Satellite® M30/M35 Series User’s Guide

If you need assistance:

❖ Toshiba Global Support Centre

Calling within the United States (800) 457-7777 Calling from outside the United States (949) 859-4273

For more information, see “If Something Goes Wrong” on

page 161 in this guide.

Handling the cord on this product will expose you to lead, a chemical known to the State of California to cause birth defects or other reproductive harm. Wash hands after handling.

C6659-0304M2

03/04

Page 2

Models: Satellite M30/M35 Series

ReWritable CD/DVD Drives

The computer system you purchased may include a ReWritable CD and/or DVD drive(s), among the most advanced data storage technologies available. As with any new technology, you must read and follow all set-up and usage instructions in the applicable user guides and/or manuals enclosed. If you fail to do so, this product may not function properly and you may lose data or suffer other damage. TOSHIBA AMERICA INFORMATION SYSTEMS (“TOSHIBA”), ITS AFFILIATES AND SUPPLIERS DO NOT WARRANT THAT OPERATION OF THE PRODUCT WILL BE UNINTERRUPTED OR ERROR FREE. YOU AGREE THAT TOSHIBA, ITS AFFILIATES AND SUPPLIERS SHALL HAVE NO RESPONSIBILITY FOR DAMAGE TO OR LOSS OF ANY BUSINESS, PROFITS, PROGRAMS, DATA OR REMOVABLE STORAGE MEDIA ARISING OUT OF OR RESULTING FROM THE USE OF THE PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY THEREOF.

Protection of Stored Data

For your important data, please make periodic back-up copies of all the data stored on the hard disk or other storage devices as a precaution against possible failures, alteration, or loss of the data. IF YOUR DATA IS ALTERED OR LOST DUE TO ANY TROUBLE, FAILURE OR MALFUNCTION OF THE HARD DISK DRIVE OR OTHER STORAGE DEVICES AND THE DATA CANNOT BE RECOVERED, TOSHIBA SHALL NOT BE LIABLE FOR ANY DAMAGE OR LOSS OF DATA, OR ANY OTHER DAMAGE RESULTING THEREFROM. WHEN COPYING OR TRANSFERRING YOUR DATA, PLEASE BE SURE TO CONFIRM WHETHER THE DATA HAS BEEN SUCCESSFULLY COPIED OR TRANSFERRED. TOSHIBA DISCLAIMS ANY LIABILITY FOR THE FAILURE TO COPY OR TRANSFER THE DATA CORRECTLY.

Critical Applications

The computer you have purchased is not designed for any “critical applications.” “Critical applications” means life support systems, medical applications, connections to implanted medical devices, commercial transportation, nuclear facilities or systems or any other applications where product failure could lead to injury to persons or loss of life or catastrophic property damage. ACCORDINGLY, TOSHIBA, ITS AFFILIATES AND SUPPLIERS DISCLAIM ANY AND ALL LIABILITY ARISING OUT OF THE USE OF THE COMPUTER PRODUCTS IN ANY CRITICAL APPLICATIONS. IF YOU USE THE COMPUTER PRODUCTS IN A CRITICAL APPLICATION,

Page 3

YOU, AND NOT TOSHIBA, ASSUME FULL RESPONSIBILITY FOR SUCH USE.

FCC Notice “Declaration of Conformity Information”

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

❖ Reorient or relocate the receiving antenna.

❖ Increase the separation between the equipment and receiver.

❖ Connect the equipment to an outlet on a circuit different from that to which

the receiver is connected.

❖ Consult the dealer or an experienced radio/TV technician for help.

NOTE

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

Only Peripherals complying with the FCC Class B limits may be attached to this equipment. Operation with noncompliant peripherals or peripherals not recommended by Toshiba is likely to result in interference to radio and TV reception. Shielded cables must be used between the external devices and the computer's parallel port, monitor port, USB port, PS/2 port jack. Changes or modifications made to this equipment not expressly approved by Toshiba or parties authorized by Toshiba could void the user's authority to operate the equipment.

, i.LINK® port and microphone

❖ This device may not cause harmful interference.

❖ This device must accept any interference received, including interference

that may cause undesired operation.

Page 4

Contact:

Toshiba America Information Systems, Inc.

9740 Irvine Blvd.

Irvine, CA 92618-1697

(949) 583-3000

Industry Canada requirement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conformé à la norme NMB-003 du Canada.

FCC requirements

The following information is pursuant to FCC CFR 47, Part 68 and refers to internal modems.

This equipment complies with Part 68 of the FCC rules. On the bottom of this equipment is a label that contains, among other information, the FCC registration number and ringer equivalence number (REN) for this equipment. If requested, the information must be provided to the telephone company.

The modem connects to the telephone line by means of a standard jack called the USOC RJ11C.

A plug and jack used to connect this equipment to the premises wiring and telephone network must comply with the applicable FCC part 68 rules and requirements adopted by the ACTA. A compliant telephone cord and modular plug is provided with this product. It is designed to be connected to a compatible modular jack that is also compliant.

The REN is used to determine the number of devices that may be connected to a telephone line. Excessive RENs on a telephone line may result in the devices not ringing in response to an incoming call. In most but not all areas, the sum of RENs should not exceed five (5.0). To be certain of the number of devices that may be connected to a line, as determined by the total RENs, contact the local telephone company. For products approved after July 23, 2001, the REN for this product is part of the product identifier that has the format US:AAAEQ##TXXXX. The digits represented by the ## are the REN without a decimal point (e.g., 03 is a REN of 0.3). For earlier products, the REN is separately shown on the label.

Connection to party line service is subject to state tariffs. Contact the state public utility commission, public service commission or corporation commission for information.

Page 5

Telephone Company Procedures

The goal of the telephone company is to provide you with the best service it can. In order to do this, it may occasionally be necessary for them to make changes in their equipment, operations or procedures. If these changes might affect your service or the operation of your equipment, the telephone company will give you notice, in writing, to allow you to make any changes necessary to maintain uninterrupted service.

If Problems Arise

If this equipment causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required. But if advanced notice is not practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it is necessary.

If trouble is experienced with this equipment, for repair or limited warranty information, please contact Toshiba Corporation, Toshiba America Information Systems, Inc. or an authorized representative of Toshiba, or the Toshiba Support Centre within the United States at (800) 457-7777 or Outside the United States at (949) 859-4273. If the equipment is causing harm to the telephone network, the telephone company may request that you disconnect the equipment until the problem is resolved.

Disconnection

If you should ever decide to permanently disconnect your modem from its present line, please call the telephone company and let them know of this change.

Fax Branding

The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to use a computer or other electronic device, including Fax machines, to send any message unless such message clearly contains in a margin at the top or bottom of each transmitted page or on the first page of the transmission, the date and time it is sent and an identification of the business or other entity, or other individual sending the message and the telephone number of the sending machine or such business, other entity, or individual. (The telephone number provided may not be a 900 number or any other number for which charges exceed local or long-distance transmission charges.)

In order to program this information into your fax transmission, refer to the fax software instructions installed on this computer.

Page 6

Alarm Equipment

If your home has specially wired alarm equipment connected to the telephone line, ensure the installation of this equipment does not disable your alarm equipment. If you have questions about what will disable alarm equipment, consult your telephone company or a qualified installer.

Instructions for IC CS-03 Certified Equipment

1 NOTICE: The Industry Canada label identifies certified equipment.

This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements document(s). The Department does not guarantee the equipment will operate to the user’s satisfaction.

Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equipment must also be installed using an acceptable method of connection. The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations.

Repairs to certified equipment should be coordinated by a representative designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications company cause to request the user to disconnect the equipment.

Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines and internal metallic water pipe system, if present, are connected together. This precaution may be particularly important in rural areas.

Caution: Users should not attempt to make such connections themselves, but should contact the appropriate electric inspection authority, or electrician, as appropriate.

2 The user manual of analog equipment must contain the equipment’s

Ringer Equivalence Number (REN) and an explanation notice similar to the following:

The Ringer Equivalence Number (REN) of this device can be found on the label affixed to your computer.

NOTICE: The Ringer Equivalence Number (REN) assigned to each terminal device provides an indication of the maximum number of terminals allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the Ringer Equivalence Numbers of all the devices does not exceed 5.

Page 7

3 The standard connecting arrangement (telephone jack type) for this

equipment is jack type(s): USOC RJ11C.

Wireless Interoperability

The TOSHIBA Wireless LAN Mini PCI Card products are designed to be interoperable with any wireless LAN product that is based on Direct Sequence Spread Spectrum (DSSS) radio technology, and is compliant to:

❖ The IEEE 802.11 Standard on Wireless LANs (Revision A/B), as

defined and approved by the Institute of Electrical and Electronics Engineers.

❖ The Wireless Fidelity (Wi-Fi) certification as defined by the WECA

Wireless Ethernet Compatibility Alliance.

If you should experience any such problem, immediately turn off either one of your Bluetooth™ or Wireless LAN.

Please contact Toshiba PC product support on Web site http://www.toshibaeurope.com/computers/tnt/bluetooth.htm in Europe or http://www.pcsupport.global.toshiba.com in the United States for more information.

This device is restricted to indoor use due to its operation in the 5.15 GHz to

5.85 GHz frequency range.

Wireless LAN and your Health

Wireless LAN products, like other radio devices, emit radio frequency electromagnetic energy. The level of energy emitted by Wireless LAN devices however is far much less than the electromagnetic energy emitted by wireless devices like for example mobile phones.

Because Wireless LAN products operate within the guidelines found in radio frequency safety standards and recommendations, TOSHIBA believes Wireless LAN is safe for use by consumers. These standards and recommendations reflect the consensus of the scientific community and result from deliberations of panels and committees of scientists who continually review and interpret the extensive research literature.

Page 8

In some situations or environments, the use of Wireless LAN may be restricted by the proprietor of the building or responsible representatives of the organization. These situations may for example include:

❖ Using the Wireless LAN equipment on board of airplanes, or

❖ In any other environment where the risk of interference to other

devices or services is perceived or identified as harmful.

If you are uncertain of the policy that applies on the use of wireless devices in a specific organization or environment (e.g. airports), you are encouraged to ask for authorization to use the Wireless LAN device prior to turning on the equipment.

Regulatory Information

The TOSHIBA Wireless LAN Mini PCI Card must be installed and used in strict accordance with the manufacturer’s instructions as described in the user documentation that comes with the product. This device complies with the following radio frequency and safety standards.

Canada – Industry Canada (IC)

This device complies with RSS 210 of Industry Canada.

The installer of this radio equipment must ensure that the antenna is located or pointed such that it does not emit RF field in excess of Health Canada limits for the general population; consult Safety Code 6, obtainable from Health Canada’s Web site www.hc-sc.gc.ca/rpb. The RF device shall not be co-located with any other transmitter that has not been tested with this device.

Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device.

L’utilisation de ce dispositif est autorisée seulement aux conditions suivantes: (1) il ne doit pas produire de brouillage et (2) l’utilisateur du dispositif doit étre prêt à accepter tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de compromettre le fonctionnement du dispositif.

The term “IC” before the equipment certification number only signifies that the Industry Canada technical specifications were met.

To prevent radio interference to the licensed service, this device is intended to be operated indoors and away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to licensing.

Pour empecher que cet appareil cause du brouillage au service faisant l'objet d'une licence, il doit etre utilize a l'interieur et devrait etre place loin

Page 9

des fenetres afin de Fournier un ecram de blindage maximal. Si le matriel (ou son antenne d'emission) est installe a l'exterieur, il doit faire l'objet d'une licence.

Europe – EU Declaration of Conformity

❖ This device complies with the essential requirements of the R&TTE

Directive 1999/5/EC with essential test suites as per standards:

EN 60950 Safety of Information Technology equipment

ETS 300 328 Technical requirements for radio equipment

ETS 300 826 General EMC requirements for radio equipment.

België/ Belgique:

Deutschland: License required for outdoor installations. Check with reseller for pro-

For outdoor usage only channel 10 (2457 MHz) and 11 (2462 MHz) is allowed.

