et10
You’d swear it was right
in the room!
DLP™ and the DLP™-Badge
are registered trademarks
of Texas Instruments.
et20
High contrast: 1,500 : 1
DVD-player (et20)
Extreme wide angle thanks to Extreme Short Projection
5.1 Dolby Digital Surround Sound
Page 2
www.toshiba-europe.com/projectors
November 2006 • Subject to modifications and errors
Experience sharpness without limits!
For brilliant projection even in tight spaces.
et10
Display
0.55” DMD™ Chip
Resolution
real wide panel 854 x 480
Brightness
1,100 ANSI-lumens
Colour reproduction 16.7 mio. colours
Contrast
1,500 : 1
Projection format 16 : 9 switchable to 4 : 3
Lamp
230 / 200 W in ECO mode (TLPLET10LAMP)
Max. lamp life up to max. 2,000 hours/
up to max. 3.000 hours in ECO mode
Lens
F = 2.6 / f = 7.56 mm, manual focus
Frequency (hor./vertical)
15 - 82 kHz / 15 - 85 Hz
Projection
front, rear and ceiling
Digital keystone correction
vert. +/- 40°, horiz. +/- 30°
Picture size (diagonal)
0.65 m - 2.9 m
Projections distance
0.2 m - 1.6 m
Input signals NTSC/PAL/SECAM, 480i, 480p, 576i, 576p,
720p, 1.080i, VGA, SVGA, XGA, SXGA, UXGA
Inputs 1 x RGB (D-sub 15), composite video (1 x RCA),
S-video, component video ( 1 x Y/PB/PR), audio (mini jack),
digital coaxial, HDMI
Outputs
audio (mini jack), digital coaxial
Serial interface RS-232C, USB
Power supply AC 100 - 240 V, 50 / 60 Hz
Loudspeaker 5.1 Dolby Digital Surround
Dimensions (W x H x D)
344 x 155 x 322 mm
Weight et20: 5.0 kg, et10: 4.8 kg
Operation noise standard 36 dB / ECO mode 33 dB
Specials
extreme wide angle, all inputs at the front side,
Silicon Optix de-interlacer, et20: integrated DVD-player
Accessories
remote control with batteries, owners manual,
quick reference, power-cable, softcase, scart-adapter
Options
spare lamp
A
B
C
D
E
0.65 m 0.20 m
0.87 m 0.40 m
1.27 m 0.60 m
2.03 m 1.00 m
2.90 m 1.60 m
Projection distancePicture size
et20
only et20
Toshiba Europe GmbH
Projection & Display Technology
Phone: ++49-2131-158-01
e-mail: [email protected]
• Fax: ++49-2131-158-835
