Toshiba M5 User Manual

TECRA M5

TOSHIBA

TECRA M5

Portable Personal Computer

User’s Manual

User’s Manual

Copyright

© 2006 by TOSHIBA Corporation. All rights reserved. Under the copyright
laws, this manual cannot be reproduced in any form without the prior
written permission of TOSHIBA. No patent liability is assumed, with respect
to the use of the information contained herein.

TOSHIBA TECRA M5 Portable Personal Computer User’s Manual

First edition January 2006
Copyright authority for music, movies, computer programs, data bases and

other intellectual property covered by copyright laws belongs to the author
or to the copyright owner. Copyrighted material can be reproduced only for
personal use or use within the home. Any other use beyond that stipulated
above (including conversion to digital format, alteration, transfer of copied
material and distribution on a network) without the permission of the
copyright owner is a violation of copyright or author’s rights and is subject
to civil damages or criminal action. Please comply with copyright laws in
making any reproduction from this manual.

Disclaimer

This manual has been validated and reviewed for accuracy. The
instructions and descriptions it contains are accurate for the TOSHIBA
TECRA M5 Portable Personal Computer at the time of this manual’s
production. However, succeeding computers and manuals are subject to
change without notice. TOSHIBA assumes no liability for damages incurred
directly or indirectly from errors, omissions or discrepancies between the
computer and the manual. Graphics processor performance may vary
considerably from specifications due to design configuration.

Trademarks

IBM is a registered trademark and IBM PC is a trademark of International
Business Machines Corporation.

Intel, Intel SpeedStep, Intel Core and Centrino are trademarks or registered
trademarks of Intel Corporation or its subsidiaries in the United States and
other countries/regions.

Windows and Microsoft are registered trademarks of Microsoft Corporation.
Photo CD is a trademark of Eastman Kodak.
Sonic RecordNow! is a registered trademark of Sonic Solutions.
Bluetooth is a trademark owned by its proprietor and used by TOSHIBA

under license.
i.LINK is trademark and registered trademark of Sony Corporation.
InterVideo and WinDVD are registered trademarks of InterVideo Inc.

WinDVD Creator is trademark of InterVideo Inc.
Other trademarks and registered trademarks not listed above may be used

in this manual.

ii User’s Manual

FCC information

Product Name: TECRA M5

Model number: PTM51

FCC notice "Declaration of Conformity Information"

This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

■ Reorient or relocate the receiving antenna.

■ Increase the separation between the equipment and receiver.

■ Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

■ Consult the dealer or an experienced radio/TV technician for help.

Only peripherals complying with the FCC class B limits may be attached to
this equipment. Operation with non-compliant peripherals or peripherals
not recommended by TOSHIBA is likely to result in interference to radio
and TV reception. Shielded cables must be used between the external
devices and the computer’s external monitor port, serial port, USB port,
IEEE1394 port and microphone jack. Changes or modifications made to
this equipment, not expressly approved by TOSHIBA or parties authorized
by TOSHIBA could void the user’s authority to operate the equipment.

User’s Manual

FCC conditions

This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including
interference that may cause undesired operation.

Contact

Address: TOSHIBA America Information Systems, Inc.

9740 Irvine Boulevard
Irvine, California 92618-1697

Telephone: [phone]

User’s Manual iii

User’s Manual

EU Declaration of Conformity

TOSHIBA declares, that the product: PTM51* conforms to the following
Standards:

Supplementary
Information:

This product is carrying the CE-Mark in accordance with the related
European Directives. Responsible for CE-Marking is TOSHIBA Europe,
Hammfelddamm 8, 41460 Neuss, Germany.

“The product complies with the requirements of
the Low Voltage Directive 73/23/EEC, the EMC
Directive 89/336/EEC and/or the R&TTE
Directive 1999/05/EEC.”

VCCI Class B Information

Modem warning notice

Conformity Statement

The equipment has been approved to [Commission Decision “CTR21”] for
pan-European single terminal connection to the Public Switched Telephone
Network (PSTN).

However, due to differences between the individual PSTNs provided in
different countries/regions the approval does not, of itself, give an
unconditional assurance of successful operation on every PSTN network
termination point.

In the event of problems, you should contact your equipment supplier in the
first instance.

iv User’s Manual

Network Compatibility Statement

This product is designed to work with, and is compatible with the following
networks. It has been tested to and found to conform with the additional
requirements conditional in EG 201 121.

Germany ATAAB AN005,AN006,AN007,AN009,AN010

Greece ATAAB AN005,AN006 and GR01,02,03,04
Portugal ATAAB AN001,005,006,007,011 and

Spain ATAAB AN005,007,012, and ES01
Switzerland ATAAB AN002
All other countries/regions ATAAB AN003,004
Specific switch settings or software setup are required for each network,

please refer to the relevant sections of the user guide for more details.
The hookflash (timed break register recall) function is subject to separate

national type approvals. It has not been tested for conformity to national
type regulations, and no guarantee of successful operation of that specific
function on specific national networks can be given.

Japan regulations

Region selection

If you are using the computer in Japan, technical regulations described in
the Telecommunications Business Law require that you select the Japan
region mode. It is illegal to use the modem in Japan with any other
selection.

User’s Manual

and DE03,04,05,08,09,12,14,17

P03,04,08,10

Redial

Up to two redial attempts can be made. If more than two redial attempts are
made, the modem will return Black Listed. If you are experiencing
problems with the Black Listed code, set the interval between redials at one
minute or longer.

Japan’s Telecommunications Business Law permits up to two redials on
analogue telephones, but the redials must be made within a total of three
minutes.

The internal modem is approved by Japan Approvals Institute for
Telecommunications Equipment.

A04-0609001

User’s Manual v

User’s Manual

One of the labels is located on the module.

Pursuant to FCC CFR 47, Part 68:

When you are ready to install or use the modem, call your local telephone
company and give them the following information:

■ The telephone number of the line to which you will connect the modem

■ The registration number that is located on the device

The FCC registration number of the modem will be found on either the
device which is to be installed, or, if already installed, on the bottom of the
computer outside of the main system label.

■ The Ringer Equivalence Number (REN) of the modem, which can vary.

For the REN of your modem, refer to your modem’s label.

The modem connects to the telephone line by means of a standard jack
called the USOC RJ11C.

vi User’s Manual

Type of service

Your modem is designed to be used on standard-device telephone lines.
Connection to telephone company-provided coin service (central office
implemented systems) is prohibited. Connection to party lines service is
subject to state tariffs. If you have any questions about your telephone line,
such as how many pieces of equipment you can connect to it, the
telephone company will provide this information upon request.

Telephone company procedures

The goal of the telephone company is to provide you with the best service it
can. In order to do this, it may occasionally be necessary for them to make
changes in their equipment, operations, or procedures. If these changes
might affect your service or the operation of your equipment, the telephone
company will give you notice in writing to allow you to make any changes
necessary to maintain uninterrupted service.

If problems arise

If any of your telephone equipment is not operating properly, you should
immediately remove it from your telephone line, as it may cause harm to
the telephone network. If the telephone company notes a problem, they
may temporarily discontinue service. When practical, they will notify you in
advance of this disconnection. If advance notice is not feasible, you will be
notified as soon as possible. When you are notified, you will be given the
opportunity to correct the problem and informed of your right to file a
complaint with the FCC. In the event repairs are ever needed on your
modem, they should be performed by TOSHIBA Corporation or an
authorized representative of TOSHIBA Corporation.

User’s Manual

Disconnection

If you should ever decide to permanently disconnect your modem from its
present line, please call the telephone company and let them know of this
change.

Fax branding

The Telephone Consumer Protection Act of 1991 makes it unlawful for any
person to use a computer or other electronic device to send any message
via a telephone fax machine unless such message clearly contains in a
margin at the top or bottom of each transmitted page or on the first page of
the transmission, the date and time it is sent and an identification of the
business, other entity or individual sending the message and the telephone
number of the sending machine or such business, other entity or individual.
In order to program this information into your fax modem, you should
complete the setup of your fax software before sending messages.

User’s Manual vii

User’s Manual

Instructions for IC CS-03 certified equipment

1. The Industry Canada label identifies certified equipment. This
certification means that the equipment meets certain
telecommunications network protective, operational and safety
requirements as prescribed in the appropriate Terminal Equipment
Technical Requirements document(s). The Department does not
guarantee the equipment will operate to the user’s satisfaction.

Before installing this equipment, users should ensure that it is
permissible to be connected to the facilities of the local
telecommunications company. The equipment must also be installed
using an acceptable method of connection.

The customer should be aware that compliance with the above
conditions may not prevent degradation of service in some situations.
Repairs to certified equipment should be coordinated by a
representative designated by the supplier. Any repairs or alterations
made by the user to this equipment, or equipment malfunctions, may
give the telecommunications company cause to request the user to
disconnect the equipment.

Users should ensure for their own protection that the electrical ground
connections of the power utility, telephone lines and internal metallic
water pipe systems, if present, are connected together. This precaution
may be particularly important in rural areas.

Users should not attempt to make such connections themselves, but
should contact the appropriate electric inspection authority, or electrician,
as appropriate.

2. The user manual of analog equipment must contain the equipment’s
Ringer Equivalence Number (REN) and an explanation notice similar to
the following:

The Ringer Equivalence Number (REN) of the modem, which can vary.
For the REN of your modem, refer to your modem’s label.

The Ringer Equivalence Number (REN) assigned to each terminal device
provides an indication of the maximum number of terminals allowed to be
connected to a telephone interface. The termination on an interface may
consist of any combination of devices subject only to the requirement that
the sum of the Ringer Equivalence Numbers of all the devices does not
exceed 5.

3. The standard connecting arrangement (telephone jack type) for this
equipment is jack type(s): USOC RJ11C.
The IC registration number of the modem is shown below.

Canada: 4005B-ATHENS

viii User’s Manual

User’s Manual

Notes for Users in Australia and New Zealand

Modem warning notice for Australia

Modems connected to the Australian telecoms network must have a valid
Austel permit. This modem has been designed to specifically configure to
ensure compliance with Austel standards when the country/region selection
is set to Australia. The use of other country/region setting while the modem
is attached to the Australian PSTN would result in you modem being
operated in a non-compliant manner. To verify that the country/region is
correctly set, enter the command ATI which displays the currently active
setting.

To set the country/region permanently to Australia, enter the following
command sequence:

AT%T E=1
ATS133=1
AT&F
AT&W
AT%T E=0
ATZ

Failure to set the modem to the Australia country/region setting as shown
above will result in the modem being operated in a non-compliant manner.
Consequently, there would be no permit in force for this equipment and the
Telecoms Act 1991 prescribes a penalty of $12,000 for the connection of
non-permitted equipment.

Notes for use of this device in New Zealand

■ The grant of a Telepermit for a device in no way indicates Telecom

acceptance of responsibility for the correct operation of that device
under all operating conditions. In particular the higher speeds at which
this modem is capable of operating depend on a specific network
implementation which is only one of many ways of delivering high
quality voice telephony to customers. Failure to operate should not be
reported as a fault to Telecom.

■ In addition to satisfactory line conditions a modem can only work

properly if:
a/ it is compatible with the modem at the other end of the call and.
b/ the application using the modem is compatible with the application

at the other end of the call - e.g., accessing the Internet requires
suitable software in addition to a modem.

■ This equipment shall not be used in any manner which could constitute

a nuisance to other Telecom customers.

User’s Manual ix

User’s Manual

■ Some parameters required for compliance with Telecom’s PTC

Specifications are dependent on the equipment (PC) associated with
this modem. The associated equipment shall be set to operate within
the following limits for compliance with Telecom Specifications:

a/ There shall be no more than 10 call attempts to the same number

within any 30 minute period for any single manual call initiation, and

b/ The equipment shall go on-hook for a period of not less than 30

seconds between the end of one attempt and the beginning of the
next.

c/ Automatic calls to different numbers shall be not less than 5

seconds apart.

■ Immediately disconnect this equipment should it become physically

damaged, and arrange for its disposal or repair.

■ The correct settings for use with this modem in New Zealand are as

follows:

ATB0 (CCITT operation)
AT&G2 (1800 Hz guard tone)
AT&P1 (Decadic dialing make-break ratio =33%/67%)
ATS0=0 (not auto answer)
ATS6=4 (Blind dial delay)
ATS7=less than 90 (Time to wait to carrier after dialing)
ATS10=less than 150 (loss of carrier to hangup delay, factory

default of 15 recommended)
ATS11=90 (DTMF dialing on/off duration=90 ms)
ATX2 (Dial tone detect, but not (U.S.A.) call progress detect)

■ When used in the Auto Answer mode, the S0 register must be set with a

value of 3 or 4. This ensures:

■ a person calling your modem will hear a short burst of ringing before

the modem answers. This confirms that the call has been
successfully switched through the network.

■ caller identification information (which occurs between the first and

second ring cadences) is not destroyed.

■ The preferred method of dialing is to use DTMF tones (ATDT...) as this

is faster and more reliable than pulse (decadic) dialing. If for some
reason you must use decadic dialing, your communications program
must be set up to record numbers using the following translation table
as this modem does not implement the New Zealand “Reverse Dialing”
standard.

Number to be dialed: 0 1 2 3 4 5 6 7 8 9
Number to program into computer: 0 9 8 7 6 5 4 3 2 1
Note that where DTMF dialing is used, the numbers should be

entered normally.

x User’s Manual

■ The transmit level from this device is set at a fixed level and because of

this there may be circumstances where the performance is less than
optimal. Before reporting such occurrences as faults, please check the
line with a standard Telepermitted telephone, and only report a fault if
the phone performance is impaired.

■ It is recommended that this equipment be disconnected from the

Telecom line during electrical storms.

■ When relocating the equipment, always disconnect the Telecom line

connection before the power connection, and reconnect the power first.

■ This equipment may not be compatible with Telecom Distinctive Alert

cadences and services such as FaxAbility.

NOTE THAT FAULT CALLOUTS CAUSED BY ANY OF THE ABOVE
CAUSES MAY INCUR A CHARGE FROM TELECOM

General conditions

As required by PTC 100, please ensure that this office is advised of any
changes to the specifications of these products which might affect
compliance with the relevant PTC Specifications.

The grant of this Telepermit is specific to the above products with the
marketing description as stated on the Telepermit label artwork. The
Telepermit may not be assigned to other parties or other products without
Telecom approval.

A Telepermit artwork for each device is included from which you may
prepare any number of Telepermit labels subject to the general instructions
on format, size and color on the attached sheet.

The Telepermit label must be displayed on the product at all times as proof
to purchasers and service personnel that the product is able to be
legitimately connected to the Telecom network.

The Telepermit label may also be shown on the packaging of the product
and in the sales literature, as required in PTC 100.

The charge for a Telepermit assessment is $337.50. An additional charge
of $337.50 is payable where an assessment is based on reports against
non-Telecom New Zealand Specifications. $112.50 is charged for each
variation when submitted at the same time as the original.

An invoice for $NZ1237.50 will be sent under separate cover.

User’s Manual

Following information is only for EU-member states:

The use of the symbol indicates that this product may not be treated as
household waste. By ensuring this product is disposed of correctly, you will
help prevent potential negative consequences for the environment and
human health, which could otherwise be caused by inappropriate waste
handling of this product. For more detailed information about recycling of
this product, please contact your local city office, your household waste
disposal service or the shop where you purchased the product.

User’s Manual xi

User’s Manual

Description on Laser specification

The optical drive such as CD-ROM drive, DVD-ROM drive, DVD­ROM&CD-R/RW drive and DVD Super Multi drive that is used in this
computer is equipped with laser. The classification label with the following
sentence is affixed to the surface of the drive.

CLASS 1 LASER PRODUCT
LASER KLASSE 1
LUOKAN 1 LASERLAITE
APPAREIL A LASER DE CLASSE 1
KLASS 1 LASER APPARAT

The drive with the above label is certified by the manufacturer that the drive
complies with the requirement for laser product on the date of
manufacturing pursuant to article 21 of Code of Federal Regulations by the
United States of America, Department of Health & Human Services, Food
and Drug Administration.

