Toshiba e-STUDIO230L, e-STUDIO280L, e-STUDIO282L, e-STUDIO200L, e-STUDIO203L Service Handbook

SERVICE HANDBOOK

MULTIFUNCTIONAL DIGITAL SYSTEMS

e-STUDIO200L/230/280

e-STUDIO202L/232/282

e-STUDIO203L/233/283

Model: DP-2020/2050/2320/2330/2340/2820/2830/2840 Publish Date: June 2004 File No. SHE040003M0 R04022143002-TTEC Ver13_2007-11

Trademarks

• The official name of Windows 95 is Microsoft Windows 95 Operating System.

• The official name of Windows 98 is Microsoft Windows 98 Operating System.

• The official name of Windows Me is Microsoft Windows Millennium Edition Operating System.

• The official name of Windows 2000 is Microsoft Windows 2000 Operating System.

• The official name of Windows XP is Microsoft Windows XP Operating System.

• Microsoft, Windows, Windows NT and the brand names and product names of other Microsoft products are trademarks or registered trademarks of Microsoft Corporation in the U.S. and/or other countries.

• Apple, AppleTalk, Macintosh, and Mac are trademarks of Apple Computer, Inc. in the U.S. and other countries.

• PostScript is a trademark of Adobe Systems Incorporated.

• NOVELL, NetWare, and NDS are trademarks or registered trademarks of Novell, Inc.

• Molykote is a registered trademark of Dow Corning Corporation.

• Other company names and product names in this manual are the trademarks of their respective companies.

Under the copyright laws, this manual cannot be reproduced in any form without prior written permission of TOSHIBA TEC CORPORATION. No patent liability is assumed, however, with respect to the use of the information contained herein.

GENERAL PRECAUTIONS REGARDING THE SERVICE FOR e-STUDIO200L/202L/203L/230/232/233/280/282/283 SERIES

The installation and service should be done by a qualified service technician.

1) Transportation/Installation

- When transporting/installing the equipment, employ two persons and be sure to hold the posi-

tions as shown in the figure. The equipment is quite heavy and weighs approximately 75 kg (165.34 lb.) therefore pay full attention when handling it.

- Be sure not to hold the movable parts or units (e.g. the control panel, ADU or RADF) when trans-

porting the equipment.

- Be sure to use a dedicated outlet with AC 110 V / 13.2 A, 115 V or 127 V / 12 A, 220-240 V or 240

V / 8 A for its power source.

- The equipment must be grounded for safety.

- Select a suitable place for installation. Avoid excessive heat, high humidity, dust, vibration and

direct sunlight.

- Provide proper ventilation since the equipment emits a slight amount of ozone.

- To insure adequate working space for the copying operation, keep a minimum clearance of 80

cm (32”) on the left, 80 cm (32”) on the right and 10 cm (4”) on the rear.

- The equipment shall be installed near the socket outlet and shall be accessible.

- Be sure to fix and plug in the power cable securely after the installation so that no one trips over

it.

07/11

2) General Precautions at Service

- Be sure to turn the power OFF and unplug the power cable during service (except for the service

should be done with the power turned ON).

- Unplug the power cable and clean the area around the prongs of the plug and socket outlet once

a year or more. A fire may occur when dust lies on this area.

- When the parts are disassembled, reassembly is the reverse of disassembly unless otherwise

noted in this manual or other related documents. Be careful not to install small parts such as screws, washers, pins, E-rings, star washers in the wrong places.

- Basically, the equipment should not be operated with any parts removed or disassembled.

- The PC board must be stored in an anti-electrostatic bag and handled carefully using a wristband

since the ICs on it may be damaged due to static electricity.

- Avoid expose to laser beam during service. This equipment uses a laser diode. Be sure not to

expose your eyes to the laser beam. Do not insert reflecting parts or tools such as a screwdriver on the laser beam path. Remove all reflecting metals such as watches, rings, etc. before starting service.

- Be sure not to touch high-temperature sections such as the exposure lamp, fuser unit, damp

heater and areas around them.

- Be sure not to touch high-voltage sections such as the chargers, developer, high-voltage trans-

former, exposure lamp control inverter, inverter for the LCD backlight and power supply unit. Especially, the board of these components should not be touched since the electric charge may remain in the capacitors, etc. on them even after the power is turned OFF.

- Make sure that the equipment will not operate before touching potentially dangerous places (e.g.

rotating/operating sections such as gears, belts pulleys, fans and laser beam exit of the laser optical unit).

- Be careful when removing the covers since there might be the parts with very sharp edges

underneath.

- When servicing the equipment with the power turned ON, be sure not to touch live sections and

rotating/operating sections. Avoid exposing your eyes to laser beam.

- Use designated jigs and tools.

- Use recommended measuring instruments or equivalents.

- Return the equipment to the original state and check the operation when the service is finished.

- Be very careful to treat the touch panel gently and never hit it. Breaking the surface could cause

malfunctions.

3) Important Service Parts for Safety

- The breaker, door switch, fuse, thermostat, thermofuse, thermistor, batteries, IC-RAMs including

lithium batteries, etc. are particularly important for safety. Be sure to handle/install them properly. If these parts are short-circuited and their functions become ineffective, they may result in fatal accidents such as burnout. Do not allow a short-circuit or do not use the parts not recommended by Toshiba TEC Corporation.

4) Cautionary Labels

- During servicing, be sure to check the rating plate and cautionary labels such as “Unplug the

power cable during service”, “CAUTION. HOT”, “CAUTION. HIGH VOLTAGE”, “CAUTION. LASER BEAM”, etc. to see if there is any dirt on their surface and if they are properly stuck to the equipment.

Caution: Before using the wristband, unplug the power cable of the equipment and

make sure that there are no charged objects which are not insulated in the vicinity.

06/09

5) Disposal of the Equipment, Supplies, Packing Materials, Used Batteries and IC-RAMs

- Regarding the recovery and disposal of the equipment, supplies, packing materials, used batter-

ies and IC-RAMs including lithium batteries, follow the relevant local regulations or rules.

Caution:

Dispose of used batteries and IC-RAMs including lithium batteries according to this manual.

Attention:

Se débarrasser de batteries et IC-RAMs usés y compris les batteries en lithium selon ce manuel.

Vorsicht:

Entsorgung der gebrauchten Batterien und IC-RAMs (inclusive der Lithium-Batterie) nach diesem Handbuch.

05/11

CONTENTS

1

CONTENTS

1. SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES ................................... 1-1

1.1 Specifications....................................................................................................................... 1-1

1.2 Accessories ......................................................................................................................... 1-6

1.3 Options ................................................................................................................................ 1-7

1.3.1 e-STUDIO200L/230/230L/280/280S ........................................................................ 1-7

1.3.2 e-STUDIO202L/203L/232/232S/233/282/282S/283/283S ....................................... 1-8

1.4 Supplies............................................................................................................................. 1-10

1.4.1 e-STUDIO200L/230/230L/280/280S ...................................................................... 1-10

1.4.2 e-STUDIO202L/232/232S/282/282S ...................................................................... 1-10

1.4.3 STUDIO203L/233/283/283S .................................................................................. 1-10

1.5 System List ........................................................................................................................ 1-11

1.5.1 e-STUDIO200L/230/230L/280/280S ...................................................................... 1-11

1.5.2 e-STUDIO202L/203L/232/232S/233/282/282S/283/283S ..................................... 1-17

2. ERROR CODE AND SELF-DIAGNOSTIC MODE........................................................ 2-1

2.1 Error Code List..................................................................................................................... 2-1

2.1.1 Jam........................................................................................................................... 2-1

2.1.2 Service call ...............................................................................................................2-7

2.1.3 Error in Internet FAX / Scanning Function.............................................................. 2-10

2.1.4 Printer function error............................................................................................... 2-20

2.2 Self-diagnosis Modes ........................................................................................................ 2-23

2.2.1 Input check (Test mode 03) (e-STUDIO200L/230/280).......................................... 2-25

2.2.2 Input check (Test mode 03) (e-STUDIO202L/203L/232/233/282/283)................... 2-32

2.2.3 Output check (test mode 03) .................................................................................. 2-40

2.2.4 Test print mode (test mode 04) .............................................................................. 2-43

2.2.5 Adjustment mode (05) (e-STUDIO200L/230/280) .................................................. 2-44

2.2.6 Adjustment mode (05) (e-STUDIO202L/203L/232/233/282/283) ........................... 2-64

2.2.7 Setting mode (08) (e-STUDIO200L/230/280)......................................................... 2-84

2.2.8 Setting mode (08) (e-STUDIO202L/203L/232/233/282/283)................................ 2-153

2.2.9 Pixel counter......................................................................................................... 2-262

2.2.10 Classification List of Adjustment Mode (05) / Setting Mode (08)

(e-STUDIO200L/230/280) .................................................................................... 2-272

2.2.11 Classification List of Adjustment Mode (05) / Setting Mode (08)

(e-STUDIO202L/203L/232/233/282/283) ............................................................. 2-276

3. ADJUSTMENT ..............................................................................................................3-1

3.1 Adjustment of Auto-Toner Sensor ....................................................................................... 3-1

3.2 Image Dimensional Adjustment........................................................................................... 3-3

3.2.1 General description .................................................................................................. 3-3

3.2.2 Paper alignment at the registration roller ................................................................. 3-5

3.2.3 Printer related adjustment ........................................................................................ 3-7

3.2.4 Scanner related adjustment ................................................................................... 3-12

3.3 Image Quality Adjustment (Copying Function) .................................................................. 3-21

3.3.1 Density adjustment ................................................................................................. 3-21

3.3.2 Gamma slope adjustment ...................................................................................... 3-22

3.3.3 Sharpness adjustment............................................................................................ 3-23

3.3.4 Setting range correction ......................................................................................... 3-24

3.3.5 Setting range correction (Adjustment of background peak) ................................... 3-24

3.3.6 Adjustment of smudged/faint text ........................................................................... 3-25

3.3.7 Gamma balance adjustment < e-STUDIO 202L/203L/232/233/282/283 > ............ 3-25

3.3.8 Adjustment of image density .................................................................................. 3-26

3.4 Image Quality Adjustment (Printing Function) ................................................................... 3-27

3.4.1 Adjustment of smudged/faint text ........................................................................... 3-27

05/12

2

3.4.2 Adjustment of image density .................................................................................. 3-28

3.5 Image Quality Adjustment (Scanning Function) ................................................................ 3-29

3.5.1 Density adjustment ................................................................................................. 3-29

3.5.2 Sharpness adjustment............................................................................................ 3-30

3.5.3 Setting range correction ......................................................................................... 3-31

3.5.4 Setting range correction (Adjustment of background peak) ................................... 3-32

3.5.5 Setting range correction (Adjustment of text peak) ................................................ 3-32

3.6 Adjustment of High-Voltage Transformer .......................................................................... 3-33

3.6.1 Adjustment ............................................................................................................. 3-33

3.6.2 Precautions ............................................................................................................ 3-39

3.7 Adjustment of the Scanner Section ................................................................................... 3-41

3.7.1 Carriages ................................................................................................................ 3-41

3.7.2 Lens unit................................................................................................................. 3-46

3.8 Adjustment of the Paper Feeding System ......................................................................... 3-49

3.8.1 Sheet sideways deviation caused by paper feeding .............................................. 3-49

3.9 Adjustment of Developer Unit ............................................................................................ 3-50

3.9.1 Doctor-to-sleeve gap .............................................................................................. 3-50

3.10 Adjustment of the RADF (MR-3016).................................................................................. 3-53

3.10.1 Adjustment of RADF position ................................................................................. 3-53

3.10.2 Adjustment of RADF height .................................................................................... 3-57

3.10.3 Adjustment of skew ................................................................................................ 3-59

3.10.4 Automatic adjustment of sensors and initialization of EEPROM ............................ 3-61

3.10.5 Adjustment of aligning ............................................................................................ 3-62

3.10.6 Adjustment of aligning at reversing ........................................................................ 3-63

3.10.7 Adjustment of reverse solenoid .............................................................................. 3-64

3.10.8 Adjustment of RADF opening/closing switch.......................................................... 3-66

3.10.9 Adjustment of RADF opening/closing sensor ......................................................... 3-67

3.10.10Adjustment of tray volume ..................................................................................... 3-68

3.11 Adjustment of the RADF (MR-3020).................................................................................. 3-69

3.11.1 Adjustment of RADF Position ................................................................................. 3-69

3.11.2 Adjustment of RADF Height ................................................................................... 3-74

3.11.3 Adjustment of Skew................................................................................................ 3-76

3.11.4 Adjustment of the Leading Edge Position .............................................................. 3-79

3.11.5 Adjustment of Horizontal Position .......................................................................... 3-80

3.11.6 Adjustment of Copy Ratio....................................................................................... 3-82

3.11.7 Adjustment of RADF Opening/Closing Sensor....................................................... 3-83

3.12 Adjustment of the Finisher (MJ-1022)................................................................................ 3-84

3.12.1 Adjusting the jogging plate width............................................................................ 3-84

3.12.2 Adjusting the angle of the jogging plate ................................................................. 3-86

3.12.3 Adjusting the overlap of the sensor flag ................................................................. 3-87

3.12.4 Adjusting the tension of the stack processing motor belt ....................................... 3-88

3.12.5 Releasing the stack tray guide lever fixing plate .................................................... 3-90

3.12.6 Adjustment of the upper tray angle ........................................................................ 3-91

3.12.7 DIP switch functions ............................................................................................... 3-93

3.13 Adjustment of the Finisher (MJ-1025)................................................................................ 3-95

3.13.1 Adjusting the folding position (Electrical system (Finisher/Saddle unit)) ................3-95

3.13.2 Adjusting the sensor output (Electrical system (Puncher unit; option)) .................. 3-96

3.13.3 Registering the number of punch hole

(Electrical system (Puncher unit; option))............................................................... 3-97

3.13.4 After replacing the EEP-ROM

(IC1002) (Electrical system (Puncher unit; option))................................................ 3-98

3.14 Key Copy Counter (MU-8, MU-10) .................................................................................... 3-99

3.15 Adjustment of Dogleg ...................................................................................................... 3-101

4. PREVENTIVE MAINTENANCE (PM)............................................................................ 4-1

4.1 PM Support Mode................................................................................................................ 4-1

CONTENTS

3

4.1.1 General description .................................................................................................. 4-1

4.1.2 Operational flow and operational screen .................................................................. 4-1

4.1.3 Work flow of parts replacement ................................................................................ 4-6

4.2 General Descriptions for PM Procedure.............................................................................. 4-7

4.3 Operational Items in Overhauling ........................................................................................ 4-8

4.4 Preventive Maintenance Checklist....................................................................................... 4-9

4.5 PM KIT............................................................................................................................... 4-25

4.6 Jig List ............................................................................................................................... 4-26

4.7 Grease List ........................................................................................................................ 4-27

4.8 Precautions for Storing and Handling Supplies ................................................................. 4-28

4.8.1 Precautions for storing TOSHIBA supplies ............................................................ 4-28

4.8.2 Checking and cleaning of photoconductive drum................................................... 4-29

4.8.3 Checking and cleaning of drum cleaning blade...................................................... 4-30

4.8.4 Checking and cleaning of fuser roller and pressure roller ...................................... 4-30

4.8.5 Checking and replacing the cleaning roller ............................................................ 4-30

5. TROUBLESHOOTING ..................................................................................................5-1

5.1 Diagnosis and Prescription for Each Error Code ................................................................. 5-1

5.1.1 Paper transport jam .................................................................................................. 5-1

5.1.2 Paper misfeeding ................................................................................................... 5-15

5.1.3 Cover open jam ...................................................................................................... 5-22

5.1.4 Transport jam (RADF) ............................................................................................ 5-28

5.1.5 Finisher jam............................................................................................................ 5-35

5.1.6 Drive system related service call ............................................................................ 5-47

5.1.7 Paper feeding system related service call .............................................................. 5-48

5.1.8 Scanning system related service call ..................................................................... 5-54

5.1.9 Fuser unit related service call................................................................................. 5-56

5.1.10 Communication related service call........................................................................ 5-58

5.1.11 RADF related service call (MR-3016)..................................................................... 5-59

5.1.12 RADF related service call (MR-3020)..................................................................... 5-60

5.1.13 Laser optical unit related service call ..................................................................... 5-60

5.1.14 Finisher related service call.................................................................................... 5-61

5.1.15 Service call for others............................................................................................. 5-76

5.1.16 Error in Internet FAX / Scanning Function.............................................................. 5-79

5.2 Troubleshooting for the Image........................................................................................... 5-94

5.3 Replacement of PC Boards and HDD ............................................................................. 5-116

5.3.1 Replacing HDD..................................................................................................... 5-116

5.3.2 Replacing SYS board ........................................................................................... 5-119

5.3.3 Caution when Data overwrite kit (GP-1050/1060) is installed ............................. 5-121

5.3.4 HDD information display....................................................................................... 5-121

5.3.5 Replacing or clearing NVRAM.............................................................................. 5-124

6. FIRMWARE UPDATING ...............................................................................................6-1

6.1 Firmware Updating with Download Jig (e-STUDIO200L/230/280) ...................................... 6-3

6.1.1 PWA-DWNLD-350-JIG2 (48 MB) ............................................................................. 6-5

6.1.2 PWA-DWNLD-350-JIG1 (16 MB) ........................................................................... 6-12

6.1.3 Writing the data to the download jig (PWA-DWNLD-350-JIG) ............................... 6-21

6.1.4 K-PWA-DLM-320.................................................................................................... 6-22

6.2 Firmware Updating with Download Jig (e-STUDIO202L/203L/232/233/282/283) ............. 6-32

6.2.1 PWA-DWNLD-350-JIG2 (48 MB) ........................................................................... 6-34

6.2.2 Writing the data to the download jig (PWA-DWNLD-350-JIG) ............................... 6-48

6.2.3 K-PWA-DLM-320.................................................................................................... 6-50

6.3 Firmware Updating with FSMS (Field Service Manager) (e-STUDIO200L/230/280) ........ 6-60

6.4 Firmware Updating with USB Storage Device (e-STUDIO200L/230/280)......................... 6-72

6.5 Firmware Updating with USB Storage Device

(e-STUDIO202L/203L/232/233/282/283)........................................................................... 6-86

06/09

4

6.6 Appendix.......................................................................................................................... 6-109

6.6.1 e-STUDIO200L/230/280....................................................................................... 6-109

6.6.2 e-STUDIO202L/203L/232/233/282/283................................................................ 6-110

7. POWER SUPPLY UNIT ................................................................................................ 7-1

7.1 Output Channel ................................................................................................................... 7-1

7.2 Fuse..................................................................................................................................... 7-3

7.3 Configuration of Power Supply Unit..................................................................................... 7-4

8. REMOTE SERVICE....................................................................................................... 8-1

8.1 Auto Supply Order ............................................................................................................... 8-1

8.1.1 Outline ...................................................................................................................... 8-1

8.1.2 Setting Item .............................................................................................................. 8-2

8.1.3 Setting procedure ..................................................................................................... 8-5

8.1.4 Order Sheet Format ............................................................................................... 8-12

8.2 Service Notification............................................................................................................ 8-14

8.2.1 Outline ....................................................................................................................8-14

8.2.2 Setting (e-STUDIO200L/230/280) .......................................................................... 8-14

8.2.3 Items to be notified (e-STUDIO200L/230/280) ....................................................... 8-19

8.2.4 Setting (e-STUDIO202L/203L/232/233/282/283) ................................................... 8-24

8.2.5 Items to be notified (e-STUDIO202L/203L/232/233/282/283) ................................ 8-30

9. DATA CLONING with USB STORAGE DEVICE

(e-STUDIO202L/203L/232/233/282/283) ...................................................................... 9-1

10. WIRE HARNESS CONNECTION DIAGRAMS ........................................................... 10-1

10.1 AC Wire Harness ............................................................................................................... 10-1

10.2 DC Wire Harness (e-STUDIO200L/230/230L/280/280S) .......................................... Appendix

10.3 Connector Table (e-STUDIO200L/230/230L/280/280S)............................................ Appendix

10.4 DC Wire Harness (e-STUDIO202L/232/282)............................................................. Appendix

10.5 Connector Table (e-STUDIO202L/232/282) .............................................................. Appendix

05/11

1

2

3

4

5

6

7

8

9

10

1. SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES

2. ERROR CODE AND SELF-DIAGNOSTIC MODE

3. ADJUSTMENT

4. PREVENTIVE MAINTENANCE (PM)

5. TROUBLESHOOTING

6. FIRMWARE UPDATING

7. POWER SUPPLY UNIT

8. REMOTE SERVICE

9. DATA CLONING with USB STORAGE DEVICE (e-STUDIO202L/203L/232/233/282/283)

10. WIRE HARNESS CONNECTION DIAGRAMS

SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES

1 - 1

1

1. SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES

1.1 Specifications

Copy process Indirect electrophotographic process (dry) Type Desktop type (console type: when paper feed pedestal (PFP) and large

capacity feeder (LCF) are installed)

Original table Fixed type (the left rear corner used as guide to place originals) Accepted originals Sheet, book and 3-dimensional object. The reversing automatic document

feeder (RADF) only accepts paper which are not pasted or stapled. Carbon paper are not acceptable either. Maximum size: A3/LD

Copy speed (Copies/min.) e-STUDIO200L/202L/203L

e-STUDIO230/230L/232/232S/233

e-STUDIO280/280S/282/282S/283/283S

* “–” means “Not acceptable”. * The copy speed in the above table are available when originals are manually placed for single side,

multiple copying.

Values in { } are for e-STUDIO200L/202L/203L and values in [ ] are for e- STUDIO280/280S/282/ 282S/283/283S in case that the specification is different among e-STUDIO200L/202L/203L, e-STUDIO230/230L/232/232S/233 and e-STUDIO280/280S/282/282S/283/283S.

Single - sided original Double - sided original

MR-3016

50 ~ 127 g/m

2

(13 lb. Bond - 34 lb. Bond) 50 ~ 105 g/m2 (13 lb. Bond - 28 lb. Bond)

MR-3018

35 ~ 157 g/m

2

(9.3 lb. Bond - 58 lb. Cover) 50 ~ 157 g/m2 (13 lb. Bond - 58 lb. Cover)

Paper size Drawer

Bypass feed

PFP LCF

Size specified Size not specified

A4, LT, B5, A5-R, ST-R 20 20 16 20 20

A4-R, B5-R, LT-R 19 19 16 19 –

B4, LG 18 18 16 18 –

A3, LD 16 16 16 16 –

Paper size Drawer

Bypass feed

PFP LCF

Size specified Size not specified

A4, LT, B5, A5-R, ST-R 23 23 16 23 23

A4-R, B5-R, LT-R 21.5 21.5 16 21.5 –

B4, LG 18 18 16 18 –

A3, LD 16 16 16 16 –

Paper size Drawer

Bypass feed

PFP LCF

Size specified Size not specified

A4, LT, B5, A5-R, ST-R 28 28 16 28 28

A4-R, B5-R, LT-R 21.5 21.5 16 21.5 –

B4, LG 18 18 16 18 –

A3, LD 16 16 16 16 –

07/11

1 - 2

* When the RADF is used, the copy speed of {20}23[28] sheets per minute is only available under the

following conditions:

• Original/Mode: Single side original/A4/LT size. APS/automatic density are not selected.

• Number of sheets: {20}23[28] or more.

• Reproduction ratio: 100%

Copy speed for thick paper (Copies/min.) e-STUDIO200L/202L/203L/230/232/233/280/282/283 series

Thick 1 (81 g/m

2

to 105 g/m2, 21.3 lb. Bond to 28 lb. Bond)

Thick 2 (106 g/m

2

to 163 g/m2, 28 lb. Bond to 90 lb. Index)

Thick 3 (164 g/m

2

to 209 g/m2, 90 lb. Index to 115.7 lb. Index)

* Only A4/LT size is available for the LCF. * The tolerance is within ±2.

