Toshiba G710 User Manual

Table of contents

Preface 4

Toshiba Corporation 5

EU Warranty 8

Licenses 9

Declaration of conformity 10

Health and safety 11

General 11
Operating environment 12
Electronic devices 13
Battery safety 14
AC charger safety 15
Emergency calls 15
European RF Exposure Information 16

Care and maintenance 18

General 18
Restarting your Toshiba phone 19
Resetting your Toshiba phone 20

Getting started 21

Unpacking 21
Phone layout and functions 22
Home Screen 26
Common display indicators 27
Installing the SIM card and battery 29
Installing a microSD card 32
Charging the battery 34
Switching the power on and off 36
Quick List 36

Call functions 37

Making a call 37
Speed Dial 39
Special dialling 40
Receiving a call 41
In-call options 42
Call History 44

Table of contents

1

Table of contents

Messaging 46

Text messages 46
E-mail 48
MMS messages 53
General messaging options 57

Table of contents

Text input 59

Input modes and indicators 59
Text mode 59
Numeric/Symbol mode 60

Applications and multimedia 61

Internet Explorer 61
Tasks 64
Windows Media 65
Calendar 69
Messaging 71
Contacts 72
Office Mobile 75
Call History 76
Settings 76

2

Games 76
Voice Notes 76
Pictures & Videos 77
Camera 77
Accessories 81
Internet Sharing 83
ActiveSync 83
File Explorer 85
Messenger 86
Speed Dial 87
Windows Live 88
Tools 88

Connectivity 89

Wireless Manager 89
Bluetooth 90
Beam 93
Internet connections 94
Internet Sharing 98
USB to PC 99

Table of contents

Settings 100

Phone settings 100
Sound settings 106
Profile settings 106
Display settings 107
Clock & Alarm settings 108
Connections 109
Security settings 109
Remove Programs 113
Power Management 113
Regional Settings 114
Owner Information 114
Phone Information 114
Backlight level 115
Accessibility 115
About 116
Error Reporting 116
Customer Feedback 117

Specifications 118

Troubleshooting 120

Purchase record 124

Menu tree 125

End User License Agreements
(EULAs) 126

Index 136

Table of contents

3

Preface

Preface

To use your Toshiba phone, you must have service from a wireless service provider. Many of the
features in your Toshiba phone depend on features in the wireless network to function. These network

Preface

services may not be available on all networks, or you may have to make specific arrangements with
your service provider before you can utilise network services. Your service provider may need to give
you additional instructions for their use and explain what charges will apply. Some networks may have
limitations that affect how you can use network services. For instance, some networks may not support
all language-dependent characters and services.
The availability of particular products may vary by region.
Due to the continual development of our products, Toshiba reserves the right to modify this document
at any time without prior notice.

4

Toshiba Corporation

Toshiba Corporation

IMPORTANT: PLEASE READ THE
FOLLOWING BEFORE USING YOUR
MOBILE PHONE AS ATTEMPTING TO
USE ANY SOFTWARE ON THE
SUPPLIED PHONE CONSTITUTES
YOUR ACCEPTANCE OF THESE EULA
TERMS. IF YOU REJECT OR DO NOT
AGREE WITH ALL THE TERMS OF THIS
EULA, PLEASE DO NOT ATTEMPT TO
ACCESS OR USE THE SUPPLIED
SOFTWARE.

End User License Agreement

This End User License Agreement ("EULA") is a
legal agreement between you (as the user) and
TOSHIBA CORPORATION ("Toshiba") with
regard to the copyrighted software installed in a
Toshiba mobile phone supplied to you (the
"Phone").
Use or employment of any software installed in
the Phone and related documentations (the
"Software") will constitute your acceptance of
these terms, unless separate terms are provided
by the Software supplier on the Phone, in which
case certain additional or different terms may

apply. If you do not agree with the terms of this
EULA, do not use or employ the Software.