In other countries, the drive is certified to comply with the requirement
pursuant to IEC 825 and EN60825 on class 1 laser product.

This computer is equipped with the optical drive in the following list
according to the model.

Manufacturer Type

TEAC CD-224EN

TEAC DV-28EN

PCC UJDA770

TSST TS-L462C

Pioneer DVR-K16

PCC UJ-841

xii User’s Manual

TECRA M5

Table of Contents

Preface

Manual contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxi

Conventions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxii

Abbreviations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxii

Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxii

Keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxii

Key operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xxiii

Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xxiii

Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xxiii

General Precautions

Stress injury. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxv

Heat injury . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xxv

Pressure or impact damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xxv

PC card overheating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxvi

Mobile phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxvi

Introduction

Equipment checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Documentation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Special features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12

Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14

Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-18

The Grand Tour

Front with the display closed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Left side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Right side. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

Back side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

Underside. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7

Front with the display open . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9

System indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12

Keyboard indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13

User’s Manual xiii

Table of Contents

USB floppy disk drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14

Optical disk drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15

Region codes for DVD drives and media . . . . . . . . . . . . . . . . . . . . 2-15

Writable discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15

CDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15

DVDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16

Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16

CD-ROM drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16

DVD-ROM drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16

DVD-ROM&CD-R/RW drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17

DVD Super Multi drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17

AC adaptor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-18

Getting Started

Setting up your work space. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

General conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Placement of the computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Seating and posture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5

Work habits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5

Strategic Rest Breaks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6

Other Things to Note. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6

Connecting the AC adaptor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6

Opening the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8

Turning on the power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9

Starting up for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10

Turning off the power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10

Shut Down mode (Boot mode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10

Standby Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10

Hibernation Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12

Restarting the computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14

Create Optical Recovery Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14

Restoring the preinstalled software from the Recovery HDD. . . . . 3-15

Restoring the preinstalled software from

your creating Recovery Media . . . . . . . . . . . . . . . . . . . . . . . . 3-15

Operating Basics

TOSHIBA Dual Pointing Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Using the Touch Pad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Using the AccuPoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

AccuPoint precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

Replacing the cap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

xiv User’s Manual

Using the Fingerprint Sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3

Points to note about the Fingerprint Sensor . . . . . . . . . . . . . . . . . . . 4-3

How to Delete the Fingerprint Data . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4

Points to note about the Fingerprint Utility. . . . . . . . . . . . . . . . . . . . . 4-5

Set Up Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6

Window Logon via Fingerprint Authentication . . . . . . . . . . . . . . . . . . 4-6

Fingerprint Power-on Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7

Fingerprint Single Sign-on Feature . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8

How to Swipe the Finger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9

Using the USB floppy disk drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10

Connecting USB floppy disk drive . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10

Disconnecting USB floppy disk drive. . . . . . . . . . . . . . . . . . . . . . . . 4-10

Changing Slim Select Bay modules . . . . . . . . . . . . . . . . . . . . . . . . . 4-11

Removing a module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11

Inserting a module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12

Using optical disk drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12

Loading discs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13

Removing discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-15

How to remove CD/DVD when the disc tray will not open. . . . . . . . 4-16

Writing CDs on DVD-ROM&CD-R/RW drive . . . . . . . . . . . . . . . . . . . 4-16

Before writing or rewriting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17

When writing or rewriting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18

Writing CD/DVDs on DVD Super Multi drive. . . . . . . . . . . . . . . . . . . 4-18

Important message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-19

Legal Footnotes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-19

Before writing or rewriting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-19

When writing or rewriting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-22

RecordNow! Basic for TOSHIBA . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-22

Data Verification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-23

DLA for TOSHIBA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-24

When using WinDVD Creator Platinum. . . . . . . . . . . . . . . . . . . . . . 4-24

How to make a DVD-Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-25

How to learn more about InterVideo WinDVD Creator . . . . . . . . . . 4-25

Important information for use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-25

Media care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-27

CD/DVDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-27

Floppy disks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-27

Sound system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-28

Volume Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-28

Microphone level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-28

SigmaTel Control Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-28

TOSHIBA Mic Effect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-29

Table of Contents

User’s Manual xv

Table of Contents

Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-29

Region selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-30

Properties menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-30

Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-30

Modem Selection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-31

Dialing Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-31

Connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-31

Disconnecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-32

Wireless communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-32

Wireless LAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-33

Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-33

Bluetooth wireless technology. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-34

Bluetooth

TM

Stack for Windows® by TOSHIBA . . . . . . . . . . . . . . . . 4-34

Wireless communication switch . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-35

Wireless communication Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . 4-35

LAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-36

LAN cable types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-36

Connecting LAN cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-36

Disconnecting LAN cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-37

Cleaning the computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-37

Moving the computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-38

Using the Hard Disk Drive (HDD) Protection . . . . . . . . . . . . . . . . . . 4-38

TOSHIBA HDD Protection Properties . . . . . . . . . . . . . . . . . . . . . . . 4-40

Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-41

Heat dispersal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-42

The Keyboard

Typewriter keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

Function keys: F1 … F12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

Soft keys: Fn key combinations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

Emulating keys on enhanced keyboard . . . . . . . . . . . . . . . . . . . . . . 5-2

Hot keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

Fn Sticky key. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6

Windows special keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7

Keypad overlay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7

Turning on the overlays. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7

Temporarily using normal keyboard (overlay on) . . . . . . . . . . . . . . . 5-8

Temporarily using overlay (overlay off) . . . . . . . . . . . . . . . . . . . . . . . 5-8

Temporarily changing modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9

Generating ASCII characters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9

Power and Power-Up Modes

Power conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1

xvi User’s Manual

Power indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

Battery indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4

DC IN indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4

Power indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4

Battery types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5

Battery pack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5

2nd battey pack (option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6

Extended capacity battery pack (option) . . . . . . . . . . . . . . . . . . . . . . 6-6

High capacity battery pack (option) . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7

Real Time Clock (RTC) battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7

Care and use of the battery pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7

Safety precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8

Charging the batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-10

Monitoring battery capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-12

Maximizing battery operating time. . . . . . . . . . . . . . . . . . . . . . . . . . 6-12

Retaining data with power off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-13

Extending battery life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14

Replacing the battery pack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14

TOSHIBA Password Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-16

User Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-16

Supervisor Password. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-18

Starting the computer by password . . . . . . . . . . . . . . . . . . . . . . . . . 6-19

Power-up modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-19

Windows utilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-20

Hot keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-20

Panel power on/off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-20

System Auto Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-20

Table of Contents

HW Setup

Accessing HW Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1

HW Setup window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1

Configuring the Execute-Disable Bit Capability and TPM . . . . . . . . . 7-9

Starting and Ending the BIOS Setup Program. . . . . . . . . . . . . . . . . . 7-9

Execute-Disable Bit Capability. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-10

Security controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-11

Diagnostic Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-11

Optional Devices

PC card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2

Inserting a PC card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2

Removing a PC card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3

ExpressCard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3

Inserting an ExpressCard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3

Removing an ExpressCard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-4

User’s Manual xvii

Table of Contents

SD card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5

Formatting an SD memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5

Inserting an SD card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5

Removing an SD card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-6

SD card care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-7

Creation of a boot disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-7

Memory expansion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-7

Installing memory module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-8

Removing memory module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-10

Battery pack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-11

AC adaptor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-11

Battery charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-12

Hard disk drive pack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-12

Removing the hard disk drive pack . . . . . . . . . . . . . . . . . . . . . . . . . 8-12

Installing the hard disk drive pack . . . . . . . . . . . . . . . . . . . . . . . . . . 8-13

Slim Select Bay HDD adaptor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-14

USB floppy disk drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-15

External monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-15

TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-16

Using the TOSHIBA Assist button or TOSHIBA Presentation button8-16

Changing the resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-17

Displaying movies on a TV or CRT . . . . . . . . . . . . . . . . . . . . . . . . . . 8-17

i.LINK (IEEE1394) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-18

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-18

Connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-19

Disconnecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-19

Advanced Port Replicator III Plus . . . . . . . . . . . . . . . . . . . . . . . . . . 8-20

Serial port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-21

Security lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-21

Troubleshooting

Problem solving process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1

Preliminary checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2

Analyzing the problem. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2

xviii User’s Manual

Hardware and system checklist. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3

System start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3

Self test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-4

Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-4

Password. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-7

Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-7

Internal LCD display panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-8

Hard disk drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-8

CD-ROM drve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-9

DVD-ROM drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-10

DVD-ROM&CD-R/RW drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-11

DVD Super Multi drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-12

USB floppy disk drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-13

SD card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-13

PC card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-14

ExpressCard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-14

Dual Pointing Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-14

Fingerprint Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-16

USB device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-16

Memory expansion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-17

Sound system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-17

External monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-18

i.LINK (IEEE1394) device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-18

Modem. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-19

LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-20

Wireless LAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-20

Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-20

Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-21

TV output signal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-21

Disposing of PC and PC batteries . . . . . . . . . . . . . . . . . . . . . . . . . . 9-22

TOSHIBA support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-22

Before you call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-22

Where to write . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-23

Table of Contents

Legal Footnotes

CPU*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1

General Main Memory*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-2

Battery Life*3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-2

HDD Drive Capacity*4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-2

LCD*5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-3

Graphics Processor Unit ("GPU")*6 . . . . . . . . . . . . . . . . . . . . . . . . . 10-3

Wireless LAN*7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-3

Non-applicable Icons*8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-3

User’s Manual xix

Table of Contents

Copy Protection*9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-3

Images*10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-3

Appendix A Specifications

Appendix B Display Controller and Modes

Appendix C AT Commands

Appendix D S-registers

Appendix E V.90

Appendix F Wireless LAN

Appendix G Bluetooth wireless technology Interoperability

Appendix H AC Power Cord and Connectors

Appendix I TOSHIBA Anti-theft Protection Timer

Glossary

Index

xx User’s Manual

TECRA M5

Preface

Congratulations on your purchase of the TECRA M5 computer. This
powerful notebook computer provides excellent expansion capability,
including multimedia devices, and it is designed to provide years of reliable,
high-performance computing.

This manual tells how to set up and begin using your TECRA M5 computer.
It also provides detailed information on configuring your computer, basic
operations and care, using optional devices and troubleshooting.

If you are a new user of computers or if you’re new to portable computing,
first read over the Introduction and The Grand Tour chapters to familiarize
yourself with the computer’s features, components and accessory devices.
Then read Getting Started for step-by-step instructions on setting up your
computer.

If you are an experienced computer user, please continue reading the
preface to learn how this manual is organized, then become acquainted
with this manual by browsing through its pages. Be sure to look over the

Special features section of the Introduction, to learn about features that are

uncommon or unique to the computers and carefully read HW Setup.
If you are going to install PC cards or connect external devices such as a

monitor, be sure to read Chapter 8, Optional Devices.

Manual contents

This manual is made up of the following.
Chapter 1, Introduction, is an overview of the computer’s features,

capabilities, and options.
Chapter 2, The Grand Tour, identifies the components of the computer and

briefly explains how they function.
Chapter 3, Getting Started, provides a quick overview of how to begin

operating your computer and gives tips on safety and designing your work
area.

Chapter 4, Operating Basics, describes the basic operations of your
computer and precautions when using it, as well as the handling of CD/
DVD.

Chapter 5, The Keyboard, describes special keyboard functions including
the keypad overlay and hot keys.

User’s Manual xxi

Preface

Chapter 6, Power and Power-Up Modes, gives details on the computer’s
power resources and battery save modes and how to set a password.

Chapter 7, HW Setup, explains how to configure the computer using the
HW Setup program and TPM.

Chapter 8, Optional Devices, describes the optional hardware available.
Chapter 9, Troubleshooting, provides helpful information on how to perform

some diagnostic tests, and suggests courses of action if the computer
doesn’t seem to be working properly.

Chapter 10, Legal Footnotes, provides Legal Footnote information related
to your computer.

The Appendixes provide technical information about your computer.
The Glossary defines general computer terminology and includes a list of

acronyms used in the text.
The Index quickly directs you to the information contained in this manual.

Conventions

This manual uses the following formats to describe, identify, and highlight
terms and operating procedures.

Abbreviations

On first appearance, and whenever necessary for clarity, abbreviations are
enclosed in parentheses following their definition. For example: Read Only
Memory (ROM). Acronyms are also defined in the Glossary.

Icons

Icons identify ports, dials, and other parts of your computer. The indicator
panel also uses icons to identify the components it is providing information
on.

Keys

The keyboard keys are used in the text to describe many computer
operations. A distinctive typeface identifies the key top symbols as they
appear on the keyboard. For example, Enter identifies the Enter key.

xxii User’s Manual

Key operation

Some operations require you to simultaneously use two or more keys. We
identify such operations by the key top symbols separated by a plus sign
(+). For example, Ctrl + C means you must hold down Ctrl and at the same
time press C. If three keys are used, hold down the first two and at the
same time press the third.

Preface

ABC

When procedures require an action such as
clicking an icon or entering text, the icon’s name
or the text you are to type in is represented in the
type face you see to the left.

Display

S ABC

Names of windows or icons or text generated by
the computer that appear on its display screen
are presented in the type face you see to the left.

Messages

Messages are used in this manual to bring important information to your
attention. Each type of message is identified as shown below.

Pay attention! A caution informs you that improper use of equipment or
failure to follow instructions may cause data loss or damage your
equipment.

Please read. A note is a hint or advice that helps you make best use of
your equipment.

Indicates a potentially hazardous situation, which could result in death or
serious injury, if you do not follow instructions.

User’s Manual xxiii

Preface

xxiv User’s Manual

TECRA M5

General Precautions

TOSHIBA computers are designed to optimize safety, minimize strain and
withstand the rigors of portability. However, certain precautions should be
observed to further reduce the risk of personal injury or damage to the
computer.

Be certain to read the general precautions below and to note the cautions
included in the text of the manual.

Stress injury

Carefully read the Instruction Manual for Safety & Comfort. It contains
information on prevention of stress injuries to your hands and wrists than
can be caused by extensive keyboard use. Chapter 3, Getting Started, also
includes information on work space design, posture and lighting that can
help reduce physical stress.

Heat injury

■ Avoid prolonged physical contact with the computer. If the computer is

used for long periods, its surface can become very warm. While the
temperature will not feel hot to the touch, if you maintain physical
contact with the computer for a long time (if you rest the computer on
your lap, or if you keep your hands on the palm rest, for example) your
skin might suffer low-heat injury.

■ If the computer has been used for a long time, avoid direct contact with

the metal plate supporting the I/O ports. It can become hot.

■ The surface of the AC adaptor can become hot when in use. This

condition does not indicate a malfunction. If you need to transport the
AC adaptor, disconnect it and let it cool before moving it.

■ Do not lay the AC adaptor on a material that is sensitive to heat. The

material could be damaged.

Pressure or impact damage

Do not apply heavy pressure to the computer or subject it to strong impact.
Excessive pressure or impact can cause damage to computer components
or otherwise cause malfunctions.

User’s Manual xxv

General Precautions

PC card overheating

Some PC cards can become hot with prolonged use. Overheating of a PC
card can result in errors or instability in the PC card operation. Also be
careful when you remove a PC card that has been used for a long time.

Mobile phone

Use of mobile phones can interfere with the audio system. Computer
operation is not impaired but it is recommended that a distance of 30 cm be
maintained between the computer and a mobile phone in use.

xxvi User’s Manual

TECRA M5

Introduction

This chapter provides an equipment checklist, and it identifies the
computer’s features, options and accessories.

Some of the features described in this manual may not function properly if
you use an operating system that was not preinstalled by TOSHIBA.

Equipment checklist

Carefully unpack your computer. Save the box and packing materials for
future use.