Paper size Drawer

Bypass feed

PFP LCF

Size specified Size not specified

A4, LT, B5, A5-R, ST-R {20} 23 [27] {20} 23 [27] {15} 16 [16] {20} 23 [27] {20} 23 [27]

A4-R, B5-R, LT-R {19} 21 [21] {19} 21 [21] {15} 16 [16] {19} 21 [21] {-} - [-]

B4, LG {18} 18 [18] {18} 18 [18] {15} 16 [16] {18} 18 [18] {-} - [-]

A3, LD {15} 16 [16] {15} 16 [16] {15} 16 [16] {15} 16 [16] {-} - [-]

Paper size Drawer

Bypass feed

PFP LCF

Size specified Size not specified

A4, LT, B5, A5-R, ST-R {-} - [-] {20} 23 [27] {15} 16 [16] {-} - [-] {-} - [-]

A4-R, B5-R, LT-R {-} - [-] {19} 21 [21] {15} 16 [16] {-} - [-] {-} - [-]

B4, LG {-} - [-] {18} 18 [18] {15} 16 [16] {-} - [-] {-} - [-]

A3, LD {-} - [-] {15} 16 [16] {15} 16 [16] {-} - [-] {-} - [-]

Paper size Drawer

Bypass feed

PFP LCF

Size specified Size not specified

A4, LT, B5, A5-R, ST-R {-} - [-] {20} 23 [27] {15} 16 [16] {-} - [-] {-} - [-]

A4-R, B5-R, LT-R {-} - [-] {19} 21 [21] {15} 16 [16] {-} - [-] {-} - [-]

B4, LG {-} - [-] {18} 18 [18] {15} 16 [16] {-} - [-] {-} - [-]

A3, LD {-} - [-] {15} 16 [16] {15} 16 [16] {-} - [-] {-} - [-]

07/11

SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES

1 - 3

1

* System copy speed

* The system copy speed, including scanning time, is available when 10 sheets of A4/LT size original

are set on RADF and one of the copy modes in the above table is selected. The period of time from pressing [START] to the paper exit completely out of the equipment based on the actually measured

value. * Upper drawer is selected and copying is at the non-sort mode. * Automatic copy density, APS/AMS are turned off. * Finisher is not installed.

Copy paper

First copy time ......................... Approx. 5.4 sec. or less

(A4/LT, upper drawer, 100%, original placed manually)

Warming-up time ..................... Approx. 25 sec. (temperature: 20°C)

Multiple copying....................... Up to 999 copies; Key in set numbers

Reproduction ratio ................... Actual ratio: 100±0.5%

Zooming: 25 to 400% in increments of 1%

(25 to 200% when using RADF)

Resolution/Gradation............... Scanning: 600 dpi x 600 dpi

Printing: Equivalent to 2400 dpi x 600 dpi Gradation: 256 steps

Copy mode

Sec.

e-STUDIO200L/202/

203L

e-STUDIO230/230L/

232/232S/233

e-STUDIO280/280S/

282/282S/283/283S

Single-sided originals

↓

Single-sided copies

1 set 3 sets 5 sets

34.18

95.53

154.28

31.5

84.8

136.2

27.6

72.2

114 .0

Single-sided originals

↓

Double-sided copies

1 set 3 sets 5 sets

37.44

96.81

155.54

34.5

85.9

137.4

31.6

73.4

116 .4

Double-sided originals

↓

Double-sided copies

1 set 3 sets 5 sets

70.26

188.48

306.64

64.8

167.7

270.6

58.9

143.8

228.5

Double-sided originals

↓

Single-sided copies

1 set 3 sets 5 sets

64.65

184.73

302.58

57.8

163.1

266.1

50.5

137.3

222.1

Drawer ADU PFP LCF Bypass copy Remarks

Size A3 to A5-R, LD to ST-R,

FOLIO, COMPUTER,

13"LG, 8.5" x 8.5", 8K,

16K, 16K-R

A4, LT A3 to A5-R, LD to ST-R, FOLIO,

COMPUTER, 13"LG, 8.5" x 8.5", 8K, 16K, 16K-R (Non-standard or user-specified sizes can be set.)

Weight

64 to 105 g/m

2

17 to 28 lb. Bond

64 to 209 g/m

2

, 17 lb. Bond to 110 lb. Index (Continuous feeding)

50 to 209 g/m2, 13 lb. Bond to 110 lb. Index (Single paper feeding)

Special

paper

– Tracing paper, labels,

OHP film (thickness: 80 µm or thicker), tab paper, envelope (COM10, Monarch, DL, CHO-3, YOU-4)

These special papers recommended by Toshiba Tec CHO-3: 92 mm x 235 mm YOU-4: 105 mm x 235 mm

07/11

1 - 4

Eliminated portion.................... Leading edges: 3.0±2.0 mm, Side/trailing edges: 2.0±2.0 mm (copy)

Leading / trailing edges: 5.0±2.0 mm, Side edges: 5.0±2.0 mm (print)

Paper feeding .......................... Standard drawers:

1 or 2 drawers (stack height 60.5 mm, equivalent to 550 sheets; 64 to 80 g/m

2

(17 to 22 lb. Bond)): Depends on destinations or

versions.

PFP:

Option (One drawer or two: stack height 60.5 mm, equivalent to 550 sheets; 64 to 80 g/m

2

(17 to 22 lb. Bond))

LCF:

Option (Stack height 137.5 mm x 2: equivalent to 2500 sheets; 64 to 80 g/m

2

(17 to 22 lb. Bond))

Bypass feeding:

Stack height 11 mm: equivalent to 100 sheets; 64 to 80 g/m

2

(17

to 22 lb. Bond)

Capacity of originals in the reversing automatic document feeder (Option)

.................................................. A3 to A5-R, LD to ST-R:

100 sheets / 80 g/m

2

(Stack height 16 mm or less)

Automatic duplexing unit (ADU is available as standard equipment for some destinations or versions.)

.................................................. Stackless, Switchback type

Toner supply............................ Automatic toner density detection/supply

Toner cartridge replacing method (There is a recovered toner supply mechanism.)

Density control......................... Automatic density mode and manual density mode selectable in 11

steps

Weight ..................................... Approximately 75 kg (165.34 lb.): e-STUDIO200L/230/230L/280/280S

Approximately 77 kg (169.75 lb.): e-STUDIO202L/203L/232/233/232S/ 282/282S/283 (include the developer material and drum) (The ADU and Drawer module are installed.)

Power requirements ................ AC 110 V / 13.2 A, 115 V or 127 V / 12 A

220-240 V or 240 V / 8 A (50/60 Hz)

* The acceptable value of each voltage is ±10%.

Power consumption................. 1.5 kW or less (115 V series, 200 V series)

* The electric power is supplied to the RADF, (ADU), Finisher, Job Separator, Offset Tray, PFP and

LCF through the equipment.

Total counter............................ Electronical counter

07/11

SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES

1 - 5

1

Dimensions of the equipment...................... See the figure below (W 637 x D 719 x H 739 (mm))

* When the tilt angle of the control panel is 45 degrees.

Fig. 1-1

719

739

637

45°

04/09

1 - 6

1.2 Accessories

Machine version

NAD: North America ARD: Argentina ASD: Central and South America / Hong Kong AUD: Australia MJD: Europe ASU: Asia SAD: Saudi Arabia IRD: Iran CND: China TWD: Taiwan JPD: Japan KRD: Korea

*1: e-STUDIO200L/230/230L/280/280S only *2: In e-STUDIO202L/203L/232/232S/233/282/282S/283, 2 discs are included.

Unpacking/setup instruction 1 set

Operator’s manual 3 pcs. (except for MJD)

Operator's manual pocket 1 pc.

Power cable 1 pc.

Warranty sheet 1 pc. (for NAD)

Setup report 1 set (for NAD and MJD)

Customer satisfaction card 1 pc. (for MJD)

Drum (installed inside of the equipment) 1 pc.

Toner cartridge 1 pc. (except for NAD, MJD)

Developer material 1 pc. (except for NAD, MJD)

Control panel stopper 1 pc.

Blind seal 1 pc.

Rubber plug 5 pcs.

CD-ROM

4 pcs.

*2

Transfer charger wire cleaner (installed inside of the transfer cover)

1 pc.

Paper stopper

*1

1 pc.

Stopper bracket

*1

1 pc.

07/11

SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES

1 - 7

1

1.3 Options

1.3.1 e-STUDIO200L/230/230L/280/280S

* 1) N: North America E: Europe F: France S: Sweden

Notes:

• The bridge unit (KN-3520) is necessary for installation of the finisher (MJ-1022, MJ-1025).

• The finisher (MJ-1025) is necessary for installation of the hole punch unit (MJ-6005N/E/F/S).

• The PCI slot (GO-1040) is necessary for installation of the scrambler board (GP-1030) and parallel interface kit (GF-1140).

• GM-1030/GM-2030/GM-3030 are exclusive for e-STUDIO200L. They do not operate with e-STUDIO230/230L/280/280S.

Platen Cover KA-3511 PC/PC-C

Reversing Automatic Document Feeder (RADF) MR-3016

Drawer Module MY-1021/-C

Paper Feed Pedestal (PFP) KD-1011/-C

Large Capacity Feeder (LCF) KD-1012 A4/LT/A4-C

Finisher (Hanging type) MJ-1022/-C

Saddle stitch Finisher MJ-1025/-C

Hole Punch Unit

MJ-6005 N/E/F/S

*1

Staple Cartridge STAPLE-1600 (for MJ-1022)

STAPLE-2000 (for MJ-1025)

Bridge Kit KN-3520/-C

Job Separator MJ-5004/-C

Offset Tray MJ-5005/-C

Key copy Counter, Key copy counter socket MU-8, MU-10

Work Tray KK-3511

Damp Heater MF-2320 U/E

Fax Board GD-1150 NA/AU/EU/TW/C/AS

2nd Line for Fax Board GD-1160 NA/EU/TW/C

Wireless LAN Adapter GN-1010

PCI Slot GO-1040/C

Scrambler Board GP-1030

Printer Kit GM-1020/GM-1030

Printer/Scanner Kit GM-2020/GM-2030

Scanner upgrade Kit GM-3020/GM-3030

Parallel interface kit GF-1140

Desk MH-1700

Harness kit for coin controller GQ-1020

Automatic Duplexing Unit (ADU) MD-0102

Slot cover KE-2330

NIC board GF-1150

Data overwrite kit GP-1050

05/11

1 - 8

1.3.2 e-STUDIO202L/203L/232/232S/233/282/282S/283/283S

* 1) N: North America E: Europe F: France S: Sweden

Platen Cover KA-3511PC/-C

Reversing Automatic Document Feeder (RADF) MR-3020

Automatic Duplexing Unit (ADU) MD-0102

Drawer module MY-1021/-C

Slot cover KE-2330

Paper Feed Pedestal (PFP) KD-1011/-C

Large Capacity Feeder (LCF) KD-1012LT/A4/A4-C

Finisher (Hanging type) MJ-1022/-C

Finisher (Console saddle stitcher type) MJ-1025

Hole punch unit (for MJ-1025)

MJ-6005N/E/F/S

*1

Staple cartridge STAPLE-1600 (for MJ-1022)

STAPLE-2000 (for MJ-1025)

Bridge kit KN-3520/-C

Job separator MJ-5004/-C

Offset tray MJ-5005/-C

Work tray KK-3511/-C

Damp heater MF-3520U/E

Fax board GD-1150NA/EU/AU/AS/C/TW

2nd line for fax board GD-1160NA/EU-N/C/TW

Printer kit GM-1070/1071/1080U/1081U

Printer/Scanner kit GM-2070/2071/2080U/2081U

Scanner kit GM-4070/GM-4080U

Printer ELK GM-1130 (e-STUDIO232/232S/233/

282/282S/283/283S) GM-1140U (e-STUDIO202L/203L)

Printer/Scanner ELK GM-2130 (e-STUDIO232/232S/233/

282/282S/283/283S) GM-2140U (e-STUDIO202L/203L)

Scanner ELK GM-4130 (e-STUDIO232/232S/233/

282/282S/283/283S) GM-4140U (e-STUDIO202L/203L)

Memory GC-1230

Scrambler board GP-1040

Wireless LAN module GN-1041

Bluetooth module GN-2010

Antenna GN-3010

Data overwrite kit GP-1060

PCI slot GO-1060

Desk MH-1700

Harness kit for coin controller GQ-1020

07/11

SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES

1 - 9

1

Notes:

1. The bridge kit (KN-3520) is necessary for installation of the finisher (MJ-1022 or MJ-1025).

2. The saddle stitch finisher (MJ-1025) is necessary for installation of the hole punch unit (MJ-6005N/E/F/S).

3. The PCI slot (GO-1060) is necessary for installation of the scrambler board (GP-1040).

4. The antenna (GN-3010) is necessary to enable the wireless LAN module (GN-1041) and Bluetooth module (GN-2010).

5. When the wireless LAN module (GN-1041) and the Bluetooth module (GN-2010) are installed, only 1 antenna (GN-3010) can be connected to each.

6. GM-1080U / GM-2080U / GM-4080U are exclusive to e-STUDIO202L. They do not operate with e-STUDIO232/232S/282/282S.

7. GM-1081U / GM-2081U / GM-4080U are exclusive to e-STUDIO202L/203L. They do not operate with e-STUDIO232/232S/233/282/282S/283.

8. The Printer kit (GM-1070/1080U) or Printer/Scanner kit (MG-2070/2080U) does not have a function for printing an XPS file.

9. To enable an XPS file to be printed by the Printer kit (GM-1071/1081U) or Printer/Scanner kit (GM-2071/1081U), the Memory (GC-1230) is required to be installed.

10.To enable an XPS file to be printed by the Printer ELK (GM-1130/1140U) or Printer/Scanner ELK (GM-2130/2140U), the Memory (GC-1230) is required to be installed.

07/11

1 - 10

1.4 Supplies

1.4.1 e-STUDIO200L/230/230L/280/280S

* 1) T: Taiwan D: Asia C: China E: Europe NONE: North America

1.4.2 e-STUDIO202L/232/232S/282/282S

* 1) T: Taiwan D: Asia C: China E: Europe NONE: North America

1.4.3 STUDIO203L/233/283/283S

* 1) C: China E: Europe NONE: North America

Drum OD-1600

Toner cartridge

PS-ZT2320 /T/D/C/E

*1

Developer D-2320 /C

Drum OD-1600

Toner cartridge

PS-ZT2340 /T/D/C/E

*1

Developer D-2340 /C

Drum OD-1600

Toner cartridge

PS-ZT2840 /E

*1

PS-ZT2340C

*1

Developer D-2340 /C

07/11

SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES

1 - 11

1

1.5 System List

1.5.1 e-STUDIO200L/230/230L/280/280S

Fig. 1-2

Staple Cartridge

STAPLE-1600

Work Tray

KK-3511

Platen Cover

KA-3511

Reversing Automatic

Document Feeder

(

RADF

)

MR-3016

Key Copy

Counter

MU-8

Key Copy

Counter Socket

MU-10

Harness kit for

coin controller

GQ-1020

Bridge Kit

KN-3520

Job Separator

MJ-5004

Offset Tray

MJ-5005

Scrambler

Board

GP-1030

Parallel interface

kit

GF-1140

PCI Slot

GO-1040

FAX Board

GD-1150

NA/AU/EU/

TW/C/AS

2nd Line for

FAX Board

GD-1160

NA/EU/TW/C

Wireless LAN

Adapter

GN-1010

Damp Heater

MF-2320 U/E

NIC board

GF-1150

Printer Kit

GM-1020/

GM-1030

Data

overwrite kit

GP-1050

Desk

MH-1700

Drawer Module

MY-1021

Slot cover

KE-2330

Large Capacity

Feeder (LCF)

KD-1012 A4/LT

Paper Feed

Pedestal (PFP)

KD-1011

Printer/

Scanner Kit

GM-2020/

GM-2030

Automatic

Duplexing Unit

(

ADU

)

MD-0102

Scanner

Upgrade Kit

GM-3020/

GM-3030

Staple Cartridge

STAPLE-2000

Hole Punch Unit

MJ-6005 N/E/F/S

Finisher

(

Hanging type

)

MJ-1022

Saddle stitch

Finisher

MJ-1025

05/11

1 - 12

e-STUDIO280/280S

Area North America

Central and

South America/

Hong Kong

Australia Europe Asia

Machine version (destination)

NAD

(115V)

ASD

(220-240V)

AUD

(220-240V)

MJD

(220-240V)

ASU

(220-240V)

Model name e-STUDIO280 e-STUDIO280 e-STUDIO280 e-STUDIO280 e-STUDIO280

Platen cover KA-3511PC KA-3511PC KA-3511PC KA-3511PC KA-3511PC

RADF MR-3016 MR-3016 MR-3016 MR-3016 MR-3016

Drawer module (for Equipment)

Standard MY-1021 Standard Standard MY-1021

Drawer module (for PFP)

MY-1021 MY-1021 MY-1021 MY-1021 MY-1021

Slot cover - Standard - - KE-2330

ADU Standard MD-0102 Standard Standard MD-0102

PFP KD-1011 KD-1011 KD-1011 KD-1011 KD-1011

LCF KD-1012LT KD-1012A4 KD-1012A4 KD-1012A4 KD-1012A4

Finisher (Hanging type)

MJ-1022 MJ-1022 MJ-1022 MJ-1022 MJ-1022

Staple cartridge (for MJ-1022)

STAPLE-1600 STAPLE-1600 STAPLE-1600 STAPLE-1600 STAPLE-1600

Saddle stitch finisher MJ-1025 MJ-1025 MJ-1025 MJ-1025 MJ-1025

Staple cartridge (for MJ-1025)

STAPLE-2000 STAPLE-2000 STAPLE-2000 STAPLE-2000 STAPLE-2000

Hole punch unit MJ-6005N MJ-6005E MJ-6005E MJ-6005E/F/S MJ-6005E

Bridge kit KN-3520 KN-3520 KN-3520 KN-3520 KN-3520

Job separator MJ-5004 MJ-5004 MJ-5004 MJ-5004 MJ-5004

Offset tray MJ-5005 MJ-5005 MJ-5005 MJ-5005 MJ-5005

Key copy counter MU-8 MU-8 MU-8 MU-8 MU-8

Key copy counter socket

MU-10 MU-10 MU-10 MU-10 MU-10

Work tray KK-3511 KK-3511 KK-3511 KK-3511 KK-3511

Damp heater MF-2320U Standard Standard MF-2320E Standard

Fax board GD-1150NA GD-1150AS GD-1150AU GD-1150EU GD-1150AS

2nd line for Fax board

GD-1160NA GD-1160EU GD-1160EU GD-1160EU GD-1160EU

Wireless LAN adapter

GN-1010 GN-1010 GN-1010 GN-1010 GN-1010

PCI slot GO-1040 GO-1040 GO-1040 GO-1040 GO-1040

Scrambler board GP-1030 GP-1030 GP-1030 GP-1030 GP-1030

Parallel interface kit GF-1140 GF-1140 GF-1140 GF-1140 GF-1140

NIC board Standard GF-1150 Standard Standard GF-1150

Printer/Scanner kit GM-2020 GM-2020 GM-2020 GM-2020 GM-2020

Printer kit GM-1020 GM-1020 GM-1020 GM-1020 GM-1020

Scanner upgrade kit GM-3020 GM-3020 GM-3020 GM-3020 GM-3020

Desk MH-1700 MH-1700 MH-1700 MH-1700 MH-1700

Harness kit for coin controller

GQ-1020 GQ-1020 GQ-1020 GQ-1020 GQ-1020

04/09

SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES

1 - 13

1

Area Saudi Arabia Iran China Taiwan

Machine version (destination)

SAD

(127V)

IRD

(220-240V)

CND

(220-240V)

TWD

(110V)

Model name e-STUDIO280 e-STUDIO280 e-STUDIO280S e-STUDIO280 e-STUDIO280

Platen cover KA-3511PC KA-3511PC Standard Standard KA-3511PC

RADF MR-3016 MR-3016 MR-3016 MR-3016 MR-3016

Drawer module (for Equipment)

MY-1021 Standard Standard Standard Standard

Drawer module (for PFP)

MY-1021 MY-1021 MY-1021 MY-1021 MY-1021

Slot cover KE-2330 - - - -

ADU MD-0102 Standard MD-0102 Standard MD-0102

PFP KD-1011 KD-1011 KD-1011 KD-1011 KD-1011

LCF KD-1012A4 KD-1012A4 KD-1012-C KD-1012-C KD-1012A4

Finisher (Hanging type)

MJ-1022 MJ-1022 MJ-1022-C MJ-1022-C MJ-1022

Staple cartridge (for MJ-1022)

STAPLE-1600 STAPLE-1600 STAPLE-1600 STAPLE-1600 STAPLE-1600

Saddle stitch finisher MJ-1025 MJ-1025 MJ-1025 MJ-1025 MJ-1025

Staple cartridge (for MJ-1025)

STAPLE-2000 STAPLE-2000 STAPLE-2000 STAPLE-2000 STAPLE-2000

Hole punch unit MJ-6005E MJ-6005E MJ-6005E MJ-6005E MJ-6005E

Bridge kit KN-3520 KN-3520 KN-3520-C KN-3520-C KN-3520

Job separator MJ-5004 MJ-5004 MJ-5004-C MJ-5004-C MJ-5004

Offset tray MJ-5005 MJ-5005 MJ-5005-C MJ-5005-C MJ-5005

Key copy counter MU-8 MU-8 MU-8 MU-8 MU-8

Key copy counter socket

MU-10 MU-10 MU-10 MU-10 MU-10

Work tray KK-3511 KK-3511 KK-3511 KK-3511 KK-3511

Damp heater Standard Standard Standard Standard Standard

Fax board GD-1150NA N/A GD-1150C GD-1150C GD-1150TW

2nd line for Fax board

GD-1160NA N/A GD-1160C GD-1160C GD-1160TW

Wireless LAN adapter

GN-1010 GN-1010 GN-1010 GN-1010 GN-1010

PCI slot GO-1040 GO-1040 GO-1040C GO-1040C GO-1040

Scrambler board GP-1030 GP-1030 GP-1030 GP-1030 GP-1030

Parallel interface kit GF-1140 GF-1140 GF-1140 GF-1140 GF-1140

NIC board GF-1150 Standard GF-1150 Standard Standard

Printer/Scanner kit GM-2020 Standard GM-2020 Standard GM-2020

Printer kit GM-1020 GM-1020 GM-1020 GM-1020 GM-1020

Scanner upgrade kit GM-3020 GM-3020 GM-3020 GM-3020 GM-3020

Desk MH-1700 MH-1700 MH-1700 MH-1700 MH-1700

Harness kit for coin controller

GQ-1020 GQ-1020 GQ-1020 GQ-1020 GQ-1020

04/09

1 - 14

e-STUDIO230/230L

Area North America

Central and

South America/

Hong Kong

Australia Europe

Machine version (destination)

NAD

(115V)

ASD

(220-240V)

AUD

(220-240V)

MJD

(220-240V)

Model name e-STUDIO230 e-STUDIO230 e-STUDIO230 e-STUDIO230 e-STUDIO230L

Platen cover KA-3511PC KA-3511PC KA-3511PC KA-3511PC KA-3511PC

RADF MR-3016 MR-3016 MR-3016 MR-3016 MR-3016

Drawer module (for Equipment)

Standard MY-1021 Standard Standard MY-1021

Drawer module (for PFP)

MY-1021 MY-1021 MY-1021 MY-1021 MY-1021

Slot cover - Standard - - Standard

ADU Standard MD-0102 Standard Standard MD-0102

PFP KD-1011 KD-1011 KD-1011 KD-1011 KD-1011

LCF KD-1012LT KD-1012A4 KD-1012A4 KD-1012A4 KD-1012A4

Finisher (Hanging type)

MJ-1022 MJ-1022 MJ-1022 MJ-1022 MJ-1022

Staple cartridge (for MJ-1022)

STAPLE-1600 STAPLE-1600 STAPLE-1600 STAPLE-1600 STAPLE-1600

Saddle stitch finisher MJ-1025 MJ-1025 MJ-1025 MJ-1025 MJ-1025

Staple cartridge (for MJ-1025)