For private usage outside buildings across public grounds over less than 300m no special registration with IBPT/BIPT is required. Registration to IBPT/BIPT is required for private usage outside buildings across public grounds over more than 300m. An IBPT/BIPT license is required for public usage outside building. For registration and license please contact IBPT/BIPT.

Gebruik buiten gebouw alleen op kanalen 10 (2457 MHz) en 11 (2462 MHz). Voor privé-gebruik buiten gebouw over publieke groud over afstand kleiner dan 300m geen registratie bij BIPT/IBPT nodig; voor gebruik over afstand groter dan 300m is wel registratie bij BIPT/IBPT nodig. Voor publiek gebruik buiten gebouwen is licentie van BIPT/ IBPT verplicht. Voor registratie of licentie kunt u contact opnemen met BIPT.

L’utilisation en extérieur est autorisé sur le canal 10 (2457 MHz) et 11 (2462 MHz). Dans le cas d’une utilisation privée, a l’extérieur d’un bâtiment, audessus d’un espace public, aucun enregistrement n’est nécessaire pour une distance de moins de 300m. Pour une distance supérieure à 300m un enregistrement auprés de I’IBPT est requise. Pour une utilisation publique à I’extérieur de bâtiments, une licence de I’IBPT est requise. Pour les enregistrements et licences, veuillez contacter I’IBPT.

cedure to follow.

Page 10

Anmeldung im Outdoor-Bereich notwendig, aber nicht genehmigungspflichtig. Bitte mit Händler die Vorgehensweise abstimmen.

France: Restricted frequency band: only channels 10 and 11 (2457 MHz and

2462 MHz respectively) may be used in France. License required for every installation, indoor and outdoor installations. Please contact ART for procedure to follow.

Bande de fréquence restreinte: seuls les canaux 10 à 11 (2457 MHz et 2462 MHz respectivement) doivent être utilisés en France. Toute utilisation, qu’elle soit intérieure ou extérieure, est soumise à autorisation. Vous pouvez contacter I’Autorité de Régulation des Télécommuniations (http://www.art-telecom.fr) pour la procédure à suivre.

Italia: License required for indoor use. Use with outdoor installations not

allowed.

E’necessaria la concessione ministeriale anche per l’uso interno. Verificare con i rivenditori la procedura da seguire. L’uso per installazione in esterni non e’ permessa.

Nederland: License required for outdoor installations. Check with reseller for pro-

cedure to follow.

Licentie verplicht voor gebruik met buitenantennes. Neem contact op met verkoper voor juiste procedure.

USA – Federal Communications Commission (FCC)

This device complies with Part 15 of FCC Rules. Operation of the devices in a Wireless LAN System is subject to the following two conditions:

❖ This device may not cause harmful interference.

❖ This device must accept any interference that may cause undesired

operation.

TOSHIBA is not responsible for any radio or television interference caused by unauthorized modification of the devices included with this TOSHIBA Wireless LAN Mini PCI Card, or the substitution or attachment of connecting cables and equipment other than specified by TOSHIBA.

The correction of interference caused by such unauthorized modification, substitution or attachment will be the responsibility of the user.

Page 11

Caution: Exposure to Radio Frequency Radiation

The Toshiba Wireless LAN Mini PCI Card will be installed with one of two types of antennas. The both of antenna types, when installed are located at the upper edge of the LCD screen.

For both antennas, the radiated output power of the TOSHIBA Wireless LAN Mini PCI Card is far below the FCC radio frequency exposure limits. Nevertheless, the TOSHIBA Wireless LAN Mini PCI Card shall be used in such a manner that the potential for human contact during normal operation is minimized. In normal operating configuration, the LCD in the upright position, the distance between the antenna and the user should not be less than 20 cm. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Antenna(s) used in 5.15 GHz to 5.25 GHz frequency band must be integral antenna which provide no access to the end user.

Refer to the Regulatory Statements as identified in the documentation that comes with those products for additional information.

Caution: Radio Frequency Interference Requirements

This device is restricted to indoor use due to its operation in the 5.15 GHz to 5.25 GHz frequency range. FCC requires this product to be used indoors for frequency range 5.15 GHz to 5.25 GHz to reduce the potential for harmful interference to co-channel Mobile Satellite systems.

High power radars are allocated as primary users of the 5.25 GHz to 5.35 GHz and 5.65 GHz to 5.85 GHz bands. These radar stations can cause interference with and/or damage this device.

NOTE

The above Caution information applies to products that operate with an

802.11a device.

Taiwa n

Article 14 Unless approved, for any model accredited low power radio frequency

electric machinery, any company, trader or user shall not change the frequency, increase the power or change the features and functions of the original design.

Page 12

Article 17 Any use of low power radio frequency electric machinery shall not

affect the aviation safety and interfere with legal communications. In event that any interference is found, the use of such electric machinery shall be stopped immediately, and reusing of such products can be resumed until no interference occurs after improvement.

The legal communications mentioned in the above item refer to radio communications operated in accordance with telecommunication laws and regulations.

Low power radio frequency electric machinery shall resist against interference from legal communications or from industrial, scientific and medical radio emission electric machinery.

Using this Equipment in Japan

In Japan, the frequency bandwidth of 2,400 MHz to 2,483.5 MHz for second generation low-power data communication systems such as this equipment overlaps that of mobile object identification systems (premises radio station and specified low-power radio station).

1. Sticker

Please put the following sticker on devices incorporating this product.

2. Indication

The indication shown below appears on this equipment.

1 2.4: This equipment uses a frequency of 2.4 GHz.

2 DS: This equipment uses DS-SS modulation.

3 The interference range of this equipment is less than 40m.

4 This equipment uses a frequency bandwidth from 2,400 MHz to

2,483.5 MHz.

Page 13

It is possible to avoid the band of mobile object identification systems.

3. TOSHIBA Direct PC

Monday – Friday: 10:00 – 17:00

Toll Free Tel: 0120-13-1100

Direct Dial: 03-3457-5916

Fax: 03-5444-9450

Device Authorization

This device obtains the Technical Regulation Conformity Certification and the Technical Conditions Compliance Approval, and it belongs to the device class of radio equipment of low-power data communication system radio station stipulated in the Radio Law and the Telecommunications Business Law of Japan.

The Name of the radio equipment: MPC13A-20/R

JAPAN APPROVALS INSTITUTE FOR TELECOMMUNICATIONS EQUIPMENT

Approval Number: D01-1128JP

TELECOM ENGINEERING CENTER Approval Number: 03NY.A0018, 03GZDA0017

The following restrictions apply:

❖ Do not disassemble or modify the device.

❖ Do not install the embedded wireless module into other device.

Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures:

❖ Reorient or relocate the receiving antenna.

❖ Increase the distance between the equipment and the receiver.

Page 14

❖ Connect the equipment to an outlet on a circuit different from that to

which the receiver is connected.

❖ Consult the dealer or an experienced radio/TV technician for help.

Toshiba is not responsible for any radio or television interference caused by unauthorized modification of the devices included with this Toshiba Wireless LAN Mini PCI Card, or the substitution or attachment of connecting cables and equipment other than specified by Toshiba.

The correction of interference caused by such unauthorized modification, substitution or attachment will be the responsibility of the user.

NOTE

The following information is dependent on what type of wireless device is in your computer.

Approved Countries/Regions for use for the Atheros AR5001X Mini PCI Wireless network adapter

This equipment is approved to the radio standard by the countries/regions in the following table.

Do not use this equipment except in the countries/regions in the following table.

NOTE

802.11b (2.4 GHz)

This device works on passive scan only.

A peer-to-peer mode is not available in 802.11a and Turbo Mode.

Australia Austria Belgium

Canada Denmark Finland

France Germany Greece

Ireland Italy Liechtenstein

Luxembourg Netherlands New Zealand

Norway Portugal Sweden

Switzerland UK USA

Page 15

802.11a (5 GHz)

Australia Austria Belgium

Canada Denmark Finland

France Germany Greece

Ireland Italy Liechtenstein

Luxembourg Netherlands New Zealand

Norway Portugal Sweden

Switzerland UK USA

Turbo Mode (5 GHz)

Canada USA

Approved Countries/Regions for use for the Intel® PRO/ Wireless LAN 2100 3B Mini PCI Adapter

This equipment is approved to the radio standard by the countries/regions in the following table.

Do not use this equipment except in the countries/regions in the following table.

Argentina Australia Austria

Belgium Brazil Canada

Chile Denmark Finland

France Germany Greece

Iceland Ireland Italy

Japan Liechtenstein Luxembourg

Mexico Netherlands New Zealand

Norway Peru Portugal

Singapore Spain Sweden

Switzerland UK Uruguay

USA Venezuela

Page 16

Approved Countries/Regions for use for the Toshiba Mini PCI Wireless LAN Card

This equipment is approved to the radio standard by the countries/regions in the following table.

Do not use this equipment except in the countries/regions in the following table.

Australia Austria Belgium

Canada Denmark Finland

France Germany Greece

Hong Kong Iceland Ireland

Italy Japan Liechtenstein

Luxembourg Malaysia Netherlands

New Zealand Norway Philippines

Portugal Singapore Spain

Sweden Switzerland Thailand

UK USA

Bluetooth wireless technology Interoperability

Bluetooth™ Cards from TOSHIBA are designed to be interoperable with any product with Bluetooth wireless technology that is based on Frequency Hopping Spread Spectrum (FHSS) radio technology, and is compliant to:

❖ Bluetooth Specification Ver. 1.1, as defined and approved by The

Bluetooth Special Interest Group.

❖ Logo certification with Bluetooth wireless technology as defined by

The Bluetooth Special interest Group.

Page 17

Bluetooth wireless technology is a new innovative technology, and TOSHIBA has not confirmed compatibility of its Bluetooth™ products with all PCs and/ or equipment using Bluetooth wireless technology other than TOSHIBA portable computers.

Always use Bluetooth™ cards from TOSHIBA in order to enable wireless networks over two or more (up to a total of seven) TOSHIBA portable computers using these cards. Please contact TOSHIBA PC product support on Web site http://www.toshiba-europe.com/computers/tnt/bluetooth.htm in Europe or http://www.pcsupport.global.toshiba.com in the United States for more information.

When you use Bluetooth™ cards from TOSHIBA close to 2.4 GHz Wireless LAN devices, Bluetooth transmissions might slow down or cause errors. If you detect certain interference while you use Bluetooth™ cards from TOSHIBA, always change the frequency, move your PC to the area outside of the interference range of 2.4 GHz Wireless LAN devices (40 meters/43.74 yards or more) or stop transmitting from your PC. Please contact TOSHIBA PC product support on Web site http://www.toshiba-europe.com/computers/ tnt/bluetooth.htm in Europe or http://www.pcsupport.global.toshiba.com in the United States for more information.

Bluetooth™ and Wireless LAN devices operate within the same radio frequency range and may interfere with one another. If you use Bluetooth™ and Wireless LAN devices simultaneously, you may occasionally experience a less than optimal network performance or even lose your network connection. If you should experience any such problem, immediately turn off either one of your Bluetooth™ or Wireless LAN. Please contact Toshiba PC product support on Web site http:// www.toshiba-europe.com/computers/tnt/bluetooth.htm in Europe or http:// www.pcsupport.global.toshiba.com in the United States for more information.

Bluetooth wireless technology and your Health

The products with Bluetooth wireless technology, like other radio devices, emit radio frequency electromagnetic energy. The level of energy emitted by devices with Bluetooth wireless technology however is far much less than the electromagnetic energy emitted by wireless devices like for example mobile phones.

Because products with Bluetooth wireless technology operate within the guidelines found in radio frequency safety standards and recommendations, TOSHIBA believes Bluetooth wireless technology is safe for use by consumers. These standards and recommendations reflect the consensus of the scientific community and result from deliberations of panels and committees of scientists who continually review and interpret the extensive research literature.

Page 18

In some situations or environments, the use of Bluetooth wireless technology may be restricted by the proprietor of the building or responsible representatives of the organization. These situations may for example include:

❖ Using the equipment with Bluetooth wireless technology on board of

airplanes, or

❖ In any other environment where the risk of interference to other

devices or services is perceived or identified as harmful.