Hardware

Check to make sure you have all the following items:

■ TECRA M5 Portable Personal Computer

■ AC adaptor and power cord (2-pin plug or 3-pin plug)

■ USB floppy disk drive (Option or provided with some models)

■ Spare AccuPoint (pointing device) cap

■ Battery pack (It is pre-installed in the PC)

Chapter 1

User’s Manual 1-1

Introduction

Software

Microsoft® Windows XP Professional

■ The following software is preinstalled:

®

■ Microsoft

■ Microsoft Internet Explorer

■ TOSHIBA Utilities

■ TOSHIBA Wireless Key Logon

■ TOSHIBA SD Memory Boot Utility

■ DVD Video Player

■ TOSHIBA Dual Pointing Device utility

■ TOSHIBA Power Saver

■ TOSHIBA Mobile Extension

■ TOSHIBA Assist

■ TOSHIBA ConfigFree

■ TOSHIBA Zooming Utility

■ TOSHIBA PC Diagnostic Tool

■ TOSHIBA Controls

■ TOSHIBA Mic Effect

■ TOSHIBA Password Utility

■ Fingerprint utility

■ Online manual

Windows XP Professional

Documentation

■ TECRA M5 Portable Personal Computer User's Manual

■ Microsoft Windows XP manual package

■ Instruction Manual for Safety & Comfort

■ End User License Agreement

If any of the items are missing or damaged, contact your dealer
immediately.

Features

The computer uses TOSHIBA’s advanced Large Scale Integration (LSI),
Complementary Metal-Oxide Semiconductor (CMOS) technology
extensively to provide compact size, minimum weight, low power usage,
and high reliability. This computer incorporates the following features and
benefits:

1-2 User’s Manual

Processor

Introduction

■ Built-in

The computer is equipped with one of the
following Intel® processors.

®

■ Intel

CoreTM Duo Processor, which
incorporates a 2MB level2 cache memory. It
also supports Enhanced Intel® SpeedStep®
Technology.

■ Intel

®

CoreTM Solo Processor, which
incorporates a 2MB level2 cache memory. It
also supports Enhanced Intel

®

SpeedStepTM

Technology.

Some models of the computers carry Intel® Centrino® Duo Mobile
Technology, which is based on three separate technologies of Intel

™

Core

Duo processor, Intel® PRO/Wireless Network Connection, and

Mobile Intel

Some models of the computers carry Intel
which is based on three separate technologies of Intel
processor, Intel

®

945 Express Chipset Family.

®

Centrino® Mobile Technology,

®

PRO/Wireless Network Connection, and Mobile Intel®

®

Core™ Solo

®

945 Express Chipset Family.

Legal Footnote (CPU)*1

For more information on the Legal Footnote regarding CPU, please refer to
the Legal Footnotes section in Chapter 10. Click the *1.

Memory

Slots The slot accepts a 256, 512, 1,024, or 2,048 MB

memory module. 256, 512,1,024, or 2,048 MB
memory modules can be installed in the two
memory slots for a maximum of 4,096 MB
system memory.

Video RAM Part of system memory is used for Video RAM.

Up to 128 MB of RAM is provided for video
display.

Legal Footnote (General Main Memory)*2

For more information on the Legal Footnote regarding General Main
Memory, please refer to the Legal Footnotes section in Chapter 10. Click
the *2.

User’s Manual 1-3

Introduction

Power

Battery pack The computer is powered by one rechargeable

lithium-ion battery pack.

Legal Footnote (Battery Life)*3

For more information on the Legal Footnote regarding Battery Life, please
refer to the Legal Footnotes section in Chapter 10. Click the *3.

RTC battery The internal RTC battery backs up the Real Time

Clock (RTC) and calendar.

AC adaptor The AC adaptor provides power to the system

and recharges the batteries when they are low. It
comes with a detachable power cord which will
either have a 2-pin or 3-pin plug enclosure.

Because it is universal, it can receive a range of
AC voltage from 100 to 240 volts; however, the
output current varies among different models.
Using the wrong model can damage your
computer. Refer to the AC adaptor section in
Chapter 2, The Grand Tour.

Disks

Hard disk drive Available in five sizes.

■ 40.0 billion bytes (37.26 GB)

■ 60.0 billion bytes (55.89 GB)

■ 80.0 billion bytes (74.53 GB)

■ 100.0 billion bytes (93.16 GB)

■ 120.0 billion bytes (111.79 GB)

Part of the space in the hard disk drive is
reserved as administration space.

Legal Footnote (HDD Drive Capacity)*4

For more information on the Legal Footnote regarding HDD Drive
Capacity, please refer to the Legal Footnotes section in Chapter 10. Click
the *4.

USB floppy disk
drive

1-4 User’s Manual

Accommodates either 3 1/2" 1.44-megabyte or
720-kilobyte floppy disks. It connects to a USB
port. Option or provided with some models.

Introduction

Optical disk drive

Computers in this series can be configured with an optical disk drive
installed in the Slim Select Bay. The available optical disk drives are
described below.

CD-ROM drive Some models are equipped with a full-size, CD-

ROM drive module that lets you run CD without
using an adaptor. It reads CD-ROMs at
maximum 24 speed. This drive supports the
following formats:

■ CD-DA

■ CD-Text

■ Photo CD™ (single/multi-session)

■ CD-ROM Mode 1, Mode 2

■ CD-ROM XA Mode 2 (Form1, Form2)

■ Enhanced CD (CD-EXTRA)

■ Addressing Method 2

DVD-ROM drive Some models are equipped with a full-size, DVD-

ROM drive module that lets you run either 12 cm
(4.72") or 8 cm (3.15") CDs or 12cm (4.72")
DVDs without using an adaptor. It runs DVD­ROMs at maximum 8 speed and CD-ROMs at
maximum 24 speed. The drive supports the
following formats:

■ DVD-ROM

■ DVD-Video

■ CD-DA

■ CD-Text

■ Photo CDTM (single/multi-session)

■ CD-ROM Mode 1, Mode 2

■ CD-ROM XA Mode 2 (Form1, Form2)

■ Enhanced CD (CD-EXTRA)

■ Addressing Method 2

User’s Manual 1-5

Introduction

DVD-ROM&CD-R/RW
drive

DVD Super Multi
drive

Some models are equipped with a full-size, DVD­ROM&CD-R/RW drive module that lets you run
CD/DVDs without using an adaptor. It reads
DVD-ROMs at maximum 8 speed and CD-ROMs
at maximum 24 speed. It writes CD-R at up to 24
speed and CD-RW at up to 24 speed. This drive
supports the following formats in addition to
DVD-ROM drive.

■ CD-R

■ CD-RW

Some models are equipped with a full-size DVD
Super Multi drive module that lets you record
data to rewritable CD/DVDs as well as run either
12cm (4.72") or 8cm (3.15") CD/DVDs without
using an adaptor. It reads DVD-ROMs at
maximum 8 speed and CD-ROMs at maximum
24 speed. It writes CD-R at maximum 24 speed,
CD-RW at maximum 10 speed, DVD-R and
DVD+R at maximum 8 speed, DVD-RW and
DVD+RW at maximum 4 speed, DVD-R DL at
maximum 2 speed, DVD+R DL at maximum 2.4
speed, DVD-RAM at maximum 5 speed.This
drive supports the following formats in addition to
DVD-ROM&CDR/ RW drive.

■ DVD-R

■ DVD-RW

■ DVD-RAM

■ DVD-R DL

■ DVD+R

■ DVD+RW

■ DVD+R DL

2.6GB and 5.2GB DVD-RAM media cannot be read from or written to.

1-6 User’s Manual

Introduction

Display

The computer’ LCD display panel supports high-resolution video graphics.
The LCD screen can be set at a wide range of viewing angles for maximum
comfort and readability.

Built-in 14.1" TFT LCD screen, 16 M colors, with one of

the following resolutions:

■ XGA, 1024 horizontal × 768 vertical pixels

■ SXGA+, 1400 horizontal × 1050 vertical

pixels

Legal Footnote (LCD)*5

For more information on the Legal Footnote regarding LCD, please refer to
the Legal Footnotes section in Chapter 10. Click the *5.

Graphics controller The graphics controller maximizes display

performance. Refer to Display Controller and

Modes section in Appendix B for more

information.

Legal Footnote (Graphics Processor Unit ("GPU"))*6

For more information on the Legal Footnote regarding Graphics Processor
Unit (“GPU”), please refer to the Legal Footnotes section in Chapter 10.
Click the *6.

Keyboard

Built-in

85 keys or 87 keys, compatible with IBM
enhanced keyboard, embedded numeric overlay,

dedicated cursor control, and keys.
Refer to Chapter 5, The Keyboard, for details.

®

TOSHIBA Dual Pointing Device

Built-in Touch Pad A Touch Pad and control buttons in the palm rest

enable control of the on-screen pointer and
scrolling of windows.

Built-in AccuPoint This pointer control stick, located in the center of

User’s Manual 1-7

the keyboard, provides convenient control of the
cursor.

Introduction

Ports

Serial RS-232C compatible port (16550UART

External monitor Analog VGA port supports VESA DDC2B

Universal Serial Bus
(USB 2.0)

Docking This port enables connection of an optional

i.LINK™ (IEEE1394) This port enables high-speed data transfer

compatible).

compatible functions.

The computer has Universal Serial Bus ports that
comply with the USB 2.0 standard.

Advanced Port Replicator III Plus described in
the Options section.

directly from external devices such as digital
video cameras.

Slots

PC card The PC card slot accommodates a Type II card.

ExpressCard The ExpressCard slot accommodates an

SD card This slot lets you easily transfer data from

ExpressCard.

devices, such as digital cameras and Personal
Digital Assistants that use SD card flash­memory.

Refer to Chapter 8, Optional Devices.

Multimedia

Sound system The Windows sound system compatible sound

Video-out jack
(S-Video)

Headphone jack A 3.5 mm mini headphone jack enables

Microphone jack A 3.5 mm mini microphone jack enables

1-8 User’s Manual

system provides output to internal speakers and
microphone as well as supporting jacks for an
external microphone and headphones.

The video out jack lets you transfer video data to
external devices. Data output depends on the
type of device connected to the S-Video cable.

connection of stereo headphones.

connection of a three-conductor mini jack for
monaural microphone input.

Communications

Introduction

Modem An internal modem provides capability for data

and fax communication. It supports V.90 (V.92).
Refer to V.90 section in Appendix E. The speed
of data transfer and fax depends on analog
telephone line conditions. It has a modem jack
for connecting to a telephone line. It is
preinstalled as a standard device in some
markets. Both of V.90 and V.92 are supported
only in USA, Canada and Australia. Only V.90 is
available in other regions.

LAN The computer has built-in support for Ethernet

LAN (10 megabits per second, 10BASE-T), Fast
Ethernet LAN (100 megabits per second,
100BASE-TX) and Gigabit Ethernet LAN (1000
megabits per second, 1000BASE-T).

It is preinstalled as a standard device in some
markets.

Bluetooth Some computers in this series are equipped with

Bluetooth functions. Bluetooth wireless
technology eliminates the need for cables
between electronic devices such as computers
and printers. Bluetooth provides fast, reliable,
and secure wireless communication in a small
space.

User’s Manual 1-9

Introduction

Wireless LAN Some computers in this series are equipped with

a Wireless LAN card that is compatible with other
LAN systems based on Direct Sequence Spread
Spectrum/Orthogonal Frequency Division
Multiplexing radio technology that complies with
the IEEE 802.11 Standard (Revision A, B or G).

■ Theoretical maximum speed: 54Mbps

(IEEE802.11a, 802.11g)

■ Theoretical maximum speed: 11Mbps

(IEEE802.11b)

■ Frequency Channel Selection (5 GHz:

Revision A / 2.4 GHz: Revision B/G)

■ Roaming over multiple channels

■ Card Power Management

■ Wired Equivalent Privacy (WEP) data

encryption, based on 128 bit encryption
algorithm.

■ Wi-Fi Protected Access (WPA).

■ Advanced Encryption Standard (AES) data

encryption.

■ Wake-up on Wireless LAN

■ The values shown above are the theoretical maximums for Wireless

LAN standards. The actual values may differ.

■ The transmission speed over the Wireless LAN and the distance over

which Wireless LAN can reach may vary depending on surrounding
electromagnetic environment, obstacles, access point design and
configuration, and client design and software/hardware configurations.
The transmission rate described is the theoretical maximum speed as
specified under the appropriate standard - the actual transmission
speed will be lower than the theoretical maximum speed.

Legal Footnote (Wireless LAN)*7

For more information on the Legal Footnote regarding Wireless LAN,
please refer to the Legal Footnotes section in Chapter 10. Click the *7.

1-10 User’s Manual

Introduction

Wireless
communication
switch

This switch turns the Wireless LAN and
Bluetooth functions on and off.

All models are provided with Wireless
Communication switch. Some models are equipped
with both Wireless LAN and Bluetooth functions.

Slim Select Bay
Modules

Slim Select Bay is a single-drive bay that
accommodates a CD-ROM, DVD-ROM, DVD­ROM&CD-R/RW drive, DVD Super Multi drive,
secondary hard disk drive and 2nd battery. The
TOSHIBA Mobile Extension enables hot insertion
of modules when you are using a plug and play
operating system.

Security

Security lock slot Connects security lock to anchor the computer to

Slim Select Bay latch Slim Select Bay module can be secured by Slim

a desk or other large object.

Select Bay latch fixed with a Slim Select Bay lock
screw in the lock position. The Slim Select Bay
lock screw is inserted in the unlock position when
purchased.

User’s Manual 1-11

Introduction

Special features

The following features are either unique to TOSHIBA computers or are
advanced features, which make the computer more convenient to use.

TOSHIBA Assist
button

TOSHIBA
Presentation button

Hot keys Key combinations let you quickly change the

Display automatic
power off

HDD automatic
power off

System automatic
Standby/Hibernation

Keypad overlay A ten-key pad is integrated into the keyboard.

Press this button to launch an application
automatically. The default is TOSHIBA Assist.

Press this button to change internal display,
external display, simultaneous display, or multi­monitor display.

system configuration directly from the keyboard
without running a system configuration program.

This feature automatically cuts off power to the
computer’s LCD display panel when there is no
keyboard input for a time specified. Power is
restored when any key is pressed. You can
specify the time in the Monitor power off item of
the Basic Setup tab in TOSHIBA Power Saver.

This feature automatically cuts off power to the
hard disk drive when it is not accessed for a time
specified. Power is restored when the hard disk is
accessed. You can specify the time in the HDD
power off item of the Basic Setup tab in TOSHIBA
Power Saver.

This feature automatically shuts down the system
into Standby Mode or Hibernation Mode when
there is no input or hardware access for a time
specified. You can specify the time and select
either the System Standby or System Hibernation
item of the Basic Setup tab in TOSHIBA Power
Saver.

Refer to the Keypad overlay section in Chapter 5,
The Keyboard, for instructions on using the
keypad overlay.

Power on password Two levels of password security, supervisor and

Instant security A hot key function blanks the LCD screen and

1-12 User’s Manual

user, are available to prevent unauthorized
access to your computer.

disables the computer providing data security.

Introduction

Intelligent power
supply

A microprocessor in the computer’s intelligent
power supply detects the battery’s charge and
calculates the remaining battery capacity. It also
protects electronic components from abnormal
conditions, such as voltage overload from an AC
adaptor. You can monitor remaining battery
capacity by using the Battery remaining item in
TOSHIBA Power Saver.

Battery save mode This feature lets you save battery power. You can

specify the Power Save Mode in the Profile item
in TOSHIBA Power Saver.

Panel power on/off This feature turns power to the computer off

when the computer’s LCD display panel is closed
and turns it back on when the computer’s LCD
display panel is opened. You can specify the
setting in the When I close the lid item of the
Setup Actions tab in TOSHIBA Power Saver.

Low battery
automatic
hibernation

When battery power is exhausted to the point that
computer operation cannot be continued, the
system automatically enters Hibernation and
shuts down. You can specify the setting in the
Setup Actions tab in TOSHIBA Power Saver.

Heat dispersal To protect from overheating, the CPU has an

internal temperature sensor. If the computer’s
internal temperature rises to a certain level, the
cooling fan is turned on or the processing speed
is lowered. Use the Cooling Method item of the
Basic Setup tab in TOSHIBA Power Saver.