STAPLE-2000 STAPLE-2000 STAPLE-2000 STAPLE-2000 STAPLE-2000

Hole punch unit MJ-6005N MJ-6005E MJ-6005E MJ-6005E/F/S MJ-6005E

Bridge kit KN-3520 KN-3520E KN-3520 KN-3520 KN-3520

Job separator MJ-5004 MJ-5004 MJ-5004 MJ-5004 MJ-5004

Offset tray MJ-5005 MJ-5005 MJ-5005 MJ-5005 MJ-5005

Key copy counter MU-8 MU-8 MU-8 MU-8 MU-8

Key copy counter socket

MU-10 MU-10 MU-10 MU-10 MU-10

Work tray KK-3511 KK-3511 KK-3511 KK-3511 KK-3511

Damp heater MF-2320U Standard Standard MF-2320E MF-2320E

Fax board GD-1150NA GD-1150AS GD-1150AU GD-1150EU GD-1150EU

2nd line for Fax board

GD-1160NA GD-1160EU GD-1160EU GD-1160EU GD-1160EU

Wireless LAN adapter

GN-1010 GN-1010 GN-1010 GN-1010 GN-1010

PCI slot GO-1040 GO-1040 GO-1040 GO-1040 GO-1040

Scrambler board GP-1030 GP-1030 GP-1030 GP-1030 GP-1030

Parallel interface kit GF-1140 GF-1140 GF-1140 GF-1140 GF-1140

NIC board Standard GF-1150 Standard Standard GF-1150

Printer/Scanner kit GM-2020 GM-2020 GM-2020 GM-2020 GM-2020

Printer kit GM-1020 GM-1020 GM-1020 GM-1020 GM-1020

Scanner upgrade kit GM-3020 GM-3020 GM-3020 GM-3020 GM-3020

Desk MH-1700 MH-1700 MH-1700 MH-1700 MH-1700

Harness kit for coin controller

GQ-1020 GQ-1020 GQ-1020 GQ-1020 GQ-1020

04/09

SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES

1 - 15

1

Area Asia Saudi Arabia China Taiwan

Machine version (destination)

ASU

(220-240V)

SAD

(127V)

CND

(220-240V)

TWD

(110V)

Model name e-STUDIO230 e-STUDIO230 e-STUDIO230 e-STUDIO230

Platen cover KA-3511PC KA-3511PC Standard KA-3511PC

RADF MR-3016 MR-3016 MR-3016 MR-3016

Drawer module (for Equipment)

MY-1021 MY-1021 Standard Standard

Drawer module (for PFP)

MY-1021 MY-1021 MY-1021 MY-1021

Slot cover KE-2330 KE-2330 - -

ADU MD-0102 MD-0102 Standard MD-0102

PFP KD-1011 KD-1011 KD-1011 KD-1011

LCF KD-1012A4 KD-1012A4 KD-1012A4 KD-1012A4

Finisher (Hanging type)

MJ-1022 MJ-1022 MJ-1022-C MJ-1022

Staple cartridge (for MJ-1022)

STAPLE-1600 STAPLE-1600 STAPLE-1600 STAPLE-1600

Saddle stitch finisher MJ-1025 MJ-1025 MJ-1025 MJ-1025

Staple cartridge (for MJ-1025)

STAPLE-2000 STAPLE-2000 STAPLE-2000 STAPLE-2000

Hole punch unit MJ-6005E MJ-6005E MJ-6005E MJ-6005E

Bridge kit KN-3520 KN-3520 KN-3520-C KN-3520

Job separator MJ-5004 MJ-5004 MJ-5004-C MJ-5004

Offset tray MJ-5005 MJ-5005 MJ-5005-C MJ-5005

Key copy counter MU-8 MU-8 MU-8 MU-8

Key copy counter socket

MU-10 MU-10 MU-10 MU-10

Work tray KK-3511 KK-3511 KK-3511 KK-3511

Damp heater Standard Standard Standard Standard

Fax board GD-1150AS GD-1150NA GD-1150C GD-1150TW

2nd line for Fax board

GD-1160EU GD-1160NA GD-1160C GD-1160TW

Wireless LAN adapter

GN-1010 GN-1010 GN-1010 GN-1010

PCI slot GO-1040 GO-1040 GO-1040C GO-1040

Scrambler board GP-1030 GP-1030 GP-1030 GP-1030

Parallel interface kit GF-1140 GF-1140 GF-1140 GF-1140

NIC board GF-1150 GF-1150 Standard Standard

Printer/Scanner kit GM-2020 GM-2020 Standard GM-2020

Printer kit GM-1020 GM-1020 GM-1020 GM-1020

Scanner upgrade kit GM-3020 GM-3020 GM-3020 GM-3020

Desk MH-1700 MH-1700 MH-1700 MH-1700

Harness kit for coin controller

GQ-1020 GQ-1020 GQ-1020 GQ-1020

04/09

1 - 16

e-STUDIO200L

Area North America

Central and

South America

Machine version (destination)

NAD

(115V)

ASD

(220-240V)

Model name e-STUDIO200L e-STUDIO200L

Platen cover KA-3511PC KA-3511PC

RADF MR-3016 MR-3016

Drawer module (for Equipment)

MY-1021 MY-1021

Drawer module (for PFP)

MY-1021 MY-1021

Slot cover Standard Standard

ADU MD-0102 MD-0102

PFP KD-1011 KD-1011

LCF KD-1012LT KD-1012A4

Finisher (Hanging type)

MJ-1022 MJ-1022

Staple cartridge (for MJ-1022)

STAPLE-1600 STAPLE-1600

Saddle stitch finisher MJ-1025 MJ-1025

Staple cartridge (for MJ-1025)

STAPLE-2000 STAPLE-2000

Hole punch unit MJ-6005N MJ-6005E

Bridge kit KN-3520 KN-3520

Job separator MJ-5004 MJ-5004

Offset tray MJ-5005 MJ-5005

Key copy counter MU-8 MU-8

Key copy counter socket

MU-10 MU-10

Work tray KK-3511 KK-3511

Damp heater MF-2320 Standard

Fax board GD-1150NA GD-1150AS

2nd line for Fax board

GD-1160NA GD-1160EU

Wireless LAN adapter

GN-1010 GN-1010

PCI slot GO-1040 GO-1040

Scrambler board GP-1030 GP-1030

Parallel interface kit GF-1140 GF-1140

NIC board GF-1150 GF-1150

Printer/Scanner kit GM-2030 GM-2030

Printer kit GM-1030 GM-1030

Scanner upgrade kit GM-3030 GM-3030

Desk MH-1700 MH-1700

Harness kit for coin controller

GQ-1020 GQ-1020

SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES

1 - 17

1

1.5.2 e-STUDIO202L/203L/232/232S/233/282/282S/283/283S

Fig. 1-3

Staple Cartridge

STAPLE-1600

Antenna

GN-3010

Platen Cover

KA-3511

Reversing Automatic

Document Feeder

(

RADF

)

MR-3020

Bluetooth

module

GN-2010

Wireless LAN

module

GN-1041

Harness kit for

coin controller

GQ-1020

Bridge Kit

KN-3520

Job Separator

MJ-5004

Offset Tray

MJ-5005

Scrambler

Board

GP-1040

PCI Slot

GO-1060

FAX Board

GD-11150

NA/EU/AU/

AS/C/TW

2nd Line for

FAX Board

GD-1160

NA/EU-N/TW/C

Data overwrite

kit

GP-1060

Damp Heater

MF-2320 U/E

Memory

GC-1230

Printer Kit

.

ELK

GM-1070/1071

GM-1080U/1081U

GM1130/1140U

Desk

MH-1700

Drawer Module

MY-1021

Slot cover

KE-2330

Large Capacity

Feeder (LCF)

KD-1012 A4/LT

Paper Feed

Pedestal (PFP)

KD-1011

Printer/

Scanner Kit

.

ELK

GM-2070/2071

GM-2080U/2081U

GM-2130/2140U

Automatic

Duplexing Unit

(

ADU

)

MD-0102

Scanner Kit

.

ELK

GM-4070/4080U

GM-4130/4140U

Staple Cartridge

STAPLE-2000

Hole Punch Unit

MJ-6005 N/E/F/S

Finisher

(

Hanging type

)

MJ-1022

Saddle stitch

Finisher

MJ-1025

07/11

1 - 18

e-STUDIO282/282S/283/283S

Area North America

Central and

South Amer-

ica/Hong Kong

Argentina Australia Europe

Machine version (destination)

NAD

(115V)

ASD

(220-240V)

ARD

(220-240V)

AUD

(220-240V)

MJD

(220-240V)

Model name e-STUDIO

282/283

e-STUDIO282 e-STUDIO

282/283

e-STUDIO282 e-STUDIO

282/283

Platen cover KA-3511PC KA-3511PC KA-3511PC KA-3511PC KA-3511PC

RADF MR-3020 MR-3020 MR-3020 MR-3020 MR-3020

Drawer module (for Equipment)

Standard MY-1021 MY-1021 Standard Standard

Drawer module (for PFP)

MY-1021 MY-1021 MY-1021 MY-1021 MY-1021

Slot cover - Standard Standard - -

ADU Standard MD-0102 MD-0102 Standard Standard

PFP KD-1011 KD-1011-N KD-1011 KD-1011 KD-1011

LCF KD-1012LT KD-1012A4 KD-1012A4 KD-1012A4 KD-1012A4

Finisher (Hanging type)

MJ-1022 MJ-1022 MJ-1022 MJ-1022 MJ-1022

Staple cartridge (for MJ-1022)

STAPLE-1600 STAPLE-1600 STAPLE-1600 STAPLE-1600 STAPLE-1600

Saddle stitch finisher MJ-1025 MJ-1025 MJ-1025 MJ-1025 MJ-1025

Staple cartridge (for MJ-1025)

STAPLE-2000 STAPLE-2000 STAPLE-2000 STAPLE-2000 STAPLE-2000

Hole punch unit MJ-6005N MJ-6005E MJ-6005E MJ-6005E MJ-6005E/F/S

Bridge kit KN-3520 KN-3520 KN-3520 KN-3520 KN-3520

Job separator MJ-5004 MJ-5004 MJ-5004 MJ-5004 MJ-5004

Offset tray MJ-5005 MJ-5005 MJ-5005 MJ-5005 MJ-5005

Work tray KK-3511 KK-3511 KK-3511 KK-3511 KK-3511

Damp heater MF-2320U Standard Standard Standard MF-2320E

Fax board GD-1150NA GD-1150AS GD-1150AS GD-1150AU GD-1150EU

2nd line for Fax board

GD-1160NA GD-1160EU-N GD-1160EU-N GD-1160EU-N GD-1160EU-N

Wireless LAN module

GN-1041 GN-1041 GN-1041 GN-1041 GN-1041

Bluetooth module GN-2010 GN-2010 GN-2010 GN-2010 GN-2010

Antenna GN-3010 GN-3010 GN-3010 GN-3010 GN-3010

PCI slot GO-1060 GO-1060 GO-1060 GO-1060 GO-1060

Scrambler board GP-1040 GP-1040 GP-1040 GP-1040 GP-1040

Printer kit GM-1070/1071 GM-1070/1071 GM-1070/1071 GM-1070/1071 GM-1070/1071

Printer/Scanner kit GM-2070/2071 GM-2070/2071 GM-2070/2071 GM-2070/2071 GM-2070/2071

Scanner kit GM-4070 GM-4070 GM-4070 GM-4070 GM-4070

Data overwrite kit GP-1060 GP-1060 GP-1060 GP-1060 GP-1060

Desk MH-1700 MH-1700 MH-1700 MH-1700 MH-1700

Harness kit for coin controller

GQ-1020 GQ-1020 GQ-1020 GQ-1020 GQ-1020

07/11

SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES

1 - 19

1

Area Asia Saudi Arabia

China

Machine version (destination)

ASU

(220-240V)

SAD

(127V)

CND

(220-240V)

Model name e-STUDIO282 e-STUDIO282 e-STUDIO

282/283

e-STUDIO

282S/283S

Platen cover KA-3511PC KA-3511PC Standard Standard

RADF MR-3020 MR-3020 MR-3020 MR-3020

Drawer module (for Equipment)

MY-1021 MY-1021 Standard Standard

Drawer module (for PFP)

MY-1021 MY-1021 MY-1021-C MY-1021-C

Slot cover KE-2330 KE-2330 - -

ADU MD-0102 MD-0102 Standard MD-0102-C

PFP KD-1011 KD-1011 KD-1011-C KD-1011-C

LCF KD-1012 KD-1012A4 KD-1012A4-C KD-1012A4-C

Finisher (Hanging type)

MJ-1022 MJ-1022 MJ-1022-C MJ-1022-C

Staple cartridge (for MJ-1022)

STAPLE-1600 STAPLE-1600 STAPLE-1600 STAPLE-1600

Saddle stitch finisher MJ-1025 MJ-1025 MJ-1025 MJ-1025

Staple cartridge (for MJ-1025)

STAPLE-2000 STAPLE-2000 STAPLE-2000 STAPLE-2000

Hole punch unit MJ-6005E MJ-6005E MJ-6005E MJ-6005E

Bridge kit KN-3520 KN-3520 KN-3520-C KN-3520-C

Job separator MJ-5004 MJ-5004 MJ-5004-C MJ-5004-C

Offset tray MJ-5005 MJ-5005 MJ-5005-C MJ-5005-C

Work tray KK-3511 KK-3511 KK-3511-C KK-3511-C

Damp heater Standard Standard Standard Standard

Fax board GD-1150AS GD-1150NA GD-1150C GD-1150C

2nd line for Fax board

GD-1160EU-N GD-1160NA GD-1160C GD-1160C

Wireless LAN module

GN-1041 GN-1041 GN-1041 GN-1041

Bluetooth module GN-2010 GN-2010 GN-2010 GN-2010

Antenna GN-3010 GN-3010 GN-3010 GN-3010

PCI slot GO-1060 GO-1060 GO-1060 GO-1060

Scrambler board GP-1040 GP-1040 GP-1040 GP-1040

Printer kit GM-1070/1071 GM-1070/1071 GM-1070/1071 -

Printer/Scanner kit GM-2070/2071 GM-2070/2071 Standard -

Scanner kit GM-4070 GM-4070 GM-4070 -

Data overwrite kit GP-1060 GP-1060 GP-1060 GP-1060

Desk MH-1700 MH-1700 MH-1700 MH-1700

Harness kit for coin controller

GQ-1020 GQ-1020 GQ-1020 GQ-1020

07/11

1 - 20

Area Taiwan Korea

Machine version (destination)

TWD

(110V)

KRD

(220-240V)

Model name e-STUDIO282 e-STUDIO282

Platen cover KA-3511PC Standard

RADF MR-3020 MR-3020

Drawer module (for Equipment)

Standard Standard

Drawer module (for PFP)

MY-1021 MY-1021

Slot cover - -

ADU MD-0102 MD-0102

PFP KD-1011 KD-1011

LCF KD-1012A4 KD-1012A

Finisher (Hanging type)

MJ-1022 MJ-1022

Staple cartridge (for MJ-1022)

STAPLE-1600 STAPLE-1600

Saddle stitch finisher MJ-1025 MJ-1025

Staple cartridge (for MJ-1025)

STAPLE-2000 STAPLE-2000

Hole punch unit MJ-6005E MJ-6005E

Bridge kit KN-3520 KN-3520

Job separator MJ-5004 MJ-5004

Offset tray MJ-5005 MJ-5005

Work tray KK-3511 KK-3511

Damp heater Standard Standard

Fax board GD-1150TW GD-1150AS

2nd line for Fax board

GD-1160TW GD-1160EU-N

Wireless LAN module

GN-1041 GN-1041

Bluetooth module GN-2010 GN-2010

Antenna GN-3010 GN-3010

PCI slot GO-1060 GO-1060

Scrambler board GP-1040 GP-1040

Printer kit GM-1070/1071 GM-1070/1071

Printer/Scanner kit GM-2070/2071 GM-2070/2071

Scanner kit GM-4070 GM-4070

Data overwrite kit GP-1060 GP-1060

Desk MH-1700 MH-1700

Harness kit for coin controller

GQ-1020 GQ-1020

07/11

SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES

1 - 21

1

e-STUDIO232/232S/233

Area North America

Central and

South Amer-

ica/Hong Kong

Argentina Australia Europe

Machine version (destination)

NAD

(115V)

ASD

(220-240V)

ARD

(220-240V)

AUD

(220-240V)

MJD

(220-240V)

Model name e-STUDIO

232/233

e-STUDIO232 e-STUDIO

232/233

e-STUDIO232 e-STUDIO

232/233

Platen cover KA-3511PC KA-3511PC KA-3511PC KA-3511PC KA-3511PC

RADF MR-3020 MR-3020 MR-3020 MR-3020 MR-3020

Drawer module (for Equipment)

Standard MY-1021 MY-1021 Standard Standard

Drawer module (for PFP)

MY-1021 MY-1021 MY-1021 MY-1021 MY-1021

Slot cover - Standard Standard - -

ADU Standard MD-0102 MD-0102 Standard Standard

PFP KD-1011 KD-1011-N KD-1011 KD-1011 KD-1011

LCF KD-1012LT KD-1012A4 KD-1012A4 KD-1012A4 KD-1012A4

Finisher (Hanging type)

MJ-1022 MJ-1022 MJ-1022 MJ-1022 MJ-1022

Staple cartridge (for MJ-1022)

STAPLE-1600 STAPLE-1600 STAPLE-1600 STAPLE-1600 STAPLE-1600

Saddle stitch finisher MJ-1025 MJ-1025 MJ-1025 MJ-1025 MJ-1025

Staple cartridge (for MJ-1025)

STAPLE-2000 STAPLE-2000 STAPLE-2000 STAPLE-2000 STAPLE-2000

Hole punch unit MJ-6005N MJ-6005E MJ-6005E MJ-6005E MJ-6005E/F/S

Bridge kit KN-3520 KN-3520 KN-3520 KN-3520 KN-3520

Job separator MJ-5004 MJ-5004 MJ-5004 MJ-5004 MJ-5004

Offset tray MJ-5005 MJ-5005 MJ-5005 MJ-5005 MJ-5005

Work tray KK-3511 KK-3511 KK-3511 KK-3511 KK-3511

Damp heater MF-2320U Standard Standard Standard MF-2320E

Fax board GD-1150NA GD-1150AS GD-1150AS GD-1150AU GD-1150EU

2nd line for Fax board

GD-1160NA GD-1160EU-N GD-1160EU-N GD-1160EU-N GD-1160EU-N

Wireless LAN module

GN-1041 GN-1041 GN-1041 GN-1041 GN-1041

Bluetooth module GN-2010 GN-2010 GN-2010 GN-2010 GN-2010

Antenna GN-3010 GN-3010 GN-3010 GN-3010 GN-3010

PCI slot GO-1060 GO-1060 GO-1060 GO-1060 GO-1060

Scrambler board GP-1040 GP-1040 GP-1040 GP-1040 GP-1040

Printer kit GM-1070/1071 GM-1070/1071 GM-1070/1071 GM-1070/1071 GM-1070/1071

Printer/Scanner kit GM-2070/2071 GM-2070/2071 GM-2070/2071 GM-2070/2071 GM-2070/2071

Scanner kit GM-4070 GM-4070 GM-4070 GM-4070 GM-4070

Data overwrite kit GP-1060 GP-1060 GP-1060 GP-1060 GP-1060

Desk MH-1700 MH-1700 MH-1700 MH-1700 MH-1700

Harness kit for coin controller

GQ-1020 GQ-1020 GQ-1020 GQ-1020 GQ-1020

07/11

1 - 22

Area Asia Saudi Arabia

China

Machine version (destination)

ASU

(220-240V)

SAD

(127V)

CND

(220-240V)

Model name e-STUDIO232 e-STUDIO232 e-STUDIO

232/233

e-STUDIO232S

Platen cover KA-3511PC KA-3511PC Standard Standard

RADF MR-3020 MR-3020 MR-3020 MR-3020

Drawer module (for Equipment)

MY-1021 MY-1021 Standard Standard

Drawer module (for PFP)

MY-1021 MY-1021 MY-1021-C MY-1021-C

Slot cover KE-2330 KE-2330 - -

ADU MD-0102 MD-0102 Standard MD-0102-C

PFP KD-1011 KD-1011 KD-1011-C KD-1011-C

LCF KD-1012 KD-1012A4 KD-1012A4-C KD-1012A4-C

Finisher (Hanging type)

MJ-1022 MJ-1022 MJ-1022-C MJ-1022-C

Staple cartridge (for MJ-1022)

STAPLE-1600 STAPLE-1600 STAPLE-1600 STAPLE-1600

Saddle stitch finisher MJ-1025 MJ-1025 MJ-1025 MJ-1025

Staple cartridge (for MJ-1025)

STAPLE-2000 STAPLE-2000 STAPLE-2000 STAPLE-2000

Hole punch unit MJ-6005E MJ-6005E MJ-6005E MJ-6005E

Bridge kit KN-3520 KN-3520 KN-3520-C KN-3520-C

Job separator MJ-5004 MJ-5004 MJ-5004-C MJ-5004-C

Offset tray MJ-5005 MJ-5005 MJ-5005-C MJ-5005-C

Work tray KK-3511 KK-3511 KK-3511-C KK-3511-C

Damp heater Standard Standard Standard Standard

Fax board GD-1150AS GD-1150NA GD-1150C GD-1150C

2nd line for Fax board

GD-1160EU-N GD-1160NA GD-1160C GD-1160C

Wireless LAN module

GN-1041 GN-1041 GN-1041 GN-1041

Bluetooth module GN-2010 GN-2010 GN-2010 GN-2010

Antenna GN-3010 GN-3010 GN-3010 GN-3010

PCI slot GO-1060 GO-1060 GO-1060 GO-1060

Scrambler board GP-1040 GP-1040 GP-1040 GP-1040

Printer kit GM-1070/1071 GM-1070/1071 GM-1070/1071 -

Printer/Scanner kit GM-2070/2071 GM-2070/2071 Standard -

Scanner kit GM-4070 GM-4070 GM-4070 -

Data overwrite kit GP-1060 GP-1060 GP-1060 GP-1060

Desk MH-1700 MH-1700 MH-1700 MH-1700

Harness kit for coin controller

GQ-1020 GQ-1020 GQ-1020 GQ-1020

07/11

SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES

1 - 23

1

Area Taiwan Korea

Machine version (destination)

TWD

(110V)

KRD

(220-240V)

Model name e-STUDIO232 e-STUDIO232

Platen cover KA-3511PC Standard

RADF MR-3020 MR-3020

Drawer module (for Equipment)

Standard Standard

Drawer module (for PFP)

MY-1021 MY-1021

Slot cover - -

ADU MD-0102 MD-0102

PFP KD-1011-TW KD-1011

LCF KD-1012A4 KD-1012A4

Finisher (Hanging type)

MJ-1022 MJ-1022

Staple cartridge (for MJ-1022)

STAPLE-1600 STAPLE-1600

Saddle stitch finisher MJ-1025 MJ-1025

Staple cartridge (for MJ-1025)

STAPLE-2000 STAPLE-2000

Hole punch unit MJ-6005E MJ-6005E

Bridge kit KN-3520 KN-3520

Job separator MJ-5004 MJ-5004

Offset tray MJ-5005 MJ-5005

Work tray KK-3511 KK-3511

Damp heater Standard Standard

Fax board GD-1150TW GD-1150AS

2nd line for Fax board

GD-1160TW GD-1160EU-N

Wireless LAN module

GN-1041 GN-1041

Bluetooth module GN-2010 GN-2010

Antenna GN-3010 GN-3010

PCI slot GO-1060 GO-1060

Scrambler board GP-1040 GP-1040

Printer kit GM-1070/1071 GM-1070/1071

Printer/Scanner kit GM-2070/2071 GM-2070/2071

Scanner kit GM-4070 GM-4070

Data overwrite kit GP-1060 GP-1060

Desk MH-1700 MH-1700

Harness kit for coin controller

GQ-1020 GQ-1020

07/11

1 - 24

e-STUDIO202L/203L

Area North America Argentina

Machine version (destination)

NAD

(115V)

ARD

(220-240V)

Model name e-STUDIO

202L/203L

e-STUDIO 202L/203L

Platen cover KA-3511PC KA-3511PC

RADF MR-3020 MR-3020

Drawer module (for Equipment)

MY-1021 MY-1021

Drawer module (for PFP)

MY-1021 MY-1021

Slot cover Standard Standard

ADU MD-0102 MD-0102

PFP KD-1011 KD-1011-N

LCF KD-1012LT KD-1012A4

Finisher (Hanging type)

MJ-1022 MJ-1022

Staple cartridge (for MJ-1022)

STAPLE-1600 STAPLE-1600

Saddle stitch finisher MJ-1025 MJ-1025

Staple cartridge (for MJ-1025)

STAPLE-2000 STAPLE-2000

Hole punch unit MJ-6005N MJ-6005E

Bridge kit KN-3520 KN-3520

Job separator MJ-5004 MJ-5004

Offset tray MJ-5005 MJ-5005

Work tray KK-3511 KK-3511

Damp heater MF-2320U Standard

Fax board GD-1150NA GD-1150AS

2nd line for Fax board

GD-1160NA GD-1160EU-N

Wireless LAN module

GN-1041 GN-1041

Bluetooth module GN-2010 GN-2010

Antenna GN-3010 GN-3010

PCI slot GO-1060 GO-1060

Scrambler board GP-1040 GP-1040

Printer kit GM-1080U/

1081U

GM-1080U/

1081U

Printer/Scanner kit GM-2080U/

2081U

GM-2080U/

2081U

Scanner kit GM-4080U GM-4080U

Data overwrite kit GP-1060 GP-1060

Desk MH-1700 MH-1700

Harness kit for coin controller

GQ-1020 GQ-1020

07/11

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 1

2

2. ERROR CODE AND SELF-DIAGNOSTIC MODE

2.1 Error Code List

2.1.1 Jam

One of the following error codes is displayed at the upper right of the screen while pressing the [CLEAR] button and the digital key [8] simultaneously when the “CLEAR PAPER” or “CALL SERVICE” symbol is blinking.

