THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES; THEREFORE, THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU UNDER SUCH CIRCUMSTANCES.

FST PURE® is a registered trademark of Toshiba America Consumer Products, L.L.C.

www.toshiba.ca

041504

Introduction

your TV

Connecting

Using the

Remote Control

your TV

Setting up

Features

Using the TV’s

Appendix

Index

Introduction

your TV

Connecting

A/V cables (standard) ......................................................... 8

ANT 1/2 ...................................................................................23

Antenna cables (coaxial) ................................................... 8

AUDIO OUT sound, selecting ....................................... 56

Audio system connection................................................. 16

Auto aspect........................................................................... 34

Auto convergence ...............................................................26

Auto favorite .................................................................. 38, 42

Auto power off...................................................................... 57

BACKGROUND selection ................................................57

Back of the TV ........................................................................ 7

CableClear™ DNR ...............................................................47

Cable converter box connection ...................................10

Camcorder connection...................................................... 14

CH yz buttons.................................................................... 25

Using the

Remote Control

your TV

Setting up

Channel Return ....................................................................28

CH LABELING ......................................................................30

CH LOCK................................................................................. 42

CH RTN button .....................................................................28

Channel Number buttons ................................................25

Channel programming

Cinema mode ........................................................................48

Clock, setting ........................................................................52

Closed caption......................................................................50

Color temperature ...............................................................46

ColorStream (component) cables ................................... 8

Convergence adjustment .................................................26

Display format...................................................................... 48

Double-window (“POP”) feature ...................................35

DTV receiver connection .................................................. 13

DVD connection........................................................... 11, 12

Features

Using the TV’s

F G H

FAV yz buttons ..................................................................29

FAVORITE button .................................................................38

Favorite channels, programming...................................28

Front of the TV ........................................................................ 7

HDMI connection........................................................ 15, 16

L M

Labeling channels ...............................................................30

Labeling video inputs ........................................................49

Appendix

Language selection ............................................................23

Last mode memory .............................................................57

Locking channels ................................................................42

Locking video inputs ......................................................... 44

Locks menu ...........................................................................39

Menu system......................................................................... 22

MTS feature ........................................................................... 53

MUTE button ......................................................................... 53

O P

Index

ON timer .................................................................................51

ADD/ERASE .....................................................................25

Automatic programming .............................................24

TV/CABLE selection ...................................................... 24

Picture adjustments

COLOR TEMPERATURE ..............................................46

Picture mode ....................................................................45

Picture quality ..................................................................45

Picture-out-picture (POP)

CH SCAN button ............................................................ 37

POP CH yz buttons..................................................... 35

POP DIRECT CH button ...............................................35

SOURCE button ..............................................................35

SPLIT button .....................................................................35

SWAP button ....................................................................36

Picture scroll..........................................................................33

Picture size selection .........................................................31

POP Window..........................................................................35

Q R

RECALL button .................................................................... 57

Remote control

Battery installation .........................................................17

Learning about the buttons........................................ 21

Programming.................................................................... 18

RESET ............................................................................... 47, 55

SAP sound ..............................................................................53

Satellite receiver connection...........................................11

Scrolling the Theater Wide picture...............................33

Set-top box ............................................................................13

Sleep timer .............................................................................51

Sound quality adjustments ..............................................54

SPEAKERS on/off ...............................................................56

Specifications........................................................................58

SRS 3D surround.................................................................54

StableSound

Stereo sound .........................................................................53

SurfLock™...............................................................................28

S-video cables ........................................................................ 8

........................................................................55

Theater wide picture ..........................................................32

TouchFocus™ .........................................................................26

Troubleshooting .................................................................. 59

TV/VIDEO button ......................................................... 28, 49

V-CHI P

BLOCKING OPTION ......................................................41

ENABLE BLOCKING .................................................... 40

MPAA RATING ................................................................41

NEW PIN CODE ............................................................. 44

TV RATING ........................................................................40

Unlocking programs temporarily..............................42

VCR connection ..................................................................... 9

VIDEO LABEL ...................................................................... 49

VIDEO LOCK .........................................................................44

Warranty.......................................................................... 60, 61

WOW srround sound feature......................................... 54

Note

Introduction

your TV

Connecting

Using the

Remote Control

your TV

Setting up

Features

Using the TV’s

Appendix

Index

HEAD OFFICE: 82 TOTOWA ROAD, WAYNE, NJ 07470, U.S.A. NATIONAL SERVICE DIVISION:1420-B TOSHIBA DRIVE, LEBANON, TN 37087, U.S.A.

HEAD OFFICE: 191 McNABB STREET, MARKHAM, ONTARIO, L3R 8H2, CANADA – TEL: (905) 470-5400 SERVICE CENTERS:

TORONTO: 191 McNABB STREET, MARKHAM, ONTARIO L3R 8H2, CANADA – TEL: (905) 470-5400 MONTREAL: 18050 TRANS CANADA, KIRKLAND, QUEBEC, H9J 4A1, CANADA – TEL: (514) 390-7766 VANCOUVER: 22171 FRASERWOOD WAY, RICHMOND, B.C., V6W 1J5, CANADA – TEL: (604) 303-2500

MANUFACTURED BY

ColorStream and StableSound are registered trademarks of Toshiba America Consumer Products, L.L.C. CableClear, TouchFocus, and SurfLock are trademarks of Toshiba America Consumer Products, L.L.C.

PRINTED IN USA

(04-05)

Toshiba SRS 57H84C, SRS 51H84C, SRS 46H84C, SRS 51H84, SRS 65H84 User Manual 2

Specifications and Main Features

Frequently Asked Questions

User Manual