Optical disk drive
power icon

Use this to turn the power of the optical disk drive
on or off. Clicking on the optical disk drive icon on
the taskbar will turn the power of the optical disk
drive on or off. If the optical disk drive power is
off, the disc tray will not open even if the eject
button is pushed. The power of the optical disk
drive can be turned on using the optical disk drive
icon.

HDD Protection Using the acceleration sensor built in the

computer, HDD Protection detects vibration,
shocks, and those signs in the computer, and
automatically moves the HDD (Hard Disk Drive)
head to the safe position to reduce the risk of
damage that could be caused to the disk by
head-to-disk contact. Refer to the Using the Hard

Disk Drive (HDD) Protection section in Chapter 4,

Operating Basics, for details.

User’s Manual 1-13

Introduction

The HDD Protection function does not guarantee that the hard disk drive
will not be damaged.

Utilities

Hibernation This feature lets you turn off the power without

Standby If you have to interrupt your work, you can turn off

This section describes preinstalled utilities and tells how to start them. For
details on operations, refer to each utility’s online manual, help files or
readme.txt files.

TOSHIBA Power
Saver

HW Setup This program lets you customize your hardware

exiting from your software. The contents of main
memory are saved to the hard disk, when you
turn on the power again, you can continue
working right where you left off. Refer to the

Turning off the power section in Chapter 3,

Getting Started, for details.

the power without exiting from your software.
Data is maintained in the computer’s main
memory. When you turn on the power again, you
can continue working right where you left off.

To access this power savings management
program, click start, click Control Panel, click

Performance and Maintenance and click the
TOSHIBA Power Saver icon.

settings according to the way you work with your
computer and the peripherals you use. To start
the utility, To access this utility, click start, click

Control Panel, click Printers and Other
Hardware and click the TOSHIBA HWSetup

icon.

TOSHIBA Controls This utility have a section to let you do the

1-14 User’s Manual

following:

■ Buttons: Assign applications or functions to

the TOSHIBA Presentation button (default
setting is the simultaneous display on LCD
and CRT with resolution of 1024 × 768) and
to the TOSHIBA Assist button (default setting
is the TOSHIBA Assist).

Introduction

Fingerprint utility This product has a fingerprint utility installed for

the purpose of enrolling and recognizing
fingerprints. By enrolling the ID and password to
the fingerprint authentication device, it is no
longer necessary to input the password from the
keyboard. Just by swiping the finger against the
fingerprint sensor, the following functions will be
enabled:

■ Logon to Windows and access a security-

enabled homepage through IE (Internet
Explorer).

■ Files and folders can be encrypted/decrypted

and third party access to them prevented.

■ Disable the password-protected screen-saver

when returning from power-saving (standby)
mode.

■ Power-on Security and Single Sign-on

feature.

■ Authentication of the User Password and

Hard Disk Drive Password when booting up
the computer.

Fingerprint cannot be used in models that do not have a fingerprint module
installed.

Fn-esse This Windows program lets you define your own

“shortcut” keys to quickly launch applications and
speed your work in Windows. To start the utility,
click start, point to All Programs, point to

TOSHIBA, point to Utilities and click Fn-esse.

DVD Video Player The DVD Video Player is used to play DVD-

Video. It has an on-screen interface and
functions. Click start, point to All Programs,
point to InterVideo WinDVD, then click

InterVideo WinDVD.

Bluetooth Stack for
Windows by Toshiba

TOSHIBA Wireless
Key Logon

This software enables communication between
remote Bluetooth devices.

This utility is intended to improve the process of
logging on to BIOS/Windows by involving the
additional use of a Bluetooth-ready cellular
phone.

Bluetooth cannot be used in models that do not have a Bluetooth module
installed.

User’s Manual 1-15

Introduction

TOSHIBA SD
Memory Boot Utility

The TOSHIBA SD memory boot utility allows you
to create a bootable SD memory card to start the
system. You can boot TOSHIBA SD Memory
Boot Utility from the menu bar as follows. Click
start, point to All Programs, point to TOSHIBA,
point to Utilities and click SD Memory Boot

Utility.

TOSHIBA Zooming
Utility

This utility allows you to enlarge or reduce the
icon size on the desktop or the application
window.

RecordNow! Basic
for TOSHIBA

You can create CD/DVDs in several formats
including audio CDs that can be played on a
standard stereo CD player and data CD/DVDs to
store the files and folders on your hard disk drive.
This software can be used on a model with DVD­ROM&CD-R/RW drive and DVD Super Multi
drive.

TOSHIBA Assist TOSHIBA Assist is a graphical user interface that

provides easy access to help and services. It is
the default function launched by the TOSHIBA
Assist button.

TOSHIBA PC
Diagnostic Tool

TOSHIBA PC Diagnostic Tool displays the basic
information on the computer's configuration and
allows some of the built-in devices functionality to
be tested. To start TOSHIBA PC Diagnostic Tool,
click start, point to All Programs, point to

TOSHIBA, point to Utilities and click PC
Diagnostic Tool.

TOSHIBA Mobile
Extension

This utility supports docking your computer to an
optional Advanced Port Repricator III Plus. To
open the property dialog, select TOSHIBA Mobile
Extension from TOSHIBA Assist.

TOSHIBA ConfigFree TOSHIBA ConfigFree is a suite of utilities to

allow easy control of communication devices and
network connections. TOSHIBA ConfigFree also
allows you to find communication problems and
create profiles for easy switching between
locations and communication networks. To start
ConfigFree, click start, point to All Programs,
point to TOSHIBA, point to Networking and click
ConfigFree.

1-16 User’s Manual

Introduction

TOSHIBA Dual
Pointing Device
utility

This utility has the following functions:
To disable/enable TOSHIBA Dual Pointing

Device with Fn + F9 keys. To customize the
functions of TOSHIBA Dual Pointing Device
easily.

TOSHIBA Mic Effect TOSHIBA Mic Effect is a utility used to enable

comfortable calls with echo cancellation function.
The echo cancellation function removes or
reduces any harsh echoes or howling sounds
that occur when playing audio sounds recorded
with a microphone through the speakers. The
echo cancellation function is available only when
you use telephony software such as Windows
Messenger with a voice conversation function.

For more instructions for this software, click
start, point to All Programs, point to TOSHIBA,
point to Utilities and click TOSHIBA Mic Effect

Help.

NVIDIA Rotation
Settings

This utility let you rotate the desktop by 0 and
180 easily. It can rotate by clicking the icon in a

taskbar or pressing Ctrl + Shift + Up ( ↑ ) to
rotate 0 degrees/Ctrl + Shift + Down ( ↓ ) to

rotate 180 degrees. In a multimonitor setup, the
display that contains the cursor is effective.

TOSHIBA Password
Utility

TOSHIBA
Accessibility

This utility lets you set a password that restricts
access to the computer.

This utility lets you make the Fn key sticky, that
is, you can press it once, release it, and they
press an “F number” key. The Fn key remains
active until another key is pressed.

DLA for TOSHIBA DLA (Drive Letter Access) is the packet writing

software which provides the function, which
writes files and/or folders to DVD-RW, CD-RW
and DVD+RW discs via a drive letter like a floppy
disk or other removable disks.

TOSHIBA Hotkey
Utility for Display
Devices

This utility has the change of a display device,
and the function to change display resolution.
Press Fn + F5 to change the active display
device. Press Fn + Space keys to change the
display resolution.

User’s Manual 1-17

Introduction

Options

TOSHIBA SD
Memory Card Format

CD/DVD Drive
Acoustic Silencer

You can add a number of options to make your computer even more
powerful and convenient to use. The following options are available:

Memory expansion A 256, 512, 1,024, or 2048 MB memory module

Battery pack An additional battery pack can be purchased

Extended capacity
battery pack

High capacity
battery pack

AC adaptor If you use your computer at more than one site

This utility allows you to format an SD memory
card by the SD standard format.

This utility allows you to configure the read speed
of CD drive. You can either configure Normal
Mode, which operates the drive at its maximum
speed for quick data access, or Quiet Mode
which runs at single speed for CD audio and
which can lessen operational noise.

It is ineffective in DVD.

(DDR2-667/533) can easily be installed in the
computer.

from your TOSHIBA dealer. Use it as a spare or
replacement.

An additional battery pack can be purchased
from your TOSHIBA dealer. Use it as a spare or
replacement.

An additional battery pack can be purchased
from your TOSHIBA dealer. Use it as a spare or
replacement.

frequently, it may be convenient to purchase an
additional AC adaptor for each site so you will not
have to carry the adaptor with you.

Battery charger The battery charger lets you charge extra

Security lock A slot is available to attach a security cable to the

USB floppy disk Kit The USB floppy disk drive accommodates either

1-18 User’s Manual

batteries outside the computer.

computer to deter theft.

3 1/2" 1.44-megabyte or 720-kilobyte floppy
disks through connection to a USB port. Please
note that you cannot format 720-kilobyte floppy
disks under Windows XP, but you are able to use
disks that have been previously formatted.

Introduction

Advanced Port
Replicator III Plus

The Advanced Port Replicator III Plus provides
the ports available on the computer in addition to
separate PS/2 mouse and PS/2 keyboard ports,
a digital visual interface (DVI) port, i.LINK™
(IEEE1394) port, line-in jack and line-out jack,
External monitor port, Universal Serial Bus port
(USB2.0) × 4, LAN jack, Modem jack, Serial port,
Parallel port.

Hard disk drive You can increase your computer's data storage

capacity with additional hard disk drives. They
are available in the following sizes:

■ 80.0 billion bytes (74.53 GB)

■ 100.0 billion bytes (93.16 GB)

Bluetooth Kit This option enables Bluetooth wireless

communications in computers that do not have
Bluetooth preinstalled. It is installed by dealers
only.

Slim Select Bay options

The following modules can be installed in the Slim Select Bay. All other
modules are options.

Slim Select Bay HDD
adaptor

2nd Battery Pack The 2nd battery increases your computer’s

An adaptor lets you install an optional hard disk
drive described in Chapter 8, Optional Devices.

battery power and operating time when a main
battery is also installed.

User’s Manual 1-19

Introduction

1-20 User’s Manual

TECRA M5

The Grand Tour

This chapter identifies the various components of your computer. Become
familiar with each component before you operate the computer.

Legal Footnote (Non-applicable Icons)*8

For more information on the Legal Footnote regarding Non-applicable
Icons, please refer to the Legal Footnotes section in Chapter 10. Click the
*8.

Front with the display closed

Figure 2-1 shows the computer’s front with its LCD display panel in the
closed position.

Chapter 2

System
indicators

Wireless communication switch

Figure 2-1 Front of the computer with LCD display panel closed

System indicators These LEDs let you monitor the status of various

Wireless
communication
switch

User’s Manual 2-1

computer functions. Details are given in the

System indicators section.

Slide this switch to the left to turn off Wireless
LAN and Bluetooth functions. Slide it to the right
to turn on the functions.

All models are provided with a Wireless
Communication switch although only some
models are equipped with both Wireless LAN
and Bluetooth functions.

Display latch

Microphone

The Grand Tour

■ Turn WiFi and Bluetooth functionalities off when near a person who

may have a cardiac pacemaker implant or other medical electric
device. Radio waves may affect pacemaker or medical device
operation, possibly resulting in serious injury. Follow the instruction of
your medical device when using any WiFi or Bluetooth functionality.

■ Always turn off WiFi or Bluetooth functionality if the PC is near

automatic control equipment or appliances such as automatic doors or
fire detectors. Radio waves can cause malfunction of such equipment,
possibly resulting in serious injury.

■ Do not use the WiFi or Bluetooth functionalities near a microwave oven

or in areas subject to radio interference or magnetic fields. Interference
from a microwave oven or other source can disrupt WiFi or Bluetooth
operation.

Display latch This latch secures the LCD panel in its closed

position. Slide the latch to open the display.

Microphone A built-in microphone lets you record sound into

your applications. Refer to the Sound system
section in Chapter 4, Operating Basics.

2-2 User’s Manual

Left side

The Grand Tour

Figure 2-2 shows the computer’s left side.

ExpressCard eject button

ExpressCard slot

PC card slot

PC card
eject button

Cooling vents

External monitor port

USB port

i.LINK (IEEE1394) port

SD card slot

Security lock slot

Figure 2-2 The left side of the computer

Security lock slot A security cable attaches to this slot. The

optional security cable anchors your computer to
a desk or other large object to deter theft.

Cooling vents Cooling vents help CPU keep from overheating.

Do not block the cooling vents. Never allow metal objects, such as screws,
staples and paper clips, to enter the PC or keyboard. Foreign metal objects
can create a short circuit, which can cause PC damage and fire, possibly
resulting in serious injury.

External monitor
port

i.LINK (IEEE1394)
port

This external monitor port lets you connect an
external video display.

This port allows you to connect an external
device, such as a digital video camera for high­speed data transfer.

ExpressCard slot The ExpressCard slot can accommodate an

ExpressCard.

ExpressCard eject
button

This is a button for taking out ExpressCard from
ExpressCard slot.

PC card slot The PC card slot can accommodate a Type II

card. The slot supports 16-bit PC cards and
CardBus PC cards.

PC card eject button This is a button for taking out PC card from a PC

card slot.

User’s Manual 2-3

The Grand Tour

Keep foreign objects out of the ExpressCard slot and PC card slot. Never
allow metal objects, such as screws, staples and paper clips, to enter the
PC or keyboard. Foreign metal objects can create a short circuit, which
can cause PC damage and fire, possibly resulting in serious injury.

SD card slot SD cards are used in a wide variety of external

devices. This slot lets you transfer data from the
device to your computer.

Keep foreign objects out of the SD card slot. A pin or similar object can
damage the computer’s circuitry.

Universal Serial Bus
(USB 2.0) ports

One Universal Serial Bus port is on the left side.
The ports complies with the USB 2.0 standard.

2-4 User’s Manual

Right side

Figure 2-3 shows the computer’s right side.

Volume control

Microphone jack

The Grand Tour

Slim Select Bay

Headphone jack

USB ports

Figure 2-3 The right side of the computer

Serial port

Volume control Use this dial to adjust the volume of the stereo

speakers and the stereo headphones.

Microphone jack A 3.5 mm mini microphone jack enables

connection of a three-conductor mini jack for
monaural microphone input.

Headphone jack A 3.5 mm mini headphone jack enables

connection of stereo headphones.

Universal Serial Bus
(USB 2.0) ports

Two Universal Serial Bus ports are on the right
side. The ports comply with the USB 2.0
standard.

Keep foreign objects out of the USB connectors. Never allow metal
objects, such as screws, staples and paper clips, to enter the PC or
keyboard. Foreign metal objects can create a short circuit, which can
cause PC damage and fire, possibly resulting in serious injury.

Operation of all functions of all USB devices has not been confirmed.
Some functions might not execute properly.

Slim Select Bay A CD-ROM, DVD-ROM, DVD-ROM&CD-R/RW

drive, DVD Super Multi drive, Slim Select Bay
HDD adaptor or 2nd Battery pack can be
installed in the Slim Select Bay.

Serial port Use this 9-pin port to connect serial devices such

as an external modem, serial mouse or serial
printer.

User’s Manual 2-5

The Grand Tour

Back side

Figure 2-4 shows the computer’s back side.

Video-out jack

LAN active
indicator (orange)

Modem jack

Figure 2-4 The back side of the computer

Link indicator (green)

LAN jack

DC IN 15V jack

Video-out jack Plug an S-Video cable into this jack for video-out.

The S-Video cable carries video signal.

DC IN 15V jack The AC adaptor connects to this jack. Use only

the model of AC adaptor that comes with the
computer. Using the wrong adaptor can damage
your computer.

Modem jack In areas where an internal modem is installed as

standard equipment, there is a modem jack that
lets you use a modular cable to connect the
modem directly to a telephone line.

■ Connection to any communication line other than an analog phone line

could cause a PC system failure.

■ Connect the built-in modem only to ordinary analog phone lines.