If you are uncertain of the policy that applies on the use of wireless devices in a specific organization or environment (e.g. airports), you are encouraged to ask for authorization to use the device with Bluetooth wireless technology prior to turning on the equipment.

Regulatory statements

This product complies with any mandatory product specification in any country/region where the product is sold. In addition, the product complies with the following:

European Union (EU) and EFTA

This equipment complies with the R&TTE directive 1999/5/EC and has been provided with the CE mark accordingly.

Canada-Industry Canada (IC)

This device complies with RSS 210 of Industry Canada.

L’utilisation de ce dispositif est autorisée seulement aux conditions suivantes: (1) il ne doit pas produire de brouillage et (2) l’utilisateur du dispositif doit étre prét à accepter tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de compromettre le fonctionnement du dispositif.

The term “IC” before the equipment certification number only signifies that the Industry Canada technical specifications were met.

Caution: FCC Interference Statement

This device complies with part15 of the FCC rules. Operation is subject to the following two conditions:

❖ This device may not cause harmful interference, and

Page 19

❖ This device must accept any interference received, including

interference that may cause undesired operation.

Note that any changes or modifications to this equipment not expressly approved by the manufacturer may void the authorization to operate this equipment.

Caution: Exposure to Radio Frequency Radiation

The radiated output power of the Bluetooth™ Card from TOSHIBA is far below the FCC radio frequency exposure limits. Nevertheless, the Bluetooth™ Card from TOSHIBA shall be used in such a manner that the potential for human contact during normal operation is minimized.

In order to comply with FCC radio-frequency radiation exposure guidelines for an uncontrolled environment, the Bluetooth™ Card from TOSHIBA has to be operated while maintaining a minimum body to antenna which are located on top of LCD distance of 20 cm.

Refer to the Regulatory Statements as identified in the documentation that comes with those products for additional information.

The Bluetooth™ Card from TOSHIBA is far below the FCC radio frequency exposure limits.

Nevertheless, it is advised to use the Bluetooth™ Card from TOSHIBA in such a manner that human contact during normal operation is minimized.

NOTE

Changes or modifications made to this equipment not expressly approved by TOSHIBA or parties authorized by TOSHIBA could void the user’s authority to operate the equipment.

Taiwa n

Article 14 Unless approved, for any model accredited low power radio frequency

electric machinery, any company, trader or user shall not change the frequency, increase the power or change the features and functions of the original design.

Article 17 Any use of low power radio frequency electric machinery shall not

Page 20

The legal communications mentioned in the above item refer to radio communications operated in accordance with telecommunication laws and regulations.

Low power radio frequency electric machinery shall resist against interference from legal communications or from industrial, scientific and medical radio emission electric machinery.

Using this equipment in Japan

1. Sticker

Please put the following sticker on devices incorporating this product.

2. Indication

The indication shown below appears on this equipment.

(1) (2) (3)

2.4FH1

(4)

1 2.4: This equipment uses a frequency of 2.4 GHz.

2 FH: This equipment uses FH-SS modulation.

3 The interference range of this equipment is less than 10m.

4 This equipment uses a frequency bandwidth from 2,400 MHz to

2,483.5 MHz. It is impossible to avoid the band of mobile object identification systems.

Page 21

3. TOSHIBA Direct PC

Monday – Friday: 10:00 – 17:00

Toll Free Tel: 0120-13-1100

Direct Dial: 03-3457-5916

Fax: 03-5444-9450

Device Authorization

This device obtains the Technical Regulation Conformity Certification, and it belongs to the device class of radio equipment of low-power data communication system radio station stipulated in the Radio Law of Japan.

The Name of the radio equipment: EYXF2CS

TELECOM ENGINEERING CENTER

Approval Number: 01NYDA1305

The following restrictions apply:

❖ Do not disassemble or modify the device.

❖ Do not install the embedded wireless module into other device.

DVD-ROM, multi-function drive safety instructions

The DVD-ROM and multi-function drives employ a laser system. To ensure proper use of this product, please read this instruction manual carefully and retain for future reference. Should the unit ever require maintenance, contact an authorized service location.

Use of controls, adjustments or the performance of procedures other than those specified may result in hazardous radiation exposure.

To prevent direct exposure to the laser beam, do not try to open the enclosure.

Page 22

Location of the required label

(Sample shown below. Location of the label and manufacturing information may vary.)

This appliance contains a laser system and is classified as a “CLASS 1 LASER PRODUCT.” To use this model properly, read the user’s guide carefully and keep it for your future reference. In case of any trouble with this model, please contact your nearest “AUTHORIZED service station.” To prevent direct exposure to the laser beam, do not try to open the enclosure.

Use of controls or adjustments or performance of procedures other than those specified in the owner’s manual may result in hazardous radiation exposure.

This guide is copyrighted by Toshiba America Information Systems, Inc. with all rights reserved. Under the copyright laws, this guide cannot be reproduced in any form without the prior written permission of Toshiba. No patent liability is assumed, however, with respect to the use of the information contained herein.

Export Administration Regulation

This document contains technical data that may be controlled under the U.S. Export Administration Regulations, and may be subject to the approval of the U.S. Department of Commerce prior to export. Any export, directly or indirectly, in contravention of the U.S. Export Administration Regulations is prohibited.

Page 23

Notice

The information contained in this manual, including but not limited to any product specifications, is subject to change without notice.

TOSHIBA CORPORATION AND TOSHIBA AMERICA INFORMATION SYSTEMS, INC. (TOSHIBA) PROVIDES NO WARRANTY WITH REGARD TO THIS MANUAL OR ANY OTHER INFORMATION CONTAINED HEREIN AND HEREBY EXPRESSLY DISCLAIMS ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE WITH REGARD TO ANY OF THE FOREGOING. TOSHIBA ASSUMES NO LIABILITY FOR ANY DAMAGES INCURRED DIRECTLY OR INDIRECTLY FROM ANY TECHNICAL OR TYPOGRAPHICAL ERRORS OR OMISSIONS CONTAINED HEREIN OR FOR DISCREPANCIES BETWEEN THE PRODUCT AND THE MANUAL. IN NO EVENT SHALL TOSHIBA BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, SPECIAL, OR EXEMPLARY DAMAGES, WHETHER BASED ON TORT, CONTRACT OR OTHERWISE, ARISING OUT OF OR IN CONNECTION WITH THIS MANUAL OR ANY OTHER INFORMATION CONTAINED HEREIN OR THE USE THEREOF.

Trademarks

Satellite and Noteworthy are registered trademarks, SelectServ, FreedomWare, and SmartMedia are trademarks, of Toshiba America Information Systems, Inc. and/or Toshiba Corporation.

Microsoft, Windows, DirectX, Active Desktop, and DirectShow are registered trademarks, and Windows Media is a trademark of Microsoft Corporation.

LapLink is a registered trademark of Traveling Software, Inc.

ConfigFree is a trademark of Toshiba Corporation.

Wi-Fi

Dolby - Manufactured by Toshiba under license from Dolby Laboratories/ Dolby and the double-D symbol are trademarks of Dolby Laboratories.

TouchPad is a trademark of Synaptics, Inc.

All other brand and product names are trademarks or registered trademarks of their respective companies.

is a registered trademark of the Wireless Capability Ethernet Alliance.

Page 24

Computer disposal information

This product contains mercury. Disposal of this material may be regulated due to environmental considerations. For disposal, reuse or recycling information, please contact your local government or the Electronic Industries Alliance at

www.eiae.org.

