Toshiba SL-9000N-FFH-QR, SL-9000-FFH-CA, SL-9000-FFH-QR, EM1-31076EE, SL-9000N-FFH-US User Manual

...
TEC Electronic Computing Scale
SL-9000/9000N-FFH-US/CA/QR
Owner’s Manual

TABLE OF CONTENTS

Page
1. INTRODUCTION..................................................................................................... 1- 1
2. SPECIFICATION..................................................................................................... 2- 1
3. APPEARANCE........................................................................................................ 3- 1
4. DISPLAY................................................................................................................. 4- 1
5. KEY LAYOUT ......................................................................................................... 5- 1
6. PROCEDURE BEFORE OPERATION ..................................................................... 6- 1
7. INSTALLATION PROCEDURE ............................................................................... 7- 1
8. REMOVAL AND REPLACEMENT OF RECEIPT/LABEL......................................... 8- 1
9. OUTLINE OF OPERATION..................................................................................... 9- 1
10. PROGRAMMING PROCEDURES ........................................................................... 10- 1
10.5 PLU VERIFYING LABEL ............................................................................... 10-12
10.6 ADDRESS AND COMMERCIAL MESSAGE SETTING.................................. 10-13
10.7 COMBINATION MESSAGE........................................................................... 10-14
10.8 SPECIAL INFORMATION.............................................................................. 10-16
10.9 GRADE LINE................................................................................................. 10-16
10.10 SPEED KEY SETTING.................................................................................. 10-17
10.11 PRINT FORMAT............................................................................................ 10-18
10.12 DATE/TIME SETTING................................................................................... 10-20
10.13 CMT/PL-3...................................................................................................... 10-20
10.14 IN-LINE/LOCAL............................................................................................. 10-23
10.15 LON SYSTEM............................................................................................... 10-24
10.16 BAR CODE FORMAT.................................................................................... 10-26
10.17 TITLES.......................................................................................................... 10-28
10.18 TRANSFERRING LOGO DATA..................................................................... 10-29
10.19 IDIOM SETTING............................................................................................ 10-30
10.20 VENDOR SETTING....................................................................................... 10-31
10.21 FREE FORMAT SETTING............................................................................. 10-32
Page
CAUTION:
WARNING!
11. PROGRAMMED DATA VERIFICATION REPORTS ................................................. 11- 1
12. PASSWORD SECURITY.........................................................................................12- 1
13. OPERATING PROCEDURES..................................................................................13- 1
13.5 ISSUING LABELS WITH NET WEIGHT STATEMENT
(FOR US TYPE ONLY)..................................................................................13- 9
13.6 TARE/SAVE FUNCTION PROCEDURES ......................................................13-11
13.7 CALLING AND PRINTING GRADE LINES.....................................................13-12
13.8 CALLING AND PRINTING LOGOS................................................................13-13
13.9 SELECTING PRINT ITEM..............................................................................13-14
13.10 DATE CHANGE.............................................................................................13-15
13.11 BATCH PRINT MODE (with 30 Items Run Assignment)................................. 13-16
13.12 VISUAL COMMODITY LIBRARY ...................................................................13-19
13.13 FLOATING VENDOR.....................................................................................13-20
14. TOTAL OPERATION............................................................................................... 14- 1
15. ERROR MESSAGE TABLE ..................................................................................... 15- 1
16. CLEANING THE PRINT HEAD................................................................................16- 1
17. TROUBLESHOOTING.............................................................................................17- 1
1. The installation should be authorized installing dealer. Please contact your nearest TOSHIBA TEC representative.
2. Installation by anyone except an authorized installing dealer will release the manufacturer from all liabliity for damage or injury to users.
3. Scale is prohibited to be hung from a plaster or wooden board. It has to be installed on structual materials (concrete, steel frame, beam and pillar, etc.)
4. Do not exceed the platter weight of maximum capacity. Or hang any item from the scale which exceed the platter weight.
1. This manual may not be copied in whole or in part without prior written permission of TOSHIBA TEC.
2. The contents of this manual may be changed without notification.
3. Please refer to your local Authorized Service representative with regard to any queries you may have in this manual.
Copyright 2001 by TOSHIBA TEC CORPORATION All Rights Reserved 570 Ohito, Ohito-cho, Tagata-gun, Sizuoka-ken, JAPAN