1. License Grant. Toshiba grants to you a

personal, non-transferable and non-exclusive
right to use the Software as set out in this
EULA. Modifying, adapting, translating,
renting, copying, making available,
transferring or assigning all or part of the
Software, or any rights granted hereunder, to
any other persons, and removing any
proprietary notices, labels or marks from the
Software is strictly prohibited, except as
expressly permitted in this EULA.
Furthermore, you hereby agree not to create
derivative works based on the Software.

2. Copyright. The Software is licensed, not sold.

You acknowledge that no title to the
intellectual property in the Software is or will be
transferred to you. You further acknowledge
that title and full ownership rights to the
Software will remain the exclusive property of
Toshiba, Toshiba's affiliates, and/or their
suppliers, and you will not acquire any rights to
the Software, except as expressly set out in

Toshiba Corporation

5

Toshiba Corporation

this EULA. You may keep a backup copy of the
Software only so far as necessary for its lawful
use. All copies of the Software must contain
the same proprietary notices as contained in
the Software and are subject to the terms of
this EULA. All rights not expressly granted
under this EULA are reserved to Toshiba,
Toshiba's affiliates and/or their suppliers.

Toshiba Corporation

3. Reverse Engineering. You agree that you

will not attempt, and if you are a business
organisation, you will use your best efforts to
prevent your employees, workers and
contractors from attempting, to reverse
engineer, decompile, modify, translate or
disassemble the Software in whole or in part
except to the extent that such actions cannot
be excluded by mandatory applicable law and
only if those actions are taken in accordance
with such applicable law. Any failure to c omply
with the above or any other terms and
conditions contained herein will result in the
automatic termination of this license and the
reversion of the rights granted hereunder to
Toshiba.

6

4. LIMITED WARRANTY. Only during the

warranty period for the Phone, Toshiba,
Toshiba's affiliates, its suppliers or its
authorised service company will repair or
replace, at Toshiba's sole discretion, defective
Software unless such defect results from acts
or incidences beyond the reasonable control
of Toshiba. EXCEPT AS PROVIDED IN THIS
EULA:
(A) TOSHIBA, TOSHIBA'S AFFILIATES, AND
THEIR SUPPLIERS DISCLAIM ALL
WARRANTIES, CONDITIONS OR OTHER
TERMS (WHETHER EXPRESS OR
IMPLIED), INCLUDING BUT NOT LIMITED
TO WARRANTIES, CONDITIONS AND
TERMS OF SATISFACTORY QUALITY,
MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE AND NON­INFRINGEMENT OF THIRD-PARTY
RIGHTS; AND (B) THE ENTIRE RISK AS TO
THE QUALITY AND PERFORMANCE OF
THE SOFTWARE IS WITH YOU. YOU
ACCEPT THAT SOFTWARE MAY NOT
MEET YOUR REQUIREMENTS AND NO
WARRANTY CAN BE GIVEN THAT

Toshiba Corporation

OPERATION OF THE SOFTWARE WILL BE
UNINTERRUPTED OR ERROR-FREE.

5. LIMITATION OF LIABILITY. TO THE

FULLEST EXTENT LEGALLY PERMITTED,
IN NO EVENT SHALL TOSHIBA, TOSHIBA'S
AFFILIATES OR THEIR SUPPLIERS BE
LIABLE TO YOU FOR ANY DAMAGES FOR
(A) LOST BUSINESS OR REVENUE,
BUSINESS INTERRUPTION, LOSS OF
BUSINESS DATA; OR (B)
CONSEQUENTIAL, SPECIAL, INCIDENTAL
OR INDIRECT DAMAGES OF ANY KIND
(WHETHER UNDER CONTRACT, TORT OR
OTHERWISE) ARISING OUT OF: (I) THE
USE OR INABILITY TO USE THE
SOFTWARE, EVEN IF TOSHIBA,
TOSHIBA'S AFFILIATES OR THEIR
SUPPLIER HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES; OR (II)
ANY CLAIM BY A THIRD PARTY. SAVE AS
SET OUT IN THIS SECTION, TOSHIBA'S
ENTIRE LIABILITY UNDER THIS EULA
SHALL NOT EXCEED THE PRICE PAID FOR
THE SOFTWARE, IF ANY. THE ABOVE
DISCLAIMER AND LIMITATION DOES NOT