Page 25

Introduction ..............................................................33

This guide ..............................................................34

Safety icons ...........................................................34

Other icons used ..............................................35

Other documentation .............................................35

Service options ......................................................36

Chapter 1: Getting Started .........................................37

Selecting a place to work .......................................37

Creating a computer-friendly environment .......37

Keeping yourself comfortable ..........................38

Other precautions .................................................41

Setting up your computer ......................................42

Adding memory .....................................................46

Installing a memory module ............................47

Removing a memory module ...........................50

Turning on the computer .......................................52

Opening the display panel ................................52

Turning on the power ......................................52

Using the TouchPad™ ............................................53

Page 26

Contents

Scrolling with the TouchPad™ .........................54

Control buttons ................................................54

Disabling or enabling the TouchPad ................55

Setting up your software ........................................56

Registering your computer with Toshiba ...............57

Setting up other devices ..................................57

Turning off the computer .......................................57

Closing the display panel .................................58

Using external display devices ...............................58

Connecting the display device ..........................59

Directing the display output when you

turn on the computer .................................61

Adjusting the quality of the external display .....62

Using an external keyboard ....................................63

Using a mouse .......................................................63

Connecting a local printer .....................................63

Connecting an optional external diskette drive .......65

Connecting external speakers or headphones ........66

Connecting a microphone ......................................66

Chapter 2: Learning the Basics ................................. 67

Computing tips ......................................................67

Using the keyboard ................................................69

Character keys ................................................69

Making your keyboard emulate a full-size

keyboard ....................................................69

Ctrl, Fn, and Alt keys ........................................70

Function keys ...................................................70

Windows special keys ......................................71

Overlay keys .................................................... 71

Using the overlay to type numeric data ............72

Starting a program .................................................73

Starting a program from the Start menu ..........73

Starting a program from Windows® Explorer ..74

Page 27

Contents

Starting a program from the Run dialog box ...75

Saving your work ...................................................76

Printing your work .................................................78

Using the DVD-ROM or multi-function drive ..........79

CD/DVD control buttons ..................................81

Inserting compact discs ..................................82

Removing compact discs ................................84

Caring for CDs or DVDs Discs ........................85

Using PC Cards ......................................................86

Hot swapping ...................................................86

Using SD® (Secure Digital) cards ..........................87

Using your computer at the office ..........................87

Using a computer lock ...........................................88

Caring for your computer .......................................89

Cleaning the computer .....................................89

Moving the computer .......................................89

Backing up your work ............................................90

Restoring your work ........................................90

Preparing for communications ..............................91

Powering down the computer ................................91

Using Turn Off Computer or Shut Down ..........92

Using Hibernation ............................................94

Using Standby .................................................96

Toshiba’s online resources ....................................98

Chapter 3: Mobile Computing ...................................99

Toshiba’s energy-saver design............................... 99

Running the computer on battery power .............100

Battery Notice ................................................100

Charging the battery ......................................100

Maximizing battery life ...................................101

Charging the RTC battery ...............................102

Monitoring battery power ..............................103

What to do when the battery alarm sounds .........106

Page 28

Contents

Changing batteries ...............................................107

Disposing of used batteries ...........................109

Conserving power ................................................109

Power profiles in Windows XP .......................110

Using a hot key to set the power profile .........111

Additional options for power ................................111

Chapter 4: Expansion Options ................................. 112

Devices for office computing ...............................112

Connecting external (optional) devices ..........113

Using an external keyboard ..................................113

Using a mouse ....................................................113

Connecting a USB mouse ..............................113

Using a printer ....................................................113

Connecting a parallel printer ..........................114

Setting up your printer ...................................115

Using the Wi-Fi™ Wireless LAN Mini PCI module 118

Chapter 5: Enhancing Productivity .......................... 119

Exploring the desktop ..........................................119

Finding your way around the desktop ............119

Exchanging data with another computer ..............122

Transferring files ............................................122

Getting help transferring files .........................123

Setting up for communications ......................123

Connecting the modem to a telephone line ....124

Connecting your computer to a network .......125

An overview of using the Internet ........................127

The Internet ...................................................127

The World Wide Web ....................................127

Internet Service Providers ..............................128

Connecting to the Internet ............................128

Surfing the Internet ........................................129

Internet features .............................................129

Page 29

Contents

Uploading and downloading files from

the Internet .............................................130

Exploring audio features ......................................130

Playing an audio CD .......................................130

Playing CDs using Auto-Run ..........................132

Creating a CD .................................................132

Recording sounds ..........................................132

Using external speakers or headphones .........135

Inserting and removing hard drives .....................136

Inserting and removing PC Cards ........................138

Inserting a PC Card ........................................138

Removing a PC Card ......................................139

Inserting and removing Wi-Fi™ modules .......140

Setting up a PC Card for your computer ........140

Using SD® cards ..................................................140

Inserting an SD® card ....................................140

Removing an SD® card ..................................141

Using the i.LINK® port .........................................142

Connecting your modem to a telephone line ........142

Connecting to a phone line ............................143

Chapter 6: Toshiba Utilities .....................................145

Fn-esse® ..............................................................146

Starting Fn-esse

Using the keyboard or pointing device to

assign keys ..............................................148

Viewing existing key assignments .................149

Changing or removing existing key

assignments ...........................................150

TOSHIBA Console ................................................150

Customizing Your Computer ..........................151

Network .........................................................151

Security ..........................................................151

Power Management .......................................151

...........................................146

Page 30

Contents

Mouse utility ...............................................153

Hotkey utility ...............................................154

Toshiba Hardware Settings ............................154

Enabling Hibernation ............................................156

Setting user passwords .......................................156

Using an instant password .............................157

Setting a user password ................................157

Disabling a user password .............................158

Using a supervisor password ...............................159

Setting a supervisor password .......................159

Deleting a supervisor password .....................160

Chapter 7: If Something Goes Wrong ..................... 161

Problems that are easy to fix ...............................161

Problems when you turn on the computer ...........163

The Windows® operating system is not working .164

Using Startup options to fix problems ...........165

Internet problems ..........................................166

The Windows® XP operating system can

help you ...................................................166

Resolving a hardware conflict ..............................167

A plan of action ..............................................167

Resolving hardware conflicts on your own ....168

Fixing a problem with Device Manager ..........169

Memory problems .........................................171

Power and the batteries .................................171

Keyboard problems ........................................173

Display problems ...........................................173

Disk drive problems .......................................175

DVD-ROM or multi-function drive problems ..178

Sound system problems ................................178

PC Card problems ..........................................179

Printer problems ............................................182

Modem problems ...........................................183

Page 31

Contents

Develop good computing habits ..........................183

If you need further assistance ..............................185

Before you call ...............................................185

Contacting Toshiba ........................................186

Other Toshiba Internet Web sites ........................187

Toshiba’s worldwide offices .................................187

Appendix A: Hot Keys .............................................. 191

Volume Mute .......................................................191

Instant password security ....................................192

Power usage profile ......................................192

Stand By mode ....................................................193

Hibernation mode ...............................................194

Display modes .....................................................195

Display brightness ...............................................195

Disabling or enabling the TouchPad ....................196

Keyboard hot keys ..............................................196

Appendix B: Power Cable Connectors .....................197

Appendix C: Using ConfigFree™ with your

Toshiba Computer ...............................198

Getting Started .....................................................199

ConfigFree Main Screen .................................199

Starting ConfigFree ........................................200

Configuring ConfigFree ..................................200

ConfigFree Utilities ...............................................201

Connectivity Doctor .......................................201

Device Settings ..............................................202

Profile Settings ..............................................204

Quick Connect ................................................205

Using Auto Switch ...............................................206

Auto Switch (Cable Disconnect) .....................207

Auto Switch (SSID) ........................................207

Page 32

Contents

Glossary ................................................................. 208

Index ....................................................................... 223

Page 33

Introduction

Welcome to the world of powerful, portable multimedia computing. With your Toshiba notebook computer, your work can accompany you wherever you go.

Satellite computing power, enabling you to perform the most demanding computing tasks from any location.

You will find your operating system, Microsoft XP Home or Windows your computer. Your operating system offers exciting features and easy Internet access.

M30/M35 Series computers provide considerable

XP Professional, already installed on

Windows®

NOTE

While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications, configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your computer, or to stay current with the various computer software or hardware options, visit Toshiba's Web site at pcsupport.toshiba.com.

Page 34

Introduction

This guide

This guide introduces the computer’s features. You can:

❖ Read the entire guide from beginning to end

❖ Skim through and stop when a topic interests you

❖ Use the table of contents and the index to find specific

information

Safety icons

This manual contains safety instructions that must be observed in order to avoid potential hazards that could result in personal injuries, damage to your equipment, or loss of data. These safety cautions have been classified according to the seriousness of the risk, and the icons highlight these instructions as follows:

Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.

Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.

Indicates a potentially hazardous situation which, if not avoided, may result in property damage.

Page 35

Introduction

Service options

❖ The Microsoft

documentation which explains the features of the operating system.

Service options

Toshiba offers a full line of service options built around its SelectServ information, visit Toshiba’s Web site at toshiba.com.

If you have a problem or need to contact Toshiba, see “If

Something Goes Wrong” on page 161.

™

limited warranty programs. For more

Windows® operating system

Page 37

Chapter 1

Getting Started

This chapter provides tips for working comfortably, describes how to connect components, and explains what to do the first time you use your computer.

Selecting a place to work

Your computer is designed to be used in a variety of locations and situations. This section provides guidelines for setting up your computing environment.

Creating a computer-friendly environment

Place the computer on a flat surface that is large enough for the computer and any other items you need to use, such as a printer. Leave enough space around the computer and other equipment to give adequate ventilation, otherwise, they may overheat.

To keep your computer in prime operating condition, protect your work area from:

❖ Dust, moisture and direct sunlight

❖ Liquids and corrosive chemicals

Page 38

Getting Started

Selecting a place to work

If you spill liquid into the computer, turn it off, unplug it from the AC power source and let it dry out completely before turning it on again.

If the computer does not operate properly after you turn it back on, contact a Toshiba service representative or your network administrator.

❖ Equipment that generates a strong electromagnetic field,

such as large stereo speakers (other than speakers that are connected to the computer) or speakerphones.

❖ Rapid changes in temperature or humidity and sources of

temperature change such as air conditioner vents or heaters.

❖ Extreme heat, cold, or humidity. Operate the computer

within a temperature range of 41 degrees to 95 degrees Fahrenheit (5 degrees to 35 degrees Celsius) and 20 percent to 80 percent non-condensing humidity.

Keeping yourself comfortable

Strain and stress injuries are becoming more common as people spend more time using their computers. However, with a little care and the proper use of the equipment, you can work comfortably throughout the day.

Using the computer keyboard incorrectly can result in discomfort and possible injury. If your hands, wrists, and/or arms hurt while typing, stop using the computer and rest. If the discomfort persists, consult a physician.

This section provides hints on avoiding strain and stress injuries. For more information, consult books on ergonomics, repetitive-strain injury, and repetitive-stress syndrome.

Page 39

Getting Started

Selecting a place to work

Placement of the computer

Proper placement of the computer and external devices is important to avoid stress-related injuries. Consider the following when placing your computer.

❖ Place the computer on a flat surface at a comfortable

height and distance. You should be able to type without twisting your torso or neck and look at the screen without slouching.

❖ If you use an external monitor, the top of the screen

should be no higher than eye level.

❖ If you use a paper holder, set it at the same height and

distance as the screen.

Seating and posture

When using your computer, maintain good posture with your body relaxed and your weight distributed evenly. Proper seating is a primary factor in reducing work strain. Some people find a backless chair more comfortable than a conventional chair. Whichever type you choose, use the following guidelines to adjust your chair for maximum computing comfort.

Below eye level

Footrest

Correct posture and positioning of the computer

Approximately 90° angles

Page 40

Getting Started

Selecting a place to work

❖ Position your chair so that the keyboard is at or slightly

lower than the level of your elbow. You should be able to type comfortably with your shoulders relaxed and your forearms parallel to the floor.

If you are using a conventional chair:

❖ Your knees should be slightly higher than your hips. If

necessary, use a footrest to raise the level of your knees and ease the pressure on the back of your thighs.

❖ Adjust the back of your chair so that it supports the lower

curve of your spine. If necessary, use a cushion to provide extra back support. Lower-back-support cushions are available at many office supply stores.

❖ Sit with your back straight so that your knees, hips, and

elbows form approximately 90-degree angles when you work. Do not slump forward or lean back too far.

Lighting

Proper lighting can improve the readability of the display and reduce eyestrain.

❖ Position the display panel or external monitor so that

sunlight or bright indoor lighting does not reflect off the screen. Use tinted windows or shades to reduce glare.

❖ Avoid placing your computer in front of a bright light that

shines directly into your eyes.

❖ If possible, use soft, indirect lighting in your computer

work area.

Arms and wrists

❖ Avoid bending, arching, or twisting your wrists. Keep

them in a relaxed, neutral position while typing.

❖ Exercise your hands, wrists and arms to improve

circulation.

Page 41

Work habits

The key to avoiding discomfort or injury from strain is to vary your activities. If possible, schedule a variety of tasks into your working day. Finding ways to break up the routine can reduce stress and improve your efficiency.

❖ Take frequent, short breaks to change position, stretch

your muscles, and relieve your eyes. A break of two or three minutes every half hour is more effective than a long break after several hours.

❖ Avoid performing repetitive activities for long periods.

Intersperse such activities with other tasks.

❖ Focusing your eyes on your computer screen for long

periods can cause eyestrain. Look away from the computer frequently and focus your eyes on a distant object for at least 30 seconds.

Other precautions

Getting Started

Other precautions

Your computer is designed to optimize safety, minimize strain, and withstand the rigors of portability. However, you should observe certain precautions to further reduce the risk of personal injury or damage to the computer.

Do not apply heavy pressure to the computer or subject it to sharp impacts. Excessive pressure or impact can damage computer components or cause your computer to malfunction.

Page 42

Getting Started

Setting up your computer

Some PC Cards can become hot with prolonged use. If two cards are installed, both can become hot even if only one is used extensively. Overheating of a PC Card can result in errors or instability in the PC Card operation.

Be careful when you remove a PC Card that has been used for lengthy periods of time.

Setting up your computer

TECHNICAL NOTE: You must complete all set up steps up to

“Setting up your software” on page 56 before adding external

or internal components to your computer. These components include, but are not limited to, a mouse, keyboard, printer, memory, and PC cards.

Your computer comes with a rechargeable battery pack that must be charged before you can use it.

To use external power or to charge the battery, you must attach the AC adapter. See “Connecting to a power source”

on page 43.

To register your computer online, or to sign up for an Internet account, you must be connected to the Internet using a modem or LAN connection.

Before adding any of these devices to the computer, be sure to complete “Setting up your software” on page 56.

After setting up your computer, you may want to:

❖ Add more memory

❖ Connect a mouse

❖ Connect a full-size keyboard

❖ Connect an external monitor

Page 43

Getting Started

Setting up your computer

❖ Connect a local printer

❖ Install PC Cards

Connecting to a power source

Your computer requires power to operate. Use the power cable and AC adapter to connect the computer to a live electrical outlet, or to charge the computer’s battery.

AC adapter

Power cable

Sample power cable and AC adapter

Handling the cord on this product will expose you to lead, a chemical known to the State of California to cause birth defects or other reproductive harm. Wash hands after handling.

Hold the power cable by its plug when you connect/disconnect it. Do NOT pull the cable itself. Doing so may damage the power cable and result in a short circuit or electric shock.

Page 44

Getting Started

Setting up your computer

Use only the AC adapter supplied with your computer or an equivalent adapter that is compatible. Use of any incompatible adapter could damage your computer. Toshiba assumes no liability for any damage caused by use of an incompatible adapter.

When you connect the AC adapter to the computer, always follow the steps in the exact order as described in the User's Manual. Connecting the power cable to a live electrical outlet should be the last step; otherwise’ the adapter DC output plug could hold an electrical charge and cause an electrical shock or minor bodily injury when touched. As a general safety precaution, avoid touching any metal parts.

To connect AC power to the computer:

1 Connect the power cable to the AC adapter.

Connecting the power cable to the AC adapter

2 Plug the AC adapter into the DC-IN on the back of the

computer.

Page 45

Getting Started

Setting up your computer

Connecting the AC adapter to the computer

3 Connect the power cable to a live electrical outlet.

If the electrical outlet is live, the system indicator panel’s AC power light ( ) glows blue.

If the main battery is present, the battery light glows:

❖ Amber while the battery is charging

❖ Blue when the battery is fully charged

If the battery light flashes amber during charging, either the battery pack is malfunctioning, or it is not receiving input from the AC power supply. Disconnect the AC cable and remove the battery pack. See “If Something Goes Wrong” on

page 161 for troubleshooting information.