Error code Classification Contents Troubleshooting

E010 Paper exit jam Jam not reaching the exit sensor: The paper which

has passed through the fuser unit does not reach the exit sensor.

P. 5 - 1

E020 Stop jam at the exit sensor: The trailing edge of the

paper does not pass the exit sensor after its leading edge has reached this sensor.

P. 5 - 1

E030 Other paper jam Power-ON jam: The paper is remaining on the

paper transport path when power is turned ON.

P. 5 - 2

E061 Incorrect paper size setting for upper drawer: The

size of paper in the 1st drawer differs from size setting of the equipment.

P. 5 - 2

E062 Incorrect paper size setting for lower drawer: The

size of paper in the 2nd drawer differs from size setting of the equipment.

P. 5 - 2

E063 Incorrect paper size setting for PFP upper drawer:

The size of paper in the 3rd drawer differs from size setting of the equipment.

P. 5 - 2

E064 Incorrect paper size setting for PFP lower drawer:

The size of paper in the 4th drawer differs from size setting of the equipment.

P. 5 - 2

E065 Incorrect paper size setting for bypass tray: The

size of paper in the bypass tray differs from size setting of the equipment.

P. 5 - 2

E090 HDD abnormality causes jam: Image data to be

printed cannot be prepared.

P. 5 - 3

E110 Paper misfeeding ADU misfeeding (Paper not reaching the 1st trans-

port sensor): The paper which has passed through ADU does not reach the 1st transport sensor during duplex printing.

P. 5 - 1 5

E120 Bypass misfeeding (Paper not reaching the 1st

transport sensor): The paper fed from the bypass tray does not reach the 1st transport sensor.

P. 5 - 1 6

E130 Upper drawer misfeeding (Paper not reaching the

1st transport sensor): The paper fed from the upper drawer does not reach the 1st transport sensor.

P. 5 - 1 7

E140 Lower drawer misfeeding (Paper not reaching the

2nd transport sensor): The paper fed from the lower drawer does not reach the 2nd transport sensor.

P. 5 - 1 8

E150 PFP upper drawer misfeeding (Paper not reaching

the PFP upper drawer feed sensor): The paper fed from the PFP upper drawer does not reach the PFP upper drawer feed sensor.

P. 5 - 1 9

06/09

2 - 2

E160 Paper misfeeding PFP lower drawer misfeeding (Paper not reaching

the PFP lower drawer feed sensor): The paper fed from the PFP lower drawer does not reach the PFP lower drawer feed sensor.

P. 5 - 2 0

E190 LCF misfeeding (Paper not reaching the LCF feed

sensor): The paper fed from the LCF does not reach the LCF feed sensor.

P. 5 - 2 1

E200 Paper transport jam Upper drawer transport jam (Paper not reaching the

registration sensor): The paper does not reach the registration sensor after it has passed the 1st transport sensor.

P. 5 - 3

E210 Lower drawer transport jam (Paper not reaching the

registration sensor): The paper does not reach the registration sensor after it has passed the 1st transport sensor.

P. 5 - 3

E220 Lower drawer transport jam (Paper not reaching the

1st transport sensor): The paper does not reach the 1st transport sensor after it has passed the lower drawer feed sensor.

P. 5 - 4

E270 Bypass transport jam (paper not reaching the regis-

tration sensor): The paper does not reach the registration sensor after it has passed the 1st transport sensor.

P. 5 - 5

E280 ADU transport jam (paper not reaching the registra-

tion sensor): The paper which has passed through ADU and the 1st transport sensor does not reach the registration sensor during duplex printing.

P. 5 - 5

E300 PFP upper drawer transport jam (Paper not reach-

ing the registration sensor): The paper does not reach the registration sensor after it has passed the 1st transport sensor.

P. 5 - 3

E310 PFP upper drawer transport jam (Paper not reach-

ing the 1st transport sensor): The paper does not reach the 1st transport sensor after it has passed the 2nd transport sensor.

P. 5 - 4

E320 PFP upper drawer transport jam (Paper not reach-

ing the 2nd transport sensor): The paper does not reach the 2nd transport sensor after it has passed the PFP upper drawer feed sensor.

P. 5 - 6

E330 PFP lower drawer transport jam (Paper not reach-

ing the registration sensor): The paper does not reach the registration sensor after it has passed the 1st transport sensor.

P. 5 - 3

E340 PFP lower drawer transport jam (Paper not reach-

ing the 1st transport sensor): The paper does not reach the 1st transport sensor after it has passed the PFP lower drawer feed sensor.

P. 5 - 4

E350 PFP lower drawer transport jam (Paper not reach-

ing the 2nd transport sensor): The paper does not reach the 2nd transport sensor after it has passed the PFP upper drawer feed sensor.

P. 5 - 6

E360 PFP lower drawer transport jam (Paper not reach-

ing the PFP upper drawer feed sensor): The paper does not reach the PFP upper drawer feed sensor after it has passed the PFP lower drawer feed sensor.

P. 5 - 7

Error code Classification Contents Troubleshooting

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 3

2

E3C0 Paper transport jam LCF transport jam (Paper not reaching the registra-

tion sensor): The paper does not reach the registration sensor after it has passed the 1st transport sensor.

P. 5 - 3

E3D0 LCF transport jam (Paper not reaching the 1st

transport sensor): The paper does not reach the 1st transport sensor after it has passed the 2nd transport sensor.

P. 5 - 4

E3E0 LCF transport jam (Paper not reaching the 2nd

transport sensor): The paper does not reach the 2nd transport sensor after it has passed the LCF feed sensor.

P. 5 - 6

E400 Cover open jam Transfer cover open jam: The transfer cover has

opened during printing.

P. 5 - 2 2

E410 Front cover open jam: The front cover has opened

during printing.

P. 5 - 2 3

E420 PFP side cover open jam: The PFP side cover has

opened during printing.

P. 5 - 2 4

E430 ADU open jam: The ADU has opened during print-

ing.

P. 5 - 2 5

E440 Side cover open jam: The side cover has opened

during printing.

P. 5 - 2 5

E450 LCF side cover open jam: The LCF side cover has

opened during printing.

P. 5 - 2 6

E480 Bridge unit open jam: The bridge unit has opened

during printing.

P. 5 - 2 6

E490 Job separator cover open jam: The job separator

cover has opened during printing.

P. 5 - 2 7

E491 Offset tray cover open jam: The offset tray cover

has opened during printing.

P. 5 - 2 7

E510 Paper transport jam

(ADU section)

Stop jam in the ADU: The paper does not reach the ADU exit sensor after it has passed the ADU entrance sensor.

P. 5 - 8

E520 Jam not reaching the ADU entrance sensor: The

paper does not reach the ADU entrance sensor after it is switchbacked in the exit section.

P. 5 - 9

E550 Other paper jam Paper remaining jam on the transport path: The

paper is remaining on the transport path when printing is finished (caused by a multiple paper feeding).

P. 5 - 1 0

Error code Classification Contents Troubleshooting

2 - 4

E711 RADF jam Jam not reaching the original length sensor: The

original fed from the original feeding tray does not reach the original length sensor.

P. 5 - 2 8

E712 Jam not reaching the registration sensor: The origi-

nal fed from the original feeding tray does not reach the registration sensor.

P. 5 - 2 8

E713 Stop jam at the original length sensor: The trailing

edge of the original does not pass the original length sensor after its leading edge has reached this sensor.

P. 5 - 2 8

E714 Feed signal reception jam: The feed signal is

received even no original exists on the original feeding tray.

P. 5 - 2 9

E721 Jam not reaching the read sensor: The original

does not reach the read sensor after it has passed the registration sensor (when scanning obverse side) or the reverse sensor (when scanning reverse side).

P. 5 - 2 9

E722 Jam not reaching the exit sensor (during scanning):

The original which passed the read sensor does not reach the exit sensor when it is transported from the scanning section to exit section.

P. 5 - 3 0

E723 Jam not reaching the reverse sensor (during scan-

ning): The original which passed the read sensor does not reach the reverse sensor when it is transported from the scanning section to reverse section.

P. 5 - 3 0

E724 Stop jam at the registration sensor: The trailing

edge of the original does not pass the registration sensor after its leading edge has reached this sensor.

P. 5 - 3 0

E725 Stop jam at the read sensor: The trailing edge of the

original does not pass the read sensor after its leading edge has reached this sensor.

P. 5 - 3 1

E726 Transport/exit signal reception jam: RADF receives

the transport/exit reception signal from the equipment when no original is at the exposure waiting position.

P. 5 - 3 1

E731 Stop jam at the exit sensor: The trailing edge of the

original does not pass the exit sensor after its leading edge has reached this sensor.

P. 5 - 3 2

E741 Stop jam at the reverse sensor: The trailing edge of

the original does not pass the reversal sensor after its leading edge has reached this sensor.

P. 5 - 3 2

E742 Jam not reaching the reverse sensor (during

reverse feeding): The leading edge of the original does not reach the reverse sensor when original is fed from the reverse section.

P. 5 - 3 3

E743 Jam not reaching the exit sensor (during reverse

feeding): The original does not reach the exit sensor after it has passed the reverse sensor when the original is exited from the reverse section.

P. 5 - 3 3

E860 RADF jam access cover open: The RADF jam

access cover has opened during RADF operation.

P. 5 - 3 4

E870 RADF open jam: RADF has opened during RADF

operation.

P. 5 - 3 4

Error code Classification Contents Troubleshooting

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 5

2

E910 Finisher jam

(Bridge unit)

Jam at the bridge unit transport sensor-1: The paper does not reach the bridge unit transport sensor-1 after it has passed the exit sensor.

P. 5 - 3 5

E920 Stop jam at the bridge unit transport sensor-1: The

trailing edge of the paper does not pass the bridge unit transport sensor-1 after its leading edge has reached the sensor.

P. 5 - 3 5

E930 Jam at the bridge unit transport sensor-2: The trail-

ing edge of the paper does not reach the bridge unit transport sensor-2 after its leading edge has reached the bridge unit transport sensor-1.

P. 5 - 3 5

E940 Stop jam at the bridge unit transport sensor-2: The

trailing edge of the paper does not reach the bridge unit transport sensor-2 after its leading edge has reached the bridge unit transport sensor-2.

P. 5 - 3 5

E950 Job separator jam Jam not reaching the job separator transport sen-

sor: The paper has passed through the exit sensor does not reach the job separator transport sensor.

P. 5 - 11

E951 Stop jam at the job separator transport sensor: The

trailing edge of the paper does not pass the job separator transport sensor.

P. 5 - 11

E960 Offset tray jam Jam not reaching the offset tray transport sensor:

The paper has passed through the exit sensor does not reach the offset tray transport sensor.

P. 5 - 11

E961 Stop jam at the offset tray transport sensor: The

trailing edge of the paper does not pass the offset tray transport sensor.

P. 5 - 11

E9F0 Finisher jam

(Puncher unit)

Punching jam: Punching is not performed properly. [MJ-1025 (When MJ-6005 is installed)]

P. 5 - 3 6

EA10 Finisher jam

(Finisher unit)

Paper transport delay jam: The paper which has passed the bridge unit does not reach the inlet sensor. [MJ-1022/1025]

P. 5 - 3 7

EA20 Paper transport stop jam: The paper does not pass

through the inlet sensor. [MJ-1022/1025]

P. 5 - 3 8

EA30 Power-ON jam: Paper exists at the inlet sensor

when power is turned ON. [MJ-1022/1025]

P. 5 - 3 9

EA40 Door open jam: The finisher has been released

from the equipment during printing. [MJ-1022/1025]

P. 5 - 4 0

EA50 Stapling jam: Stapling is not performed properly.

[MJ-1022/1025]

P. 5 - 4 1

EA60 Early arrival jam: The inlet sensor detects the paper

earlier than a specified timing. [MJ-1022]

P. 5 - 4 2

EA70 Stack delivery jam: It cannot deliver the stack of

paper on the intermediary process tray to the stack tray. [MJ-1022/1025]

P. 5 - 4 3

EAB0 Finisher jam

(Saddle Stitcher section)

Saddle paper transport stop jam: The paper which passed through the inlet sensor does not reach or pass through the folding position sensor. [MJ-1025]

P. 5 - 4 5

EAC0 Saddle transport delay jam: The paper which has

reached the inlet sensor does not pass through this sensor. [MJ-1025]

P. 5 - 4 5

EAD0 Other paper jam Print end command time-out jam: The printing has

not finished normally because of the communication error between the SYS board and LGC board at the end of printing.

P. 5 - 4 6

Error code Classification Contents Troubleshooting

2 - 6

EAE0 Finisher jam Receiving time time-out jam: The printing has been

interrupted because of the communication error between the equipment and finisher when the paper is transported from the equipment to the finisher.

P. 5 - 4 6

EAF0 Finisher jam

(Finisher unit)

Stack return jam: It cannot load the paper which passed through the delivery roller on the intermediary process tray. [MJ-1022]

P. 5 - 4 4

EB30 Finisher jam Ready time time-out jam: The equipment judges

that the paper transport to the finisher is disabled because of the communication error between the equipment and finisher at the start of printing.

P. 5 - 4 6

EB50 Paper transport jam Paper remaining on the transport path: The multiple

feeding of preceding paper caused the misfeeding of upcoming paper.

P. 5 - 1 2

EB60 Paper remaining on the transport path: The multiple

feeding of preceding paper caused the misfeeding of upcoming paper (redetection after no jam is detected at [EB50]).

P. 5 - 1 4

Error code Classification Contents Troubleshooting

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 7

2

2.1.2 Service call

Error code Classification Contents Troubleshooting

C010 Drive system

related service call

Main motor abnormality: The main motor is not rotating normally.

P. 5-47

C040 Paper feeding sys-

tem related service call

PFP motor abnormality: The PFP motor is not rotating normally.

P. 5-48

C130 Upper drawer tray abnormality: The upper drawer tray

motor is not rotating or the upper drawer tray is not moving normally.

P. 5-49

C140 Lower drawer tray abnormality: The lower drawer tray

motor is not rotating or the lower drawer tray is not moving normally.

P. 5-49

C150 PFP upper drawer tray abnormality: The PFP upper

drawer tray motor is not rotating or the PFP upper drawer tray is not moving normally.

P. 5-50

C160 PFP lower drawer tray abnormality: The PFP lower

drawer tray motor is not rotating or the PFP lower drawer tray is not moving normally.

P. 5-50

C180 LCF tray-up motor abnormality: The LCF tray-up motor is

not rotating or the LCF tray is not moving normally.

P. 5-51

C1A0 LCF end fence motor abnormality: The LCF end fence

motor is not rotating or the LCF end fence is not moving normally.

P. 5-52

C1B0 LCF transport motor abnormality: The LCF transport

motor is not rotating normally.

P. 5-53

C260 Scanning system

related service call

Peak detection error: Lighting of the exposure lamp (white reference) is not detected when power is turned ON.

P. 5-54

C270 Carriage home position sensor not turning OFF within a

specified period of time: The carriage does not shift from its home position in a specified period of time.

P. 5-55

C280 Carriage home position sensor not turning ON within a

specified period of time: The carriage does not reach to its home position in a specified period of time.

P. 5-55

C410 Fuser unit related

service call

Thermistor or heater abnormality at power-ON: Abnormality of service call the thermistor is detected when power is turned ON or the temperature of the fuser roller does not rise in a specified period of time after power is turned ON.

P. 5-56

C430 Thermistor abnormality after abnormality judgment:

Abnormality of the thermistor is detected after a specified period of time has passed from power-ON (including ready state).

P. 5-57

C440 Heater abnormality after abnormality judgment: The tem-

perature of the fuser roller has exceeded the range of control (in this case, the main switch turns OFF automatically) or does not even reach the range.

P. 5-57

C450 Thermistor abnormality during printing: Abnormality of the

thermistor is detected during printing.

P. 5-57

C550

(C780)

Optional communication related service call

RADF I/F error: Communication error has occurred between the RADF and the scanner.

P. 5-58

C570 Communication error between Engine-CPU and IPC

board

P. 5-58

C580 Communication error between IPC board and finisher P. 5-58

07/04

2 - 8

C730 RADF related ser-

vice call

EEPROM initialization error: EEPROM is not initialized normally when performing the code 05-356.

P. 5-59

C740 Reverse sensor adjustment error P. 5-59 C810 Fan motor abnormality: The fan motor is not rotating nor-

mally.

P. 5-59

C820 Read sensor adjustment error: The read sensor cannot

be adjusted normally when performing the code 05-356.

P. 5-59

C830 Original length sensor adjustment error: The original

length sensor cannot be adjusted normally when performing the code 05-356.

P. 5-59

C940 Circuit related ser-

vice call

Engine-CPU abnormality P. 5-76

C970 Process related

service call

High-voltage transformer abnormality: Leakage of the main charger is detected.

P. 5-76

CA10 Laser optical unit

related service call

Polygonal motor abnormality: The polygonal motor is not rotating normally.

P. 5-60

CA20 H-Sync detection error: H-Sync detection PC board can-

not detect laser beams.

P. 5-60

CB10 Finisher related

service call

Transport motor abnormality: The transport motor or stack transport roller is not rotating normally. [MJ-1025]

P. 5-61

CB20 Delivery motor abnormality: Delivery motor or delivery

roller is not rotating normally. [MJ-1022/1025]

P. 5-62

CB30 Tray lift motor abnormality: The tray lift motor is not rotat-

ing normally or the delivery tray is not moving normally. [MJ-1025]

P. 5-63

CB50 Staple motor (staple/fold) abnormality: The staple motor

is not rotating normally or the stapler is not moving normally. [MJ-1025]

P. 5-64

CB60 Stapler unit shift motor abnormality: The stapler unit shift

motor is not rotating normally or the Stapler Unit is not moving normally. [MJ-1025]

P. 5-66

CB80 Backup RAM data abnormality:

1) Abnormality of checksum value on finisher controller board is detected when the power is turned on. [MJ-1025]

2) Abnormality of checksum value on punch controller board is detected when the power is turned on. [MJ-1025 (when MJ-6005 is installed)]

P. 5-67

CC30 Stack processing motor abnormality: The stack process-

ing motor is not rotating normally or the stack delivery belt is not moving normally. [MJ-1022] Paddle motor abnormality: The paddle motor is not rotating normally or the swing guide is not moving normally. [MJ-1025]

P. 5-67

CC50 Horizontal registration motor abnormality: The horizontal

registration motor is not rotating normally or the puncher is not moving normally. [MJ-1025 (when MJ-6005 is installed)]

P. 5-69

CC60 Punch motor abnormality: The punch motor is not rotating

normally or the puncher is not moving normally. [MJ-1025 (when MJ-6005 is installed)]

P. 5-69

CC80 Front jogging motor abnormality: Front jogging motor is

not rotating normally or the front alignment plate is not moving normally. [MJ-1022] Alignment motor (front) abnormality: The alignment motor (front) is not rotating normally or the front alignment plate is not moving normally. [MJ-1025]

P. 5-70

CC90 Upper stack tray lift motor abnormality: The upper stack

tray lift motor is not rotating or the upper stack tray is not moving normally. [MJ-1022]

P. 5-71

Error code Classification Contents Troubleshooting

06/09

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 9

2

CCA0 Finisher related

service call

Lower stack tray lift motor abnormality: The lower stack tray lift motor is not rotating or the lower stack tray is not moving normally. [MJ-1022]

P. 5-72

CCB0 Rear jogging motor abnormality: Rear jogging motor is

not rotating normally or the rear alignment plate is not moving normally. [MJ-1022] Alignment motor (rear) abnormality: The alignment motor (rear) is not rotating normally or the rear alignment plate is not moving normally. [MJ-1025]

P. 5-73

CDC0 Punch power failure abnormality: 24 V is not applied to

the punch controller board. [MJ-1025 (when MJ-6005 is installed)]

P. 5-74

CDD0 Folding position sensor abnormality: Automatic adjust-

ment of the folding position sensor can not be performed properly. [MJ-1025]

P. 5-74

CDE0 Paddle motor abnormality: The paddle motor does not

rotate properly. [MJ-1025]

P. 5-75

CDF0 Offset tray related

service call

Initialization error of the offset tray: The home position of the separator cannot be detected when the power is turned ON.

P. 5-76

CE00 Finisher related

service call

Communication error between finisher unit and puncher unit: Communication error between the finisher controller PC board and punch controller PC board. [MJ-1025 (when MJ-6005 is installed)]

P. 5-75

CF60 Other service call Toner for recycle transport area lock P. 5-76

F070 Communication

related service call

Communication error between System-CPU and EngineCPU

P. 5-58

F090 Other service call SRAM abnormality on the SYS board P. 5-76 F091 NVRAM abnormality on the SYS board P. 5-77 F092 SRAM and NVRAM abnormality on the SYS board P. 5-77 F100 HDD format error: HDD cannot be initialized normally. P. 5-77 F101 HDD unmounted: Connection of HDD cannot be

detected.

P. 5-77

F102 HDD start error: HDD cannot become ‘Ready’ state. P. 5-77 F103 HDD transfer time-out: Reading/writing cannot be per-

formed in the specified period of time.

P. 5-77

F104 HDD data error: Abnormality is detected in the data of

HDD.

P. 5-77

F105 HDD other error P. 5-77 F106 Point and Print partition damage P. 5-78 F107 /SHR partition damage P. 5-78 F108 /SHA partition damage P. 5-78

F110 Communication

related service call

Communication error between System-CPU and Scanner-CPU

P. 5-58

F111 Scanner response abnormality P. 5-58

F120 Other service call Database abnormality: Database is not operating nor-

mally.