EXCLUDE OR LIMIT (A) LIABILITY FOR
DEATH OR PERSONAL INJURY CAUSED
BY NEGLIGENCE; OR (B) ANY
MANDATORY LEGAL RIGHT OR LIABILITY
TO THE EXTENT THAT IT CANNOT BE
LAWFULLY EXCLUDED OR LIMITED
UNDER APPLICABLE LAW. PLEASE MAKE
AND RETAIN A COPY OF ALL DATA YOU
HAVE INSERTED INTO YOUR PRODUCT,
FOR EXAMPLE NAMES, ADDRESSES,
PHONE NUMBERS, PICTURES,
RINGTONES ETC, BEFORE SUBMITTING
YOUR PRODUCT FOR A WARRANTY
SERVICE, AS SUCH DATA MAY BE
DELETED OR ERASED AS PART OF THE
REPAIR OR SERVICE PROCESS.

6. Laws. This EULA will be governed by the laws

of England and Wales. All disputes arising out
of this EULA shall be subject to the exclusive
jurisdiction of the English Courts.

7. Export Laws. Any use, duplication or

employment of the Software involves products
and/or technical data that may be controlled
under the export laws of applicable countries

Toshiba Corporation

7

Toshiba Corporation

or region, and may be subject to the approval
of the applicable governmental authorities
prior to export. Any export, directly or
indirectly, in contravention of the export laws
of applicable countries or region is prohibited.

8. Third Party Beneficiary. You agree that

certain suppliers of the Software to Toshiba
have a right as a third party beneficiary to

Toshiba Corporation

enforce the terms of this EULA against you as
a user.

9. Transfers. The Software may be transferred

only as installed on the Phone to a lawful third
party user, where that party accepts the terms
of this EULA, which will continue to apply.

10. IF YOU ARE DEALING AS A CONSUMER IN
THE UK AND THE SOFTWARE QUALIFIES
AS 'GOODS', YOUR STATUTORY RIGHTS
UNDER APPLICABLE LAW ARE NOT
AFFECTED.

8

EU Warranty

Your Toshiba phone, battery and AC charger
contain no user serviceable parts. For further
information on service, please contact your
retailer or service provider.

Licenses

Licenses

Microsoft, Windows, Windows Mobile, Windows
Live, Windows Media, ActiveSync, Internet
Explorer, Outlook, Excel, PowerPoint and Word
are either registered trademarks or trademarks of
Microsoft Corporation in the United States and/or
other countries.

Java™ and all Java-based marks are trademarks
or registered trademarks of Sun Microsystems,
Inc.

The Bluetooth
registered trademarks owned by Bluetooth SIG,
Inc.

microSD™ and the microSD™ logo are
trademarks.

ArcSoft and the ArcSoft logo are registered
trademarks of ArcSoft, Inc.

®

word mark and logos are

Licenses

9

Declaration of conformity

Declaration of conformity

We, Toshiba Information Systems UK (Ltd), Mobile Communications Division, of
Toshiba Court, Weybridge Business Park, Addlestone Road, Weybridge, KT15 2UL declare
under our sole responsibility that the product (G710, Type (Model) Name SJ3-E01) is in conformity
with the following standards and/or other normative documents:

3GPP TS 51.010-1, EN 301511, EN 301 419, EN 301 420, EN 50360, EN 50361, EN 300 328,
EN 301 489-1, EN 301 489-7, EN 301-489-17 and EN 60950

We hereby declare that all essential radio test suites, EMC & safety requirements have been carried
out and that the above named product is in conformity to all the essential requirements of Directive
1999/5/EC.

Declaration of conformity

The technical documentation relevant to the above equipment will be held at:

Toshiba Information Systems UK (Ltd), Mobile Communications Division
Delta House, The Crescent, Southwood Business Park,
Farnborough, Hampshire, GU14 ONL

3 March 2008

Takashi Okamoto
Deputy Managing Director of TIU
General Manager Mobile Communications Division

10

Health and safety

Health and safety

General

• Always use your Toshiba phone in the intended

manner. Incorrect usage may affect
performance.