Damaged power cables can cause fire or electric shock. Never modify, forcibly bend, place heavy objects on top of, or apply heat to the power cable.

If the power cable becomes damaged or the plug overheats, discontinue use. There is a risk of electric shock.

Never remove the power plug from the outlet with wet hands. Doing so may cause an electric shock.

Page 46

Getting Started

Adding memory

Charging the battery

Your computer came with its battery already installed. Before using the battery to power the computer, you must charge it.

To charge the battery, leave the computer plugged in to an AC power source for at least three hours with the computer turned off. After that, the battery will be completely charged and ready to power the computer.

Once the battery is charged for the first time, avoid leaving the computer plugged in and turned off for more than a few hours at a time. Continuing to charge a fully charged battery can damage the battery.

Adding memory

HINT: To purchase additional memory modules, see the accessories information packaged with your system or visit

toshiba.com.

Your Satellite memory to run most of today’s popular applications. You may want to increase the computer’s memory if you use complex software or process large amounts of data.

For more information on memory options, check the accessories information that came with your computer, or visit

toshiba.com.

M30/M35 Series computer comes with enough

Page 47

Installing a memory module

Additional memory modules can be installed in the memory expansion slots on the base of the computer. You will need a standard Phillips no.1 screwdriver for this procedure.

To avoid damaging the computer’s screws, use a standard Phillips no. 1 screwdriver that is in good condition.

Installing a memory module with the computer’s power on may damage the computer, the module, or both.

The computer has two memory expansion slots — Slot A and Slot B. You can install one or two memory modules.

If the computer is on, begin at step 1; otherwise, skip to step

Getting Started

Adding memory

1 If the computer is on, click Start, Turn off computer.

The Turn off computer window appears.

2 Click Turn O ff .

The operating system turns off the computer.

3 Unplug and remove any cables connected to the

computer.

4 Remove the battery.

5 Close the display panel and turn the computer upside

down to locate the expansion memory slot cover to the memory slot.

Page 48

Getting Started

Adding memory

Memory module cover

Locating the memory slot cover

6 Using a standard Phillips no. 1 screwdriver, unscrew the

screw that secures the memory slot cover, then remove the memory slot cover.

Removing the memory module cover

7 Place the screw and the cover in a safe place so that you

can retrieve them later.

Page 49

Getting Started

Adding memory

Static electricity can damage the memory module. Before you handle the module, touch a grounded metal surface to discharge any static electricity you may have built up.

To avoid damaging the memory module, be careful not to touch its pin connector on the side you insert into the computer.

8 Remove the new memory module from its antistatic

packaging.

9 Holding the memory module by its edges so that the gold

connector bar faces the slot, fit the module into the socket.

10 Gently press down on the memory module connector

until the clips snap into place.

Do not force the module into position. The memory module should be level when secured in place.

Inserting the memory module into the slot

The clips on either side of the module will click to secure the module.

Page 50

Getting Started

Adding memory

Avoid touching the connectors on the memory module or on the computer. Grease or dust on the connectors may cause memory access problems.

11 Replace the cover plate and the screw.

12 Turn the computer over and restart it.

You can now continue setting up the computer. When the operating system has loaded, you can verify that the computer has recognized the additional memory.

If you are adding extra memory after setting up the computer, verify that the computer has recognized it correctly as described in “Checking total memory” on page 51.

Removing a memory module

If you need to remove a memory module:

1 Complete steps 1–6 in “’Installing a memory module’” to

shut down the computer and open the memory module cover.

Do not try to remove a memory module with the computer turned on. You can damage the computer and the device.

Do not remove the memory module while the computer is in Standby mode. The computer could hang up the next time you turn it on and data in memory will be lost. In either of the above cases, the Standby configuration will not be saved.

The following message appears when you turn on the power:

Warning: Resume Failure Press Any Key To Continue

If the computer hangs up when you turn it on, perform the following: Press the power button and hold it down for five seconds, then turn the power on again.

Page 51

Getting Started

Adding memory

2 Pull the clips away from the memory module.

The memory module pops partially out of the slot.

3 Carefully remove the module from the slot.

Removing the memory module

4 Replace the cover plate and screws.

5 Turn the computer over and restart it.

Checking total memory

When you add or remove memory, you can check that the computer has recognized the change. To do this:

1 Click Start, then click Control Panel.

2 Click Performance and Maintenance.

3 Click System.

4 The General tab view automatically appears and shows

total memory.

If the computer does not recognize the memory configuration, turn off the computer, remove the memory slot cover, and make sure the memory module is seated properly, as described in step 10 of “Adding memory” on page 46.

Page 52

Getting Started

Turning on the computer

The computer is now ready for you to turn it on and begin using it.

Opening the display panel

1 Slide the display latch to the right.

2 Lift the display panel.

To avoid damaging the display panel, do not force it beyond the point where it moves easily, and never lift the computer by the display panel.

Small bright dots may appear on your TFT display when you turn on your computer. Your display contains an extremely large number of thin-film transistors (TFT) and is manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT manufacturing technology.

Turning on the power

To turn on the computer:

1 Make sure any external devices (such as the AC adapter, if

you plan to use AC power rather than battery power) are properly connected and ready.

2 Check to ensure that all drives are empty.

3 Press and hold the power button in until the on/off light

on the system indicator panel glows blue—about one second.

Page 53

Getting Started

Using the TouchPad™

Turning on the power

4 The preinstalled operating system will load

automatically.

When you turn on the computer for the first time, do not turn off the power again until the operating system has loaded completely.

Using the TouchPad

The TouchPad, the small, smooth square cutout located in front of the keyboard, is sensitive to touch and enables you to move the cursor with the stroke of a finger. Simply move your finger on the TouchPad in the direction you’d like to move the cursor:

❖ To move the cursor to the top of the page, push your

finger forward on the TouchPad.

❖ To move the cursor to the bottom of the page, drag your

finger toward yourself.

❖ To move the cursor to the right side of the page, slide

your finger across the TouchPad from left to right.

™

Page 54

Getting Started

Using the TouchPad™

❖ To move it to the left side, slide your finger from right to

left.

NOTE

Once you’ve positioned your cursor, you can either click it into place by double-tapping the TouchPad or clicking the control buttons.

Because the TouchPad is much smaller than the display screen, moving your cursor across the screen often means having to move your finger several times across the TouchPad in the preferred direction.

Scrolling with the TouchPad

There are two active regions on the TouchPad that allow you to scroll as you would with any wheel device on a mouse or trackball.

To scroll vertically, run your finger up or down along the right edge of the TouchPad. To scroll horizontally, run your finger along the bottom edge of the TouchPad.

Control buttons

When a step instructs you to click or choose an item, move the cursor to the item, then press and release the primary (left-hand) button. To double-click, press the primary button twice in rapid succession. The primary button usually corresponds to the left mouse button.

™

The function of the secondary (right-hand) button depends on the program you are using. It usually corresponds to the right mouse button. Check your program’s documentation to find whether it uses the right mouse button.

Page 55

Using the TouchPad™

Disabling or enabling the TouchPad

The TouchPad is enabled by default. To change the enable/ disable TouchPad setting:

1 Click Start, Control Panel.

The Control Panel window appears.

2 Click Printers and Other Hardware.

3 Click the Mouse icon.

4 Click the TouchPAD ON/OFF tab.

The TouchPAD ON/OFF tab view window appears.

Getting Started

5 Select Disable or Enable, whichever is appropriate.

6 Click Apply.

7 Click OK.

The Mouse Properties window closes.

8 Close the Printers and Other Hardware window.

9 Close the Control Panel window.

Page 56

Getting Started

Setting up your software

You can also use a hot key to disable or enable the TouchPad. See “Disabling or enabling the TouchPad” on page 196.

Setting up your software

The first time you turn on your computer, the Setup Wizard guides you through steps to set up your software.

1 From the welcome screen, click Next to enter the Setup

Wizard.

2 Confirm acceptance of Microsoft’s End User License

Agreement and click Next.

3 Enter the computer name and description, and click Next

or Skip.

The computer will pause for a moment while checking for an internet connection.

A window will display the message: “An Internet connection could not be chosen.”

4 Click Skip to exit the process or Next to continue.

NOTE

5 Click Ye s to register, or No to exit the process.

NOTE

6 Enter your personal information in the registration

To register online, your computer’s modem must be connected to a voice-grade telephone line.

A window will display asking if you wish to register with Toshiba and Microsoft.

If you click No, you may register with Toshiba by clicking the Register with Toshiba icon on the desktop.

window.

Page 57

Getting Started

Registering your computer with Toshiba

7 Enter your name and click Finish to complete the

process.

Your computer restarts automatically.

Registering your computer with Toshiba

To register your computer with Toshiba at a time later than when you first start your computer, you may also click on the desktop icon to do so electronically.

Setting up other devices

You may want to take this time to set up your printer. For more information, see “Setting up your printer” on page 115.

Turning off the computer

It is a good idea to turn off your computer when you are not using it for a while.

If you are using the computer for the first time, leave the computer plugged into a power source (even though the computer is off) to fully charge the main battery. With the computer off, it may take up to three hours to recharge the main battery.

When you power down the computer, you have three options to choose from: Turn Off (or Shut down), Hibernate, and Standby. Each option has its advantages.

❖ Use the Turn Off command if you are using the Windows

XP Home version operating system, or the Windows XP Professional operating system when not connected to a domain server.

❖ Use the Shut down command if you are using the

Windows connected to a domain server.

❖ If you have work in progress and are not connected to a

network, use the Windows Standby or Hibernate

XP Professional operating system and are

Page 58

Getting Started

Using external display devices

commands to save your system settings to memory so that, when you turn on the computer again, you will automatically return to where you left off.

❖ To leave the computer off for a longer period, you can use

the Windows Turn Off command when not connected to a domain server or the Shut down when connected to a domain server instead.

Never turn off the computer while any drive is in use. Doing so may damage the media in use and result in loss of data. For more information, see “Powering down the computer” on

page 91.

Closing the display panel

When you are finished, shut the computer down and close the display panel to keep dust and dirt out of the computer.

If you close the computer while it is still on, these actions will occur:

❖ If you have the LCD power-saver feature set, the LCD

panel will automatically turn off until you open it again.

❖ If you have the audible warning set, the computer will

beep to notify you that it is still on.

❖ If you have an action feature set, the computer will

perform either: Nothing, Standby, Hibernate, or Turn Off (see “Enabling Hibernation” on page 156).

Using external display devices

Your computer comes with a built-in LCD display, but you can also connect three different types of external display devices to one of two available video ports:

❖ A television via the video-out port.

Page 59

Using external display devices

TECHNICAL NOTE: In the Windows®XP operating system, you do not need an Internet connection to watch cable or broadcast TV, but you must purchase a compatible TV tuner card.

❖ A video display device, such as a video projection unit,

via the video-out port.

❖ An external monitor or projector via the RGB (monitor)

port.

❖ A video display device via the S-Video port.

Before connecting a television, video projector, monitor or other display device, configure your computer for the type of device you’re connecting. To do this, refer to the documentation for your operating system and devices.

Connecting the display device

Getting Started

If you’re connecting a television or other video display device to the computer’s video-out port, first refer to “Selecting

video cables” on page 59 below for guidelines on choosing a

video cable, then refer to ’Connecting to the video-out port’ below.

If you’re connecting an SVGA monitor, skip to “Connecting

an external monitor or projector” on page 61.

Selecting video cables

To connect a device to the S-video port, you’ll need to purchase a cable. For the best video quality, always use a properly shielded cable.

HINT: Toshiba recommends using a cable no longer than 20 feet (approximately 6 meters).

Page 60

Getting Started

Using external display devices

Using a poor quality cable may result in a dull or fuzzy picture, poor color, ghosting, video noise, or loss of video.

Connecting to the video-out port

NOTE

To connect the device:

1 Connect one end of the video cable to the external video

2 Connect the other end of the video cable to the video-out

3 Turn on the external video device.

4 Set the display mode by pressing

Video cables are not included with your computer. To connect a device to the video-out port, you will need to purchase an Svideo cable.

device.