■ Never connect the built-in modem to a digital line (ISDN).

■ Never connect the built-in modem to the digital connector on a

public telephone or to a digital private branch exchange (PBX).

■ Never connect the built-in modem to a key telephone system for

residences or offices.

■ Never operate your PC on AC power during a thunderstorm. If you see

lightning or hear thunder, immediately turn off the PC. An electric surge
caused by the storm, may result in a system failure, loss of data or
hardware damage.

2-6 User’s Manual

The Grand Tour

LAN jack This jack lets you connect to a LAN. The adaptor

has built-in support for Ethernet LAN (10
megabits per second, 10BASE-T), Fast Ethernet
LAN (100 megabits per second, 100BASE-TX)
and Gigabit Ethernet LAN (1000 megabits per
second, 1000BASE-T). The LAN has two
indicators. Refer to Chapter 4, Operating Basics,
for details.

■ Do not connect any cable other than a LAN cable to the LAN jack. It

could cause damage or malfunction.

■ Do not connect the LAN cable to a power supply. It could cause

damage or malfunction.

Link indicator
(green)

LAN active indicator
(orange)

Underside

Figure 2-5 shows the underside of the computer. Make sure the display is
closed before turning over your computer.

Slim Select Bay

Slim Select Bay
latch

Battery lock

This indicator glows green when the computer is
connected to a LAN and the LAN is functioning
properly.

This indicator glows orange when data is being
exchanged between the computer and the LAN.

Battery pack

Slim Select Bay lock

Notches

Battery
release latch

Docking
port

Memory
module cover

HDD pack cover screw

User’s Manual 2-7

Hard disk drive cover

Figure 2-5 The underside of the computer

The Grand Tour

Battery lock Slide the battery lock to release the battery pack

for removal.

Battery pack The battery pack powers the computer when the

AC adaptor is not connected. For detailed
information on the battery pack, refer to Chapter
6, Power and Power-Up Modes.

Notches Notches on the computer engage hooks on the

Advanced Port Replicator III Plus to ensure a
secure connection.

Battery release
latch

Slide and hold this latch to release the battery
pack for removal.

For detailed information on removing the battery
pack, refer to Chapter 6, Power and Power-Up

Modes.

Docking port This port enables connection of an optional

Advanced Port Replicator III Plus described in
Chapter 8, Optional Devices.

■ Only the Advanced Port Replicator III plus can be used with this

product (PC). Do not attempt to use any other Port Replicator.

■ Keep foreign objects out of the docking port. A pin or similar object can

damage the computer's circuitry. A plastic shutter protects the
connector.

Slim Select Bay See the Right side section in this chapter for

details.

Slim Select Bay latch Slide the latch to release or secure the Slim

Select Bay ejector.

Be sure to lock the Slim Select Bay latch before you transport or carry the
computer.

Slim Select Bay lock

One screw secures the Slim Select Bay latch.

screw

Memory module
cover

This cover protects memory module sockets.
Refer to the Memory expansion section in
Chapter 8, Optional Devices.

2-8 User’s Manual

The Grand Tour

HDD pack cover

One screw secures the HDD cover.

screw

Hard disk drive
cover

A HDD disk drive pack is under this, which can
be removed and reinstalled. For more
information on how to remove or reinstall the

Hard disk drive pack, refer to the section on the

in Chapter 8, Optional Devices.

Front with the display open

This section shows the computer with the LCD display panel open. Refer to
the appropriate illustration for details. To open the display, slide the display
latch on the front of the LCD display panel and lift up. Position the LCD
display panel at a comfortable viewing angle.

Display hinge

Display screen

Stereo speaker (Right)

LCD Sensor switch
(Not shown)

Stereo speaker
(Left)

Power button

TOSHIBA Assist
button

TOSHIBA Presentation button

Figure 2-6 The front of the computer with the LCD panel open

User’s Manual 2-9

Accupoint control button

AccuPoint

Touch Pad

Fingerprint
Sensor

Touch Pad
control buttons

The Grand Tour

Display hinge The display hinge holds the LCD display panel at

easy-to-view angles.

Fingerprint Sensor

Just by swiping the finger against the fingerprint
sensor, the following functions will be enabled:

■

Logon to Windows and access a security­enabled homepage through IE (Internet
Explorer).

■

Files and folders can be encrypted/decrypted
and third party access to them prevented.

■

Disable the password-protected screen-saver
when returning from power-saving (standby)
mode.

■

Power-on Security and Single Sign-on feature.

■

Authentication of the User Password and Hard
Disk Drive Password when booting up the
computer.

Display screen The LCD screen displays high-contrast text and

graphics. The available resolution depends on
the model. With XGA, you can change the
resolution between 800 × 600 and 1024 × 768
pixels. With SXGA+, between 800 × 600 and
1400 × 1050 pixels. Refer to Display Controller

and Modes section in Appendix B.

When the computer operates on the AC adaptor
the LCD screen’s image will be somewhat
brighter than when it operates on battery power.
The lower brightness level is intended to save
battery power.

Stereo speakers The speakers emit sound generated by your

software as well as audio alarms, such as low
battery condition, generated by the system.

AccuPoint control
buttons

Control buttons below the keyboard let you select
menu items or manipulate text and graphics
designated by the on-screen pointer. Refer to the

Using the AccuPoint section in Chapter 4,

Operating Basics.

AccuPoint A pointer control device located in the center of

the keyboard is used to control the on-screen
pointer. Refer to the Using the AccuPoint section
in Chapter 4, Operating Basics.

Touch Pad control
buttons

Control buttons below the Touch Pad let you
select menu items or manipulate text and
graphics designated by the on-screen pointer.

2-10 User’s Manual

The Grand Tour

Touch P a d A Touch Pad located in the center of the palm

rest is used to control the on-screen pointer.
Refer to the Using the Touch Pad section in
Chapter 4, Operating Basics.

TOSHIBA
Presentation button

Press this button to display same image on
internal and external monitors or to use multi­monitor display (Windows XP Only).

The default setting is "Presentation (Same Image
1024x768)", it can be displayed same image on
internal and external monitors with screen
resolution 1024x768.

In the setting of "Presentation (Different Image)",
you can use the internal and external monitors as
a widescreen.

"Presentation (Different Image)" is supported in
Windows XP only.

Pressing the button again can be changed single
display mode on an internal monitor only.

You can specify the function of TOSHIBA
Presentation button in the TOSHIBA Controls
properties.

TOSHIBA Assist
button

Press this button to launch the program. The
default is TOSHIBA Assist.

When power-off, stand-by and hibernation, press
this button to start the computer and launch the
program.

You can specify the function of TOSHIBA Assist
button in the TOSIHBA Controls properties.

Power button Press the power button to turn the computer’s

power on and off.

LCD Sensor switch This switch senses when the computer’s LCD

display panel is closed or opened and activates
the Panel Power Off/On feature. When you close
the LCD display panel the computer enters
Hibernation Mode and shuts down. When you
open the computer's LCD display panel the
computer starts in Hibernation Mode. Use the
TOSHIBA Power Saver Utility to enable or
disable this feature. The default is “enabled”.

Refer to the TOSHIBA Power Saver Utility and
Panel Power Off/On items in Chapter 1, Special

features, for details on settings.

User’s Manual 2-11

The Grand Tour

Do not put a magnetic object close to the switch. The computer will
automatically enter Hibernation Mode and shut down even if the Panel
Power Off features is disabled.

System indicators

LEDs beneath icons, light when various computer operations are in
progress.

Figure 2-7 System indicators

SD card The SD card indicator glows green when the

DC IN The DC IN indicator glows green when DC power

Power The Power indicator glows green when the

Battery The Battery indicator shows the condition of the

HDD The HDD indicator glows green when the

Wireless
communication

computer is accessing the SD card slot.

is supplied from the AC power adaptor. If the
adaptor’s output voltage is abnormal or if the
power supply malfunctions, this indicator flashes
orange.

computer is on. If you select Standby from Shut
Down Windows, this indicator flashing (one
second on, two seconds off) while the computer
shuts down.

battery’s charge: Green indicates full charge,
orange indicates battery charging and flashing
orange indicates a low battery charge. Refer to
Chapter 6, Power and Power-Up Modes.

computer is accessing the built-in hard disk drive.

The Wireless communication indicator glows
when the Bluetooth and wireless LAN functions
are turned on.

All models are provided with a Wireless
Communication switch although only some
models are equipped with both Wireless LAN
and Bluetooth functions.

2-12 User’s Manual

Slim Select Bay The Slim Select Bay indicator glows in green

Keyboard indicators

The figures below show the positions of the keypad overlay indicators and
the Caps Lock indicator.

When the Arrow mode indicator glows the keypad overlay lets you control
the cursor.

When the Numeric mode indicator glows the keypad overlay lets you enter
numbers.

When the Caps Lock indicator glows the keyboard is in all-caps mode.

The Grand Tour

when the computer is accessing a CD-ROM
drive, DVD-ROM drive, DVD-ROM&CD-R/RW
drive, DVD Super Multi drive and DVDÅ}R/Å}RW
drive or Slim Select Bay HDD adaptor in the Slim
Select Bay. When the 2nd battery is in the Slim
Select Bay, the Slim Select Bay indicator glows
as follows:green : fully charged orange : charging
the battery

Caps Lock indicator

Figure 2-8 Caps Lock indicator

Caps Lock This indicator glows green when the alphabet

keys are locked in uppercase.

Arrow mode

Figure 2-9 Keypad overlay indicators

User’s Manual 2-13

Numeric
mode

The Grand Tour

Arrow mode When the Arrow mode indicator lights green,

Numeric mode You can use the keypad overlay (gray labeled

USB floppy disk drive

The USB floppy disk drive accommodates 1.44-megabyte or 720-kilobyte
floppy disks and connects to the USB port. It is supplied as standard with
some models and as an option with others.

USB connector

you can use the keypad overlay (gray labeled
keys) as cursor keys. Refer to the Keypad

overlay section in Chapter 5, The Keyboard.

keys) for numeric input when the Numeric mode
indicator lights green. Refer to the Keypad

overlay section in Chapter 5, The Keyboard.

Disk-In-Use
Indicator

Floppy disk
slot

Figure 2-10 USB floppy disk drive

Eject button

USB connector Insert this connector into one of the USB ports of

your computer.

Disk-In-Use Indicator This indicator lights when the floppy disk is being

accessed.

Floppy disk slot Insert a floppy disk in this slot.

Eject button When a floppy disk is fully seated in the drive, the

eject button pops out. To remove a floppy disk,
push in the eject button and the floppy disk pops
out partially for removal.

Check the Disk-In-Use indicator when you use the USB floppy disk drive.
Do not press the eject button or turn off the computer while the light is
glowing. Doing so could destroy data and damage the floppy disk or the
drive.

2-14 User’s Manual

■ The USB floppy disk drive should be placed on a flat, horizontal surface

when in use. Do not set the drive on an incline 20° while it is operating.

■ Do not set anything on top of the floppy disk drive.

Optical disk drives

One of the following Optical disk drives is installed in the computer: CD­ROM, DVD-ROM, DVD-ROM&CD-R/RW and DVD Super Multi drives. An
ATAPI interface controller is used for CD/DVD-ROM operation. When the
computer is accessing a CD/DVD, an indicator on the drive glows.

For information on loading and unloading discs refer to the Using optical

disk drives section in Chapter 4, Operating Basics.

Region codes for DVD drives and media

DVD-ROM&CD-R/RW, DVD Super Multi drives and media are
manufactured according to the specifications of six marketing regions.
When you purchase DVD-Video, make sure it matches your drive,
otherwise it will not play properly.

Code Region

1 Canada, United States

2 Japan, Europe, South Africa, Middle East

The Grand Tour

3 Southeast Asia, East Asia

4 Australia, New Zealand, Pacific Islands, Central

5 Russia, Indian Subcontinent, Africa, North Korea,

6 China

America, South America, Caribbean

Mongolia

Writable discs

This section describes the types of writable CD/DVD discs. Check the
specifications for your drive to for the type of discs it can write. Use
RecordNow! to write compact discs. Refer to Chapter 4, Operating Basics.

CDs

■ CD-R discs can be written only once. The recorded data cannot be

erased or changed.

■ CD-RW discs including multi speed CD-RW discs, high-speed CD-RW

discs and ultra-speed CD-RW discs can be recorded more than once.

User’s Manual 2-15

The Grand Tour

DVDs

Formats

■ DVD-R, DVD+R, DVD-R DL and DVD+R DL discs can be written only

once. The recorded data cannot be erased or changed.

■ DVD-RW, DVD+RW and DVD-RAM discs can be recorded more than

once.

The drives support the following formats:

■ CD-ROM

■ DVD-ROM

■ CD-DA

TM

■ Photo CD

■ CD-ROM XA Mode 2 (Form1,

Form2)

(single/multi-session)

■ DVD -Video

■ CD-Text

■ CD-ROM Mode 1, Mode 2

■ Enhanced CD (CD-EXTRA)

■ Addressing Method 2

CD-ROM drive

The full-size CD-ROM drive module lets you run either 12 cm (4.72") or 8
cm (3.15") CD without using an adaptor.

The read speed is slower at the center of a disc and faster at the outer
edge.

CD read 24 speed (maximum)

DVD-ROM drive

The full-size DVD-ROM&CD-R/RW drive module lets you record data to
rewritable CDs as well as run either 12 cm (4.72") or 8 cm (3.15") CD/DVDs
without using an adaptor.

The read speed is slower at the center of a disc and faster at the outer
edge.

DVD read 8 speed (maximum)
CD read 24 speed (maximum)

2-16 User’s Manual

DVD-ROM&CD-R/RW drive

The full-size DVD-ROM drive module lets you run either 12 cm (4.72") or 8
cm (3.15") CD/DVDs without using an adaptor.

The read speed is slower at the center of a disc and faster at the outer
edge.

DVD read 8 speed (maximum)
CD read 24 speed (maximum)
CD-R write 24 speed (maximum)
CD-RW write 24 speed (maximum, Ultra speed media)

DVD Super Multi drive

The full-size DVD Super Multi drive module lets you record data to
rewritable CDs as well as run either 12 cm (4.72") or 8 cm (3.15") CD/DVDs
without using an adaptor.

■ The read speed is slower at the center of a disc and faster at the outer

edge.

DVD read 8 speed (maximum)
DVD-R write 8 speed (maximum)
DVD-RW write 4 speed (maximum)
DVD-R DL write 2 speed (maximum)
DVD+R write 8 speed (maximum)
DVD+R DL write 2.4 speed (maximum)
DVD+RW write 4 speed (maximum)
DVD-RAM write 5 speed (maximum)
CD read 24 speed (maximum)
CD-R write 24 speed (maximum)
CD-RW write 10 speed (maximum, Ultra-speed media)

2.6GB and 5.2GB DVD-RAM media cannot be read from or written to.

The Grand Tour

User’s Manual 2-17

The Grand Tour

AC adaptor

The AC adaptor can automatically adjust to any voltage ranging from 100
to 240 volts and to a frequency of either 50 or 60 hertz, enabling you to use
this computer in almost any country/region. The adaptor converts AC
power to DC power and reduces the voltage supplied to this computer.

To recharge the battery, simply connect the AC adaptor to a power source
and the computer. Refer to Chapter 6, Power and Power-Up Modes for
details.

Figure 2-11 The AC adaptor (2-pin plug)

Figure 2-12 The AC adaptor (3-pin plug)

■ The Universal AC Adaptor and power cord bundled with this product

may differ depending on the product model. Depending on the model, a
2-pin plug or 3-pin plug set of the above may be bundled.

■ Do not use a 3-pin to 2-pin conversion plug.

■ The supplied power cord conforms to safety rules and regulations in

the region the product is bought and should not be used outside this
region. For use in other regions, please buy power cords that conform
to safety rules and regulations in the particular region.