• Do not attempt to dismantle the phone or any of

its accessories. Only qualified service
personnel should repair the phone and its
accessories.

• To avoid permanent damage to your Toshiba

phone, use only Toshiba approved batteries
and accessories.

• The bundled battery and AC charger are only

for use with your Toshiba phone. Do not use
this battery or AC charger with any other device
as this may cause permanent damage to the
device, battery or charger.

• The use of third party equipment (including

batteries, cables and accessories) not
manufactured or authorised by Toshiba, may
invalidate the warranty of your phone and
adversely affect the operation of the phone.

• Before connecting your Toshiba phone to

another device, read the supporting
documentation to confirm that the other device

is compatible.

• When using the headset, be careful not to listen
at excessive volumes. Listening to loud sound
levels may lead to hearing loss.

• It is recommended that pregnant and young
women take precautions while in a call and
keep the phone at a distance from their lower
abdomen. For this situation, use of a hands­free kit is recommended.

• Your phone contains metal that may cause skin
irritation.

•If your Toshiba phone has a flash unit, do not
operate the flash too close to a person’s eyes ­this may cause damage to their eyes.

Health and safety

11

Health and safety

Operating environment

• Observe all local safety regulations regarding
the use of mobile phones while driving.

• Pull off the road and park before making or
answering a call.

• Do not stop on the hard shoulder of a motorway

Health and safety

to answer or make a call, except in an
emergency.

• If using an integrated hands-free device, make
sure the phone is securely placed in its holder.

• Only qualified personnel should install the
device in a vehicle. Faulty installation or serv ice
may be dangerous and may invalidate any
warranty. For more information, consult your
vehicle manufacturer or representative.

• Do not place objects, including either installed
or portable wireless equipment, in the area
over the airbag or in the airbag deployment
area.

• Switch off your Toshiba phone when refuelling.

• Do not handle your Toshiba phone when
operating machinery.

12

•Switch your Toshiba phone off if you are
entering a hospital or health care facilities.
Medical equipment may be affected by phone
usage. Always follow building regulations
governing phone usage.

•Switch your Toshiba phone off when travelling
on an aircraft. The phone signal may interfere
with the systems in the aircraft. You are legally
bound to comply with this recommendation.

•Switch your Toshiba phone off in any facility
where posted notices prohibit phone usage.

•Switch your Toshiba phone off when blasting is
in progress and observe all provided guidelines
and regulations.

•Switch your Toshiba phone off in areas with
potentially explosive atmospheres. For
example, fuel storage areas and spray paint
facilities.

•Switch your Toshiba phone off when outdoors
during an electrical storm.

• Keep your Toshiba phone away from fuel and
chemicals.

Health and safety

Electronic devices

• If you wear a pacemaker, or are in the company
of someone who does, you should be aware
that there is a small risk of mobile phone usage
interfering with the operation of the pacemaker.
You should contact your doctor, or the
manufacturer of the pacemaker, for more
information.

• Mobile phone usage may interfere with some
hearing aids. If this happens you should
contact your service provider or doctor.

• Mobile phone usage may interfere with the
functionality of inadequately shielded medical
devices. Consult a physician or the
manufacturer of the device to ensure safe
procedures are used.

• Mobile phone usage may interfere with the
functionality of any inadequately shielded
electronic system in a motor vehicle. Examples
include airbags and fuel injection. You should
contact the manufacturer of the vehicle to
ensure that the electronic system is properly
shielded.

• Do not place your Toshiba phone alongside
computer disks, credit cards, travel cards and
other magnetic media. Information contained
on disks or cards may be affected by the
phone.

Health and safety

13

Health and safety

Battery safety

Your Toshiba phone is powered by a
rechargeable Lithium ion (Li-ion) battery. The full
performance of a new battery is achieved only
after two or three complete charge and discharge
cycles. The battery can be charged and

Health and safety

discharged hundreds of times but it will eventually
wear out. When the talk and standby times are
noticeably shorter than normal, it is
recommended that you buy a new battery.