Refer to the documentation provided with the device for the location of its video-in port.

port on the left side of the computer.

Fn + F5, or by setting the

Display Properties settings. For more information, see

“Directing the display output when you turn on the computer” on page 61.

TECHNICAL NOTE: If you are connecting to a television, you may need to change the display properties. Most televisions use or support an 800 x 600 standard resolution.

Page 61

Getting Started

Using external display devices

Connecting an external monitor or projector

You can easily attach an external monitor or projector to your computer if you need a larger screen. To do this:

1 Connect the monitor’s video cable to the RGB (monitor) port

on the back of the computer.

2 Connect the device’s power cable to a live electrical

outlet.

3 Turn on the external device.

4 Set the display mode by pressing

Display Properties settings.

Fn + F5, or by setting the

Directing the display output when you turn on the computer

Once you’ve connected an external display device, you can choose to use the internal display only, the external device only, or both simultaneously. The quickest way to change the display output settings is to use the display hot key (

1 Press

2 While holding down

Fn and F5 simultaneously.

Fn, press F5 repeatedly until the

setting you want takes effect.

This hot key cycles through the settings in the following order:

❖ Built-in display only

❖ Built-in display and external monitor simultaneously

❖ External monitor only

❖ Built-in display and TV (or other external video device)

simultaneously

❖ TV (or other external video device) only

Fn + F5):

3 Release the

Fn key.

Page 62

Getting Started

Using external display devices

TECHNICAL NOTE: You can also change these settings using the Display Properties Box.

Set the option for the video controller by clicking Start, then Control Panel and clicking Display. Choose the Settings tab, click the Advanced button, select Display Device, select the applicable Monitor type, click Apply or OK.

For more information on switching the display output, see

“Directing the display output when you turn on the computer” on page 61.

Adjusting the quality of the external display

To obtain the best picture quality from your television (or other video display device), you may need to adjust the video settings. See the video device documentation for additional configuration steps.

TECHNICAL NOTE: In order to use one of the simultaneous modes, you must set the resolution of the internal display panel to match the resolution of the external display device. The external display device must support a resolution of 640 X 480 or higher.

Page 63

Using an external keyboard

If you prefer to use a full-size keyboard, you can attach one to your computer. The computer’s USB port supports any USBcompatible keyboard.

Using a mouse

You may want to use a mouse instead of the computer’s builtin TouchPad. You can use a USB-compatible mouse.

Getting Started

NOTE

After logging on to your system, the mouse cursor may move to the upper-right side of the screen. If this occurs, push the

Esc or Windows key to return it to its original position.

Connecting a local printer

Your printer documentation may require you to install the printer software before physically connecting the printer to your computer. If you do not install the software as instructed by the printer manufacturer, the printer may not function correctly.

Never connect the printer cable while the computer’s power is on. Doing so may damage the printer, the computer, or both.

NOTE

Read the documentation that came with your printer. Follow the manufacturer’s instructions when connecting a local printer.

Page 64

Getting Started

Connecting a local printer

NOTE

These instructions assume you have a parallel printer. If you have a USB printer, consult the document that came with your printer.

To connect the printer:

1 If the computer is on, turn it off.

2 Connect the printer cable to the printer and to the

Identifying the ends of a parallel printer cable

3 Plug the printer’s power cable into a live electrical outlet.

You must supply the proper printer cable. If one did not come with your printer, you may purchase one from an electronics or computer store.

If your printer is ECP- or IEEE-compliant, make sure your printer cable is an IEEE 1284 cable.

computer’s parallel port. Use the printer cable illustration as a connection guide.

To the computer To the printer

4 See your printer documentation for additional

configuration steps.

NOTE

For more information on setting up your printer, see “Using a

printer” on page 113.

For more information on getting your printer to print, see

“Printing your work” on page 78.

Some printers use USB to connect.

Page 65

Getting Started

Connecting an optional external diskette drive

Some operations, such as creating a password service diskette, require a diskette drive designed for use with 3.5inch diskettes.

An optional external USB diskette drive

To connect an optional external USB diskette drive, connect the cable to one of the USB ports.

Connecting an optional external USB diskette drive

Page 66

Getting Started

Connecting external speakers or headphones

To attach an external stereo output device:

1 Locate the headphone jack near the front of the right side of

the computer.

2 Using any necessary adapters, plug the cable from the

external audio device into the headphone jack. The headphone jack requires a 3.5-mm, 16-ohm stereo jack.

When the headphone is inserted, the internal speakers are automatically disabled.

Connecting a microphone

To record high-quality sounds, you can attach a microphone:

1 Locate the microphone jack near the front of the right side of

the computer.

2 Plug the microphone cord into the jack.

3 Turn on the microphone.

For more information, see “Recording sounds” on page 132.

Page 67

Chapter 2

Learning the Basics

This chapter gives some computing tips and provides important information about basic features.

Computing tips

❖ Save your work frequently.

Your work stays in the computer’s temporary memory until you save it to the disk. If the network you are using goes down and you must restart your computer to reconnect, or your battery runs out of charge while you are working, you will lose all work since you last saved.

See “Saving your work” on page 76 for further information.

HINT: Some programs have an automatic save feature that can be activated. This feature saves your file to the hard disk at preset intervals. See your software documentation for details.

Page 68

Learning the Basics

Computing tips

❖ Back up your files to disks (or other removable media) on

a regular basis. Label the backup copies clearly and store them in a safe place.

It’s easy to put off backing up because it takes time. However, if your hard disk suddenly fails, you will lose all the data on it unless you have a separate backup copy.

❖ Use Error-checking and Disk Defragmenter regularly to

conserve disk space and improve performance.

❖ Scan all new files for viruses.

❖ This precaution is especially important for files you

receive via diskette, email, or download from the Internet. Take frequent breaks to avoid repetitive-motion injuries and eyestrain.

❖ Do not turn off the computer if a drive indicator light

indicates a drive is active.

Turning off the computer while it is reading from or writing to a disk may damage the disk, the drive, or both.

❖ Before turning off the computer, use the Turn off

computer command or Standby command. See

“Powering down the computer” on page 91 to learn more

about Standby.

NOTE

The Windows®XP operating system records information, such as your desktop setup, during its shutdown procedure. If you do not let the Windows normally, details such as new icon positions may be lost.

XP operating system shut down

Page 69

Using the keyboard

Learning the Basics

Using the keyboard

Your computer’s keyboard contains character keys, control keys, function keys, and special Windows the functionality of a full-size keyboard.

Keyboard

Character keys

Typing with the character keys is very much like typing on a typewriter, except that:

❖ The space bar creates a space character instead of just

passing over an area of the page.

❖ The lowercase letter l (el) and the number 1 are not

interchangeable.

❖ The uppercase letter O and the number 0 are not

interchangeable.

keys, providing all

Making your keyboard emulate a full-size keyboard

Although your computer’s keyboard layout is compatible with a standard full-size keyboard, it has fewer keys.

A standard full-size keyboard has two editing keys; cursor positioning keys; and a numeric keypad. Pressing the of the specially marked keys allows you to emulate a full-size keyboard.

Your computer’s keyboard has only one Most of the time, this does not matter. However, some

Fn key simultaneously in combination with one

Enter, Ctrl, and Alt keys;

Enter and one Ctrl key.

Page 70

Learning the Basics

Using the keyboard

programs assign separate functions to the right and left Ctrl

Alt keys, or to the regular and numeric pad Enter keys on

and the full-sized keyboard. Using the these separate keys, as follows:

❖ Press Fn and Ctrl simultaneously to simulate the Ctrl key on

the right side of the enhanced keyboard.

❖ Press Fn and Enter simultaneously to simulate the Enter key

on the numeric pad of the enhanced keyboard.

Ctrl, Fn, and Alt keys

Ctrl

Ctrl, Fn, and Alt keys

Ctrl, Fn, and Alt keys do different things depending on the

The program you are using. For more information, see your program documentation.

Fn key you can simulate

Alt

Function keys

The function keys (not to be confused with the Fn key) are the 12 keys at the top of the keyboard.

The function keys

F1 through F12 are called function keys because they execute

programmed functions when pressed. Used in combination with the specific functions on the computer. TouchPad. For more information, see “Fn-esse®” on

page 146, or “Hot Keys” on page 191.

Fn key, function keys marked with icons execute

Fn+F9 turns off the

Page 71

Windows special keys

The Windows special keys

Your computer’s keyboard has two keys that have special functions in Windows:

❖ Start key—Opens the Start menu

❖ Application key—Has the same function as the

secondary mouse (or AccuPoint II) button

Overlay keys

The keys with gray numbers and symbols on the front of them form the numeric and cursor overlay. This overlay lets you enter numeric data or control the cursor as you would using the 10-key keypad on a desktop computer’s keyboard.

Start key

Application key

Learning the Basics

Using the keyboard

Numeric and cursor control overlay

Page 72

Learning the Basics

Using the keyboard

Using the overlay to type numeric data

The keys with the numbers on their right front are the numeric overlay keys.

To turn the numeric overlay on, press simultaneously. The numeric mode light on the keyboard indicator panel glows when the numeric overlay is on.

You can still use the overlay keys to type alphabetic characters while the numeric overlay is on. To do so:

❖ For lowercase letters, hold down Fn while you type the

letters.

❖ For uppercase letters, hold down both Fn and Shift while

you type the letters.

To use the cursor control keys when the numeric overlay is on:

❖ Press and hold down Shift while you use the cursor control

overlay keys.

❖ To return to the numeric overlay, release Shift.

To disable the numeric overlay, hold down the

F11 again. The numeric mode light on the keyboard

press indicator panel goes out.

Fn and F11

Fn key and

Using the overlay for cursor control

The keys with the gray arrows and symbols on their left front are the cursor control overlay keys.

To turn the cursor control overlay on, press simultaneously. The cursor control mode light on the keyboard indicator panel glows when the cursor control overlay is on.

To type alphabetic characters while the overlay is on:

❖ For lowercase letters, hold down Fn while you type the

letters.

Fn and F10

Page 73

Learning the Basics

Starting a program

❖ For uppercase letters, hold down both Fn and Shift while

you type the letters.

To use the numeric overlay keys while the cursor control overlay is on:

❖ Hold down Shift while you use the numeric overlay keys.

❖ To return to the cursor control overlay, release Shift.

To disable the cursor control overlay, hold down the and press keyboard indicator panel goes out.

F10 again. The cursor control mode light on the

Starting a program

The easiest way to start a program is to double-click the name of the file that contains the information you want to work on. To find the file, use My Computer or Windows

If you prefer to open the program first, you have four options. You can:

❖ Double-click the icon for the program on your desktop

❖ Use the Start menu

❖ Use Windows

program file

❖ Use the Run dialog box

The next three sections explain how to start a program from the Start menu, Explorer and the Run dialog box.

Starting a program from the Start menu

When you install a program, the operating system usually puts an icon in the All Programs menu. To start a program that has an icon in the All Programs menu, follow these steps, which use the Windows

Explorer or My Computer to locate the

WordPad program as an example:

Fn key

Explorer.

1 Click Start, then point to All Programs.

Page 74

Learning the Basics

Starting a program

The Windows® XP operating system displays the All Programs menu, which lists programs and program groups. If your program is listed, go to Step 3, otherwise, continue with Step 2.

2 Point to the program group, in this example, Accessories.

The Accessories menu is displayed.

3 Click the program, in this example, Wor dPa d.

WordPad opens.

To close the program, click the Close button in the upper-right corner of the program’s window.

Starting a program from Windows® Explorer

If a program is not listed in the Programs menu, you can start it from Windows view of your computer’s contents as a hierarchy or “tree.” You can easily see the content of each drive and folder on your computer. To use this method, you should know the file name and location of the program’s executable file (this file ends with .exe).

This example opens WordPad using its file name, wordpad.exe.

1 Click Start, then point to All Programs.

2 Click Accessories.

3 Click Windows Explorer.

4 Click My Computer, to expand it.

5 In the left part of the window, under the C: icon, double-

click the folder containing the program, in this case Program Files.