1. INTRODUCTION

manual, may cause harmful interference to radio communications. Operations of this equipment in a
1. INTRODUCTION
1. INTRODUCTION
Thank you for purchasing the TEC SL-9000 electronic computing scale. The TEC SL-9000 is designed to be hung from the ceiling. As you will discover, it has many features and functions designed for user friendliness as well as complete customer satisfaction. The 256x64 dot fluorescent display provides customers with ample information, the 216 speed keys realize a higher degree of operability, and the 3 inch/sec. print speed ensures fast and clear printing. Password security prevents unauthorized access to the PROG., M.DOWN, REWRAP, REPORT and RESET modes. The latest high speed in-line system, Local Operation Network (LON), allows easy system configuration and greater throughput. Various options, including a TMCC Interface, etc., are selectable in accordance with your needs. We believe that your needs will now be fully satisfied, and you will have total reliability in price calculation. Should you have any questions concerning the scale, please refer to this manual. Be sure to keep this manual for future reference.
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. (for USA only)
Changes or modifications not expressly approved by manufacturer for compliance could void the user’s authority to operate the equipment.
“This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.” “Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.”
(for CANADA only)
Some procedures described in this manual may be illegal in various state jurisdictions. When there are optional settings to enable various functions or to disable functions. Please ensure that the optional settings for scale operation meet the local requirements of weights and measures. If you are uncertain of specific items, contact the state or county office of weights and measures for clarification.
1-1
1. INTRODUCTION
(EM1-31076)
(24089500013)
Sealing Lead
report (US type only)
Platter Arm
Platter Mount Plate
Platter
Stranded Wire
Nut (N-6)
Rubber Pipe Cover
Hanging Support (R)
Pipe Spacer
(M-6x60)
ex.) US, CA, QR, etc.

1.1 APPLICABLE MODEL

• SL-9000-15M-FFH-CA • SL-9000-30M-N-FFH-US
• SL-9000-15M-FFH-QR • SL-9000-15M-N-FFH-CA
• SL-9000-15M-N-FFH-QR
The description of the model number is as follows.
SL-9000-30M-N-FFH-US
Max. Capacity
30M: 30 lbs (decimal pound
/multi-interval)
15M: 15 Kg (multi-interval)
N: LAN (Option) is available. Blank: LAN (Option) is not available.
1.1 APPLICABLE MODEL
Destination Code
Scale Type
H: Hanging scale
Display Type
FF: Fluorescent full dot display

1.2 ACCESSORIES

Owner’s Manual
Quality control
Cap Screw
(M-6x12)
Print Head Cleaner
Cap Screw
Spring Washer
(SW-6)
NOTE : Check that there are no missing or incorrect parts in the accessories
1- 2

2. SPECIFICATION

37.5 lb (17 Kg)
2. SPECIFICATION

2.1 SCALE

Item US CA QR
Maximum Capacity 30 lb 15 Kg (30 lb) Minimum Scale Division 0.005 lb (0 to 15 lb.)
0.01 lb (15 to 30 lb.)
Display Range 0 to 30.05 lb 0 to 15.025 Kg (0 to 30.05 lb) Maximum Tare 2.000 lb 1.000 Kg (2.205 lb) Unit Price Presettable $ 0.01 to 99.99 $ 0.01 to 99.99 0 to 99999 Minimum Price Display $ 0.01 $ 0.01 1 Power Requirement
Power Consumption Temperature Limits
Relative Humidity Message Display
Weight Unit Price
Total Price Display Mode Capacity of PLU Memory
Print Head Media Issue Method Dot Density Print Speed Available Media Width Recommended Media
Thermal Label
Variable Length Label
Thermal Receipt Interface
Dimensions (approx.)
Without a platter
With a platter Weight
AC 120 V ±10%, 60 Hz (US/CA type) AC 220 V ±10%, 50/60 Hz (QR type) US/CA: 85 W, 1.4 A (Standby: 30 W, 0.5 A) QR: 80 W, 0.66 A (Standby: 32 W, 0.26 A) 32°F to 104°F (0℃ to 40℃) 35 % to 85 % (No condensation) 256 x 64 dots Fluorescent display 5 digits (US/CA type), 5 digits (QR type) 4 digits (US/CA type), 5 digits (QR type) 5 digits (US/CA type), 6 digits (QR type) Dual sides SL-9000: 560 PLUs (Standard), 240 PLUs when LOGO is available.
3120 PLUs max. (Option) SL-9000N: 3600 PLUs max. (Standard) Thermal Print Head (2 inch wide) On-demand/Batch 193 dots/inch (7.6 dots/mm) 3 inch/sec. (76.2 mm/sec.)
1.89 inch (48 mm), 2.24 inch (57 mm) VHTS, VLTS (OSP)/Outer diameter: φ150 mm (Max.)
VHTS, VLTS (OSP)/Outer diameter: φ150 mm (Max.) 120 FC (RICOH)/Outer diameter: φ90 mm (Max.) CMT/PL-3 interface (Program Loader) LON interface (RS-485) TMCC interface (Option) LAN Interface (10 Base T, SL-9000N Option)
15.6 inch (width) x 7.1 inch (depth) x 19.3 inch (height) 395 mm (width) x 181 mm (depth) x 490 mm (height)
15.6 inch (width) x 10.8 inch (depth) x 32.7 inch (height) 395 mm (width) x 274 mm (depth) x 830 mm (height)
0.002 Kg (0 to 6 Kg)
0.005 Kg (6 to 15 Kg)
0.005 lb (0 to 15 lb)
0.01 lb (15 to 30 lb)
2.1 SCALE
2-1
2. SPECIFICATION