P. 5-78

F130 Invaid MAC address P. 5-78 F200 Data overwrite kit (GP-1050/1060) is taken off P. 5-78

Error code Classification Contents Troubleshooting

2 - 10

2.1.3 Error in Internet FAX / Scanning Function

1) Internet FAX related error (when GM-1020/3020, GM-1030/3030, GM-2020, GM-2030, GM-1070/4070, GM-1080U/4080U, GM-2070, GM-2080U, GM-1071/4070, GM-1081U/4080U, GM-2071, GM-2081U, GM-1130/4130, GM-1140U/4140U, GM-2130, or GM-2140U is installed)

Error code Contents Troubleshooting

1C10 System access abnormality P. 5-79

1C11 Insufficient memory P. 5-79

1C12 Message reception error P. 5-79

1C13 Message transmission error P. 5-79

1C14 Invalid parameter P. 5-79

1C15 Exceeding file capacity P. 5-79

1C20 System management module access abnormality P. 5-79

1C21 Job control module access abnormality P. 5-79

1C22 Job control module access abnormality P. 5-79

1C30 Directory creation failure P. 5-80

1C31 File creation failure P. 5-80

1C32 File deletion failure P. 5-79

1C33 File access failure P. 5-80

1C40 Image conversion abnormality P. 5-80

1C60 HDD full failure during processing P. 5-80

1C61 Address Book reading failure P. 5-80

1C62 Memory acquiring failure P. 5-80

1C63 Terminal IP address unset P. 5-80

1C64 Terminal mail address unset P. 5-80

1C65 SMTP address unset P. 5-80

1C66 Server time time-out error P. 5-80

1C67 NIC time time-out error P. 5-80

1C68 NIC access error P. 5-80

1C69 SMTP server connection error P. 5-81

1C6A HOST NAME error P. 5-81

1C6B Terminal mail address error P. 5-81

1C6C Destination mail address error P. 5-81

1C6D System error P. 5-80

1C70 SMTP client OFF P. 5-81

1C71 SMTP authentication error P. 5-81

1C72 POP before SMTP error P. 5-81

1C80 Internet FAX transmission failure when processing E-mail job received P. 5-81

1C81 Onramp Gateway transmission failure P. 5-81

1C82 Internet FAX transmission failure when processing FAX job received P. 5-81

1CC0 Job canceling -

1CC1 Power failure P. 5-81

07/11

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 11

2

2) RFC related error (when GM-1020/3020, GM-1030/3030, GM-2020, GM-2030, GM-1070/4070, GM-1080U/4080U, GM-2070, GM-2080U, GM-1071/4070, GM-1081U/4080U, GM-2071, GM-2081U, GM-1130/4130, GM-1140U/4140U, GM-2130, or GM-2140U is installed)

Error code

Message displayed in the

TopAccess screen

Contents Troubleshooting

2500 Syntax error, command unrecog-

nized

HOST NAME error (RFC: 500) Destination mail address error (RFC: 500) Terminal mail address error (RFC: 500)

P. 5 - 8 2

2501 Syntax error in parameters or

arguments

HOST NAME error (RFC: 501) Destination mail address error (RFC: 501) Terminal mail address error (RFC: 501)

P. 5 - 8 2

2503 Bad sequence of commands Destination mail address error

(RFC: 503)

P. 5 - 8 2

2504 Command parameter not imple-

mented

HOST NAME error (RFC: 504) P. 5-82

2550 Mailbox unavailable Destination mail address error

(RFC: 550)

P. 5 - 8 2

2551 User not local Destination mail address error

(RFC: 551)

P. 5 - 8 2

2552 Insufficient system storage Terminal/Destination mail address error

(RFC: 552)

P. 5 - 8 2

2553 Mailbox name not allowed Destination mail address error

(RFC: 553)

P. 5 - 8 2

07/11

2 - 12

3) Electronic Filing related error

Error code

Message displayed in the

TopAccess screen

Contents Troubleshooting

2B10 There was no applicable job. No applicable job error in job control

module

P. 5 - 8 3

2B11 Job status failed. JOB status abnormality P. 5-83

2B20 Failed to access file. File library function error P. 5-83

2B21 Message size exceeded limit or

maximum size

Exceeding file capacity

P. 5 - 8 3

2B30 Insufficient disk space. Insufficient disk space in /SHR partition P. 5-83

2B31 Failed to access Electronic Filing. Status of specified Electronic Filing or

folder is undefined or being created/ deleted

P. 5 - 8 3

2B32 Failed to print Electronic Filing

document.

Electronic Filing printing failure: Specified document can not be printed because of client's access (being edited, etc.).

P. 5 - 8 3

2B50 Failed to process image. Image library error P. 5-83

2B51 Failed to process print image. List library error P. 5-83

2B60 The folder was renamed. A folder

of the same name already existed.

A folder with the same name exists in the box.

-

2B70 The document was renamed. A

document of the same name already existed.

A document with the same name exists in the box or folder.

-

2B71 Document(s) expire(s) in a few

days

Documents expiring in a few days exist -

2B80 Hard Disk space for Electronic

Filing nearly full.

Hard disk space in /SHR partition is nearly full (90%).

-

2B90 Insufficient Memory. Insufficient memory capacity P. 5-83

2BA0 Invalid Box password specified. Invalid Box password P. 5-84

2BA1 Incorrect paper size A Paper size not supported in the Elec-

tronic Filing function is being selected.

P. 5 - 8 4

2BB0 Job canceled Job canceling -

2BB1 Power failure occurred Power failure P. 5-84

2BC0 System fatal error. Fatal failure occurred. P. 5-83

2BC1 Failed to acquire resource. System management module resource

acquiring failure

P. 5 - 8 3

2BD0 Power failure occurred during e-

Filing restoring.

Power failure occurred during restoring of Electronic Filing

P. 5 - 8 4

2BE0 Failed to get machine parameter. Machine parameter reading failure P. 5-84

2BF0 Maximum number of pages has

been exceeded (list Maximum)

Exceeding maximum number of pages P. 5-84

2BF1 Maximum number of documents

has been exceeded (list Maximum)

Exceeding maximum number of documents

P. 5 - 8 4

2BF2 Maximum number of folders has

been exceeded (list Maximum)

Exceeding maximum number of folders P. 5-84

07/11

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 13

2

4) E-mail related error (when GM-1020/3020, GM-1030/3030, GM-2020, GM-2030, GM-1070/4070, GM-1080U/4080U, GM-2070, GM-2080U, GM-1071/4070, GM-1081U/4080U, GM-2071, GM-2081U, GM-1130/4130, GM-1140U/4140U, GM-2130, or GM-2140U is installed)

Error code

Message displayed in the

TopAccess screen

Contents Troubleshooting

2C10 Illegal Job status System access abnormality P. 5-85

2C11 Not enough memory Insufficient memory P. 5-85

2C12 Illegal Job status Message reception error P. 5-85

2C13 Illegal Job status Message transmission error P. 5-85

2C14 Invalid parameter specified Invalid parameter P. 5-85

2C15 Message size exceeded limit or

maximum size

Exceeding file capacity P. 5-85

2C20 Illegal Job status System management module access

abnormality

P. 5 - 8 5

2C21 Illegal Job status Job control module access abnormality P. 5-85

2C22 Illegal Job status Job control module access abnormality P. 5-85

2C30 Failed to create directory Directory creation failure P. 5-85

2C31 Failed to create file File creation failure P. 5-85

2C32 Failed to delete file File deletion failure P. 5-85

2C33 Failed to create file File access failure P. 5-85

2C40 Failed to convert image file format Image conversion abnormality P. 5-85

2C43 Encryption error. Failed to create

file.

Encryption error P. 5-86

2C44 Creating the image file was not

permitted.

Encryption PDF enforced mode error P. 5-86

2C60 Failed to process your Job. Insuffi-

cient disk space.

HDD full failure during processing P. 5-86

2C61 Failed to read AddressBook Address Book reading failure P. 5-86

2C62 Not enough memory Memory acquiring failure P. 5-85

2C63 Invalid Domain Address Terminal IP address unset P. 5-86

2C64 Invalid Domain Address Terminal mail address unset P. 5-86

2C65 Failed to connect to SMTP server SMTP address unset P. 5-86

2C66 Failed to connect to SMTP server Server time time-out error P. 5-86

2C67 Failed to send E-Mail message NIC time time-out error P. 5-86

2C68 Failed to send E-Mail message NIC access error P. 5-86

2C69 Failed to connect to SMTP server SMTP server connection error P. 5-86

2C6A Failed to send E-Mail message HOST NAME error (No RFC error) P. 5-86

2C6B Invalid address specified in From:

field

Terminal mail address error P. 5-87

2C6C Invalid address specified in To:

field

Destination mail address error (No RFC error)

P. 5 - 8 7

2C6D NIC system error System error P. 5-86

2C70 SMTP service is not available SMTP client OFF P. 5-87

2C71 Failed SMTP Authentication SMTP authentication error P. 5-87

2C72 POP Before SMTP Authentication

Failed

POP before SMTP error P. 5-87

2C80 Failed to process received E-mail

job

E-mail transmission failure when processing E-mail job received

P. 5 - 8 7

2C81 Failed to process received Fax job Process failure of FAX job received P. 5-87

2CC0 Job canceled Job canceling -

2CC1 Power failure occurred Power failure P. 5-87

07/11

2 - 14

5) File sharing related error (when GM-1020/3020, GM-1030/3030, GM-2020, GM-2030, GM-1070/4070, GM-1080U/4080U, GM-2070, GM-2080U, GM-1071/4070, GM-1081U/4080U, GM-2071, GM-2081U, GM-1130/4130, GM-1140U/4140U, GM-2130, or GM-2140U is installed)

Error code

Message displayed in the

TopAccess screen

Contents Troubleshooting

2D10 Illegal Job status System access abnormality P. 5-88

2D11 Not enough memory Insufficient memory P. 5-88

2D12 Illegal Job status Message reception error P. 5-88

2D13 Illegal Job status Message transmission error P. 5-88

2D14 Invalid parameter specified Invalid parameter P. 5-88

2D15 There are too many documents in

the folder. Failed in creating new document.

Exceeding document number P. 5-88

2D20 Illegal Job status System management module access

abnormality

P. 5 - 8 8

2D21 Illegal Job status Job control module access abnormality P. 5-88

2D22 Illegal Job status Job control module access abnormality P. 5-88

2D30 Failed to create directory Directory creation failure P. 5-88

2D31 Failed to create file File creation failure P. 5-88

2D32 Failed to delete file File deletion failure P. 5-88

2D33 Failed to create file File access failure P. 5-88

2D40 Failed to convert image file for-

mat

Image conversion abnormality P. 5-89

2D43 Encryption error. Failed to create

file.

Encryption error P. 5-89

2D44 Creating the image file was not

permitted.

Encryption PDF enforced mode error P. 5-89

2D60 Failed to copy file File library access abnormality P. 5-88

2D61 Invalid parameter specified Invalid parameter P. 5-88

2D62 Failed to connect to network des-

tination. Check destination path

File server connection error P. 5-89

2D63 Specified network path is invalid.

Check destination path

Invalid network path P. 5-89

2D64 Logon to file server failed. Check

username and password

Login failure P. 5-89

2D65 There are too many documents in

the folder. Failed in creating new document.

Exceeding documents in folder: Creating new document is failed.

P. 5 - 8 9

2D66 Failed to process your Job. Insuf-

ficient disk space.

HDD full failure during processing P. 5-89

2D67 FTP service is not available FTP service not available P. 5-89

2D68 File Sharing service is not avail-

able

File sharing service not available P. 5-89

2DA0 Expired scan documents deleted

from share folder.

Periodical deletion of scanned documents completed properly.

-

2DA1 Expired Sent Fax documents

deleted from shared folder.

Periodical deletion of transmitted FAX documents completed properly.

-

2DA2 Expired Received Fax documents

deleted from shared folder.

Periodical deletion of received FAX documents completed properly.

-

2DA3 Scanned documents in shared

folder deleted upon user's request.

Manual deletion of scanned documents completed properly.

-

07/11

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 15

2

2DA4 Sent Fax Documents in shared

folder deleted upon user's request.

Manual deletion of transmitted FAX documents completed properly.

-

2DA5 Received Fax Documents in

shared folder deleted upon user's request.

Manual deletion of received FAX documents completed properly.

-

2DA6 Failed to delete file. File deletion failure P. 5-88

2DA7 Failed to acquire resource. Resource acquiring failure P. 5-88

2DA8 The HDD is running out of capac-

ity for the shared folder.

Hard disk space in /SHA partition is nearly full (90%).

-

2DC0 Job canceled Job canceling -

2DC1 Power failure occurred Power failure P. 5-89

Error code

Message displayed in the

TopAccess screen

Contents Troubleshooting

07/11

2 - 16

6) E-mail reception related error (when GM-1020/3020, GM-1030/3030, GM-2020, GM-2030, GM-1070/4070, GM-1080U/4080U, GM-2070, GM-2080U, GM-1071/4070, GM-1081U/4080U, GM-2071, GM-2081U, GM-1130/4130, GM-1140U/4140U, GM-2130, or GM-2140U is installed)

Error code

Message displayed in the

TopAccess screen

Contents Troubleshooting

3A10 MIME Error has been detected in

the received mail.

E-mail MIME error P. 5-90

3A11 MIME Error has been detected in

the received mail. This mail has been transferred to the administrator.

P. 5 - 9 0

3A12 MIME Error has been detected in

the received mail. This mail could not be transferred to the administrator.

P. 5 - 9 0

3A20 Analyze Error has been detected

in the received mail.

E-mail analysis error P. 5-90

3A21 Analyze Error has been detected

in the received mail. This mail has been transferred to the administrator.

P. 5 - 9 0

3A22 Analyze Error has been detected

in the received mail. This mail could not be transferred to the administrator.

P. 5 - 9 0

3A30 Whole partial mails were not

reached by timeout.

Partial mail time-out error P. 5-90

3A40 Partial Mail Error has been

detected in the received mail.

Partial mail related error P. 5-90

3A50 HDD Full Error has been

occurred in this mail.

Insufficient HDD capacity error P. 5-90

3A51 HDD Full Error has been

occurred in this mail. This mail has been transferred to the administrator.

P. 5 - 9 0

3A52 HDD Full Error has been

occurred in this mail. This mail could not be transferred to the administrator.

P. 5 - 9 0

3A60 HDD Full Warning has been

occurred in this mail.

Warning of insufficient HDD capacity P. 5-90

3A61 HDD Full Warning has been

occurred in this mail. This mail could not be transferred to the administrator.

P. 5 - 9 0

3A62 HDD Full Warning has been

occurred in this mail. This mail could not be transferred to the administrator.

P. 5 - 9 0

3A70 Receiving partial mail was

aborted since the partial mail setting has been changed to Disable.

Warning of partial mail interruption P. 5-90

07/11

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 17

2

3A80 Partial mail was received during

the partial mail setting is disabled.

Partial mail reception setting OFF P. 5-90

3A81 Partial mail was received during

the partial mail setting is disabled. This mail has been transferred to the administrator.

P. 5 - 9 0

3A82 Partial mail was received during

the partial mail setting is disabled. This mail could not be transferred to the administrator.

P. 5 - 9 0

3B10 Format Error has been detected

in the received mail.

E-mail format error P. 5-90

3B11 Format Error has been detected

in the received mail. This mail has been transferred to the administrator.

P. 5 - 9 0

3B12 Format Error has been detected

in the received mail. This mail could not be transferred to the administrator.

P. 5 - 9 0

3B20 Content-Type Error has been

detected in the received mail.

Content-Type error P. 5-90

3B21 Content-Type Error has been

detected in the received mail. This mail has been transferred to the administrator.

P. 5 - 9 0

3B22 Content-Type Error has been

detected in the received mail. This mail could not be transferred to the administrator.

P. 5 - 9 0

3B30 Charset Error has been detected

in the received mail.

Charset error P. 5-91

3B31 Charset Error has been detected

in the received mail. This mail has been transferred to the administrator.

P. 5 - 9 1

3B32 Charset Error has been detected

in the received mail. This mail could not be transferred to the administrator.

P. 5 - 9 1

3B40 Decode Error has been detected

in the received mail.

E-mail decode error P. 5-90

3B41 Decode Error has been detected

in the received mail. This mail has been transferred to the administrator.

P. 5 - 9 0

3B42 Decode Error has been detected

in the received mail. This mail could not be transferred to the administrator.

P. 5 - 9 0

Error code

Message displayed in the

TopAccess screen

Contents Troubleshooting

2 - 18

3C10 Tiff Analyze Error has been

detected in the received mail.

TIFF analysis error P. 5-91

3C11 Tiff Analyze Error has been

detected in the received mail. This mail has been transferred to the administrator.

P. 5 - 9 1

3C12 Tiff Analyze Error has been

detected in the received mail. This mail could not be transferred to the administrator.

P. 5 - 9 1

3C13 Tiff Analyze Error has been

detected in the received mail.

P. 5 - 9 1

3C20 Tiff Compression Error has been

detected in the received mail.

TIFF compression error P. 5-91

3C21 Tiff Compression Error has been

detected in the received mail. This mail has been transferred to the administrator.

P. 5 - 9 1

3C22 Tiff Compression Error has been

detected in the received mail. This mail could not be transferred to the administrator.

P. 5 - 9 1

3C30 Tiff Resolution Error has been

detected in the received mail.

TIFF resolution error P. 5-91

3C31 Tiff Resolution Error has been

detected in the received mail. This mail has been transferred to the administrator.

P. 5 - 9 1

3C32 Tiff Resolution Error has been

detected in the received mail. This mail could not be transferred to the administrator.

P. 5 - 9 1

3C40 Tiff Paper Size Error has been

detected in the received mail.

TIFF paper size error P. 5-91

3C41 Tiff Paper Size Error has been

detected in the received mail. This mail has been transferred to the administrator.

P. 5 - 9 1

3C42 Tiff Paper Size Error has been

detected in the received mail. This mail could not be transferred to the administrator.

P. 5 - 9 1

3C50 Offramp Destination Error has

been detected in the received mail.

Offramp destination error P. 5-91

3C51 Offramp Destination Error has

been detected in the received mail. This mail has been transferred to the administrator.

P. 5 - 9 1

3C52 Offramp Destination Error has

been detected in the received mail. This mail could not be transferred to the administrator.

P. 5 - 9 1

Error code

Message displayed in the

TopAccess screen

Contents Troubleshooting

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 19

2

3C60 Offramp Security Error has been

detected in the received mail.

Offramp security error P. 5-91

3C61 Offramp Security Error has been

detected in the received mail. This mail has been transferred to the administrator.

P. 5 - 9 1

3C62 Offramp Security Error has been

detected in the received mail. This mail could not be transferred to the administrator.

P. 5 - 9 1

3C70 Power Failure has been occurred

in E-mail receiving.

Power failure error P. 5-91

3D10 SMTP Destination Error has been

detected in the received mail. This mail was deleted.

Destination address error P. 5-91

3D20 Offramp Destination limitation

Error has been detected in the received mail.

Offramp destination limitation error P. 5-91

3D30 Fax Board Error has been

occurred in the received mail.

FAX board error P. 5-92

3E10 POP3 Connection Error has been

occurred in the received mail.

POP3 server connection error P. 5-92

3E20 POP3 Connection Timeout Error

has been occurred in the received mail.

POP3 server connection time-out error P. 5-92

3E30 POP3 Login Error has been

occurred in the received mail.

POP3 login error P. 5-92

3E40 POP3 Login Error occurred in

received mail.

POP3 login method error P. 5-92

3F00 File I/O Error has been occurred

in this mail. The mail could not be received until File I/O is recovered.

File I/O error P. 5-92

3F10 P. 5 - 9 2

3F20 P. 5 - 9 2

3F30 P. 5 - 9 2

3F40 P. 5 - 9 2

Error code

Message displayed in the

TopAccess screen

Contents Troubleshooting

05/11

2 - 20

2.1.4 Printer function error

Following codes are displayed at the end of the user name on the print job log screen (when GM-1020/3020, GM-1030/3030, GM-2020, GM-2030, GM-1070/4070, GM-1080U/4080U, GM2070, GM-2080U, GM-1071/4070, GM-1081U/4080U, GM-2071, GM-2081U, GM-1130/4130, GM1140U/4140U, GM-2130, or GM-2140U is installed)

Error code Contents Troubleshooting

4030 No Printer Kit / Printer Kit function disabled: The Printer Kit (GM-1010) or the

Printer/Scanner Kit (GM-2010) is not installed. Or network printing of an XPS file is performed without the Expansion Memory (GC-1230), or network printing is performed after the termination of a trial period..

P. 5-92

4031 HDD full during print: Large quantity image data by private print or invalid

network print are saved in HDD.

P. 5-92

4032 Private-print-only error: Jobs other than Private print jobs cannot be per-

formed.

P. 5-92

4033 Printing data storing limitation error: Printing with its data being stored to the

HDD temporarily (Proof print, Private print, Scheduled print, etc.) cannot be performed.

P. 5-92

4034 e-Filing storing limitation error: Printing with its data being stored to the HDD

(print and e-Filing, print to e-Filing, etc.) cannot be performed.

P. 5-92

4035 Local file storing limitation error: Network FAX or Internet FAX cannot be sent

when "Local" is selected for the destination of the file to save.

P. 5-92

4036 User authentication error: The user who intended to print a document is not

registered as a user.

P. 5-92

A221 Print job cancellation: Print job (copy, list print, network print) is deleted from

the print job screen.

P. 5-93

A222 Print job power failure: The power of the equipment is turned OFF during

print job (copy, list print, network print).

P. 5-93

A290 Limit over error: The numbers of output pages have exceeded those speci-

fied with both of the department code and the user code at the same time.

P. 5-93

A291 Limit over error: The number of output pages has exceeded the one speci-

fied with the user code.

P. 5-93

A292 Limit over error: The number of output pages has exceeded the one speci-

fied with the department code.

P. 5-93

07/11

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 21

2

<<Error history: e-STUDIO200L/230/280>> In the setting mode (08-253), the latest twenty groups of error data will be displayed. Display example

EA10

04 07 11 17 57 32 064 064 23621000000 Error code YY MM DD HH MM SS MMM NNN ABCDEFHIJLO 4 digits 12 digits (Year is indicated

with its last two digits.)

3 digits 3 digits 11 digits

A Paper source

0: Not selected 1: Bypass feed 2: LCF 3: PFP upper drawer 4: Unused 5: PFP lower drawer 6: Unused 7: Upper drawer 8: Lower drawer

B Paper size code

0: A5/ST 1: A5-R 2: ST-R 3: LT 4: A4 5: B5-R 6: LT-R 7: A4-R 8: OTHER/UNIV 9: B5 A: FOLIO/COMP B: LG C: B4 D: LD E: A3 F: 13” LG G: Unused H: A6-R I: Postcard J: 8.5SQ K: Unused L: Unused M: 8K N: 16K-R O: 16K P: COM10 (Envelope) Q: DL (Envelope) R: Monarch (Envelope) S: CHO-3 (Envelope) T: YOU-4 (Envelope) Z: Not selected

C Sort mode/staple mode

0: Non-sort/Non-staple 1: Group 2: Sort 7: Front staple 8: Double staple 9: Rear staple A: Saddle stitch

D ADF mode

0: Unused 1: AUTO FEED (SADF) 2: STACK FEED

E APS/AMS mode

0: Not selected 1: APS 2: AMS

F Duplex mode

0: Not selected 1: Book 2: Double-sided/Single-sided 4: Double-sided/Duplex copying 8: Single-sided/Duplex copying

GUnused

H Image shift

0: Unused 1: Book 2: Left 4: Right

I Editing

0: Unused 1: Masking 2: Trimming 3: Mirror image 4: Negative/Positive Reversal

J Edge erase/Dual-page

0: Unused 1: Edge erase 2: Dual-page 3: Edge erase & Dual-page

KUnused

L Function

0: Unused 1: Copying 2: FAX/Internet FAX transmission 3: FAX/Internet FAX/E-mail reception printing 4: Unused 5: Printing/List print 6: Scan/E-mail transmission

MMM Primary scanning reproduction ratio (Display in hexadecimal)

(Mx256)+(Mx16)+M

NNN Secondary scanning reproduction ratio (Display in hexadecimal)

(Nx256)+(Nx16)+N

O Mode

0: Unused 1: Unused 2: Black

06/09

2 - 22

<<Error history: e-STUDIO202L/203L/232/233/282/283>> In the setting mode (08-253), the latest twenty groups of error data will be displayed. Display example

EA10

99999999 04 07 11 17 57 32 064 064 23621000000 Error code Total counter YY MM DD HH MM SS MMM NNN ABCDEFHIJLO 4 digits 8 digits 12 digits (Year is indicated

with its last two digits.)