Windows folder on the right side of the window. The left side of the

Explorer. Windows® Explorer gives you a

Explorer shows the contents of the Program Files

Page 75

Learning the Basics

Starting a program

window shows all the folders contained within the Program Files folder.

6 In the left part of the window, click Windows NT.

7 Click Accessories.

Windows folder on the right side of the window.

8 In the right part of the window, double-click Word Pad.

The operating system opens WordPad.

To close the program, click the Close button in the upper-right corner of the program’s window.

Explorer shows the contents of the Accessories

Starting a program from the Run dialog box

This example uses the Run command to start WordPad:

1 Click Start, then click Run.

The Run dialog box appears.

Sample Run dialog box

2 In the Run dialog box:

❖ If you know the program’s location, type the command

line. For a program in the Windows

program name. Otherwise, type the full file path. For

example, to access WordPad, type:

c:\Program Files\WindowsNT\Accessories\Wordpad, then click

OK.

folder, type just the

Page 76

Learning the Basics

Saving your work

❖ If you do not know the location, click Browse....

In the Browse dialog box, enter the file name (for example, wordpad.exe) and select the drive to search. When the operating system has found the file, click Open.

HINT: To run the same program again, click the arrow to the right of the text box and select the command line from the drop-down list.

Saving your work

Before you turn off the computer, save your work on the hard disk drive or a diskette. This is one of the most important rules of computing.

TECHNICAL NOTE: Save your data even when you are using the Standby command, in case the main battery discharges before you return to work.

Saving documents is quick and easy, so it is a good idea to get in the habit of saving frequently.

Many programs offer a feature that saves documents at regular intervals. Check your program’s documentation to see if it has an automatic save feature.

Saving files

1 On the File menu of your Windows® program, click Save.

If you are working with a document that already has a file name, this is all you need to do. If you created a new document, your program displays a Save As dialog box.

Page 77

Learning the Basics

Saving your work

Use this dialog box to specify where to store the document and to give it a file name.

A sample Save As dialog box

2 Choose the drive and folder where you want your file to

be stored.

3 Type a file name, then click Save.

HINT: To make another copy of the file you are currently working with, choose Save As from the File menu and give the new file a different name.

The Windows up to 255 characters; the names can include spaces. Some applications still require MS-DOS

XP operating system supports file names of

file names.

File names

If you plan to share your files with a computer using a preWindows file name must be no more than eight characters long. Typically the file name also has an extension, consisting of a period and up to three additional characters.

95 version of the Windows® operating system, the

Page 78

Learning the Basics

Printing your work

You may use all the letters and numbers on the keyboard plus these characters: _ ^ $ ~ ! # % & { } ( ) @ and ‘. MS-DOS file names are not case-sensitive and must not contain spaces.

Using a file extension

Most programs assign an extension to the file name that identifies the file as being created in the program with a particular format. For example, Microsoft with a .doc extension. Any file name with an extension of “.doc” is assumed to be a Microsoft own extension is usually unwise, since the program is unlikely to recognize a strange extension and may refuse to handle your file correctly.

Printing your work

Ensure the operating system is set up for your printer as described in “Using a printer” on page 113.

HINT: You only need to set up the printer the first time you connect it. If you use more than one printer or are changing printers, you will need to set up the Windows Professional operating system to run with the additional printer(s).

Word saves files

Word file. Creating your

To print a file:

1 If your printer is not on, turn it on now.

2 Open the File menu of your Windows

Print.

The program displays a Print dialog box.

program and click

Page 79

Learning the Basics

Using the DVD-ROM or multi-function drive

A sample Print dialog box

3 Specify the print parameters. For example, the range of

pages and number of copies to print.

4 Click Print.

Using the DVD-ROM or multi-function drive

Optical storage has become the preferred medium for software, music, and video. Digital versatile discs (DVDs) provide a significant increase in data storage and support features that are not available on any other video platform. These features include wide-screen movies, multiple language tracks, digital surround sound, multiple camera angles, and interactive menus.

For these reasons, your computer may come with a DVDROM drive or multi-function drive.

Page 80

Learning the Basics

Using the DVD-ROM or multi-function drive

TECHNICAL NOTE: Your DVD-ROM or multi-function drive is set to play region 1 (North America) DVD-ROMs. If you play a DVD disc from another region, the drive will automatically change to play in the format of the other region. The drive will allow you to change regions four times. On the fourth change, the region will be “locked in.” That is, the drive will only play DVDs from that last region. Note that changing from region 1 to region 2 and back to region 1 is counted as two changes.

Drive in-use indicator light Eject button Manual eject hole

Sample DVD-ROM drive shown

Drive in-use indicator light—Indicates when the drive is in use.

Eject button—Press to release the disc tray.

Do not press the eject button or turn off the computer while the Drive in-use indicator light is glowing. Doing so could damage the disc or the drive.

When the disc tray is open, be careful not to touch the lens or the area around it. Doing so could cause the drive to malfunction.

Manual eject hole—Use if you need to release the disc tray when the power is off. Use a straightened paper clip or other narrow object to press the manual eject button located inside the hole.

Page 81

Using the DVD-ROM or multi-function drive

Never use a pencil to press the eject button. Pencil lead can break off inside the computer and damage it.

CD/DVD control buttons

The control buttons on the front edge of the computer let you play audio CDs when the computer is off. You can also use them to play CDs and DVDs when the computer is on.

Learning the Basics

Mode

CD/DVD control buttons on the front of the computer

The mode button switches between the CD/DVD and digital audio modes. You can lock the mode to its current setting by pressing and holding the mode button for four seconds. When the mode button is locked, you cannot switch between the CD/DVD and digital audio modes. To unlock the mode button, press and hold it for four seconds.

The previous track button returns to the preceding track on the disc.

The next track button skips to the following track on the disc.

The play/pause button starts playing the disc or makes it

pause if currently playing.

The stop/eject button stops a disc that is currently playing.

You can eject a disc by pressing the stop/eject button twice. Use this method to eject a disc when the computer is turned off and the sound subsystem is turned on.

track track

Play/Pause

Stop/Eject

Page 82

Learning the Basics

Using the DVD-ROM or multi-function drive

CD/DVD control and digital audio modes

The following chart describes CD/DVD control and digital audio modes.

Power is off and you press Play/Pause

CD/DVD Mode Digital Audio Mode

If a CD is in the drive, the system enters CD player mode and operates as a stand-alone CD player.

If a DVD is in the drive, the operating system starts and the DVD player starts.

The operating system starts, the Media Player starts and the digital audio file begins to play.

While in CD/DVD mode, you press the mode button

Operating system is running and you press Play/Pause

DVD-ROM drive power turns off.

If a CD is in the drive, the Media Player starts and the digital audio file begins to play.

If a DVD is in the drive, the DVD begins to play.

Inserting compact discs

To insert a compact disc into the drive:

1 Make sure the computer is turned on.

2 Make sure the in-use indicator light is off.

3 Press the drive’s eject button.

Media Player starts and the digital audio file begins to play.

Page 83

Learning the Basics

Using the DVD-ROM or multi-function drive

The disc tray slides partially out of the drive (about 1 inch).

HINT: The drive will not open if the computer’s power is off.

4 Grasp the tray and pull it fully open.

The drive tray fully extended

5 Hold the disc by its edges and check that it is free of dust.

If the disc is dusty, clean it as described in “Caring for CDs or

DVDs Discs” on page 85.

6 Place the disc carefully in the disc tray, label side up.

Positioning the disc in the drive

Page 84

Learning the Basics

Using the DVD-ROM or multi-function drive

7 Gently press the disc onto the center spindle until you

feel it click into place.

Handle DVDs and CDs carefully, making contact only with the center hole and edge. Do not touch the surface of the disc. Do not stack discs. If you incorrectly handle the discs, you could lose data.

8 Make sure the disc is completely on the spindle and is

lying flat on the tray.

If you insert the disc incorrectly, it may jam the drive. If this happens, contact your Toshiba support for assistance.

9 Push the disc tray in by pressing gently on the center of

the tray until it clicks into place.

You are ready to use the disc.

Removing compact discs

To remove a compact disc (CD or DVD) with the computer turned on:

1 Press the eject button on the drive.

Do not press the eject button while the in-use indicator light is glowing. Doing so could damage the disc or the drive.

Also, if the disc is still spinning when you open the disc tray, wait for it to stop spinning before you remove it.

2 Pull the tray until it is fully open, remove the disc, and

place it in its protective cover.

3 Gently push the tray in to close it.

Page 85

Using the DVD-ROM or multi-function drive

To remove a compact disc with the computer turned off:

1 Insert a slender object, such as a straightened paper clip, into

the manual eject hole.

2 Gently pull the tray out until it is fully open, remove the

disc, and place it in its protective cover.

3 Gently push the tray in to close it.

Caring for CDs or DVDs Discs

❖ Store your discs in their original containers to protect

them from scratches and keep them clean.

❖ Do not bend a disc or place heavy objects on top of it.

❖ Do not apply a label to, or otherwise mar the surface of a

disc.

❖ Hold a disc by its outside edge. Fingerprints on the

surface can prevent the DVD-ROM drive or multifunction drive from reading the data properly.

Learning the Basics

❖ Do not expose discs to direct sunlight or extreme heat or

cold.

❖ To clean a disc that is dirty, wipe it with a clean, dry

cloth. The most efficient method to clean it is to start from the center of the disc and wipe toward the outward edge (not in a circle). If necessary, moisten the cloth with water or a neutral cleaner (not benzine or rubbing alcohol). Let the disc dry completely before inserting it in the drive.

Page 86

Learning the Basics

Using PC Cards

TECHNICAL NOTE: For PCMCIA-compatible PC Cards, check the package to make sure they conform to the PCMCIA 2.1 standard (or later). Other cards may work with your computer, but are likely to be much more difficult to set up and use.

For information on inserting or removing a PC Card, see

“Inserting and removing PC Cards” on page 138.

Hot swapping

With PC Cards, you can replace one PC Card with another while the computer is on. This is called “hot swapping.”

Hot swapping precautions

Although you can insert a PC Card at any time, remember not to remove a card while it is in use. Otherwise, you could lose valuable information. For example:

❖ Do not remove a hard disk card while the system is

accessing it.

❖ Do not remove a network card while you are connected to

a network.

❖ Do not remove a SCSI card while any of the SCSI

devices connected to it are operating.

Before removing a PC Card, stop it by clicking the Safely Remove Hardware icon on the System tray. After the PC Card is stopped, it is safe to remove.

Page 87

Learning the Basics

Using SD

(Secure Digital) cards

Using SD® (Secure Digital) cards

If you do not already have a SD card inserted in the computer, you may do so following the procedures outlined in

“Inserting an SD® card” on page 140.

Important: Do not use the Copy Disk function for SD cards. In order to copy data from one SD card to another, use the following procedure:

1 Format the target SD card in the same format as the source SD

card.

2 Insert the source SD card.

3 Create a temporary folder on the hard disk drive.

4 Copy the contents of the source SD card into the

temporary folder you created in step 3.

5 Remove the source SD card.

6 Insert the target SD card created in step 1.

7 Copy the file contents from the temporary folder to the

target SD card.

8 Eject the target SD card.

NOTE

MMC cards (multimedia cards) do not work in this slot.

Using your computer at the office

By connecting an external monitor, external full-size keyboard, and a mouse, you can work with your notebook as if it were a standard office computer.

An external monitor or projector connects to the RGB (monitor) port.

Any USB device can connect to the USB ports.

Page 88

Learning the Basics

Using a computer lock

For your own peace of mind, you may want to secure your computer to a heavy object such as your desk. The easiest way to do this is to purchase an optional PORT-Noteworthy Computer Lock Cable.

PORT-Noteworthy

To secure the computer:

1 Loop the cable through or around some part of a heavy object.

Make sure there is no way for a potential thief to slip the cable off the object.

2 Pass the locking end through the loop.

Computer Lock Cable

3 Insert the cable’s locking end into the security lock slot

on the computer, then give the key a quarter turn and remove it.

The computer is now securely locked.

Locking the computer

Page 89

Caring for your computer

This section gives tips on cleaning and moving your computer. For information about taking care of your computer’s battery, see “Running the computer on battery

power” on page 100.