• A new battery, or one that has not been used
for a long time, could have reduced capacity
during initial use.

• Only use batteries approved by Toshiba, and
only recharge the battery with the
recommended charger supplied by Toshiba.

• Stop using the battery if you detect any
abnormalities, such as odour, discolouration or
heat during use, charging or storage.

• Do not use your Toshiba phone with a
damaged battery.

• When the charger is not in use, disconnect it
from the power source.

14

• Do not leave the battery connected to the
charger and power source for longer than
necessary as overcharging will shorten the
lifespan of the battery.

• Do not short-circuit the battery. Accidental
short-circuiting can occur when a metallic
object causes a direct connection between the
+ and - terminals of the battery.

• Do not leave the battery in areas of extreme
cold or heat as this will affect the performance
of the battery. Areas of extreme cold include a
refrigerator, and areas of extreme heat include
a car exposed to direct sunlight.

• In the unlikely event of a battery leak, take care
to keep the battery discharge away from your
eyes and skin. If the leakage does come into
contact with eyes or skin, flush thoroughly with
clean water and consult a doctor.

• Do not dispose of the battery in a fire.

• Do not dispose of the battery in an ordinary bin.
The battery contains toxic chemicals and must
be disposed of appropriately. Contact your
local authorities for more information.

Health and safety

AC charger safety

• Do not use a damaged or worn AC charger.
The use of a damaged or worn AC charger
could result in electric shock, burns or fire.
Contact an authorised Toshiba service
provider immediately to obtain suitable
replacements.

• Do not bend or twist the cable of the AC
charger.

• Do not pull on the cable of the AC charger in
order to remove the plug from a socket.

• Grasp the plug directly when unplugging the
AC charger to avoid causing any damage to the
cable.

• Do not place heavy objects on the AC charger.

• Do not touch the phone, battery or AC charger
with wet hands while the phone is charging.

Emergency calls

Wh en ma kin g e mer ge nc y ca ll s fr om yo ur T os hiba
phone, ensure that the phone is switched on and
in service.
Calls cannot be made to emergency services
while data communication is being performed
within a GSM area. Also, calls may not be able to
be made to emergency services depending on
the network services of some service providers.

IMPORTANT: You can still make calls to
emergency services when the SIM card is
not inserted, the SIM card is locked, the
phone is locked, Fixed Dialling is set, or
Call Barring is set.

There is no guarantee that a connection can be
established in all countries and areas because
operation of your phone differs depending on the
wireless network, wireless signal and your setting
status. Do not rely solely on your mobile phone
when you need to make emergency calls.

Health and safety

15

Health and safety

European RF Exposure
Information

Your Toshiba phone is a radio transmitter and
receiver. It is designed not to exceed the limits for
exposure to radio waves recommended by
international guidelines. These guidelines were

Health and safety

developed by the independent scientific
organisation ICNIRP and include safety margins
designed to assure the protection of all persons,
regardless of age and health.

The guidelines use a unit of measurement known
as the Specific Absorption Rate, or SAR. The
SAR limit for mobile devices is 2W/kg and the
SAR value for this device when tested at the ear
was 0.666W/kg*.

As SAR is measured utilising the device’s highest
transmitting power, the actual SAR of this device
while operating is typically below that indicated
above. This is due to automatic changes to the
power level of the device to ensure it only uses the
minimum level required to reach the network.

The World Health Organization has stated that
present scientific information does not indicate

16

the need for any special precautions for the use of
mobile devices. They state that if you want to
reduce your exposure then you can do so by
limiting the length of calls or using a ‘hands-free’
device to keep the mobile phone away from the
head and body. Additional Information can be
found on the website of the World Health
Organization (http://www.who.int/emf).

* The tests are carried out in accordance with
international guidelines for testing.