2.2 OPTION

2.2 OPTION
Option Name
LON Connector TM8P-88P
LON Terminal
LON
TMCC
MEMO PC Board (SL-9000 only)
Memory Module
Power Cord
10 Base T (LAN) Interface Board (SL-9000N only)
LAN Cable Kit (SL-9000N only)
Resistor 285D-8P
LON Cable S-STLAN-2P (200 m/roll)
I/O PC Board
TMCC Cable kit
Model No.
or Part No.
Part No. EAJ-0028001
Part No. EAJ-0029001
Part No. 10319100003
OP-9000-IOB An I/O board equipped with the TMCC
OP-9000-IOCN­TMCC
OP-9000­PIGGYBACK OP-9000­PIGGYBACK-S/F
OP-9000-RAM­512KB
OP-9000-SRAM­512KB
---------- Please locally purchase a power cord of
OP-9000N-LAN This board enables the SL-9000N to be used
OP-9000N-LAN-
FFH
A modular connector used to connect scales to each other in a LON configuration.
A modular resistor attached to the scales connected at both ends of the LON configuration.
An 8-pin telephone cable used with the LON connectors attached to both ends of the cable. This cable connects scales to each other in a LON configuration.
interface. It is used to construct a TMCC system.
A cable kit for the TMCC interface.
This board is used to expand the PLU memory to 4MB by installing the memory module.
DIP type PS-RAM to be installed on the MEMO PC board (OP-9000-PIGGYBACK) for memory expansion. When expanding the memory, install the two modules as one set.
DIP type S-RAM to be installed on the MEMO PC board (OP-9000-PIGGYBACK-S/F) for memory expansion. When expanding the memory, install the two modules as one set.
proper length for the installation location. Power cord shall be a standardized article of each destination.
in a LAN network. This kit is required when installing the OP-
9000N-LAN (LAN Interface Board) on the SL­9000N-FFH.
Description
Source
See
Note 2
See
Note 2
See
Note 2
See
Note 1
See Note 1
See
Note 1
See Note 1 and 3
See
Note 1
See Note 1
See Note 1
NOTES:
1. Contact TOSHIBA TEC H.Q. or your nearest TOSHIBA TEC representative.
2. Order from TOSHIBA TEC Parts Center or purchase locally.
3. When purchasing memory modules locally, select one having the following specifications.
■ Maker: HITACHI Pseudo Static RAM (OP-9000-RAM-512KB)
HITACHI Static RAM (OP-9000-SRAM-512KB)
■ Type: HM658512ALP-8V 80 ns, 600 mil 32-pin Plastic DIP (DP-32) (OP-9000-RAM-512KB)
HM628512ALP-770ns, 600mil 32-pin Plastic DIP (DP-32) (OP-9000-SRAM-512KB)
4. The MEMO PC Board (with Flash ROM) is installed in the SL-9000N model as standard.
2-2

3. APPEARANCE

3. APPEARANCE
3. APPEARANCE
Front Display
Keyboard Frame
Operation/Speed/ Programming Keyboard
Power Inlet
LON Interface
LAN Interface (SL-9000N option)
TMCC Interface (Option)
Rear Display
Main Power
Printer Cover
CMT/PL-3 Interface
Print Head
Platter
NOTE: To set the speed/operation key sheet, open the keyboard frame and insert the two tabs of the
key sheet into the two slots of the keyboard frame bottom.
3- 1

4. DISPLAY

SL-9000N
SL-9000N
4. DISPLAY

4.1 US TYPE

n Front Display Panel
4.1 US TYPE
x
o
n Rear Display Panel
CAPACITY
WEIGHT e=d
0〜15 lb 0.005 lb
15〜30 lb 0.01 lb
SCROLLING MESSAGE INDICATES SCALE AT ZERO
CAPACITY
WEIGHT e=d
0〜15 lb 0.005 lb
15〜30 lb 0.01 lb
SCROLLING MESSAGE INDICATES SCALE AT ZERO
4- 1
4. DISPLAY
SL-9000N
SL-9000N