Cleaning the computer

Keep liquids, including cleaning fluid, out of the computer’s keyboard, speaker, and other openings. Never spray cleaner directly onto the computer. Never use harsh or caustic chemical products to clean the computer.

To keep your computer clean, gently wipe the display panel and exterior case with a lightly dampened cloth. Ask your Toshiba dealer for suggestions for appropriate cleaning products.

Learning the Basics

Moving the computer

Before moving your computer, even across the room, make sure all disk activity has ended (the drive indicator light stops glowing) and all external peripheral cables are disconnected.

Do not pick up the computer by its display panel or by the back (where the ports are located).

Although your notebook computer is built to withstand reasonable shock and vibration, transport it in a carrying case for long trips. You can purchase a carrying case from your Toshiba dealer, through the accessories information packaged with your system, or visit

toshiba.com.

Page 90

Learning the Basics

Backing up your work

Your computer comes with Recovery media that enable you to reinstall software that was preinstalled. This media can be used to install or reinstall particular Toshiba applications, utilities, and drivers. Back up all the files you create in case something happens to your computer. If you have a network partition, you can hold copies of your files there.

Alternatively, you can back up your files to diskette one at a time as you are working on them.

To back up several files at one time, use the Microsoft Windows hard disk.

backup program preinstalled on the computer’s

Complete information on the backup program is in the online Help and your Windows

HINT: Backing up all the files on your hard disk takes a considerable amount of time and many diskettes. You may prefer to use a high-capacity backup system, such as an external tape drive.

Restoring your work

To restore information from your backup media to your hard disk, use the Restore page in the backup program. Look in the online Help or your operating system documentation for information on restoring files.

TECHNICAL NOTE: When restoring files, the backup program prompts you if you try to overwrite a file that already exists on the hard disk. Make sure the backup version is the one you want before overwriting the existing file.

documentation.

Page 91

Learning the Basics

Preparing for communications

To connect to the Internet, use an online service, or communicate across the telephone lines with another computer, you need:

❖ A modem (supplied with your computer)

❖ A telephone line

❖ A browser or communications program

❖ An Internet Service Provider (ISP) or an online service if

you plan to use the Internet

Before you can use the modem, you must connect it to a standard voice-grade telephone line. See “Connecting to a

power source” on page 43 for details.

Powering down the computer

NOTE

When you power down the computer, you have three options to choose from: Turn Off Computer, Standby, and Hibernation.

Pushing the power button before shutting down the Windows operating system could cause you to lose your work. Make sure the system indicator panel’s disk light and the drive-in use light are off. If you turn off the power while a disk is being accessed, you may lose data or damage the disk and/or drive.

TECHNICAL NOTE: Before using any of these options to power down your computer, save your files and make sure the disk activity lights are off.

If you change your mind and decide to continue working after all, wait a few seconds before turning the computer on again.

Page 92

Learning the Basics

Powering down the computer

Using Turn Off Computer or Shut Down

For the Windows XP Home operating system, follow these steps to shut down the computer:

1 Click Start, select Turn off computer.

The Turn off computer dialog box appears.

Sample Turn off computer Windows dialog box

2 Click Turn O ff .

The computer shuts down completely.

For the Windows these steps to shut down the computer:

1 Click the Start button, then Shut down.

The Shut Down Windows dialog box appears.

2 Select Shut down from the drop-down list.

3 Click OK.

The computer shuts down completely.

NOTE

Holding the shift key while the Turn Off computer Windows dialog box is open, changes the Stand By button to hibernate. For more information about setting up hibernation, refer to

“Using Hibernation” on page 94.

XP Professional operating system, follow

Page 93

Learning the Basics

Powering down the computer

Shutting down more quickly

In addition, you can shut down the computer by pressing the power button.

To use either of these methods, you first need to turn it on in Toshiba’s Power Saver utility.

1 Open the Start menu, click Control Panel, then

Performance and Maintenance.

2 Click the Tos hi ba Po w er Save r icon.

3 Click on the Setup Action tab.

4 Select the options you want from the drop-down lists.

❖ When I press the power button

Set this option to Shutdown to have the computer shut

down when you press the power button.

5 Click Apply.

6 Click OK.

Sample system power mode settings

Page 94

Learning the Basics

Powering down the computer

NOTE

For more information about the Power Saver utility, see

“Power Management” on page 151.

Starting again after Shut down

To start the computer up again, press the power button until the on/off light changes to blue.

If you shut down the computer by closing the display panel, you can start it again by opening the display panel.

Using Hibernation

Hibernation mode shuts the computer down completely, but it first saves the current mode of the computer to the hard disk. Since Hibernation mode does not require power to maintain the saved information, the system settings are retained indefinitely. Restoring information from the hard disk takes longer than restoring it from memory. When you start up again, the computer runs a self-test, loads the operating system, and then returns to the mode in which you left it.

Factors to consider when choosing Hibernation:

❖ While in Hibernation mode, the computer uses no battery

power

❖ Because the mode of the system is held on the hard disk,

no data is lost if the main battery discharges

❖ When starting up again, Hibernation uses less time and

battery power than does Turn off computer

❖ Restarting from Hibernation uses a little more time and

battery power to start up than restarting from Standby, because information is being retrieved from the hard disk rather than from memory

Page 95

Learning the Basics

Powering down the computer

❖ When starting up again, the computer returns to the mode

in which you left it, including all open programs and files you were using

Configuring your computer for Hibernation

1 Open the Start menu, click Control Panel then

Performance and Maintenance.

2 Click the Tos hi ba Po w er Save r icon.

3 Click the Setup Action tab.

4 Select Hibernation for the options you want.

❖ When I press the power button

Set this option to Hibernate so that the computer will go

into Hibernation mode when you press the power button.

❖ When I close the lid

Set this option to Hibernate so that the computer will go

into Hibernation mode when you close the display panel.

5 Click Apply.

6 Click OK.

The computer is now set to automatically go into Hibernation when your option settings occur.

NOTE

Once the computer is configured, put the computer into Hibernation mode by either pressing the power button or closing the display panel, depending on the hibernation options taken.

For more information about the Power Saver utility, see

“Power Management” on page 151.

Page 96

Learning the Basics

Powering down the computer

Starting again from Hibernation mode

To start up the computer from Hibernation mode, press the power button until the on/off light turns blue. The computer returns to the screen you were using.

If you put the computer in Hibernation mode by closing the display panel, you can start it again by opening the display panel.

Using Standby

The Standby command puts the computer into a powersaving mode. Standby holds the current mode of the computer in memory so that, when you restart the computer, you can continue working from where you left off.

Factors to consider when choosing Standby:

❖ While in Standby mode, the computer uses some battery

power. A fully charged main battery will last up to eight hours in Standby mode.

❖ Restarting from Standby uses less time and battery power

than restarting from Turn off computer or Hibernation.

❖ When starting up again, the computer returns to the mode

in which you left it, including all open programs and files you were using.

NOTE

To power down the computer using the Standby command, click Start, Turn off computer, and select Stand By.

If you power down using the Standby command and the main battery discharges fully, your information will be lost. Be sure to save your work first.

Page 97

Learning the Basics

Powering down the computer

Sample Turn off computer Windows® dialog box

NOTE

The computer saves the status of all open programs and files, turns off the display, and goes into a low-power mode. The on/off light blinks amber indicating the machine is in Standby mode.

If you hold down the Shift key, Stand By becomes Hibernate in the Turn off computer dialog box. To enter hibernation mode, you must hold down the Shift key while you select Hibernate.

Going into Standby mode more quickly

In addition, you can put the computer into Standby mode by either pressing the power button or closing the display panel. You can also specify an amount of time after which the computer automatically goes into Standby mode.

To use any of these methods, you first need to enable them in Toshiba’s Power Saver utility.

1 Open the Start menu, click Control Panel then

Performance and Maintenance.

2 Click the Tos hi ba Po w er Save r icon.

3 Click the Setup Action tab.

4 Select Standby for the options you want.

Page 98

Learning the Basics

Toshiba’s online resources

❖ When I press the power button

Set this option to Standby to put the computer into Standby mode when you press the power button.

❖ When I close the lid

Set this option to Standby to put the computer into Standby mode when you close the display panel.

5 Click Apply.

6 Click OK.

NOTE

For more information about the Power Saver utility, see

“Power Management” on page 151.

Starting again from Standby mode

To start up the computer from Standby mode, press the power button until the on/off light changes to blue. The computer returns to the screen you were using.

If you put the computer in Standby mode by closing the display panel, you can start it again by opening the display panel.

Toshiba’s online resources

Toshiba maintains a number of online sites to which you can connect. These sites provide information about Toshiba products, give help with technical questions and keep you up to date with future upgrades. For more information, see

“Contacting Toshiba” on page 186.

Page 99

Chapter 3

Mobile Computing

Toshiba’s energy-saver design

Your computer enters a low-power, standby mode when it is not being used, thereby conserving energy and saving money in the process. It has a number of other features that enhance its energy efficiency. Many of these energy-saving features have been set by Toshiba. We recommend you leave these features active, allowing your computer to operate at its maximum energy efficiency, so that you can use it for longer periods of time while traveling.

For more information on managing your power usage, see

“Power profiles in Windows XP” on page 110.

This chapter covers all the aspects of using your computer on battery power.

Page 100

Mobile Computing

100

Running the computer on battery power

The computer contains a removable Lithium-Ion (Li-ion) battery pack that provides power when you are away from an AC outlet. This is the main battery. You can recharge it many times.

TECHNICAL NOTE: For optimum DVD performance, always play DVDs while your computer is connected to AC power.

Battery Notice

To ensure that the battery maintains its maximum capacity, operate the computer on battery power at least once a month until the battery is fully discharged. Please see “Maximizing

battery life” on page 101 for procedures. If the computer is

continuously operated on AC power, either through an AC adapter or a docking station (if applicable to your system), for an extended period (more than a month), the battery may fail to retain a charge. This may shorten the life of the battery, and the battery light may not indicate a low-battery condition.

The RTC battery powers the RTC memory that stores your system configuration settings and the current time and date information. It maintains this information for up to a month while the computer is turned off.

TECHNICAL NOTE: The RTC battery does not charge while the computer is turned off, even when AC power is attached.

Charging the battery

To charge the main battery while it is in your computer, plug the computer into a live electrical outlet. The battery charges whether the computer is on or off.

Toshiba M35 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Satellite® M30/M35 Series User’s Guide

Contents

Introduction

This guide

Safety icons

Other documentation

Other icons used

Service options

Selecting a place to work

Creating a computer-friendly environment

Keeping yourself comfortable

Other precautions

Setting up your computer

Adding memory

Installing a memory module

Removing a memory module

Turning on the computer

Opening the display panel

Turning on the power

Using the TouchPad™

Control buttons

Disabling or enabling the TouchPad

Setting up your software

Registering your computer with Toshiba

Setting up other devices

Turning off the computer

Using external display devices

Closing the display panel

Connecting the display device

Directing the display output when you turn on the computer

Adjusting the quality of the external display

Using an external keyboard

Using a mouse

Connecting a local printer

Connecting an optional external diskette drive

Connecting external speakers or headphones

Connecting a microphone

Computing tips

Using the keyboard

Character keys

Making your keyboard emulate a full-size keyboard

Ctrl, Fn, and Alt keys

Function keys

Windows special keys

Overlay keys

Using the overlay to type numeric data

Starting a program

Starting a program from the Start menu

Starting a program from Windows® Explorer

Starting a program from the Run dialog box

Saving your work

Printing your work

Using the DVD-ROM or multi-function drive

CD/DVD control buttons

Inserting compact discs

Removing compact discs

Caring for CDs or DVDs Discs

Using PC Cards

Hot swapping

Using SD® (Secure Digital) cards

Using your computer at the office

Using a computer lock

Caring for your computer

Cleaning the computer

Moving the computer

Backing up your work

Restoring your work

Preparing for communications

Powering down the computer

Using Turn Off Computer or Shut Down

Using Hibernation

Using Standby

Toshiba’s online resources

Toshiba’s energy-saver design

Running the computer on battery power

Battery Notice