3 digits 3 digits 11 digits

A Paper source

0: Not selected 1: Bypass feed 2: LCF 3: Upper drawer 4: Lower drawer 5: PFP upper drawer 6: PFP lower drawer 7: Unused 8: Unused

B Paper size code

0: A5/ST 1: A5-R 2: ST-R 3: LT 4: A4 5: B5-R 6: LT-R 7: A4-R 8: OTHER/UNIV 9: B5 A: FOLIO/COMP B: LG C: B4 D: LD E: A3 F: 13” LG G: Unused H: A6-R I: Postcard J: 8.5SQ K: Unused L: Unused M: 8K N: 16K-R O: 16K P: COM10 (Envelope) Q: DL (Envelope) R: Monarch (Envelope) S: CHO-3 (Envelope) T: YOU-4 (Envelope) Z: Not selected

C Sort mode/staple mode

0: Non-sort/Non-staple 1: Group 2: Sort 7: Front staple 8: Double staple 9: Rear staple A: Saddle stitch

D ADF mode

0: Unused 1: AUTO FEED (SADF) 2: STACK FEED

E APS/AMS mode

0: Not selected 1: APS 2: AMS

F Duplex mode

0: Not selected 1: Book 2: Double-sided/Single-sided 4: Double-sided/Duplex copying 8: Single-sided/Duplex copying

GUnused

H Image shift

0: Unused 1: Book 2: Left 4: Right

I Editing

0: Unused 1: Masking 2: Trimming 3: Mirror image 4: Negative/Positive Reversal

J Edge erase/Dual-page

0: Unused 1: Edge erase 2: Dual-page 3: Edge erase & Dual-page

KUnused

L Function

0: Unused 1: Copying 2: FAX/Internet FAX transmission 3: FAX/Internet FAX/E-mail reception printing 4: Unused 5: Printing/List print 6: Scan/E-mail transmission

MMM Primary scanning reproduction ratio (Display in hexadecimal)

(Mx256)+(Mx16)+M

NNN Secondary scanning reproduction ratio (Display in hexadecimal)

(Nx256)+(Nx16)+N

O Mode

0: Unused 1: Unused 2: Black

07/11

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 23

2

2.2 Self-diagnosis Modes

Notes:

1. To enter the desired mode, turn ON the power while two digital keys designated to each mode (e.g. [0] and [5]) are pressed simultaneously.

2. When the optional FAX unit is installed, Faxes received automatically during the self-diagnosis mode may not be printed out. Be sure to disconnect the modular code from the line connectors (LINE1, LINE2) of the equipment before starting the self-diagnosis mode. Also, be sure to finish the self-diagnosis mode by turning the power OFF and back ON before connecting the modular code.

• Control panel check mode (01):

Notes:

1. A mode can be canceled by [POWER] OFF/ON when the LED is lit and the LCD is blinking.

2. Button Check

Buttons with LED (Press to turn OFF the LED.) Buttons without LED (Press to display the message on the control panel.) Button on touch panel (Press to display the screen on the control panel at power-ON.)

• Test mode (03): Refer to  P. 2-25 "2.2.1 Input check (Test mode 03) (e-STUDIO200L/230/280)"/  P. 2-32 "2.2.2 Input check (Test mode 03) (e-STUDIO202L/203L/232/233/282/283)" and  P. 2 - 40 "2.2.3 Output check (test mode 03)".

• Test print mode (04): Refer to  P. 2-43 "2.2.4 Test print mode (test mode 04)".

• Adjustment mode (05): Refer to  P. 2-44 "2.2.5 Adjustment mode (05) (e-STUDIO200L/230/280)"/  P. 2-64 "2.2.6 Adjustment mode (05) (e-STUDIO202L/203L/232/233/282/283)".

• Setting mode (08): Refer to  P. 2-84 "2.2.7 Setting mode (08) (e-STUDIO200L/230/280)"/ P. 2 153 "2.2.8 Setting mode (08) (e-STUDIO202L/203L/232/233/282/283)".

Mode For start Contents For exit Display

Control panel check mode

[0]+[1]+ [POWER]

All LEDs on the control panel are lit, and all the LCD pixels blink.

[POWER]

OFF/ON

-

Test mode [0]+[3]+

[POWER]

Checks the status of input/output signals. [POWER]

OFF/ON

100% C A4

TEST MODE

Te s t p r i n t mode

[0]+[4]+ [POWER]

Outputs the test patterns. [POWER]

OFF/ON

100% P A4

TEST PRINT

Adjustment mode

[0]+[5]+ [POWER]

Adjusts various items. [POWER]

OFF/ON

100% A A4

TEST MODE

Setting mode [0]+[8]+

[POWER]

Sets various items. [POWER]

OFF/ON

100% D

TEST MOD

List print mode [9]+[START]

+[POWER]

Prints out the data lists of the codes 05 and 08, PM support mode and pixel counter.

[POWER]

OFF/ON

100% UA A4

LIST PRINT

PM support mode

[6]+[START] +[POWER]

Clears each counter. [POWER]

OFF/ON

100% K

TEST MODE

Firmware update mode

[8]+[9]+ [POWER]

Performs updating of the system firmware. [POWER]

OFF/ON

-

[0][1]

[POWER]

LED lit/

LCD blinking

[START]

(Button check)

[POWER] OFF/ON

(Exit)

07/11

2 - 24

• List print mode (9S): The procedure varies depending on the code.

• PM support mode (6S):

• Firmware update mode (89): Refer to “6. FIRMWARE UPDATING”.

Fig. 2-1

*1 Turn OFF the power after using the self-diagnosis modes, and leave the equipment to the user.

[9][START]

[POWER]

(Code) 101: Adjustment mode (05) 102: Setting mode (08)

(Code) 103: PM support mode 104: Stored information of pixel counter (toner cartridge reference) 105: Stored information of pixel counter (service technician reference) 106: Error history

[Digital keys]

Key in the first

code to be printed

[Digital keys]

Key in the last

code to be printed

[POWER] OFF/ON

(Exit)

[START]

List starts to

be printed

[START] [START]

[6][START]

[POWER]

(Code) 1: Auto-toner adjustment 2: PM Support Screen

[START]

(Operation started)

[POWER] OFF/ON

(Exit)

Warming up

Control panel

check mode

Test mode

Test print

mode

Adjustment

mode

Setting

mode

List print

mode

PM support

mode

Firmware

update mode

[POWER]

ON

Normal

Ready

[POWER]

OFF

To user

*1

[0][1] [0][3] [0][4] [0][5] [0][8] [9][START] [6][START] [8][9]

State transition diagram of self-diagnosis modes

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 25

2

2.2.1 Input check (Test mode 03) (e-STUDIO200L/230/280)

Note: Note:

Initialization is performed before the equipment enters the test mode.

Fig. 2-2 Example of display during input check

Items to be checked and the condition of the equipment when the buttons [A] to [H] are highlighted are listed in the following pages.

The status of each input signal can be checked by pressing the [FAX] button, and the digital keys in the test mode (03).

[0][3]

[POWER]

[START] [FAX] [Digital keys]

[CLEAR]

(LCD ON)

[POWER] OFF/ON

(Exit)

05/12

2 - 26

[FAX] button: OFF ([FAX] LED: OFF)

Digital

key

Button Items to check

Contents

Highlighted

display

e.g.

Normal dis-

play

e.g.

[1]

A- -B LCF connection Not connected Connected C Bypass unit connection Not connected Connected D Bypass paper sensor No paper Paper present E ADU connection Not connected Connected F ADU opening/closing switch ADU opened ADU closed G ADU exit sensor Paper present No paper H ADU entrance sensor Paper present No paper

[2]

A PFP upper drawer detection switch Drawer not

installed

Drawer

present B- -C PFP upper drawer paper stock sensor Paper almost

empty

Paper present

D PFP upper drawer feed sensor Paper present No paper E PFP connection Not connected Connected F PFP side cover opening/closing switch Cover opened Cover closed G PFP upper drawer empty sensor No paper Paper present H PFP upper drawer tray-up sensor Tray at upper

limit position

Other than

upper limit

position

[3]

A LCF tray bottom sensor Tray at bottom

position

Other than

bottom posi-

tion B LCF standby side paper mis-stacking sensor Correct stack-

ing

Incorrect

stacking C- -D- -E LCF drawer detection switch Drawer not

installed

Drawer

present F- -G- -H LCF feed side paper stock sensor Paper almost

empty

Paper present

[4]

A PFP lower drawer detection sensor Drawer not

installed

Drawer

present B- -C PFP lower drawer paper stock sensor Paper almost

empty

Paper present

D PFP lower drawer feed sensor Paper present No paper E PFP motor rotation status (Motor is rotating at output mode

(03))

Abnormal rotation

Normal rota-

tion F- -G PFP lower drawer empty sensor No paper Paper present H PFP lower drawer tray-up sensor Tray at upper

limit position

Other than

upper limit

position

05/12

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 27

2

[5]

A LCF end fence home position sensor Fence home

position

Other than

home position B LCF end fence stop position sensor Fence stop

position

Other than

stop position C LCF standby side empty sensor No paper Paper present D LCF side cover opening/closing switch Cover closed Cover opened E LCF motor rotation status (Motor is rotating at output mode

(03))

Abnormal rotation

Normal rota-

tion F LCF tray-up sensor Tray at upper

limit position

Other than

upper limit

position G LCF feed sensor No paper Paper present H LCF feed side empty sensor Paper present No paper

[6]

A- -B- -C- -D- -E 1st transport sensor Paper present No paper F- -G Upper drawer empty sensor No paper Paper present H Upper drawer tray-up sensor Tray at upper

limit position

Other than

upper limit

position

[7]

A- -B- -C- -D- -E 2nd transport sensor Paper present No paper F- -G Lower drawer empty sensor No paper Paper present H Lower drawer tray-up sensor Tray at upper

limit position

Other than

upper limit

position

[8]

A- -B Bypass feed paper width sensor-2 Refer to table 1 C Bypass feed paper width sensor-1 Refer to table 1 D Bypass feed paper width sensor-0 Refer to table 1 E- -F- -G- -H- --

[9]

A- -B- -C- -D Upper drawer detection switch Drawer not

installed

Drawer

present E Upper drawer paper stock sensor Paper almost

empty

Paper present

F- -G- -H- --

Digital

key

Button Items to check

Contents

Highlighted

display

e.g.

Normal dis-

play

e.g.

05/11

2 - 28

Table 1. Relation between the status of the bypass paper width sensor and paper size (width).

[0]

A- -B- -C- -D Lower drawer detection switch Drawer not

installed

Drawer

present E Lower drawer paper stock sensor Paper almost

empty

Paper present

F- -G- -H- --

Bypass paper-width sensor

Paper-width size

210

111 A3/A4

110 B5-R

101 A5-R

100 A3/A4

0 1 1 Card size

010 A4-R/A5

001 B6-R

000 B4-R/B5

Digital

key

Button Items to check

Contents

Highlighted

display

e.g.

Normal dis-

play

e.g.

05/11

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 29

2

[FAX] button: ON ([FAX] LED: ON)

Digital

key

Button Items to check

Contents

Highlighted

display

e.g.

Normal dis-

play

e.g.

[1]

A- -B- -C 24 V power supply Power ON Power OFF D IPC board connection Not connected Connected E- -F Polygonal motor rotation status (Motor is rotating at Output

Mode (03))

Abnormal rotation

Normal rota-

tion G Auger lock switch Lock Unlock H Toner cartridge installation switch OFF ON

[2]

A Registration sensor Paper present No paper B Exit sensor Paper present No paper C Auto-toner sensor connection Not connected Connected D Front cover opening/closing switch Cover opened Cover closed E- -F Side cover opening/closing sensor Cover opened Cover closed G Transfer cover opening/closing switch Cover opened Cover closed H Main motor rotation status (Motor is rotating at Output

Mode (03))

Abnormal rotation

Normal rota-

tion

[3]

A- -B Key copy counter connection Not connected Connected C Job Separator upper stack sensor

(When Job Separator is installed)

Paper full Paper not full

Offset Tray separate sensor (When Offset Tray is installed) Separator at

home position

Other than

home position D Fuser unit connection Fuser unit

installed

Fuser unit not

installed E Bridge unit transport sensor-2 (When bridge unit is

installed)

No paper Paper present

F Bridge unit cover opening/closing detection switch

(When Bridge unit is installed)

Cover opened Cover closed

Job Separator cover switch (When Job Separator is installed)

Cover opened Cover closed

Offset Tray cover switch (When Offset Tray is installed) Cover opened Cover closed

G Bridge unit paper full detection sensor

(When bridge unit is installed)

Paper not full Paper full

Job Separator lower stack sensor (When Job Separator is installed)

Paper full Paper not full

Offset Tray stack sensor (When Offset Tray is installed) Paper full Paper not full

H Bridge unit transport sensor-1 (When bridge unit is

installed)

No paper Paper present

Job Separator feed sensor (When Job Separator is installed)

Paper present No paper

Offset Tray feed sensor (When Offset Tray is installed) Paper present No paper

[4]

A- -B- -C- -D- -E- -F Bypass feed sensor No paper Paper present G- -H High-voltage power supply abnormality (shutdown) detec-

tion

Normal Abnormal

05/11

2 - 30

[5]

A- -B- -C- -D- -E- -F RADF connection RADF con-

nected

Not connected

G Platen sensor Platen cover

opened

Platen cover

closed H Carriage home position sensor Carriage at

home position

Other than

home position

[6]

A- -B- -C- -D APS sensor (APS-R) No original Original

present E APS sensor (APS-C) No original Original

present F APS sensor (APS-3) No original Original

present G APS sensor (APS-2) No original Original

present H APS sensor (APS-1) No original Original

present

[7]

A RADF tray sensor Original

present

No original

B RADF empty sensor Original

present

No original

C RADF jam access cover switch Cover opened Cover closed D RADF opening/closing sensor RADF opened RADF closed E RADF exit sensor Original

present

No original

F RADF reverse sensor Original

present

No original

G RADF read sensor Original

present

No original

H RADF registration sensor Original

present

No original

[8]

A- -B- -C- -D- -E RADF original length sensor Original

present

No original

F RADF original width sensor-1 Original

present

No original

G RADF original width sensor-2 Original

present

No original

H RADF original width sensor-3 Original

present

No original

Digital

key

Button Items to check

Contents

Highlighted

display

e.g.

Normal dis-

play

e.g.

05/11

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 31

2

Table 2. Connecting status of additional options at inner area of the equipment

[9]

A Bridge unit/Job Separator/Offset Tray connection detection-3Refer to table 2

B Bridge unit/Job Separator/Offset Tray connection detection-2Refer to table 2

C Bridge unit/Job Separator/Offset Tray connection detection-1Refer to table 2

D- -E- -F- -G- -H- --

[0]

A Dongle (for Printer/Scanner kit (GM-2020 or 2030)) Connectable Not connect-

able B Dongle (for Printer kit (GM-1020 or 1030)) Connectable Not connect-

able C Dongle (for Scanner upgrade kit (GM-3020 or 3030)) Connectable Not connect-

able D Dongles for other equipments/Other USB devices Connectable Not connect-

able E- -F- -G- -H- --

Bridge unit Job Separator Offset Tray None

Bridge unit/Job Separator/Offset Tray

connection detection-3

Normal display Highlighting

display

Highlighting

display

Highlighting

display

Bridge unit/Job Separator/Offset Tray

connection detection-2

Highlighting

display

Highlighting

display

Normal display Highlighting

display

Bridge unit/Job Separator/Offset Tray

connection detection-1

Normal display Normal display Normal display Highlighting

display

Digital

key

Button Items to check

Contents

Highlighted

display

e.g.

Normal dis-

play

e.g.

05/11

2 - 32

2.2.2 Input check (Test mode 03) (e-STUDIO202L/203L/232/233/282/283)

Note: Note:

Initialization is performed before the equipment enters the test mode.

Fig. 2-3 Example of display during input check

Items to be checked and the condition of the equipment when the buttons [A] to [H] are highlighted are listed in the following pages.

The status of each input signal can be checked by pressing the [FAX] button, and the digital keys in the test mode (03).

[0][3]

[POWER]

[START] [FAX] [Digital keys]

[CLEAR]

(LCD ON)

[POWER] OFF/ON

(Exit)

07/11

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 33

2

[FAX] button: OFF ([FAX] LED: OFF)

Digital

key

Button Items to check

Contents

Highlighted

display

e.g.

Normal dis-

play

e.g.

[1]

A- -B LCF connection Not connected Connected C Bypass unit connection Not connected Connected D Bypass paper sensor No paper Paper present E ADU connection Not connected Connected F ADU opening/closing switch ADU opened ADU closed G ADU exit sensor Paper present No paper H ADU entrance sensor Paper present No paper

[2]

A PFP upper drawer detection switch Drawer not

installed

Drawer

present B- -C PFP upper drawer paper stock sensor Paper almost

empty

Paper present

D PFP upper drawer feed sensor Paper present No paper E PFP connection Not connected Connected F PFP side cover opening/closing switch Cover opened Cover closed G PFP upper drawer empty sensor No paper Paper present H PFP upper drawer tray-up sensor Tray at upper

limit position

Other than

upper limit

position

[3]

A LCF tray bottom sensor Tray at bottom

position

Other than

bottom posi-

tion B LCF standby side paper mis-stacking sensor Correct stack-

ing

Incorrect

stacking C- -D- -E LCF drawer detection switch Drawer not

installed

Drawer

present F- -G- -H LCF feed side paper stock sensor Paper almost

empty

Paper present

[4]

A PFP lower drawer detection sensor Drawer not

installed

Drawer

present B- -C PFP lower drawer paper stock sensor Paper almost

empty

Paper present

D PFP lower drawer feed sensor Paper present No paper E PFP motor rotation status (Motor is rotating at output mode

(03))

Abnormal rotation

Normal rota-

tion F- -G PFP lower drawer empty sensor No paper Paper present H PFP lower drawer tray-up sensor Tray at upper

limit position

Other than

upper limit

position

05/11

2 - 34

[5]

A LCF end fence home position sensor Fence home

position

Other than

home position B LCF end fence stop position sensor Fence stop

position

Other than

stop position C LCF standby side empty sensor No paper Paper present D LCF side cover opening/closing switch Cover closed Cover opened E LCF motor rotation status (Motor is rotating at output mode

(03))

Abnormal rotation

Normal rota-

tion F LCF tray-up sensor Tray at upper

limit position

Other than

upper limit

position G LCF feed sensor No paper Paper present H LCF feed side empty sensor Paper present No paper

[6]

A- -B- -C- -D- -E 1st transport sensor Paper present No paper F- -G Upper drawer empty sensor No paper Paper present H Upper drawer tray-up sensor Tray at upper

limit position

Other than

upper limit

position

[7]

A- -B- -C- -D- -E 2nd transport sensor Paper present No paper F- -G Lower drawer empty sensor No paper Paper present H Lower drawer tray-up sensor Tray at upper

limit position

Other than

upper limit

position

[8]

A- -B Bypass feed paper width sensor-2 Refer to table 1 C Bypass feed paper width sensor-1 Refer to table 1 D Bypass feed paper width sensor-0 Refer to table 1 E- -F- -G- -H- --

[9]

A- -B- -C- -D Upper drawer detection switch Drawer not

installed

Drawer

present E Upper drawer paper stock sensor Paper almost

empty

Paper present

F- -G- -H- --

Digital

key

Button Items to check

Contents

Highlighted

display

e.g.

Normal dis-

play

e.g.

05/11

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 35

2

Table 1. Relation between the status of the bypass paper width sensor and paper size (width).

[0]

A- -B- -C- -D Lower drawer detection switch Drawer not

installed

Drawer

present E Lower drawer paper stock sensor Paper almost

empty

Paper present

F- -G- -H- --

Bypass paper-width sensor

Paper-width size

210

111 A3/A4

110 B5-R

101 A5-R

100 A3/A4

0 1 1 Card size

010 A4-R/A5

001 B6-R

000 B4-R/B5

Digital

key

Button Items to check

Contents

Highlighted

display

e.g.

Normal dis-

play

e.g.

05/11

2 - 36

[FAX] button: ON ([FAX] LED: ON)

Digital

key

Button Items to check

Contents

Highlighted

display

e.g.

Normal dis-

play

e.g.

[1]

A- -B- -C 24 V power supply Power ON Power OFF D IPC board connection Not connected Connected E- -F Polygonal motor rotation status (Motor is rotating at Output

Mode (03))

Abnormal rotation

Normal rota-

tion G Auger lock switch Lock Unlock H Toner cartridge installation switch OFF ON

[2]

A Registration sensor Paper present No paper B Exit sensor Paper present No paper C Auto-toner sensor connection Not connected Connected D Front cover opening/closing switch Cover opened Cover closed E- -F Side cover opening/closing sensor Cover opened Cover closed G Transfer cover opening/closing switch Cover opened Cover closed H Main motor rotation status (Motor is rotating at Output

Mode (03))

Abnormal rotation

Normal rota-

tion

[3]

A- -B Key copy counter connection Not connected Connected C Job Separator upper stack sensor

(When Job Separator is installed)

Paper full Paper not full

Offset Tray separate sensor (When Offset Tray is installed) Separator at

home position

Other than

home position D Fuser unit connection Fuser unit

installed

Fuser unit not

installed E Bridge unit transport sensor-2 (When bridge unit is

installed)

No paper Paper present

F Bridge unit cover opening/closing detection switch

(When Bridge unit is installed)

Cover opened Cover closed

Job Separator cover switch (When Job Separator is installed)

Cover opened Cover closed

Offset Tray cover switch (When Offset Tray is installed) Cover opened Cover closed

G Bridge unit paper full detection sensor

(When bridge unit is installed)

Paper not full Paper full

Job Separator lower stack sensor (When Job Separator is installed)

Paper full Paper not full

Offset Tray stack sensor (When Offset Tray is installed) Paper full Paper not full

H Bridge unit transport sensor-1 (When bridge unit is

installed)

No paper Paper present

Job Separator feed sensor (When Job Separator is installed)

Paper present No paper

Offset Tray feed sensor (When Offset Tray is installed) Paper present No paper

[4]

A- -B- -C- -D- -E- -F Bypass feed sensor No paper Paper present G- -H High-voltage power supply abnormality (shutdown) detec-

tion

Normal Abnormal

05/11

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 37

2

[5]

A- -B- -C- -D- -E- -F RADF connection RADF con-

nected

Not connected

G Platen sensor Platen cover

opened

Platen cover

closed H Carriage home position sensor Carriage at

home position

Other than

home position

[6]

A- -B- -C- -D APS sensor (APS-R) No original Original

present E APS sensor (APS-C) No original Original

present F APS sensor (APS-3) No original Original

present G APS sensor (APS-2) No original Original

present H APS sensor (APS-1) No original Original

present

[7]

A RADF tray sensor Original

present

No original

B RADF empty sensor Original

present

No original

C RADF jam access cover switch Cover opened Cover closed D RADF opening/closing sensor RADF opened RADF closed E RADF exit sensor Original

present

No original

F RADF intermediate sensor Original

present

No original

G RADF read sensor Original

present

No original

H RADF registration sensor Original

present

No original

[8]

A- -B- -C- -D- -E RADF original length sensor Original

present

No original

F RADF original width sensor-1 Original

present

No original

G RADF original width sensor-2 Original

present

No original

H RADF original width sensor-3 Original

present

No original

Digital

key

Button Items to check

Contents

Highlighted

display

e.g.

Normal dis-

play

e.g.