4.2 CA/QR TYPE

n Front Display Panel
4.2 CA/QP TYPE
x
o
CAPACITY
CAPACITÉ
WEIGHT e=d WEIGHT e=d
0〜6 kg 0.002 kg 0〜15 lbs 0.005 lbs
6〜15 kg 0.005 kg 15〜30 lbs 0.01 lbs
n Rear Display Panel
CAPACITY
CAPACITÉ
NOTE: For the SL-9000 model, the model name on the display panel is “SL-9000”.
WEIGHT e=d WEIGHT e=d
0〜6 kg 0.002 kg 0〜15 lbs 0.005 lbs
6〜15 kg 0.005 kg 15〜30 lbs 0.01 lbs
4- 2

5. KEY LAYOUT

NEXT
*
5. KEY LAYOUT

5.1 PROGRAMMING KEYBOARD

NOTE: Blank keys have no function.
■ Programming Keyboard Function
5.1 PROGRAMMING KEYBOARD
Name of Key Function
CLEAR
1. Clears numeric data just entered.
2. Releases the scale from the error mode. Selects the upper case or lower case.
SHIFT
SET
Calls the PLU # which follows the PLU # currently called. Sets the media transparency on the sensor.
NEXT
PLU
AUTO
CODE
CHANGE
PLU
DELETE
PLU
TEST
Calls the PLU # registered right after currently called PLU #.
Sets “AUTO CODE”.
Changes the PLU # currently called.
Deletes PLU.
Prints data set in the currently called PLU.
Inputs data to the SL-9000 system during programming.
ENTER
VOID
Displays the preceding PLU data. (only when changing the unit price)
RPT/
ESC.
Inputs data to the SL-9000 system during programming. (only when changing the unit price) Returns to the main menu.
5- 1
5. KEY LAYOUT
1
1/4
SPACE
Name of Key Function
−
5.1 PROGRAMMING KEYBOARD
1. Displays the preceding PLU data.
2. Used to set an auto code.
3. Calls the preceding label format # when setting the print position.
←
→
DELETE
(A)
1/2
INSERT
DELETE
(B)
RETURN
↑
SEND
RECEIVE
Moves the cursor to left.
Moves the cursor to right.
1. Deletes a character selected by the cursor when setting the commodity name or message.
2. Sets a unit price per 1/2 lb.
1. Inserts a space at the cursor position when setting the commodity name or message.
2. Sets a unit price per lb/100g/Kg.
Deletes all characters on the current setting line when setting the commodity name or message.
1. Displays the next line when setting the ingredient and message.
2. Sets a unit price per 1/4 lb.
Inserts a blank space in descriptors.
Stores “ingredient data” in the temporary memory.
Calls “ingredient data” from the temporary memory.
↑
↓
PROG.
◇
Other Keys
Sets the preceding item when setting PLU and nutrition information.
Sets the following item when setting PLU and nutrition information.
Returns to the programming menu.
1. Changes the programming menu page.
2. Selects capitals or small letters.
3. Sorts the file when setting PLU data, ingredient data and nutrition data.
4. Sets a block PLU # using the confirmation label procedure.
5. Selects the scrolling message or fixed message.
6. Changes the speed key page and sets a department #.
7. Selects the adjusting item of print format in rotation.
8. Toggles between In-line and Local or in-line and off-line of LON system.
The other keys are used to set the character.
5- 2
5. KEY LAYOUT
(4)
NEXT
LB/kg
5.2 OPERATION KEYBOARD AND SPEED KEYBORAD