2-18 User’s Manual

The Grand Tour

Always use the Toshiba AC adaptor that was provided with your PC and
the Toshiba Battery Charger (that may have been provided with your PC),
or use Toshiba recommended alternate models to avoid any risk of fire or
other damage to the PC. Use of an incompatible AC adaptor or Battery
Charger could cause fire or damage to the PC possibly resulting in serious
injury.

User’s Manual 2-19

The Grand Tour

2-20 User’s Manual

TECRA M5

Getting Started

This chapter provides basic information to get you started using your
computer. It covers the following topics:

■ Setting up your work space - for your health and safety

Be sure also to read Instruction Manual for Safety & Comfort. This guide,
which is included with the computer, explains product liability.

■ Connecting the AC adaptor

■ Opening the display

■ Turning on the power

■ Starting up for the first time

■ Turning off the power

■ Restarting the computer

■ Creating recovery media

■ Restoring the preinstalled software from the HDD

■ Restoring the preinstalled software from the Recovery Media

Chapter 3

All users should be sure to read the section Starting up for the first time.

Setting up your work space

Establishing a comfortable work site is important for you and your
computer. A poor work environment or stressful work habits can result in
discomfort or serious injury from repetitive strain to your hands, wrists or
other joints. Proper ambient conditions should also be maintained for the
computer’s operation. This section discusses the following topics:

■ General conditions

■ Placement of the computer

■ Seating and posture

■ Lighting

■ Work habits

User’s Manual 3-1

Getting Started

General conditions

In general, if you are comfortable, so is your computer, but read the
following to make sure your work site provides a proper environment.

■ Select a work area that has:

■ a well-designed and functioning ventilation system that does not

■ good air circulation

■ a comfortable ambient temperature and relative humidity.

■ Never place your PC where it will be exposed to excess heat, such as in

direct sunlight, an unventilated vehicle or near a heater. This may result
in a system failure, malfunction, loss of data or damage to PC.

■ Never place your PC in a location where it will be exposed to extremely

low temperatures. This may result in a system failure, malfunction or
loss of data.

■ Never subject your PC to sudden temperature variations. This may

result in condensation, causing a system failure, malfunction or loss of
data.

■ Do not expose your PC to dusty environments. If dust gets inside the

PC, it could cause a system failure, malfunction or loss of data. If dust
contaminates the PC, do not turn on the power. Take it to an authorized
Toshiba service provider before you use it.

■ Never place your PC near an object that generates a magnetic field,

such as a speaker or TV. Do not wear magnetic bracelets while using
your PC. Exposure to magnetic fields can cause system failure,
malfunction or loss of data.

■ Never place a heavy object on the PC and be careful not to drop a

heavy object onto the PC. It could damage the PC or cause system
failure.

■ Never use benzene, thinner or other chemicals when cleaning the PC,

AC adaptor, or storage device. The use of benzene, thinner or other
chemicals may result in deterioration, deformation or discoloration of
those items and the loss of data.

■ Make sure the AC power cord connects to an outlet that is close to the

computer and easily accessible.

■ The temperature should be 5 to 35 degrees Centigrade (41 to 95

degrees Fahrenheit) and the relative humidity should be 20 to 80
percent.

■ Keep the computer free of dust, moisture, and exposure to direct

sunlight.

■ Some parts of the computer, including data storage media, can be

damaged by magnets. Do not place the computer near magnetic
objects or bring magnetic objects close to the computer. Be careful of
objects, such as stereo speakers, that produce strong magnetic fields
during operation. Also, be careful with metal objects, such as bracelets,
which can be inadvertently magnetized.

■ Do not operate the computer in close proximity to a mobile phone.

forcefully direct air on you

3-2 User’s Manual

■ Leave ample ventilation room for the fan. Do not block the vents.

■ If the PC interferes with radio equipment, turn the PC power off

immediately. Such interference could cause equipment malfunction.

■ Never place your PC on a shaky table, uneven, tilted surface or other

unstable location. Your PC may fall, causing damage to the PC or
possibly injury.

■ Never leave the power to your PC on continuously for more than 24

hours. Turn the power off when this product is not in use.

■ Always avoid abrupt changes of temperature or humidity.

■ Never place close to heat radiating appliances such as a heater.

■ Never place close to corrosive chemicals.

■ Never place close to magnetic field radiating appliances such as a

stereo speaker.

■ Always place this product on a flat surface.

■ Provide a sufficient space behind the PC to allow easy adjustment of

the display panel.

■ Always provide sufficient space around the PC to ensure adequate

ventilation.

■ Always provide sufficient space for operating a mouse and other

peripheral devices.

Placement of the computer

Position the computer and peripheral devices to provide comfort and
safety.

■ Position your LCD display panel or place your monitor in an appropriate

position to help reduce awkward postures and overhead glare. For
example:

■ Position LCD directly in front of you and at a comfortable distance

away.

■ Position LCD so the top of the screen is at or slightly below eye

level. A display screen that is too high or too low can cause
awkward postures and possibly fatigue muscles that support the
head.

■ Rest your eyes periodically by focusing on objects that are farther

away.

■ If you use a paper holder, set it at about the same height and distance

as the computer.

Getting Started

User’s Manual 3-3

Getting Started

Seating and posture

Maintain a comfortable working posture when using your PC where your
body joints are naturally aligned to reduce stress on different parts of your
body. Consider the following:

Foot rest

■ Keep hands, wrists, and forearms straight, in-line and roughly parallel to

the floor.

■ Keep head level, or bent slightly forward, forward facing, and balanced.

Generally the head is in-line with the torso.

■ Keep shoulders relaxed and let upper arms hang normally at the side of

the body.

■ Keep elbows in close to the body and bent.

■ Keep feet fully supported by floor or foot rest.

■ Keep back fully supported with appropriate lumbar support when sitting

vertical or leaning back slightly.

■ Keep thighs and hips supported by a well-padded seat cushion and

generally parallel to the floor.

■ Keep knees about the same height as the hips with the feet slightly

forward.

Below eye level

90°angles

Figure 3-1 Posture and positioning of the computer

3-4 User’s Manual

Lighting

Select the right level of illumination and place your PC appropriately to
minimize glare from overhead lights, desk lamps and windows. Glare on
the LCD or monitor may cause eye strain, eye fatigue or headaches.

Consider the following suggestions regarding lighting your work
environment:

■ Position the PC so that the light source does not shine or reflect directly

onto the display or shine or reflect directly into the eyes of the user.

■ Shield the PC from direct light by using tinted windows or by installing

blinds or a screen.

■ Use soft, indirect lighting.

■ Adjust the display panel to provide maximum visibility.

Work habits

A key to avoiding discomfort or injury from repetitive strain is to vary your
activities. If possible, schedule a variety of tasks into your workday. If you
must spend long periods at the computer, finding ways to break up the
routine can reduce stress and improve your efficiency.

■ Sit in a relaxed posture. Good positioning of your chair and equipment

as described earlier can reduce tension in your shoulders or neck and
ease back strain.

■ Vary your posture frequently.

■ Occasionally stand up and stretch or exercise briefly.

■ Exercise and stretch your wrists and hands a number of times during

the day.

■ Frequently, look away from the computer and focus your eyes on a

distant object for several seconds, for example 30 seconds every 15
minutes.

■ Take frequent short breaks instead of one or two long breaks, for

example, two or three minutes every half hour.

■ When you use a PC, rest your eyes periodically and relax or stretch

your muscles to avoid strain. If you experience discomfort while
operating the PC, stop immediately and rest. Continuous operation for
long periods without adequate rest may cause pain in the arms, wrists,
hands, back, neck or other parts of the body. If pain persists despite
rest, consult your doctor.

A number of books are available on ergonomics and repetitive strain injury
or repetitive stress syndrome. For more information on these topics or for
pointers on exercises for such stress points as hands and wrists, please
check with your library or book vendor. Also refer to the computer’s

Instruction Manual for Safety & Comfort.

Getting Started

User’s Manual 3-5

Getting Started

Strategic Rest Breaks

Take short, strategically spaced rest breaks to avoid eye strain and body
discomforts.

For more specific recommendations on the safety and comfort of your
computer environment, customers in the United States may visit the United
States Department of Labor, Occupational Safety & Health Administration
website at: http://www.osha.gov/SLTC/etools/computerworkstations/

Other Things to Note

■ Never turn off the power while an application is running. Doing so could

cause loss of data.

■ Use a virus-check program and make sure it is updated regularly.

■ Never turn off the power, disconnect an external storage device or

remove storage media during data read/write. Doing so can cause data
loss.

■ Never format storage media without checking its content. Formatting

destroys all stored data.

■ It is a good idea to periodically back up the internal hard disk or other

main storage device to external media. General storage media is not
durable or stable over long periods of time and under certain conditions
may result in data loss.

■ Before you install a device or application, save any data in memory to

the hard disk drive or other storage media. Failure to do so may result in
the loss of data.

Connecting the AC adaptor

Attach the AC adaptor when you need to charge the battery or you want to
operate from AC power. It is also the fastest way to get started, because
the battery pack will need to be charged before you can operate from
battery power.

The AC adaptor can be connected to any power source supplying from 100
to 240 volts and 50 or 60 hertz. For details on using the AC adaptor to
charge the battery pack, refer to Chapter 6, Power and Power-Up Modes.

3-6 User’s Manual

Getting Started

■ Always use the Toshiba AC adaptor that was provided with your PC

and the Toshiba Battery Charger (that may have been provided with
your PC), or use Toshiba recommended alternate models to avoid any
risk of fire or other damage to the PC. Use of an incompatible AC
adaptor or Battery Charger could cause fire or damage to the PC
possibly resulting in serious injury.

■ Use only the AC adaptor supplied with your computer or an equivalent

adaptor that is compatible. Use of any incompatible adaptor could
damage your computer. TOSHIBA assumes no liability for any damage
caused by use of an incompatible adaptor.

■ Never plug the AC adaptor or Battery Charger into a power source that

does not correspond to both the voltage and the frequency specified on
the regulatory label of the unit. Failure to do so could result in a fire or
electric shock, possibly resulting in serious injury.

■ Always use or purchase power cables that comply with the legal

voltage and frequency specifications and requirements in the country
of use. Failure to do so could result in a fire or electric shock, possibly
resulting in serious injury.

■ The supplied power cord conforms to safety rules and regulations in

the region the product is bought and should not be used outside this
region. For use in other regions, please buy power cords that conform
to safety rules and regulations in the particular region.

■ Do not use a 3-pin to 2-pin conversion plug.

■ When you connect the AC adaptor to the computer, always follow the

steps in the exact order as described in the User’s Manual. Connecting
the power cable to a live electrical outlet should be the last step
otherwise the adaptor DC output plug could hold an electrical change
and cause an electrical shock or minor bodily injury when touched. As
a general safety precaution, avoid touching any metal parts.

■ Never place an AC adaptor on a wooden surface, furniture, or any

other surface that could be marred by exposure to heat since the AC
adaptor's surface temperature increases during normal use.

■ Always place the PC on a suitable heat-insulating material to prevent

possible heat damage.

1. Connect the power cord to the AC adaptor.

Figure 3-2 Connecting the power cord to the AC adaptor (2-pin plug)

User’s Manual 3-7

Getting Started

Figure 3-3 Connecting the power cord to the AC adaptor (3-pin plug)

The Universal AC Adaptor and power cord bundled with this product may
differ depending on the product model. Depending on the model, a 2-pin
plug or 3-pin plug set of the above may be bundled.

2. Connect the AC adaptor’s DC output plug to the DC IN 15V jack on the
back of the computer.

DC IN 15V jack

AC adaptor's DC
output plug

Figure 3-4 Connecting the adaptor to the computer

3. Plug the power cord into a live wall outlet. The Battery and DC IN
indicators on the front of the computer should glow.

Opening the display

The computer’s LCD display panel can be opened in a wide range of
angles for optimal viewing.

1. Slide the display latch on the front of the computer to unlatch the
display panel.

3-8 User’s Manual

2. While holding down the palm rest with one hand so that the main body

is not raised, lift the panel slowly. Adjust the angle of the panel to
provide optimal clarity.

Use reasonable care when opening and closing the LCD display panel.
Opening it vigorously or slamming it shut could damage the computer.

LCD display panel

Figure 3-5 Opening the LCD display panel

Turning on the power

This section describes how to turn on the power.
The Power button LED indicates the status. Refer to the Power indicators

section in Chapter 6, Power and Power-Up Modes.

Getting Started

Display latch

■ After you turn on the power for the first time, do not turn it off until you

have set up the operating system. Refer to the section Starting up for

the first time.

■ If the USB floppy disk drive is connected, make sure it is empty. If a

floppy disk is in the drive, press the eject button and remove the floppy
disk.

1. Open the computer’s LCD display panel.

2. Press and hold the computer’s power button for two or three seconds.

Power button

Figure 3-6 Turning on the power

User’s Manual 3-9

Getting Started

Starting up for the first time

When you first turn on the power, the computer’s initial screen is the
Microsoft Windows XP Startup Screen Logo. Follow the on-screen
directions for each screen. During setup, you can click the Back button to
return to the previous screen.

Be sure to read the Windows End User License Agreement display
carefully.

Turning off the power

The power can be turned off in one of the following modes: Shut down
(Boot), Hibernation or Standby Mode.

Shut Down mode (Boot mode)

When you turn off the power in Shut Down mode no data is saved and the
computer will boot to the operating system’s main screen.

1. If you have entered data, save it to the hard disk or to a storage media.

2. Make sure all disk (disc) activity has stopped, then remove the CD/
DVDs or floppy disk.

■ Make sure the HDD and Slim Select Bay’s module indicators are off. If

you turn off the power while a disk (disc) is being accessed, you can
lose data or damage the disk (disc).

■ Never turn off the power while an application is running. Doing so could

cause loss of data.

■ Never turn off the power, disconnect an external storage device or

remove storage media during data read/write. Doing so can cause data
loss.

3. Click start then click Turn Off Computer. From the Turn Off
Computer menu select Turn Off.

4. Turn off the power to any peripheral devices.

Do not turn the computer or devices back on immediately. Wait a moment
to let all capacitors fully discharge.

Standby Mode

If you have to interrupt your work, you can turn off the power without exiting
from your software. Data is maintained in the computer’s main memory.
When you turn on the power again, you can continue working right where
you left off.

3-10 User’s Manual

Getting Started

■ When the AC adaptor is connected, the computer will go into Standby

Mode according to the settings in the TOSHIBA Power Saver utility.

■ To restore operation from Standby Mode, press the power button or

press any key. The latter action only works on the internal keyboard if
the Wake-up on Keyboard option is enabled in HW Setup.

■ If the computer automatically enters Standby Mode while a network

application is active, the application might not be restored when the
computer wakes up from Standby.

■ To prevent the computer from automatically entering Standby Mode,

disable Standby in TOSHIBA Power Saver. That action, however, will
nullify the computer’s Energy Star compliance.

■ Before entering Standby Mode, be sure to save your data.

■ Do not install or remove a memory module while the computer is in

Standby Mode. The computer or the module could be damaged.

■ Do not remove the battery pack while the computer is in Standby Mode

(unless the computer is connected to an AC power source). Data in
memory will be lost.

■ If you carry the computer on board an aircraft or into a hospital, be sure

to shut down the computer in Hibernation Mode or in shutdown mode
to avoid radio signal interference.

Benefits of standby

The standby feature provides the following benefits:

■ Restores the previous working environment more rapidly than does

hibernation.

■ Saves power by shutting down the system when the computer receives

no input or hardware access for the duration set by the System Standby
feature.

■ You can use the panel power off feature.

Executing standby

You can also enable Standby by pressing Fn + F3. See Chapter 5, The

Keyboard, for details.

You can enter Standby Mode in one of three ways:

1. Click start, click Turn Off Computer and click Stand By.

2. Close the computer’s LCD display panel. This feature must be enabled.

Refer to the Setup Actions tab in TOSHIBA Power Saver Utility
described in the Control Panel.
Open Performance and Maintenance and open TOSHIBA Power

Saver.

User’s Manual 3-11

Getting Started

3. Press the power button. This feature must be enabled. Refer to the

When you turn the power back on, you can continue where you left when
you shut down the computer.