05/11

2 - 38

Table 2. Connecting status of additional options at inner area of the equipment

[9]

A Bridge unit/Job Separator/Offset Tray connection detection-3Refer to table 2

B Bridge unit/Job Separator/Offset Tray connection detection-2Refer to table 2

C Bridge unit/Job Separator/Offset Tray connection detection-1Refer to table 2

D- -E- -F- -G- -H- --

[0]

A Dongle (for Printer/Scanner kit (GM-2020 or 2030)) Connectable Not connect-

able B Dongle (for Printer kit (GM-1020 or 1030)) Connectable Not connect-

able C Dongle (for Scanner upgrade kit (GM-3020 or 3030)) Connectable Not connect-

able D Dongles for other equipments/Other USB devices Connectable Not connect-

able E- -F- -G- -H- --

Bridge unit Job Separator Offset Tray None

Bridge unit/Job Separator/Offset Tray

connection detection-3

Normal display Highlighting

display

Highlighting

display

Highlighting

display

Bridge unit/Job Separator/Offset Tray

connection detection-2

Highlighting

display

Highlighting

display

Normal display Highlighting

display

Bridge unit/Job Separator/Offset Tray

connection detection-1

Normal display Normal display Normal display Highlighting

display

Digital

key

Button Items to check

Contents

Highlighted

display

e.g.

Normal dis-

play

e.g.

05/11

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 39

2

[FAX] button: OFF/ [COPY] button: ON ([FAX] LED: OFF/ [COPY] LED: ON)

*1

• Be sure to install the USB storage device to the equipment and check if the device can be used with this code.

• Be sure to turn OFF the write protection (the function to prevent data from erasure by the accidental recording or deleting) of the USB storage device before performing the check, otherwise this code cannot be used.

• It may take some time (2 sec. to 10 sec.) before this check is completed depending on the USB storage device.

Digital

key

Button Items to check

Contents

Highlighted

display

e.g.

Normal dis-

play

e.g.

[0]

A Dongle (for Printer/Scanner kit (GM-2070 or 2080U)) Con-

nected

Connectable Not connect-

able

B Dongle (for Printer kit (GM-1070, 1071, 1080U or 1081U))

Connected

Connectable Not connect-

able

C Dongle (for Scanner kit (GM-4070 or 4080U)) Connected Connectable Not connect-

able

D Dongles for other equipments/Other USB devices Con-

nected

Connectable Not connect-

able E Judgement for acceptable USB storage device (*1) Acceptable Not acceptable F- -G- -H- --

07/11

2 - 40

2.2.3 Output check (test mode 03)

<Operation procedure> Procedure 1

Procedure 2

Procedure 3

Procedure 4

Status of the output signals can be checked by keying in the following codes in the test mode 03.

[0][3]

[POWER]

[POWER] OFF/ON

(Exit)

[START]

(Code)

Operation

ON

Stop code

Operation

OFF

[START]

[0][3]

[POWER]

[POWER] OFF/ON

(Exit)

[START] [CLEAR]

Operation

One direction

Test mode

standby

(Code)

[0][3]

[POWER]

OFF/ON

(Exit)

(Code)

[START] [START]

Operation

ON

Test mode

standby

[CLEAR]

Operation

OFF

[0][3]

[POWER]

[POWER] OFF

[START]

(Code)

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 41

2

Code Function Code Function Procedure

101 Main motor ON (operational without

developer unit)

151 Code No. 101 function OFF 1

102 Toner motor ON (normal rotation) 152 Code No. 102 function OFF 1

103 Polygonal motor ON (600 dpi) 153 Code No. 103 function OFF 1

108 Registration clutch ON 158 Code No. 108 function OFF 1

109 PFP motor ON 159 Code No. 109 function OFF 1

110 ADU motor ON (low speed) 160 Code No. 110 function OFF 1

118 Laser ON 168 Code No. 118 function OFF 1

120 Exit motor ON (normal rotation) 170 Code No. 120 function OFF 1

121 Exit motor ON (reverse rotation) 171 Code No. 121 function OFF 1

122 LCF motor ON 172 Code No. 122 function OFF 1

177 Offset Tray motor ON (reciprocating movement) 2

201 Upper drawer feed clutch ON/OFF 3

202 Lower drawer feed clutch ON/OFF 3

203 Upper transport clutch ON/OFF 3

204 Bypass feed clutch ON/OFF 3

205 Middle transport clutch ON/OFF 3

206 LCF pickup solenoid ON/OFF 3

207 LCF end fence reciprocating movement 2

208 LCF end fence motor ON/OFF 3

209 LCF feed clutch ON/OFF 3

210 LCF transport clutch ON/OFF 3

217 Lower transport clutch ON/OFF 3

218 Key copy counter count up 2

222 ADU clutch ON/OFF 3

225 PFP transport clutch ON/OFF 3

226 PFP upper drawer feed clutch ON/OFF 3

228 PFP lower drawer feed clutch ON/OFF 3

232 Bridge unit gate solenoid ON/OFF 3

234 Bypass pickup solenoid ON/OFF 3

235 Discharge LED ON/OFF 3

236 Exhaust fan ON/OFF (low speed) 3

237 Exhaust fan ON/OFF (high speed) 3

242 Upper drawer tray-up motor ON (tray up) 2

243 Lower drawer tray-up motor ON (tray up) 2

248 Developer bias [+DC] ON/OFF 3

249 Developer bias [-DC] ON/OFF 3

252 Main charger ON/OFF 3

253 Separation bias ON/OFF 3

255 Transfer guide bias ON/OFF 3

256 Transfer transformer ON/OFF 3

261 Scan motor ON (Automatically stops at limit position; speed can be changed with the

[ZOOM] button

2

264 SLG board cooling fan 1 ON/OFF 3

265 SLG board cooling fan 2 ON/OFF 3

267 Scanner exposure lamp ON/OFF 3

05/11

2 - 42

Code Function Procedure

271 LCF tray-up motor (up/down) 2

278 PFP upper drawer tray-up motor ON (tray up) 2

280 PFP lower drawer tray-up motor ON (tray up) 2

281 RADF feed motor ON/OFF (normal rotation) 3

282 RADF feed motor ON/OFF (reverse rotation) 3

283 RADF read motor ON/OFF (normal rotation) 3

284 RADF reverse motor ON/OFF (normal rotation) 3

285 RADF reverse motor ON/OFF (reverse rotation) 3

289 Internal cooling fan 1 ON/OFF (high speed) 3

290 Internal cooling fan 1 ON/OFF (low speed) 3

294 RADF reverse solenoid ON/OFF 3

295 Power OFF mode (for 200 V series) 4

297 RADF fan motor ON/OFF 3

410 Internal cooling fan 2 ON/OFF (low speed) 3

411 Internal cooling fan 2 ON/OFF (high speed) 3

05/11

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 43

2

2.2.4 Test print mode (test mode 04)

Notes:

1. When an error occurs, it is indicated on the panel, but the recovery operation is not performed. Turn OFF the power and then back ON to clear the error.

2. During test printing, the [CLEAR] button is disabled when “Wait adding toner” is displayed.

The embedded test pattern can be printed out by keying in the following codes in the test print mode (04).

Code Types of test pattern Remarks

111 Primary scanning direction 33 gradation steps Error diffusion

113 Secondary scanning direction 33 gradation steps Error diffusion

142 Grid pattern Pattern width: 2 dots, Pitch: 10 mm

[0][4]

[POWER]

[POWER] OFF/ON

(Exit)

(Code)

[START]

[CLEAR]Operation

Continuous

Test Printing

2 - 44

2.2.5 Adjustment mode (05) (e-STUDIO200L/230/280)

Procedure 1

Procedure 2

Procedure 3

Procedure 4

Items in the adjustment mode list in the following pages can be corrected or changed in the adjustment mode (05). Turn ON the power with pressing the digital keys [0] and [5] simultaneously in order to enter this mode.

[0][5]

[POWER]

OFF/ON

(Exit)

[Digital key]

(Code)

[START]

[CANCEL]

[Digital key]

*

[FUNCTION CLEAR]

(Key in a value)

[CLEAR]

(Corrects value)

[ENTER]

or

[INTERRUPT]

(Stores value in RAM)

([FAX])

(Test copy)

*Press [

FUNCTION CLEAR

] to enter minus (-).

[0][5]

[POWER]

OFF/ON

(Exit)

(Code)

[START]

[ENTER]

or

[INTERRUPT]

(Value unchangeable)

([FAX])

(Test copy)

Value

displayed

()

[0][5]

[POWER]

OFF/ON

(Exit)

[Digital key]

(Code)

[START]

[CANCEL]

[UP]

or

[DOWN]

(Adjust a value)

[CLEAR]

(Corrects value)

[ENTER]

or

[INTERRUPT]

(Stores value in RAM)

([FAX])

(Test copy)

[0][5]

[POWER]

OFF/ON

(Exit)

[Digital key]

(Code)

[Digital key]

*

[FUNCTION CLEAR]

[START]

[Digital key]

(Sub code)

[CLEAR]

(Corrects value)

[CLEAR]

(Corrects value)

[ENTER]

or

[INTERRUPT]

*Press [FUNCTION CLEAR] to enter minus (-).

(Key in a value)

Stores value

in RAM

()

([FAX])

(Test copy)

[CANCEL]

[START]

05/12

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 45

2

Procedure 6

* When the automatic adjustment ends abnormally, error message is displayed.

Procedure 7

* When the automatic adjustment ends abnormally, error message is displayed.

Procedure 10

Procedure 17

* When the “storing is not performed within 2 minutes after pressing the [START] button at the

manual adjustment, the “automatic adjustment” starts automatically.

Note: Note:

The fuser roller temperature control at the adjustment mode is different from that at the normal state. Therefore, the problem of fusing efficiency may be occurred in the test copy at the adjustment mode. In that case, turn ON the power normally, leave the equipment for approx. 3 minutes after it has become ready state and then start up the adjustment mode again.

[0][5]

[POWER]

[POWER]OFF/ON

(Exit)

[Digital key]

(Code)

[START]

()

Automatic

adjustment

([FAX])

(Test copy)

*[CANCEL] or [CLEAR]

[0][5]

[POWER]

OFF/ON

(Exit)

[Digital key]

(Code)

[START]

()

Automatic

adjustment

([FAX])

(Test copy)

*[CANCEL] or [CLEAR]

[CANCEL]

()

[ENTER]

Stores value

in RAM

[0][5]

[POWER]

OFF/ON

(Exit)

[Digital key]

(Code)

[Digital key]

(Sub code)

[START] [START][START]

[SET] or [INTERRUPT]

(Value unchangeable)

()

Value

displayed

[0][5]

[POWER]

OFF/ON

(Exit)

[Digital key]

(Code)

[START]

Automatic

adjustment

[ENTER]

or

[INTERRUPT]

Stores value

in RAM

()

[ENTER]

or

[INTERRUPT]

Stores value

in RAM

()

([FAX])

(Test copy)

[UP]

or

[DOWN]

(Adjust a value)

[CANCEL] or [CLEAR]

()

[UP]

or

[DOWN]

(Adjust a value)

[CANCEL] or [CLEAR]

)

(

Manual

adjustment

2 - 46

Test print pattern in Adjustment Mode (05)

Operation: One test print is printed out when the [FAX] button is pressed after the code is keyed in at Standby Screen.

Code Types of test pattern Remarks

1 Grid pattern Refer to 3.2.3 Printer related adjustment

3 Grid pattern (Duplex printing) Refer to 3.2.3 Printer related adjustment

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 47

2

Notes:

• The digit after the hyphen in “Code” of the following table is a sub code.

• In “RAM”, the NVRAM of the board in which the data of each code is stored is indicated. “M” stands for the LGC board and “SYS” stands for the SYS board.

Adjustment mode (05) <e-STUDIO200L/230/280>

Code

Classi-

fication

Items

Func-

tion

Default

<Accept-

able

value>

RAM Contents

Proce-

dure

200 Devel-

oper

Automatic adjustment of auto-toner sensor (Fuser heater ON)

ALL - - As the value increases,

the sensor output increases correspondingly. The value starts changing approx. 2 minutes after this adjustment was started and is automatically set in the range of

2.35 to 2.45 V. * Selection is disable

when developer unit is not installed. (Chap. 3.1)

17

201 Devel-

oper

Correction of auto-toner sensor (Fuser heater ON)

ALL 164

<0-255>

M Corrects the control

value of the auto-toner sensor setup in 05-200. * Selection is disable

when developer unit is not installed.

3

205 Devel-

oper

Developer bias DC output adjustment

ALL 135

<0-255>

M As the value increases,

the transformer output increases correspondingly. Remove the developer unit and install the adjustment jig to make adjustment. (Chap. 3.6)

3

210 Charger Main charger grid bias out-

put adjustment

ALL 90

<0-255>

M3

220 Transfer Transfer transformer DC

output adjustment (H)

ALL 165

<0-255>

M3

221 Transfer Transfer transformer DC

output adjustment (C)

ALL 179

<0-255>

M3

222 Transfer Transfer transformer DC

output adjustment (L)

ALL 126

<0-255>

M3

233 Separa-

tion

Separation transformer DC output adjustment (H)

ALL 64

<0-255>

M3

234 Separa-

tion

Separation transformer DC output adjustment (C)

ALL 65

<0-255>

M3

235 Separa-

tion

Separation transformer DC output adjustment (L)

ALL 46

<0-255>

M3

280 Process Forced performing of idling

for toner recycle

ALL - M Perform this adjustment

before the replacement of the developer material. (The toner is forcibly removed from the cleaner.)

6

286 Laser Laser power adjustment ALL 63

<0-255>

M When the value

increases, the laser output increases correspondingly.

3

305 Scanner Image location adjustment

of secondary scanning direction (scanner section)

ALL 125

<92-164>

SYS When the value

increases by “1”, the image shifts by approx.

0.137 mm toward the trailing edge of the paper.

1

05/12

2 - 48

306 Scanner Image location adjustment

of primary scanning direction (scanner section)

ALL 156

<0-255>

SYS When the value

increases by “1”, the image shifts by approx.

0.0846 mm toward the front side of the paper.

1

308 Scanner Distortion mode ALL - - Moves carriages to the

adjusting position. (Chap. 3.2.4)

6

340 Scanner Reproduction ratio adjust-

ment of secondary scanning direction (scanner section)

ALL 129

<0-255>

SYS When the value

increases by “1”, the reproduction ratio in the secondary scanning direction (vertical to paper feeding direction) increases by approx.

0.223%.

1

354 RADF Adjustment of

RADF paper alignment

for single sided original

ALL 10

<0-20>

SYS When the value

increases by “1”, the aligning amount increases by approx.

0.5 mm.

1

355 for double

sided original

ALL 10

<0-20>

SYS 1

356 RADF Automatic adjustment of

RADF sensor and EEPROM initialization

ALL - SYS Performs the adjustment

and initialization when the RADF board or RADF sensor is replaced.

6

357 RADF Fine adjustment of RADF

transport speed

ALL 50

<0-100>

SYS When the value

increases by “1”, the reproduction ratio of the secondary scanning direction when using the RADF increases by approx. 0.1%.

1

358 RADF RADF sideways deviation

adjustment

ALL 128

<0-255>

SYS When the value

increases by “1”, the image of original fed from the RADF shifts toward the rear side of paper by approx.

0.0846 mm.

1

359 Scanner Carriage position adjust-

ment during scanning from RADF

ALL 128

<0-255>

SYS When the value

increases by “1”, the carriage position when using the RADF shifts by approx. 0.1 mm toward the original feeding side.

1

365 RADF RADF lead-

ing edge position adjustment

for single sided original

ALL 50

<0-100>

SYS When the value

increases by “1”, the copied image of original fed from the RADF shifts toward the trailing edge of paper by approx.

0.1 mm.

1

366 for double

sided original

ALL 50

<0-100>

SYS 1

Adjustment mode (05) <e-STUDIO200L/230/280>

Code

Classi-

fication

Items

Func-

tion

Default

<Accept-

able

value>

RAM Contents

Proce-

dure

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 49

2

367 RADF RADF original guide width

adjustment (Minimum)

ALL - - Stores the current width

of RADF original guide by keying in this code with the guide set at the minimum width. Perform this adjustment when the RADF board or volume is replaced, or when the code (05-356) is performed.

6

368 RADF RADF original guide width

adjustment (Maximum)

ALL - - Stores the current width

of RADF original guide by keying in this code with the guide set at the maximum width. Perform this adjustment when the RADF board or volume is replaced, or when the code (05-356) is performed.

6

401 Laser Fine adjustment of polygo-

nal motor rotation speed (adjustment of primary scanning direction reproduction ratio)

PRT 136

<0-255>

M When the value

increases by “1”, the reproduction ratio of primary scanning direction increases by approx.

0.07%. (approx. 0.1 mm/ step)

1

405 PPC 134

<0-255>

M1

410 Laser Adjustment of primary

scanning laser writing start position.

PPC 128

<0-255>

M When the value

increases by “1”, the writing start position shifts to the front side by approx.

0.0423 mm.

1

411 PRT 153

<0-255>

M1

421 Drive Adjustment of secondary

scanning direction reproduction ratio (fine adjustment of main motor speed)

PPC/

PRT

129

<0-255>

M When the value

increases by “1”, the reproduction ratio of secondary scanning direction increases by approx.

0.04%.

1

422 FAX 139

<0-255>

M1

424 Drive Fine adjustment of exit

motor speed

PPC/

PRT

160

<0-255>

M When the value

increases by “1”, the rotation becomes faster by approx. 0.05%.

1

425 FAX 121

<0-255>

M1

Adjustment mode (05) <e-STUDIO200L/230/280>

Code

Classi-

fication

Items

Func-

tion

Default

<Accept-

able

value>

RAM Contents

Proce-

dure

04/09

2 - 50

430 Image Top margin adjustment

(blank area at the leading edge of the paper)

PPC 0

<0-255>

M When the value

increases by “1”, the blank area becomes wider by approx.

0.0423 mm.

1

431 Image Left margin adjustment

(blank area at the left of the paper along the paper feeding direction)

PPC 0

<0-255>

M1

432 Image Right margin adjustment

(blank area at the right of the paper along the paper feeding direction)

PPC 0

<0-255>

M1

433 Image Bottom margin adjustment

(blank area at the trailing edge of the paper)

PPC 0

<0-255>

M1

434-0 Image Bottom margin adjustment

(blank area at the trailing edge of the paper)/ Reverse side at duplexing

PPC/

PRT29<0-255>

M4

434-1 Image Right margin adjustment

(blank area at the right of the paper along the paper feeding direction)/Reverse side at duplexing

PPC/

PRT29<0-255>

M4

435 Image Top margin adjustment

(blank area at the leading edge of the paper)

PRT 24

<0-255>

M1

436 Image Left margin adjustment

(blank area at the left of the paper along the paper feeding direction)

PRT 0

<0-255>

M1

437 Image Right margin adjustment

(blank area at the right of the paper along the paper feeding direction)

PRT 0

<0-255>

M1

438 Image Bottom margin adjustment

(blank area at the trailing edge of the paper)

PRT 0

<0-255>

M1

440 Laser Adjustment of

secondary scanning laser writing start position

Upper drawer

ALL 8

<Refer to

content>

M When the value

increases by “1”, the image shifts toward the leading edge of the paper by approx.

0.2 mm. <Acceptable value> e-STUDIO230, e-STUDIO280: 0-15 e-STUDIO200L, e-STUDIO230L/S, e-STUDIO280S: 0-40

1

441 Lower

drawer

ALL 21

<0-40>

M1

442 Bypass

feeding

ALL 8

<0-15>

M1

443 LCF ALL 8

<0-15>

M1

444 PFP ALL 8

<0-15>

M1

445 Duplex

feeding

ALL 8

<0-15>

M1

Adjustment mode (05) <e-STUDIO200L/230/280>

Code

Classi-

fication

Items

Func-

tion

Default

<Accept-

able

value>

RAM Contents

Proce-

dure

04/09

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 51

2

448-0 Paper

feeding

Paper aligning amount adjustment at the registration section (PFP upper drawer/Plain paper)

Long size ALL 10

<0-63>

M When the value

increases by “1”, the aligning amount increases by approx.

0.8 mm. <Paper length> Long size:

330 mm or longer

Middle size:

220 mm to 329 mm

Short size:

219 mm or shorter

4

448-1 Middle

size

ALL 10

<0-63>

M4

448-2 Short size ALL 8

<0-63>

M4

449-0 Paper

feeding

Paper aligning amount adjustment at the registration section (PFP lower drawer/Plain paper)

Long size ALL 10

<0-63>

M4

449-1 Middle

size

ALL 10

<0-63>

M4

449-2 Short size ALL 8

<0-63>

M4

450-0 Paper

feeding

Paper aligning amount adjustment at the registration section (Upper drawer/Plain paper)

Long size ALL 17

<0-63>

M4

450-1 Middle

size

ALL 17

<0-63>

M4

450-2 Short size ALL 17

<0-63>

M4

452-0 Paper

feeding

Paper aligning amount adjustment at the registration section (Lower drawer/Plain paper)

Long size ALL 12

<0-63>

M4

452-1 Middle

size

ALL 10

<0-63>

M4

452-2 Short size ALL 10

<0-63>

M4

455-0 Paper

feeding

Paper aligning amount adjustment at the registration section (Duplex feeding/Plain paper)

Long size ALL 20

<0-63>

M4

455-1 Middle

size

ALL 20

<0-63>

M4

455-2 Short size ALL 30

<0-63>

M4

457 Paper

feeding

Paper aligning amount adjustment at the registration section (LCF/Plain paper)

ALL 8

<0-63>

M1

Adjustment mode (05) <e-STUDIO200L/230/280>

Code

Classi-

fication

Items

Func-

tion

Default

<Accept-

able

value>

RAM Contents

Proce-

dure

2 - 52

458-0 Paper

feeding

Paper aligning amount adjustment at the registration section (Bypass feeding/Plain paper)

Long size ALL 26

<0-63>

M When the value

increases by “1”, the aligning amount increases by approx.

0.8 mm. <Paper length> Long size:

330 mm or longer

Middle size:

220 mm to 329 mm

Short size:

219 mm or shorter

* Postcard is sup-

ported only for JPN model.

4

458-1 Middle

size

ALL 26

<0-63>

M4

458-2 Short size ALL 25

<0-63>

M4

460-0 Paper

feeding

Paper aligning amount adjustment at the registration section (Bypass feeding/Thick paper 1)

Long size ALL 26

<0-63>

M4

460-1 Middle

size

ALL 26

<0-63>

M4

460-2 Short size ALL 26

<0-63>

M4

461-0 Paper

feeding

Paper aligning amount adjustment at the registration section (Bypass feeding/Thick paper 2)

Long size ALL 17

<0-63>

M4

461-1 Middle

size

ALL 17

<0-63>

M4

461-2 Short size ALL 17

<0-63>

M4

462-0 Paper

feeding

Paper aligning amount adjustment at the registration section (Bypass feeding/Thick paper 3)

Long size ALL 17

<0-63>

M4

462-1 Middle

size

ALL 17

<0-63>

M4

462-2 Short size ALL 17

<0-63>

M4

462-3 Postcard ALL 14

<0-63>

M4

463-0 Paper

feeding

Paper aligning amount adjustment at the registration section (Bypass feeding/OHP film)

Long size ALL 26

<0-63>

M4

463-1 Middle

size

ALL 26

<0-63>

M4

463-2 Short size ALL 26

<0-63>

M4

464-0 Paper

feeding

Paper aligning amount adjustment at the registration section (Bypass feeding /Envelope)

Long size ALL 26

<0-63>

M4

464-1 Middle

size

ALL 26

<0-63>

M4

464-2 Short size ALL 26

<0-63>

M4

Adjustment mode (05) <e-STUDIO200L/230/280>

Code

Classi-

fication

Items

Func-

tion

Default

<Accept-

able

value>

RAM Contents

Proce-

dure

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 53

2

466-0 Paper

feeding

Adjustment of paper pushing amount/ Bypass feeding

Plain paper

ALL 0

<0-255>

M When the value

increases by “1”, the driving speed of bypass feed roller increases by approx. 0.2 ms when the paper transport is started from the registration section. * Postcard is sup-

ported only for JPN model.