5.2 OPERATION KEYBOARD AND SPEED KEYBOARD

(3)
NOTES: 1. Pressing the key enables another 108 PLUs assignment.
2. When the initial setting #8-7 is set to 1 (SL-9000) or #28-4 is set to 1 (SL-9000N), the (3) key will function as a Tare% key instead of a speed key.
3. When the initial setting #12-8 is set to 1, the (4) key will function as an AUTO/MANUAL key instead of a speed key.
■ Operation Keyboard Function
Name of Key Function
0
to
Enters PLU #, unit price and tare.
9
1.Clears numeric entries.
C
2.Releases the scale from error mode.
3.Releases the scale from SAVE mode.
T
Subtracts tare.
Calls a PLU or clears displayed PLU.
PLU
Prints the customer label.
PRT/*
Saves tare and unit price after taking off the commodity from a platter.
SAVE
FOR
Sets the number of articles in “BY COUNT” mode.
Displays the date.
DT/TM
Selects the item for change Print/OFF.
PLU
5- 3
5. KEY LAYOUT
#
■ Operation Keyboard Function
Name of Key Function
5.2 OPERATION KEYBOARD AND SPEED KEYBORAD
VOID
◇
ESC.
PROG.
POWER
1/2 1/4
100g
LB/kg
PRESET
COUNT
GRADE
LINE
Corrects data just after the registration.
1. Selects the speed key page.
2. Selects the function for change Print/OFF. Returns to the main menu.
Accesses print item, auto message timer, print format and issue mode selection mode.
Turns the display on/off when the scale power is on.
Changes between 1/2 lb and 1/4 lb (US type only).
Changes the unit of measure to 100 g (CA/QR type only).
Changes the unit of measure between lb and kg (CA/QR type only).
Sets the number of labels to print.
Prints a grade line.
LOGO
GROUP
ST
%
FEED
TEST
ZERO
AUTO/
MANUAL
1 108
to
Calls the logo.
No function.
No function.
This key is used for item or subtotal discount by entering a percentage. (Optional key by initial setting) Feeds the label.
Issues a test label.
Adjusts the zero point.
Changes the label issue mode between Automatic issue and manual issue. (Optional key by initial setting) Calls the PLU frequently used.
5- 4

6. PROCEDURE BEFORE OPERATION

6. PROCEDURE BEFORE OPERATION
6. PROCEDURE BEFORE OPERATION
1. Ask an authorized installing dealer for the scale installation. Please contact your nearest TOSHIBA TEC representative.
2. Hang the platter arm from the scale. (See page 7-1.)
3. Load the label or receipt.
4. Set the following programming menus:
Menu Page ITEM No. Programming Name
2 0 PRINT FORMAT 2 1 DATE/TIME SETTING 1 1 PLU DATA SETTING
If necessary, set the following program menu:
Menu Page ITEM No. Programming Name
1 2 INGREDIENT MESSAGE 1 3 NUTRITION SETTING 1 5 ADDRESS AND COMMECIAL MESSAGE SETTING 1 7 SPECIAL INFORMATION 1 8 GRADE LINE 1 9 SPEED KEY SET
5. Call a PLU which contains the unit price used in weighing mode, then place a weight on the platter and check a correct price is displayed.
6. Label issued is ready.
NOTE: For details of the programming menus, refer to Section 10.
6- 1

7. INSTALLATION PROCEDURE

7. INSTALLATION PROCEDURE
■ Scale installation on the wall or ceiling
The installation should be an authorized installing dealer. Please contect your nearest TOSHIBA TEC representative.
■ Platter
1. Attach the two platter mount plates to the platter arm with the four D-4x8 screws.
Screw
Platter Arm
Platter Mount Plate
7. INSTALLATION PROCEDURE
2. Fit the notch of the platter arm on the joint nut of the scale.
Joint nut
Platter Arm
7- 1

8. REMOVAL AND REPLACEMENT OF RECEIPT/LABEL

8. REMOVAL AND REPLACEMENT OF RECEIPT/LABEL
8. REMOVAL AND REPLACEMENT OF RECEIPT/LABEL
1. Open the printer cover and turn the head-up lever to the anticlockwise.
2. Pull out the roll stopper and backing paper stopper, then remove the receipt/label core with the
backing paper. You can loosen the backing paper by turning the paper winding shaft anti­clockwise.
Receipt/Label Core
Head-up Lever
Backing Paper (Labels only)
Backing Paper Stopper
Paper Winding Shaft
3. Put a new receipt/label roll over the media shaft and fix it with the roll stopper.
Media Shaft
Receipt/Label
Roll Stopper
Roll Stopper
8-1
8. REMOVAL AND REPLACEMENT OF RECEIPT/LABEL
8. REMOVAL AND REPLACEMENT OF RECEIPT/LABEL
4. Insert the tip of the receipt/label into the print head.
5. Align the two media guides with the right edge of the receipt/label.
Media Guide
Media Guide
6. Thread the receipt/label as shown below.
NOTE: Labels and receipts should be left-aligned as viewed from the front of the machine, and
always threaded in parallel with the media shaft and the print head. Failure to do this may cause a paper jam or a skew feed.
7. Turn the head-up lever to the arrow indicating direction to set the print head in position.
(Label threading method) (Receipt threading method)
Label
Receipt
Head-up Lever
Winding Roll
Print Head
Backing Paper Stopper
Head-up Lever
8. Close the printer cover.
9. Finally press the Feed key to confirm that the labels/receipts are loaded correctly.
8-2