Health and safety

The following Information is only for European
Union Member States:

The use of the above symbol indicates that this
product may not be treated as household waste.
By ensuring this product is disposed of correctly,
you will help prevent potential negative
consequences for the environment and human
health, which could otherwise be caused by
inappropriate waste handling of this product. For
more detailed information about recycling of this
product, please contact your local city office, your
household waste disposal service or the shop
where you purchased the product.
Please recycle the cardboard packaging supplied
with this phone.

Health and safety

17

Care and maintenance

Care and maintenance

General

You can greatly enhance the life span of your
Toshiba phone, and the parts and accessories,
by following the suggestions below.

TIP: Maintaining your Toshiba phone, and
the parts and accessories, in a good
condition will help you fulfil the warranty
obligations.

• Keep your Toshiba phone, and all the parts and

Care and maintenance

accessories, out of the reach of small children
and pets.

• Do not allow your Toshiba phone, battery or
accessories to come into contact with liquids or
moisture. Moisture of any kind can contain
minerals that will corrode the electronic circuits.
The manufacturer's warranty may become
invalid if the phone or battery get wet due to
misuse.

• Do not use or store your Toshiba phone in
dusty or dirty locations as the moving parts of
the phone can be damaged.

• Do not use or store your Toshiba phone in hot

18

areas. High temperatures will shorten the life

span of the phone, damage the battery, and
warp/melt internal circuits.

• Do not keep your Toshiba phone in, or near,
heat sources such as a radiator or microwave
oven - this can cause the battery inside the
phone to overheat and explode.

• Do not store your Toshiba phone in cold areas.
A big difference between room temperature
and the temperature in the phone can cause
condensation to form inside the phone,
damaging the electronic circuits.

• Do not open your Toshiba phone unless
absolutely necessary.

• Do not mishandle or abuse your Toshiba
phone. Dropping the phone, or knocking or
shaking it, can damage the internal circuits.

•When your Toshiba phone is set to vibrate, the
vibration may cause the phone to move. Take
care not to place the phone near a heat source
or the edge of a high surface.

• Only use a soft, clean, dry, anti-static cloth to
clean your Toshiba phone. Do not use
chemicals, detergents, or abrasive
substances.

Care and maintenance

• Do not use water to clean the LCD screen.

• Keep the LCD screen away from sharp objects
to avoid it being scratched and damaged.

• Do not remove the battery while the phone is
switched on.

• Do not leave the battery empty or disconnected
for a long time, as this may cause data to be
reset.

• Do not apply paint or other such substances to
your Toshiba phone.

• Interference may affect the performance of
your Toshiba phone. This is normal and the
phone should operate as usual once you move
away from the source of the interference.

• If your Toshiba phone, or any of the
accessories, are not working as they should,
please consult your dealer, who can provide
you with the expert assistance you require.

• Do not attempt to disassemble your Toshiba
phone. Only Toshiba authorised personnel
should service the phone.

Restarting your Toshiba
phone

If you have any problems, such as the phone
freezing, restart the phone.

To restart the phone:

1. Press and hold the Power key to switch off

the phone.

2. Wait a few seconds, then switch on the
phone.

IMPORTANT: If you restart your Toshiba
phone, data that you have not saved will be
lost.

If, after you have restarted your Toshiba phone,
there is still a problem:

1. Remove the battery (refer to Getting started
for instructions).

2. Re-insert the battery, then switch on the
phone on (refer to Getting started section for
instructions).

Care and maintenance

19

Care and maintenance

Resetting your Toshiba phone

For details of resetting your Toshiba phone, refer
to Master Clear in Settings.
We recommend that you back up all of your data
before resetting your Toshiba phone.

IMPORTANT: It is recommended that you
frequently back up the data on your
Toshiba phone.

Care and maintenance

20

n

Getting started

Getting started

Unpacking

Please ensure that the contents of your sales
pack include:

•Your Toshiba phone

•Battery

•AC charger

•USB cable

• Headset

•User guide

• CD (Getting Started)

NOTE: If any of the items listed above are
missing, contact the retailer where you
purchased your Toshiba phone.

Getting started

21

Getting started

1

2

3

6

9

13

14

15

16

5

4

7

8

12

10

11

Phone layout and functions

Getting started

22

1. Earpiece

2. Display screen

3. Left softkey and Right softkey - perform

operations indicated on the display.