■ When the computer is shut down in Standby Mode, the power indicator

■ If you are operating the computer on battery power, you can lengthen

Standby limitations

Standby will not function under the following conditions:

■ Power is turned back on immediately after shutting down.

■ Memory circuits are exposed to static electricity or electrical noise.

Hibernation Mode

The Hibernation Mode feature saves the contents of memory to the hard
disk when the computer is turned off. The next time the computer is turned
on, the previous state is restored. The Hibernation Mode feature does not
save the status of any peripheral devices.

Setup Actions tab in TOSHIBA Power Saver Utility described in the
Control Panel.
Open Performance and Maintenance and open TOSHIBA Power

Saver.

blinking orange.

the operating time by shutting down in Hibernation Mode. Standby
Mode consumes more power.

■ Save your data. While entering Hibernation Mode, the computer saves

the contents of memory to the hard disk drive. However, for safety
sake, it is best to save your data manually.

■ Data will be lost if you remove the battery or disconnect the AC adaptor

before the save is completed. Wait for the HDD indicator to go out.

■ Do not install or remove a memory module while the computer is in

Hibernation Mode. Data will be lost.

3-12 User’s Manual

Getting Started

Benefits of Hibernation Mode

The Hibernation Mode feature provides the following benefits:

■ Saves data to the hard disk when the computer automatically shuts

down because of a low battery.

For the computer to shut down in Hibernation Mode, this feature must be
enabled in two places: the Hibernate tab in Power Options and Setup
Actions tab in TOSHIBA Power Saver.

If you do not configure this feature, the computer will shut down in Standby
Mode - if battery power becomes depleted, data saved in Standby Mode
will be lost.

■ You can return to your previous working environment immediately when

you turn on the computer.

■ Saves power by shutting down the system when the computer receives

no input or hardware access for the duration set by the System
hibernate feature.

■ You can use the panel power off feature.

Starting Hibernation Mode

You can also enable Hibernation Mode by pressing Fn + F4. Refer to
Chapter 5, The Keyboard, for details.

To enter Hibernation Mode, follow the steps below.

1. Click start.

2. Select Turn Off Computer.

3. Open the Turn Off Computer dialog box.

4. Click Hibernate.

Automatic Hibernation

The computer will enter Hibernate mode automatically when you press the
power button or close the lid. First, however, make the appropriate settings
according to the steps below.

1. Click start and open the Control Panel.

2. Open Performance and Maintenance and open Power Options.

3. Select the Hibernate window in the Power Options Properties,

select the Enable hibernation check box and click the Apply button.

4. Open TOSHIBA Power Saver.

5. Select the Setup Action window.

6. Enable the desired Hibernation settings for When I press the power

button and When I close the lid.

7. Click the OK button.

User’s Manual 3-13

Getting Started

Data save in Hibernation Mode

When you turn off the power in Hibernation Mode, the computer takes a
moment to save current memory data to the hard disk. During this time, the
HDD indicator will light.

After you turn off the computer, and the content of memory has been saved
to the hard disk, turn off the power to any peripheral devices.

Do not turn the computer or devices back on immediately. Wait a moment
to let all capacitors fully discharge.

Restarting the computer

Certain conditions require that you reset the system. For example, if:

■ You change certain computer settings.

■ An error occurs and the computer does not respond to your keyboard

commands.

■ There are three ways to reset the computer system:

1. Click start then click Turn off computer. From the Turn off
computer menu select Restart.

2. Press Ctrl + Alt + Del to display the Windows Task Manager, then
select Shut Down and Restart.

3. Press the power button and hold it down for five seconds. Wait 10 to 15
seconds, then turn the power on again by pressing the power button.

Create Optical Recovery Discs

A recovery image of your computer is stored on the hard disk. You may use
this image to create CD or DVD recovery discs using the following steps:

1. Select either blank CDs or DVD media.

2. The application will allow you to choose a type of media to create
recovery CDs/DVD including: CD-R, CD-RW, DVD-R, DVD-R DL,
DVD-RW, DVD+R, DVD+R DL and DVD+RW.

Some media may not be compatible with the optical disk drive of your
computer. Please verify your optical disk drive supports the blank media
you choose.

3. Turn on your computer without a PC card storage device such as HDD
to open Windows XP.

4. Insert the (first) blank media into the tray of the optical disk drive.

5. Double click the Recovery Disc Creator Launcher icon on the Windows
XP desktop, or select the application from start Menu.

6. After Recovery Disc Creator starts, select the type of media and the title
you wish to copy to the media then click the Burn button.

3-14 User’s Manual

If your optical disk drive can only write to CDs, select "CD" as the "Type"
on Recovery Disc Creator. If your optical disk drive of your computer can
write to either CD or DVDs, select the one you are using as the "Type" on
Recovery Disc Creator.

Restoring the preinstalled software from the Recovery HDD

About 2.5GB of hard disk space is reserved for recovery partition.
When re-setting up your hard disk, do not change, delete or add partitions

in a manner other than specified in the manual. Otherwise, space for
software may be destroyed.

In addition, if you use a third-party partitioning program to reconfigure
partitions on your hard disk, it may become impossible to re-setup your
computer.

When sound mute is turned ON by the Fn + Esc key, turn OFF before
starting restore. Refer to Chapter 5, The Keyboard, for details.

1. Turn off your computer.

2. While holding down 0 (zero) key on the keyboard, turn on your

computer.

3. A Menu appears, follow the on-screen instructions

Getting Started

Restoring the preinstalled software from your creating Recovery Media

If preinstalled files are damaged, you can either use the Recovery Media
you have created or the hard disk drive recovery to restore them. To
restore the operating system and all preinstalled software, follow the steps
below.

When sound mute is turned ON by the Fn + Esc key, turn OFF before
starting restore. Refer to Chapter 5, The Keyboard, for details.

When you reinstall the Windows operating system, the hard disk will be
reformatted and all data will be lost.

1. Load the Recovery Media in the optional optical disk drive and turn off

the computer’s power.

2. Hold down the F12 key and turn on the power. When In Touch with

Tomorrow TOSHIBA appears, release the F12 key.

3. Use the left or right cursor key to select the CD-ROM icon in the display

menu. For details, refer to the Boot Priority section in Chapter 7, HW
Setup.

User’s Manual 3-15

Getting Started

4. A menu appears, follow the on-screen instructions.

3-16 User’s Manual

TECRA M5

Operating Basics

This chapter describes the basic operations of your computer and
precautions when using it, as well as the handling of CD/DVD.

TOSHIBA Dual Pointing Device

The computer is equipped with a dual point system: a Touch Pad and an
AccuPoint pointing stick.

Using the Touch Pad

To use the Touch Pad, simply touch and move your fingertip across it in the
direction you want the on-screen pointer to go.

AccuPoint

Chapter 4

Fingerprint
Sensor

AccuPoint
control buttons

Touch Pad

Figure 4-1 Touch Pad and Touch Pad control buttons

Two buttons below the Touch Pad are used like the buttons on a mouse
pointer. Press the left button to select a menu item or to manipulate text or
graphics designated by the pointer. Press the right button to display a
menu or other function depending on the software you are using.

User’s Manual 4-1

Touch Pad
control buttons

Operating Basics

You can also tap the Touch Pad to perform functions similar to those of the
left button.

Click: Tap once
Double-click: Tap t wi ce
Drag and drop: Tap to select the material you want to move. Leave

your finger on the Touch Pad after the second tap and move the
material.

Using the AccuPoint

To use the AccuPoint, simply push it with your finger tip in the direction you
want to move the on-screen pointer.
Two buttons above the Touch Pad work in the same way with the
AccuPoint as they do with the Touch Pad. Refer to the Using the Touch

Pad section for details.

AccuPoint precautions

Certain conditions can affect the on-screen pointer when using AccuPoint.
For example, the pointer may travel contrary to AccuPoint operation or an
error message may appear, if

■ You touch the AccuPoint during power-up.

■ You apply constant, soft pressure during power-up.

■ There is a sudden temperature change.

■ Strong stress is applied to the AccuPoint.

If an error message appears, reboot the computer. If an error message
does not appear, wait a moment for the pointer to stop, then continue
operation.

Replacing the cap

The AccuPoint cap is an expendable item that should be replaced after
prolonged use. The spare AccuPoint cap is supplied with the computer.

1. To remove the AccuPoint cap, firmly pinch the cap and pull it straight
up.

Figure 4-2 Removing the AccuPoint cap

4-2 User’s Manual

2. Position a new cap on the peg and press it into place.

The peg is square, so be careful to align the cap’s square hole with the
peg.

Using the Fingerprint Sensor

This product has a fingerprint utility installed for the purpose of enrolling
and recognizing fingerprints. By enrolling the ID and password to the
fingerprint authentication device, it is no longer necessary to input the
password from the keyboard. Just by swiping the finger against the
fingerprint sensor, the following functions will be enabled:

■ Logon to Windows and access a security-enabled homepage through

IE (Internet Explorer).

■ Files and folders can be encrypted/decrypted and third party access to

them prevented.

■ Disable the password-protected screen-saver when returning from

power-saving (standby) mode.

■ Power-on Security and Single Sign-on feature.

■ Authentication of the User Password and Hard Disk Drive Password

when booting up the computer.

Fingerprint cannot be used in models that do not have a fingerprint module
installed.

Operating Basics

Points to note about the Fingerprint Sensor

Failure to follow these guidelines might result in (1) damage to the sensor
or cause sensor failure, (2) finger recognition problems, or lower finger
recognition success rate.

■ Do not scratch or poke the sensor with your nails or any hard or sharp

objects.

■ Do not press the sensor strongly.

■ Do not touch the sensor with a wet finger or any wet objects. Keep

sensor surface dry and free of water vapor.

■ Do not touch the sensor with a soiled finger. Minute foreign particles on

a soiled or dirty finger may scratch the sensor.

■ Do not paste stickers or write on the sensor.

■ Do not touch the sensor with a finger or any object with built-up static

electricity.

Observe the following before you place your finger on the sensor whether
for fingerprint enrollment/registration or recognition.

■ Wash and dry your hands thoroughly.

■ Remove static electricity from your fingers by touching any metal

surface. Static electricity is a common cause of sensor failures,
especially when the weather is dry.

User’s Manual 4-3

Operating Basics

■ Clean the sensor with a lint-free cloth. Do not use detergent to clean the

sensor.

■ Avoid the following finger conditions for enrollment or recognition as

they may result in fingerprint enrollment errors or a drop in the
fingerprint recognition success rate

■ Soaked or swollen finger (e.g. after taking bath)

■ Injured finger

■ Wet finger

■ Soiled or oily finger

■ Extremely dry skin condition on finger

Observe the following to improve the fingerprint recognition success rate.

■ Enroll two or more fingers.

■ Enroll additional fingers if recognition failure occurs often using enrolled

fingers.

■ Check your finger condition. Changed conditions, such as injured,

rough, extremely dry, wet, soiled, dirty, oily, soaked, swollen fingers,
may lower the recognition success rate. Also if the fingerprint is worn
down or the finger becomes thinner or fatter, the recognition success
rate may be lowered.

■ The fingerprint for each finger is different and unique. Please ensure

that only the registered or enrolled fingerprint or fingerprints are used
for identification.

■ Check sliding position and speed (see the drawing below).

How to Delete the Fingerprint Data

Saved fingerprint data is stored in the Non-volatile memory inside the
fingerprint sensor. If you hand over the PC to others, or dispose of it, to do
the following operations is recommended.

1. Click start, point to All Programs, point to Protector Suite QL and
click Control Center.

2. The Protector Suite Software screen is displayed.

3. Click Fingerprints and click Delete.

4. Click Settings and click Fingerprint Storage Inspector.

5. The Fingerprint Storage Inspector screen is displayed. If other
fingerprint data is still displayed on the list. Select all fingerprint data
and click remove.

6. Check whether all fingerprint data was deleted on the fingerprint
Storage inspector screen.

4-4 User’s Manual

Operating Basics

Fingerprint Sensor Limitations

■ The fingerprint sensor compares and analyzes the unique

characteristics in a fingerprint.

■ A warning message will be displayed when recognition is abnormal or

recognition is not successful within a fixed duration.

■ The recognition success rate may differ from user to user.

■ Toshiba does not guarantee that this fingerprint recognition technology

will be error-free.

■ Toshiba does not guarantee that the fingerprint sensor will recognize

the enrolled user or accurately screen out unauthorized users at all
times. Toshiba is not liable for any failure or damage that might arise
out of the use of this fingerprint recognition software or utility.

The following illustrations show the correct way to swipe your finger over
the recognition sensor.

Align your fingertip with the sensor as shown in the drawing and Swipe.

Points to note about the Fingerprint Utility

Backups for saved fingerprint data and saved information in the
PasswordBank can be performed in Import or Export User Data under
Fingerprint Software Management. However, encrypted files cannot be
backuped within Mysafe with this function. Recommended is backing up
encrypted files to external media with standard methods such as copying
files.

If Windows XP’s file encryption function EFS (Encryption File System) is
used to encrypt a file, the file cannot be further encrypted using the
encryption function of this software.

If the fingerprint sensor and Trusted Platform Module (TPM) security are
used as identification devices, install and configure the Infineon TPM
Professional package first before configuring the fingerprint utility. Please
refer to the TPM (Trusted Platform Module) Installation Guide for the
installation and configuration methods for TPM.

In the help file, it is stated that this software's PasswordBank function can
be used for the Internet and general applications. However, the Internet
PasswordBank function in the fingerprint utility provided in this computer
can only be used with IE (Internet Explorer).

User’s Manual 4-5

Operating Basics

Set Up Procedure

Please use the following procedure when first using fingerprint
authentication.

Fingerprint Registration

Enroll the required authentication data using the "User Enrollment" Wizard.

■ The fingerprint authentication uses the same Windows logon ID and

■ Up to 21 fingerprint patterns can be registered on this sensor.

1. Click start, point to All Programs, point to Protector Suite QL and

You can also start User Enrollment Wizard using the following method.

■ Click the Protector Suite QL icon in the Task Bar.

■ Swipe your finger across the Fingerprint Sensor.

2. Click Next.

3. The User’s Password screen is displayed. Ensure the same Windows

4. The Hints for Fingerprint Enrollment screen is displayed.

5. The Correct Swipe Procedure screen is displayed.

6. The Scanning Practice screen is displayed.

7. The User’s Fingers screen is displayed. Based on the illustration,

8. The Advanced Security screen is displayed.

9. The Finalization screen is displayed. Click Finish. This completes the

password. If the Windows logon password has not been setup, please
do so before registration.

click User Enrollment Wizard.

logon username is displayed before entering a password into the Enter
your password field. Click Next.

Confirm the message and that there is a checkmark in Run Interactive
Tutor ial, and click Next.

Confirm the message and click Next.

You can practice swiping your finger When you have finished practicing
swiping your finger, click Next.

select the finger to be recognized, and then click Next. Previously
enrolled fingerprints would have green check marks. The fingerprint
being enrolled now would have a red check mark. If any of the
previously enrolled fingerprints is selected again, the latest information
will be enrolled and previous information over-written.

Select whether to enable the security function, and click Next.

fingerprint registration process.

Window Logon via Fingerprint Authentication

In place of the usual Windows logon by ID and password, fingerprint
authentication also allows logon to Windows.

This is useful especially when many users are using the PCs, as user
selection can be skipped.

4-6 User’s Manual

Fingerprint Authentication Procedure

1. Start up the computer.

2. The Logon Authorization screen is displayed. Choose any of the

enrolled fingers and swipe the fingerprint on the sensor.
If authentication is successful, the user will be logged on to Windows.

If the fingerprint authentication fails, please logon using the Windows logon
password.

Please logon using the Windows logon password if the fingerprint
authentication failed for three consecutive tries. To logon using the
Windows logon password, enter the Windows logon password at the
"Welcome" screen as normal.

A warning message will be displayed when authentication is abnormal or
authentication is not successful within a fixed duration.

Fingerprint Power-on Security

General

The fingerprint authentication system can be used to replace the keyboard­based User/BIOS Password authentication system when booting up.