9. OUTLINE OF OPERATION

Switch ON
REG
Menu
REWRAP
Menu
MARK DOWN
Menu
PROG
Menu
REPORT
Menu
RESET
Menu
SECURITY
Menu
Return to
each mode
Display OFF
Password
Main Menu
Password Input
Select the Menu #
NOTES:
Key
Key
9. OUTLINE OF OPERATION
Main Power
Display OFF
9. OUTLINE OF OPERATION
②
Menu#1
①
Press the
POWER
No Press
key
POWER
Press the
POWER
Scanning Display
key
Press
Other than Menu #1.
Unnecessary
Necessary
①
ESC.
No Press
Press
②
1. You can register a password to avoid unauthorized access to each menu except for REG. menu.
2. To avoid unneeded use of the display, press the key to turn the display off while being unused. Pressing the key again allows you to enter REG mode without scanning.
POWER
POWER
3. Refer to respective sections for explanation of each menu enclosed by a thick rectangle.
9-1
10. PROGRAMMING PROCEDURES
Enter a
0
4. CONFIRMATION LABEL 9. SPEED KEY SET
4. LON SYSTEM 9. IDIOM

10. PROGRAMMING PROCEDURES

■ How to access to Programming Menu
unnecessary
Password
neccesary
Enter the
Password
ESC.
menu number
0 0 9
■
How to access to Programming Menu
Select the programming menu page.
Select an item No. (See next page.)
◇
〜
Programming
starts
Programming
completes
PROG.
NOTES:
1. When the selected menu ( ) is protected froman access, refer to Section 12.2 and enter
the password.
2. In Section 10.1, 10.2 and 10.3, items which have been sold on that day cannot be called before resetting (refer to Section 14) unless Initial Set #1-4 is set to 1.
<Menu> PROG.1
0. PLU DATA EDIT 5. MESSAGE
1. PLU DATA 6. MSG. COMBINATION
2. INGREDIENT 7. SPECIAL INFO
3. NUTRITION 8. GRADE LINE
<Menu> PROG.2
0. PRT LOCATION 5. INITIAL SET
1. DATE TIME 6. BAR CODE FORMAT
2. CMT 7. TITLE
3. ON-LINE/LOCAL 8. LOGO
<Menu> PROG.3
0. VENDOR
1. FREE FORMAT
2. LAN SYSTEM (SL-9000N only)
10- 1
10. PROGRAMMING PROCEDURES
■ Title and Contents of Programming Menu
Table 1.
NO. TITLE
1 PLU DATA EDIT 1 0 CHANGE UNIT PRICE 10-4 2 PLU DATA 1 1 PROGRAM/CHANGE/DELETE PLU 10-5 3 INGREDIENT MESSAGE 1 2 PROGRAM/CHANGE INGREDIENT 10-7 4 NUTRITION SETTING 1 3 PROGRAM/CHANGE NUTRITION FACTS TABLE 10-8 5 CONFIRMATION LABEL 1 4 VERIFY THE PROGRAMMING DATA OF PLU 10-12 6 ADDRESS OR MESSAGE SETTING 1 5 PROGRAM MESSAGE/ADDRESS 10-13 7 COMBINATION MESSAGE 1 6 PROGRAM MESSAGE ON DISPLAY AND TIME 10-14 8 SPECIAL INFO. 1 7 PROGRAM SPECIAL INFORMATION 10-16 9 GRADE LINE 1 8 PROGRAM GRADE LINE 10-16
MENU PAGE
ITEM
NO.
■
Title and Contents of Programming Menu
CONTENTS Page
10 SPEED KEY SETTING 1 9 ASSIGN COMMON PLU TO SPECIFIC SPEED KEY 10-17 11 PRT LOCATION 2 0 SELECT LABEL FORMAT AND ADJUST 10-18 12 DATE/TIME SETTING 2 1 PROGRAM DATE/TIME/MACHINE #/STORE CODE 10-20 13 CMT/PL-3 2 2 BACK-UP/LOAD DATA OF PLU/ING/NUTRI./SPEED
KEY
14 IN-LINE/LOCAL 2 3 SET PARAMETERS FOR TMCC 10-23 15 LON SYSTEM 2 4 SET PARAMETERS FOR LON 10-24 16 INITIAL SET 2 5 SET INITIAL PARAMETERS ---­17 BAR CODE FORMAT 2 6 PROGRAM BARCODE FORMAT 10-26 18 TITLE 2 7 PROGRAM/CHANGE TITLE ON DISPLAY/PRINT 10-28 19 LOGO 2 8 SEND/RECEIVE LOGO DATA 10-29 20 IDIOM 2 9 PROGRAM IDIOM 10-30 21 VENDOR 3 0 VENDOR NAME 10-30 22 FREE FORMAT 3 1 PROGRAM FREE FORMAT 10-31 23 LAN SYSTEM (SL-9000N only) 3 2 PROGRAMS PARAMETERS FOR LAN ----
10-20
NOTE: Menu No. 16 and 23 are program for use of dealers. Contact your nearest TOSHIBA TEC
representative if you desire to use them. When you enter one of these menus by mistake, press [ESC.] key to return to Main Menu.
10- 2
10. PROGRAMMING PROCEDURES
8. To call a preset ingredient message idiom, follow the procedure below:
RETURN 1/4
Enter the idiom #.
CHANGE PLU
Enter the line #.
■ How to enter characters
Use the following procedure to enter a commodity name, address and ingredient message.
Example) 1st line: TEC STORE
2nd line: (TEL) 0123-45-6789
■
How to enter characters
T E C SPACE S T R E
O
RETURN
1/4
1 st line content
DELETE
SHIFT ( SHIFT T E E
(A) 1/2
L 6 7 8 9
2 nd line content
NOTES:
1. and keys are the cursor keys.
←
→
2. To insert a space, move the cursor to the next character to the space to be inserted, and press key.
3. To delete a line, press key.
INSERT
DELETE (B)
4. To move the cursor to the preceding line when entering a commodity name, press key, or key.
↑
5. Pressing the key toggles between the capital and small letter.
6. When entering a commodity name, press or key instead of the key to
ENTER
↓
return.
7. Pressing the key toggles the type font between normal and boldface.
PLU
NEXT
RETURN
1/4
9. To skip a line when entering an ingredient message, follow the procedure below:
SET
NEXT
RETURN
1/4
10- 3
10. PROGRAMMING PROCEDURES
Enter the PLU #
Speed key #
(max. 4 digit)
Speed key
<MENU>
Page 1
Main
*
*