4

466-1 Postcard ALL 0

<0-255>

M4

466-3 Envelope ALL 0

<0-255>

M4

466-4 Thick

paper 1

ALL 0

<0-255>

M4

466-5 Thick

paper 2

ALL 0

<0-255>

M4

466-6 Thick

paper 3

ALL 0

<0-255>

M4

466-7 OHP film ALL 0

<0-255>

M4

468-0 Finisher Fine adjust-

ment of binding position/ folding position

A4-R/LT-R ALL 0

<-14-14>

M When the value

increases by “1”, the binding/folding position shifts toward the right page by 0.25 mm.

4

468-1 B4 ALL 0

<-14-14>

M4

468-2 A3/LD ALL 0

<-14-14>

M4

469-0 Paper

feeding

Paper aligning amount adjustment at the registration section (Upper drawer)

Thick paper 1 Long size

ALL 20

<0-63>

M When the value

increases by “1”, the aligning amount increases by approx.

0.8 mm. <Paper length> Long size:

330 mm or longer

Middle size:

220 mm to 329 mm

Short size:

219 mm or shorter

4

469-1 Thick

paper 1 Middle size

ALL 20

<0-63>

M4

469-2 Thick

paper 1 Short size

ALL 20

<0-63>

M4

469-3 Thick

paper 2 Long size

ALL 20

<0-63>

M4

469-4 Thick

paper 2 Middle size

ALL 22

<0-63>

M4

469-5 Thick

paper 2 Short size

ALL 19

<0-63>

M4

470-0 Paper

feeding

Paper aligning amount adjustment at the registration section (Lower drawer/Thick paper 1)

Long size ALL 20

<0-63>

M4

470-1 Middle

size

ALL 22

<0-63>

M4

470-2 Short size ALL 19

<0-63>

M4

471-0 Paper

feeding

Paper aligning amount adjustment at the registration section (PFP upper drawer/Thick paper 1)

Long size ALL 20

<0-63>

M4

471-1 Middle

size

ALL 22

<0-63>

M4

471-2 Short size ALL 19

<0-63>

M4

Adjustment mode (05) <e-STUDIO200L/230/280>

Code

Classi-

fication

Items

Func-

tion

Default

<Accept-

able

value>

RAM Contents

Proce-

dure

2 - 54

472-0 Paper

feeding

Paper aligning amount adjustment at the registration section (PFP lower drawer/Thick paper 1)

Long size ALL 20

<0-63>

M When the value

increases by “1”, the aligning amount increases by approx.

0.8 mm. <Paper length> Long size:

330 mm or longer

Middle size:

220 mm to 329 mm

Short size:

219 mm or shorter

4

472-1 Middle

size

ALL 22

<0-63>

M4

472-2 Short size ALL 19

<0-63>

M4

473 Paper

feeding

Paper aligning amount adjustment at the registration section (LCF/Thick paper 1)

ALL 8

<0-63>

M1

474-0 Paper

feeding

Paper aligning amount adjustment at the registration section (Duplex feeding/Thick paper 1)

Long size ALL 24

<0-63>

M4

474-1 Middle

size

ALL 24

<0-63>

M4

474-2 Short size ALL 33

<0-63>

M4

497-0 Laser Adjustment of

drawer sideways deviation

Upper drawer

ALL 128

<0-255>

M When the value

increases by “1”, the image shifts toward the front side by 0.0423 mm.

4

497-1 Lower

drawer

ALL 128

<0-255>

M4

497-2 PFP upper

drawer

ALL 128

<0-255>

M4

497-3 PFP lower

drawer

ALL 128

<0-255>

M4

497-4 LCF ALL 128

<0-255>

M4

497-5 Bypass

feeding

ALL 128

<0-255>

M4

498-0 Laser Adjustment of

primary scanning laser writing start position at duplex feeding

Long size ALL 148

<0-255>

M When the value

increases by “1”, the image shifts toward the front side by 0.0423 mm.

4

498-1 Short size

(A4/LT or smaller)

ALL 148

<0-255>

M4

501 Image Density

adjustment Fine adjustment of “manual density”/ Center value

Photo PPC 128

<0-255>

SYS When the value

increases, the image at the center step becomes darker.

1

503 Text/Photo PPC 128

<0-255>

SYS 1

504 Text PPC 128

<0-255>

SYS 1

505 Image Density

adjustment Fine adjustment of “manual density”/ Light step value

Text/Photo PPC 20

<0-255>

SYS When the value

increases, the image of the “light” steps becomes lighter.

1

506 Photo PPC 20

<0-255>

SYS 1

507 Text PPC 20

<0-255>

SYS 1

Adjustment mode (05) <e-STUDIO200L/230/280>

Code

Classi-

fication

Items

Func-

tion

Default

<Accept-

able

value>

RAM Contents

Proce-

dure

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 55

2

508 Image Density

adjustment Fine adjustment of “manual density”/ Dark step value

Text/Photo PPC EUR:20

UC:20

JPN:30

<0-255>

SYS When the value

increases, the image of the “dark” steps becomes darker.

1

509 Photo PPC EUR:24

UC:24

JPN:24

<0-255>

SYS 1

510 Text PPC EUR:20

UC:20

JPN:27

<0-255>

SYS 1

512 Image Density

adjustment Fine adjustment of “automatic density”

Photo PPC 128

<0-255>

SYS When the value

increases, the image becomes darker.

1

514 Text/Photo PPC 128

<0-255>

SYS 1

515 Text PPC 128

<0-255>

SYS 1

532 Image Range correc-

tion/Background peak adjustment

Text/Photo PPC 40

<0-255>

SYS When the value

increases, the background becomes more brightened.

1

533 Photo PPC 16

<0-255>

SYS 1

534 Text PPC 64

<0-255>

SYS 1

570 Image Range correc-

tion on original manually set on the original glass

Text/Photo PPC EUR:12

UC:12 JPN:22 <11-14,

21-24,

31-34,

41-44>

SYS Sets whether the values

of the background peak and text peak are fixed or not. One’s place is an adjustment for “automatic density” and ten’s place is for “manual density”. Once they are fixed, the range correction is performed with standard values. The values of the background peak and text peak affect the reproduction of the background density and text density respectively. 1: fixed/fixed 2: varied/fixed 3: fixed/varied 4: varied/varied * Background peak/

Text peak

1

571 Photo PPC 12

<11-14,

21-24,

31-34,

41-44>

SYS 1

572 Text PPC 22

<11-14,

21-24,

31-34,

41-44>

SYS 1

Adjustment mode (05) <e-STUDIO200L/230/280>

Code

Classi-

fication

Items

Func-

tion

Default

<Accept-

able

value>

RAM Contents

Proce-

dure

2 - 56

593 Image Gamma data

slope adjustment

Text/Photo PPC 0

<0-99>

SYS One’s place:

0: Equivalent to the set value 5 1 to 9: Select the slope of Gamma curve (The larger the value is, the larger the slope becomes.) Ten’s place: 0: Equivalent to the set value 5 1 to 9: Select the slope of low density (The smaller the value is, the darker the background becomes.) 00: Use default value

1

594 Image Photo PPC 0

<0-99>

SYS 1

595 Image Text PPC 0

<0-99>

SYS 1

620 Image Sharpness

adjustment

Text/Photo PPC EUR: 1

UC: 1 JPN: 0 <0-99>

SYS When the value

increases, the image becomes sharper. When the value decreases, the image becomes softer. The smaller the value is, the less the moire becomes. One’s place: Fixed value (05-620 is “1”, 05-621 is “2”, 05-622 is “5”) Ten’s place: Adjustable from 0 to 9 regarding the default value as the standard (The larger the value is, the sharper the image becomes.) * When entering “0” on

the ten's place, this value is not displayed on the entry screen.

1

621 Photo PPC 2

<0-99>

SYS 1

622 Text PPC EUR: 45

UC: 45

JPN: 45

<0-99>

SYS 1

653 Image Adjustment of

smudged/faint text

Text/Photo PPC EUR: 208

UC: 208

JPN: 216

<0-255>

SYS Adjusts the level of the

smudged/faint text. With increasing the value, the faint text is suppressed, and with decreasing it, the smudged text is suppressed.

1

654 Image Adjustment of

smudged/faint text

PS PRT 5

<0-9>

M Adjustment of the

smudged/faint text. With decreasing the value, the faint text is suppressed, and with increasing it, the smudged text is suppressed.

1

655 PCL PRT 5

<0-9>

M1

Adjustment mode (05) <e-STUDIO200L/230/280>

Code

Classi-

fication

Items

Func-

tion

Default

<Accept-

able

value>

RAM Contents

Proce-

dure

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 57

2

667-0 Image Density adjustment of cop-

ied image

PPC 0

<0-10>

M Adjusts the density level

of copied image. When the value decreases, the text becomes lighter.

4

667-1 PPC 4

<0-10>

M4

667-2 PPC 5

<0-10>

M4

667-3 PPC 6

<0-10>

M4

667-4 PPC 10

<0-10>

M4

672-0 Image Adjustment of

printer image density

Normal PRT 0

<0-10>

M Adjustment of the image

density. With decreasing the value, the text becomes lighter.

4

672-1 PRT 4

<0-10>

M4

672-2 PRT 5

<0-10>

M4

672-3 PRT 6

<0-10>

M4

672-4 PRT 10

<0-10>

M4

676-0 Toner sav-

ing

PRT 0

<0-10>

M4

676-1 PRT 2

<0-10>

M4

676-2 PRT 3

<0-10>

M4

676-3 PRT 4

<0-10>

M4

676-4 PRT 5

<0-10>

M4

693 Image Range correc-

tion on original set on the RADF

Text/Photo PPC EUR:12

UC:12 JPN:22 <11-14,

21-24,

31-34,

41-44>

SYS Sets whether the values

of the background peak and text peak are fixed or not. One’s place is an adjustment for “automatic density” and ten’s place is for “manual density”. Once they are fixed, the range correction is performed with standard values. The values of the background peak and text peak affect the reproduction of the background density and text density respectively. 1: fixed/fixed 2: varied/fixed 3: fixed/varied 4: varied/varied * Background peak/

Text peak

1

694 Photo PPC 12

<11-14,

21-24,

31-34,

41-44>

SYS 1

695 Text PPC 22

<11-14,

21-24,

31-34,

41-44>

SYS 1

Adjustment mode (05) <e-STUDIO200L/230/280>

Code

Classi-

fication

Items

Func-

tion

Default

<Accept-

able

value>

RAM Contents

Proce-

dure

2 - 58

700 Image Adjustment of

binarized threshold (Text)

Center value

FAX 120

<0-255>

SYS When the value

increases, the image at the center step becomes lighter.

1

701 Light step

value

FAX 2 0

<0-255>

SYS When the value

increases, the image of “light” side becomes lighter.

1

702 Dark step

value

FAX 2 0

<0-255>

SYS When the value

increases, the image of “dark” side becomes darker.

1

710 Image Density

adjustment Fine adjustment of “manual density”/ Center value

Photo FAX 128

<0-255>

SYS When the value

increases, the image at the center step becomes darker.

1

714 Text/Photo FAX 128

<0-255>

SYS 1

715 Image Density

adjustment Fine adjustment of “manual density”/ Light step value

Photo FAX 20

<0-255>

SYS When the value

increases, the image of the “light” steps becomes lighter.

1

719 Text/Photo FAX 20

<0-255>

SYS 1

720 Image Density

adjustment Fine adjustment of “manual density”/ Dark step value

Photo FAX 20

<0-255>

SYS When the value

increases, the image of the “dark” steps becomes darker.

1

724 Text/Photo FAX 20

<0-255>

SYS 1

725 Image Density

adjustment Fine adjustment of “automatic density”

Photo FAX 128

<0-255>

SYS When the value

increases, the image becomes darker.

1

729 Text/Photo FAX 128

<0-255>

SYS 1

820 Image Range correc-

tion/Text peak adjustment

Text/Photo SCN 224

<0-255>

SYS When the value

decreases, the text becomes darker.

1

821 Text SCN 224

<0-255>

SYS 1

822 Photo SCN 239

<0-255>

SYS 1

Adjustment mode (05) <e-STUDIO200L/230/280>

Code

Classi-

fication

Items

Func-

tion

Default

<Accept-

able

value>

RAM Contents

Proce-

dure

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 59

2

825 Image Range correc-

tion on original manually set on the original glass

Text/Photo SCN 12

<11-14,

21-24,

31-34,

41-44>

SYS Sets whether the values

of the background peak and text peak are fixed or not. One’s place is an adjustment for “automatic density” and ten’s place is for “manual density”. Once they are fixed, the range correction is performed with standard values. The values of the background peak and text peak affect the reproduction of the background density and text density respectively. 1: fixed/fixed 2: varied/fixed 3: fixed/varied 4: varied/varied * Background peak/

Text peak

1

826 Text SCN 12

<11-14,

21-24,

31-34,

41-44>

SYS 1

827 Photo SCN 12

<11-14,

21-24,

31-34,

41-44>

SYS 1

830 Image Range correc-

tion on original set on the RADF

Text/Photo SCN 12

<11-14,

21-24,

31-34,

41-44>

SYS Sets whether the value

of the background peak and text peak are fixed or not. One’s place is an adjustment for “automatic density” and ten’s place is for “manual density”. Once they are fixed, the range correction is performed with standard values. The values of the background peak and text peak affect the reproduction of the background density and text density respectively. 1: fixed/fixed 2: varied/fixed 3: fixed/varied 4: varied/varied * Background peak/

Text peak

1

831 Text SCN 12

<11-14,

21-24,

31-34,

41-44>

SYS 1

832 Photo SCN 12

<11-14,

21-24,

31-34,

41-44>

SYS 1

835 Image Range correc-

tion/Background peak adjustment

Text/Photo SCN 48

<0-255>

SYS When the value

increases, the background becomes more brightened.

1

836 Text SCN 48

<0-255>

SYS 1

837 Photo SCN 40

<0-255>

SYS 1

845 Image Density

adjustment Fine adjustment of “manual density”/ Center value

Text/Photo SCN 128

<0-255>

SYS When the value

increases, the image at the center step becomes darker.

1

846 Text SCN 128

<0-255>

SYS 1

847 Photo SCN 128

<0-255>

SYS 1

Adjustment mode (05) <e-STUDIO200L/230/280>

Code

Classi-

fication

Items

Func-

tion

Default

<Accept-

able

value>

RAM Contents

Proce-

dure

04/09

2 - 60

850 Image Density

adjustment Fine adjustment of “manual density”/ Light step value

Text/Photo SCN 20

<0-255>

SYS When the value

increases, the image of the “light” steps becomes lighter.

1

851 Text SCN 20

<0-255>

SYS 1

852 Photo SCN 20

<0-255>

SYS 1

855 Image Density

adjustment Fine adjustment of “manual density”/ Dark step value

Text/Photo SCN 20

<0-255>

SYS When the value

increases, the image of the “dark” steps becomes darker.

1

856 Text SCN 20

<0-255>

SYS 1

857 Photo SCN 20

<0-255>

SYS 1

860 Image Density

adjustment Fine adjustment of “automatic density”

Text/Photo SCN 128

<0-255>

SYS When the value

increases, the image becomes darker.

1

861 Text SCN 128

<0-255>

SYS 1

862 Photo SCN 128

<0-255>

SYS 1

865-0 Image Sharpness

adjustment (Text/Photo)

Reproduction ratio 40% or smaller

SCN 1

<0-99>

SYS When the value

increases, the image becomes sharper. When the value decreases, the image becomes softer. The smaller the value is, the less the moire becomes.

One's place: Fixed value (05-865 is “1”, 05-866 is “2”, 05-867 is “5”) Ten's place: Sharpness intensity (0: Use default value, 1-9: Filter intensity)

4

865-1 Reproduc-

tion ratio 41-80%

SCN 1

<0-99>

SYS 4

865-2 Reproduc-

tion ratio 81% or larger

SCN 1

<0-99>

SYS 4

866-0 Image Sharpness

adjustment (Text)

Reproduction ratio 40% or smaller

SCN 2

<0-99>

SYS 4

866-1 Reproduc-

tion ratio 41-80%

SCN 2

<0-99>

SYS 4

866-2 Reproduc-

tion ratio 81% or larger

SCN 2

<0-99>

SYS 4

867-0 Image Sharpness

adjustment (Photo)

Reproduction ratio 40% or smaller

SCN 5

<0-99>

SYS 4

867-1 Reproduc-

tion ratio 41-80%

SCN 5

<0-99>

SYS 4

867-2 Reproduc-

tion ratio 81% or larger

SCN 5

<0-99>

SYS 4

Adjustment mode (05) <e-STUDIO200L/230/280>

Code

Classi-

fication

Items

Func-

tion

Default

<Accept-

able

value>

RAM Contents

Proce-

dure

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 61

2

913 Image Range correc-

tion on original manually set on the original glass

Custom Mode 1

PPC EUR:12

UC:12 JPN:22 <11-14,

21-24,

31-34,

41-44>

SYS Set whether the values

of the background peak and text peak are fixed or not. One's place is an adjustment for “automatic density” and ten's place is for “manual density”. Once they are fixed, the range correction is performed with standard values. The values of the background peak and text peak affect the reproduction of the background density and text density respectively. 1: fixed/fixed 2: varied/fixed 3: fixed/varied 4: varied/varied * Background peak/

Text peak

1

914 Custom

Mode 2

PPC 22

<11-14,

21-24,

31-34,

41-44>

SYS 1

915 Custom

Mode 3

PPC 12

<11-14,

21-24,

31-34,

41-44>

SYS 1

916 Image Range correc-

tion on original set on the RADF

Custom Mode 1

PPC EUR:12

UC:12 JPN:22 <11-14,

21-24,

31-34,

41-44>

SYS Set whether the values

of the background peak and text peak are fixed or not. One's place is an adjustment for “automatic density” and ten's place is for “manual density”. Once they are fixed, the range correction is performed with standard values. The values of the background peak and text peak affect the reproduction of the background density and text density respectively. 1: fixed/fixed 2: varied/fixed 3: fixed/varied 4: varied/varied * Background peak/

Text peak

1

917 Custom

Mode 2

PPC 22

<11-14,

21-24,

31-34,

41-44>

SYS 1

918 Custom

Mode 3

PPC 12

<11-14,

21-24,

31-34,

41-44>

SYS 1

919 Image Range correc-

tion Background peak adjustment

Custom Mode 1

PPC 40

<0-255>

SYS When the value

increases, the background becomes more brightened.

1

920 Custom

Mode 2

PPC 64

<0-255>

SYS 1

921 Custom

Mode 3

PPC 16

<0-255>

SYS 1

Adjustment mode (05) <e-STUDIO200L/230/280>

Code

Classi-

fication

Items

Func-

tion

Default

<Accept-

able

value>

RAM Contents

Proce-

dure

2 - 62

922 Image Sharpness

adjustment

Custom Mode 1

PPC 1

<0-99>

SYS When the value

increases, the image becomes sharper. When the value decreases, the image becomes softer. The smaller the value is, the less the moire becomes. One's place: Fixed value (05-922 is “1”, 05-923 is “5”, 05-924 is “2”) Ten’s place: Adjustable from 0 to 9 regarding the default value as the standard (The larger the value is, the sharper the image becomes.) * When entering “0” on

the ten's place, this value is not displayed on the entry screen.

1

923 Custom

Mode 2

PPC EUR:45

UC:45 JPN:45

<0-99>

SYS 1

924 Custom

Mode 3

PPC 2

<0-99>

SYS 1

928 Image Adjustment of

smudged/faint text

Custom Mode 1

PPC 208

<0-255>

SYS Adjustment of the

smudged/faint text. With increasing the value, the faint text is suppressed, and with decreasing it, the smudged text is suppressed.

1

931 Image Density

adjustment Fine adjustment of “manual density”/ Center value

Custom Mode 1

PPC 128

<0-255>

SYS When the value

increases, the image of the center step becomes darker.

1

932 Custom

Mode 2

PPC 128

<0-255>

SYS 1

933 Custom

Mode 3

PPC 128

<0-255>

SYS 1

934 Image Density

adjustment Fine adjustment of “manual density”/ Light step value

Custom Mode 1

PPC 20

<0-255>

SYS When the value

increases, the image of the “light” step density becomes lighter.

1

935 Custom

Mode 2

PPC 20

<0-255>

SYS 1

936 Custom

Mode 3

PPC 20

<0-255>

SYS 1

937 Image Density

adjustment Fine adjustment of “manual density”/ Dark step value

Custom Mode 1

PPC 20

<0-255>

SYS When the value

increases, the image of the “dark” step density becomes darker.

1

938 Custom

Mode 2

PPC 20

<0-255>

SYS 1

939 Custom

Mode 3

PPC 20

<0-255>

SYS 1

940 Image Density

adjustment Fine adjustment of “automatic density”

Custom Mode 1

PPC 128

<0-255>

SYS When the value

increases, the image becomes darker.

1

941 Custom

Mode 2

PPC 128

<0-255>

SYS 1

942 Custom

Mode 3

PPC 128

<0-255>

SYS 1

Adjustment mode (05) <e-STUDIO200L/230/280>

Code

Classi-

fication

Items

Func-

tion

Default

<Accept-

able

value>

RAM Contents

Proce-

dure

05/05

ERROR CODE AND SELF-DIAGNOSTIC MODE

2 - 63

2

943 Image Gamma data

slope adjustment

Custom Mode 1

PPC 0

<0-99>

SYS One’s place:

0: Equivalent to the set value 5 1 to 9: Select the slope of Gamma curve (The larger the value is, the larger the slope becomes.) Ten’s place: 0: Equivalent to the set value 5 1 to 9: Select the slope of low density (The smaller the value is, the darker the background becomes.) 00: Use default value

1

944 Custom

Mode 2

PPC 0

<0-99>

SYS 1

945 Custom

Mode 3

PPC 0

<0-99>

SYS 1

976 Mainte-

nance

Equipment number (serial number) entry

ALL - SYS When this adjustment is

performed with this code, the setting code (08-995) is also performed automatically (10 digits).

1

Adjustment mode (05) <e-STUDIO200L/230/280>

Code

Classi-

fication

Items

Func-

tion

Default

<Accept-

able

value>

RAM Contents

Proce-

dure

05/05

2 - 64

2.2.6 Adjustment mode (05) (e-STUDIO202L/203L/232/233/282/283)

Procedure 1

Procedure 2

Procedure 3

Procedure 4

Items in the adjustment mode list in the following pages can be corrected or changed in the adjustment mode (05). Turn ON the power with pressing the digital keys [0] and [5] simultaneously in order to enter this mode.

[0][5]

[POWER]

OFF/ON

(Exit)

[Digital key]

(Code)

[START]

[CANCEL]

[Digital key]

*

[FUNCTION CLEAR]

(Key in a value)

[CLEAR]

(Corrects value)

[ENTER]

or

[INTERRUPT]

(Stores value in RAM)

([FAX])

(Test copy)

*Press [

FUNCTION CLEAR

] to enter minus (-).

[0][5]

[POWER]

OFF/ON

(Exit)

(Code)

[START]

[ENTER]

or

[INTERRUPT]

(Value unchangeable)

([FAX])

(Test copy)

Value

displayed

()

[0][5]

[POWER]

OFF/ON

(Exit)

[Digital key]

(Code)

[START]

[CANCEL]

[UP]

or

[DOWN]

(Adjust a value)

[CLEAR]

(Corrects value)

[ENTER]

or

[INTERRUPT]

(Stores value in RAM)

([FAX])

(Test copy)

[0][5]

[POWER]

OFF/ON

(Exit)

[Digital key]

(Code)

[Digital key]

*

[FUNCTION CLEAR]

[START]

[Digital key]

(Sub code)

[CLEAR]

(Corrects value)

[CLEAR]

(Corrects value)

[ENTER]

or

[INTERRUPT]

*Press [FUNCTION CLEAR] to enter minus (-).

(Key in a value)

Stores value

in RAM

()

([FAX])

(Test copy)

[CANCEL]

[START]

07/11

Toshiba e-STUDIO230L, e-STUDIO280L, e-STUDIO282L, e-STUDIO200L, e-STUDIO203L Service Handbook

Specifications and Main Features

Frequently Asked Questions

User Manual