If you do not want to use the fingerprint authentication system for password
authentication when booting up, but prefer to use the keyboard-based
system instead, press the BkSP (backspace) key or the ESC/Rotation
button when the Fingerprint Power-on Security screen is displayed. This
will switch the password input screen to the keyboard-based one.

Operating Basics

■ It is necessary to register the User Password before using the

Fingerprint Power-on Security and its extended function, the
Fingerprint Single Sign-on Feature. Please use TOSHIBA Password
Utility to register the User Password.

■ If you fail fingerprint authentication more than five times, you must

enter the User Password or Supervisor Password manually to start the
computer.

■ When swiping, please do it slowly and at a constant speed. If this does

not improve the authentication rate, please adjust the speed.

■ If there are any changes in the environment or settings related to

authorization, you will be required to provide authorization information
such as a User Password and HDD password.

User’s Manual 4-7

Operating Basics

How to Enable Fingerprint Power-on Security Settings

It is necessary to first enroll your fingerprint with the Protector Suite QL

application prior to enabling and configuring the Fingerprint Power-on
Security System. Check that your fingerprint is enrolled before configuring
the settings. See Manual for Fingerprint Registration/Enrollment
instructions.

1. Swipe your finger across the Fingerprint Sensor.

2. MENU appears in the lower right corner of the screen. Swipe your
finger on the Fingerprint Sensor, and select Control Center from the
MENU items.

3. The Fingerprint Software Management screen is displayed. Click
Settings and click Power-on Security.

4. The Power-on Security screen is displayed. Place a checkmark in
Replace the power-on and hard drive passwords with the fingerprint
reader and click OK.

Fingerprint Single Sign-on Feature

General

This is a feature that allows the user to complete the authentication for both
the User/BIOS Password (and optionally HDD password) and logging on to
Windows using only one fingerprint authentication when booting up. It is
necessary to register the User/BIOS Password and Windows Logon
password before using the Fingerprint Power-on Security and this
Fingerprint Single Sign-on Feature. Please use TOSHIBA Password Utility
to register your User/BIOS Password. If Windows Logon is not the default
for your system, see Manual to register your Windows Logon password.

Only one fingerprint authentication is required to replace the User/BIOS
Password (and, if selected, HDD password) and Windows Logon
password.

How to Enable Fingerprint Single Sign-on Feature

It is necessary to first enroll your fingerprint with the Protector Suite QL
application prior to enabling and configuring the How to Enable Fingerprint
Single Sign-on Feature. Check that the fingerprint is enrolled before
configuring the settings. See Manual for Fingerprint Registration/
Enrollment instructions.

1. Swipe your finger across the Fingerprint Sensor.

2. MENU appears in the lower right corner of the screen. Swipe your
finger on the Fingerprint Sensor, and select Control Center from the
MENU items.

3. The Fingerprint Software Management screen is displayed. Click
Settings and click System Settings.

4. The Protector Suite Settings screen is displayed. Place a checkmark
in Allow power-on security single sign-on within Enable logon support
and click OK.

4-8 User’s Manual

Fingerprint utility limitations

TOSHIBA does not guarantee that the Fingerprint utility technology will be
completely secure or error-free. TOSHIBA does not guarantee that the
Fingerprint utility will accurately screen out unauthorized users at all times.
TOSHIBA is not liable for any failure or damage that might arise out of the
use of the fingerprint software or utility.

How to Swipe the Finger

Using the following steps when swiping fingers for fingerprint registration or
authentication will help to minimize authentication failures:

1. Align the first joint of the finger to the center of the sensor. Lightly touch

the sensor and swipe finger levelly towards you.
While lightly touching the sensor, swipe the finger towards you until the
sensor surface becomes visible.
Ensure the center of the fingerprint is on the sensor when swiping the
finger.

■ Avoid swiping with the finger stiff or pressed-on too hard

Fingerprint reading may fail if the center of the fingerprint is not
touching on the sensor, or when finger is swiped while pressing hard.
Make sure that the center of the fingerprint is touching the sensor
before swiping.

■ Confirm the center of the fingerprint whirl before swiping

Always confirm the center of the fingerprint whirl so that it is swiped
along the center line of the sensor.

■ When fingerprint reading is not successful

There is a possibility of authentication failures if the finger is swiped too
quickly or too slowly. Follow the onscreen instructions to adjust the
speed of the swipe.

Operating Basics

User’s Manual 4-9

Operating Basics

Using the USB floppy disk drive

The USB floppy disk drive accommodates 1.44-megabyte or 720-kilobyte
floppy disks and connects to the USB port. Refer to Chapter 2, The Grand

Tou r, for more information. It is supplied as standard with some models and

as an option with others.

Connecting USB floppy disk drive

To connect the drive, plug the floppy disk drive’s USB connector into a
computer’s USB port. Refer to Figure 4-3.

Make sure the connector is right side up and properly aligned with the
socket. Do not try to force the connection, doing so can damage the
connecting pins.

USB connector

USB port

Figure 4-3 Connecting the USB floppy disk drive

If you connect the USB floppy disk drive after turning on the computer, it
will take about 10 seconds for the computer to recognize the drive. Do not
disconnect and reconnect before 10 seconds has elapsed.

Disconnecting USB floppy disk drive

When you have finished using the USB floppy disk drive, follow the
procedures below to disconnect it:

1. Wait for the indicator light to go out to make sure all floppy disk activity
has stopped.

If you disconnect the USB floppy disk drive or turn off the power while the
computer is accessing the drive you may lose data or damage the floppy
disk or the drive.

2. Click the Safely Remove Hardware icon on the Task Bar.

3. Click USB floppy disk drive device that you want remove.

4. Pull the floppy disk drive’s USB connector out of the computer’s USB
port.

4-10 User’s Manual

Changing Slim Select Bay modules

This section explains how to change modules in the Slim Select Bay. The
illustrations show replacement of the optical disk drive with the Slim Select
Bay HDD adaptor. Therefore, the text refers to those modules. However,
the procedures are the same for any of the modules: CD-ROM, DVD-ROM,
DVD-ROM&CD-R/RW drive, DVD Super Multi drive, HDD adaptor and 2nd
battery pack.

To avoid injury, do not put your hand into the Slim Select Bay slot.

The TOSHIBA Mobile Extension is preinstalled to support hot swapping
under Windows. Refer to Chapter 1, Introduction for information on using
this utility to change modules while the computer’s power is on.

Removing a module

Remove the optical disk drive as described below.

1. You can confirm that the disks are not operating with indicators. If all

indicators are off, it means that no disks are operating currently.

2. Turn the computer upside down.

Wait for all disk indicators to go out before you turn over the computer and
do not lay the computer down gently. Shock can damage the HDD or other
components.

Operating Basics

3. Remove the screw near the icon securing the Slim Select Bay.

4. Make sure the screw in the Slim Select Bay lock screw is set in the hole

for the unlock position.

5. Slide the Slim Select Bay latch to the unlock position.

6. Grasp the optical disk drive and slide it out.

Lock screw

Slim Select Bay
latch

Optical disk drive

Figure 4-4 Removing the optical disk drive

User’s Manual 4-11

Operating Basics

The optical disk drive and other Slim Select Bay modules can become hot
with use. Be careful when removing the module.

Inserting a module

Insert the Slim Select Bay HDD adaptor as described below.

1. Insert the Slim Select Bay HDD adaptor in the computer as shown

2. If you want to lock the Slim Select Bay HDD adaptor, set the Slim Select

below and press until the ejector clicks.

Bay lock screw in the hole for the lock position (➁). The lock screw is
inserted in the unlock position (➀) at the time of purchasing.

Lock screw

Slim Select Bay HDD
adaptor

Figure 4-5 Inserting the Slim Select Bay HDD adaptor

Using optical disk drives

The text and illustrations in this section refer primarily to the optical disk
drive. However, operation is the same for other optical drive in the Slim
Select Bay. The full-size drive provides high-performance execution of CD/
DVD-ROM-based programs. You can run either 12 cm (4.72") or 8 cm
(3.15") CD/DVDs without an adaptor. An ATAPI interface controller is used
for CD/DVD-ROM operation. When the computer is accessing a CD/DVD­ROM, an indicator on the drive glows and the Slim Select Bay indicator
glows.

Use the WinDVD application to view DVD-Video discs.

If you have a DVD-ROM&CD-R/RW drive, refer also to the Writing CDs on

DVD-ROM&CD-R/RW drive section for precautions on writing to CDs.

If you have a DVD Super Multi drive, refer also to the Writing CD/DVDs on

DVD Super Multi drive section for precautions on writing to CDs/DVDs.

4-12 User’s Manual

When the power of the optical disk drive is off, pressing the Fn + Ta b keys
will turn the power of the optical disk drive on. Furthermore, it is possible to
set it to turn the power of the optical disk drive on and eject the tray at the
same time.

Loading discs

To load CD/DVDs, follow the steps below and refer to figures 4-6 to 4-9.

1. When the computer’s power is on, press the eject button to open

the disc tray slightly.

Figure 4-6 Pressing the eject button

2. Grasp the disc tray gently and pull until it is fully opened.

Operating Basics

Eject button

Disc tray

Figure 4-7 Pulling the disc tray open

User’s Manual 4-13

Operating Basics

3. Lay the CD/DVD, label side up, in the disc tray.

Laser lens

Figure 4-8 Inserting a CD/DVD

When the disc tray is fully opened, the edge of the computer will extend
slightly over the CD/DVD tray. Therefore, you will need to turn the CD/DVD
at an angle when you place it in the disc tray. After seating the CD/DVD,
however, make sure it lies flat, as shown in figure 4-8.

■ Do not touch a laser lens and its circumference portion. Doing so could

cause misalignment.

■ Prevent foreign objects from entering the drive. Check the surface of

the disc tray, especially the area behind the front edge of the disc tray,
to make sure there are no such objects before closing the drive.

4. Press gently at the center of the CD/DVD until you feel it click into
place. The CD/DVD should lie below the top of the spindle, flush with
the spindle base.

4-14 User’s Manual

5. Push the center of the disc tray to close it. Press gently until it locks into

place.

If the CD/DVD is not seated properly when the disc tray is closed, the CD/
DVD might be damaged. Also, the disc tray might not open fully when you
press the eject button.

Figure 4-9 Closing the CD/DVD disc tray

Removing discs

To remove the CD/DVD, follow the steps below and refer to figure 4-10.

Do not press the eject button while the computer is accessing the media
drive. Wait for the Slim Select Bay indicator to go out before you open the
disc tray. Also, if the CD/DVD is spinning when you open the disc tray, wait
for it to stop before you remove it

.

Operating Basics

1. To pop the disc tray partially open, press the eject button. Gently pull

the disc tray out until it is fully opened.

When the disc tray pops open slightly, wait a moment to make sure the
CD/DVD has stopped spinning before pulling the disc tray fully open.

2. The CD/DVD extends slightly over the sides of the disc tray so you can

hold it. Hold the CD/DVD gently and lift it out.

Figure 4-10 Removing a CD/DVD

User’s Manual 4-15

Operating Basics

3. Push the center of the disc tray to close it. Press gently until it locks into
place.

How to remove CD/DVD when the disc tray will not open

Pressing the eject button will not open the disc tray when the computer
power is off. If the power is off, you can open the disc tray by inserting a
slender object (about 15 mm) such as a straightened paper clip into the
eject hole just to the right of the eject button.

Eject hole

Figure 4-11 Manual release with the eject hole

Turn off the power before you use the eject hole. If the CD/DVD is spinning
when you open the disc tray, the CD/DVD could fly off the spindle and
cause injury.

15mm

Writing CDs on DVD-ROM&CD-R/RW drive

Depending on the type of drive installed, you may be able to write CDs. The
DVD-ROM&CD-R/RW drive lets you write as well as read CD-ROMs.
Observe the precautions in this section to ensure the best performance for
writing CDs. For information on loading and unloading CDs refer to the

Using optical disk drives section.

■ Refer to the Writable discs, Chapter 2 for the details about the types of

writable CD/DVD discs.

■ Do not turn off the power of the optical disk drive while the computer is

accessing the drive. If you turn off the power, you may lose data.

■ When the power of the optical disk drive is off, the disc tray will not

open even if the eject button is pushed. Use the optical disk drive
power icon to turn the power of the optical disk drive on. Refer to
Chapter 1, Special features.

4-16 User’s Manual

When writing to media using an optical drive, always connect the AC
adaptor to a power plug socket. If data is written while powered by the
batteries, writing may sometimes fail due to low battery power and data
loss may occur.

Before writing or rewriting

Please observe the following points when you write or rewrite the data.

■ We recommend the following manufacturers of CD-R and CD-RW

media. Media quality can affect write or rewrite success rates.

CD-R:

TAIYO YUDEN CO., LTD.
MITSUBISHI CHEMICAL CORPORATION
RICOH Co., Ltd.

Multi-Speed and High-Speed CD-RW:

MITSUBISHI CHEMICAL CORPORATION
RICOH Co., Ltd.

Ultra-Speed CD-RW:

MITSUBISHI CHEMICAL CORPORATION

TOSHIBA has confirmed the operation of CD-R and CD-RW media of the
manufacturers above. Operation of other media cannot be guaranteed.

■ The actual number of rewrites to CD-RW is affected by the quality of the

disc and the way it is used.

■ Be sure to connect the AC adaptor when you write or rewrite.

■ Be sure to close all other software programs except the writing

software.

■ Do not run software such as a screen saver which can put a heavy load

on the CPU.

■ Operate the computer at full power. Do not use power-saving features.

■ Do not write while virus check software is running. Wait for it to finish,

then disable virus detection programs including any software that
checks files automatically in the background.

■ Do not use hard disk utilities, including those intended to enhance hard

disk drive access speeds. They may cause unstable operation and
damage data.

■ Write from the computer's hard disk drive to the CD. Do not try to write

from shared devices such as a LAN server or any other network device.

■ Writing with software other than Sonic RecordNow! has not been

confirmed. Therefore, operation with other software cannot be
guaranteed.

Operating Basics

User’s Manual 4-17

Operating Basics

When writing or rewriting

Note the following when you write or rewrite a CD-R or CD-RW.

■ Always copy data from the hard disk drive to the optical media. Do not

use cut-and-paste as the original data will be lost if there is a write error.

■ Do not perform any of the following actions:

■ Change users in the Windows XP operating system.

■ Operate the computer for any other function, including use of a

mouse or Touch Pad, closing/opening the LCD panel.

■ Start a communication application such as a modem.

■ Apply impact or vibration to the computer.

■ Install, remove or connect external devices, including the following:

PC card, SD card, ExpressCard, USB devices, external monitor,
i.LINK devices, optical digital devices.

■ Open the optical disk drive.

■ Remove the optical disk drive from the Slim Select Bay.

■ Make sure writing or rewriting is completed before going into standby/

hibernation. Writing is completed if you can open the CDs on DVD­ROM&CD-R/RW drive tray.

■ If the media is poor in quality, dirty or damaged, writing or rewriting

errors may occur.

■ Set the computer on a level surface and avoid places subject to

vibration such as airplanes, trains or cars. Do not use an unstable
surface such as a stand.

■ Keep mobile phones and other wireless communication devices away

from the computer.

Writing CD/DVDs on DVD Super Multi drive

You can use the DVD Super Multi drive to write data to either CD-R/RW or
DVD-R/-R DL/-RW/+R/+R DL/+RW/-RAM discs. The following applications
for writing are provided: RecordNow!, and DLA licensed by Sonic
Solutions, and InterVideo’s WinDVD Creator Platinum.

■ Refer to the Writable discs, Chapter 2 for the details about the types of

writable CD/DVD discs.

■ Do not turn off the power of the optical disk drive while the computer is

accessing the drive. If you turn off the power, you may lose data.

■ When the power of the optical disk drive is off, the disc tray will not

open even if the eject button is pushed. Use the optical disk drive
power icon to turn the power of the optical disk drive on. Refer to
Chapter 1, Special features.

4-18 User’s Manual