10.1 PLU DATA EDIT

Menu Page: 1 Item No.: 0
In this procedure, use operation keys (except when calling a PLU by using a speed key). The unit price stored in a PLU can be changed with this menu.
a
10.1 PLU DATA EDIT
<MENU>
Page 1
0
NEXT
Page 1ÖPage 2
PLU
◇
or
VOID
Enter the
PRT
a
Change the unit price
PRT
PROG.
TEST
ESC.
NOTES:
1. An attempt to call a PLU # that has not been stored in the PLU file results in an error.
2. Under this Menu (Menu No. 0), “open-price” PLU’s price cannot be changed.
<MENU>
10- 4
10. PROGRAMMING PROCEDURES
(max. 32 chars.×4 lines)
WEIGH
<MENU>
Set auto code
for the UPC#
Is status
#8-2?
Max. 1Kg/2.205 lb (CA/QR)
Is status
Is status
#26-4?
(Refer to NOTE4)
(Max. 3 dig.)
Is status
#7-8?
Is status
#8-1?
Is status
#23-1?
Is status
#1-5?
2: Fix Price
Is status
#10-5?
1: Print
PLU#
Status
#8-7/28-4?
The memory file is sorted when a
<MENU>
Main
<MENU>
Is status
#12-4?
Is status
#9-4?
*: Selectable by the initial setting #10-7.

