EQUIUM 7000D Product Specifications
PLATFORM
SERIES NAME EQUIUM 7000D
PART NUMBER As Listed: See Configuration Page
PROCESSOR
Intel Pentium II w/MMX
Available processor speeds
Integrated Coprocessor Yes
Processor Cache (L1) Capacity 32KB: (16KB code; 16KB data)
Bus Speed 66 MHz
LEVEL 2 (L2) CACHE Yes: 512KB Pipeline Burst SRAM Integrated into CPU
Data Bus Width/Address Bus Width 64-bit/64-bit
Local Clock Bus Speed Half of the Processor clock (116 MHz, 133MHz or 150MHz)
SYSTEM BOARD
Form Factor NLX
Chipset 82440LX
Down Components
I/O Controller Yes
Graphics Controller ATI Rage Pro 2X AGP
Audio Controller Crystal Audio CS4236B
SYSTEM ARCHITECTURE
Form Factor NLX Riser Adapter (3-PCI and 1-PCI/ISA)
PCI BUS (V2.1): (32-bit, 33mhz) Yes: 3-Half-length slot
ISA BUS: (16-bit, 8MHz) Yes: 1-Shared PCI/ISA full-length slot
HARDWARE MONITORING (DMI ASIC)
MEMORY: SDRAM
Type 168-pin SDRAM DIMM’s with gold-plated contacts, unbuffered
Available Standard Configurations (x*32MB)
Maximum 256 MB
ECC/Parity Support Optional (No parity standard)
Local Clock Bus Speed 66 MHz
Socket type: (2) 168-pin gold plated DIMM sockets: Accepts 16/32/64/128MB memory
BIOS (2Mbit FLASH EEPROM, 256KB)
PnP 1.0a Support Yes
Advanced Power Management 1.2 (APM) Yes
DMI 2.0 Compliant Yes
UDMA - 33 Yes
POST Yes
Machine ID Yes
DPMS Support Yes
Toshiba Secure Sleep Yes
SOUND SYSTEM
Chipsets: Crystal CS4236B
Compatibility Yamaha OPL3 and MPU-401
FM Synthesis Yes
16-bit stereo audio full duplexed Yes
Built-in microphone No
Yes
233MHz, 266 Mhz, or 300MHz (As Listed: See Configuration Page)
Yes: LM78 (Voltage, Temperature, Fan Speed, and Chasis Intrusion)
32 MB or 64MB (As Listed: See Configuration Page)
Yes
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1997 TAIS 7000dr.doc Rev. 6 04/04/00 nmm. Page 1 of 4
EQUIUM 7000D Product Specifications
PLATFORM (con.)
SERIES NAME EQUIUM 7000D
PART NUMBER As Listed: See Configuration Page
EXTERNAL INTERFACES All ports color coded for easy installation
Two 9/25-Pin Serial (16550 UART compliant) Yes
Two Universal Serial Bus ports
One 25-Pin Parallel (IEEEP1284 compliant) Yes: EPP/ECP compliant
One 15-Pin RGB (SVGA video) Yes
One (PS/2) Mouse Port Yes
One (PS/2) 104 Keyboard Yes
One External Microphone jack Yes
Line-out (3.5mm mini jack, stereo, 0.7V rms) Yes
AC IN (Standard 2 prong ) Yes
VIDEO
Video Memory: SGRAM 2 MB expandable to 6MB (via SO-DIMM socket)
Speed 40ns
Data Bus Width 64-bit
Clock Speed 100 MHz
Graphic Controller
Standards Supported DPMS Power Managment, DDC1, DDC2B+, PnP Compliant
Local Bus support Yes: PCI Bus (33 Mhz, 32-bit)
Controller Chip ATI 3D Rage Pro 2X (AGP -- Accelerated Graphics Port)
Connected Bus type AGP 1.0
Bus Speed 133 MHz
64-bit BitBLT Engine Yes
2D Supported Features BitBLT, Hardware Cursor (up to 64 x 64 x 2), DirectDraw,
3D Supported Features Yes: supports 24-bit color
AGP Support Yes: (133mhz with sidebands and pipelining 64-bit PCI Graphics Accelerator)
Triangle Setup Yes
Modeling Fogging, lighting
Shading Gouraud shading
Rendering Texture mapping: Bilinear,Trilinear, Anti-aliasing, MIP mapping, Z-Buffering
Alpha-blending Yes
Direct3D support Yes
QuickDraw 3D RAVE support Yes
Open GL support Yes
Digital Video Accelerator
YUV Color Space Conversion Yes: Off-loads conversion from CPU for higher performance full motion video
Scaling/ Interpolation Yes: vertical & horizontal
Direct Video, DirectMPEG Yes
Motion Compensation Yes
SUPPORTED VIDEO RESOLUTIONS Colors/ Refresh Rate Colors/ Refresh Rate
(Non-interlaced unless otherwise specified) 2MB Memory 4MB Memory
1. Both ports operate from a single controller allowing 128 devices total, not per port. Throughput for the Universal Serial
Bus (UBS) is 12Mbits/sec.
1
640 x 480 32-bit 160 Hz 32-bit 160 Hz
800 x 600 32-bit 160 Hz 32-bit 160 Hz
1024 x 768 16-bit (64K) 140 Hz 32-bit 140 Hz
1152 x 864 16-bit (64K) 120 Hz 32-bit 100 Hz
1280 x 1024 8-bit (256) 100 Hz 24-bit (16.7M) 85 Hz
Supports 2 USB peripherals without external hub
Retangle Fill,Line Draw, Polygon Fill, Panning/Scrolling, Bit Masking,
Monochrome Expansion, Scssoring and full ROP support
without compromising picture quality or frame rate.