4. Back/Clear key - returns to the previous

screen or deletes text.

5. End key - short press: ends calls/operations
and returns to Home Screen.
long press: locks the keypad.

6. Keypad

7. Messaging key - accesses Messaging
application.

8. Calendar key - accesses Calendar
application.

9. Microphone

10. Symbol key - accesses symbols when
entering or editing text.

11. Caps Shift key - short press: toggles
between text input sub-modes for entering
letter characters. See Text input section for
details.

Getting started

long press: used to enter upper case letters.
See Text input section for details.

12. Function key - short press: toggles between

text input modes when entering or editing text.
See Text input section for details.
long press: works in the same way as the Shift
key on a PC. See Text input section for
details.

13. Send key - short press: used to make,

answer and hold calls.
long press: activates speakerphone while in a
call.

14. Navigation/Action key - trackball type key

that moves the cursor, selects items and
confirms operations.

15. Home key - returns to Home Screen.

16. LED indicator (red) - on when phone is

charging.

Getting started

23

Getting started

17

21

18

19

22

20

Getting started

24

17. Volume Up key

18. Volume Down key

19. Cable, phone charging and headset
connector

20. Removable antenna interface

21. Camera key - launches Camera
application. If Camera application is already
running, captures a photo or begins recording
of a video clip.

22. Power key - short press: accesses Quick
List.
long press: switches phone on/off.

Getting started

25

23

24

23. Camera flash

24. Battery cover

25. Camera lens

Getting started

25

Getting started

n

Home Screen

The Home Screen displays important
information, such as upcoming appointments,
status indicators, current time, date and profile,
and icons for frequently used programs.

Getting started

You can open an application by selecting the
relevant icon.

To access the Home Screen, press the Home
key.

26

NOTE: To change the Home Screen
settings:

1. From the Home Screen, select Start >
More > Settings.

2. Select Display > Home Screen.

3. Change the settings as required.

Getting started

Common display indicators

Type Icon Description

Radio signal icons Signal strength

Call in progress

GPRS in use

EDGE in use

No radio signal

Phone set to Off. Refer to Switching radio transmission
on/off in Connectivity for details.

GPRS available

EDGE available

Roaming

Notification icons Missed call

New message(s) received (includes voice mail messages)*

New voice mail message received*

New instant message(s) received

Incoming beam

Call icons Call on hold

Speakerphone on

Calls forwarded

Getting started

27

Getting started

Type Icon Description

Other icons Missing or invalid SIM card

Alarm pending
Bluetooth set to On. Refer to Changing Bluetooth mode in

Getting started

Volume icons Vibrate for incoming calls

Battery icons Battery level

Text input mode (see Text
input section for details)

*The type of voice mail message indicator
displayed is dependent on your service provider.
Your service provider may also allow you to select
the type of voice mail notification that you receive.
Please contact your service provider for details.

28

Connectivity for details.

Ringer off for incoming calls

Battery level low

Battery charging

Text mode, lower case

Text mode, initial letter upper case, subsequent letters lower
case

Text mode, upper case

Numeric/Symbol mode, to input a single character

Numeric/Symbol mode, to input multiple characters

Getting started

Installing the SIM card and
battery

WARNING: There is a danger of explosion

!

if the battery is incorrectly replaced. To
reduce risk of fire or burns, do not
disassemble, crush, puncture, short
external contacts, expose to temperature
above 60°C (140°F), or dispose of battery
in fire or water. Replace only with specified
batteries according to the local regulations.

IMPORTANT: The SIM card is easily
damaged by scratching and bending, so
take care when handling it.

IMPORTANT: Keep SIM card away from
static, dust and water.

IMPORTANT: Power off the phone and
disconnect the charger before inserting or
removing the SIM card.

1. With the back of the phone facing up, press
down on the back cover. Slide the cover as
shown in the diagram below, and remove it
from the phone.

Getting started

2. If the battery is already installed, press at the
base of the battery and lift it out of the battery
compartment.

29