10.2 PLU DATA SETTING

Menu Page: 1 Item No.: 1
Setting or changing the contents of PLU (PLU#, UPC#, Commodity Name, etc).
b
1
Max. 2 lb (US)
0
Page 1
SET
NEXT
1
NEXT
PLU
or
AUTO
CODE
ENTER
of initial set
10.2 PLU DATA SETTING
Set tare limit.
ENTER
Enter PLU#
(max. 6 dig.)
of initial set
#1-6?
of initial set
0
of initial set
0
of initial set
0
CHANGE
PLU
DELETE
PLU
TEST
b
In what mode is PLU used?
or FIX
unit price.
Enter tare.
Enter UPC# (Max. 6 dig.)
BY COUNT
Enter quantity for that
price. (Max. 2 dig.)
ENTER
ENTER
ENTER
ENTER ENTER ENTER
1
0
Enter flag of
1
1
Max. 2lb (US)
Max. 1 kg/2.205 lb (CA/QR)
Selection Mode Flag
1
0: Weight 1: By Count
Enter commodity name.
Enter shelf life.
of initial set
1
ENTER
0: Non Print
ENTER
Safe Handing
Instruction
0
Enter current
PLU#
Enter
ENTER ENTER
ENTER
The setting label is issued.
Enter new
PLU#
or
Y N
(Sorting)
Y◊
PROG.
ESC.
Page 1
memory full error occurs.
Any key
except
(Not Sorting)
10- 5
Y
of initial set
0
of initial set
of initial set
Enter unit price.
(max. 4 dig.)
1
Enter PERIOD OF
RELISH (Max. 3 dig.)
◊
Select compulsory tare
ENTER
ENTER
◊
2
0 or 1
1
0
(SL-9000N only)
ENTER
2
of initial set
0 or 1
of initial set
0
Set tare %
(Max. 99.9%)
(Price↔%)
Enter discount price
or rate. (Price: Max. 5 digit Rate: Max. 3 digit)
Enter LOGO #.
(#0 - 26)
or (#0 - 99)*
ENTER
1
See NOTE7.
ENTER
ENTER
10. PROGRAMMING PROCEDURES
ENTER
INSERT 1
DELETE (A) 1/2
RETURN 1/4
INSERT 1
↑
ENTER
10.2 PLU DATA SETTING
key instead of the key advances to the next menu. Pressing the
↓
Verification label of PLU data
(W: Weigh, F: Fix, B: By-count)
(C: Compulsory, Blank: Not compulsory)
NOTES:
1. A UPC code is made up of a combination of an entered code and an AUTO CODE. Be sure to attach some characters to the end of the AUTO CODE, or all entered codes will be ignored and an AUTO CODE will become an UPC code (see ex. 1). ex. 1) enter code: 456 ex. 2) enter code: 4567 ex. 3) enter code: 123456
AUTO CODE: 123- - - AUTO CODE: 123- - - AUTO CODE: 987
↓
↓
↓
code#: 123456 code#: 123567 code#: 987
2. When there is no area to store PLU data, an error occurs when pressing the key.
3. Changing a PLU # to the number to which other PLU data is set will result in an error.
4. Unit price flag may be selected as follows:
1) In case of lb scale a. key : $ per lb
b. key : $ per 1/2 lb c. key : $ per 1/4 lb
2) In case of kg scale a. key : $ per 100 g or Kg
5. Tare limit should be a multiple of 5, up to 2.000 lb for US type and a multiple of 2, up to 1.000 Kg for CA/QR type.
6. Safe handling instructions can be printed on 57-mm wide labels only. Safe handling instructions are printed on labels formatted for ingredient messages. Only ingredient message labels with 13 or more lines can be used to print safe handling instructions. Available print formats are as follows: 13 (63), 15 (65), 16 (66), 23 (73), 25 (75), 26 (76), 33 (83), 35 (85), 36 (86), 41, 42, 43, 48 and
49.
7. Tare % indicates a percentage of tare in gross weight, which is available when the Initial Setting #8-7 is set to 1 (SL-9000) or #28-4 is set to 1 (SL-9000N).
8. When setting open prices in the count mode (Initial Setting #1-6: 1), set zeros as quantity and unit price.
10- 6
10. PROGRAMMING PROCEDURES
Enter the PLU#
<MENU>
The memory file is sorted when a
<MENU>
Main
the key.
RECEIVE
SEND
the work buffer.
SEND
Y
10.3 INGREDIENT MESSAGE

10.3 INGREDIENT MESSAGE

Menu Page: 1 Item No.: 2
Ingredient messages can be printed on a label with a maximum of 54 characters per line using small letters or 32 characters per line using boldfaced small letters. Will print up to 38 lines.
c
Page 1
2
Enter the ingredient message (Refer to Page 10-3.)
Pressing the key calls data stored by pressing
Pressing the key temporarily stores data into
NEXT
PLU
or
(max. 6 dig.)
ENTER
◇
memory full error occurs.
TEST
Sorting
Y
Any key
except
ENTER
c
Not Sorting
PROG.
ESC.
Page 1
<MENU>
NOTES: 1. When no data is programmed for the PLU, ingredient cannot be set.
2. When a selected PLU is not stored in the PLU file, a PLU NOT FOUND error occurs.
3. Once you exit this menu and enter again, data stored in the work buffer is cleared.
4. When there is no area to store ingredient data, a “MEMORY FULL” error occurs.
5. Different PLUs cannot use the same ingredient data. (PLU and ingredient data are in pairs.)
10- 7
Loading...
+ 64 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