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1997 TAIS 7000dr.doc Rev. 6 04/04/00 nmm. Page 2 of 4
EQUIUM 7000D Product Specifications
CHASSIS (DESKTOP DESIGN)
SERIES NAME EQUIUM 7000D
PART NUMBER As Listed: See Configuration Page
EXPANSION BAY TOTAL
Internal 3.5” 2 1 1 (HDD)
5.25” 0 0 0
External 3.5” 1 0 1 (FDD)
As Listed: See Configuration Page 5.25”
EXPANSION SLOTS TOTAL
PCI: Half-Le ngth 3 3 0
PCI/ISA Shared: Full-length 1 1 0
POWER SUPPLY (200W)
Input (Voltage/Frequency) 115-230V; 50-60Hz, Switch Selectable
SUPPORTED SAFETY STANDARDS
US/Canada UL 1950 - CSA950-95, 3rd Edition, 7/28/95
CSA22.2 No.950-93, 3rd Edition
ICES-003, Issue 2
FCC Class B
Europe EN 60950 w/Nordic deviation
CE Mark
EN61000-4-2 (IEC 801-2), EN61000-4-3 (IEC 801-3), EN61000-4-4
TUV/GS Mark
Japan EN61000-4-5, VCCI Class 2 (ITE)
CERTIFICATIONS: Windows 95 & Windows NT logo, Novell Client, Ener gy Star
HARDWARE COMPLIANT: PC97, PC98, Wired For Management (WfM)
SECURITY
Hardware Chasis Lock (key mechanism/padlock) -- Lock not included
Keyboard/Mouse Lock Secure sleep
Miscellaneous Screen blank
Password Support Power-on, Supervisor/Administrator, User, Sleep
DIMENSIONS
BUNDLED SOFTWARE: Windows 95 or Windows NT Workstation v4.0 w/WindowsNT Service Pack 3 (optional);
Intel LanDesk Client Manager 3.1; Microsoft Internet Explorer 4.0.; Expert Intelligent Help(SystemWizard v1.4)
Online User’s Guide
CD’s Included: Backup CD, Recovery CD
WARRANTY: 3 Yr. Parts/One Yr. Labor (First Yr. On-site); 24 x 7 Dedicated technical support
ENVIRONMENTAL SPECIFICATIONS Operating Non-operating
Temperature: 50°F (10°C) to 95°F (35 °C) -4°F (-20°C) to 140°F (60°C)
Packaged: -30°C to 70°C -- --
Relative Humidity: 30% to 80% non-condensing 10% to 90% non-c ondensing
Shock: 10G; 1.5G w/CD-ROM installed 60G; 10G w/CD-ROM installed
Vibration (5~150Hz f/30 minutes, each axis) 0.3G
Packaged: 1.0G -- --
17.5”W x 17.0”D x 5.5”H
211 (CD-ROM)
AVAILABLE CONFIGURED
AVAILABLE CONFIGURED
0.6G
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1997 TAIS 7000dr.doc Rev. 6 04/04/00 nmm. Page 3 of 4
EQUIUM 7000D Product Specifications
COMPONENT
SERIES NAME EQUIUM 7000D
PART NUMBER As Listed: See Configuration Page
STORAGE
FDD
HDD (3.5”Half-height Enhanced IDE) As Listed: See Configuration Page
Type Removable, SMART, Ultra-DMA
Capacity options
Buffer 256KB
Access Time <9.7 msec
Ultra DMA Yes
Burst Data Transfer Rate Ultra DMA Mode2 (33.0MB/sec); PIO Mode 4 (16.7MB/sec)
Certifications SMART, UDMA-33, Energy Star
Controller Integrated (ATA-4)
CD-ROM: As Listed: See Configuration Page
Available options No CD-ROM, 32X CD-ROM or DVD-ROM
CD-ROM speed 32X
Interface ATAPI ( Enhanced IDE )
Random Access Time 85 ms
Sustained Data Transfer Rate 16,700 KB/sec (16.7MB/sec DMA Mode 1)
Supported Disk Formats Multisession Photo-CD, CD-Extra, CD-ROM XA, CD-I, Video CD, CD-G,
ETHERNET SUPPORT As Listed: See Configuration Page
Form Factor NSX Riser
Model
Chipset i82558
Support Network 100Base-TX, 10Base T
Port RJ 45 (with Connection Status LED and Ethernet Speed LED)
Wake on LAN Yes
KEYBOARD (PS/2) As Listed: See Configuration Page
Enhanced 104-key keyboard Yes Yes
Windows 95 support Yes Yes
Total Number of Hot Keys 14 None
Application Launch keys 6 Not Appli cable
CD keys 4 Not Applicable
Volume keys 3 No t Applicab le
Sleep keys 1 Not Applicable
3.5mm Travel Yes Yes
12 dedicated function keys Yes Yes
Numeric keypad Yes Yes
Keyboard tilt Yes Yes
Detatchable palm rest Yes No
Scroll Lock, CapsLock, NumLock Indicators Yes Yes
POINTING DEVICE
PS/2 Mouse Yes: 2 Button with 6 foot cable
3.5” 1.44MB Floppy Disk Drive
2.1GB; 3.2GB; 4.3GB (As Listed: See Configuration Page)
CD-I Ready, MPC-3 Compliant, Red Book, Yellow Book, Plug and Play
Intel EtherExpress PRO PCI
Mult-function Keyboard Option Value Keyboard Option
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1997 TAIS 7000dr.doc Rev. 6 04/04/00 nmm. Page 4 of 4
